SONA Electronics SE560 User Manual

SONA ELECTRONICS, L.L.C.

WORLDWIDE LEADER IN MANUFACTURING AND

DISTRIBUTION OF CONSUMER ELECTRONICS

P.O. Box 5370, Concord, NC 28027, USA

SONA ELECTRONICS, L.L.C.

WORLDWIDE LEADER IN MANUFACTURING AND DISTRIBUTION OF CONSUMER ELECTRONICS

P.O. Box 5370, Concord, NC 28027, USA

Tel: 704.721.7800 Toll Free: 1.866.766.2353 Fax: 704.721.7803

info@sona-vision.com www.sona-vision.com

HEADREST MONITORS

SE•560

5.6” Stand Alone or Headrest Monitor

• Best Mobile Video system with FAA approval

• Excellent Industry Design Tooling

• Thinnest Type, Highest Brightness among industry

• High resolution picture quality

• Compact design suitable for mounting into headrest

• Reverse Mirror function for rear view camera

• Earphone

• Video System:

• 2 Video Inputs

• Audio Output

• Left/Right x 2 (Stereo)

• Wireless Remote Control

• Operating Temperature 0 ~ + 65 ¢J

• Storage Temperature -25 ~ + 70 ¢J

• Special Reverse Mirror for parking

• Dimension… 140 (L) x 117 (W) x 13 (D) mm

SE•700

7” Stand Alone or

Headrest Widescreen (16:9) TFT Monitor

NTSC / PAL dual system

• Amorphous Active Matrix TFT

• Compact Design

• 2 Video Inputs

• OSD On Screen Display

• NTSC/PAL Auto Switching

• Headrest Shroud or Mounting Stand Kit Included

• Independent Color Video Display System

• Full Function Remote

• Compact Size

• Bright Picture

• Adjustable Brightness, Contrast, Color, Tint and Sharpness

• Universal Installation

• Resolution: 1440 (H) x 234 (V) dots

• Dimensions: 178 (L) x 135 (W) x 28 (D) mm

SE•701BR

7” Wide Screen (16:9) TFT Slim Design Headrest Monitor

• Amorphous Active Matrix TFT

• Built-in Auto On/Off Signal Switch

• Very Slim and Compact Design

• Compact Headrest Shroud

• 2 Video Inputs

• OSD On Screen Display

• NTSC System

• High Resolution Picture

• Slim Headrest Shroud Kit Included

• Mounting Stand Included

• Independent Color Video Display System

• Bright Picture

• Low Reﬂ ection Panel

• Universal Installation

• Easy Installation

• Resolution: 1440 (H) x 234 (V) dots

• Dimensions: 178 (W) x 112 (H) x 27 (D) mm

ROOF MOUNT MONITORS

SV•700

7” Wide Screen (16:9) Swivel TFT Roof Mount Video Monitor

• Smallest Roof Mount Monitor in the World

• Amorphous Active Matrix TFT

• Full Swivel to either direction

• 2 Video Inputs

• OSD On Screen Display

• NTSC/PAL Auto Switching

• Built-in Dual Dome Lights

• Independent Color Video Display System

• Full Function Remote

• High Resolution Picture

• Compact Size

• Reverse Image Picture

• Adjustable Brightness, Contrast, Color, Tint and Sharpness

• Universal Console Installation

• Resolution: 1440 (H) x 234 (V) dots

• Dimensions: 200 (L) x 170 (W) x 38 (D) mm

SV•1240

12.4” Wide Screen (4:3) Swivel TFT Roof Mount Video Monitor with IR Transmitter

• Amorphous Active Matrix TFT

• Built-in IR Transmitter

• Full Swivel to either direction

• 2 Video Inputs

• OSD On Screen Display

• NTSC/PAL Dual System

• Built-in Dual Dome Lights

• Overhead Console Bracket

• Independent Color Video Display System

• Full Function Remote

• High Resolution Picture

• Small Foot Print and Light Weight

• Adjustable Brightness, Contrast, Color, Tint and Sharpness

• Universal Console Installation

• Low Power Consumption

• Resolution: 800 (H) x 600 (V) = 480,000 dots

• Dimensions: 340 (H) x 310 (W) x 50 (D) mm

SV•850

8.5” Wide Screen Swivel Video Monitor

• Amorphous Active Matrix TFT Color Monitor

• Japanese Sharp High Quality Panel

• Built-in IR Transmitter for wireless headphones

• Light Weight/Slim Design

• High Resolution Picture (800x600 Dots)

• NTSC/PAL Auto Switch Format

• On Screen Display (OSD)

• Wide Angle Viewing

• Swivel 45 degrees left and right

• Dual Built-in Dome Lights

• Credit Card Size Remote

• Used as Monitor, Car Navigation System or Video Game Console

• 2 Video Inputs for DVD, VHS, GPS, Video Games

• Overhead ﬂ ip-down with complete mounting hardware

• Contrast ratio: 300:1

• Brightness: 500cd/M2 (NITS)

• Dimensions: 215x218x35 MM

SV•104F

10.4” Wide Screen TFT Roof Mount SWIVEL Video Monitor with built in IR Transmitter

• Amorphous Active Matrix TFT

• Full Swivel of monitor to either direction

• Built-in IR Transmitter

• 2 Video Inputs

• OSD On Screen Display

• NTSC/PAL Auto Switching, SECAM Available

• Built-in Dual Dome Lights

• Overhead Console Bracket

• Multi-Language Menu Support

• RCA Jack for Easy Installation

• Independent Color Video Display System

• Full Function Remote

• High Resolution Picture, Non Reﬂ ective TFT

• Very Compact Size

• Reverse Image Picture

• Adjustable Brightness, Contrast, Color, Tint and Sharpness

• Universal Console Installation

• Low Power Consumption

• Safety Certiﬁ cation: UL, FCC, CE, TUV

• Resolution: 800 (H) x 3 (RGB) x 600 (V) dots

• Dimensions: 268 (H) x 265 (W) x 40.8 (D) mm

SN•350RM

3.5” Swivel Roof Mount TFT-LCD Monitor

• HannStar New panel (wide angle view)

• TFT- LCD Color Monitor

• Automatic reverse trigger

• Screen Size: 3.5 inches

• Resolution(HxV): 480x234 dots

• CCFT Backlight

• 2 video inputs

• NTSC/PAL

• Adjustable Brightness and View

• Normal and/or mirror image

• Dimensions(LxHxD): 125mm*120mm*80mm

• Easy Installation

• Flip Down or Stand Alone Available

SV•114F

11.4” Wide Screen

TFT ROOF MOUNT SWIVEL VIDEO MONITOR

• Amorphous Active Matrix TFT

• 2 Video Inputs

• OSD On Screen Display

• NTSC/PAL Auto Switching, SECAM

• Built-in Dual Dome Lights

• Overhead Console Bracket

• Multi-Language Menu Support

• Composite Video (RCA Jack) x 2

• Independent Color Video Display System

• Full Function Remote

• High Resolution Picture, Non Reﬂ ective TFT

• Very Compact Size

• Adjustable Brightness, Contrast, Color, Tint and Sharpness

• Universal Console Installation

• Low Power Consumption

• Resolution: 800 (H) x 600 (V) =480,000 dots

• Dimensions: 268 (H) x 265 (W) x 40.8 (D) mm
