30.03.2022
200-0151
Art. No.:
Microphone Cable SC-Primus; 2 x 0,50 mm²;
PVC Ø 6,70 mm; black
General Data
Article number :
200-0151
Name :
SC-Primus
EAN :
4049371001960
Properties :
Analog
Properties :
OFC oxygen free copper
Application area :
Stage / live
Application area :
Mobile outdoor / indoor
Application area :
Studio / Broadcast
Application area :
Installation
Application area :
ELA 100 V
Application :
Microphone Cable
Colour :
black
BPVo-Euroclass :
Fca
Technical Data
Signal transmission :
symmetrical
Construction :
(2LI2Y0,50mm²)(ST)DY
Jacket material :
PVC
Jacket Ø [mm] :
6,70
Number of Channels (audio) :
1
Inner conductor (audio) :
2
Inner conductor (audio) [mm²] :
0,50
Inner conductor Ø (audio) [mm] :
0,80
AWG (audio) :
20
Shielding :
Copper spiral sleeve tin-plated
+ metalic fleece
Shielding factor [%] :
100
Copper strands (audio) :
28
Copper strand Ø (audio) [mm] :
0,15
Conductor insulation material :
PE
Conductor insulation Ø [mm] :
1,65
Weight per 1 m [g] :
53,97
UV-resistant :
yes
Fire load per m [kWh] :
0,23
Style variant :
round
Packing :
100 m spool
Packing :
500 m spool
Temperature min. [°C] :
-25
Temperature max. [°C] :
70
Width [mm] :
6,7
Height [mm] :
6,5
Electrical Data
Capac. cond./cond. per 1 m (audio) [pF] :
80
Capac. cond./shield. per 1 m (audio) [pF] :
145
Insulation resist. per 1 km [GΩ] :
1
Insulation resist. per 1 km (audio) [GΩ] :
1
Conductor resistance per 1 km [Ω] :
37
Shield. resistance per 1 km [Ω] :
27
