Socket S700, S730, S740, S760 User Manual

SocketScan® 700 Series User Guide

socketmobile.com

700, 730, 740, nd 760

Bluetooth® wireless technology

Barcode Scanner

www.socketmobile.com

Package Contents 4

Table of Contents

Optional Charging Accessories 5

Product Information 6

Attach Wrist Strap 7

Charge the Battery 8

Powering On/Off 9

Scanning Barcodes 10

Bluetooth Connection Modes 11-12

Bluetooth Connection Roles/Reconnection 13-15

Setup using Application Mode

• Apple® 16-17

• Android 18-19

• Windows PC 20

Setup without software application (Basic Mode):

• Apple® 21

• Android 22

• Windows PC 23

Pairing Reset (Bluetooth connection) 24

Table of Contents

Factory Reset 25

Restore Method 26

Battery Replacement 27

Quick Programming 28-33

Status Indicators 34-37

Product Specifications 38-39

Supported Symbologies 40-42

Safety, Bluetooth, Compliance & Warranty 43-49, 52-55

Battery Warning Statements 50-51

Package Contents

YOUR BARCODE SCANNER

Set up your scanner with
Socket Mobile Companion App

More at: socketmobile.com/companion

GET STARTED WITH

Download for Free!

SocketScan

Wrist Strap Charging Connector

Insert Card

700 Series

Thank you for choosing Socket Mobile!

Let’s get started!

© 2021 Socket Mobile, Inc. All rights reserved. Socket®, the Socket Mobile logo, SocketScan®, DuraScan®, Battery
Friendly® are registered trademarks or trademarks of Socket Mobile, Inc. Microsoft® is a registered trademark of
Microsoft Corporation in the United States and other countries. Apple®, iPad®, iPad Mini®, iPhone®, iPod Touch®,
and Mac iOS® are registered trademarks of Apple, Inc., registered in the U.S. and other countries. The Bluetooth®
Technology word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such
marks by Socket Mobile, Inc. is under license. Other trademarks and trade names are those of their respective
owners.

Available separately

Optional Charging Accessories

Chrn Doc

For all optional accessories visit our Socket Store.

Chrn Stnd AC Power Suppl

International Adapters

available

5

Product Information

Scan Indicator Light

Bluetooth Light (Blue)

Battery Light
(Green/Yellow/Red)

Scan button

Power button*

Scanner head

Product label

Power Connector

Battery Door

Stand Attachment

Lanyard Eyelet

Charging pins

Socket Mobile’s barcodes scanners can be wiped clean with a cloth dampened with
isopropyl alcohol or water. Or, the barcode scanners can be wiped clean with a Sani­Cloth.

Warning: DO NOT IMMERSE IN WATER (scanner’s mechanics could be damaged)

DO NOT USE BLEACH FOR CLEANING (scanner’s material property may be affected)

*Also used to display the on-screen keyboard in Basic Mode (iOS only).

6

Attch the Wrst Strp (optional)

Attach Wrist Strap

1. Detach the string loop of the tether from the wrist strap.

2. Feed the string loop through the eyelet.

3. Pull the tether through the string loop.

4. Pull tight so the string loop is secure.

5. Reattach the string loop’s tether to the wrist strap.

7

Charge the Battery

Power Adapter

Plug in the power adapter and the scanner will beep twice.

The scanner must be fully charged before first use. Please allow 8
hours uninterrupted charging for the initial battery charge.

The scanner will stop charging once the battery is full (No
overcharging occurs)

• Yellow Light = Charging

• Green Light = Fully charged

Importnt: Charging from a computer USB port is not reliable
and not recommended.

8

Powering on/off

Power button

Powern On

Press and hold down the small
power button until the Battery
light turns on and the scanner
beeps twice (low-high).

Powern Off/ Dsconnectn

Press and hold down the small
power button until the scanner
beeps twice (high-low) and all
lights turn off.

The scanner will power off
automatically if device is not
connected within 5 minutes.
Scanner connected to a device
will power off within 2 hours if
idle/inactive.

9

1D/2D Brcode nd OCR

Scanning Barcodes

Aim the scan beam straight

across the entire barcode

Trigger button

Scnnn Brcodes

1. Hold the scanner a few inches from the barcode.

2. Aim, press and hold the trigger button.

By default, the scanner will beep, vibrate, and the scan indicator will
flash green to confirm a successful scan.

Cuton: Do not stare directly into the scanner’s light beam.

10

Opertn Sstem Connecton Optons

Bluetooth Connection Modes

Operating

Systems

(OS)

Android

Devices

Android 4.0.3 &

later

Bluetooth

HID

Support

Yes Yes N/A

Bluetooth

SPP

Support

Bluetooth

Apple
Serial

Specific

(MFi

Mode)

Apple iOS

Windows

PC

Mac OS

Note: To switch from one mode to the other you must remove the
pairing information from both devices - host device and the scanner.
(see pairing reset procedure on page 24)

iPod, iPhone, &

iPad

Windows 7, 8, 10 Yes Yes N/A

Mac OS X 10.4 to

10.X

Mac Books, Mac

Mini, & iMac

Yes N/A Yes

Yes No N/A

11

Connect your scanner using one of the following Bluetooth

Bluetooth Connection Modes

connection modes:

Bluetooth Connecton Profles

Bluetooth Mode Description

Bsc Mode
(HID) *Defult

Human Interface
Device Profile

App Mode
(SPP)

Serial Port
Profile

App Mode
(MF-SPP)

Apple Specific
Serial Profile

• NO software installation needed

• Connects to most devices

• Good for barcodes containing small amounts
of data

• Scanner interacts with host device like a
keyboard

For Android or Windows

1. Software installation is required

2. More efficient and reliable data
communications for barcodes containing lots
of data

3. If you have an application that supports
Socket Mobile Scanners this is the mode
recommended

For iOS Devices

1. Must use with an App developed to work with
iOS devices

2. Software installation is required

3. If you have an iOS application that supports
Socket Mobile Scanners this is the mode to
use

*B defult, the scnner s set to Bsc Mode (HID)

12

Advanced users only.

Bluetooth connection roles

Note: For the S730 laser barcode scanner print the barcode to scan.

Basic Mode (HID) Keyboard

Changes a scanner in HID-Peripheral mode to HID-Keyboard mode.

For Mac OS, Apple iOS, and other smart devices.

Basic Mode (HID) Peripheral

Changes a scanner in HID-Keyboard mode to HID-Peripheral mode.

For some MS Windows or Android mobile devices.

Scan only with scanner in Application Mode (SPP)
*For Windows PC only.

Acceptor (default)

Configures the scanner to accept a Bluetooth connection puts the
scanner in discoverable mode.

Initiator

Configures the scanner to initiate a connection to a computer/device
with the Bluetooth Device Address specified in the barcode.

The barcode must be formatted in Code 128 and contain the data
#FNIaabbccddeeff# such that aabbccddeeff is the Bluetooth device
address of the computer/device you want to connect to the scanner.

You must create a custom barcode for each computer/device that
you want to connect to the scanner.

You can use barcode generating software or website
(e.g., http://barcode.tec-it.com).

13

Data Mode-For SPP Mode Only

Advanced users only.

Note: For the S730 laser barcode scanner print the barcode to scan.

Packet Mode (default)

Configures the scanner to transmit decoded data in packet format.

Raw Mode - Android and Windows only

Configures the scanner to transmit decoded data in raw (unpacketed)
format.

14

Bluetooth ReConnection

All Bluetooth Connection Modes are OK.

Note: For the S730 laser barcode scanner print the barcode to scan.

Important! After scanning this command barcode, power off and
power on the scanner to make sure it is configured properly.

Enable Automatic Reconnection from scanner (default)

Configure the scanner to automatically initiate a connection to the
last paired computer/device after the scanner is powered on.

Disable Automatic Reconnection from scanner

Configure the scanner to wait for a computer/device to initiate a
Bluetooth connection after the scanner is powered on.

15

Setup-Apple iOS App Mode

To ssst n scnner setup nd confurton,
downlod our new Compnon App for free

Socket Mobile Companion App will help you
configure and check the status of your
Socket Mobile Barcode scanners.

• Easy to follow instructions for pairing scanners in Application Mode

• Verify scanner status

• Check warranty and register scanners

Learn more about Application Mode.

Scan this QR code with your

mobile device to download our

new app!

Scan this QR code with your

mobile device to download our

new app!

16

Setup-Apple iOS App Mode

Scan QR Code using your host device to download Socket Mobile
Companion app to pair your scanner.

For quc set up

Note: For the S730 laser barcode scanner print the barcode to scan.

1. Power on the scanner. Make sure the scanner is discoverable
(unpaired). The Blue light should be blinking fast.

2. Scan barcode. The scanner will beep 3 times.

App Mode (MFi-SPP)

3. Turn on Bluetooth on the Apple device. Go to Settings >

Bluetooth. A Bluetooth devices search will begin.

17

Setup-Apple ios App Mode

4. Tap Socket S700[xxxxxx] in the list of other devices found. After

a few seconds the status will change to “Connected” and the scanner
blue LED will stop blinking and turn solid blue.

Note: The characters in brackets are the last 6 characters of the
Bluetooth Address.

5. Launch your scanner-enabled Application. The scanner will beep

once indicating that it is connected to the appropriate application.

Now you are ready to scan barcodes!

Please check with your scanner application vendor or visit

www.socketmobile.com/appstore to confirm your scanner-enabled

application supports the scanner.

18

Setup-Android App Mode

Scan QR Code using your host device to download Socket Mobile
Companion app to pair your scanner.

For quc set up

1. Power on the scanner. Make sure the scanner is discoverable
(unpaired). The Blue light should be blinking fast.

2. Scan barcode

(

Note: For the S730 laser barcode scanner print the barcode to scan).

App Mode (SPP)

3. Turn on Bluetooth on the Android device. Go to Settings >

Bluetooth. A Bluetooth Devices search will begin.

19

Setup-Android App Mode

4. Tap Socket S700[xxxxxx] in the list of other devices found. After
a few seconds the status will change to “Connected” and the LED
will stop blinking and turn solid blue.

Note: The characters in brackets are the last 6 characters of the
Bluetooth Address.

5. Launch your scanner-enabled Application. The scanner will beep
once indicating that it is connected to the appropriate application.

Now you are ready to scan barcodes!

20

Setup-Windows App Mode

Note: Make sure you have administrative privileges.

1. Download Companion for Windows:

https://www.socketmobile.com/support/companion

2. Follow on-screen instructions to install the software

3. Power on the scanner. Make sure the scanner is discoverable to be
connected to Bluetooth (unpaired).

4. Launch Companion from icon in the task tray. In the pop-up
menu, click Open.

5. Click the “Start” button and follow the instructions in the wizard.

6. Once complete, you will be ready to scan using Socket’s keyboard
emulation (this should be turned off if you have an application
that supports the Capture SDK)

Note: For the S730 laser barcode scanner print the barcode to scan.

App Mode (SPP)

Mode 1

Now you are ready to scan barcodes!

21

iMAC

Setup Basic Mode

In this mode the scanner functions and communicates similar to a
keyboard. Therefore, scanner will work with Safari, Notes, and any
other application that support an active cursor.

1. Power on the scanner. Make sure the scanner is

discoverable (unpaired). The Blue light blinks fast.

2. Start a Bluetooth device search.

• Settings | Bluetooth: Turn on Bluetooth and search for device.

• Mac OS: Click System Preferences | Bluetooth. A Bluetooth device
search will begin.

3. In the device list, tap on S700 [xxxxxx]. Tap Pair.

4. The scanner will connect to the Apple device.

5. The scanner will beep once after it has connected.

Now you are ready to scan barcodes!

22

Androd

Setup Basic Mode

In this mode the scanner functions and communicates similar to a
keyboard. Therefore, scanner will work with Notes, and any other
application that supports an active cursor.

1. Power on the scanner. Make sure the scanner is
discoverable (unpaired) and the blue light blinks fast.

2. Settings | Bluetooth.

3. Make sure the device has Bluetooth “On” to scan for devices.

4. In the list of found devices, select S700 [xxxxxx]. Tap Pair.

5. The scanner will connect to the Android device.

6. The scanner will beep once after it has connected.

*If you have trouble connecting or pairing with host device, turn host
device’s Bluetooth off/on, and/or perform factory reset to the scanner
(see page 25).

Now you are ready to scan barcodes!

23

Setup Basic Mode

Wndows

In this mode the scanner functions and communicates similar to a
keyboard. Therefore, scanner will work with Notes, and any other
application that support an active cursor.

1. Turn Bluetooth on for your device. Go to Settings > Bluetooth. A
Bluetooth Devices search will begin.

2. Tap Socket S700[xxxxxx] in the list of Devices found. After a few
seconds the status will change to “Connected” or “Paired” and the
scanner blue light will stop blinking and turn solid blue.

Now you are ready to scan barcodes!

24

This procedure will put the scanner in discoverable mode.

Pairing Reset

If the scanner is paired with a device, unpair it before trying to
connect to a different device.

Step 1: Remove or forget the scanner from the Bluetooth list on the
host device.

Step 2: Scan Pairing Reset barcode.

(Note: For the S730 laser barcode scanner print the barcode to scan).

Or, follow the Pairing Reset button sequence:

1. Power on the scanner.

2. Press the trigger button then power button and hold both until

you hear 3 beeps.

The scanner will unpair and automatically power off. The next time
you power on the scanner, it will be discoverable.

Importnt: Both steps above must be done to complete
the unpairing.

25

Factory Reset

Configures the scanner to factory defaults. The scanner powers off
after scanning this barcode.

Or, follow the Fctor Reset button sequence

1. Power ON the scanner.

2. Press and hold the scan button.

3. Tap the power button once while continuing to press the scan

button.

1

2

Quickly press and release
the power button

4. Keep holding the trigger button until you hear a beep

(about15 seconds).

When you release the scan button you will hear 5 confirmation beeps
then the scanner will power off.

Note: If you follow this sequence but release the trigger button too
early (before 15 seconds and the beep) the Factory Reset will fail.

26

Restore Method

NOTE: If your scanner remains in an unresponsive state after following
the Factory Reset, use the Restore Method.

The Restore Method should be the last attempt used to revive an
unresponsive scanner. It will reinitialize the core hardware.

1. Make sure your scanner is OFF.

2. Press and hold the power button until the LED light goes on and

off (about 15 seconds)

Watch Youtube video for demonstration.

27

Battery Replacement

Step 1 Remove Battery Door
Use screw driver to loosen screw and remove battery door.

Step 2 Remove Battery
Use a flat head screw driver and place in the top right corner to
gently push the battery out. Then, pull the connector to remove.

Step 3 Insert New Battery
Plug the connector on the new battery.

Step 4 Secure Battery Door
Ensure the battery door is properly placed, then screw the battery
door back on.

28

Quick Programming

Scan command barcode(s) to quickly configure the Scanner.

Importnt Make sure the Scanner is not connected to a host
computer or device before scanning a command barcode!

For custom prefix and suffix, contact [e-mail]

(Note: For the S730 laser barcode scanner print the barcode to scan).

Prefix/Suffix

Suffx- Crre
Return

(default) in Basic Mode

Configures the scanner
to add a carriage return
after decoded data.

Suffx- Tb

Configures the scanner
to add a tab after
decoded data.

Suffx- Crre
Return & Lne Feed

Configures the scanner
to add a carriage return
and line feed after
decoded data.

Dt As Is

Configures the scanner
to return only the
decoded data. (i.e., no
prefix or suffix).

29

Scn one of the brcodes to enble/dsble vbrte nd beep

Quick Programming

settns

(Note: For the S730 laser barcode scanner print the barcode to scan).

Vibrate/Beep Modes

Vbrte ON (default)

Enables scanner to
vibrate to indicate
successful scans.

Vbrte OFF

Disables scanner from
vibrating to indicate
successful scans.

Beep ON (default)

Enables scanner to
beep to indicate
successful scans.

Beep OFF

Disables scanner from
beeping to indicate
successful scans.

30

Scn one of the brcodes to reconfure the scnner to remn

Quick Programming

powered on for  loner tme

(Note: For the S730 laser barcode scanner print the barcode to scan).

Active Modes

2 Hours (defult)

Scanner powers off
in 2 hours whwen
idle/inactive while
connected and
5 minutes when
disconnected

Contnuous Power
for 4 Hours

Configures the
scanner to remain on
for 4 hours.

Contnuous Power
for 8 Hours

Configures the
scanner to remain on
for 8 hours.

Scnner Alws On

Configures the
scanner to never
power off.

These settns drn the btter fster Plese ensure the

scnner s chred dl

31

Scan one of the barcodes to configure the scanner to automatically

Quick Programming

scan barcodes.

Command barcode is for model S740 and S760 only.

Presentation modes

Moble Mode
(defult)

Reverts back to
manual scan mode.

#FNB 41FBA50000#

Auto Mode
(recommended)

Configures the
sccanner to switch
to presentation
mode when power
is detected on the
charging pins. The
scanner will remain
on presentation mode

#FNB 41FBA50003#

until the scan button
is pressed to exit the
mode.

Detect Mode

Configures the
scanner to switch
to presentation
mode when power
is detected on the
charging pins. The
automatic scan will
continue until power
is removed.

Stnd Mode

Scanner is
permanently in
presentation mode.

#FNB 41FBA50002#

#FNB 41FBA50001#

32

Quick Programming

These barcodes are to configure the scanner for different languages
using Microsoft Windows keyboard layout.

Scan only when the scanner is in Basic Mode (HID profile).

(Note: For the S730 laser barcode scanner print the barcode to scan).

HID Keyboard Language Settings

Enlsh (defult)

Enlsh U

French

Germn

Itln

33

(Note: For the S730 laser barcode scanner print the barcode to scan).

Quick Programming

HID Keyboard Language Settings

Jpnese

Polsh

Spnsh

Swedsh

ANSI Emulton
*Cn be slower on
Wndows Sstem

34

Status Indicators

Battery

Charging

when plugged

into Power

Supply

Battery Status

When not

connected to

power supply

LED Activity Meaning

Blinking Yellow Charging the battery

Solid Green Battery is 100% full

LED Activity Meaning

Solid Green

Solid Yellow

Solid Red

Blinking Red

Battery capacity from
100% to 25%

Battery capacity from
25% to 10%

Warning - Battery

capacity below 10%

Charge immediately!

The battery level is
critically low.
Alternatively, if battery
capacity is
unknown battery status
will blink red until the
power is applied &
scanner is fully charged.

35

Status Indicators

Bluetooth LED Activity Meaning

Quick Blinking Blue
(2 blinks every
second)

Bluetooth

Scan/Read LED Activity Meaning

Scan/Read

Slow Blinking Blue
(1 blink every
second)

No Light - No
Activity

Solid Blue Scanner is connected

Blink Green Once Good Scan/Read

Blink Red Once Bad Scan/Read

Solid Red - for
as long as power
button is pressed

Discoverable - waiting
for a host Bluetooth
connection.

Scanner is attempting to
connect to the last known
host device.
After 1 minute of
blinking, scanner will stop
searching.

Scanner has attempted
to connect and failed.
Press trigger button to try
again.

Power Button Pressed

Quick Blinking Green
(2 blinks every
second)

Scanner is in bootloader
mode during firmware
upgrade.

36

Status Indicators

Beep Pttern Sound Menn

Low-High Tone Power On

High-Low Tone Power Off

High-High Tone Power Supply detected and scanner started

charging

1 Low Beep Scanner has toggled on-screen keyboard or

keyboard toggle feature is enabled (iOS devices
only)

1 Beep Scanner connected to device and is ready to

scan
barcodes

1 Beep Data successfully scanned

2 Beeps (same
tone)

1 Long Beep Scanner gave up searching for a host

3 Beeps
(escalating tone)

3 Beeps
(escalating tone
followed by long
tone)

Scanner disconnected

Scanner has been reconfigured (the command
scanned successfully)

The command barcode did NOT work! (Verify
if the command barcode used is valid for your
scanner and try again)

37

Status Indicators

Vibrate Meaning

Vibrate Data successfully scanned.

Command Barcodes are available on page 28 to modify beep
and vibrate settings.

If you are using a scanner-enabled application, typically the
application provides settings for beep, and vibrate settings.

Configuration Settings

Time after powering on Scanner Bluetooth mode

0-5 minutes Discoverable and connectable

5 minutes If connection is not made,

scanner powers off

2 hours If your scanner is connected but

not used it will power off in 2
hours. When trigger button is
pressed the timer is reset.

38

Product Specifications

Specifications S700/S730/S740/S760

Dimensions (L x W
x H)

Total Mass 3.8 oz (108 g)

Battery 1400 mAh Lithium - Ion Battery

Charge Time

Battery Life -
Per Full Charge

Bluetooth Version

Wireless Range 10 meters (33 ft.)eters (98 feet) line of sight

Scanner Type

5.2” x 1.5” x 1.6” (132.2 x 37.1 x 40.1 mm)

8 Hours

Standby time: over 30 hours
Active Scan Time: 70,000 scans within 9 hours
(based on 2 scans every 1 second) or 14,000
scans within 16 hours (calculation based on 1
scan every 4 seconds)

Note: Battery life varies depending on
operating conditions.

Class 2 Bluetooth v2.1 + EDR with 56 bit
data
encryption

1D Barcode Omni-directional Imager with
highly visible light

39

Product Specifications

Specifications S700/S730/S740/S760

Symbologies See next page

Supported
Language Settings
[in Basic Mode (HID)]

Systems/Battery
Charging
Requirement

Ambient Light From 0 to 100 000 lux

English, French, German, Spanish

USB Type 5V 1A

From pitch black to direct sunlight

Operating
Temperature

Storage Temperature -40° to 158° F (-40° to 70° C)

Relative Humidity 95% at 140° F (60° C) (non-condensing), 4

Sealing (Ingress
Protection Rating for
solids and liquids)

Drop Specifications 4 ft. drops to linoleum

Tumble Specication

32° to 113° F (0° to 45° C)

days

IP40

2,500 cycles at 3.3 ft. (1 m) to metal plate,
IEC6008-2-31, IEC60068-2-32

40

Supported Symbologies

Supported
Symbologies

S700 S730 S740 S760

1D Barcodes

Bookland EAN

Chinese 2 of 5 x x x x

Codabar

Code 11 x x x x

Code 39

Code 39 Full ASCII x x x x

Code 93 x

Code 128

Discrete 2 of 5 x x x x

EAN-8/JAN

EAN-13/JAN

GS1-128

GS1 DataBar

GS1 DataBar Expanded

GS1 DataBar Limited

Enabled Enabled Enabled Enabled

P P P P

P

P P P P

P P P P

P P P P

P P P P

P P P P

P P P P

P P P P

P P P

x

P P P

P

x

x

Interleaved 2 of 5

Inverse 1D x x x x

ISBT 128

Matrix 2 of 5 x x x x

MSI x x x x

UPC-A

UPC-E

*Korean 3 of 5
(S730/S760 only)

P P P P

P P P P

P P P P

P P P P

x x x x

41

Supported Symbologies

Supported
Symbologies

2D Barcodes Enabled Enabled

S740 S760

Aztec

Codablock-F

Data Matrix

Han Xin

Maxicode

Micro PDF 417

PDF417

QR Code

*DotCode
S760 only

*Grid Matrix
S760 only

*GS1 QR (S760 only) x x

P P

P P

P P

P

P P

P P

P P

P P

x x

x x

x

*Micro QR (S760 only) x

*Linked QR (S760 only) x x

P

42

Supported

Supported Symbologies

Symbologies
Postal Codes Enabled Enabled

Australia Post x x

Japan Postal x x

USPS 4CB/
One Code/
Intelligent Mail

*Netherlands KIX Code
(S740/S760 only)

*UK Postal (S740/S760 only) x x

*US Planet (S740/S760 only) x x

*US Postnet (S740/S760 only) x x

Supported Font S760
OCR Enabled

S740 S760

x x

x x

OCR A x

OCR B

MICR E 13B x

US Currency x

Watermark Symbology S760
Digimarc Enabled

Digimarc

P

P

43

Helpful Resources

Techncl Support & Product Restrton

https://www.socketmobile.com/support

Phone: [phone] [phone] (worldwide)

Wrrnt Checer

https://www.socketmobile.com/support/warranty-checker

Socet Moble Developer Prorm

Learn more at: http://www.socketmobile.com/developers

The User’s Guide (full installation and usage instructions) and
Programming Guide (Advanced Scanner Configurations) can be
download at:

https://www.socketmobile.com/support/downloads

44

WARNING: Failure to follow these safety instructions could

Safety and Handling Information

result in fire or other injury or damage to the barcode scanners
or other property.

Crrn nd Hndln the SocetScn brcode scnners The
Socket Mobile barcode scanner contains sensitive components.
Do not disassemble, open, crush, bend, deform, puncture, shred,
microwave, incinerate, paint, or insert foreign objects into this unit.

Do not attempt to disassemble the product. Should your unit need
service, contact Socket Mobile technical support at

https://www.socketmobile.com/support

Changes or modifications of this product, not expressly approved by
Socket Mobile may void the user’s authority to use the equipment.

Do not charge the SocketScan barcode scanner using an AC adapter
when operating the unit outdoors, or in the rain.

Opertn Temperture - this product is designed for a maximum
ambient temperature of 50° degrees C or 122° degrees F.

Pcemer Dsclmer For now, we do not have specific
information on the effect(s) of vibration or Bluetooth devices on
pacemakers. Socket Mobile cannot provide any specific guidance.
Individuals who are concerned with using the barcode scanner should
immediately turn the device off.

45

FCC ID T9J-RN42

Bluetooth Device United States

LUBMA41

Federl Communcton Commsson Interference Sttement

This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful
interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from

that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

FCC Cuton: To assure continued compliance, any changes or
modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate this equipment.
(Example - use only shielded interface cables when connecting to
computer or peripheral devices).

46

FCC Rdton Exposure Sttement

Bluetooth Device United States

This equipment complies with FCC RF radiation exposure limits set
forth for an uncontrolled environment. This device meets the FCC
requirements for RF exposure in public or uncontrolled environments.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:

1. This device may not cause harmful interference, and

2. This device must accept any interference received, including
interference that may cause undesired operation

47

IC

Bluetooth Device Canada

ID

This device complies with Industry Canada license exempt RSS
standard(s). Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this device must
accept any interference, including interference that may cause
undesired operation of the device.

Le présent appareil est conforme aux CNR d’Industrie Canada
applicables aux appareils radio exempts de licence. L’exploitation est
autorisée aux deux conditions suivantes: (1) l’appareil ne doit pas
produire de
brouillage, et (2) l’utilisateur de l’appareil doit accepter tout
brouillage radioélectrique subi, même si le brouillage est susceptible
d’en
compromettre le fonctionnement.

6514A-RN42
2529A-MA41-S7

48

CE Mrn & Europen Unon Complnce

Bluetooth Device Europe

Products intended for sale within the European Union are marked
with a CE Mark, which indicates compliance to applicable Directives
and European Normes (EN), as follows. Amendments to these
Directives or ENs are included: Normes (EN), as follows:

Applcble Drectves

• Bluetooth Products: R&TTE Directive 2014/53EW

• Low Voltage Directives: 2014/35/EU, and 2006/95/EC

• EMC Directive: 2004/108/EU

• Rotts Directive: 2011/65/EU

• WEEE Directive: 2012/19/EU

SAFETY: EN 60950-1: 2006/A11
:2009/A1
:2010/A12
:2011/A2:2013

49

Telec Mrn Complnce

Bluetooth Device JAPAN

Products intended for sale within the country of Japan
are marked with a Telec mark, which indicates compliance to
applicable Radio Laws, Articles and Amendments.

R201-125709
R 211-181219

50

Battery Warning Statements

This device contains two AA rechargeable NiMH replaceable
batteries.

Stop charging SocketScan barcode scanners if charging is not
completed within 24 hours. (Look into replacing the battery).

Stop charging the battery if the SocketScan barcode scanner case
becomes abnormally hot, or shows signs of odor, discoloration,
deformation, or abnormal conditions is detected during use, charge,
or storage.

Stop using the SocketScan barcode scanner if the enclosure is
cracked, swollen or shows any other signs of misuse, discontinue use
and email [e-mail].

Your device contains a rechargeable NiMH battery which may
present a risk of fire or chemical burn if mistreated.

Do not charge in hot temperatures over 60 degrees C or 140 degrees F.

• Never throw the battery into a fire, as that could cause the battery
to explode.

• Never short circuit the battery by bringing the terminals in contact
with another metal object. This could cause personal injury, or fire,
and could also damage the battery.

• Never dispose of used batteries with other ordinary solid wastes.
Batteries contain toxic substances.

51

Battery Warning Statements

• Dispose of used batteries in accordance with the prevailing
community regulations that apply to the disposal of batteries.

• Never expose this product or the battery to any liquids.

• Do not shock the battery by dropping it or throwing it.

If this unit shows any type of damage, such as bulging, swelling or
disfigurement, discontinue use and promptly dispose.

Product Dsposl

Your device should not be placed in municipal waste. Please check
local regulations for disposal of electronic products.

52

Laser and LED Devices

Cuton: DO NOT STARE DIRECTLY INTO THE LASER BEAM.

The following statement is required to comply with US and
international regulations:

Cuton: Use of controls, adjustments or performance of
procedures other than those specified herein may result in
hazardous laser beam exposure.

MODEL - S730 CAUTION - LASER LIGHT. DO NOT

STARE INTO BEAM. CLASS 2 LASER PRODUCT

COMPLIES WITH LASER NOTICE 50.

650nm

1.0mw

ATTENTION - LUMIERE LASER NE PAS

REGARDER LE RAYON. CLASSE 2 PRODUIT LASER

Complies with Laser Notice 50, dated June 24, 2007
Complies with IEC/EN 60825-1:2007, IEC/EN60825-1:2014
Manufacturer Name: Socket Mobile, Inc.
MANUFACTURER ADDRESS: 39700 Eureka Drive, Newark, CA 94560,
USA

53

Regulatory Compliance

CE MARKING AND EUROPEAN UNION COMPLIANCE
Testing for compliance to CE requirements was performed by an
independent laboratory. The unit under test was found compliant
with all the applicable Directives, 2004/108/EC and 2006/95/EC.

WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT
The WEEE directive places an obligation on all EU-based
manufacturers and importers to take-back electronic products at the
end of their useful life.

RoHS STATEMENT OF COMPLIANCE
This product is compliant to Directive 2011/95/EC.

NON-MODIFICATION STATEMENT
Changes or modifications not expressly approved by
the party responsible for compliance.

CONFORMS TO THE FOLLOWING EUROPEAN DIRECTIVES

Low Voltage Directives: 2014/35/EU
RED Directive: 2014/53/EU
EMC Directive: 2014/30/EU
RoHS Directive: 2011/65/EC
WEEE Directive: 2012/19/EC

Supplementary Information:

Safety: EN 60950-1: 2006/A11:2009, A12:2011, A1:2010, A2:2013
ETSI EN 300 328
ETSI EN 301 489

WEEE

54

Limited Warranty

Socket Mobile Incorporated (Socket) warrants this product against
defects in material and workmanship, under normal use and
service, for one (1) year from the date of purchase. Product must be
purchased new from a Socket Authorized Distributor or Reseller. Used
products and products purchased through non-authorized channels
are not eligible for this warranty support.

Warranty benefits are in addition to rights provided under local
consumer laws. You may be required to furnish proof of purchase
details when making a claim under this warranty.

Consumables such as batteries, removable cables, cases, straps,
and chargers: 90 day coverage only

For more warranty information, please visit:

https://www.socketmobile.com/support/downloads/product-support

55

Extend Your Warranty...

SocketCare

Receive Priority Service and Personal Care.

You have 60 Days from purchase date to enroll in a SocketCare Service
Program!

For detailed information visit:

https://www.socketmobile.com/socketcare

04/2021
