Solo 416 Li Instruction Manual
9 416 108 ENGLISH 01/2015
416 Li
Instruction manual
Translation of the original
instructions
Important!
Read this instruction manual carefully
before first operation and strictly observe
the safety regulations!
Pressure sprayer
with rechargeable
battery
- ENGLISH - Pressure sprayer with rechargeable battery 416 Li
ENGLISH 2
Instruction manual
Translation of the original instructions
Caution!
Prior to operating the unit, please read
this instruction manual carefully, and most
importantly, observe all safety rules.
To ensure that your device will continue to work
properly and deliver optimum performance for
many years to come, ensure that you follow all
operating and maintenance instructions.
Your authorised SOLO dealer will be glad to assist
you with any questions.
EC declaration of conformity
The EC declaration of conformity on a separate
piece of paper forms part of these operating
instructions.
National requirements
The pressure sprayer may be subject to national
requirements for regular inspection by designated
bodies, as provided for in Directive 2009/128/EC
1
.
Packaging and disposal
Please keep the original packaging in order to
protect the equipment against transport damage in
case you ever need to ship it or transport it.
If the packaging materials are no longer required
then they must be disposed of properly in
accordance with applicable local regulations.
Cardboard packaging materials are raw materials
which can be recycled or reused.
At the end of the equipment's service life, please
make sure that you dispose of it properly in
accordance with the official directives and
regulations that apply in your area.
In the best interest of continued technological
progress we reserve the right to change the design
and configuration of any product without prior
notice.
For that reason, no claims can be accepted with
reference to text and illustrations in this manual.
1
Directive 2009/128/EC of the European Parlia-
ment and of the Council of 21 October 2009
establishing a framework for Community action
to achieve the sustainable use of pesticides
Symbols
The following symbols are used in this instruction
manual and on the device itself:
In the instruction manual:
Read the manual carefully.
DANGER! Failure to comply with the
instructions could cause accidents with
potentially life-threatening injuries.
Wear the prescribed protective clothing.
Wear protective gloves.
Wear face protection
(e.g., safety goggles).
Wear breathing mask.
Smoking prohibited.
No naked flames.
Minimum distance to bystanders:
15 m (approx. 16 yards)
On the device:
Pump toggle switch (12):
Pump switched on for low operating
pressure (setting I), with standard nozzle:
approx. 2.46 bar [35.7 psi]
Pump switched off (setting "O")
Pump switched on for high operating
pressure (setting II), with standard nozzle:
approx. 4.3 bar [62.4 psi]
Electrical equipment must not be disposed
of as normal domestic waste.
Ensure that the device and all electrical
accessories are disposed of or recycled at
an official disposal or recycling facility for
electrical equipment.
ENGLISH 3
Table of contents
1 Wearing parts ............................................................................................................................................ 4
2 Warranty .................................................................................................................................................... 4
3 Safety regulations ..................................................................................................................................... 4
3.1 Correct use / areas of application 4
3.2 General safety instructions 5
3.3 Work clothing / personal protection equipment (PPE) 5
3.4 Safe handling of spraying agents 6
3.5 Safe handling of the rechargeable battery and the charger 6
3.6 Transportation of the device 7
3.7 Before and during work 7
3.8 Maintenance, repairs and storage 7
4 Type plate .................................................................................................................................................. 8
5 Operating and functional components ................................................................................................... 8
6 Preparing the device for use ................................................................................................................. 10
6.1 Assembly 10
6.2 Spray nozzle, ball valve filter and filling strainer 10
6.3 Charging the battery 11
6.4 Adjusting the carrying straps 11
6.5 Trial run 11
7 Mixing spraying agents and filling the spraying agent tank ............................................................... 12
8 Using the pressure sprayer ................................................................................................................... 13
8.1 Spraying 13
8.2 Residual spraying agents / finishing spraying 14
9 Maintenance, cleaning and storage ...................................................................................................... 14
9.1 General operating and maintenance instructions 14
9.2 Trial run 14
9.3 Checking th
e spray nozzles and the ball valve filter by measuring the spraying agent delivery rate
14
9.4 Changing the spray nozzle and the ball valve filter 15
9.5 Information on using the rechargeable battery 15
9.6 Replacing the fuse 15
9.7 Greasing the cap gasket 15
9.8 Draining the spraying agent tank and cleaning the spraying agent carrying parts 15
9.9 Taking the sprayer out of service and putting it into storage 16
10 Maintenance plan .................................................................................................................................. 17
11 Standard delivery .................................................................................................................................. 17
12 Specification and special accessories ............................................................................................... 18
13 Specification of spray nozzles............................................................................................................. 19
1 Wearing parts / 2 Warranty / 3 Safety regulations
ENGLISH 4
1 Wearing parts
Various parts are subject to application-specific
wear or to normal wear and must be replaced in
good time if necessary.
The following parts are subject to normal wear and
are not covered by the manufacturers guarantee:
All rubber parts that come into contact with the
spraying agent
Spray nozzle
Filters
Seals
Rechargeable battery
Fuse
2 Warranty
We warrant problem free quality and will cover the
cost of replacing parts which are found to be faulty
in material or show manufacturing defects within
the prescribed guarantee period after the date of
purchase.
Please note that specific guarantee conditions may
differ from country to country.
When in doubt, please ask the vendor of the
goods. The vendor of the product is responsible for
guarantee applications.
We hope you will understand that we cannot be
liable for damage resulting from these causes:
Non-compliance with operating instructions.
Neglecting required maintenance and repair
jobs.
Wear from normal use (particularly: gasket
seals, membranes, collars, spray nozzles and
filters).
Using non-approved tools.
Use of force, improper treatment, misuse and
accidents.
Attempted adjustments and repairs by
non-qualified persons.
Unauthorized modification or changes made to
the device.
Use of unsuitable spare parts or non-genuine
parts if such parts are the cause of the damage.
Use of non-approved media in the spraying
agent tank.
Damage caused by using the product in the hire
or rental industry.
Normal cleaning, adjustments or maintenance jobs
cannot be claimed as part of the guarantee.
All guarantee work must be carried out by one of
our authorised service centres.
3 Safety regulations
3.1 Correct use / areas of application
This pressure sprayer must only be used for the
purpose of applying approved liquid plant
protection agents, pesticides, insecticides, weed
killer (herbicides) and liquid fertilizers available
from authorised specialist dealers as well as for
the purpose of applying clean water.
Observe all instructions provided by the spraying
agent manufacturer.
We recommend using only spraying agents that
have been approved for use as spraying agent
for the above mentioned areas of application by
the relevant authorities in your country.
The pressure sprayer must only be used for
applications in agriculture, tree nurseries,
forestry, fruit and vegetable growing, vineyards,
home and garden and greenhouse cultivation
with adequate ventilation.
The pressure sprayer must not be used for any
other purposes, e.g., for the spraying of liquid
paint or applying any other media than the
above mentioned liquids!
Particularly, aggressive, acid- or solventcontaining liquids, disinfectants or impregnating
agents must not be sprayed with this device!
Never use fluids with a temperature in excess of
40 °C [104 °F].
To enable the operator in connection with the
spraying agent manufacturer to check the
material resistance to certain chemicals, we will
provide details of the type of materials used for
the pressure sprayer.
3 Safety regulations
ENGLISH 5
3.2 General safety instructions
Please take the time to carefully read
through these operating instructions
before using the device for the first time and keep
them in a safe place thereafter.
Always take great care when using the device.
You can put your life at risk by failing to follow the
safety instructions.
It is also important to follow any relevant health and
safety regulations that apply to your place of work.
Anyone who fails to follow the safety instructions,
operating instructions or maintenance instructions
will make themselves liable for any damage and
consequential damage caused as a result.
The operating instructions must be kept available
at all times wherever the device is used or stored.
They must be read by anyone instructed to use the
equipment or perform work with or on the device
(including servicing, maintenance and repairs).
A first time operator should obtain practical
instruction by an authorised SOLO dealer before
using the equipment.
Persons under the age of 18 are only permitted
to use this plant protection device under
supervision.
Keep persons and animals away from areas in
which you are working. Never spray in the
direction of other persons, animals or objects
that could be damaged as a result. Bear in mind
that the liquid emerges at high speed from the
spray nozzle. Objects could be kicked up as a
result, and this could in some cases represent a
risk. The user is responsible for any hazards or
accidents involving other persons and/or their
property.
This equipment must only be hired out, lent or
passed on to persons who are familiar with this
type of equipment and its operation and who
have read the operating instructions. Always
ensure that you hand over the operating
instructions together with the device.
Ensure that you are in good shape, well rested
and healthy when using this device.
Do not use this device, if you are tired or sick.
Never use this device under the influence of
alcohol, drugs or medication that could impair
your reaction speed.
Never alter, change or modify any safety
equipment or operating controls.
Never use the device if any part of it is unsafe or
if it is not in an overall condition that makes it
safe to use. Before using the device always
check whether it is safe to use according to
section 10.
Immediately replace damaged parts. Only use
genuine SOLO replacement parts.
Only use accessories and add-on parts that
have been supplied and specifically approved for
installation on the device by us.
The quality of any spare parts used is also an
important factor in ensuring that your device is
reliable and safe to use. Always use genuine
SOLO replacement parts, as these are the only
parts that have been manufactured with the
same equipment and under the same conditions
as the parts originally fitted to the device. This
ensures the highest possible level of quality and
accuracy of fit – vital factors in ensuring the
safety, reliability and proper functioning of your
device. Genuine SOLO replacement parts and
accessories are available from your authorised
SOLO dealer. He also has access to the necessary spare parts lists, from which the required
part numbers can be taken, and he will also be
kept up to date about any minor improvements
and changes to the range of parts on offer.
Please note that the use of non-genuine
replacement parts will invalidate your warranty.
When the device is not being used it should be
safely stored in a place where it will not endanger the health and safety of others. Prepare the
device for storage according to section 9.8.
Ensure that the device is stored in a safe place
where unauthorised persons cannot access it.
3.3 Work clothing /
personal protection equipment (PPE)
Always wear suitable protective clothing in
accordance with the relevant regulations. The
clothing must protect all parts of your body against
contact with spraying agents and against objects
that are kicked up – i.e., protective gloves, face
protection (e.g., protective goggles), protective
footwear, body protection (e.g., rubber apron), if
required breathing protection.
Clothing should be appropriate – i.e., tight-fitting,
but not obstructive.
Wear protective shoes with good grip, preferably
safety shoes.
Wear protective gloves with non-slip
palms.
Wear face protection (e.g., safety goggles)
against the spraying agents.
Always wear a breathing mask when
working in dense and tall plants, in
greenhouses, in dips in the ground or in
trenches and when using dangerous
spraying agents.
Immediately change any clothing that becomes
soaked with the spraying agent.
Wash the work clothing regularly.
Never wear a scarf, tie, loose jewellery or other
items of clothing that could be caught in a bush
or on a branch.
3 Safety regulations
ENGLISH 6
3.4 Safe handling of spraying agents
Avoid contaminating the environment, the mains
water supply and/or public sewer systems with
spraying agent or cleaner!
Ensure to avoid contamination when mixing,
filling, using, draining, cleaning, servicing and
transporting by using adequate procedures and
suitable containers.
Spraying agents and cleaners must never be
allowed to enter the mains water supply – not
even by back-suction when filling, public sewer
systems, sprayed onto wastelands, allowed to
drain into natural bodies of water or disposed of
together with normal domestic waste. This also
means that appropriate care must be taken
during filling to ensure that none of the spraying
agent is drawn back into water pipes. Spraying
agents and cleaners and any unused leftovers of
spraying agents and cleaners must always be
collected in a suitable container and disposed of
via approved facilities for household chemical
waste. Please contact your local authorities for
information about your nearest disposal facilities.
Avoid any direct contact with spraying agents.
In case of contact with health hazardous spraying agents, immediately rinse the affected body
parts with plenty of clean water, immediately
change the clothing soaked with spraying agents
and immediately seek medical advice.
Never eat or drink when handling spraying
agents.
Stop working immediately if you start to feel
unwell while working, or if you become unusually
tired. Seek medical advice if the condition
persists.
Never allow children or anybody who is not
familiar with handling this type of spraying agent
to handle the spraying agent.
Clean the spraying agent tank and all other
spraying agent carrying parts whenever the
spraying agent is changed. To flush out any
residue from the pump and the hose, run the
pressure sprayer with clean water after cleaning
the spraying agent tank and before the next
spraying agent is filled in. This will prevent the
risk of any chemical reactions taking place
between the different substances.
Never spray in narrow or enclosed spaces –
spraying agents are toxic and there is a risk of
poisoning. Spraying equipment must for
example only be used in greenhouses if
adequate ventilation is provided. Signs must be
put up in greenhouses that have been treated.
Nobody should enter the greenhouse again until
it has been thoroughly ventilated.
When you have finished spraying, prepare the
device for storage according to section 9.8,
thoroughly wash your face and hands with soap,
take off your work clothing and ensure that it is
washed regularly.
Any unused spraying agent that is left over in the
device could cause corrosion and hence
damage the device. Special attention must be
paid to wearing parts like spray nozzles, filters
and seals.
3.5 Safe handling of the rechargeable battery
and the charger
The charger must only be connected to a mains
supply with an operating voltage between 100V
and 240V AC 50/60Hz. It must only be
connected using the correct adapter plugs.
- Check that the mains voltage is correct
before connecting the device.
- Use the correct mains adapter plug.
- The charger must not be connected to the
mains supply in countries for which no
matching mains adapter plug is supplied
together with the backpack sprayer or in
countries where the mains voltage differs
from the operating voltage of the charger.
In this case you should contact a local
dealer to enquire about options for
connecting the charger to the mains
supply.
Always hold the charger itself to push it into the
electrical socket or to pull it out. Never pull on
the cable.
The charger is only designed to recharge the
rechargeable battery that is supplied by SOLO
for this pressure sprayer. Ensure that the battery
is always correctly connected to the charger
before charging.
Always switch off the pump when the charger is
connected.
Never connect the two terminals of the
rechargeable battery (+ / -) with a conducting
object (short circuit).
Keep the charger, the rechargeable battery and
all of the electronics well away from splash
water. These areas should only be cleaned with
a dry or slightly damp cloth. Before cleaning,
always disconnect the power plug from the
socket and the charging cable from the charging
socket on the device.
The rechargeable battery contains dangerous
substances. Never open the battery or the
charger.
Only use the genuine charger to recharge the
battery.
The rechargeable battery and the charger must
not be disposed of as normal domestic waste.
Ensure that you take them to an official disposal
facility for electrical equipment.
Loading...
