USER MANUAL
3
CONTENTS
Exploded View
Operation
Conguration
Cleaning
Replacing/Changing
the Inner Panel
Base Assembly
Universal Bracket Pair
Extended Bracket Pair
Warranty
Thank you for purchasing a KwickScreen.
KwickScreen is an award winning portable,
retractable room divider with a very small
footprint for easy storage and use.
KwickScreens are simple to transport and
clean.
KwickScreens are often used in infection
control, privacy and dignity, and new builds
and refurbishments providing exible
space management within healthcare.
Wemtech health and safety reports can
be provided upon request.
5
6
8
10
11
12
14
16
18
INTRODUCTION
For more information, visit our website:
www.sohowerks.com/kwickscreen
For all
inquiries call: 888-881-8830 (Mon-Fri/9-5 EST)
or email us at info@sohokwickscreen.com
This sign denotes
important information
USER MANUAL
4
It is important to be gentle when pulling the KwickScreen out for use. This is
especially true when the product is new or if it has not been used recently.
The screen must be allowed to nd its ‘natural position’ where the screen
moves smoothly in and out of the casing. If you nd the screen more
difcult to push in or pull out, or you hear a crumpling sound, then reverse
your action (push if pulling and pull if pushing). This is a rare occurrence
but if forced, the screens will crumple and this will cause damage and can
crease the inner panel.
If you have purchased a printed screen we recommend leaving it
open in a well ventilated space to remove the smell of ink for 3-4
days.
Read all instructions in this user guide prior to installation and operation
of your KwickScreen.
For personal and operational safety, use only parts approved by
KwickScreen.
Before installation ensure all parts are present, complete and without
defects.
If you believe parts to be missing contact info@sohokwickscreen.com
Packaging material should be disposed of in accordance with local rules
and regulations.
PLEASE READ BEFORE USE
2
5
1 Front handle
2 Front base
3 C-tube
1
2 64
3
5
4 Rear base
5 Screen inner panel
6 Main body (top view below)
Left
Right
Back
1
2
4
6
6
OPERATION
GENERAL INSTRUCTIONS
The KwickScreen is designed for use on smooth, horizontal surfaces. Extra care should be
taken when using on other surfaces
When moving the KwickScreen check all 4 brakes have been released. The unit should
then be moved with two hands at low down waist height
Push/pull gently
If there is resistance then stop, pull out and push in again gently
Make sure the front handle is vertical and that its four wheels are all in contact with the
oor
IF LEAVING THE SCREEN ON AN INCLINE, ENSURE ALL
BRAKES ARE ENGAGED
DO NOT RUN WHEN USING THE KWICKSCREEN
IF YOU EXPERIENCE ANY PROBLEMS,
PLEASE CALL OUR TECHNICAL HELP LINE 888-881-8830
74-51⁄64 in
122-3⁄64 in
11-13⁄16 in
1-31⁄32 in
7
HOW TO USE THE KWICKSCREEN
1
3
Working area to
pull out / push in
2
Screen cannot be pulled
out / pushed in beyond
this area
Working area is +/- 45°
from the centre line
Bending direction
C-tubes can only bend
inwards
Do not bend C-tubes back
on themselves, as this will
damage them
Bending position
Do not position the bend more
than 1m from the handle as this
makes the product unstable
A bend can be created next
to the handle: be careful when
doing this as incorrect method
will damage the inner screen
4
Pivoting screen
Pull out to desired
length
Rotate to desired
angle in correct
direction
Do not rotate screen on
the outside of the C-tubes
as this will damage them
39-3⁄8 in
8
CONFIGURATION
The KwickScreen is a versatile room divider which can be arranged in a number of
congurations to provide exible space management. Below are a few arrangements
demonstrating some of the possible combinations.
Standard
Front to side
Front to back
Front to front
T-shape
FREE STANDING
1
2
5
3
1
4
9
A FIXED TO THE FLOOR DESIGN IS ALSO AVAILABLE:
CALL OUR TECHNICAL HELP LINE FOR MORE INFORMATION
888-881-8830
FIXED TO WALL
The KwickScreen can be used in a more permanent way by being xed to the wall
with a top and bottom bracket. Here are a few examples of possible congurations:
1
2
3
4
Fixed to back
Fixed to left
Fixed to right
Built in
TWIN
The KwickScreen can also be delivered as two units attached together back to back on
a single wheel plate.
1
Creates a wall up to 7
metres long
2
Can form a 90° corner
7m
1
2
3 4
1
2
10
CLEANING
KwickScreens are designed in line
with infection control performance
specications. The smooth surfaces are
easy to clean and designed to withstand
regular cleaning. The metal parts are
powder-coated and the screen material is
polyester lm manufactured by DuPont.
NORMAL CLEANING
Surfaces should be cleaned using
a solution of warm water and mild
detergent. Use a clean soft cloth and rinse
with clean water after washing.
Hypochlorite may also be used on the
screen material. Hypochlorite can be
applied at 1000–10000 ppm or a 70%
alcohol solution.
STUBBORN STAINS
If normal cleaning does not remove all
stains the following cleaning agents may
be used at room temperature
• Methyl alcohol butyl alcohol
• Naptha VM&P
• Ethyl alcohol
• Isopropyl alcohol.
DEEP CLEANING
Deep cleaning is recomended every 3-4
months. To deep clean, retract screen
fully and clean inside the body.
• Wax polishes or solvents
• Products with an abrasive surface
such as steel wool
• Detergents which can form lime or
synthetic detergents
• Alkalis
• Solvents
• Gasoline
• Greases or oils
• Cloths containing grit or abrasive particles, or kitchen scouring
compounds to clean the printed
polyester lm surface
• Razor blades or other sharp instruments to scrape the surface
• Gasoline to remove stains
Do not clean in direct sunlight or in
elevated temperatures
WHEN CLEANING THE
KWICKSCREEN
DO NOT USE:
11
REPLACING OR CHANGING THE INNER PANEL
1 Extend screen fully 2 Inserting screen, start in top left corner
and start zip
3 With one hand supporting rolled
screen slowly zip top zip. Once done, zip
the bottom and side zips
4 Pass extra screen around roller and
align magnetic strips
5 Close the side zip 6 Close the bottom zip. Reverse process
to remove screen
To insert follow steps 1-6
To remove follow 2-3 then 6-1
12
Back
Left
Right
Right
Back
Left
Top Bracket
Bottom Bracket
UNIVERSAL BRACKET PAIR
The universal bracket pair is a top and bottom bracket set which allows
the attachment of a KwikScreen to a wall. The right, left and back sides
of the main body can be xed to a wall using the different holes
provided on the brackets.
TOP VIEWS - showing the top universal bracket in 3 orientations:
13
BOTTOM VIEWS - showing the bottom universal bracket in 3 orientations:
Back
Right
Left
BackLeft Right
The universal brackets are desgined to t on any side of the product. As
such the brackets have multiple holes on them, this is not a manufacturing
default and the appropriate holes to use will become apparent during
installation.
14
One simple method to achieve the appropriate height is to measure the
top bracket’s location rst, using the top of the front handle as a guide.
Use the front handle with the
bracket resting on top to mark a
line on the wall.
Align the top edge of the top
bracket to the line and x to the
wall.
To
x the KwickScreen to the wall,
the top of the main body needs
to sit ush with the top of the front
handle. Therefore the bottom
of the main body needs to be
mounted 5-5⁄16 in from the floor,
meaning the holes for top bracket
will be centred at 6-17⁄64 in from
the floor and the top bracket holes
will be 72-7⁄8 in from the floor.
INSTALLING THE UNIVERSAL BRACKET PAIR
Screw Bracket
69-17⁄32in
5-5⁄16 in
6-17⁄64 in
72-7⁄8 in
15
Measure down 69-17⁄32 in from
the top
bracket line and make a
new horizontal line.
Align the bottom edge of the
bottom bracket to this line, making
sure the two brackets are vertically
aligned, and x to the wall.
ATTACHING THE BRACKET TO THE MAIN BODY
For the top bracket, remove the 3
appropriate screws from the top
of the main body.
Re-insert the removed screws
through the bracket and the main
body via the appropriate holes.
For the bottom bracket, align 2 of the 4 protruding studs on the bottom
of the main body with the 2 of the holes on the bottom bracket. Fit the
studs into the holes and x using 2 of the ‘nylock’ bolts provided.
16
EXTENDED BRACKET PAIR
INSTALLING THE EXTENDED BRACKET PAIR
The extended bracket pair are designed to replace the universal
bracket pair. Therefore instructions from ‘installing the universal bracket
pair’ can be followed. The extended bracket cannot however be used
for attachment to the left or right sides of the main body, but has holes
which will allow for 3 different distances between the wall and the back
side of the main body.
Top extended bracket, use
alignment procedure discussed on
the previous page
Bottom extended bracket, align
below top bracket at the base of
the main body
A top bracket and a bottom bracket set that can only be positioned at
the back of the product but that has 3 hole positions to give clearance
between the back of the product and the wall, to allow for trunking or
other wall-based obstacles.
17
Although we recommend following
the instructions in the previous
section, brackets can be installed
facing away from the main body.
If this method is used, make sure
that the top of the KwickScreen’s
main body is level with the top of
the front handle.
ADDITIONAL NOTES / ALTERNATE METHOD
18
WARRANTY
1. Should you experience any problems with our workmanship or materials
within the rst 2 years please contact your point of purchase
2. Repairs made during the warranty period will be carried out free of charge,
provided the product has been used strictly in accordance with the guidelines
set out in this guide
3. The warranty does not cover replacements, adjustments or repairs which may
be required as a result of normal wear and tear, willful or accidental damage,
misuse, neglect or any cause which is beyond the control of SohoWerks/Kwickscreen
4. Modications and repairs made to this product by unauthorised persons will
render the warranty void
5. Only parts manufactured or approved by KwickScreen shall be used to
repair this product. Use of unauthorised parts will invalidate all warranties and
remove all liability from SohoWerks/Kwickscreen for the safety of the product
For any questions, issues or technical support,
call 888-881-8830 or visit www.sohowerks.com/kwickscreen
