202F User Guide
202F User Guide Contents
1
Introduction
Introduction.........................................................................3
Getting Started
Package Contents............................................................... 6
Parts & Functions.............................................................. 6
USIM Card Installation....................................................... 8
Using Handset Memory & SD Card.................................... 9
Charging Battery.............................................................. 12
Power On/Off................................................................... 14
Touchscreen Operations...................................................15
Basic Operations
Basic Operations...............................................................18
Handset Phone Number.................................................... 19
Mobile Manners................................................................. 20
Text Entry.........................................................................21
Google Account................................................................. 23
Google Play™.................................................................... 25
Security Codes.................................................................. 27
USIM PIN............................................................................28
Screen Lock....................................................................... 29
Software Updates.............................................................30
Handset Interface
Home Screen Basics..........................................................32
Status Bar......................................................................... 32
Notifications Window.......................................................34
Phone
Calling................................................................................ 36
Optional Services..............................................................38
Address Book.................................................................... 43
Messaging & Browser
Messaging.......................................................................... 46
Using NX! Mail.................................................................. 46
Creating/Sending Mail/SMS..............................................48
Creating/Sending Gmail....................................................50
Internet Mail Settings..................................................... 51
Web Browsing....................................................................51
Camera
Imaging...............................................................................56
Music & Images
Music Files.........................................................................60
Image Files........................................................................ 60
TV
Full Seg and One Seg....................................................... 64
Connectivity
Wi-Fi...................................................................................68
SoftBank 202F
2
Using Tethering Option....................................................69
Bluetooth®........................................................................ 70
Global Services
Calling Outside Japan...................................................... 72
Settings
About Settings..................................................................74
Wi-Fi Settings...................................................................75
Sound and Vibration Settings......................................... 77
Applications Settings.......................................................78
Accounts & Sync Settings............................................... 78
Appendix
Specifications....................................................................80
Customer Service.............................................................. 80
Safety Precautions
Safety Precautions........................................................... 82
Important Product Information.......................................87
Waterproofing/Dustproofing........................................... 91
General Notes................................................................... 93
RF Exposure Information/Specific Absorption Rate (SAR)
Information........................................................................95
Introduction
Introduction
Thank you for purchasing SoftBank 202F.
Before You Begin
・SoftBank 202F is referred to as "handset" in this guide.
・Read "Safety Precautions" and this guide thoroughly
beforehand for proper usage.
・Accessible services may be limited by contract conditions.
・Unauthorized copying of any part of this guide is
prohibited.
・Guide content subject to change without prior notice.
・Contact SoftBank Customer Support, General Information if
you find inaccuracies.
Guide Usage Notes
・Most operation descriptions are based on default settings.
・Unless noted otherwise, descriptions are for Home Screen.
・Some operation descriptions may be omitted.
・In this guide and on handset, "abroad" means "outside Japan"
with regard to handset/service usage.
・In this guide, microSD™/microSDHC™/microSDXC™ Card is
referred to as "SD Card."
・Descriptions are for default screens (home theme: NX!
Blue）of "Grace Blue" as body color.
・"Authenticate" means operations to enter password or
security code depending on the features, or fingerprint
authentication.
3
Introduction
Screenshots & Key Labels
Screenshots and Key labels are provided for reference only.
Actual handset windows, menus, etc. may differ in appearance.
Accessing Guide on Handset
Access this Guide on handset via Guide icon in Home Screen or
via Guide indicator on Status Bar. Guide indicator appears on
Status Bar by default. To hide Guide indicator:
Drag down Status Bar Tap here for Guide
Indicator off Back
・Guide usage information and confirmation for automatic
updates appear at initial startup. Follow onscreen
instructions.
SoftBank 202F
4
Getting Started
Package Contents............................................................... 6
Parts & Functions.............................................................. 6
USIM Card Installation....................................................... 8
Using Handset Memory & SD Card.................................... 9
Charging Battery.............................................................. 12
Power On/Off................................................................... 14
Touchscreen Operations...................................................15
6
Package Contents
Package Contents
・Handset (SoftBank 202F)
・Desktop Holder (FMEAC1)
・AC Charger (FMCAB1)
・クイックスタート (Japanese)
・お願いとご注意 (Japanese)
・Handset Warranty (Japanese)
・AC Charger Warranty (Japanese)
Parts & Functions
Front/Top/Bottom
Part Description
USIM Card
Slot
SD Card
Slot
Notification
Lamp
Light/
Proximity
Sensor
Earpiece
Touchscreen
Mic
Earphone
Port
TV/FM
Transmission
Antenna
Internal
Camera
External
Device Port
Insert USIM Card
Insert SD Card
Flashes for incoming transmissions
Lights for charging
Detects surrounding brightness to
automatically adjust Display or backlight
and prevents Touchscreen misoperation
during call
Hear the other party's voice here
Tap, Swipe/Flick, etc.
Speak here for calls
Works as a microphone when recording
Connect earphone
Receive TV signal/for FM Transmitter
Photograph your own face, etc.
Connect Micro USB Cable/MHL Cable
Part Description
External
Camera
Wi-Fi/
Bluetooth
Antenna
FeliCa Logo
Temperature/
Humidity
Sensor
Infrared
Port
Fingerprint
Sensor
Strap Hole
(Side)
GPS
Antenna
Internal
Antenna Area
Mobile
Light
Speaker
Charging
Terminal
Capture images
Internal Antenna for Wi-Fi and Bluetooth
function
Hold to reader/writer to use NFC/Osaifu-
®
Keitai
Detects surrounding temperature and
humidity
For infrared transmission
For fingerprint authentication, etc.
Attach strap here
Internal Antenna for GPS function
For handset transmissions
Use as camera flash
Emits tones, music, sounds, the other
party's voice for handsfree calls, etc.
For charging by Desktop Holder
7
Handset Keys
Getting Started
Part Description
Volume Up
®
Key ( )
Volume
Down Key ( )
Power Key
( )
Navigation
Bar
Desktop Holder
Lock
Hole (Sound Hole)
Speaker Duct
External Device Port
Charging Terminal
Increase Volume
Decrease Volume
Long Press for activate/deactivate
Manner mode
Toggle Sleep mode on/off
Long Press for power on/off
Onscreen navigation buttons
( / / ) and Slide display
button ( / )
SoftBank 202F
8
USIM Card Installation
USIM Card IC chip contains customer and authentication
information, including handset number.
Inserting USIM Card
Always power off first.
Open Slot Cover
・Face Display down.
・Use notch (○) to open Slot Cover as shown.
Slide Tray out
Removing USIM Card
Always power off first.
Open Slot Cover
・Face Display down.
・Use notch (○) to open Slot Cover as shown.
Slide Tray out
・Use tab (○) to draw Tray straight out.
・When inserting or removing Tray to or from USIM Card Slot,
do not apply excessive force. Tray may be damaged.
・Do not lose Tray.
・Use tab (○) to draw Tray straight out.
・When inserting or removing Tray to or from USIM Card Slot,
do not apply excessive force. Tray may be damaged.
・Do not lose Tray.
Insert USIM Card
・Confirm orientation of USIM Card (see the notch), then
place it with IC chip facing up on Tray ( ). Place Tray to
USIM Card Slot ( ), then push it slowly ( ).
Close Slot Cover
・Press down Slot Cover firmly and check there are no gaps.
Remove USIM Card
・
Remove USIM Card from Tray ( ), place Tray to USIM Card
Slot ( ) with correct orientation, then push it slowly
( ).
Close Slot Cover
・Press down Slot Cover firmly and check there are no gaps.
9
Using Handset Memory & SD Card
Handset accepts an SD Card up to 64 GB. Some SD Cards may
not operate properly.
Save captured photos and videos to SD Card and handset
internal storage.
Memory and SD Card
Use System memory and Internal storage in handset and SD
Card as follows.
Type Description
System
Memory
Internal
Storage
SD Card
1 Location for saving data varies by application settings.
System data and applications are installed
Save images, music, mail attachments,
application data1; Connect a PC for data
transmission
Save captured photos/videos; Connect a
PC for data transmission
Formatting SD Card
When using a new SD Card for the first time, format it on
handset before trying to save files, etc.
・Format Card deletes all SD Card files, even those created on
other devices.
・Format SD Card while charging Battery or after Battery is
fully charged.
In Home Screen, Settings
Storage
Getting Started
Inserting SD Card
Open Slot Cover
・Use notch (○) to open Slot Cover as shown.
Insert SD Card
・Slide in SD Card with metal contacts facing down.
・SD Card Slot is found on the upper side when handset is
placed face up.
・Do not insert other objects.
Unmount SD card OK
Menu item changes from Unmount SD card to Mount SD
card .
Erase SD card
Close Slot Cover
・Press down Slot Cover firmly and check there are no gaps.
SoftBank 202F
10
Erase SD card
Erase everything
Unmounting SD Card
In Home Screen, Settings
Storage
Handset erases all SD Card files.
・
Authenticate if Security unlock preference is set.
Unmount SD card OK
・
Menu item changes from Unmount SD card to Mount SD
card and SD Card is unmounted.
11
Removing SD Card
Always unmount SD Card first.
Open Slot Cover
・Use notch (○) to open Slot Cover as shown.
Remove SD Card
・Gently push in SD Card and release it; SD Card pops out.
Carefully remove without bending.
Close Slot Cover
・Press down Slot Cover firmly and check there are no gaps.
Important SD Card Usage Notes
Back Up Your Files
SoftBank Mobile Corp. is not liable for any damages
resulting from accidental loss/alteration of information.
Keep a copy of contacts, etc. in a separate place.
While Reading/Writing Data
Never power off while reading/writing data. Also do not
remove SD Card.
Low Battery Warning
SD Card may not read/write files correctly if Battery is
low.
Data Transfer to MicroSDXC Card
Handset supports microSDXC Cards. Use microSDXC Card
only on SDXC-compatible devices. Data may be damaged.
Exchanging Data with Non-SDXC-Compatible
Devices
To exchange data between handset and non-SDXCCompatible devices, use microSD Cards or microSDHC
Cards supported by handset and those devices. Inserting a
microSDXC Card used on handset in a non-SDXC-Compatible
device may corrupt card data. In such cases, do not format
the microSDXC Card on that device even if prompted to do
so.
Formatting deletes all microSDXC Card data and changes
the file system. The original memory capacity may
be unavailable after formatting. To use a corrupted
microSDXC Card, format it on an SDXC-compatible device.
Getting Started
Handling SD Card
Keep SD Cards out of infants' reach. Infants may swallow
them resulting in choking.
SoftBank 202F
12
Charging Battery
Battery is built into handset and not removable.
Desktop Holder
Use Desktop Holder and AC Charger FMCAB1 (USB Cable and
AC Charger).
Insert USB plug of USB Cable into AC Charger USB port
・Confirm USB plug and USB port orientation.
Insert Micro USB plug of USB Cable into Desktop Holder Micro
USB port
Place handset in Desktop Holder
Notification Lamp illuminates while charging.
・
Insert handset ( ) and press it in the direction of Lock
until it clicks ( ), then confirm that handset is securely
locked.
・Notification Lamp goes out when Battery is full. Remove
handset from Desktop Holder. Unplug AC Charger and
retract blades.
・When charging starts from Home Screen or Launcher page,
Theater mode starts.
・Insert Micro USB plug with print side facing up.
Extend blades and plug AC Charger into AC outlet
13
AC Charger
Use AC Charger FMCAB1 (USB Cable and AC Charger).
Insert USB plug of USB Cable into AC Charger USB port
・Confirm USB plug and USB port orientation.
Open External Device Port Cover and connect Micro USB plug
of USB Cable
・Insert Micro USB plug with print side facing up.
Extend blades and plug AC Charger into AC outlet
Internal Battery
Bulges
Depending on usage, bulges may appear near end of battery
life; this does not affect safety.
Replacing Battery
Internal Battery is a consumable item; may need to be
replaced if operating time shortens noticeably. Internal
Battery is not user replaceable; its replacement incurs fees
and requires handset submission to a SoftBank Shop, etc.
For details, contact a SoftBank Shop or SoftBank Customer
Support, General Information.
To check Battery performance, in Home Screen,
Settings About phone Status Battery
performance .
Handling Desktop Holder
Note the following when handling Desktop Holder.
・Do not get strap etc. caught between handset and
Desktop Holder.
・When locking handset to Desktop Holder, do not apply
excessive force.
・Do not cover Hole (Sound Hole) of Desktop Holder, or let
dust adhere on it.
・Always use AC Charger FMCAB1 with Desktop Holder.
Getting Started
Notification Lamp illuminates while charging. Notification
Lamp goes out when Battery is full.
Unplug AC Charger and retract blades
Disconnect USB Cable from handset and close External Device
Port Cover
・Press down External Device Port Cover firmly and check
there are no gaps.
Handset Use while Charging
Charging time may be longer or charging may not be
completed.
SoftBank 202F
14
Power On/Off
Power On
Power on handset and open Home Screen.
(Long Press)
Lock Screen appears.
Power Off
(Long Press)
Power off
Flick up
Home Screen appears.
・
Do no touch Fingerprint Sensor after Pressing until Lock
Screen appears. Fingerprint Sensor may not work. If alert
appears, reboot handset.
・Sliding Fingerprint Sensor cancels Screen Lock by default.
・Initial setup menu opens before Home Screen appears after
powering on for the first time.
・After set period of inactivity, handset goes into Sleep mode.
To show Lock Screen, Press /Fingerprint Sensor.
OK
Handset shuts down.
Reboot/Safe Mode Operation
Reboot
In Phone options, Restart
Start/Stop Safe Mode
In Phone options, Touch & Hold Restart OK
・When Safe mode starts, "Safe mode" appears on the lower
left of Display.
・Reboot handset to exit from Safe mode.
Touchscreen Operations
Touch Display to select menu items, open functions, scroll
pages, etc.
Tap
Tap item or key to open or execute corresponding function/
operation.
Touch & Hold
Touch item for 1+ seconds to move icons, open menus, etc.
15
Getting Started
Drag
Drag item to move it.
Swipe/Flick
Swipe/Flick to toggle sheets, pages, etc.
Pinch/Spread
Pinch/Spread to zoom in or out on images, etc.
SoftBank 202F
16
Basic Operations
Basic Operations...............................................................18
Handset Phone Number.................................................... 19
Mobile Manners................................................................. 20
Text Entry.........................................................................21
Google Account................................................................. 23
Google Play™.................................................................... 25
Security Codes.................................................................. 27
USIM PIN............................................................................28
Screen Lock....................................................................... 29
Software Updates.............................................................30
18
Basic Operations
Home Screen & Launcher
Home Screen top sheet appears at power on. Most handset
operations start from Home Screen sheets or Launcher pages.
Handset Navigation
Tap menu items, icons, onscreen key, etc. to open assigned
items.
・
Press to go back or escape.
Menu Operations
Tap for options.
Navigation Bar
Navigation buttons are located in Navigation Bar at bottom of
Display.
Part Description
Show Home Screen; Touch & Hold to
Home
button ( )
Back
button ( )
Menu
button ( )
Slide
display
button1
( / )
show recently-used applications; Touch
& Hold then Slide it to to use audio
assistance or Google search
Return to the previous screen; Hide
onscreen keyboard (turns to )
Open Menu window
Tap to slide screen down
Tap to return to full screen view
・In some windows, Touch & Hold window to show settings or
items.
Handset Settings
In Home Screen, Settings to customize settings.
・If confirmation appears, follow onscreen instructions.
1 Available when Slide display in Display setting is ON. ON is
set by default.
19
Handset & Display Orientation
In most cases, Display orientation changes with handset
orientation.
・Some application contents may not change with handset
orientation.
・Home Screen, Launcher, and Lock Screen are shown in
horizontal view only when charging with Desktop Holder.
Capturing Screens
Long Press and at the same time.
・Check captured screens in Gallery album etc.
・Capturing is not available on some application screens.
Handset Phone Number
My Phone Number
In Home Screen, Settings Profile
Handset phone number appears.
・
Alternatively, in Home Screen, (NX! Contact).
Basic Operations
SoftBank 202F
20
Mobile Manners
Manner Mode
Cancel most handset sounds to avoid disturbing others around
you.
・Camera shutter, video recording tones, etc. sound even in
Manner mode.
(Long Press)
Wi-Fi/Bluetooth® in Airplane Mode
Enabling Airplane mode disables Wi-Fi and Bluetooth®.
But they can be turned on in Airplane mode. For details,
see "Connecting to Wi-Fi Networks" and "Activating
Bluetooth®."
Tap the Manner mode to set OK
Manner mode is set.
・
Long Press and Tap the set Manner mode again to cancel.
Airplane Mode
Cancel all handset communication.
(Long Press)
Airplane mode OK
Airplane mode is set.
・
Long Press and Tap Airplane mode again to cancel.
21
Text Entry
Keyboards
Use onscreen keyboards for text entry. In Numeric keypad,
multiple characters are assigned to each key. In QWERTY
keypad, a single letter is assigned to each key. Handwritten
input is also available.
・
In any keyboard, Tap QWERTYキー / テンキー for
QWERTY keypad/Numeric keypad to switch keyboards.
・
To use handwritten input, Tap 手書き .
・
Tap (Back) to hide keyboard.
・Most operation descriptions are based on NX!input.
・If "…" is shown on key, Touch & Hold key to show options,
Slide quickly to the option and release to enter suggested
characters or perform operation. Depending on the setting,
options may not appear.
Numeric Keypad Layout
・Keypad layout may vary by application.
・
Overwrite handwritten input is enabled ( ) by default,
and blue frames are shown on keyboard. However, operation
descriptions are based on Numeric keypad with Overwrite
handwritten input disabled ( ).
Current entry mode
Enable ( )/disable ( ) Overwrite handwritten
input. When enabled, blue frames are shown on keyboard
Adjuster Bar to adjust height and width of keyboard
Show menu for switching keyboards, handwritten input,
fixed phrase, symbol, smiley, ATOK setting, Settings.
Touch & Hold to start Voice input
Move cursor
Symbol list
Toggle entry modes
Smiley/Pictogram list
Hide keyboard. Return to previous window from menu.
Delete character during text entry
Open menu to hide or fix Adjuster Bar, save/restore
keyboard width and height, etc.
Delete character before cursor
Enter space
Line feed; Move to next entry area; Execute function or
confirm text entry
Text entry
Basic Operations
SoftBank 202F
22
QWERTY Keypad Layout
・Keypad layout may vary by application.
・When Show numeric keys is disabled in QWERTY keypad
settings, Flick up/down keys to enter characters.
Current entry mode
Enable ( )/disable ( ) Overwrite handwritten
input. When enabled, blue frames are shown on keyboard
Adjuster Bar to adjust height and width of keyboard
Text entry
Toggle uppercase/lowercase; In lowercase text entry
mode, Tap (twice) to change uppercase (locked) mode
(key lights up)
Toggle entry modes
Show menu for switching keyboards, handwritten input,
fixed phrase, symbol, smiley, ATOK setting, Settings;
Touch & Hold to start Voice input
Hide keyboard. Return to previous window from menu.
Delete character during text entry
Enter space
Open menu to hide or fix Adjuster Bar, save/restore
keyboard width and height, etc.
Delete character before cursor
Line feed; Move to next entry area; Execute function or
confirm text entry
Move cursor
Handwritten Input Layout
・Keypad layout may vary by application.
Current entry mode
Adjuster Bar to adjust height and width of keyboard
Handwriting area
Show menu for switching keyboards, handwritten input,
fixed phrase, symbol, smiley, ATOK setting, Settings.
Touch & Hold to start Voice input
Hide keyboard; Return to previous window from menu.
Delete character during text entry
Open menu to hide or fix Adjuster Bar, save/restore
keyboard width and height, etc.
Line feed; Move to next entry area; Execute function or
confirm text entry
Delete character before cursor
Enter space
Move cursor
23
Toggling Text Entry Modes
Toggle entry mode between hiragana, alphabetical and
numeric.
・
shows entry mode in blue. Status Indicator also
changes.
Tap
Entry mode changes.
Google Account
Create a Google Account to use Google services. A Google
Account is required to fully use some services and
applications/functions.
Creating a Google Account
Basic Operations
In Home Screen, Settings Add account
Google
Add a Google Account appears.
New
Enter first name Enter last name
SoftBank 202F
24
Enter mail address
・If confirmation appears, follow onscreen instructions.
Enter password Re-type password
Tap entry field Enter shown characters
・Distorted characters are shown. If characters are illegible,
enter any characters and Tap for alternative.
Not now
Tap Choose a security question and Tap a question Tap
Answer Enter answer Enter Recovery email
address
・If entry field is not shown, Flick/Swipe entry area up or
down.
Join Google+ / Not now
A Google Account is added.
・
To save credit card information for payment, Tap Set
up credit card and enter information. Follow onscreen
instructions to complete.
・For the second or later Google Account, sync setting is
shown.
・Handset does not support Google Account backup.
Checkmarking Keep this phone backed up with my Google
Account ( ) is not applied.
・
To join Google+, Tap Join Google+ and Tap . Follow
onscreen instructions to complete.
・
To skip joining to Google+, Tap Not now .
In Finish account window, select necessary item ( )/
deselect ( )
25
Signing in to a Google Account
If an application requires a Google Account, Google sign in
appears. Sign in to use the application.
In Add a Google Account screen, Existing
Google Account sign in appears.
Enter mail address Tap Password field Enter
password
Google Play™
Download songs, videos, books, Android applications and games
in Google Play (Android Market™). Sign in to your Google
Account beforehand.
Installing Free Applications
Basic Operations
In Home Screen, (Play Store)
Google Play opens.
・If confirmation appears, follow onscreen instructions.
OK Follow onscreen instructions
You are signed in to your Google Account.
Google Account Cautions
Do not forget your Google Account ID and Password.
Tap application INSTALL ACCEPT
Application downloads and installs.
Purchasing Applications
In Home Screen, (Play Store)
Google Play opens.
・If confirmation appears, follow onscreen instructions.
Tap pay-for application Tap price Follow onscreen
instructions
Application downloads and installs.
SoftBank 202F
26
Updating Installed Applications
In Home Screen, (Play Store)
Google Play opens.
・If confirmation appears, follow onscreen instructions.
My apps Tap application UPDATE
ACCEPT / CONTINUE
Application downloads and installs.
Google Play Caution
Installing Applications
Download and install applications on this handset via
Google Play (developed by Google Inc.) at your own
risk. SoftBank Mobile Corp. is not responsible for user
installed application content (quality, reliability, legality,
appropriateness, accuracy, etc.) or malfunctions installed
applications may cause (due to viruses, etc.).
Purchasing Applications
Purchase applications via Google Play at your own risk.
SoftBank Mobile Corp. is not responsible for transactions
between users and third party publishers.
・If confirmation appears, follow onscreen instructions.
Purchased Applications
Payment
Pay once. Re-downloads of uninstalled applications are free
of charge.
Installations on Other Android Devices
Install same application on other Android devices under
same Google Account at no added cost.
Application Operations
Requesting Refunds
Refunds are possible within a limited time. Requesting a
refund deletes the application and cancels the invoice.
Request one refund per application.
In Google Play, My apps Tap application
REFUND Yes
Automatic Application Updates
In Google Play, My apps Tap application
Auto-update ( )
・Automatic update is not available for some applications.
27
Security Codes
Code Types
Some functions/services require these codes for use.
・Do not reveal Security Codes. SoftBank Mobile Corp. is not
liable for misuse or damages.
・If you forget Security Codes, contact us for recovery. For
more information, see SoftBank Mobile Website (http://
mb.softbank.jp/en/#pagetop).
Types Details
Center Access
Code (Call
Barring
Password)
Handset
Security Code
4-digit code in service contract:
Change services, use Optional Services via
landlines, or set call restrictions
User settable:
Use/change some handset functions/
settings
Alternatively, use Pattern, Password,
Fingerprint or Face recognition to
authenticate
Setting Security Code
Set Handset Security Code to cancel Screen Lock, etc.
・Pattern, Password (alphanumerics and symbols), Fingerprint
and Face recognition are also available for authentication.
Basic Operations
In Home Screen, Settings Security
Security unlock preference Security code
・When Security unlock preference has been already set,
authenticate.
Enter Security Code Continue Enter Security Code
again OK
Security Code is set.
SoftBank 202F
28
USIM PIN
9999 by default; enable USIM Card lock to restrict handset
use.
Enabling USIM Card Lock
Enable USIM PIN and show USIM PIN entry window when
handset with USIM Card inserted is powered on.
In Home Screen, Settings Security
PIN Cautions
Entering PIN incorrectly three times activates PIN Lock.
Enter PUK (Personal Unblocking Key) to unlock. Entering
PUK incorrectly ten times activates USIM Lock. To use
handset again, reissue USIM Card at SoftBank Shop (fees
apply). For more about PUK, contact SoftBank Customer
Support (http://mb.softbank.jp/en/customer_support/
contacts.html).
Set up USIM/RUIM card lock Lock USIM card Enter
USIM PIN OK
PIN is enabled.
Changing USIM PIN
USIM PIN can be changed only when USIM PIN is enabled.
In Home Screen, Settings Security
Set up USIM/RUIM card lock Change USIM PIN Enter
PIN OK Enter New PIN OK Enter New PIN
again OK
PIN is changed.
29
Screen Lock
When Screen Lock activates, canceling Screen Lock is required
to use handset. It prevents erroneous operation and saves
power.
Locking Screen
Activate Screen Lock with simple key operation.
・After set period of inactivity, handset goes into Sleep mode
and Screen Lock activates.
In Lock Screen, Press or Fingerprint Sensor
Handset goes into Sleep mode and Screen Lock activates.
・When Select lock in Security settings is set to Security on,
Security Lock is enabled. If Power button instantly locks is
unchecked, Security Lock does not activate immediately but
only after certain time elapses according to Automatically
lock setting.
Unlocking by Fingerprint Sensor
Cancel Sleep mode and Screen Lock. To operate Fingerprint
Sensor, Press Fingerprint Sensor or Slide your finger.
In Sleep mode, Press Fingerprint Sensor
Basic Operations
Lock Screen appears.
Slide your finger over Fingerprint Sensor
Screen Lock is canceled.
・Press Fingerprint Sensor, release your finger, and then slide
it.
・When Select lock in Security settings is set to Security on,
authenticate based on the set Security unlock preference.
Lock Screen Operation
Using Widgets
Canceling Screen Lock
In Sleep mode, Press
Lock Screen appears.
Flick up
Screen Lock is canceled.
・When Select lock in Security settings is set to Security on,
authenticate based on the set Security unlock preference.
Tap EMERGENCY CALL in the authentication window to
show onscreen dialpad and make an emergency call.
Flick right on the left side of Lock Screen Flick right
or left to show widget sheet
・Some widgets activate by Tapping.
Activating Camera
Flick left on the right side of Lock Screen
SoftBank 202F
30
Software Updates
Look for available updates. Update as required.
Automatic Software Updates
Download update file automatically and update software on
specified day and time.
Update via Wi-Fi is described here.
Receive Software update information
Downloading of update file starts automatically. When
downloading is complete, Confirm a software update window
appears.
・Alternatively, download update file via mobile network.
When appears on Status Bar, Drag down Status Bar,
and Tap New Software Available , then follow onscreen
instructions.
・If download fails due to Wi-Fi interruption etc., follow
onscreen instructions.
Manual Software Updates
In Home Screen, Settings About phone
Software Update Software Update
Check Confirm a software update in Software Update window
Specify update date
・
To update immediately, Tap Update now . Follow onscreen
instructions.
・If Confirm a software update window closes without any
operation, software update starts at the time set in Time
to start automatic update.
Set date Done Set time Done
Check if software update is required. If required,
confirmation screen to start data download appears. Follow
onscreen instructions.
Before Software Update
Handset data may be lost to damage, malfunction, etc.
Always back up important files. Back up important
information before Software Update. SoftBank Mobile
Corp. is not liable for loss or associated damages.
Setting Automatic Update
Enabling Automatic Update starts Software update at
specified time. Automatic Update is enabled by default.
In Home Screen, Settings About phone
Software Update Time to start automatic
update Set time Done
・
To disable Automatic Update, Tap Automatic Update
( ). Tapping Automatic Update toggles enable ( )/
disable ( ) Automatic Update.
Date and time are set. Notification appears on specified
date (settable in range from two minutes to one week). Follow
onscreen instructions.
Software Update Cautions
Handset cannot be used until Software Update completes;
it may take some time to complete. Confirm signal strength
and battery charge beforehand. Poor signal strength or
low Battery may disrupt updates leading to lost data or
handset malfunction.
Handset Interface
Home Screen Basics..........................................................32
Status Bar......................................................................... 32
Notifications Window.......................................................34
32
Home Screen Basics
Home Screen top sheet appears at power on and when Screen
Lock is canceled; most operations start here. Add shortcuts,
folders and widgets to Home Screen.
Layout
Item Description
Status Bar
Current
Position
Dock
Navigation
Bar
Customize
Area
Launcher
Drag down to open Notifications Window
Current Home Screen sheet position
Tap an icon to launch application or
function; User can customize with up to 4
shortcuts and folders
Show onscreen navigation buttons
( / / ) and Slide display
button ( )
Customize with application shortcuts,
folders or widgets
Open Launcher
Status Bar
Status Bar appears at the top of Display. Notification
Indicators for incoming calls etc. and Status Indicators for
handset status appear.
Status Bar
Notification Indicators
Status Indicators
Toggling Home Screen Sheets
Home Screen consists of several sheets. Add shortcuts,
widgets or folders to sheets. Swipe or Flick left/right to
toggle Home Screen sheets.
・
In any Home Screen sheet, Press to return to Home
Screen top sheet.
33
Notification Indicators
These Notification Indicators appear in Status Bar:
Icon Description
New Gmail
New Email
New NX! Mail
Urgent News
New Answer Phone Message
New Voicemail
Music Playing
Wi-Fi Available
File Received via Bluetooth
Wi-Fi Tethering On
Wi-Fi Tethering and USB Tethering On
USB Tethering On
Call Arriving
Missed Call
Call on Hold
Data Uploading
Data Downloading
Google Play Application Update Available/
Installation Complete
Comfortable Alarm Set
Syncing Trouble
FM Transmitter On
Earphone Connected (Input from Phone
MIC)
Earphone Connected (Input from Headset
MIC)
Viewing One Seg
Viewing Full Seg
Recording One Seg
Recording One Seg Scheduled
VPN Connected
Battery Doctor Notification
NX! eco
Zoomed with Best-fit zoom
Screen Orientation Locked with Shake to
unrotate
GPS Positioning
Phone Memory Low
Dolby Mobile setting On (Icon Varies by
Set Genre)
Software Update Notification
New Notification from 音声アシスト (Onsei
Assist Voice Assistant Application)
®
Status Indicators
These Status Indicators appear in Status Bar:
Indicator Description
Battery Charged
Charge Battery
Battery Charging
Signal Strength
Roaming
No Signal
4G Data in Use
3G Data in Use
Wi-Fi Connected
Bluetooth® On
Bluetooth® Connected
Airplane Mode
NFC/Osaifu-Keitai® Locked
Osaifu-Keitai® Unlocked and NFC Locked
Answer Phone Set
Speakerphone On
Mic Muted
Ringtone Volume 0
Vibration On
Manner Mode Active
Manner Mode (Silent) Active
Screen Lit with Lit when held
Kana Input Mode
Alphabet Input Mode
Number Input Mode
Handwriting Input Mode
Smiley/Pictogram/Symbol, Phrase Input
Improved sound for IP calls On
1 Also appears when Osaifu-Keitai® is locked and NFC is
unlocked.
1
Handset Interface
SoftBank 202F
34
Notifications Window
Drag down Status Bar for Notifications Window. Open
notifications to check details.
Opening Notifications Window
Drag Status Bar down
Notifications Window opens. Check notifications.
・Alternatively, Flick down Home Screen to open Notifications
Window.
Notifications Window Operation
Closing Notifications Window
Drag up
・
Alternatively, Flick Notifications Window up or Tap .
Deleting a Notification
Flick notification left/right to delete it
Customizing Status Switch
Touch & Hold Status Switch to be changed Select
function
Calling Back to Missed Call
Tap Call back for missed call notification
・
Tap Message to create SMS.
・If Call back or Message is not shown, Flick missed call
notification down.
Layout
Item Description
Status
Switches
Notifications/
Running Items
Clear
Notifications
Settings
On/Off of each function
Notification details or item setting
Delete notifications
Some notifications are not deletable
Set each function
Phone
Calling................................................................................ 36
Optional Services..............................................................38
Address Book.................................................................... 43
36
Calling
Learn calling basics, including handling incoming calls, and incall operations.
Placing Calls
In Home Screen, (NX! Dial)
Onscreen dialpad appears.
・
Alternatively, in Home Screen, (NX! Dial) to
activate NX! Dial.
・
If Log window appears, Tap Phone .
To end the call, End
Call ends.
Answering Calls
When call connects, Answer
Use onscreen dialpad to enter number
・Enter area code for landlines.
Outgoing call
Ringback tone sounds. Wait for receiver to accept call.
Talk.
・
Drag right when a call arrives in Sleep mode or while
Lock Screen is shown.
To end the call, End
Call ends.
Emergency Location Report
Using SoftBank 3G handset for emergency calls (110,
119 or 118) automatically reports handset location to
corresponding agency (police, etc.).
・Location Report does not incur registration/transmission
fees.
・Location/signal conditions affect positioning accuracy.
Always provide location and call purpose.
・Hiding Caller ID (using 184, etc.) cancels Location Report.
However, corresponding agency may obtain location
information in life threatening situations.
・Location Report is not sent for calls made while outside
Japan.
Call Operation
Stopping Ringtone
Press / when a call arrives
Declining a Call
Decline when a call arrives
・
Drag right when a call arrives in Sleep mode or
while Lock Screen is shown.
Using Answer Phone
When a call arrives, Other operations Answer
phone
・
Drag up Other operations Tap Answer phone
when a call arrives in Sleep mode or while Lock Screen is
shown.
Playing Phone Memo
In Home Screen, Drag down Status Bar Phone memo
Tap phone memo
・
To stop playback, Tap .
Putting a Call on Hold When a Call Arrives
When a call arrives, Other operations Hold
・
Drag up Other operations Tap Hold when a call
arrives in Sleep mode or while Lock Screen is shown.
・
To answer a call, Tap Answer .
Forwarding a Call
Using Push Signal
Push signal is used for services such as checking voicemail
on your home telephone, booking tickets, checking bank
balance, etc.
Use onscreen dialpad to enter phone number Touch &
Hold ＊ ("," (pause) appears) Enter push signal to
send Outgoing call
When call connects, push signal is sent automatically.
・
To enter ";" (wait), Touch & Hold ＃ . When call
connects and confirmation appears, Tap Yes to send
push signal.
Troubleshooting
Q. Why can't a call connect?
A. Area code is always required. Dial phone number
starting with 0 for the area code, etc.
A. Check signal strength. Move to a place with a good
signal and make a call.
Q. It is difficult to talk
A. In a noisy place, talking on a phone may be difficult.
A. When using speaker phone, check volume level.
Adjusting volume to too high may make it difficult to
hear.
Q. Machine sound enters during a call
A. It may sound when switching areas due to signal
conditions. It is not a malfunction.
37
Phone
When a call arrives, Other operations Call Fwd
・Set Call Forwarding beforehand.
・
Drag up Other operations Tap Call Fwd when a
call arrives in Sleep mode or while Lock Screen is shown.
Adjusting Call Volume
During a call, Press /
Putting a Call on Hold during a Call
During a call, Hold
・
To answer the call, Tap Hold again.
Emergency Location Report Cautions
Emergency Location Report is not sent in Airplane mode.
SoftBank 202F
38
Optional Services
This handset is compatible with SoftBank Optional Services.
Optional Services
Use these SoftBank Optional Services:
Service Description
Call
Forwarding
Voicemail
Call Waiting
Group Calling
Caller ID
Call Barring Restrict calls according to situation
1 Requires separate subscription.
Divert all/unanswered calls to a preset
number
Divert all/unanswered calls to Voicemail
Center; access messages via handset/
touchtone phones
1
Answer calls during a call
Switch between open lines/connect
1
multiple lines
Show or hide your number when placing
calls
Call Forwarding
In Home Screen, (NX! Dial)
Call Settings
Call settings appears.
・Alternatively, perform same operation in Log window to
open Call settings.
Voicemail/Call Forwarding
Voicemail/Call Forwarding appears.
Call Forwarding
Tap Phone number field Enter number OK
39
Voicemail
In Home Screen, (NX! Dial)
No calls / Calls
・
Set Call time when selecting Calls .
OK
Call Forwarding is set.
Phone
Call Settings
Call settings appears.
Voicemail/Call Forwarding
Voicemail
SoftBank 202F
40
Call Waiting
No calls / Calls
・
Set Call time when selecting Calls .
OK
Voicemail is set.
・
When a new message is recorded, appears in Status Bar.
Drag down Status Bar and Tap New voicemail for voice
guidance.
Requires separate subscription.
In Home Screen, (NX! Dial)
Call Settings
Call settings appears.
Call Waiting
Setting
OK OK
Call Waiting is set.
・
Call Waiting tone sounds for new call. Tap Answer to
accept the call.
41
Group Calling
Requires separate subscription.
During a call, Add call
Enter another phone number Outgoing call
Caller ID
In Home Screen, (NX! Dial)
Phone
Call Settings
When receiver accepts call, Merge calls
Group Calling begins.
Call settings appears.
Caller ID notification
Setting
OK OK
Caller ID is set.
SoftBank 202F
42
Call Barring
Restrict calls to/from specified numbers.
・Call Barring requires Call Barring Password.
・Entering incorrect Call Barring Password three times
disables Call Barring. Call Barring Password must be
changed. For details, contact SoftBank Customer Support.
・If you have previously changed Call Barring Password on a
SoftBank handset, use the new password.
・If a call is attempted while calling is restricted, a message
appears. Message may take time to appear in some areas.
In Home Screen, (NX! Dial)
Outgoing call barring / Incoming call barring
Tap incoming/outgoing restrictions OK
Enter Call Barring Password OK OK
Call Barring is set.
Call Settings
Call settings appears.
Call barring
Call barring screen appears.
Address Book
Save phone numbers, mail addresses, etc. to Address Book.
Adding New Contacts
In Home Screen, (NX! Contact)
New Contact window appears.
・
Alternatively, in Home Screen, (NX! Dial)
PhoneBook .
43
Phone
Create contact
・If account selection appears, Tap an account.
Enter items Done
Contact is saved.
Address Book Cautions
If handset is left uncharged, contacts may be altered/
lost; handset damage may also affect information recovery.
SoftBank Mobile Corp. is not liable for any resulting
damages. Keep separate copies of contacts and other
important information.
SoftBank 202F
44
Messaging & Browser
Messaging.......................................................................... 46
Using NX! Mail.................................................................. 46
Creating/Sending Mail/SMS..............................................48
Creating/Sending Gmail....................................................50
Internet Mail Settings..................................................... 51
Web Browsing....................................................................51
46
Messaging
S! Mail
Exchange long text messages with S! Mail-compatible SoftBank
handsets, other mobile providers' terminals, computers/other
email-compatible devices. Attach media files for multimedia
messaging.
・Exchange messages using NX! Mail.
SMS
Exchange short text messages (up to 140 single-byte
characters) using handset phone numbers as addresses.
・Exchange messages using NX! Mail.
Gmail
Gmail is Google's webmail service. Handset automatically syncs
with Gmail.
Using NX! Mail
NX! Mail, which supports POP, IMAP, SMTP protocols, manages
multiple mail accounts of S! Mail, SMS, Gmail, etc.
NX! Mail supports Privacy mode; set to show or hide contacts,
to notify or not to notify new mail, etc.
Setup for Wi-Fi Communication
Wi-Fi communication is also available for sending/receiving
mail. For S! Mail, setup for Wi-Fi communication is required.
When activating NX! Mail for the first time, set up Wi-Fi
communication.
In Home Screen, (NX! Mail)
・Also exchange messages using Email or NX! Mail.
Internet Mail
Use Internet Mail (POP3/IMAP4) on handset.
・Exchange messages using Email or NX! Mail.
・Set up Internet Mail accounts beforehand.
・Exchanging Internet Mail via handset syncs handset and mail
server.
・If confirmation appears, follow onscreen instructions.
OK
Setup Wi-Fi communication starts.
・
If Setup later is Tapped, from Folder list,
Edit account Tap S! Mail account Setting up
Wi-Fi communication OK OK to set up Wi-Fi
communication later.
OK
Wi-Fi communication setup is complete.
Adding Accounts
47
Add accounts such as Gmail account, Internet mail account for
using NX! mail.
・S! Mail account is set by default. SMS is available as well.
In Home Screen, (NX! Mail)
Folder list appears.
・
Alternatively, in Home Screen, (NX! Mail) to
activate NX! Mail.
・
If Folder list does not appear, Tap or several
times.
Google account set on terminal / Another account
Enter mail address and password Next
・
When Google account set on terminal is Tapped in Step
, enter password Next Go to Step .
Messaging & Browser
Edit account
Account list appears.
・
Alternatively, Tap Settings Account
settings to show Account list.
Add new account
IMAP / POP
・If message indicating that mail server is not found, enter
information in incoming/outgoing mail server settings, and
then follow onscreen instructions.
Edit the account name display, Account icon, Name displayed
in outgoing email as required Finished
An account is added.
・Tap the account icon to change its color and set photo
saved in Gallery. Name and icon for S! Mail account are not
changeable.
SoftBank 202F
48
Creating/Sending Mail/SMS
Creating/Sending Mail
In Home Screen, (NX! Mail)
Tap To field Enter mail address
・Enter name or mail address saved in Contacts to show
candidates.
・
Alternatively, Phonebook / Outgoing history /
Incoming history Select recipients.
Folder list appears.
・
If Folder list does not appear, Tap or several
times.
New email
New email window appears.
・
Alternatively, Tap New email in Mail list to open New
email window.
Tap From field Select an account
Tap Subject field Enter subject
Tap Enter message here. field Enter text Send
Mail is sent.
OK
Operation is complete.
49
Creating/Sending SMS
In New email window, Tap From field SMS
New SMS window appears.
Tap To field Enter phone number
Creating/Sending Mail/SMS
Choosing Mail Address or Phone Number of
Recipient
When several mail addresses or phone numbers are saved
for recipient, easily switch them.
In New email/SMS window, Tap To field Tap mail
address or phone number
Deleting Address
In New email/SMS window, Tap To field Delete
address / Delete phone number OK
Discarding Message
In New email/SMS window, OK
・
When keyboard is shown, Tap OK .
Saving Message as a Draft
In New email/SMS window, Save
Messaging & Browser
・Enter name or phone number saved in Contacts to show
candidates.
・
Alternatively, Phonebook / Outgoing history /
Incoming history Select recipient.
Tap Enter message here. field Enter message Send
SMS is sent.
Message is saved in Draft folder.
・Unsendable message is also saved in Draft folder.
SoftBank 202F
50
Creating/Sending Gmail
To use Google Mail, create a Google Account and sign in
beforehand.
Creating/Sending Gmail
In Home Screen, (Gmail)
Inbox appears.
・If confirmation appears, follow onscreen instructions.
Creating Gmail
Adding Cc/Bcc
In Compose window, Add Cc/Bcc Add Cc/
Bcc
Attaching Photos or Video
In Compose window, Attach picture / Attach
video Select files
Saving Message as a Draft
In Compose window, Save draft
Message is saved as a draft.
Discarding Message
In Compose window, Discard OK
Compose window appears.
Enter To, Subject, and message text
Gmail Caution
Barring Internet Mail on handset blocks Gmail messages.
Message is sent.
51
Internet Mail Settings
Adding Accounts
Check usernames (user IDs), passwords, server names, etc. of
your Internet Mail accounts beforehand.
In Home Screen, (Email)
Account setup menu opens (if no account is set up).
Enter mail address and password Next
Web Browsing
Use Browser to access the Internet.
Using Browser
In Home Screen, (Browser)
Browser opens.
・
Alternatively, in Home Screen, (Browser) to open
Browser.
Messaging & Browser
Account setup menu opens.
・Operation may differ depending on the mail service. Tap
Manual setup to configure incoming/outgoing server
settings directly.
Enter items for account setup menu Next
Internet mail account is set.
・Operation may differ depending on the mail service.
SoftBank 202F
52
Adding Bookmarks
In Home Screen, (Browser)
Browser opens.
Open target page Save to bookmarks
Opening New Tabs
Open up to 16 pages in different tabs to switch between
pages easily.
In Home Screen, (Browser)
Browser opens.
Add bookmark window opens.
Check/edit label, URL, etc. OK
Current webpage is added to Bookmarks.
Tab index appears.
・Dragging screen down shows address bar.
New tab appears.
・Tap tab in tab list to change it.
Using SSL/TLS
Secure Sockets Layer (SSL) and Transport Layer Security
(TLS) are encryption protocols that secure Internet
transmissions of important/sensitive information such
as credit card numbers and corporate secrets, providing
protection against online threats (eavesdropping,
falsification, impersonation, etc.). Handset is preloaded
with digital certificates issued by certificate authorities.
SSL/TLS Caution
When a security notice appears upon opening a webpage,
subscribers must decide for themselves whether or not to
open the page. Opening secure pages constitutes agreement
to the terms of SSL/TLS usage. SoftBank Mobile Corp.,
VeriSign Japan and Cybertrust cannot be held liable for any
damages associated with the use of SSL/TLS.
53
Messaging & Browser
SoftBank 202F
54
Camera
Imaging...............................................................................56
56
Imaging
Camera optimizes settings according to the subjects or scenes.
Capture photos and videos with simple operations.
Capturing Photos
・Captured photos are saved to SD Card by default.
In Home Screen, (Camera)
Camera Viewfinder appears.
・
Alternatively, in Home Screen, (Camera) to open
Viewfinder.
・Alternatively, Flick left on Lock Screen to open Viewfinder.
・
If Viewfinder does not open, Tap MENU Still .
・If confirmation appears, follow onscreen instructions.
Recording Videos
・Recorded videos are saved to SD Card by default.
In Home Screen, (Camera)
Camera Viewfinder appears.
MENU Video
Video Viewfinder appears.
・
Alternatively, in Viewfinder, Tap Video to
activate.
・If confirmation appears, follow onscreen instructions.
Frame subject in Viewfinder
Auto focus activates. Focus frame turns to green when the
subject is focused on.
・Handset recognizes face and automatically focuses on it.
・If Auto focus fails, focus frame turns to red.
(Shutter)/
Shutter clicks and photo is saved.
・When Touch shutter is enabled, Tap subject to focus on and
capture.
・When number of savable photos is 99 or less, savable
number appears.
Frame subject in Viewfinder (Record)/
Auto focus activates, recording start sound sounds and
then recording starts.
・When subject is already focused on, handset starts
recording.
Camera Cautions
57
Tap (End recording)/ to end recording
Recording end sound sounds and video is saved.
・
While recording, Tap to capture a photo. Shutter does
not sound at this time. Captured photos are saved.
・Tap subject while recording to change focus point. Focus
lock does not sound at this time.
・If confirmation appears, follow onscreen instructions.
Imaging Notes
Photo File Format
Photos are saved as JPEG files.
Video File Format
Videos are saved as MP4 (H.264) files.
Keep Lens Clean
Fingerprints/smudges may hinder handset imaging. Clean
Lens with a soft cloth beforehand.
Avoid Direct Sunlight Exposure
Do not expose Lens to direct sunlight for extended
periods; may color filter, altering images.
If Battery Is Low When Using Camera
Camera uses battery power quickly. If Battery is low when
using Camera, Viewfinder may be dark, captured photo may
be distorted, or Camera may end automatically. Flash may
be dark.
Using Camera When Handset Is Hot
If Camera is used when handset is hot, alert may appear
and Camera may end.
Launching from Other Application
When Camera is launched from NX! Mail etc. with Max
13MP 4128x3096/Max pix wide 4128x2336 set as picture
size, setting may be automatically changed to Fit screen
1920x1080.
Camera
Capturing/Recording Operation
Zooming
Pinch in/out Viewfinder
Subject is zoomed out/in.
・Zoom in/out while recording.
・While zooming in/out, Zoom slider appears. Drag Zoom
slider to zoom in/out.
Checking Captured Photos and Videos in Gallery
Flick left in Viewfinder
Gallery opens and shows photos/videos.
・
To show Viewfinder from Gallery, Tap or Flick the
last photo/video right.
Warning on Flash
Do not position Flash close to eyes. Do not look at Flash
directly while in use. Do not point Flash at eyes of others.
It may harm eyesight.
SoftBank 202F
58
Music & Images
Music Files.........................................................................60
Image Files........................................................................ 60
60
Music Files
Playing Music Files
Supported file formats (extension): aac, mp4, m4a, mp3, 3gp,
3g2, amr, awb, mkv (Video with sound only), wav, ogg, flac,
wma, mid, xmf, mxmf, rtttl, rtx, ota, imy.
・Some files in these file formats may not be playable.
In Home Screen, (Play Music)
Music Library appears.
Image Files
Viewing Images
View photos and videos saved on handset or SD Card. See
below for supported file formats.
・Some files in these file formats may not be playable.
Type File Format
Photos JPEG, BMP, GIF1, PNG, WebP
Videos H.263, H.264, MPEG-4, WMV9, VP8
1 GIF Animation is not available.
In Home Screen, (Gallery)
Flick Display left/right to select category (ALBUMS, etc.)
List of songs appears.
Tap item Tap a song
Album index appears.
Tap an album
Photo/video list appears.
Tap image to view it
Song plays.
Playing Music on Lock Screen
After set period of inactivity during music playback,
Screen Lock activates. Press or Fingerprint Sensor for
Operation panel to enable playback operation.
Image appears.
Saving Location for Photos/Videos
In album/photo/video list, files/folders shown with are
saved on SD Card. Files/folders shown with / are
saved in Internal storage. For files/folders synced with an
online album, the icon of the online album may be shown.
Operation in Gallery
Brightening Image to View
In Albums, Setting Brightness up
・
Tap Brightness up to enable ( )/disable ( ).
Activating Camera
In album/photo/video list,
Slideshow
61
In photo list, Slideshow
Moving/Copying Data
In album/photo/video list, Touch & Hold data to move/
copy Move/Copy Select where to save
Yes
・Alternatively, in photo/videos list, Tap data to move/
copy Move/Copy Select where to
save Yes .
Sharing Photos/Videos with Applications
In photo/video window, Tap application
Follow onscreen instructions
・
Next to , recently-used application icon appears.
Music & Images
SoftBank 202F
62
TV
Full Seg and One Seg....................................................... 64
64
Full Seg and One Seg
Both Full Seg and One Seg are available (only in Japan).
Settings
In Home Screen, (TV)
"使用許諾" window appears.
同意する
Watching Television
In Home Screen, (TV)
TV window appears.
・If confirmation appears, follow onscreen instructions.
(Channel) in Control Bar
"チャンネルリスト作成" window appears.
地域を選択してスキャン
・
Tap 受信チャンネルをスキャン to scan available stations
and set channels.
Tap region Tap prefecture Tap area
Channel scan (searching) starts. Channel list appears when
channels are set.
保存
TV activates.
Channel list appears in information area.
Tap a channel
Selected channel window appears.
・Alternatively, Swipe/Flick service area left/right to switch
channel.
Troubleshooting
Q. Cannot activate TV
A. Battery may be low. Charge Battery.
Q. Cannot watch TV
A. Fully extend TV Antenna, check reception. If reception
is poor, move to a place with good reception. If inside
of a building, moving near windows may improve
reception.
・If confirmation appears, follow onscreen instructions.
Important Notes on TV
About Full Seg
Use Full Seg while charging Battery or with Battery fully
charged.
Full Seg may not be received while moving, out of service
area, etc. When "自動切替" is set by View controller, it is
switched to One Seg automatically in such cases.
Background Play
If Home Screen appears or handset goes into Sleep mode
while watching TV, TV is played in background and sound
is heard. To stop background play, open TV window and
Double-tap or end TV from テレビ終了 .
Background play ends after two hours elapses.
Do Not Use TV under Following Conditions
Do not use TV while riding a bicycle or motorcycle, or
driving a car. Pay attention to the surrounding traffic
when walking.
65
Using Abroad
TV is not available due to different broadcast frequencies
and formats abroad.
Channel Setting
Channel setting using area selection may not be available
when the broadcasting frequency is changed or in some
areas. In this case, set channels again.
Watching TV for a Long Time
Watching TV at a loud volume may affect hearing. Handset
may also become warm and cause low-temperature burns by
skin contact.
Auto Ending TV
TV ends automatically when battery level is less than 2%.
Using TV When Handset Is Hot
If TV is watched when handset is hot, alert may appear and
TV may end.
TV
Playable Recorded Data
If recording time is extremely short, data may not be
playable.
Recording Programs
Depending on broadcasting stations, different programs
may be broadcasted in Full Seg and One Seg. Even if
Full Seg program is watched, One Seg program might be
recorded.
SoftBank 202F
66
Connectivity
Wi-Fi...................................................................................68
Using Tethering Option....................................................69
Bluetooth®........................................................................ 70
68
Wi-Fi
Use household Wi-Fi networks, etc. to connect to the Internet.
Connecting to Wi-Fi Networks
Select from available networks to establish a connection.
In Home Screen, Settings Wi-Fi
Wi-Fi settings appears.
Automatic Updates for Optimizing WiFi Connection
While using Wi-Fi, updates for optimizing connection may
be received or applied automatically.
Wi-Fi Operations
Checking Connected Access Point
In Wi-Fi settings, Tap access point
Connecting Status, Signal strength, Link speed, Security
and IP address are shown.
OFF
Wi-Fi is enabled ( ).
・
Tap ON to disable Wi-Fi.
Tap access point Enter password Connect
Handset connects to Wi-Fi network.
・A Wireless LAN router in your home may have a sticker with
a password for WEP, WPA, and KEY. For details contact
your router manufacturer. Also, please check your provider's
contract for the password for Public Wireless LAN.
・Unsecured networks do not require password entry.
69
Using Tethering Option
Tethering Option
Use handset like a Wi-Fi router to access the Internet from a
PC or game devices.
・Requires separate subscription.
・Use after confirming that handset is updated to the latest
software.
Activating Tethering Option
In Home Screen, (Tethering)
Tethering Option Help
In Home Screen, (Tethering)
Tethering Option window appears.
・
When Terms of Agreement appears, read and Tap Agree .
Help
Tethering Option window appears.
・
When Terms of Agreement appears, read and Tap Agree .
Help window (Japanese) appears.
Follow onscreen instructions
Description of each item appears.
USB Connection
To use tethering function via USB connection, install the
USB driver beforehand. Download the driver from the
Fujitsu website.
Connectivity
SoftBank 202F
70
Bluetooth
Connect handset to other Bluetooth® devices for wireless
connectivity.
Activating Bluetooth
・Handset may not pair with all Bluetooth® devices.
・Some paired devices may not operate correctly.
・Noise may occur when using wireless/handsfree devices.
In Home Screen, Settings Bluetooth
®
®
OFF
Bluetooth® is enabled ( ).
・
Tap ON to disable Bluetooth®.
・If confirmation appears, follow onscreen instructions.
Trouble Shooting
Q. Why can't I use Bluetooth®?
A. Airplane mode may be active. Bluetooth® is not
available in Airplane mode.
・Bluetooth® can be enabled again while in Airplane
mode.
Global Services
Calling Outside Japan...................................................... 72
72
Calling Outside Japan
International Calling
In Home Screen, (NX! Dial)
Onscreen dialpad appears.
・
If Log window appears, Tap Phone .
Touch & Hold
Global Roaming
Place calls the same way you would within Japan.
・Do not enter country code or omit first 0 from phone
numbers.
In Home Screen, (NX! Dial)
Onscreen dialpad appears.
・
If Log window appears, Tap Phone .
＋ appears.
Omit first 0 from phone numbers when placing international
calls
・Do not omit first 0 from phone numbers when dialing Italy
(39).
Use onscreen dialpad to enter phone number
Outgoing call
Ringback tone sounds. Wait for receiver to accept call to
talk.
Outgoing call
Ringback tone sounds. Wait for receiver to accept call to
talk.
Settings
About Settings..................................................................74
Wi-Fi Settings...................................................................75
Sound and Vibration Settings......................................... 77
Applications Settings.......................................................78
Accounts & Sync Settings............................................... 78
74
About Settings
About Settings
In Home Screen, Settings to customize settings.
・
Tap More... to show/hide some settings.
Item Description
Profile Check handset phone number.
Initial
settings
Wi-Fi Enable Wi-Fi connection.
Easy Wi-Fi
registration
SoftBank
Wi-Fi Spot
settings
Miracast
Bluetooth Enable Bluetooth® connection.
FM
transmitter
Data usage Check mobile data usage and set limit.
Airplane mode
VPN settings Add a VPN.
NFC/OsaifuKeitai
Settings
Mobile
networks
Bluetooth
Low Energy
Settings
Sound and
Vibration
Display Set Wallpaper, Display brightness, etc.
Multimedia
Storage
Battery Check Battery usage.
NX! eco
Apps
Location
access
Security
Make necessary settings for handset use.
Easily connect to an AOSS-, WPScompatible Wireless LAN access point.
Set SoftBank Wi-Fi Spot.
Show handset screen on your TV or
monitor via Wi-Fi Direct.
Send played music or audio via FM and
listen with a car FM radio, etc.
Disable handset transmissions without
powering off.
Lock NFC/Osaifu-Keitai® function, change
password, etc.
Set networks and a network operator.
Set actions when a BLE (Bluetooth® Low
Energy) device is connected.
Set ringtone, confirmation tones, etc.
Set image quality, sound quality for
photos or videos.
Check handset and SD Card memory space.
Also perform SD Card mount and erase SD
Card data.
Turn off Display backlight, running
functions to reduce battery consumption
when Battery reaches a specified level or
at a specified time.
Check/manage installed and running
applications.
Enable/disable location access.
Make security settings such as setting
Screen Lock, USIM Card Lock, managing
authentication information.
Enter user information before using
My physical
profile
Slide-in
function
Language &
input
Data reset Delete all handset system memory files.
Add account
Date & time Set functions for date and time.
Accessibility Set functions for text-to-speech, etc.
About phone Check handset status.
In Home Screen, Settings
Settings window appears.
Set each item
Item is set.
health-conscious apps and widgets. Also
set Voice adjust, Step/Activity counter
app, etc.
Set Slide-in function for launching apps,
capturing screens, etc. by sliding from
edge of screen (Slide Spot).
Set functions for language and text entry.
Create/add accounts and synchronize
accounts.
Wi-Fi Settings
Wi-Fi Settings
In Home Screen, Settings
Wi-Fi
75
Tap access point Enter password Connect
Handset connects to Wi-Fi network.
・A Wireless LAN router in your home may have a sticker with
a password for WEP, WPA, and KEY. For details contact
your router manufacturer. Also, please check your provider's
contract for the password for Public Wireless LAN.
・Unsecured networks do not require password entry.
Wi-Fi settings appears.
OFF
Wi-Fi is enabled ( ).
・
Tap ON to disable Wi-Fi.
Settings
SoftBank 202F
76
Operation When Wi-Fi Is Connected
Connecting with Wi-Fi Direct Device to
Exchange Data
In Wi-Fi setting window, Wi-Fi Direct Tap
a device Invitation is accepted on the device
・Setting is available when Wi-Fi is ON.
Enable/Disable Network Notification
In Wi-Fi setting window, Advanced
Network notification
・Setting is available when Wi-Fi is ON.
・
Tap Network notification to enable ( )/disable ( )
setting.
Setting Wi-Fi Sleep Policy
In Wi-Fi setting window, Advanced Wi-Fi
sleep policy Tap an item
Enabling/Disabling Auto-IP Setting
In Wi-Fi setting window, Advanced auto-IP
setting
・
Tap auto-IP setting to enable ( )/disable ( )
setting.
・Setting is available when Wi-Fi is OFF.
・When auto-IP setting is enabled and if correct IP address
is not assigned, fixed IP address is given. In this case,
Internet connection is not available and message that
connection is limited is shown.
Enable/Disable Wi-Fi Non-Connection for
Unstable Connection
In Wi-Fi setting window, Advanced Avoid
poor connections
・
Tap Avoid poor connections to enable ( )/disable
( ) setting.
Specifying Frequency Band
In Wi-Fi setting window, Advanced Wi-Fi
frequency band Tap an item
Saving Battery When Wi-Fi Is ON
In Wi-Fi setting window, Advanced Wi-Fi
optimization
・
Tap Wi-Fi optimization to enable ( )/disable ( )
setting.
Checking MAC Address
In Wi-Fi setting window, Advanced
・MAC address is shown below MAC address.
Checking IP Address
In Wi-Fi setting window, Advanced
・IP address is shown below IP address.
Sound and Vibration Settings
Sound and Vibration Settings
Set Manner mode, Volume, phone ringtone, etc.
Item Description
Volumes Adjust volume levels.
Alert
sensitivity
Manner mode Set Manner mode.
Turn off
sound when
flipped
MIC input
Phone
ringtone
Notification
LED
Vibrate when
ringing
Notification
sound
Dial pad touch
tones
Touch sounds
Screen lock
sound
Charge
vibrate
Vibrate when
touch
Distinct touch Vibrate when Tapping icon, etc.
Vibration
level
Increase
vibration level
when walking
Automatically adjust volume levels
according to the ambient noise.
Set to stop ringtone and vibration by
flipping handset over.
Set Mic when stereo earphones are
connected.
Set phone ringtone.
Set notification LED.
Enable/disable vibration for ringtone.
Set notification sound.
Enable/disable dialpad tones.
Enable confirmation tones when Tapping a
menu.
Enable tone when locking/unlocking
screen.
Enable vibration when charging starts/
ends.
Vibrate when unlocking screen.
Set vibration level for Distinct touch.
Set vibration level for Distinct touch
when walking.
77
Sound and Vibration
Set each item
Item is set.
Settings
In Home Screen, Settings
SoftBank 202F
78
Applications Settings
Applications Settings
Check installed applications and running applications. Also
uninstall applications.
Item Description
DOWNLOADED Check downloaded applications.
RUNNING Check running applications.
ALL Check all applications.
In Home Screen, Manage apps
Accounts & Sync Settings
Accounts & Sync Settings
Add accounts and set Sync.
In Home Screen, Settings
Add account
Apps window appears.
・
Alternatively, in Home Screen, Settings
Apps .
Flick left/right to switch tabs Tap an application
Check application information.
・Uninstalling, force-stopping, disabling, etc. can be done for
some applications.
Add an account window opens.
Select an account type Follow onscreen instructions
An account is set.
Setting Applications to Be Synced by
Account
In setting window, Tap type of account Tap account
Tap items
・
Tap an item to enable ( )/disable ( ) setting.
Appendix
Specifications....................................................................80
Customer Service.............................................................. 80
80
Specifications
Handset
Item Description
1
Weight
Continuous
Talk Time
Continuous
Standby
Time
Charging
Time
Dimensions (W
x H x D)
Maximum
Output
1 Approximate value
1
1
1
1
Battery
Item Description
Voltage 3.8 V
Type Lithium-ion
Capacity 3020 mAh (12 Wh)
158 g
3G: 1010 minutes
GSM: 680 minutes
4G: 510 hours
3G: 690 hours
GSM: 720 hours
190 minutes
69 x 139 x 9.8 mm
4G: 0.2 W
3G: 0.25 W
GSM: 2 W
Customer Service
For SoftBank handset or service information, call General
Information.
For repairs, call Customer Assistance.
SoftBank Customer Support
General Information
From a SoftBank handset, dial toll free at 157
From a landline/IP phone, dial toll free at
0800-919-0157
Customer Assistance (Repairs/Lost
Handsets)
From a SoftBank handset, dial toll free at 113
From a landline/IP phone, dial toll free at
0800-919-0113
If you cannot reach a toll free number, use the number
(charges apply) below for your service area:
Hokkaido Area, Tohoku Area, Hokuriku Area, Kanto &
Koshinetsu Area: 022-380-4380
Tokai Area: 052-388-2002
Kansai Area: 06-7669-0180
Chugoku Area, Shikoku Area, Kyushu & Okinawa Area:
092-687-0010
Smartphone Technical Support Center
From a SoftBank handset, dial toll free at 151
From a landline/IP phone, dial toll free at 0800-1700-151
SoftBank Mobile Global Call Center
From outside Japan, dial +81-3-5351-3491 (toll free from
SoftBank handsets)
If handset is lost/stolen, call this number immediately
(international charges apply)
Safety Precautions
Safety Precautions........................................................... 82
Important Product Information.......................................87
Waterproofing/Dustproofing........................................... 91
General Notes................................................................... 93
RF Exposure Information/Specific Absorption Rate (SAR)
Information........................................................................95
82
Safety Precautions
Read safety precautions before using handset.
Observe precautions to avoid injury to self or others, or
damage to property.
SoftBank Mobile Corp. is not liable for any damages resulting
from use of this product.
Safety Precautions
These labels indicate the degree of risk from improper use.
Make sure you thoroughly understand their meanings before
reading on.
Mark Descriptions
Great risk of death or serious injury
from improper use
Risk of death or serious injury1 from
improper use
Risk of minor injury2 or damage to
property3 from improper use
1
Handset, USIM Card, AC Charger,
Desktop Holder
Use specified AC Charger and Desktop Holder
only.
Non-specified accessory use may cause Battery to leak,
overheat, burst or ignite, or cause AC Charger to overheat,
ignite, malfunction, etc.
Do not disassemble, modify or solder.
May cause fire, injury, electric shock or malfunction.
Battery may leak, overheat, burst or ignite.
Modifying handsets is prohibited by the Radio Law and
subject to penalty.
1 Serious injury includes: Loss of eyesight, physical injury,
high temperature burns, low temperature burns, electric
shock, fractures, poisoning and other conditions having side
effects or requiring hospitalization or long term treatment.
2 Minor injury includes: Physical burns (high-temperature and
low-temperature), electric shock, and other conditions not
requiring hospitalization or long-term treatment.
3 Damage to property includes: Incidental damage to
structures and household property and/or to pets and
livestock.
These symbols indicate prohibited or compulsory actions. Make
sure you thoroughly understand their meanings before reading
on.
Mark Descriptions
Prohibited actions
Disassembly prohibited
Exposure to liquids prohibited
Use with wet hands prohibited
Keep away from water.
Do not let liquid-exposed handset/related hardware remain
wet. Doing so may cause overheating, electric shock, fire,
injury or malfunction. Use handset/related hardware
properly/appropriately.
Do not charge Battery in or use or expose
handset/related hardware to extreme heat (e.g.
near fire or source of heat, in direct sunlight,
inside vehicles, etc.). Do not charge, use or
leave handset/related hardware in a place
where heat collects, such as under a kotatsu
(blanketed warming table) or next to a kairo
(worn warming patch), etc.
May cause warping/malfunction; Battery may leak,
overheat, ignite or burst. Handset or related hardware may
become too hot to touch, leading to burn injuries, etc.
Compulsory actions
Unplug AC Charger from outlet
Do not force AC Charger into handset.
Battery may leak, overheat, burst, ignite, etc.
83
Do not put handset, AC Charger or Desktop
Holder in cooking appliances such as a
microwave or pressure cooker or on IH cooking
heaters.
May cause Battery to leak, overheat, burst or ignite or
cause handset or AC Charger to overheat, emit smoke,
ignite or cause malfunction.
Keep handset off and do not charge Battery
near gas station or places with fire/explosion
risk.
Handset use near petrochemicals or other flammables
may cause fire/explosion. Be sure to power off handset
before using NFC/Osaifu-Keitai® in filling stations. (When
NFC/Osaifu-Keitai® Lock is set, power off handset after
unlocking setting.)
Do not drop, throw or otherwise subject to
strong force or impact.
Battery may leak, overheat, burst, or ignite, and may result
in fire, cause electric shock, malfunction, etc.
Take these actions in case of odd sound, odor,
smoke or abnormalities:
Do not place handset on unstable/uneven
surfaces.
Handset or related hardware may fall, resulting in injury,
malfunction, etc.; take added care when Vibration is set or
while charging.
Keep handset and related hardware out of
infants' reach or pets.
Infants or pets may swallow handset or related hardware
resulting in injuries.
A guardian should supervise use by children and
insure handset is used as instructed.
Failure to do so may result in injuries.
Handset
Internal Battery type is as follows.
Symbol
on Label
Li-ion00 Lithium-ion
Battery Type
1. Grasp AC Charger and unplug it.
2. Power off.
Continued use may cause fire, electric shock, etc.
Keep liquids (water, pet urine, etc.) and
conductive material (pencil lead, metal parts,
necklaces, hairpins, etc.) away from charging
terminal of Desktop Holder, External Device
Port and Earphone Port.
May cause short circuit, resulting in fire, malfunction, etc.
Do not dispose of handset in fire.
Battery may leak, burst, ignite, etc.
Do not damage (nail, hammer, stomp, etc.)
handset or subject it to strong impact.
Battery may leak, overheat, burst, ignite, etc.
If battery fluid gets into eyes, do not
rub; rinse with water and consult a doctor
immediately.
May cause blindness.
Safety Precautions
SoftBank 202F
84
Do not use handset while driving a vehicle,
motorbike or riding a bicycle.
May cause an accident. Drivers/riders using handsets while
driving/riding are subject to prosecution. Stop your vehicle
and park in a safe place before using handset.
Power off near electronic devices or equipment
operating on high precision control or weak
signals.
May cause electronic malfunctions, etc.
*Take added care near these devices: Hearing aids,
implanted cardiac pacemakers, implanted cardioverter
defibrillators, other electronic medical equipment, fire
detectors, automatic doors, and other automatically
controlled devices or equipment.
If battery fluid contacts skin or clothes,
discontinue handset use and rinse with clean
water immediately.
May cause skin damage.
If Battery does not charge after specified
time, stop charging.
Battery may leak, overheat, burst, ignite, etc.
Power off before boarding aircraft to avoid
possible radio wave interference with aircraft
operations.
If mobile phone use is allowed on board, follow airline or
cabin crew instructions regarding handset use.
Users with a heart condition should adjust
ringtone Vibration and Volume as needed.
May cause heart damage.
During thunderstorms, power off immediately
and seek shelter.
Lightning strikes or electric shock may occur.
Do not send via infrared aiming someone's eye.
May affect eyes.
Do not position Flash close to the faces of
others. Do not look at Flash directly while in
use. Do not point Flash at the eyes of others.
It may harm eyesight. Do not photograph infants up close.
Flash may impair vision, causing accidents.
Do not use handset when it may affect a
vehicle's electronic equipment.
Handset use may affect devices and lead to unsafe driving.
85
Use FM Transmitter only in Japan. FM
Transmitter uses weak signals requiring no
license as a radio station under Japanese laws
and regulations. Using this function abroad may
be subject to prosecution.
If you experience any skin irritation associated
with handset use, discontinue handset use and
consult a doctor.
Metal and other materials may cause skin irritation, rashes,
or itchiness depending on your physical condition.
Keep handset away from magnetic cards, etc.
Data on bank cards, credit cards, telephone cards, floppy
disks, etc. may be lost.
Do not swing handset by Strap, etc.
Handset may harm yourself or others or Strap may break
resulting in injury or handset malfunction/ breakage.
Handset may become hot while in use,
especially in high temperatures.
Do not dispose of handset with ordinary
refuse.
Take handset to a SoftBank Shop, or follow the local
disposal regulations.
Prolonged contact with skin may cause low-temperature
burn injuries.
Always maintain some distance from Speaker
while ringtones, music or other handset sounds
play.
Excessive volume may damage ears or hearing.
Watch TV from a distance in good light.
May impair vision.
Moderate handset Volume when using Headsets.
Prolonged use and excessive volume may damage ears or
hearing.
Safety Precautions
SoftBank 202F
86
Desktop Holder, AC Charger
Do not cover/wrap with clothing or bedding
while charging.
Heat may build up resulting in fire, malfunction, etc.
Use specified power supply and voltage.
May cause fire, malfunction, etc.
AC Charger: 100 V to 240 V AC (household AC outlet only)
Do not use commercially available voltage converter, as
when travelling. Doing so may cause fire, electric shock or
malfunction.
Do not touch AC Charger if thunder is audible.
May cause electric shock, etc.
Grasp AC Charger and unplug it before
cleaning.
May cause electric shock, etc.
Always grasp AC Charger (not USB Cable) to
disconnect it.
Unplug AC Charger if you are not going to use
it for long periods.
May cause electric shock, fire or malfunction.
If liquids (water, pet urine, etc.) seep inside AC
Charger, unplug it immediately.
May cause electric shock, smoke or fire.
If plug is dusty, grasp AC Charger and unplug
it, then clean with a dry cloth.
May cause fire.
When plugging AC Charger into outlet, keep
conductive materials (pencil leads, metal
parts, necklaces, hair pins, etc.) away from AC
Charger plug/terminals and plug AC Charger
firmly into outlet.
May cause electric shock, short circuit, fire, etc.
Do not plug in/unplug AC Charger with wet
hands.
May cause electric shock or malfunction.
Pulling USB Cable may damage cord, causing electric shock,
fire, etc.
Do not subject AC Charger to strong shock or
impact while it is plugged into the outlet.
May cause injury or malfunction.
Do not touch Charging Terminal of Desktop
Holder for a long time while charging.
May result in low-temperature burns.
Do not touch Charging Terminal with your
hands, fingers, etc.
May cause electric shock, injury or malfunction.
Handset Use & Electronic Medical
Equipment
This section is based on "Guidelines on the Use of Radio
Communications Equipment such as Cellular Telephones and
Safeguards for Electronic Medical Equipment" (Electromagnetic
Compatibility Conference, April 1997) and "Guidelines for
Prevention of Effects of Radio Waves from Various Equipment
Using Radio Waves on Implantable Medical Equipment"
(Ministry of Internal Affairs and Communications, January
2013).
Persons with an implanted pacemaker or
defibrillator should keep handset at least 15
cm away from the device.
Radio waves may interfere with implanted pacemakers or
defibrillators.
When using electronic medical equipment
(other than implanted cardiac pacemakers/
defibrillators) outside medical facilities, check
with the equipment vendor or distributor for
information about the effects of radio waves.
Handset radio waves may affect electronic medical
equipment.
Handset radio waves may affect electronic
medical equipment. Observe these guidelines in
medical institutions:
・Do not take handset into operating rooms, or intensive
or coronary care units.
・Keep handset turned off in hospital wards.
・Even in lobbies or other places where handset use
is permitted, keep handset off near electronic medical
equipment.
・Follow medical facility rules on handset use.
There may be someone who is wearing an
implanted pacemaker or defibrillator. Disable
handset transmissions (e.g. airplane mode) or
power off handset when it is difficult to keep
distance from others for at least 15 cm such
as in a crowd.
When auto powering on function (e.g. alarm) is
set, disable the function before powering off.
87
Important Product Information
Handset, USIM Card, AC Charger
・Use handset with External Device Port Cover and Slot Cover
firmly closed to ensure water and dust resistance.
・Do not apply excessive force on handset.
- Do not sit down with handset in a back pocket.
- Do not place heavy objects in a bag with handset inside.
・Display is made of hardened glass, however, it may be
broken if it is subject to excessive force or strong impact.
If Display should be broken, stop using and do not touch
fragments.
・Use AC Charger, Micro USB Charging Adapter (sold
separately) within temperatures of 5℃ to 35℃ and
humidity 35% to 80%. Avoid extreme temperatures,
humidity.
・Use handset, USIM Card (inserted in handset) within
temperatures of 5°C to 35°C and humidity 35% to 90%.
Avoid extreme temperatures, humidity, direct sunlight
(temporary use at 36°C to 40°C).
・Do not use handset, USIM Card, or AC Charger in a dusty
place or where there is much vibration.
・Clean Charging Terminal with a dry cotton swab etc. Dust
in port may cause contact failure. Do not apply excessive
force.
・Clean handset, USIM Card, or AC Charger with a dry, soft
cloth. Using benzine, thinner, alcohol, detergent, etc. may
fade color/print.
・Handset use near TVs, speakers, etc. may cause interference.
・Handset may become warm while calling, using applications,
charging, etc., but is not a malfunction.
・Do not scratch or subject Fingerprint Sensor to strong
impact. It may cause malfunction or fault.
・Do not poke Fingerprint Sensor with sharp objects such as a
pen. It may cause malfunction.
・Do not use Fingerprint Sensor with a wet or dirty finger. It
may cause malfunction. Wipe off water or dust.
A finger wrinkled from being wet also may cause
malfunction.
・Connect AC Charger in the correct direction. Failure to do so
may cause damage or malfunction.
・A guardian should supervise use by children and insure
handset is used as instructed. Failure to do so may result in
injuries.
Safety Precautions
People with implanted pacemakers or defibrillators may be
near. Radio waves may interfere with implanted pacemakers
or defibrillators causing such devices to malfunction.
SoftBank 202F
88
Handset
・Handset is certified as conforming to technical standards
for specified wireless equipment based on the Radio Law.
To show "Technical Compliance Mark ," in Home Screen,
Settings About phone Auth .
・Mail and downloaded data (paid and free) saved on handset
cannot be transferred when handset is replaced in case of
model change or repair.
・Display is manufactured with high precision technology,
however, some pixels may appear darker/brighter.
・Do not apply strong force to Display.
・Do not press fingernails, sharp objects, or hard objects
against Keys or Display. To prevent malfunction of Display,
do not:
- Touch with gloved hand
- Operate with fingernails
- Operate with a foreign object on Display
- Attach protective sheet
- Operate wet Display
- Operate with wet fingers
- Operate under water
・Use handset without disturbing others.
・Prolonged use of Camera or other applications may make
handset warm. Do not touch warm handset for a long time.
May cause low-temperature burns.
・Handset may become warm during use or charging. Charging
may stop or Display may become dark, but is not a
malfunction. If handset is used under such conditions, alert
may appear and handset may power off.
・Do not use Camera while handset is warm. Camera may
automatically stop.
・If handset becomes extremely hot during use, stop using
immediately.
・If the same screen remains for a long while, afterimages
may remain. This is not a malfunction.
・Clean handset with a dry, soft cloth. Using alcohol, thinner,
etc. may damage it.
・Do not cover Light Sensor with your finger or a sticker.
・Do not cover Proximity Sensor with a sticker or your hair
during call. Doing so may cause misoperation or interruption
of call.
・Covering Temperature/Humidity Sensor may affect
measuring accuracy.
・Covering Antenna with your fingers or metal objects may
affect receiving sensitivity.
・External Device Port Cover and Slot Cover are designed not
to easily be removed. If they should be removed, reattach
them.
・Extreme temperature changes, cold air from air conditioning,
etc. may cause condensation. It may result in corrosion.
・Place your ear on center of Speaker for the best reception.
・Handset is designed not to easily be disassembled. Modifying
handset is prohibited by the Radio Law.
・Keep away from magnetism-generating devices such as a TV.
It may cause malfunction.
・If handset is used while charging, charging time may take
longer or charging may not be completed.
Touchscreen
・Lock screen when putting handset in a pocket or bag to
avoid erroneous operation.
・Do not touch Display with sharp objects such as ball point
pens and pencils.
・Do not attach protective sheet or sticker.
・Do not touch with fingernails.
Internal Battery
・Under extreme temperatures such as in a closed car in
summer, battery capacity lowers and battery time becomes
shorter.
・Internal Battery may bulge near the end of its lifetime
depending on usage. This is not a malfunction.
・Internal Battery is a consumable item; may need to be
replaced if operating time shortens noticeably. Internal
Battery is not user replaceable; its replacement incurs
fees and requires handset submission to a SoftBank Shop,
etc. For details, contact a SoftBank Shop or SoftBank
Customer Support, General Information. To check Battery
performance, in Home Screen, Settings About
phone Status Battery performance .
・Charge handset before use when handset is used for the
first time or when it is not used for a long time.
・If handset is not fully charged after a long time, charging
fails and Notification Lamp turns off. Remove handset from
AC Charger and charge again.
・When Battery is low, alert may appear and handset may
power off. Handset cannot activate with empty Battery
even while charging. Charge a while with power off and try
to power on.
AC Charger (FMCAB1)
・Use accessory USB Cable with AC Charger.
・Unplug AC Charger if you are not going to use it.
・Grasp USB plug to unplug it. Do not forcefully pull it out.
・Do not loop AC Charger cable around AC Charger or Desktop
Holder. It may cause electric shock, overheating, or fire.
・Do not bend blades of AC Charger plug or connector and
cable.
・If power plug of AC Charger is removed, attach it as shown
below.
・Data communication using AC Charger USB Cable is not
guaranteed.
・AC Charger is for indoor use only.
89
Camera
・Mind etiquette when using Camera.
・Do not expose Camera Lens to direct sunlight. Concentrated
sunlight through Lens may cause handset to malfunction.
・SoftBank Mobile Corp. is not liable for damages from
accidental loss/alteration/repair of handset/SD Card
information (image files, etc.).
・Test Camera before capturing/recording special moments.
・Be considerate of privacy of others when taking/recording
pictures/videos or sending images.
・Do not capture/record sold books or text prohibited from
capturing/recording.
Copyrights
・Copyrights
The rights of copyright holders to literary works, music,
still images, video, computer programs, databases, etc. are
protected by copyright laws. You may copy these materials
for private use only. Copying for purposes other than
the above (including data format conversion), modifying,
transferring copies, distributing on networks may be subject
of compensation for losses or of prosecution for "copyright
infringement" or "copyright holder rights infringement." If
copying using this product, observe copyright laws. Handset
is equipped with Cameras. Observe copyright laws when
shooting with Cameras.
・Software contained in handset is copyrighted work including
copyright holder rights and protected by copyright laws.
Do not reproduce, modify, alter, disassemble, decompile
or reverse engineer all or part of the software; do not
separate it from hardware.
・Except where exempted by copyright laws, forwarding
copyrighted images is prohibited.
・Except where exempted by copyright laws such as personal
use, using and forwarding copyrighted images without
copyright holder's authorization are prohibited. When
disclosing recorded photographs of others to general
public through Internet websites etc., take care with the
copyrights or portrait rights. Note that taking photos or
recording at demonstrations, performances or exhibitions
may be prohibited even when only for personal use.
・Portrait Rights
Portrait rights protect individuals' right to refuse to be
photographed or to refuse unauthorized publication/use
of their photographs. Portrait rights consist of the right
to privacy, which protects the interests of celebrities.
Therefore, photographing others including celebrities
and publicizing/distributing their photographs without
permission is illegal; use Camera responsibly.
Note on Applications
・Installation of various applications is possible from Google
Play™ provided by Google. SoftBank Mobile Corp. is not
liable for application content (quality, reliability, legality,
accuracy, etc.) or any problems (viruses, etc.) resulting from
installation.
・Google Accounts
Create a Google Account to use Google services. A Google
Account is required to fully use some services and
applications/functions. Do not forget your Google Account
ID and password.
Urgent News (Japanese)
・Urgent News Incoming Setting is enabled by default.
・Urgent News messages appear in Japanese.
・Upon reception, alert tone sounds even in Manner mode.
・Urgent News messages cannot be received during calls or
other transmissions, or in poor signal conditions. Message
reception is available during 4G data communication.
・Urgent News accuracy may vary with signal conditions/
handset location.
・Enabling Urgent News may reduce Continuous Standby Time.
・SoftBank Mobile Corp. is not responsible for any losses
associated with Urgent News reception, etc.
Fingerprint Authentication
・Fingerprint Sensor is used for identifying the user.
It may not function for fingerprints without strong
characteristics.
・To save a fingerprint, scan the same finger three times or
more. Always use the same finger.
・Accuracy may differ depending on various conditions. A wet,
sweaty, or dry finger may affect accuracy or ability to save
or identify a fingerprint. In such a case, washing/wiping
hands, or changing fingers may improve accuracy.
・Place your first joint on center of sensor and slide it down
until it passes through sensing area keeping it parallel to
sensor. To avoid error, put your finger in the same direction
as handset.
・Sliding too fast or too slow may prevent reading.
・Slide finger down centered on sensor.
・Error appears when fingerprint is not read correctly.
・Do not place your finger before starting saving or reading.
Remove finger when activating.
・When connecting handset to a device requiring grounding
such as a desktop PC with a USB cable, make sure it
is grounded. If not, fingerprint authentication may be
unavailable. Disconnect handset from it to authenticate.
・Fingerprint authentication technology does not guarantee
complete identity authentication or verification. SoftBank
Mobile Corp. is not responsible for any damages caused by
use of handset or its unavailability.
Safety Precautions
SoftBank 202F
90
Fingerprint Sensor
・Do not remove or poke protective film on Fingerprint
Sensor with a pointed object such as a pen. It may reduce
waterproof performance.
・Water or dirt on Fingerprint Sensor or your finger may
cause malfunction.
・Do not hit or subject to strong impact. Doing so may cause
damage or malfunction. Do not scratch or poke with pointed
item.
・Scratching with mud, or muddying surface may cause damage
or malfunction.
・Do not place sticker on surface or let surface get ink on it.
・Dust, oil, sweat, or condensation may affect accuracy. Keep
Fingerprint Sensor clean.
・If errors reoccur, clean Fingerprint Sensor.
・Use a dry, soft and static-free cloth to clean surface. Do
not use sharp-pointed items.
・Static electricity may cause malfunction. Before placing
finger on sensor, eliminate static electricity by touching a
metal object etc. Take particular care in dry seasons such as
winter.
Bluetooth® Function
・Connection with all Bluetooth® devices is not guaranteed.
・Handset complies with Bluetooth® security standards,
however, communication may be intercepted depending on
the environment/settings. Take care when using Bluetooth®.
・SoftBank Mobile Corp. is not responsible for data leaked via
Bluetooth® communication.
・Bluetooth® and Wi-Fi transmit on the same frequency
band. Using Bluetooth® devices near handset may affect
Wi-Fi transmission speed, availability and clarity. Should
interference occur, disable either Bluetooth® or Wi-Fi.
・Bluetooth® devices operate on the same frequency band
used by industrial or scientific machinery, consumer
electronics (like microwave ovens), medical equipment,
(licensed) premises radio stations used to identify mobile
units used in manufacturing lines, (unlicensed) specified low
power radios and (licensed) amateur radios.
1. Before using handset Bluetooth® functions, confirm that
premises radio stations, specified low power radios, and
amateur radios are not in use nearby.
2. If handset Bluetooth® function use interferes with
premises radio stations, immediately change frequency band,
or halt usage and take steps (set up a partition, etc.) to
prevent crosstalk.
3. If handset Bluetooth® function use interferes with
specified low power radios or amateur radios, contact
SoftBank Customer Support, General Information.
・Bluetooth® function uses frequencies in the 2.4 GHz band
ranging from 2,400 MHz to 2,483.5 MHz.
・2.4FH/XX1
Frequency Band: 2.4 GHz
Modulations: FH-SS or other modulations
Estimated Range of Radio Frequency Interference: up to 10
m
: Utilizes 2,400 MHz to 2,483.5 MHz band
without mobile device bandwidth differentiation
・When using Bluetooth® function in other countries, check
local regulations beforehand.
・For use in an airplane, contact your airline.
・Communication speed and connectable range vary by
conditions.
91
Wi-Fi (Wireless LAN)
・Connection with all Wi-Fi devices is not guaranteed.
・Handset complies with Wi-Fi security standards, however,
communication may be intercepted depending on the
environment/settings. Take care when using Wi-Fi.
・SoftBank Mobile Corp. is not responsible for data leaked via
Wi-Fi communication.
・Wi-Fi devices operate on the same frequency band used by
industrial or scientific machinery, consumer electronics
(like microwave ovens), medical equipment, (licensed)
premises radio stations used to identify mobile units used in
manufacturing lines, (unlicensed) specified low power radios
and (licensed) amateur radios.
1. Before using Wi-Fi, confirm that premises radio stations,
specified low power radios, and amateur radios are not in
use nearby.
2. If Wi-Fi use interferes with premises radio stations,
immediately change frequency band, or halt usage and take
steps (set up a partition, etc.) to prevent crosstalk.
3. If Wi-Fi use interferes with specified low power radios or
amateur radios, contact SoftBank Customer Support, General
Information.
・Wi-Fi uses frequencies in the 2.4 GHz band ranging from
2,400 MHz to 2,483.5 MHz.
Waterproofing/Dustproofing
Water and Dust Resistance
Handset complies with IPX5*1, IPX8*2 waterproof standards
and IP5X*3 dustproof standard with External Device Port
Cover and Slot Cover firmly closed.
*1 Protection against water jet (at 12.5 L/min. from every
direction from a distance of approximately 3 m for over 3
minutes through 6.3 mm nozzle)
*2 Protection against seepage when slowly submerged in still
tap water at room temperature to depth of 1.5 m for 30
minutes
*3 Protection against dust (in a device containing dust
particles with a diameter of 75 μm or less, agitated for 8
hours)
・Note: Complete protection is not guaranteed under all
conditions. Malfunctions due to improper handling by the
user are not covered by Warranty.
・2.4DS/OF4
Frequency Band: 2.4 GHz
Modulations: DS-SS, OFDM
Estimated Range of Radio Frequency Interference: up to 40
m
: Utilizes 2,400 MHz to 2,483.5 MHz band with
mobile device bandwidth differentiation
・Available channels may vary by country.
・For use in an airplane, contact your airline.
・When using Wi-Fi in other countries, check regulations
beforehand.
・Do not use Wi-Fi near magnetic devices such as electrical
appliances or AV/OA devices.
・Magnetic/radio waves may hinder or disable communication.
Avoid microwave ovens.
・Use near a TV or radio, etc. may cause interference; may
affect TV reception.
・If there are multiple Wi-Fi access points using the same
channel, search may fail.
・The three channels of W52, W53 and W56 can be used on
5 GHz frequency band. W52 and W53 are prohibited from
outdoor use under the Radio Law.
What if Handset Freezes
Safety Precautions
・If handset deactivates, freezes, or does not accept any
input, reboot handset as follows (Rebooting erases data
being edited.):
(Long Press 10 seconds or more)
When handset is powered off, (Long Press）
SoftBank 202F
92
Precautions
・Do not place handset directly on beach.
- Sand may enter Mic, Earpiece, Speaker, or Earphone Port
which may distort sound or cause overheating, malfunction.
・Make sure to securely close External Device Port Cover and
Slot Cover.
・A fine particle (a hair, grain of sand, tiny fiber, etc.)
between External Device Port Cover, Slot Cover and handset
may allow water to enter.
・Do not use handset with Earphone Port wet or sand or dust
inside.
・Do not use handset under water.
・Do not leave handset in a humid place such as a bathroom,
kitchen etc. for a long time.
・Handset complies with water resistance specifications only
for tap water at room temperature. Do not splash or soak
in:
- Water containing soap, detergent, bath salts
- Seawater
- Pool water
- Hot spring water
- Boiled water
- Chemicals
- Perspiration
・Hold handset approximately 10 cm below faucet or shower
head and wash with low-pressure tap water ((6 L/min. or
lower) at room temperature (5℃ to 35℃)).
・When washing handset, make sure to securely close External
Device Port Cover and Slot Cover. Do not use a brush or
sponge.
・Do not wash Earphone Port Area.
・Do not wash handset in a washing machine.
・To avoid seepage, do not:
- Remove rubber seals.
- Pinch rubber seals when closing External Device Port Cover
or Slot Cover.
- Open/close External Device Port Cover or Slot Cover with
gloves on.
- Leave fine particles (a hair, grain of sand, tiny fiber, etc.)
between External Device Port Cover, Slot Cover and handset.
- Insert sharp-edged objects into gaps around External
Device Port Cover or Slot Cover to remove those fine
particles.
・Replacing parts every two years regardless of handset
performance is recommended (at cost). Contact SoftBank
Shop or SoftBank Customer Support, General Information.
・Rinse seawater, detergent, sand, mud, etc. off with tap
water.
・If handset gets wet, drain water and wipe off water from
handset with a clean dry cloth.
・Do not leave handset wet.
- Doing so may cause short circuit with External Device
Port.
- Do not leave Earphone Port wet.
- In cold climates, freezing may cause malfunction.
・Water may leak into Earphone Port or Keypad. Shake handset
to flick water away and wipe off from Keypad with a clean
dry cloth.
・Wipe off water or snow with a dry clean cloth not to wet
your clothes or bag.
・Before using Earphone, make sure that Earphone Port is dry.
・Desktop Holder and AC Charger are not water and dust
resistant. Do not charge wet handset. When charging, drain
and wipe off water before inserting into Desktop Holder or
opening External Device Port Cover.
・If charging handset with External Device Port Cover opened,
make sure to firmly close External Device Port Cover
after charging. To avoid seepage, using Desktop Holder is
recommended.
・Do not charge wet handset. Doing so may cause electric
shock, fire or malfunction due to short circuit.
・Do not touch Desktop Holder or AC Charger with wet hands.
Doing so may cause electric shock.
・Keep Desktop Holder and AC Charger away from water.
Failure to do so may cause fire or electric shock.
・Do not use Desktop Holder and AC Charger in a humid place
such as a bathroom, kitchen, etc. Doing so may cause fire or
electric shock.
・Do not soak handset in hot spring water, water with soap,
detergent, bath salts, etc. Also do not leave handset under
water for a long time. Doing so may cause malfunction.
・Do not open/close External Device Port Cover, or Slot Cover
with wet hands or when handset gets wet.
・Handset is not heat resistant. Do not immerse handset in
hot water, use it in a sauna or dry it with hot air (e.g. a
dryer).
・Handset is not shock resistant. Do not drop handset or
subject it to excessive shock. Do not poke Mic, Earpiece, or
Speaker with cotton swab or sharp-edged object. May affect
waterproofing/dustproofing.
・Do not apply excessive amount of water to handset.
・Handset does not float.
・Handset is waterproof and dustproof only in the
temperatures of 5℃ to 40℃ (only temporary use is
available at 36℃ to 40℃) and humidity of 35% to 90%.
・If External Device Port or Slot Cover is damaged, replace it
with a new one. May result in electric shock or corrosion of
Battery due to seepage.
・If handset gets wet with External Device Port Cover, or
Slot Cover open, seepage may occur. In such case, power
off handset, and bring it to a SoftBank Shop or contact
SoftBank Customer Support, General Information.
・Do not leave water in Mic, Earpiece, Speaker or Earphone
Port. May cause malfunction.
・Do not leave water in Temperature/Humidity Sensor.
Temperature/humidity may not be detected correctly.
93
General Notes
General Use
・If USIM Card/handset with USIM Card installed is lost or
stolen, contact SoftBank Customer Support or Global Call
Center.
・SoftBank Mobile Corp. is not liable for damages from
accidental loss/alteration/repair of handset/SD Card
information (Contacts, image/sound files, etc.). Back up
important information.
・Handset transmissions may be disrupted inside buildings,
tunnels or underground, or when moving into/out of such
places.
・Use handset without disturbing others.
・Handsets are radios as stipulated by the Radio Law. Under
the Radio Law, handsets must be submitted for inspection
upon request.
・Handset use near landlines, TVs or radios may cause
interference.
・Read SD Card manual beforehand for proper use.
・Beware of eavesdropping.
Digital signals reduce interception, however transmissions
may be overheard. Deliberate/accidental interception of
communications constitutes eavesdropping.
"Eavesdropping" means radio communication is received by
another receiver deliberately or accidentally.
Electromagnetic Safety
For body-worn operation, this phone has been tested and
meets RF exposure guidelines when used with accessories
containing no metal, that position handset a minimum of 15
mm from the body. Use of other accessories may not ensure
compliance with RF exposure guidelines.
FCC Notice
・This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
・Changes or modifications not expressly approved by the
manufacturer responsible for compliance could void the
user's authority to operate the equipment.
・The device complies with 15.205 of the FCC Rules.
Note:
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference
by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and
receiver.
- Connect the equipment into an outlet on circuit different
from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician
for help and for additional suggestions.
Safety Precautions
SoftBank 202F
94
FCC RF Exposure Information
Your handset is a radio transmitter and receiver. It is
designed and manufactured not to exceed the emission limits
for exposure to radio frequency (RF) energy set by the Federal
Communications Commission of the U.S. Government.
The guidelines are based on standards that were developed
by independent scientific organization through periodic and
thorough evaluation of scientific studies. The standards
include a substantial safety margin designed to assure the
safety of all persons, regardless of age and health.
The exposure standard for wireless handsets employs a unit of
measurement known as the Specific Absorption Rate, or SAR.
The SAR limit set by the FCC is 1.6 W/kg. The tests are
performed in positions and locations (e.g. at the ear and worn
on the body) as required by the FCC for each model.
The highest SAR value for this model handset as reported to
the FCC when tested for use at the ear is 0.57 W/kg, and
when worn on the body in a holder or carry case, is 0.57 W/kg.
Body-worn Operation; This device was tested for typical
body-worn operations with the back of the handset kept
1.0 cm from the body. To maintain compliance with FCC RF
exposure requirements, use accessories that maintain a 1.0
cm separation distance between the user's body and the back
of the handset. The use of beltclips, holsters and similar
accessories should not contain metallic components in its
assembly.
The use of accessories that do not satisfy these requirements
may not comply with FCC RF exposure requirements, and
should be avoided. The FCC has granted an Equipment
Authorization for this model handset with all reported SAR
levels evaluated as in compliance with the FCC RF emission
guidelines. SAR information on this model handset is on
file with the FCC and can be found under the Display Grant
section of http://www.fcc.gov/oet/ea/ after searching on FCC
ID YUW-202F.
Additional information on Specific Absorption Rates (SAR) can
be found on FCC Radio Frequency Safety website at http://
transition.fcc.gov/oet/rfsafety/.
European RF Exposure Information
Your mobile device is a radio transmitter and receiver. It is
designed not to exceed the limits for exposure to radio waves
recommended by international guidelines. These guidelines
were developed by the independent scientific organization
ICNIRP and include safety margins designed to assure the
protection of all persons, regardless of age and health.
The guidelines use a unit of measurement known as the
Specific Absorption Rate, or SAR. The SAR limit for mobile
devices is 2.0W/kg and the highest SAR value for this
device when tested at the ear was 0.71 W/kg*. As mobile
devices offer a range of functions, they can be used in
other positions, such as on the body as described in this
User Guide**. In this case, the highest tested SAR value is
0.546 W/kg***. As SAR is measured utilizing the devices
highest transmitting power the actual SAR of this device
while operating is typically below that indicated above. This
is due to automatic changes to the power level of the device
to ensure it only uses the minimum level required to reach the
network.
The World Health Organization has stated that present
scientific information does not indicate the need for any
special precautions for the use of mobile devices. They note
that if you want to reduce your exposure then you can do so
by limiting the length of calls or using a hands-free device to
keep the mobile phone away from the head and body.
*The tests are carried out in accordance with international
guidelines for testing.
** Please see Electromagnetic Safety for important notes
regarding body worn operation.
*** A method of measuring SAR when a mobile phone is used
at positions other than at the ear was established in March
2010 through an international standard (IEC62209-2). MIC
technical regulation was reported in October 2011 by the
Information and Communications Council.
World Health Organization
http://www.who.int/emf
List of Specific Absorption Rates (SAR) for radio waves by
smartphone model
http://mb.softbank.jp/mb/support/sar/ (Japanese)
Warning
This device have been tested to comply with the Sound
Pressure Level requirement laid down in the applicable EN
50332-1 and/or EN 50332-2 standards. Permanent hearing
loss may occur if earphones or headphones are used at high
volume for prolonged periods of time.
Prevention of Hearing Loss
Warning statement requirement under EN 60950-1:A12.
Warning: To prevent possible hearing damage, do not listen to
high volume levels for long periods.
95
RF Exposure Information/Specific
Absorption Rate (SAR) Information
RF Exposure Information/Specific
Absorption Rate* (SAR) Information
This mobile phone 202F meets the MIC's**** technical
regulation for exposure to radio waves.
The technical regulation* established permitted levels of
radio frequency energy, based on standards developed by
independent scientific organizations through periodic and
thorough evaluation of scientific studies.
The regulation employs a unit of measurement known as the
Specific Absorption Rate, or SAR.
The SAR limit is 2 watts/kilogram (W/kg)** averaged over ten
grams of tissue.
The limit includes a substantial safety margin designed to
assure the safety of all persons, regardless of age and health.
The value of the limit is equal to the international guidelines
recommended by ICNIRP*****.
The highest SAR value for this mobile phone is 0.690 W/kg
when tested for use at the ear.
While there may be differences between the SAR levels of
various phones and at various positions, all phones meet MIC's
technical regulation.
Although the SAR is determined at the highest certified power
level, the actual SAR of the phone during operation can be
well below the maximum value.
Use at positions other than at the ear
This mobile phone may be used at positions other than at the
ear. By using an accessory such as a belt clip holster that
maintains a 1.0 cm separation with no metal (parts) between
the body and the mobile phone, this mobile phone will comply
with international guidelines for radio wave protection (***).
The World Health Organization has announced that "A large
number of studies have been performed over the last two
decades to assess whether mobile phones pose a potential
health risk. To date, no adverse health effects have been
established as being caused by mobile phone use."
For more information about SAR, see the following websites:
・ Ministry of Internal Affairs and Communications (MIC)
http://www.tele.soumu.go.jp/e/sys/ele/body/index.htm
・ Association of Radio Industries and Businesses (ARIB)
http://www.arib-emf.org/index02.html (Japanese)
* The technical regulation is provided in Article 14-2 of the
Ministry Ordinance Regulating Radio Equipment.
** Provided for in "Radio-radiation protection guidelines,"
reported in 1997 by the Telecommunications Technology
Council, Ministry of Posts and Telecommunications.
*** A method of measuring SAR when a mobile phone is used
at positions other than at the ear was established in March
2010 through an international standard (IEC62209-2). MIC
technical regulation was reported in October 2011 by the
Information and Communications Council.
**** Ministry of Internal Affairs and Communications
***** International Commission on Non-Ionizing Radiation
Protection
Standards of the Federal Communications Commission (FCC)
of the U.S. Government and information from the E.U. are
given as information relating to RF exposure. For details, see
"FCC RF Exposure Information" and "European RF Exposure
Information."
Safety Precautions
SoftBank 202F
96
97
Ａ
About Settings..................................................................74
Accounts & Sync Settings............................................... 78
Address Book.....................................................................43
Applications Settings....................................................... 78
Ｂ
202F User Guide Index
Basic Operations...............................................................18
Bluetooth®........................................................................ 70
Ｃ
Calling................................................................................ 36
Calling Outside Japan...................................................... 72
Charging Battery.............................................................. 12
Creating/Sending Gmail....................................................50
Creating/Sending Mail/SMS..............................................48
Customer Service.............................................................. 80
Ｆ
Full Seg and One Seg....................................................... 64
Ｇ
General Notes................................................................... 93
Google Account................................................................. 23
Google Play™.................................................................... 25
Ｈ
Handset Phone Number.................................................... 19
Home Screen Basics..........................................................32
Ｉ
Image Files........................................................................ 60
Imaging...............................................................................56
Important Product Information.......................................87
Internet Mail Settings..................................................... 51
Introduction.........................................................................3
Ｍ
Messaging.......................................................................... 46
Mobile Manners................................................................. 20
Music Files.........................................................................60
Ｎ
Notifications Window.......................................................34
SoftBank 202F
98
Ｏ
Optional Services..............................................................38
Ｐ
Package Contents............................................................... 6
Parts & Functions...............................................................6
Power On/Off................................................................... 14
Ｒ
RF Exposure Information/Specific Absorption Rate (SAR)
Information........................................................................95
Ｓ
Safety Precautions........................................................... 82
Screen Lock....................................................................... 29
Security Codes.................................................................. 27
Software Updates.............................................................30
Sound and Vibration Settings......................................... 77
Specifications....................................................................80
Status Bar......................................................................... 32
Ｔ
Text Entry.........................................................................21
Touchscreen Operations...................................................15
Ｕ
USIM Card Installation....................................................... 8
USIM PIN............................................................................28
Using Handset Memory & SD Card.................................... 9
Using NX! Mail.................................................................. 46
Using Tethering Option....................................................69
Ｗ
Waterproofing/Dustproofing........................................... 91
Web Browsing....................................................................51
Wi-Fi...................................................................................68
Wi-Fi Settings...................................................................75
Loading...
