Installation Guide
Smart EV Charger
with SetApp Configuration
For North America
Version 1.1
1 Disclaimers
Disclaimers
Important Notice
Copyright © SolarEdge Inc. All rights reserved.
No part of this document may be reproduced, stored in a retrieval system or
transmitted, in any form or by any means, electronic, mechanical, photographic,
magnetic or otherwise, without the prior written permission of SolarEdge Inc.
The material furnished in this document is believed to be accurate and reliable.
However, SolarEdge assumes no responsibility for the use of this material. SolarEdge
reserves the right to make changes to the material at any time and without notice. You
may refer to the SolarEdge web site (https://www.solaredge.com/us/) for the most
updated version.
All company and brand products and service names are trademarks or registered
trademarks of their respective holders.
Patent marking notice: see https://www.solaredge.com/us/patent
The general terms and conditions of delivery of SolarEdge shall apply.
The content of these documents is continually reviewed and amended, where
necessary. However, discrepancies cannot be excluded. No guarantee is made for the
completeness of these documents.
The images contained in this document are for illustrative purposes only and may vary
depending on product models.
Smart EV Charger Installation MAN-01-00657-1.1
Disclaimers 2
FCC Compliance
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, you are encouraged to try to correct
the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and the receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party responsible for
compliance may void the user’s authority to operate the equipment.
Smart EV Charger Installation MAN-01-00657-1.1
3 Revision History
Revision History
Version 1.1 July 2020
Added a step for grounding in the 'Directly Connecting the AC Grid to the Smart EV
Charger' procedure
Modified LED ring and buzzer indications
RS485 connection - changed master/slave to leader /follower
Connecting the AC cable between the Single phase inverter with HD-Wave
technology and the Smart EV Charger - various modifications
Connecting the Smart EV Charger to the Single phase inverter with HD-Wave
technology- various modifications
Added steps for using wire ferrules in the 'Directly Connecting the AC Grid to the
Smart EV Charger 'procedure
Modified the Smart EV Charger push button functionality table
Modified Wi-Fi section in Communication Options
NEMA 6-50 removed
Version 1.0 , December 2019 - first release
Smart EV Charger Installation MAN-01-00657-1.1
Contents 4
Contents
Disclaimers 1
Important Notice 1
FCC Compliance 2
Revision History 3
Contents 4
HANDLING AND SAFETY INSTRUCTIONS 6
Safety Symbols Information 6
RISK OF FIRE AND ELECTRIC SHOCK PREVENTION
IMPORTANTSAFETYINSTRUCTIONS 7
Smart EV Charging Safety Instructions 12
Chapter 1: Introduction to Smart EV Charger 13
Packages Contents and Required Equipment 14
Chapter 2: Connectors and Interfaces 15
Buzzer 17
Main Procedures 18
Chapter 3: Configuring and Using Smart EV Charger with mySolarEdge 21
Using mySolarEdge 21
Chapter 4: Charging Instructions 22
Chapter 5: Professional Installer- Connecting the AC Directly to the Smart
EVCharger 23
Required Equipment 23
Main Procedure 23
Grid Connection Guidelines 23
Setting the Circuit Breaker Ratings 23
Supported ACGrids 25
Removing the Smart EV Charger Covers 25
Disconnecting the AC Plug 27
Directly Connecting the AC Grid to the Smart EV Charger 28
Connecting the Smart EV Charger to the Single phase inverter with HD-Wave
technology 30
Prerequisites 30
Kit Contents 30
Required Equipment 30
Main Procedure 30
Removing the DC Safety Unit Cover and Opening the Conduit Drill Guides 31
Replacing the AC terminal Blocks, Inside the DC Safety Unit 32
Replacing the Bus Bar, inside the DC Safety Unit 34
Smart EV Charger Installation MAN-01-00657-1.1
5 Contents
Connecting the AC cable Between the Single Phase inverter with HD-Wave
Technology and the Smart EV Charger 34
Connecting RS485 between the Single Phase Inverter with HD-Wave Technology
and the Smart EV Charger 35
Closing the Smart EV Charger Covers 38
Setting the Circuit Breaker Limit Value 40
Verifying that the EV is Charging 41
Closing the Smart EV Charger Covers 41
Chapter 6: Professional Installer - Setting Up Communication 42
Communication Options 42
Communication Connectors 43
Creating an Ethernet (LAN) Connection 44
Creating an RS485 Bus Connection to SolarEdge Inverter or Gateway 48
RS485 Bus Configuration 48
Verifying the Connection to the Monitoring Platform 49
Chapter 7: Processional Installer - Configuring and Using Smart EV Charger with
SetApp 50
Configuring the Smart EV Charger 50
Configuring Communication Options 50
Viewing Communication Status 51
Chapter 8: Errors and Troubleshooting 52
Appendix A: Professional Installer - Connecting the Smart EV Charger to an
Energy Meter 55
Energy Meter DIPSwitches 55
Mechanical Specifications 58
Technical Specifications - Smart EV Charger (North America) 59
Support Contact Information 61
55
Smart EV Charger Installation MAN-01-00657-1.1
HANDLING AND SAFETY INSTRUCTIONS 6
HANDLING AND SAFETY INSTRUCTIONS
During installation, testing and inspection, adherence to all the handling and safety
instructions is mandatory. Failure to do so may result in injury or loss of life and
damage to the equipment.
Safety Symbols Information
The following safety symbols are used in this document. Familiarize yourself with the
symbols and their meaning before installing or operating the system.
WARNING!
Denotes a hazard. It calls attention to a procedure that, if not correctly
performed or adhered to, could result in injury or loss of life. Do not proceed
beyond a warning note until the indicated conditions are fully understood and
met.
AVERTISSEMENT!
Dénote un risque: il attire l'attention sur une opération qui, si elle n'est pas faite
ou suivi correctement, pourrait causer des blessures ou un danger de mort. Ne
pas dépasser une telle note avant que les conditions requises soient
totallement comprises et accomplies.
CAUTION!
Denotes a hazard. It calls attention to a procedure that, if not correctly
performed or adhered to, could result in damage or destruction of the
product. Do not proceed beyond a caution sign until the indicated conditions
are fully understood and met.
ATTENTION!
Dénote un risque: il attire l'attention sur une opération qui, si elle n'est pas faite
ou suivi correctement, pourrait causer un dommage ou destruction de
l'équipement. Ne pas dépasser une telle note avant que les conditions requises
soient totallement comprises et accomplies.
NOTE
Denotes additional information about the current subject.
IMPORTANTSAFETYFEATURE
Denotes information about safety issues.
Smart EV Charger Installation MAN-01-00657-1.1
7 RISK OF FIRE AND ELECTRIC SHOCK PREVENTION
IMPORTANTSAFETYINSTRUCTIONS
RISK OF FIRE AND ELECTRIC SHOCK PREVENTION
IMPORTANTSAFETYINSTRUCTIONS
SAVETHESEINSTRUCTIONS
PRÉVENTION DES RISQUES D'INCENDIE ET D'ÉLECTROCUTION
CONSIGNES DE SÉCURITÉ IMPORTANTES
CONSERVEZ CES INSTRUCTIONS
Warning!
When using electric products, basic precautions should always be followed,
including the following. This manual contains important instructions that shall
be followed during installation, operation and maintenance of the unit.
a. Read all the instructions before using this product.
b. This device should be supervised when used around children.
c. Do not put fingers into the electric vehicle connector.
d. Do not use this product if the flexible power cord or EV cable is frayed, has
broken insulation, or any other signs of damage.
e. Do not use this product if the enclosure or the EV connector is broken,
cracked, open, or shows any other indication of damage.
f. Flexible cord use in accordance with CE code, Part I,Rule 4-012, is to be
determined by the local inspection authority having jurisdiction.
1. An insulated grounding conductor that is identical in size, insulation
material, and thickness to the grounded and ungrounded branch-circuit
supply conductors, except that it is green with or without one or more
yellow stripes, shall be installed as part of the branch circuit that supplies the
device or system.
2. The grounding conductor described in item 1 shall be grounded to earth at
the service equipment or, when supplied by a separately derived system, at
the supply transformer.
AVERTISSEMENT!
Des mesures de précautions de base devraient être utilisées avec tous les
produits électriques, y compris les mesures indiquées ici. Ce manuel contient
d’importantes instructions à suivre au moment de l’installation, de l’utilisation et
de l’entretien de l’appareil.
a. Lire toutes les instructions avant d’utiliser ce produit.
Smart EV Charger Installation MAN-01-00657-1.1
RISK OF FIRE AND ELECTRIC SHOCK PREVENTION
IMPORTANTSAFETYINSTRUCTIONS 8
b. Ce dispositif ne devrait pas être laissé sans surveillance s’il est utilisé près
d’enfants.
c. Ne pas mettre les doigts dans la prise du véhicule électrique.
d. Ne pas utiliser ce produit si le cordon souple ou le câble VE est effiloché, si
l’isolant est endommagé, ou s’il présente tout autre signe
d’endommagement.
e. Ne pas utiliser ce produit si le boîtier ou la prise EV est endommagé, fissuré,
ouvert, ou s’il présente tout autre signe d’endommagement.
f. L'utilisation du cordon flexible doit être conforme à la règle 4-012 de la
partie I du code CE et doit être déterminée.
1. Un conducteur de mise à la terre isolé dont les dimensions, le matériau
d'isolation et l'épaisseur sont identiques aux conducteurs d'alimentation de
circuit de dérivation mis à la terre et non mis à la terre, sauf qu'il est vert avec
ou sans une ou plusieurs bandes jaunes circuit qui alimente l'appareil ou le
système.
2. Le conducteur de mise à la terre décrit à l'article 1 doit être relié à la terre à
l'équipement de service ou, lorsqu'il est alimenté par un système dérivé
séparément, au transformateur d'alimentation.
WARNING!
Before operating the Smart EV Charger, ensure that the Smart EV Charger is
grounded properly. This product must be connected to a grounded, metal,
permanent wiring system, or an equipment-grounding conductor must be run
with the circuit conductors and connected to the equipment grounding
terminal or lead on the product.
AVERTISSEMENT!
Avant d'utiliser Smart EV Charger monophasé, assurez-vous que Smart EV
Charger est correctement mis à la terre. Ce produit doit être raccordé à un
système de câblage fixe, métallique, l'équipement-le conducteur de mise à la
terre doit être exécuté avec les conducteurs de circuit et raccordé à
l'équipement borne de mise à la terre ou de plomb sur le produit.
NOTE
Use only copper conductors rated for a minimum of 167°F.
NOTE
The symbol appears at grounding points on the SolarEdge equipment. This
symbol is also used in this manual.
Smart EV Charger Installation MAN-01-00657-1.1
9 RISK OF FIRE AND ELECTRIC SHOCK PREVENTION
IMPORTANTSAFETYINSTRUCTIONS
WARNING!
The Smart EV Charger must be connected to a dedicated AC branch circuit with
a maximum Overcurrent Protection Device (OCPD) of 50A.
WARNING!
Le chargeur EV intelligent doit être connecté à un circuit AC dedié avec un
protecteur de surtension de 50A.
Smart EV Charger Installation MAN-01-00657-1.1
RISK OF FIRE AND ELECTRIC SHOCK PREVENTION
IMPORTANTSAFETYINSTRUCTIONS 10
WARNING!
SolarEdge products can expose you to chemicals including antimony trioxide,
which is known to the State of California to cause cancer. For more information,
go to www.P65Warnings.ca.gov .
AVERTISSEMENT!
Les produits SolarEdge peut vous exposer à des agents chimiques, y compris
trioxyde d'antimoine, identifiés par l'État de Californie comme pouvant causer le
cancer. Pour de plus amples informations, prière de consulter
www.P65Warnings.ca.gov.
CAUTION!
This unit must be operated according to the technical specification datasheet
provided with the unit.
ATTENTION!
Cette unité doit être utilisée selon les spécifications de fonctionnement, comme
décrit dans la dernière fiche technique des spécifications.
NOTE
This Smart EV charger s provided with an IMI (Isolation Monitor Interrupter) for
ground fault protection
NOTE
Ce chargeur pour Véhicule électrique est fourni avec un interrupteur de
moniteur d’isolation (IMI) pour la protection contre les défauts à la terre
NOTE
The Smart EV Charger is NEMAtype 3R rated . Unused conduit entry and glands
should be sealed with appropriate seals.
NOTE
The local inspection authority having jurisdiction will determine if the Smart EV
Charger power cord connected to the outlet is suitable for use in accordance
with CE code, part I, rule 4-012.
NOTE
C’EST À L’AUTORITÉ LOCALE COMPÉTENTE EN MATIÈRE D’INSPECTION
QU’INCOMBE DE DÉTERMINER SI UN CORDON SOUPLE PEUT ÊTRE UTILISÉ
CONFORMÉMENT À L’ARTICLE 4-012 DU CCÉ,PREMIÈRE PARTIE
WARNING!
Risk of electric shock. Do not remove cover. No user serviceable parts inside.
Refer servicing to qualified service personnel.
AVERTISSEMENT!
Risque de choc électrique. Ne pas retirer le couvercle. Pas de pièces sujettes à
maintenance. Laissez la maintenance à du personnel qualifié.
Smart EV Charger Installation MAN-01-00657-1.1
11 RISK OF FIRE AND ELECTRIC SHOCK PREVENTION
IMPORTANTSAFETYINSTRUCTIONS
Grounding Instructions
This product must be grounded. If it should malfunction or break down,
grounding provides a path of least resistance for electric current to reduce the
risk of electric shock. This product is equipped with a cord having an equipment
grounding conductor and a grounding plug. The plug must be plugged into an
appropriate outlet that is properly installed and grounded in accordance with all
local codes and ordinances.
CONSIGNES DE MISE À LA TERRE
Ce produit doit être mis à la terre. En cas de mauvais fonctionnement ou de
rupture, la mise à la terre offre un trajet de moindre résistance au courant
électrique ce qui réduit le risque de chocélectrique. Ce produit est munid’un
cordon contenant unconducteur et une fiche demise à la terre. La fiche doit être
introduite dans une prise appropriée, installée correctement et mise à la terre
conformément aux codes et règlements locaux
WARNING!
Improper connection of the equipment-grounding conductor might result in a
risk of electric shock. Check with a qualified electrician or serviceman if you are
in doubt as to whether the product is properly grounded. Do not modify the
plug provided with the product – if it will not fit the outlet, have a proper outlet
installed by a qualified electrician.
AVERTISSEMENT
Une mauvaise connexion du conducteur de mise à la terre peut présenter un
risque de choc électrique. Consultez un électricien ou un technician qualifié si
vous avez des doutes quant à la qualité de la mise à la terre. Ne pas modifier la
fiche qui équipe le produit – si elle ne convient pas à la prise, faire installer une
prise appropriée par un électricien qualifié.
Smart EV Charger Installation MAN-01-00657-1.1
Smart EV Charging Safety Instructions 12
Smart EV Charging Safety Instructions
WARNING!
Do not charge a vehicle indoors if it requires ventilation. Contact your EV service
representative for information.
AVERTISSEMENT!
Ne pas recharger un véhicule à l’intérieur si il nécessite une ventilation.
Contactez votre représentant de service pour plus d’informations.
WARNING!
Automatic CCID (charge circuit interrupting device) reset provided.
AVERTISSEMENT!
Réinitialisation CCID (charge circuit interrupting device) automatique incluse.
CAUTION!
Do not use this product if there is any damage to the unit.
ATTENTION!
Ne pas utiliser pas ce produit si l'appareil est endommagé.
CAUTION!
Do not use an extension cord between the Smart EV Charger Cable and the
Smart EV Charger. You may use a conversion adapter only if it has been
approved by SolarEdge.
ATTENTION!
Ne pas utiliser de rallonge entre le câble du chargeur EV SolarEdge et Smart EV
Charger. Vous ne pouvez utiliser un adaptateur de conversion que s'il a été
approuvé par SolarEdge
Smart EV Charger Installation MAN-01-00657-1.1
13 Chapter 1: Introduction to Smart EV Charger
Chapter 1: Introduction to Smart EV Charger
The Smart EV Charger is designed to provide reliable and economical charging of an
electric vehicle (EV). It provides Level 2 EV charging from the AC and the PV system, and
is designed to work with all plug-in vehicles with J1772 (Type 1) socket.
The Smart EV Charger is also used for hanging the Smart EV Charger cable, protecting
the plug from rain when not plugged into the vehicle.
The Smart EV Charger offers the following connection options to the grid:
AC plug used for plugging the Smart EVCharger into the wall socket for connecting
to the alternating current (AC).
Direct AC connection to the Smart EV Charger. To be performed only by a
professional installer.
Additionally, there is an option for connecting the Smart EV Charger to a Single phase
inverter with HD-Wave technology at your site, enabling to use PV power as well as grid
power for EV charging. This option is to be performed only by a professional installer.
Figure 1: Smart EV Charger
Smart EV Charger Installation MAN-01-00657-1.1
Chapter 1: Introduction to Smart EV Charger 14
Packages Contents and Required Equipment
Smart EV Charger Package
Smart EV Charger Station
Smart EV Charger mounting bracket and tightening screws
EV Cable Package
EV Cable
EVCable Locker
Required Equipment
Screwdriver
Unibit Drill
Crimper
15/32" (12 mm) 3 wire ferrules
Smart EV Charger Installation MAN-01-00657-1.1
15 Chapter 2: Connectors and Interfaces
Chapter 2: Connectors and Interfaces
Figure 2: Smart EV Charger connectors and interfaces
Smart EV Charger cable connector: Used for connecting the cable to the Smart EV
Charger
AC plug :Used for plugging the Smart EVCharger into the wall socket
Smart EV Charger push button: Pressing the button has the following functionality:
Press Description
In case of malfunction resets errors and starts charging.
Short press
Long press Pairs the Smart EV Charger with the smartphone
Communication gland - for professional installer:
For connection of Smart EV Charger communication options, refer to
Installer - Setting Up Communication
In case the Smart EV Charger is on scheduling mode press to
immediately start charging.
on page 42 for more information.
Smart EV Charger Installation MAN-01-00657-1.1
Professional
Chapter 2: Connectors and Interfaces 16
Plug holder: Holds the plug when not being used.
Smart EV Charger LED ring indicator: Indicates the Smart EV Charger statuses as
described in the following table:
LED Ring Color Indication Description
Off Off No power
Red On Error
Green On
Green Blinking
Green Pulsating
- Charging
- Connected to the Internet
- Connected to EV
- Connected to Internet
- Not connected to EV
(1)
- Connected to the Internet
- Charging
Orange On
- Not connected to the Internet
- Connected to EV
Orange Blinking
-Not connected to the Internet
- Not connected to EV
On
(1)
- Not connected to the Internet
Ready to connect to your smartphone for direct
setting of Smart EV Charger via smartphone app.
Connected to your smartphone for direct setting
of Smart EV Charger via smartphone app.
Orange Pulsating
Purple Blinking fast
Purple
Momentary
(1)
The light switches on slowly and gradually increases up to maximum and then slowly decreases back to
off
Smart EV Charger Installation MAN-01-00657-1.1
17 Buzzer
Buzzer
The Smart EV charger includes a buzzer with the following indications:
Event Buzzer Indication
Connected to EV 1 short beep
Charging starts 2 short beeps + 1 long beep
Error 5 beeps
Smart EV Charger Installation MAN-01-00657-1.1
Chapter 2: Connectors and Interfaces 18
Main Procedures
The Smart EV Charger is supplied with a mounting bracket kit.
1. Mount the Smart EV Charger bracket
2. Mount the Smart EV Charger on the bracket
3. Connect the Smart EV Charger cable to the Smart EV Charger
4. Set the circuit breaker rating DIP switches
5. Plug in the AC plug
Follow the detailed procedures in the following sections to mount and connect the
Smart EV Charger
To mount the Smart EV Charger bracket:
Figure 3: Mounting bracket
1. Determine the Smart EV Charger mounting location, on the mounting surface.
2. Maintain the following minimum clearance areas between the Smart EV Charger and
other objects:
8" from the top and sides of the Smart EV Charger
At least 18" from the bottom of the Smart EV Charger if installing it indoors, 24” if
outdoors. If you are connecting the Smart EV Charger directly to the AC leave
sufficient clearance for the conduit as well.
3. Position the mounting bracket against the mounting surface and mark at least three
drilling hole locations (refer to
Smart EV Charger Installation MAN-01-00657-1.1
Mechanical Specifications
on page 58 for mounting
19 Main Procedures
bracket dimensions). Drill holes in the locations you marked and mount the bracket.
Verify that the bracket is firmly attached to the mounting surface.
To mount the Smart EV Charger on the bracket:
Lift and hang the Smart EV Charger on the mounted bracket (see the following
1.
figure).
Fasten the supplied bolt to the Smart EVCharger.
2.
To connect the Smart EV charger cable:
1. Align the two white arrows on the Smart EV charger cable connector with the white
dot on the Smart EV Charger connector located at the bottom of the Smart EV
Charger. The dot should be between the two arrows (see the following figure).
Plug the cable connector into the Smart EV charger connector (see the following
2.
figure).
Smart EV Charger Installation MAN-01-00657-1.1
Chapter 2: Connectors and Interfaces 20
Rotate the cable connector clockwise to fasten it (see the following figure).
3.
4. Assemble the two parts of the cable lock around the cable connector. Push the parts
together until they click to lock (see the following figure).
Smart EV Charger Installation MAN-01-00657-1.1
21 Chapter 3: Configuring and Using Smart EV Charger with mySolarEdge
Chapter 3: Configuring and Using Smart EV
Charger with mySolarEdge
After installing the Smart EV Charger configure it, then enable charging and other
advanced features (e.g. scheduling, excess solar charging) with mySolarEdge.
Using mySolarEdge
The following procedure describes the main actions required for using mySolarEdge to
configure and use the Smart EV Charger. You can download the app from the Apple
App Store or from Google Play, then click mySolarEdge icon.
To sign up to mySolarEdge:
1. Tap Sign up then follow the on- screen instructions until you get to the Scan the
QRBarcode screen.
2. Scan the QR barcode on the silver sticker located on the side of the device.
To configure and use mySolarEdge:
1. Login using your credentials.
2. Press the Smart EV Charger pushbutton (
connection between the Smart EV Charger and the smartphone.
3. Connect to the Smart EV Charger using the Connecting to Wi-Fi screen.
4. Once successfully connected return to mySolarEdge Welcome screen.
5. On the Welcome screen tap EV Charger, then tap the car icon to access the Smart EV
Charger configuration screens.
6. Follow the on-screen instructions to configure and use mySolarEdge with Smart EV
Charger.
Figure 2
Smart EV Charger Installation MAN-01-00657-1.1
) for 5 seconds to establish a Wi-Fi
Chapter 4: Charging Instructions 22
Chapter 4: Charging Instructions
1. Verify that the green LED ring is ON indicating that the Smart EV Charger is ON and
ready to charge.
2. Unplug t the Smart EV Charger plug.
Connect the Smart EV Charger plug to the charging socket of the vehicle and push
3.
firmly until it clicks into the socket. The Smart EV Charger will sound 1 short beep
and the green LED will change from breathing to blinking indicating a proper
connection.
The charging starts automatically, indicated by 2 short beeps and 1 long beep while
the green LED is steadily on.
When the charging is complete, the green LED starts blinking.
4. Press the Smart EV Charger plug latch and pull it from the vehicle's EV charging
socket.
5. Wind the Smart EV Charger cable around the device and put the plug back in the
holder.
Smart EV Charger Installation MAN-01-00657-1.1
23 Chapter 5: Professional Installer- Connecting the AC Directly to the
Smart EVCharger
Chapter 5: Professional Installer- Connecting
the AC Directly to the Smart EVCharger
It is recommended to use this connection option for outdoor installations in case an AC
socket is not accessible indoors. This option enables you to connect the Smart EV
charger directly to a service panel.
Required Equipment
Open ended 36 mm wrench
4 mm Allen Key
Screwdriver
Main Procedure
Set the circuit breaker rating DIP switches
1.
2. Remove the Smart EV Charger covers
3. Disconnect the AC Plug
4. Directly connect the AC to the Smart EV Charger
5. Close the Smart EV Charger
Grid Connection Guidelines
The conduits, hubs and fittings must be suited for field wiring systems.
Use only copper conductors rated for a minimum of 167°F.
Use the conduit and wiring appropriate for the installation location per the NEC.
Outdoor installations must use components that are rated NEMA 3R or higher.
NOTE
For more wiring information refer to the
Recommended AC Wiring Application Note
SolarEdge website at
https://www.solaredge.com/sites/default/files/applicationnote-recommended-wiring.pdf
SolarEdge
, available on the
Setting the Circuit Breaker Ratings
DIPSwitches
Set the circuit breaker rating DIP switches as shown in the following figure and table.
Smart EV Charger Installation MAN-01-00657-1.1
Chapter 5: Professional Installer- Connecting the AC Directly to the Smart
WARNING!
Before changing the DIP Switches, turn off the ACto the Smart EV Charger.
AVERTISSEMENT!
Avant de changer les commutateurs DIP, coupez l'alimentation CA du chargeur
Smart EV.
EVCharger 24
Figure 4: Smart EV Charger DIP switch interface
To set the circuit breaker ratings:
Adjust the Smart EV Charger DIP switches according to your circuit breaker rating to set
maximum allowed AC current from the grid.
By default, the DIP switch is set to the 40A which is the maximum allowed AC current.
Circuit Breaker Rating
SW1 SW2
DIPSwitch
Settings
Maximum
Allowed
AC Current
from Grid
Wire Gauge Range
20 A OFF OFF 16 A 14-6 AWG
30 A ON OFF 24 A 10-6 AWG
40 A OFF ON 32 A 8-6 AWG
50 A ON ON 40 A 8-6 AWG
Smart EV Charger Installation MAN-01-00657-1.1
25 Supported ACGrids
Supported ACGrids
The following figures illustrate grids that are supported by the Smart EV Charger.
Ground connection is required for all grids, as described in
on page 27.
Note that in some cases L1 and L2 are not interchangeable. In such cases, L1 and L2
locations appear in the following drawing.
Figure 5: 240V AC grids supported by Smart EV Charger
Disconnecting the AC Plug
Removing the Smart EV Charger Covers
The Smart EV Charger has two covers: a top cover and a bottom cover. You must
remove both covers to open the Smart EV Charger.
To remove the Smart EVCharger covers:
Loosen the screws on the top cover (see the following figure) and remove it.
1.
2. Loosen the screws of the bottom cover (see the following figure)and remove it as
well.
Smart EV Charger Installation MAN-01-00657-1.1
Chapter 5: Professional Installer- Connecting the AC Directly to the Smart
EVCharger 26
CAUTION!
When removing the covers, make sure not to damage the internal components.
SolarEdge will not be held responsible for any components damaged as a result
of incautious cover removal.
ATTENTION!
Lors du retrait du couvercle, assurez-vous de ne pas endommager les
composants internes. SolarEdge ne peut être tenue pour responsable des
composants endommagés à la suite d'une imprudence dans le retrait du
couvercle.
Smart EV Charger Installation MAN-01-00657-1.1
27 Disconnecting the AC Plug
Disconnecting the AC Plug
Figure 6: Inside the Smart EV Charger
To disconnect the AC plug:
Remove the Smart EV Charger covers. See
1.
page 25.
Release the two clamping screws and remove the clamp. See
2.
Push the terminal blocks levers up to release the G, L1 and L2 wires. See
3.
A neutral connection to the Smart EV Charger is not required.
Removing the Smart EV Charger Covers
Figure 6
Smart EV Charger Installation MAN-01-00657-1.1
on
.
Figure 6
Chapter 5: Professional Installer- Connecting the AC Directly to the Smart
EVCharger 28
4. Release the gland nut. See
5. Pull out the AC Plug cable from the conduit entry. See
Figure 6
.
Figure 6
.
Directly Connecting the AC Grid to the Smart EV
Charger
To directly connect the AC grid to the Smart EV Charger:
1. Strip 15/32'' (12mm) of the 14-6 AWG AC wire insulation.
Attach 15/32" (12 mm) wire ferrules to the bare wire (end of wire)of the G, L2 and L1
2.
wires:
a. Twist the bare wires.
b. Put the wire ferrule on the bare wires. Ensure you can see the end of the wire
through the wire ferrule .
c. Crimp the wire ferrule with a crimper. Repeat for all three wires.
If required, connect the conduit ground with a 14-6 AWG wire to the GND (see the
3.
figure in step 5).
4. Insert the AC conduit into the AC conduit entry.
NOTE
Connect the equipment grounding before connecting the AC wires to the AC
terminal block.
Veillez à relier le conducteur de PE (la terre) avant de connecter les fils CA au
bornier CA.
5. Insert the AC cable through the conduit entry and tighten the screws (see the figure
in step 5).
Insert the wire ferrules into the round openings according to the labels on the
6.
terminal blocks (G, L2 and L1) and close the levers – the wire ferrules are
automatically clamped (see the following figure).
Smart EV Charger Installation MAN-01-00657-1.1
29 Directly Connecting the AC Grid to the Smart EV Charger
7. Verify that there are no unconnected wires.
If a grounding wire needs to be connected, use the grounding lug, see the above
8.
figure. Tighten using a torque of 3 N*m / 27 lb-in.
9. Close the Smart EV Charger covers. See
Closing the Smart EV Charger Covers
41.
on page
Smart EV Charger Installation MAN-01-00657-1.1
Chapter 5: Professional Installer- Connecting the AC Directly to the Smart
EVCharger 30
Connecting the Smart EV Charger to the Single phase
inverter with HD-Wave technology
This section describes the procedures required for connecting the Smart EVCharger to
the Single phase inverter with HD-Wave technology. This option enables using PV
produced by the Single phase inverter with HD-Wave technology as well as power from
the grid, for Level 2 EV charging.
Prerequisites
Before connecting the Smart EV Charger to the Single phase inverter with HD-Wave
technology, replace the bus bar and AC terminal blocks inside the DC Safety Unit as
described in these following procedures, using this extension kit.
Kit Contents
2 terminal blocks, one labeled L1 and the other L2
9 hole neutral bus bar
Required Equipment
Unibit drill
Open ended 36mm wrench
3.6" / 5mm flat-blade screwdriver
4mm Allen key
Main Procedure
Disconnect the AC to the inverter/s and Smart EV Charger by turning OFF the circuit
1.
breaker/s on the distribution panel.
2. Remove the DC Safety Unit Cover and open the AC conduit drill guide.
3. Replace the existing AC terminal blocks, inside the DC Safety Unit.
Replace the existing ground bus bar, inside the DC Safety Unit.
4.
NOTE
Replacing the ground bus bar is only required if an additional grounding
wire connection is needed.
5. Connect the AC cable between the Single phase inverter with HD-Wave technology
and the Smart EV Charger.
Smart EV Charger Installation MAN-01-00657-1.1
31 Removing the DC Safety Unit Cover and Opening the Conduit Drill
Guides
6. Connect the AC wires to the DC Safety Unit AC terminals.
Connect RS485 between the Single Phase Inverter with HD-Wave Technology and
7.
the Smart EV Charger.
WARNING!
In case you are using a StorEdge Single Phase Inverter with HD-Wave
Technology and SetApp, set the circuit breaker limit value to prevent tripping.
Close the DC Safety unit : Attach the cover and secure it by tightening the four
8.
screws with a torque of 1.2 N*m/ 0.9 lb*ft.
9. Close the Smart EV Charger cover.
10. Turn on the Single Phase Inverter/s with HD-Wave Technology
Verify that the EV s charging.
11.
The following are the detailed procedures.
Figure 7: Inside the DC Safety Unit before (left) and after (right) replacements
Removing the DC Safety Unit Cover and Opening the
Conduit Drill Guides
Follow this procedure to remove the DC Safety Unit ,open the AC a d the DCconduit
drill guides
To remove the DC Safety Unit cover and to open the AC and DCconduit drill
guides:
1. Turn OFF the inverter ON/OFF switch, and wait until the green LED is blinking,
indicating that the DC voltage is safe (<50V), or wait five minutes before continuing
to the next step.
2. Disconnect the AC to the inverter by turning OFF the circuit breakers on the
distribution panel.
Open the DCSafety cover (see the following figure):
3.
Smart EV Charger Installation MAN-01-00657-1.1
Chapter 5: Professional Installer- Connecting the AC Directly to the Smart
a. Release the four Allen screws of the cover.
b. Tilt the top of the cover towards you.
c. Slide the cover down and remove it.
CAUTION!
When removing the cover, make sure not to damage internal components.
SolarEdge will not be held responsible for any components damaged as a
result of incautious cover removal.
ATTENTION!
Lors du retrait du couvercle, assurez-vous de ne pas endommager les
composants internes. SolarEdge ne peut être tenue pour responsable des
composants endommagés à la suite d'une imprudence dans le retrait du
couvercle.
EVCharger 32
Open the AC and DCconduit drill guides on the side and the bottom of the DC
4.
Safety unit according to the following image, taking care not to interfere with any of
the internal components . It is recommended to use a Unibit drill.
Replacing the AC terminal Blocks, Inside the DC Safety
Unit
For the location of the existing and new AC terminal blocks inside the DC Safety Unit,
see
Figure 7
Smart EV Charger Installation MAN-01-00657-1.1
.
33 Replacing the AC terminal Blocks, Inside the DC Safety Unit
To remove the existing AC terminal blocks:
1. Unscrew the screws on the right and left sides of the DIN-rail.
Using a screwdriver remove the right end-stop from the DIN-rail (see the following
2.
figure).
3. Pull out the DIN- rail.
4. Insert a screwdriver into each AC terminal block and press to pull out the cables.
Remove the AC terminal blocks from the DIN-rail.
5.
To install the new AC terminal blocks:
Insert the AC conduit into the AC-side drill at the bottom of the DC Safety Unit (see
1.
the following figure).
2. Snap the two new AC terminal blocks onto the DIN rail.Place the terminal block
labeled “L1” on the left side of each pair and “L2“ on the right and put back the
terminal block labeled “N".
Smart EV Charger Installation MAN-01-00657-1.1
Chapter 5: Professional Installer- Connecting the AC Directly to the Smart
EVCharger 34
Snap the end-stops onto the DIN rail - one on each side of the DIN rail.
3.
4. Insert a dedicated tool or a 3.6"/5mm flat-blade screwdriver into the opening and
rotate it counter-clockwise to unlock the clamp mechanism.
5. Press the latch with your finger to hold the clamp in the unlock position.
6. Fully insert the ACcables into the cable openings and slightly rotate the screwdriver
counter-clockwise to release the latch.
7. Check that all the terminal block wires are firmly and correctly connected.
Replacing the Bus Bar, inside the DC Safety Unit
Replacing the bus bar is only required if an additional grounding wire connection is
needed.
For the location of the existing bus bars inside the DC Safety Unit, see
To replace the bus bar:
1. Unscrew the two screws connecting the bus bar to the board.
2. Replace with the new bus bar and tighten the screws with a screwdriver.
3. Reconnect the grounding wires.
Figure 7
.
Connecting the AC cable Between the Single Phase
inverter with HD-Wave Technology and the Smart EV
Charger
Figure 8: Single phase inverter with HD-Wave technology connected to Smart EV Charger
To connect the AC cable between the Single phase inverter with HD-Wave
technology and the Smart EV Charger:
Smart EV Charger Installation MAN-01-00657-1.1
35 Connecting RS485 between the Single Phase Inverter with HD-Wave
Technology and the Smart EV Charger
Disconnect the AC plug from the bottom of the Smart EV Charger. Refer to the
1.
'Smart EV Charger Installation Guide' for instructions.
2. Insert the AC cable that contains the L1, L2 and grounding wires through the
opened conduit on the side of the DC Safety Unit.
3. Connect the AC wires according to the labels on the terminal block (see the
following figure):
4. Close all covers and turn on the inverter and the Smart EV Charger.
Connecting RS485 between the Single Phase Inverter
with HD-Wave Technology and the Smart EV Charger
The RS485 option enables creating a bus of connected SolarEdge devices, in this case
the Single Phase Inverter with HD-Wave Technology and the Smart EV Charger for
communication with the Monitoring Platform.
To install the Single Phase Inverter with HD-Wave Technology, refer to the installation
guide supplied with it:
https://www.solaredge.com/sites/default/files/se_hd_wave_inverter_with_
SetApp_installation_guide_na.pdf
Smart EV Charger Installation MAN-01-00657-1.1
Chapter 5: Professional Installer- Connecting the AC Directly to the Smart
EVCharger 36
Figure 9: RS485 connection between the Single Phase Inverter with HD-Wave Technology and
the Smart EV Charger
Figure 10: RS485 bus connection between Single Phase Inverter/s with HD-Wave Technology
and the Smart EV Charger
To connect RS485 between the HD inverter and the Smart EV charger:
In the Single Phase Inverter with HD-Wave Technology:
1.
Remove the inverter cover as described in the 'Single Phase Inverter with HD-
a.
Wave Technology' Installation Guide.
Remove the seal from one of the openings in communication gland and insert
b.
the wire through the opening.
Pull out the RS485 terminal block connector, as shown below:
c.
Smart EV Charger Installation MAN-01-00657-1.1
37 Connecting RS485 between the Single Phase Inverter with HD-Wave
Technology and the Smart EV Charger
Loosen the screws of pins A(+), B(-), and G on the left of the RS485 terminal
d.
block (RS485-1).
Insert the wire ends into the G, A and B pins shown above. Use Four- or six-wire
e.
twisted pair cable for this connection.
You can use any color wire for each of the A, B and G connections, as long as:
-The same wire pair is used for all A pins the same color for all B pins and the
same color for all G pins.
- The wire for G is not from the same twisted pair as A or B.
For creating an RS485 bus - connect all B, A and G pins in all inverters.
f.
Figure 10
Tighten the terminal block screws
g.
Check that the wires are fully inserted and cannot be pulled out easily
h.
Push the RS485 terminal block firmly all the way into the connector on the right
i.
shows this connection schema.
side of the communication board.
Terminate the first and last SolarEdge device in the chain by switching a
j.
termination DIP-switch inside the inverter to ON (move the left switch up). The
switch is located on the communication board and is marked SW2.
Smart EV Charger Installation MAN-01-00657-1.1
NOTE
Only the first and last SolarEdge devices in the chain should be
terminated. The other inverters in the chain should have the termination
switch OFF (down position).
If not using surge protection, connect the grounding wire to the first inverter in
k.
the RS485 chain; make sure the grounding wire is not in contact with other
wires inverters with a Safety Switch, connect the grounding wire to the
grounding bus bar in the Safety Switch.
In the Smart EV Charger:
2.
Remove the seal from one of the openings in the communication gland at the
a.
bottom of the Smart EV Charger and insert the RS485 wires from the HD Wave
through the opening.
Remove the 3-pin connector from the RS485-1 port on the communication
b.
board.
Chapter 5: Professional Installer- Connecting the AC Directly to the Smart
EVCharger 38
Loosen the screws of the connector and connect theSmart EV Charger wires
c.
according to the connector label B to B, A to A, and G to G, see
wire for G is not from the same twisted pair as A or B.
Insert the twisted wires into the connector and tighten them with the screws.
d.
Connect the connector back to the RS485-1 port.
e.
Figure 9
Closing the Smart EV Charger Covers
To close the Smart EVCharger covers:
Place the bottom cover on the Smart EV Charger and tighten the screws (see the
1.
following figure).
Smart EV Charger Installation MAN-01-00657-1.1
. The
39 Closing the Smart EV Charger Covers
2. Place the top cover on the bottom cover, insert and tighten screws (see the
following figure).
To configure the RS485 bus connection to the Single Phase Inverter with HD-Wave
Technology:
Connect all the inverters and Smart EV Chargers to the RS485 bus.
1.
Turn on all the inverters and the Smart EV Chargers.
2.
Set up the Smart EV Charger:
3.
Smart EV Charger Installation MAN-01-00657-1.1
Chapter 5: Professional Installer- Connecting the AC Directly to the Smart
EVCharger 40
Login in to SetApp or download and sign in using one of these following
a.
barcodes:
Follow the on-screen instructions.
b.
NOTE
The connection to the Internet is established via RS485
On the Smart EVCharger:
4.
a. Long press the Push Button
b. Scan the QR Code Pairing Label
Perform follower detection on the leader inverter:
5.
a. RS485 èProtocol èSolarEdge
b. RS485 èFollower detect
Open the leader inverter's Communication menu that is connected to the Smart EV
6.
Charger with AC and RS485 wires.
Select, Communication è Samrt EV Charger èSelect ID of Smart EV Charger
Verify that the Smart EV Charger is connected to the monitoring platform.
7.
The Ring LED is Green either: blinking, pulsating or continually on.
Setting the Circuit Breaker Limit Value
In case you are using a StorEdge Single Phase Inverter with HD-Wave Technology and
SetApp, set the circuit breaker limit value to prevent tripping.
To set the circuit breaker limit value:
1. Open the leader inverter's Maintenance menu then select Circuit Breaker.
2. In the Circuit Breaker field add the limit value of the installed circuit breaker.
Smart EV Charger Installation MAN-01-00657-1.1
41 Verifying that the EV is Charging
Verifying that the EV is Charging
To verify that the EV is charging:
On the Smart EVCharger, short press the Push Button.
1.
Verify that the Ring indicator is Green.
2.
Closing the Smart EV Charger Covers
To close the Smart EVCharger covers:
Place the bottom cover on the Smart EV Charger and tighten the screws (see the
1.
following figure).
2. Place the top cover on the bottom cover, insert and tighten screws (see the
following figure).
Smart EV Charger Installation MAN-01-00657-1.1
Chapter 6: Professional Installer - Setting Up Communication 42
Chapter 6: Professional Installer - Setting Up
Communication
This section describes how to set up communication between the Smart EV Charger and
the monitoring platform through the Internet (wired/ wireless).
Communication setup is not required for charging, however it is needed for using
advanced features (e.g. scheduling, excess solar charging) and for transferring EV
charging related information to the monitoring platform.
NOTE
It is recommended to connect communications before connecting the AC,for
easier access to the communication board.
Communication Options
The following types of communication can be used to transfer the monitored
information from the Smart EV Charger to the monitoring platform.
Only communication products offered by SolarEdge are supported.
Wi-Fi
A Wi-Fi connection is provided for connecting my SolarEdge app and SetApp to the
monitoring platform. An antenna is required and available from SolarEdge for
extending the Wi-Fi range.
The Wi-Fi access point is built into the Smart EV Charger.
Ethernet
Ethernet is used for a LAN connection. For connection instructions refer to
Ethernet (LAN) Connection
on page 44.
Creating an
RS485
The RS485 ports are used for communicating with:
Single phase inverter with HD-Wave technology. For connection instructions refer
to
Creating an RS485 Bus Connection to SolarEdge Inverter or Gateway
Import/Export Meter. For connection instructions refer to
Connecting the Smart EV Charger to an Energy Meter
Smart EV Charger Installation MAN-01-00657-1.1
Professional Installer -
on page 55.
on page 48.
43 Communication Connectors
Cellular
This wireless communication option (purchased separately) enables using a cellular
network to connect to the monitoring platform.
The Cellular Plug-in is provided with a user manual, which should be reviewed prior to
connection. Refer to https://www.solaredge.com/sites/default/files/se-cellular-plug-
in-for-inverters-with-setapp-installation-guide.pdf
Communication Connectors
A communication gland with multiple openings is used for connection of the various
communication options. The table below describes the functionality of each gland
opening. Unused openings should remain sealed.
Opening for cable size (diameter) Connection type
2.5 - 5 mm RS485
4.5 - 7 mm, with cut
2 - 4 mm, with cut
Cable for external wireless or cellular
Ethernet (CAT5/6)
communication
Figure 11: Communication Gland
The communication board has a standard RJ45 terminal block for Ethernet connection
and a 6-pin terminal block for RS485 connection.
The CellularPlug-in can be connected to the communication board for optional
wireless connection.
Smart EV Charger Installation MAN-01-00657-1.1
Chapter 6: Professional Installer - Setting Up Communication 44
Figure 12: Communication board connectors
Creating an Ethernet (LAN) Connection
This communication option enables using an Ethernet connection to connect the Smart
EV Charger to the monitoring platform through a LAN.
Figure 13: Example of Ethernet connection
Ethernet cable specifications:
Cable type – a shielded Ethernet cable (Cat5/5E STP) may be used
Maximum distance between the Smart EV Charger and the router –330 ft.
NOTE
If using a cable longer than 33 ft in areas where there is a risk
of induced voltage surges by lightning, it is recommend to use
external surge protection devices.
For details refer to:
https://www.solaredge.com/sites/default/files/overvoltage_
surge_protection_na.pdf.
Smart EV Charger Installation MAN-01-00657-1.1
45 Creating an Ethernet (LAN) Connection
To connect the Ethernet cable:
1. Remove the Smart EV Charger covers as described in
Covers
on page 25.
Removing the Smart EV Charger
2. Open the communication gland.
CAUTION!
The gland includes a rubber waterproof fitting, which should be used to
ensure proper sealing.
ATTENTION!
Le cote interne du gland contient une rondelle qui doit être utilisée pour une
bonne étancheïté.
3. Remove the plastic seal from one of the large openings.
4. Remove the rubber fitting from the gland and insert the CAT5/6 cable through the
gland and through the gland opening in the Smart EV Charger.
5. Insert the cable through the opening in the Smart EV Charger towards the
communication board.
Push the cable into the cut opening of the rubber fitting (see the following figure).
6.
CAT5/6 standard cables have eight wires (four twisted pairs), as shown in the diagram
below. Wire colors may differ from one cable to another. You can use either wiring
standard, as long as both sides of the cable have the same pin-out and color-coding.
Smart EV Charger Installation MAN-01-00657-1.1
Chapter 6: Professional Installer - Setting Up Communication 46
(1)
10Base-T Signal
100Base-TX Signal
RJ45 Pin #
Wire Color
T568B T568A
1 White/Orange White/Green Transmit+
2 Orange Green Transmit3 White/Green White/Orange Receive+
4 Blue Blue Reserved
5 White/Blue White/Blue Reserved
6 Green Orange Received7 White/Brown White/Brown Reserved
8 Brown Brown Reserved
7. Use a pre-crimped cable to connect via gland #1 to the RJ45 plug on the Smart EV
Charger's communication board or, if using a spool of cable, connect as follows:
a. Insert the cable through the gland.
b. Remove the cable’s external insulation using a crimping tool or cable cutter and
expose eight wires.
c. Insert the eight wires into an RJ45 connector, as described in
d. Use a crimping tool to crimp the connector.
e. Connect the Ethernet connector to the RJ45 port on the communication board
(see the following figure).
(1)
The Smart EV Charger connection does not support RX/TX polarity change. Supporting crossover
Ethernet cables depends on the switch capabilities.
Smart EV Charger Installation MAN-01-00657-1.1
47 Creating an Ethernet (LAN) Connection
8. For the switch/router side, use a pre-crimped cable or use a crimper to prepare an
RJ45 communication connector: Insert the eight wires into the RJ45 connector in the
same order as above (Figure 2).
9. Connect the cable RJ45 connector to the RJ45 port of the Ethernet switch or router.
You can connect more than one Smart EV Charger to the same switch/router or to
different switches/routers, as needed. Each Smart EV Charger sends its monitored
data independently to the SolarEdge monitoring platform.
The Smart EV Charger is configured by default to LAN.
10.
Turn ON the AC to the Smart EV Charger by turning ON the circuit breaker on
a.
the main distribution panel.
WARNING!
ELECTRICAL SHOCK HAZARD. Do not touch uninsulated wires when the
SMI cover is removed.
AVERTISSEMENT!
RISQUE D’ÉLECTROCUTION, ne touchez pas les fils non isolés lorsque le
couvercle de Smart EV Charger est retiré.
Configure the connection with SetApp. Refer to
b.
Configuring and Using Smart EV Charger with SetApp
11. Verify the connection with SetApp. Refer to
Monitoring Platform
on page 49.
Smart EV Charger Installation MAN-01-00657-1.1
Processional Installer -
on page 50.
Verifying the Connection to the
Chapter 6: Professional Installer - Setting Up Communication 48
Creating an RS485 Bus Connection to SolarEdge
Inverter or Gateway
The RS485 option enables creating a bus of connected devices, consisting of up to 31
follower devices and 1 leader device. Using this option, devices are connected to each
other in a bus (chain), via their RS485 connectors. The first and last device in the chain
must be terminated as described in
RS485 wiring specifications:
Cable type: Min. 3-wire shielded twisted pair (a shielded Ethernet cable (Cat5/5E
STP) may be used)
Wire cross-section area: 0.2- 1 mm²/ 24-18 AWG (a CAT5 cable may be used)
Maximum nodes: 32
Maximum distance between first and last devices: 1 km /3300 ft.
NOTE
If using a cable longer than 10 m/ 33 ft in areas where there is a
risk of induced voltage surges by lightning, it is recommend to
use external surge protection devices. For details refer to:
https://www.solaredge.com/sites/default/files/overvoltage_
surge_protection_na.pdf.
If grounded metal conduit are used for routing the communication wires, a
lightning protection device is not required.
If not using surge protection, connect the grounding wire to the first inverter
in the RS485 chain; make sure the grounding wire is not in contact with other
wires. Connect the grounding wire to the grounding bus-bar in the
Connection Unit with Safety Switch.
RS485 Bus Configuration
on page 48
RS485 Bus Configuration
To connect to the monitoring platform:
1. Designate a single inverter as the connection point between the RS485 bus and the
monitoring platform. This inverter will serve as the leader inverter.
2. Connect the leader to the monitoring platform via the LAN option (refer to
an Ethernet (LAN) Connection
To configure the RS485 bus:
All devices are configured by default as followers. To configure the leader:
Smart EV Charger Installation MAN-01-00657-1.1
on page 44) or any of the other options.
Creating
49 Verifying the Connection to the Monitoring Platform
1. Verify that AC is on.
2. Use SetApp to access the Commissioning menu
Select the following to configure the connection:
3.
Server è LAN
RS485- è Protocol è SolarEdge Leader
RS485- è Follower Detect
The system starts automatic detection of the follower devices connected to the leader
inverter. The inverter should report the correct number of followers . If it does not,
verify the connections and terminations.
4. To check the follower IDs and last communication time, select
RS485- è Follower List.
5. Verify the connection of the leader to the monitoring platform, as described in the
next section.
Verifying the Connection to the Monitoring Platform
After connecting and configuring a communication option, perform the following
steps to check that the connection to the monitoring server has been successfully
established.
To verify the connection to the monitoring platform:
1. Open SetApp and follow the instructions on the screen. The mobile device creates a
Wi-Fi connection with the Smart EV Charger and displays the main Commissioning
screen.
2. From the Commissioning menu select Status.
Check that S_OK - Server Connected status appears in the main Smart EVCharger
3.
section.
Scroll down to the Communication section and check that the communication
4.
options are as required. Refer to
Viewing Communication Status
Smart EV Charger Installation MAN-01-00657-1.1
on page 51.
Chapter 7: Processional Installer - Configuring and Using Smart EV Charger
with SetApp 50
Chapter 7: Processional Installer - Configuring
and Using Smart EV Charger with SetApp
After installing the Smart EV Charger configure it, then enable charging and other
advanced features (e.g. scheduling, excess solar charging) with SetApp.
You can connect communication options at this stage, as described in
Installer - Setting Up Communication
You can download the SetApp from the Apple App Store and Google Play prior to
reaching the site.
on page 42.
Professional
Internet connection is required for the download and for the one-time registration,
however not required for using the SetApp.
Configuring the Smart EV Charger
1. Download and Follow the on- screen instructions to configure and use SetApp with
Smart EV Charger.
Configuring Communication Options
Communication settings can be configured only after communication connections are
complete. Refer to
To configure communication options:
Tap the Communication menu to define and configure the following:
1.
The communication option used by the Smart EV Charger to communicate with
the monitoring platform.
The communication option used to communicate between multiple SolarEdge
devices.
Tap the Server red arrow to set the communication method to be used for
2.
Smart EV Charger Installation MAN-01-00657-1.1
Professional Installer - Setting Up Communication
on page 42.
51 Viewing Communication Status
communication between the Smart EV Charger and the SolarEdge monitoring
platform. The default is LAN.
NOTE
The Server menu shows only the communication options installed in the
Smart EV Charger.
For detailed information about all the configuration options, refer to the
Communication Options Application Note
website at https://www.solaredge.com/sites/default/files/solaredge-
communication_options_application_note_v2_250_and_above.pdf.
, available on the SolarEdge
Viewing Communication Status
The Communication screen displays the status of connection option(s): LAN, RS485,
Wi-Fi and cellular.
To view communication status:
1. From the Commissioning menu select Status then scroll down to the
Communication section.
For each communication option, one of the following statuses is displayed:
Connected: The Smart EV Charger established a successful connection and
communication with the specified server port.
NC: Not Connected
S_OK: The connection to the monitoring platform is successful .
N/A : Not Applicable
Temporarily displayed (with a clock sign):
Initializing communication
Connecting to a network
Connecting to SolarEdge servers
Error message (with the sign)
Smart EV Charger Installation MAN-01-00657-1.1
Chapter 8: Errors and Troubleshooting 52
Chapter 8: Errors and Troubleshooting
For the following system errors, when an error occurs, the red LEDring lights ON and
the buzzer beeps 10 times.
The error messages are displayed on the mobile app screen.
If the error persists- contact SolarEdge Support.
Error code Displayed Error message Description and Troubleshooting
An internal communication error.
When this error occurs, the red
LEDring is not lit, the buzzer does
3x85 EVSEComm. Error
1Cx1; 1Cx8
Over Current
Press Charge Now
not beep and charging is not
affected.
Check that the internal connections
on the communication board are
properly done.
Smart EVCharger AC over current.
Press the Charge Now push
button on the Smart EV Charger,
see
Figure 2
-orTap Charge Now on the Smart EV
Charger tab of the Monitoring
App
1Cx2; 1xC9
1Cx3,Cx14;
1Cx15
Smart EV Charger Installation MAN-01-00657-1.1
Over Voltage
Press Charge Now
Ground Fault (RCD)
Press Charge Now
Smart EVCharger ACvoltage too
high.
Press the Charge Now push
button on the Smart EVCharger,
see
Figure 2
-orTap Charge Now on the Smart EV
Charger tab of the Monitoring
App
Smart EVCharger ground fault
detected.
53 Chapter 8: Errors and Troubleshooting
Error code Displayed Error message Description and Troubleshooting
Press the Charge Now push
button on the Smart EV Charger ,
see
Figure 2
-orTap Charge Now on the Smart EV
Charger tab of the Monitoring
App
Internal error.
Disconnect the Smart EVCharger
cable from the vehicle.
Turn the inverter ACcircuit
breaker OFF and ON.
1Cx4; 1Cx5;
1Cx12 -1Cx13
Internal Error
Disconnect from EV
Reconnect the Smart EVCharger
Cable to the vehicle.
If the EV Charger is powered by
the inverter, then turn the inverter
AC circuit breaker OFF and ON.
If the EV Charger is standalone,
then turn the EV Charger AC
circuit OFF and ON.
1CxB/D; 1Cx10 1Cx11
1Cx6
Interface Error (Pilot) Press
Charge Now
Ground Disconnected
Disconnect from EV
1Cx7 Over Temperature
Press the Charge Now push
button on the Smart EV Charger,
see
Figure 2
-orTap Charge Now on the Smart
EVCharger tab of the Monitoring
App
Ground Disconnected.
Disconnect the Smart EVCharger
cable from the vehicle.
Contact SolarEdge Support.
Smart EVCharger over temperature
Smart EV Charger Installation MAN-01-00657-1.1
Chapter 8: Errors and Troubleshooting 54
Error code Displayed Error message Description and Troubleshooting
Verify proper clearances around the
Smart EV charger Cable.
After verification reconnect the
Smart EV charger cable to the EV.
Contact SolarEdge Support.
Smart EVCharger ACvoltage too
low.
Press the Charge Now push
button on the Smart EVCharger,
see
Figure 2
-or-
1CxA
Under Voltage
Press Charge Now
Tap Charge Now on the EV Smart
Charger tab of the Monitoring
App
The SolarEdge Smart EV charger
does not charge vehicles that
require ventilation while charging.
If this error occurs, the vehicle
1CxC
Vent not supported
Disconnect from EV
cannot be charged.
Charging retries ended
1CxE;1CxF
Charging retries ended
Disconnect from EV
Disconnect the Smart EVCharger
cable from the vehicle.
Contact SolarEdge Support.
Smart EV Charger Installation MAN-01-00657-1.1
55 Appendix A: Professional Installer - Connecting the Smart EV Charger
to an Energy Meter
Appendix A: Professional Installer - Connecting
the Smart EV Charger to an Energy Meter
This section provides instructions for connecting the Smart EV Charger to an Energy
Meter. An Energy Meter is required for Smart Energy Management applications, such as
controlled Excess Solar charging.
To install the Energy Meter, refer to the installation guide supplied with it:
Energy Meter DIPSwitches
The following sections explain the DIPSwitches IDs and termination.
Energy Meter ID DIP Switches
The IDDIPswitches are used to set the Modbus address of the meter. The addressing
options are listed in the table below. See the figure
page 56 for switch direction guidelines.
Table 1: Energy Meter I D DIP Switches
Modbus Address ID 1 ID 2 ID 3
0 Down Down Down
1 Up Down Down
2 Down Up Down
3 Up Up Down
4 Down Down Up
5 Up Down Up
6 Down Up Up
7 Up Up Up
ID and termination DIP switches
on
Energy Meter Termination DIPSwitches
The Termination DIPswitches are used to configure RS485 wiring termination. The
termination options are listed in the table below. See the figure
switches
on page 56 for switch direction guidelines and refer to
Smart EV Charger Installation MAN-01-00657-1.1
ID and termination DIP
Table 1
.
Appendix A: Professional Installer - Connecting the Smart EV Charger to an
Energy Meter 56
Table 2: Energy Meter I D DIP Switches
RS485 Termination TERM 1 TERM 2
Terminated Down Down
Not Terminated (factory default) Up Up
Figure 14: ID and termination DIP switches
Figure 15: Meter connection
To connect the Energy Meter to the Smart EV Charger:
1. Connect one end of the communication cable to the Energy Meter, as explained in
the Energy Meter's installation guide.
Remove the seal from one of the openings in the communication gland at the
2.
bottom of the Smart EV Charger and insert the RS485 wires from the meter through
the opening (see
Remove the 3-pin connector from the RS485-1 port on the communication board
3.
(see
Figure 15
Smart EV Charger Installation MAN-01-00657-1.1
Figure 15
).
).
57
Loosen the screws of the connector and connect the Energy Meter wires according
4.
to the connector label B to B, A to A, and G ot G (see
Figure 15
).
The wire for G is not from the same twisted pair as A or B.
5. Insert the twisted wires into the connector and tighten them with the screws.
6. Connect the connector back to the RS485-1 port.
7. In the meter, ensure the RS485-1 DIPswitch is down. See
8. In the meter, set the Modbus address 1-3 of the meter according to
Figure 14
.
Table 1
Smart EV Charger Installation MAN-01-00657-1.1
Mechanical Specifications 58
Mechanical Specifications
The following figure provides Smart EV Charger dimensions in [in].
Figure 16: Smart EV Charger dimensions
Smart EV Charger Installation MAN-01-00657-1.1
59 Technical Specifications - Smart EV Charger (North America)
Technical Specifications - Smart EV Charger
(North America)
Level 2 EVSE, 40A (9.6kW), Wi-Fi enabled
EV CHARGER SPECIFICATIONS
Charging Mode AC Level 2
Rated AC Power Output 9.6 kW
Maximum Continuous
Output Current @240
Nominal AC Output
Voltage @240Vac
Nominal AC Frequency 60 A
Ground Fault Detection
Threshold
Supported
Communication
Interfaces
Wi-Fi (built-in antenna included)
RS485 and Cellular (optional)
SUPPORTED FEATURES WHEN CONNECTED TO A SOLAREDGE INVERTER
Smart Energy
Management
Mobile app control, smart schedules, excess
solar charging
ADDITIONAL FEATURES
EV Charger Status LEDs,
Fault Indicator
EV Charger Unplugging
Yes, current termination according to SAE J1772
Detection
EV Charger Ground
Connection Monitoring
EV Charger
Configuration
Installer commissioning via SetApp. Homeowner
configuration, controls and monitoring via
Yes, continuous
mySolarEdge app
(1)
40
(2)
240
5 mA
(3)
, Ethernet,
(4)
(5)
, solar boost mode
Yes
Vac
Vac
(1)
Configurable to the following max output current levels: 16 / 24 / 32 / 40 A.
(2)
Connected to L1, L2, G; No need for neutral.
(3)
Wi-Fi antenna is available for extended Wi-Fi communication. More details here:
https://www.solaredge.com/sites/default/files/se-wifi-zigbee-antenna-datasheet.pdf
(4)
Internal cellular communication kit is available as an option. More details here:
https://www.solaredge.com/us/products/communication/cellular-communication-options
(5)
For excess solar charging with a SolarEdge inverter- an Import / Export meter is required
Smart EV Charger Installation MAN-01-00657-1.1
Technical Specifications - Smart EV Charger (North America) 60
STANDARD COMPLIANCE
Emissions FCC Part 15 Class B
Safety
UL2594, UL2231-1, UL2231-2, NEC Article 625
compliant
EV Charger SAE J1772
EV CHARGING CABLE
EV Cable Weight 12.5 / 5.7 ib / kg
EVCable Length 25 / 7.6 ft / m
Operating Temperature
Range
-22 to +122 / -30 to +50 F / ˚C
INSTALLATION SPECIFICATIONS
EV Charger Dimensions
(H x W x D)
12 x 7.3 x 6 / 309 x 190 x 154 in / mm
EV Charger Weight 6.3 / 2.85 ib / kg
AC Power Plug NEMA 6-50 / NEMA 14-50
Protection Rating
(1)
NEMA 3R
(1)
Connected to EV or with dust cap
Smart EV Charger Installation MAN-01-00657-1.1
61 Support Contact Information
Support Contact Information
If you have technical problems concerning SolarEdge products, please contact us:
https://www.solaredge.com/service/support
Before contact, make sure to have the following information at hand:
Model and serial number of the product in question.
The error indicated on the product's mobile application.
The communication method to the SolarEdge ,monitoring platform , if the site is
connected.
Smart EV Charger Installation MAN-01-00657-1.1
