Soleus Air HGW-308R User Manual

HGW-308R Wall Mountable

Micathermic Heater w/ Remote

3092402

Model No. HGW-308R

© 2007 Soleus Air International

Thank you for choosing a Soleus Air Micathermic heater. This owner’s manual will provide you with
valuable information necessary for the proper care and maintenance of your new product. Please take
a few moments to thoroughly read the instructions and familiarize yourself with all the operational
aspects of your new Soleus Air Micathermic heater.

For your own records, please attach a copy of your sales receipt to this manual. Also, write the store
name/location, date purchased, and serial number below:

Store Name: ____________________________________________________

Location: ______________________________________________________

Date Purchased: _________________________________________________

Serial Number (located on back of unit): ______________________________

IMPORTANT INSTRUCTIONS

Before using your Soleus Air personal heater, please read this owner’s manual carefully. Store this manual in a
safe place for future reference.

1. Read ALL instructions before using this unit.

2. CAUTION: Risk of Electric Shock. DO NOT open or try to repair the heater yourself.

3. This heater is hot when in use. To avoid burns, DO NOT let bare skin touch hot surfaces. If provided,
use handles when moving this heater.

4. Keep combustible materials, such as furniture, pillows, bedding, paper, clothes, and curtains at least 3
ft from the front of the heater and keep them away from the sides and rear. DO NOT place towels or
other objects on the heater.

5. Extreme caution is necessary when any heater is used by or near children or the disabled, or when the
heater is left operating and unattended.

6. DO NOT operate any heater with a damaged cord or after the heater malfunctions, has been dropped
or damaged in any manner. Return heater to authorized service facility for examination, electrical or
mechanical adjustment, or repair.

7. This heater is not intended for use in bathrooms, laundry areas and similar indoor locations. NEVER
locate heater where it may fall into a bathtub or other water container. To protect against electrical
hazards, DO NOT immerse in water or other liquids.

8. DO NOT touch the control panel or plug with a wet hand.

9. DO NOT run cord under carpeting. DO NOT cover cord with throw rugs, runners, or similar
coverings. Arrange cord away from traffic area and where it will not be tripped over.

10. DO NOT insert or allow foreign objects to enter any ventilation or exhaust opening as this may cause
an electric shock or fire, or damage the heater.

11. To prevent a possible fire, DO NOT block air intakes or exhaust in any manner. DO NOT use on soft

surfaces, like a bed, where openings may become blocked.

2

12. A heater has hot and arcing or sparking parts inside. DO NOT use in areas where gasoline, paint,
explosive and/or flammble liquids are used or stored. Keep unit away from heated surfaces and open
flames.

13. Avoid the use of an extension cord because the extension cord may overheat and cause a risk of fire.
However, if you have to use an extension cord, the cord shall be No16.AWG minimum size and rated
not less than 1500W.

14. To avoid fire or shock hazard, plug the unit directly into a 120 V AC electrical outlet.

15. To disconnect heater, turn controls to OFF, then remove plug from outlet. Pull firmly on the plug, DO
NOT unplug by pulling on the cord.

16. Always unplug the unit before moving or cleaning, or whenever the heater is not in use.

17. Use only for intended household use as described in this manual. Any other use not recommended by
the manufacturer may cause fire, electric shock, or injury to persons. The use of attachments not rec­ommended or sold by unauthorized dealers may cause hazards.

18. Always use on a dry, level surface.

19. DO NOT use outdoors.

20. WARNING: To reduce the risk of fire or electric shock, DO NOT use this unit with any solid-state
speed control device.

21. DO NOT attempt to repair or adjust any electrical or mechanical functions on this unit. Doing so will
void your warranty. The inside of the unit contains no user serviceable parts. Qualified personnel
should perform all servicing only.

22. Connect to properly grounded outlets only.

23. SAVE THESE INSTRUCTIONS.

PRODUCT INFORMATION & SPECIFICATIONS

Micathermic heating technology combines two popular heating technologies to create the ideal room heater.
Using radiant and convection heat, Micathermic heaters are able to achieve full power within minutes and
provide a consistent and comfortable silent heat without causing dry spots.

Voltage Rating 120 V (60Hz)

Power Consumption 1000 (ECO) /1000 (LOW) /1500W (HIGH)

Unit Size 24.6 in. (W) x 8.5 in. (D) x 22.5 in. (H)

Unit Weight 11 lbs

DISCLAIMER

ALL INFORMATION AND THE TECHNICAL SPECIFICATIONS PRESENTED IN THIS USER’S MANUAL ARE THE
PRESENTATION OF THE MANUFACTURER. SOLEUS INTERNATIONAL HAS NOT CONDUCTED INDEPENDENT
TEST TO THE INFORMATION AND THE SPECIFICATIONS PRESENTED HEREWITHIN.

3

SAFETY FEATURES

Tip-Over Safety Feature

This heater is equipped with a tip-over safety feature. Once the heater is tipped over, an internal switch will
automatically shut the heater off. Once the heater is restored to an upright position, the heater will reset. To
continue operation, turn on the heater using the supplied remote control or the control panel on the heater.

Overheat Safety Feature

This heater is equipped with a overheat safety feature. When the heaters internal components reach a certain
temperature that could cause overheat and possible fire, the heater will automatically shut off. To reset the
heater, unplug the heater power cord from the electrical outlet for 10 minutes. After 10 minutes, plug the
heater into the electrical outlet and turn on using the supplied remote control or the control panel on the heater.

WARNING: This heater is for use on 120 volts. The

cord has a plug as shown in A. An adapter as shown in
C is available for connecting three-blade grounding­type plugs to two-slot receptacles. The grounding lug
extending from the adapter must be connected to a
permanent ground such as a properly grounded outlet
box. The adapter should not be used if a three-slot
grounded receptacle is available.

DO NOT DEFEAT THE SAFETY PURPOSE OF
THE GROUNDED PLUG.

WARNING: It is normal for the power cord to feel warm to the touch; however, a loose fit between the outlet
and the plug may cause overheating of the plug. If this occurs, try inserting the plug into a different outlet.
Contact a qualified electrician to inspect the original outlet for damage.

IN THE BOX

• MICATHERMIC HEATER

• REMOTE CONTROL

• REMOTE CONTROL BATTERY

• INSTRUCTION BOOKLET

• WALL MOUNTING BRACKET

• 4 - DRY WALL ANCHORS

• 4 - MOUNTING SCREWS

• 2 - LEGS

• 2 - LEG SCREWS

• 2 - MEDIUM BLACK SPRING WASHERS

• 2 - MEDIUM GREY WASHERS

• 4 - WHEELS

• 4 - WHEEL SCREWS

• 4 - SMALL BLACK SPRING WASHERS

• 4 - SMALL GREY WASHERS
