26.04.2022
200-0101
Art. No.:
Microphone Cable SC-Source MKII; 2 x 0,25
mm²; PVC Ø 6,50 mm; black
General Data
Article number :
200-0101
Name :
SC-Source MKII
EAN :
4049371004169
Properties :
Analog
Properties :
OFC oxygen free copper
Application area :
Stage / live
Application area :
Mobile outdoor / indoor
Application area :
Studio / Broadcast
Application area :
Installation
Application area :
ELA 100 V
Application :
Microphone Cable
Colour :
black
BPVo-Euroclass :
Fca
Technical Data
Signal transmission :
symmetrical
Construction :
(2LI2Y0,25mm²)(ST)DY
Jacket material :
PVC
Jacket Ø [mm] :
6,50
Number of Channels (audio) :
1
Inner conductor (audio) :
2
Inner conductor (audio) [mm²] :
0,25
Inner conductor Ø (audio) [mm] :
0,56
AWG (audio) :
23
Shielding :
copper spiral sleeve tin-plated
95 % + AL-fleece
Shielding factor [%] :
100
Copper strands (audio) :
128
Copper strand Ø (audio) [mm] :
0,05
Conductor insulation material :
PE
Conductor insulation Ø [mm] :
1,55
Weight per 1 m [g] :
48
UV-resistant :
yes
Fire load per m [kWh] :
0,21
Style variant :
round
Packing :
100 m spool
Packing :
500 m spool
Temperature min. [°C] :
-25
Temperature max. [°C] :
70
Width [mm] :
6,5
Height [mm] :
6,5
Electrical Data
Capac. cond./cond. per 1 m (audio) [pF] :
60
Capac. cond./shield. per 1 m (audio) [pF] :
110
Insulation resist. per 1 km [GΩ] :
0,2
Insulation resist. per 1 km (audio) [GΩ] :
0,2
Conductor resistance per 1 km [Ω] :
78
Shield. resistance per 1 km [Ω] :
25
