SolaHD SFL Series Specifications

SFL Specifications

Power Supplies

4

Parameter Value

Input

Input voltages nominal (user selectable)

Input Frequency

Input current at full load (typical)

- 75 W (12 V/6 A, 24 V/3 A, 48 V/1.5 A)

- 150 W (24 V/6 A, 48 V/3 A)

- 300 W (24 V/12 A, 48 V/6 A)

- 600 W (24 V/24 A, 48 V/12 A)

Inrush current (max.)

- 75 W

- 150 W

- 300 W

- 600 W

Internal fuse (slow blow) not accessible

- 75 W / 150 W

- 300 W

- 600 W

Output

Voltage Adjustment Range

- 12 V models

- 24 V models

- 48 V models

Output Regulation

- Line voltage variation

- Load variation 10–90%
75W, 150W models
300W, 600W models

Ripple and noise (20 MHz bandwidth)

Electronic short circuit protection /
current limitation

Parallel Operation

- SFL12-24-100RED

- SFL24-24-100RED

Overvoltage Protection, trigger point at

Holdup Time

93-132 Vac / 187-264 Vac

47-63 Hz

115 Vac

1.7A

3.0A

5.4A

10.5A

115 Vac

16.5 A

35.0 A

35.0 A

70.0 A

12 – 14 Vdc
24 – 28 Vdc
48 – 52 Vdc

±0.2% max.

±1.0% max.
±0.5% max.

< 50 mVpp

110 % typ. (constant current)

Up to 5 units

140% typical out nominal

min. 20 mS

230 Vac

0.9 A

1.7 A

3.3 A

6.4 A

230 Vac

33.0 A

70.0 A

70.0 A

80.0 A

4.0 A

6.3 A

12.0 A

Parameter Value

Operating Temperature Range
Derating above 50°C

Storage Temperature

Humidity (non condensing)

Switching Frequency

- 75 W

- 150 W/300 W/600 W

Efficiency

Operation Indication

Isolation Voltage

- Input/output

- Input/case

- Output/case

Safety Class (IEC536)

Safety Standards Met

Conducted EMI according to:

Electromagnetic Susceptibility

- Electrostatic discharge ESD.

- RF field susceptibility.

- Electrical fast transients/
bursts on main line.

- Immunity to conducted radio
frequency disturbances above
9 kHz.

- Mains frequency field

Case protection according to IEC529

Case material

Mounting

General

-25°C...+70°C 2%/°C

-25°C...+85°C

95% rel H max.

100 kHz typical

67 kHz typical

>85%

LED, DC OK

3,000 Vac (1 minute)
2,000 Vac (1 minute)

500 Vac (1 minute)

Class 1

IEC950,EN60950,CE marked
for LVD, UL60950 recognized

and UL 508.

EN55022 Class B, EN55011

Class B, FCC-B

EN61000-4-2
EN61000-4-3
EN61000-4-4

EN61000-4-6

EN61000-4-8

Snap-on 35 mm DIN Rail as

per EN50022 or Chassis mounting

option available

4 kV/8 kV

10 V/m

30 A/m

IP 20

Steel

2 kV

10 V

Mounting Brackets

For easy conversion to panel or chassis mounting.

Catalog Number Output Power Maximum

SFL 75-PMBRK
SFL 150-PMBRK
SFL 300-PMBRK
SFL 600-PMBRK

contact Technical Services at [phone] with any questions.

75 Watt
150 Watt
300 Watt
600 Watt
