Page 1

ELECTRIC PRESSURE WASHER

2030 PSI | 1.76 GPM | 14.5 AMP

Model SPX3000

A Division of Snow Joe®, LLC

IMPORTANT!

Safety Instructions

All Operators Must Read These Instructions Before Use

mWARNING! This indicates a hazardous situation, which,

if not avoided, could result in death or serious injury.

mCAUTION! This indicates a hazardous situation, which,

if not avoided, could result in minor or moderate injury.

mDANGER! This indicates a hazardous situation, which,

if not followed, will result in death or serious injury.

General Safety

WARNING! This appliance is not intended for use

by children or by unassisted, unsupervised persons whose physical, sensory or mental capabilities prevent them from using it safely. Children should be supervised to ensure that they do not play with the appliance.

Before starting up your machine, please check it carefully for

any defects. If you nd any, do not start up your machine.

Contact your authorized Snow Joe call the Snow Joe 1-866-SNOWJOE (1-866-766-9563).

+ Sun Joe® customer service center at

+ Sun Joe® dealer or

mWARNING! When using the pressure washer, basic

safety precautions should always be followed to reduce the

risk of re, electric shock, and personal injury. These include:

• Know your product – Know how to stop the machine and

bleed pressure quickly. Thoroughly familiarize yourself with the controls.

• Keep bystanders away – All visitors and pets should be

kept a safe distance away from the work area.

• Use the right product – Do not use this machine for any

job except that for which it is intended.

• Dress properly – Do not wear loose clothing or jewelry.

They can get caught in moving parts. Protective rubber gloves and non-slip footwear are recommended when working outdoors.

•

mCAUTION! – Exercise caution to avoid slipping or falling.

Wear protective footwear that will protect your feet and improve your footing on slippery surfaces.

Form No. SJ-SPX3000-880E-MR2

OPERATOR’S MANUAL

• Stay alert – Watch what you are doing. Use common

sense. Do not operate the pressure washer when you are tired, or under the inuence of alcohol or drugs.

• Do not overreach –

all times.

• Avoid unintentional starting – Do not carry a plugged-

in machine with your nger on the trigger. Make sure the switch is o before plugging in the machine.

• Do not abuse the cord – Never carry the machine by the

cord or yank the cord to disconnect it from the receptacle. Keep the cord away from heat, oil, and sharp edges.

• Use safety glasses – Also use safety footwear, snug-tting

clothing, protective gloves, hearing and head protection.

• Check the water temperature – This pressure washer is

not meant to pump hot water. NEVER connect it to a hot

water supply as it will signicantly reduce the life of the

pump.

• Store indoors – NEVER store the pressure washer

outdoors or where it could freeze. The pump could be seriously damaged.

• Ground Fault Circuit Interrupter (GFCI) – Protection

should be provided on the circuits or outlets to be used for this pressure washer. Receptacles are available having built-in GFCI protection and may be used for this measure of safety.

• Inspect electrical cables – The insulation of the power cord should be perfectly intact. If the power cord is damaged or shows any signs of wear or tear, do not use the pressure washer. Contact your authorized Snow Joe

Sun Joe service center at 1-866-SNOWJOE (1-866-766-9563).

dealer or call the Snow Joe® + Sun Joe® customer

Keep proper footing and balance at

mWARNING! Do not use this appliance without reading

this instruction manual.

mWARNING! This appliance has been designed for

use with cleaning agents that are recommended by the manufacturer. The use of other cleaning agents or chemicals

may adversely aect the safety of the appliance.

mWARNING! Do not use the appliance within range of

persons unless they are wearing protective clothing.

mWARNING! High-pressure jets can be dangerous if

subject to misuse. The jet must not be directed at persons, pets, live electrical equipment, or the appliance itself.

• Do not direct the jet at yourself or others in order to clean

clothes or footwear.

• Risk of explosion – Do not spray ammable liquids.

SAVE THESE INSTRUCTIONS

Page 2

• Disconnect the tool – Disconnect from the electrical power

supply before performing any maintenance task.

• Keep children away – This high-pressure electric

power washer must not be used by children or untrained personnel.

• To ensure appliance safety, use only original replacement

parts from the manufacturer or those approved by the manufacturer.

mWARNING! Water that has owed through backow

preventers is considered to be non-potable.

mWARNING! During cleaning, maintenance or when

replacing parts, the machine must be disconnected from its power source by removing the plug from the socket outlet.

mWARNING! High-pressure hoses, ttings, and

couplings are important for the safe operation of the appliance.

Use only hoses, ttings, and couplings recommended by the

manufacturer.

• Check for damaged parts – Do not use the appliance if

the supply cord or other important parts of the appliance are damaged (e.g. safety devices, high-pressure hoses, trigger gun).

mWARNING! If an extension cord is used, the plug and

socket must be of watertight construction.

mWARNING! Inadequate extension cords can be

dangerous.

• This high-pressure electric power washer must not be used

at temperatures below 32ºF (0°C).

mWARNING! Power cords on drums should always be

completely unwound to prevent the cord from overheating.

• Power cord connections should be kept dry and o the

ground.

• If the power cord is damaged, do not use the appliance.

Contact your authorized Snow Joe® + Sun Joe® dealer or call the Snow Joe 1-866-SNOWJOE (1-866-766-9563).

• Keep the machine on a stable, at surface during operation,

handling, transportation, and storage. Sudden overturn of the machine can cause bodily injury.

• In the event of an accident or breakdown, switch o the

machine immediately. (If contact with detergent occurs, rinse with an abundance of clean water.)

+ Sun Joe® customer service center at

Electrical Safety

ATTENTION: If there are problems with the electrical

MAINS, short voltage drops may appear when starting the equipment. This can, in turn, inuence other equipment (e.g. cause a lamp to blink). If the MAINS-IMPEDANCE Zmax < 0.335 OHM, such disturbances are not expected. (If you require assistance, contact your local supply authority for further information.)

mWARNING! Electrical Shock Hazard – Before starting

up your machine, please check it carefully for any defects. If

you nd any, do not start up your machine and contact your

distributor.

The following should be observed when connecting the

high-pressure electric power washer to the electric supply:

• The electric supply connection should be performed by a qualied person.

• The electric supply to this appliance should include either

a residual current device that will interrupt the supply if the leakage current to the earth exceeds 30 mA for 30 ms or a device that will interrupt the earth circuit (GFCI).

IMPORTANT: Only use water without any impurities.

If there is a risk of running sand into the inlet water (i.e. from

your own well), an additional lter should be installed.

Safety devices

The unloader valve can reduce pressure if it exceeds preset values. The spray gun features a locking device. When the lock is activated, the spray gun cannot be operated.

1. Thermal sensor – A thermal sensor protects the motor against overloading. The machine will restart after a few minutes when the thermal sensor has cooled.

2. Double insulation – In a double-insulated appliance, two systems of insulation are provided instead of grounding. No grounding means is provided on a double-insulated appliance, nor should a means for grounding be added to the appliance. Servicing a double-insulated appliance requires extreme care and knowledge of the system, and

should be performed only by qualied service personnel at

an authorized Snow Joe parts for a double-insulated appliance must be identical to the parts they replace. A double-insulated appliance is marked with the words “Double Insulation” or “Double Insulated.” The symbol also be marked on the appliance.

3. Ground fault circuit interrupter (GFCI) protection – A GFCI should be provided on the circuit(s) or outlet(s) to be used for the pressure washer. Receptacles are available having built-in GFCI protection and may be used for this measure of safety.

4. It is not recommended to use an extension cord with this pressure washer. The unit comes standard with a 35 ft GFCI power cable. Using an extension cord may cause a drop in line voltage resulting in loss of power and overheating.

5. To reduce the risk of electric shock, this appliance has a polarized plug (i.e. one blade is wider than the other).

The appliance plug will t into a polarized outlet only one

way.

If the appliance plug does not t fully into the outlet,

reverse the plug. If the plug still does not t, make sure

that you are using the correct polarized wall outlet. If the

+ Sun Joe® dealer. Replacement

(square within a square) may

Page 3

plug still does not t, contact a qualied electrician to

install the proper wall outlet. Do not modify the appliance plug, power cord receptacle, or power cord plug in any way.

m WARNING m

Electric shock may cause SEVERE INJURY or DEATH. Heed these warnings:

• Do not allow any part of the electric pressure washer

to make contact with water while it is in operation. If

the appliance becomes wet while turned o, wipe dry

before starting.

• Do not use an extension cord over 25 ft. The

pressure washer comes equipped with a 35 ft power cable. Combined cord length must not exceed 60 ft. Any extension cord must be 14-gauge (or heavier) to safely power the pressure washer.

• Do not touch the appliance or its plug with wet hands

or while standing in water. Wearing rubber boots

oers some protection.

EXTENSION CORD CHART

Cord Length:

Min. Wire Gauge (A.W.G.):

6. To prevent the appliance cord from disconnecting from the extension cord during operation, make a knot with the two cords as shown in Table 1.

25 ft (7.6 m)

Risk of electrocution

• Inspect cord before using.

• Do not use if cord is damaged.

• Keep all connections dry and o the ground.

• Do not touch plug with wet hands.

• Keep cord away from heat and sharp edges.

• Do not spray electrical apparatus and wiring.

Risk of explosion

• Do not spray ammable liquids.

• Do not use acids, bases, solvents, or any ammable

material in this product. These substances can cause physical injuries to the operator and irreversible damage to the machine.

Additional safety instructions

• High-pressure: keep clear of nozzle.

• Injection hazard: equipment can cause serious injury if the

spray penetrates the skin.

• Do not point the gun at anyone or at any part of the body.

• In case of skin penetration, seek medical aid immediately.

• Before servicing, cleaning, or removing any parts, shut o

the power and relieve pressure.

• This machine is not suitable for connection to the potable

water mains.

Product Description

Table 1. Method of Securing Extension Cord

Cord set Appliance cord

(A) Tie cord as shown

(B) Connect plug and receptacle

7. Do not abuse the cord. Never pull the pressure washer

by the cord or yank the cord to disconnect it from the receptacle. Keep the cord away from heat, oil, and sharp edges.

Purpose

• This high-pressure electric power washer is intended for

residential use to clean vehicles, machines, buildings, facades, etc.

Areas of application

• Never use the machine in potentially explosive areas under

any circumstances!

• The operating temperature must be between 32ºF (0ºC) and

104ºF (40ºC).

• The machine consists of an assembly with a pump, which

is encased in a shock-absorbing housing. To provide the operator with an optimal working position, the machine is equipped with a spray wand and a non-slip handle grip,

whose shape and conguration comply with applicable

regulations.

• Do not cover or modify the spray wand or the spray nozzles

in any way.

• The high-pressure electric power washer is designed to be

used with cold or lukewarm water; higher temperatures can damage the pump.

• Do not use water that is dirty, gritty, or contains any

chemical products, as these could impair operation and shorten the life of the machine.

Page 4

Safety Symbols

The following table depicts and describes safety symbols that may appear on this product. Read, understand, and follow all instructions on the machine before attempting to assemble and operate.

Symbols SymbolsDescriptions Descriptions

READ THE OPERATOR'S MANUAL(S) – Read, understand,

and follow all instructions in the user manual(s) before attempting to assemble and operate.

WARNING! Electrical shock hazard.

SAFETY ALERT – Indicates a

precaution, a warning, or a danger.

WEAR EYE AND HEARING PROTECTION – For protection

against injury, wear ear defenders and safety goggles.

Wear safety gloves during use to protect hands.

Store indoors. Never store the pressure washer outdoors. If the pump freezes, permanent damage may result.

WARNING! Do not expose the unit to rain or wet conditions. Keep dry.

To reduce the risk of injury, user must keep all bystanders at least 49 ft (15 m) away.

Wear non-slip footwear that will protect your feet and improve your footing on slippery surfaces.

Machine not suitable for connection to the potable water mains.

Always keep the power cable away from heat sources, oils, or sharp edges. Immediately remove plug from the mains if the cable is damaged, frayed, or entangled.

Sound power level is 96 dB(A).

WARNING! Turn the machine OFF and disconnect it from the power supply before inspecting, cleaning, changing accessories, or conducting any other maintenance task.

Double Insulation – When servicing, use only identical replacement parts.

Page 5

Know Your Electric Pressure Washer

15º

25º

0º

SOAP

40º

Read the owner’s manual and safety instructions carefully before operating the electric pressure washer. Compare the illustration below to the electric pressure washer in order to familiarize yourself with the location of the various controls and adjustments. Save this manual for future reference.

1. Safety lock (Locate lock in center of trigger. Pull up and snap in place. See Fig. 20, pg. 10)

2. Trigger

3. Transport handle

4. High-pressure hose connection

5. Trigger gun

6. Spray wand

7. Water inlet (garden hose connection)

8. Spray wand protector

9. High-pressure hose

10. Garden hose adaptor (female coupler)

11. Needle clean-out tool

12. 0º Quick-Connect nozzle (orange)

13. 15º Quick-Connect nozzle (yellow)

14. 25º Quick-Connect nozzle (green)

15. 40º Quick-Connect nozzle (gray)

16. Soap Quick-Connect nozzle (black)

17. Detergent selection dial

18. Removable detergent tanks

19. Hose holder

20. On/O switch

21. Power cord with GFCI

22. Cord holder

23. Onboard storage for Quick-Connect nozzles

24. Detergent tube

25. Trigger gun holder

26. Water outlet

(high-pressure connection)

27. Wheels 9

1 2 3

(REAR)(FRONT)

Technical Data

Rated Voltage 120 V ~ 60 Hz

Motor 14.5 amp (1800 W)

Max. Water Inlet Temperature 104ºF/40ºC

Max. Water Inlet Pressure 0.7 MPa

Max. Rated Flow 1.76 GPM

14122613 15 16

Rated Pressure 1450 PSI

Max. Pressure 2030 PSI

Hose Length 20 ft (6 m)

Power Cord Length 35 ft (10.7 m)

Weight 31 lbs (14 kg)

Page 6

Unpacking

Assembly

Carton Contents

• Electric pressure washer

• Handle

• Trigger gun

• Spray wand

• Five (5) Quick-Connect nozzles (0º, 15º, 25º, 40º and Soap)

• Two (2) removable detergent tanks

• Four (4) large screws

• Two (2) small screws

• Spray wand protector

• Trigger gun holder

• Hose holder

• Needle clean-out tool

• High-pressure hose

• Garden hose adaptor (female coupler) with two sealing rings

• Manual with registration card

1. Carefully remove the pressure washer and check to see that all of the above items are supplied.

2. Inspect the product carefully to make sure no breakage or

damage occurred during shipping. If you nd damaged or

missing parts, DO NOT return the unit to the store. Please call the Snow Joe

1-866-SNOWJOE (1-866-766-9563).

NOTE: Do not discard the shipping carton and packaging

material until you are ready to use your new electric pressure washer. The packaging is made of recyclable materials. Properly dispose of these materials in accordance with local regulations.

IMPORTANT! The equipment and packaging material are not toys. Do not let children play with plastic bags, foils, or small parts. These items can be swallowed and pose a

suocation risk!

+ Sun Joe® customer service center at

1. Position the washer as CLOSE as possible to the water supply.

2. The washer must be used on a secure and stable surface in a standing, upright position (Fig. 1).

Fig. 1

3. Slide the trigger gun holder into position (Fig. 2).

Fig. 2

4. Slide the handle into position and secure it with 4 large

screws (Fig. 3).

mWARNING! Do not connect to power supply until

assembly is complete. Failure to comply could result in accidental starting and possible serious personal injury.

Fig. 3

4 large screws

Page 7

5. Insert the detergent bottles (top end rst) under the ridge

of their designated storage compartment (Figs. 4 & 5). Then snap the bottom of the bottles into the V-shaped grooves to secure them in place (Fig. 6).

Fig. 4

6. Connect the PVC detergent tube to the detergent

connection (Fig. 7).

Fig. 7

Detergent tank

Fig. 5

Detergent tube

7. To assemble the spray wand protector, rst snap the tab

into the slot located at the bottom left side of the unit, and then secure it in place with one small screw. (Figs. 8 & 9).

Detergent connection

Fig. 8

Fig. 6

Fig. 9

small screw

Page 8

8. To assemble the hose holder, slide the holder into position (Figs. 10 & 11) and secure it to the unit with the remaining small screw (Fig. 12).

Fig. 10

9. Fit the spray wand into the trigger gun and rotate it until

the two parts are completely locked (Fig. 13).

Fig. 13

Trigger gun

Spray wand

10. Connect the high-pressure hose to the trigger gun

(Fig. 14).

Fig. 11

Fig. 12

OFF

Fig. 14

Trigger gun

High-pressure hose

11. Connect the high-pressure hose to the water outlet on the

washer (Fig. 15).

Fig. 15

(REAR)

Small screw

High-pressure hose

High-pressure water outlet

Page 9

mWARNING! Keep hose away from sharp objects.

Bursting hoses may cause injury. Examine hoses regularly and replace if damaged. Do not attempt to mend a damaged hose.

12. Connect the garden hose adaptor (female coupler) to the water inlet of the pressure washer, then thread your garden hose (male end) into the garden hose adaptor (Fig. 16). The garden hose must have an internal diameter of at least 13 mm (1/2 in.) and must be reinforced. The water supply must be at least equal to the washer delivery capacity.

NOTE: The machine is not suitable for connection to the

potable water main.

Fig. 18

OFF

(FRONT)

Garden hose (male end)

Fig. 16

13. Attach garden hose to water supply (Fig. 17).

This end to the water inlet on the unit

Garden hose

Water inlet

(female coupler)

Fig. 17

Connect to water supply

Garden hose

15. Check that the electrical supply voltage and frequency

(Volt/Hz) correspond to those specied on the pressure

washer rating plate. If the power supply is correct, you may now plug the pressure washer into the power outlet (Fig. 19).

Fig. 19

Reset

RESET

GFCI

TEST

Power light indicator

NOTE: The GFCI may need to be reset when rst plugged

into the electric outlet. Press the "Reset" button until the power light indicator on the GFCI illuminates.

mWARNING! The intake water temperature must not

exceed 104ºF/40ºC. The water supply must not exceed

0.7 MPa.

mCAUTION! The washer must only be used with clean

water; use of unltered water containing corrosive

chemicals will damage the washer.

14. Make sure the motor switch is pushed to the OFF (0) position before plugging the unit into the power outlet (Fig. 18).

Operation

IMPORTANT! This pressure washer is equipped with

a micro-switch sensitive to water ow. This Total Stop System (TSS) senses water ow in the pump. When the trigger is released, water stops owing through the pump. The TSS then automatically turns the motor o to protect the pump from

overheating, thus saving energy and prolonging pump life.

1. Turn the water supply tap on completely.

2. Make sure the safety lock is down and in its original

position (Fig. 20), then press the trigger for a few seconds

until water ow is steady. This will allow air to escape and

discharge any residual pressure in the hose.

Page 10

Fig. 20

2. Engage the safety lock on the trigger handle by pushing

up on the safety lock until it clicks into the slot (Fig. 22).

Slot

Safety lock

Trigger

3. Turn the switch to the ON (I) position to start the pressure

washer (Fig. 21).

Fig. 21

OFF

Fig. 22

Slot

Safety lock

3. Snap the desired nozzle onto the Quick-Connect collar

until it clicks into place (Fig. 23).

Fig. 23

Spray wand

Nozzle

“Click”

Using the nozzles

Before beginning any cleaning task, determine the best nozzle

for the job. Each of the nozzles has a dierent spray pattern. The nozzle patterns are 40˚ (for gentle cleaning), 25˚ (for all-purpose cleaning), 15˚ (for tough jobs), 0˚ (for spot cleaning

or hard-to-reach areas) and the Soap nozzle (for detergent application).

mCAUTION! NEVER change nozzles without locking the

safety lock on the trigger handle.

mWARNING! High-pressure jets can be dangerous if

subject to misuse. The jet must not be directed at persons, pets, live electrical equipment, or the appliance itself.

This electric pressure washer is equipped with ve (5) Quick-Connect nozzles that easily snap onto the Quick-Connect collar of the spray wand.

To connect a nozzle to the spray wand:

1. Turn o the pressure washer and shut o the water supply.

Pull the trigger to release water pressure.

Quick-Connect collar

To disconnect a nozzle from the spray wand once the cleaning

job is complete:

4. Turn o the pressure washer and shut o the water supply.

Pull the trigger to release water pressure.

5. Engage the safety lock on the trigger handle by pushing up on the safety lock until it clicks into the slot (Fig. 22).

6. Remove the nozzle by placing your hand over the nozzle while pulling back on the Quick-Connect collar.

mWARNING! Do not make changes to the nozzle while

the trigger is engaged. Doing so could result in damage to the pressure washer or injury to the user.

Working with detergents

When cleaning with the pressure washer, some cleaning tasks can be solved with water alone, but for most tasks cleaning

with detergent allows for more eective dirt removal.

Page 11

mWARNING! Use only detergents specically designed

for use with pressure washers. DO NOT USE household detergents, acids, alkaline solutions, bleaches, solvents,

ammable material, or industrial grade solutions. These could

damage the pressure washer. Many detergents may require mixing prior to use. Prepare the cleaning solution as instructed

on the solution bottle.

1. Remove the cap(s) and detergent suction tube(s) from the detergent bottle(s).

2. Gently pull each of the onboard detergent tanks out of its

storage position and ll each tank with detergent (Fig. 24).

Fig. 24

Fig. 25

Detergent selection dial

8. Apply detergent from the bottom to the top of the dry

surface to be cleaned.

NOTE: Wetting the surface rst is not recommended as it

dilutes the detergent and reduces its cleaning ability.

9. Allow the detergent to remain on the surface for a short time before rinsing. Do not allow the detergent to dry on the surface.

Detergent tank

3. Insert the suction tube(s) back into the tank(s) and cap the

tank(s) closed. Push the tank(s) back into storage position on the unit.

4. Use the detergent dial to select which of the two detergent tanks the unit will draw from and to control the rate of

ow. When not working with detergent, such as when

using a non-soap nozzle, turn the detergent dial to the center (O) (Fig. 25).

5. Install the Soap nozzle (black) on the spray wand (Fig. 23).

Pressure washer detergent

mCAUTION! Always test the detergent in an

inconspicuous area before use.

6. Turn on the pressure washer. Pull the trigger to operate the unit. The liquid detergent will automatically mix with water and be discharged through the nozzle.

7. Turn the detergent dial to adjust the suction volume of the detergent solution (Fig. 25).

mCAUTION! Damage may occur to painted surfaces if

the detergent is allowed to dry on the surface. Wash and rinse a small section at a time. Avoid working on hot surfaces or in direct sunlight.

10. When you have nished using the detergent injection

system, remove the detergent suction tube from the detergent bottle and insert it into 1.3 gal (5 L) of fresh water. Siphon water at low pressure for one minute so that

all the detergent is ushed through the system. Remove

the detergent bottle and rinse it until it is thoroughly cleaned.

mCAUTION! Failure to follow these cleaning instructions

will cause the injection system to become clogged and inoperable.

Rinsing with the pressure washer

1. Turn o the pressure washer and shut o the water supply.

2. Pull the trigger to release water pressure.

3. Engage the safety lock on the trigger handle by pushing

up on the safety lock until it clicks into the slot (Fig. 22).

4. Remove the nozzle by placing your hand over the nozzle while pulling back on the Quick-Connect collar.

Page 12

5. Select the right nozzle for the job (Fig. 26):

Fig. 26

0º

15º

i) The 0º intense-jet nozzle (orange) is an extremely

powerful nozzle that delivers a high-pressure, pencilpoint jet stream. It is used to cut heavy dirt deposits in a small, concentrated area. It is ideal for dissolving stubborn substances, like tar and grease spots on concrete, or for removing caked mud from equipment. Use this nozzle to clean hard-to-reach areas including the facades of 2-story buildings or the undersides of lawn mowers and tractors.

NOTE: Care should be used when choosing the

right nozzle to avoid permanently gouging wood or damaging fragile surfaces.

ii) Use the 15º fan-tip nozzle (yellow) for intense cleaning

jobs on hard surfaces. Applications include stripping paint, removing oil stains, grease, heavy mildew stains, and rust from steel. This nozzle should only be used in areas that can withstand the high-pressure from this nozzle.

iii) Use the 25º fan-tip nozzle (green) to clean home siding,

brick patios, wood decks, driveways, or sidewalks.

When using this nozzle, test a small area rst to avoid

surface damage.

iv) Use the 40º wide-spray tip nozzle (gray) to clean items

such as cars, trucks, boats, patio furniture, or lawn equipment.

v) Use the Soap nozzle (black) for low-pressure detergent

application to clean equipment, remove mildew and oxidation stains from houses, clean bricks or degrease grimy surfaces.

NOTE: When using detergent, make sure to install the

correct Soap nozzle (black). All of the other colored nozzles will not work for detergent application.

6. Start at the top of the area to be rinsed and work your way down, making sure to overlap your strokes.

25º

40º

SOAP

mIMPORTANT! NEVER USE:

• Bleach, chlorine products, and other corrosive chemicals

• Liquids containing solvents (e.g. paint thinners, gasoline,

oils)

• Tri-sodium phosphate products

• Ammonia products

• Acid-based products

These chemicals will harm the unit and will damage the cleaning surface.

Shutting down

1. Turn the switch to the OFF (0) position and unplug the

power cord from the outlet.

2. Turn o the water source.

3. Hold the trigger to release water pressure.

4. Disconnect the garden hose from the water inlet on

the unit.

5. Disconnect the high-pressure hose connection on the trigger gun handle.

6. Release the trigger and engage the gun safety lock.

mWARNING! Turn o the water supply and squeeze the

trigger to depressurize the unit. Failure to do so could result in personal injury due to discharge of high-pressure water.

Taking a break

If you are taking a break of ve minutes or more between cleaning tasks:

1. Engage the gun safety lock (Fig. 22).

2. Turn the switch to the OFF (0) position.

3. Unplug the power cord from the outlet.

Storage

CAUTION! Always store your pressure washer in a

location where the temperature will not fall below 32ºF (0ºC). The pump in this machine is susceptible to permanent damage if it freezes. FREEZE DAMAGE IS NOT COVERED BY THE

WARRANTY.

• Store the pressure washer indoors in a dry, covered area

where it is not subject to adverse weather conditions.

• It is important to store this product in a frost-free area.

• Always empty water from all hoses, the pump, and the

detergent bottle(s) before storing.

mCAUTION! The use of a pump protector is

recommended to prevent cold weather damage during storage over the winter months.

Page 13

Winterizing and long-term storage

If you must store your pressure washer in a location where the temperature falls below 32ºF (0ºC), you can minimize the chance of damage to your machine by utilizing the following

procedure:

• Disconnect all water connections.

• Turn on the machine for a few seconds until the remaining water in the pump exits. Turn o immediately.

• Do not allow the high-pressure hose to become kinked.

• Store the machine and accessories in a room that does

not reach freezing temperatures.

• Do not store near a furnace or other sources of heat that may dry out the pump seals.

• Operate the pressure washer with non-corrosive/non-toxic

anti-freeze, a pump saver, or a pump protector before storing for the winter.

Fig. 28

Inletlter

2. Clean the nozzle with the needle clean-out tool provided (Fig. 29). Remove the spray wand from the gun; remove any dirt from the nozzle hole and rinse.

mWARNING! Before reusing, completely ush the unit

out with clear water. Anti-freeze products can damage paintwork, so you must ensure there is no anti-freeze left in the

system before using it again.

Maintenance

CAUTION! Before working on the pressure washer,

disconnect the plug from the power supply socket.

1. To ensure good performance, check and clean the water

inlet lter (Fig. 27). Remove the lter and rinse with warm water to prevent any foreign matter from clogging the pump (Fig. 28).

Fig. 27

Garden hose adaptor

(FRONT)

Waterinletlter

Fig. 29

15º

Needle clean-out tool

3. Remove additional debris by back ushing water through

the nozzle and spray wand. To do this, place the end of your garden hose (with water running) to the tip of the nozzle, pushing water and debris out of the back opening of the nozzle and spray wand.

Circuit Diagram

A circuit diagram for the pressure washer is provided below for your reference (Fig. 30).

Fig. 30

Micro-switch

Power cord

Motor

On/off switch

Capacitor

Page 14

Disposal

Recycling the washer

• Do not dispose of electrical appliances as unsorted

municipal waste. Use separate collection facilities.

• Contact your local government agency for information

regarding the collection systems available.

• If electrical appliances are disposed of in landlls

or dumps, hazardous substances can leak into the groundwater and get into the food chain, damaging your health and well-being.

• When replacing old appliances with new ones, the retailer

is legally obligated to take back your old appliance for disposal at least free of charge.

Service and Support

If your Sun Joe® Pressure Joe SPX3000 electric pressure washer requires service or maintenance, please call the Snow Joe

1-866-SNOWJOE (1-866-766-9563).

+ Sun Joe® customer service center at

Model and Serial Numbers

When contacting the company, reordering parts, or arranging service from an authorized dealer, you will need to provide the model and serial numbers, which can be found on the decal located on the housing of the unit. Copy these numbers into the space provided below.

Record the following numbers from the housing or handle of your new product:

Model #:

S P X 3 0 0 0

Serial #:

Page 15

Troubleshooting

• Disconnect the unit from the electrical power supply before carrying out maintenance on the machine or when checking that

its parts are in proper working order.

• To avoid unnecessary hassles, consult the following table before contacting customer service with any mechanical issues.

Problems Possible Cause Possible Solution

Machine refuses to start

Fluctuating pressure

Machine stops

Fuse blows

• Power failure/machine not

plugged into a working receptacle.

• Defective socket.

• Fuse has blown.

• Defective extension cord.

• Pump sucking air.

• Valves dirty, worn out, or stuck.

• Pump seals worn out.

• Fuse has blown.

• Incorrect mains voltage.

• Thermal sensor activated.

• Nozzle partially blocked.

• Fuse too small.

• Check to make sure machine is plugged into

a working outlet.

• Check the power cord and reset the GFCI. Try a dierent outlet.

• Replace fuse. Switch o any other machines

that are using the same circuit.

• Try the unit without an extension cord.

• Check the hoses and connections are airtight.

• Clean or replace valves/seals.

• Please call the Snow Joe

service center at 1-866-SNOWJOE (1-866-766-9563) for assistance.

• Replace fuse. Switch o other machines using the same circuit.

• Check that the mains voltage corresponds to specication on the model tag.

• Leave the washer for 5 minutes to cool down.

• Clean the nozzle.

• Install a fuse with a higher amp rating than the

amp consumption of the machine. Try the unit without an extension cord.

+ Sun Joe® customer

Machine pulsating

Machine often starts and stops by itself

Machine starts, but no water comes out

• Air in inlet hose.

• Inadequate supply of mains water.

• Nozzle partially blocked.

• Water lter blocked.

• Hose kinked.

• Pump/spray gun is leaking.

• Trigger mechanism is broken.

• Pump/hoses or accessories frozen.

• No water supply.

• Water inlet lter blocked.

• Nozzle blocked.

• Allow machine to run by holding the trigger until regular working pressure resumes.

• Check that the water supply corresponds to the specications required.

• WARNING! Avoid using long, thin hoses

(minimum 1/2 in. diameter).

• Clean the nozzle.

• Clean the water inlet lter.

• Straighten out the hose to remove any kinks/blockages.

• Please call Snow Joe

center at 1-866-SNOWJOE (1-866-766-9563) for assistance.

• Wait for pump/hoses or accessories to thaw.

• Connect inlet water.

• Clean the water inlet lter.

• Clean the nozzle.

+ Sun Joe® customer service

Page 16

Accessories

WARNING! ALWAYS use only authorized Snow Joe

replacement parts or accessories that are not intended for use with this electric pressure washer. Contact Snow Joe

+ Sun Joe® replacement parts and accessories. NEVER use

+ Sun Joe® if you are unsure whether it is safe to use a particular replacement part or accessory with your pressure washer. The use of any other attachment or accessory can be dangerous and could cause injury or mechanical damage.

ModelAccessories Item

SPX3000 Series Spray Tip Set – Fits SPX3000 + SPX3001 Pressure Washer Models

25-Foot Extension Hose for SPX Pressure Washer Series

SPX3000-TPS

SPX-25H

Dual Swivel Brass Connector – 3/4-In. by 3/4-In. Garden Hose to Pipe End

NOTE: Accessories are subject to change without any obligation on the part of Snow Joe

+ Sun Joe® to provide notice of such changes. Accessories can be ordered online at snowjoe.com or via phone by contacting the Snow Joe service center at 1-866-SNOWJOE (1-866-766-9563).

SPX-BSC

+ Sun Joe® customer

Page 17

NOTES

Page 18

NOTES

Page 19

SNOW JOE® + SUN JOE® CUSTOMER PROMISE

ABOVE ALL ELSE, Snow Joe® + Sun Joe® are dedicated to you, our customer. We strive to make your experience

as pleasant as possible. Unfortunately, there are times when a product does not work or breaks under normal operating conditions. We think it’s important that you know what you can expect from us. That’s why we created the Snow Joe® + Sun Joe® promise.

OUR PROMISE: Snow Joe® + Sun Joe® warrant new products for two years from the date of purchase. If your product does not work, or there’s an issue with a specic part, we will x this by either sending you a free replacement part or by sending you a new or comparable product at no charge. How cool is that! Before you know it, you’ll be back in action cutting, sawing, mowing, washing and…?

GENERAL CONDITIONS:

Snow Joe

+ Sun Joe® operating under Snow Joe®, LLC warrants this new product to the original purchaser for two years against defects in material or workmanship when used for normal residential purposes. If a replacement part or product is needed, it will be sent free of charge to the original purchaser except as noted below.

The duration of this warranty applies only if the product is put to personal use around the household. If the product is put to any business, commercial or industrial use or is rented or leased, then the duration of this warranty is 90 days from the date of original purchase. It is the owner’s responsibility to correctly perform all maintenance and minor adjustments explained in the owner’s manual.

HOW TO OBTAIN YOUR REPLACEMENT PART OR PRODUCT:

To obtain a replacement part or product, please visit snowjoe.com/help or email us at help@snowjoe.com for instructions. Please be sure to register your unit beforehand to speed up this process. Certain products may require a serial

number, typically found on the decal axed to the housing

or guard of your product. All products require a valid proof of purchase.

EXCLUSIONS:

• Wearing parts like belts, augers, chains and tines are

not covered under this warranty. Wearing parts can be purchased at snowjoe.com or by calling 1-866-SNOWJOE (1-866-766-9563).

• Batteries are covered in full for 90-days from the date of

purchase.

Snow Joe® + Sun Joe® may from time to time change the design of its products. Nothing contained in this warranty shall be

construed as obligating Snow Joe

+ Sun Joe® to incorporate such design changes into previously manufactured products, nor shall such changes be construed as an admission that previous designs were defective.

This warranty is intended to cover product defects only.

Snow Joe

, LLC is not liable for indirect, incidental or

consequential damages in connection with the use or misuse of

the Snow Joe

+ Sun Joe® products covered by this warranty. This warranty does not cover any cost or expense incurred by the purchaser in providing substitute equipment or service during reasonable periods of malfunction or non-use of this product while waiting for a replacement part or unit under this warranty. Some states do not allow exclusions of incidental or consequential damages so the above exclusions may not apply

in all states. This warranty may give you specic legal rights in

your state.

HOW TO REACH US:

We’re here to help Monday through Friday from 9AM to 6PM EST. You can reach us at 1-866-SNOWJOE (1-866-766-9563), online at snowjoe.com, via email at help@snowjoe.com or tweet us @snowjoe.

EXPORTS:

Customers who have purchased Snow Joe

+ Sun Joe®

products exported from the United States and Canada should

contact their Snow Joe

+ Sun Joe® distributor (dealer) to obtain

information applicable to your country, province or state. If for

any reason, you are not satised with the distributor’s service, or if you have diculty obtaining warranty information, contact

your Snow Joe

+ Sun Joe® seller. If in the event your eorts are

unsatisfactory, please reach out to us directly.

Page 20

snowjoe.com
