02.01.2023
200-0351
Art. No.:
Patch & Microphone Cable SC-Goblin; 2 x 0,14
mm²; PVC Ø 4,60 mm; black
General Data
Article number :
200-0351
Name :
SC-Goblin
EAN :
4049371002059
Properties :
Analog
Properties :
OFC oxygen free copper
Application area :
Studio / Broadcast
Application area :
Installation
Application :
Patch & Microphone Cable
Colour :
black
BPVo-Euroclass :
Fca
Technical Data
Signal transmission :
symmetrical
Construction :
(2LI2Y0,14mm²)(ST)DY
Jacket material :
PVC
Jacket Ø [mm] :
4,60
Number of Channels (audio) :
1
Inner conductor (audio) :
2
Inner conductor (audio) [mm²] :
0,14
Inner conductor Ø (audio) [mm] :
0,42
AWG (audio) :
26
Shielding :
Copper spiral sleeve tin-plated
+ metalic fleece
Shielding factor [%] :
100
Copper strands (audio) :
18
Copper strand Ø (audio) [mm] :
0,10
Conductor insulation material :
PE
Conductor insulation Ø [mm] :
1,05
Weight per 1 m [g] :
27
UV-resistant :
yes
Fire load per m [kWh] :
0,1
Style variant :
round
Packing :
100 m spool
Temperature min. [°C] :
-25
Temperature max. [°C] :
70
Width [mm] :
4,6
[mm] :
4,6
Electrical Data
Capac. cond./cond. per 1 m (audio) [pF] :
65
Capac. cond./shield. per 1 m (audio) [pF] :
120
Insulation resist. per 1 km [GΩ] :
0,2
Insulation resist. per 1 km (audio) [GΩ] :
0,2
Conductor resistance per 1 km [Ω] :
140
Shield. resistance per 1 km [Ω] :
30
