Page 1
11.02.2021
300-0011
Art. No.:
Instrument Cable SC-Silver Spirit; 1 x 0,22
mm²; Soft-PVC Ø 7,40 mm; black
General Data
Article number :
300-0011
Name :
SC-Silver Spirit
EAN :
4049371402958
Properties :
Ultrapure OFC copper, silver-
plated
Properties :
Analog
Application area :
Studio / Broadcast
Application area :
Mobile outdoor / indoor
Application area :
Installation
Application area :
Stage / live
Application :
Instrument Cable
Colour :
black
Technical Data
Construction :
LI2Y(LS)CY 1x0,22mm²
Jacket material :
Soft-PVC
Jacket Ø [mm] :
7,40
Number of Channels (audio) :
1
Inner conductor (audio) :
1
Inner conductor (audio) [mm²] :
0,22
Inner conductor Ø (audio) [mm] :
0,53
AWG (audio) :
24
Shielding :
Copper braiding tin-plated +
semiconductor
Copper strands (audio) :
28
Copper strand Ø (audio) [mm] :
0,10
Conductor insulation material :
Foam / Skin-PE
Conductor insulation Ø [mm] :
3,50
Weight per 1 m [g] :
73
UV-resistant :
yes
Style variant :
round
Packing :
100 m
Temperature min. [°C] :
-15
Temperature max. [°C] :
60
Width [mm] :
7,4
Height [mm] :
7,4
Electrical Data
Capac. cond./shield. per 1 m (audio) [pF] :
78
