INSTALLATION AND OPERATING MANUAL
ASYS
16 A Transfer System
IOMASY160810-GB_00
ASYS
16 A Transfer System
ENGLISH
IOMASY160810-GB_00
INTENDED USE
The ASYS TRANSFER SWITCH device is used as a power source selector providing a
redundant power supply to the load.
It runs on a single phase network. The device is compliant with all relevant safety
regulations concerning information technology equipment, including electronic
equipment for use in an oce environment.
WARNING
This document provides important instructions for a safe installation, operation and
use of the ASYS.
It is advised that this User Manual be consulted before installation of the equipment,
which operation should only be performed by skilled personnel.
DEVICE OVERVIEW
The ASYS is available in two voltage levels, 120 Vac and 220/230/240 Vac.
The nominal current 16A is available for both voltage levels.
Please strictly follow the procedures when switching the ASYS ON
or OFF. In all circumstances all repairs must only be executed by authorized and skilled personnel.
This equipment complies with the European Community directives for professional
equipment. Hence it is labelled as follows: .
ASYS
16 A Transfer System
ENGLISH
IOMASY160810-GB_00
1
TA b l E O f C O N T E N T S
1. CE R T I f I C A T E A N D C O N D I T I O N S O f W A R R A N T y 2
2. SA f E T y 3
2. 1. Im p O R T A N T 3
2. 2. Em E R G E N C y 3
2. 3. pA C k A G I N G 4
2. 4. WA R N I N G 4
3. OV E R V I E W 5
3. 1. pU R p O S E O f ASyS TRANSfER SWITCH 5
4. UN p A C k I N G A N D I N S T A l l A T I O N 5
4. 1. DE l I V E R y A N D ST O R A G E 5
4. 2. IN V E N T O R y lI S T 5
4. 3. ST O R A G E 6
4. 4. HA N D l I N G 6
4. 5. EN V I R O N m E N T A l CO N D I T I O N S 6
4. 6. RA C k mO U N T I N G 6
4. 7. EN V I R O N m E N T A l R E q U I S I T E S 7
5. pR E S E N T A T I O N 7
5. 1. fR O N T pA N E l 7
5. 2. RE A R pA N E l 7
5. 3. Op E R A T I N G pA N E l 8
5. 4. fE A T U R E S 8
6. Op E R A T I N G p R O C E D U R E S 9
6. 1. mA N U A l SW I T C H ON pR O C E D U R E S 10
7. TE C H N I C A l DA T A 11
7. 1. IN p U T / OU T p U T f E A T U R E S 11
7. 2. CO N N E C T I O N 11
7. 3. CO m m U N I C A T I O N S 12
7. 4. mE C H A N I C A l fE A T U R E S 12
7. 5. EN V I R O N m E N T 12
7. 6. SA f E T y ST A N D A R D S 13
7. 7. EmC ST A N D A R D 13
7. 8. OV E R C U R R E N T 13
7. 9. Ex T E R N A l pR O T E C T I O N A N D IS O l A T I O N DE V I C E S 14
8. TR O U b l E S H O O T I N G 15
ASYS
16 A Transfer System
ITALIANOENGLISH
2
IOMASY160810-GB_00
CE R T I f I C A T E A N D C O N D I T I O N S O f W A R R A N T y1.
The warranty conditions are stipulated in the sales contract. If not the following
points shall apply:
SOCOMEC’s guarantee is strictly limited to the product(s) and does apply neither to
the equipment in which they could be integrated nor to the performance of such
equipment.
The manufacturer, at his discretion, is entitled to adapt his product in order to comply with the warranty or replace the faulty parts. The manufacturer’s warranty does
not apply in the following cases:
- Defects arising either from designs or parts imposed or supplied by the Purchaser,
- Failure due to fortuitous circumstances or force majeure,
- Replacements or repairs resulting from normal wear of units and machinery,
- Repair, modication, regulation or replacement of parts made by a third party or
personnel not qualied without SOCOMEC’s written consent.
The period of validity of the warranty may never exceed 12 months after delivery.
Replacements, repairs or modications of parts during the warranty period cannot
extend the duration of the warranty.
For these stipulations to be valid, the Purchaser must, within a maximum of 8 days
after the warranty lapses, expressly inform the Manufacturer of the faulty design,
or the material or manufacturing defect, stating in detail the grounds for his complaint.
Defective parts replaced free of charge by the Manufacturer are to be put at his disposal, so that he may become the sole owner.
The warranty legally ceases if the Purchaser has, of his own initiative, undertaken
modications or repairs on the Manufacturer’s products without the written consent
of the latter.
The Manufacturer’s liability is limited to the obligations as dened herein (repair or
replacement), all other items of damage being formally excluded.
The Purchaser is liable for taxes or duties of any kind in compliance with either the
European regulations, or those of the country of import or transit.
ASYS
16 A Transfer System
ENGLISH
IOMASY160810-GB_00
3
SA f E T y2.
Im p O R T A N T2. 1.
Read the following safety notices carefully! Failure to observe the instructions may endanger your life, your health, the reliability of your device or the security of your data.
Transport the unit only in its original packaging. –
If the equipment is stored in a cold environment prior to installation, condensa- –
tion may occur. Before you switch on the equipment it must be absolutely dry.
The equipment must be installed in accordance with the environment conditions –
specied as follows: Operating temperature: 0 to 40°C, Operation humidity: 20%
to 85% (no condensing).
Lay all cables so that nobody can stand on them or trip over them. –
For pluggable equipment, the socket-outlet shall be installed near the equipment –
and shall be easily accessible. The plug on the power supply cord is intended to
serve as the disconnecting device.
Make sure that no objects get inside the device. –
The sum of the ASYS leakage currents does not exceed 3.5mA. –
Earth connection must be done prior to any connection to the power supply. –
Data transmission lines should NOT be connected or disconnected during a thun- –
derstorm.
Do NOT connect equipment that will overload the ASYS.
Em E R G E N C y2. 2.
The supply to the load may be interrupted by opening both input power supply.
DO NOT use WATER to extinguish any re that may occur in the area in which the
ASYS is installed.
ASYS
16 A Transfer System
ITALIANOENGLISH
4
IOMASY160810-GB_00
pA C k A G I N G2. 3.
All packaging material must be recycled in compliance with the laws in force
in the country where the system is installed.
WA R N I N G2. 4.
It is absolutely necessary to earth the ASYS before connecting any upstream and –
downstream supplies.
The Installation of the ASYS may only be carried out by qualied technical person- –
nel.
Even if the ASYS output has been switched o, hazardous voltages are present –
within the ASYS; any operation that requires the unit to be opened and/or removed may be carried out by authorized technical personnel only.
Do not remove the cover without completely disconnecting the ASYS from the –
input supplies 1 and 2.
User or Operator can intervene in ASYS on condition that the instructions of con- –
nection presented below are respected.
Mains 1
Mains 2
Load
ASYS 16A
UPS 2
UPS 1
S 1
S 2
ASYS Transfer System fed by two independent UPS
ASYS
16 A Transfer System
ENGLISH
IOMASY160810-GB_00
5
OV E R V I E W3.
pU R p O S E O f ASyS TRANSfER SWITCH3. 1.
The 2-pole ASYS is a two-way, single phase automatic switch powered by two independent synchronous or asynchronous AC power supply sources.
ASYS provides redundant power, it makes a rapid switch from one source to the other in the event of a fault to the power supply used to power the load.
One of the two sources can be designated as the preferred power supply, to which
the ASYS will supply the load. It remains there until dierent designations or faults
require it to be switched to the alternate source.
The ASYS is tted with a block diagram with LED indicators, capable of providing all
information concerning equipment operation status, together with the power source
priority selection which enables trained operators to make full use of the apparatus.
UN p A C k I N G A N D I N S T A l l A T I O N4.
DE l I V E R y A N D ST O R A G E4. 1.
The goods have been checked thoroughly before dispatch. On receipt, check the
packaging and ensure that the contents are undamaged. Any damage or missing
parts must be reported to the supplier as soon as possible.
ASYS is available in 2 models (see chapter 7 for characteristics): ASYS16 -120
ASYS16 - 230
IN V E N T O R y lI S T4. 2.
ASYS module –
2 pluggable input power cable (for ASYS16 - 230 model only) –
Screw sets (4 screw and 4 cage nuts) –
2 bracket kits for rack mounting –
2 bracket kits for vertical mounting –
User Manual –
NOTE: An approved power cable greater or equal to H05VV-F, 3G, 0.7mm² must be
used.
ASYS
16 A Transfer System
ITALIANOENGLISH
6
IOMASY160810-GB_00
ST O R A G E4. 3.
Storage temperature: -25 to 70°C,
Storage humidity: from 10% to 90%.
HA N D l I N G4. 4.
The equipment must be handled with care. Damage may be caused if dropped or
subjected to severe impacts.
EN V I R O N m E N T A l CO N D I T I O N S4. 5.
The ASYS TRANSFER SWITCH must be installed as rack mount or on a at horizontal
surface and in an area protected from temperature extremes, water and humidity
and the presence of conductive powder or dust.
DO NOT stack units and do not place any objects on top of a unit.
RA C k mO U N T I N G4. 6.
Taking into consideration that the ASYS is mounted into a cabinet, it is necessary that
the cabinet to be capable of supporting the unit with corresponding rails or angles.
ASYS scope of supply contains two angles for xing the ASYS into a 19 inch rack or
into a cabinet with 19 inch inner design.
Option: Also ASYS vertical mounting is possible.
Rack Mounting
Vertical Mounting
ASYS
16 A Transfer System
ENGLISH
IOMASY160810-GB_00
7
EN V I R O N m E N T A l R E q U I S I T E S4. 7.
It is necessary to leave a minimum space of a few centimetres around right side, left
side and rear side to allow a ow of air and to provide access to the interface.
pR E S E N T A T I O N5.
fR O N T pA N E l5. 1.
The front of the ASYS TRANSFER SWITCH with its LED display and interfaces:
RE A R pA N E l5. 2.
The back of the ASYS with its connectors, terminals and interfaces:
1 Output IEC320-C19
2 x 10A thermal protection
2 Input IEC 320 C20
2 x 3 Output IEC320-C132 Input Fuse
2 Input Fuse
2 Input Power cord AWG 12x3C / 20A
4 Output NEMA 5-20R
Op e r a t i n g p a n e l Se r v i c i n g a c c e S S
Dr y c O n t a c t (c O m m u n i c a t i O n a c c e S S )
ASyS 16A-230:
ASyS 16A-120:
ASYS
16 A Transfer System
ITALIANOENGLISH
8
IOMASY160810-GB_00
Op E R A T I N G pA N E l5. 3.
On the following scheme you can see the front panel of the ASYS.
Most functions of the ASYS are driven by an internal control device.
A priority setting can be made from the operating panel to prefer a mains source.
LEDs display the state of the relay group.
fE A T U R E S5. 4.
The ASYS provides redundant power supply to your load by switching it from preferred source to auxiliary source.
ASYS is compatible with UPS providing sinusoidal output (as well as direct main, generating set and all sinusoidal source)
Break Before Make (open transition) transfer mode –
Back feed protection (according EN62310-1). –
Complete protection for overload and short-circuit. (with accessible FUSE Hold- –
er).
Redundant power supply. (From input Source 1 and Source 2). –
AC source detection (voltage and current detection). –
Output detection (current detection). –
LED display. –
Dierent setting to adjust the voltage failure sensing level (+/- 12% ~ +/- 20%). see –
input/output table page 13
Protection: IP30. –
Buzzer inhibition –
Automatic rated frequency sensing –
ASYS
16 A Transfer System
ENGLISH
IOMASY160810-GB_00
9
Op E R A T I N G p R O C E D U R E S6.
ASYS TRANSFER SWITCH panel display
LED 1 and LED 2 = Preferred Source indication:
Green LEDs indicate witch Input Source is selected as the preferred
LEFT BUTTON = change the Preferred Source:
source 1 is the preferred source on the factory setting,
the modication of the preferred source is done by pressing for 3 seconds
on this button
LED input line = status of the input source
Green LEDs indicate a correct source is present
LED ashing indicates an incorrect input, voltage or frequency is out of
range
LED o indicate the source is not present on the input
LED output power = input source feed to the load
Green LEDs on the line 1, the load is powered by input 1
Green LEDs on the line 2, the load is powered by input 2
FAULT LED = general alarm
Red LED indicates: Overload, Output short circuit; or Input Source Relay
fault
RIGHT BUTTON = buzzer acknowledge
push the button for 1 second to stop the buzzer
To cancel alarm, push simultaneously, the left and right buttons for
3 seconds
1. In normal operation, output power is always supplied from the selected preferred
source.
2. If the preferred source is out of range, ASYS will automatic transfer to the other
source until the preferred source is recovered within preset tolerance.
3. If both sources are out of range, the ASYS output will be stopped. (Load is not
powered under this condition)
ASYS
16 A Transfer System
ITALIANOENGLISH
10
IOMASY160810-GB_00
mA N U A l SW I T C H ON pR O C E D U R E S6. 1.
First Switch on from Source 1
Check that all switches are OFF – .
Input the mains for source 1. –
Wait a few seconds until the logic is enabled and the LEDs on the display are –
switched ON.
Priority LED PS1 or PS2 depending on the default setting. •
LED S1 •
LED SW1 •
Input the mains for source 2. –
The following LEDs are illuminated: –
Priority LED PS1 or PS2 depending on the default setting. •
LED S1 •
LED S2 •
LED SW1 or SW2 according to the primary source •
First Switch on from Source 2
Check that all switches are OFF. –
Input the mains for source 2. –
Wait a few seconds until the logic is enabled and the LEDs on the display are –
switched ON.
Priority LED PS1 or PS2 depending on the default setting. •
LED S2 •
LED SW2 •
Input the mains for source 1. –
The following LEDs are illuminated: –
Priority LED PS1 or PS2 depending on the default setting. •
LED S1 •
LED S2 •
LED SW1 or SW2 according to the primary source •
ASYS
16 A Transfer System
ENGLISH
IOMASY160810-GB_00
11
TE C H N I C A l DA T A7.
IN p U T / OU T p U T f E A T U R E S7. 1.
ASYS 16A-120 ASYS 16A-230
INPUT
Nominal voltages 120V 220/230/240V selectable
Voltage acceptance window
Nominal +/- 12%* to +/- 20% adjustable**
Working range voltage 80 ~ 145Vac 160 ~ 290Vac
Nominal frequency
50/60 Hz auto sensing
acceptance +/- 15%
Current 16 Amps
OUTPUT
Voltage range same as input
Nominal frequency same as input
Current 16 Amps
Typical Transfer time 6ms
Maximum Transfer time <= 15ms
* = default
** = on demand
CO N N E C T I O N7. 2.
ASYS 16A-120 ASYS 16A-230
INLET
Power cord
AWG12X3C/20A
2 x IEC 320-C20
OUTLET
4 x NEMA 5-20R
1 x IEC 320-C19
2 x 3 x IEC 320-C13
ASYS
16 A Transfer System
ITALIANOENGLISH
12
IOMASY160810-GB_00
CO m m U N I C A T I O N S7. 3.
Dry Contact (DB-9, pin type)
PIN N°. Denition
PIN 4 Input Mains 1 (OK / NG)
PIN 8 Input Mains 2 (OK / NG)
PIN 1 Over Temperature
PIN 7 Overload
PIN 9 SUM Alarm
PIN 5 Common
mE C H A N I C A l fE A T U R E S7. 4.
Items Specication
Dimension W = 430mm D = 315mm H = 44mm (1U)
Weight 5kg
Packaging sizes W = 585mm D = 425mm H = 184mm
Structure Rack Mount Unit (1U)
Material Metallic Case
Colour Pantone 432C
EN V I R O N m E N T7. 5.
Items Specications
Operating temperature 0 to 40 °C
Storage temperature -25 °C to 70 °C Continuous
Storage humidity 10% to 90%
Operation humidity 20%to 85% No condensing
Operation Altitude ≤ 1000m (without downgrading)
Audible noise < 25dBA
Cooling Natural Cooling
IP Protection IP 30
ASYS
16 A Transfer System
ENGLISH
IOMASY160810-GB_00
13
SA f E T y ST A N D A R D S7. 6.
EN62310-1. (With CE Mark)
EmC ST A N D A R D7. 7.
EMI IEC62310-2, C1
EMS
IEC61000-4-2 level 3
IEC61000-4-3 level 2 (Lab.)
IEC61000-4-4 level 2
IEC61000-4-5 level 3
IEC 61000-2-2 LF Immunity
IEC61000-4-6 level 2 (Lab.)
IEC61000-3-2 Harmonic (Lab.)
IEC61000-3-3 Flicks *
* For ASYS 16A-230 only.
OV E R C U R R E N T7. 8.
Overload: –
105 to 125% (20A) = 45 sec: transfer is possible
126 to 150% (24A) = 27 sec: transfer is possible
151 to 210% (33.6A)= 5 sec: transfer is possible
211 to 300% (48A) = 2 sec: transfer is not possible
Output short-circuit : –
Complete protection is provided by the input FUSE subject to its operating characteristics.
ASYS
16 A Transfer System
ITALIANOENGLISH
14
IOMASY160810-GB_00
Ex T E R N A l pR O T E C T I O N A N D IS O l A T I O N DE V I C E S7. 9.
External protection devices need to be installed upstream and downstream of the
equipment to protect the cables and the unit. Upstream these devices need to be
selected and congured with the size of the unit in mind.
Disconnection devices must always be provided
All protection devices (circuit breakers and fuses) installed upstream of the unit need
to be co-ordinated for discrimination with the ASYS input protection (fuses) and the
ASYS overload capability.
If ASYS overload capacities are exceeded, the unit will switch o the
output.
Depending on overload characteristic the ASYS either will trip the
input fuses or drive only internal power relays to the open position.
ASYS
16 A Transfer System
ENGLISH
IOMASY160810-GB_00
15
TR O U b l E S H O O T I N G8.
If problems should occur, please check the following points before contacting the
customer service department:
Is the mains voltage present at the ASYS TRANSFER SWITCH input? –
Has one of the two input fuses tripped or open? –
If you contact the customer service department, please have the following information ready:
Device information (model name and serial number) –
An exact description of the problem (what load is being supplied, does the prob- –
lem occur regularly or sporadically, ...)
Rectication of errors
Problem Possible Cause Solution
No display, no alarm. Mains or feeding UPS
units switched o.
Switch on the mains or feeding
UPS units.
No mains voltage
present.
Have mains inspected by qualied
electrician.
Input fuses tripped. Check and make sure the load ca-
pacity is within the specication,
then replace a good fuse. If the
problem persists, contact the customer service department.
Both mains indicator
S1 and S2 do not illuminate, when mains
voltage present.
Both input fuses
tripped.
Check and make sure the load capacity is within the specication,
then replace a good fuse. If the
problem persists, contact the customer service department.
Alarm indicator F1 illuminates, acoustic
alarm active with 0.5
second sequence.
ASYS Fault. Contact the customer service de-
partment.
Multiples consecutive
transfers detection
Check the quality of the preferred
source
Overheating Check and make sure the load ca-
pacity is within the specication,
or decrease ambient temperature
(less than 40°C).
Loading...
