SNOWJOE iON16LM-HYB Operator's Manual

CORDLESS + ELECTRIC HYBRID LAWN MOWER

16-INCH | 40V DC MAX* | 120V AC 60HZ 6.5-AMP

Model iON16LM-HYB

A Division of Snow Joe®, LLC

IMPORTANT!

Safety Instructions

All Operators Must Read These
Instructions Before Use

Read all the instructions contained in this manual. Keep this
manual in a safe place, so that the information is available at
all times. If you give the equipment to another person, make
sure to provide these operating instructions. Basic safety
precautions should always be followed to reduce the risk of

re, electric shock and personal injury.

General Safety Rules

Notice the personal safety alert symbol m used in this
manual to draw your attention to a WARNING given along
with the particular operating instruction. This means that
the operation requires special ATTENTION, CAUTION and
AWARENESS.

1. Keep the work area clean and well-lit – Cluttered, dark

areas invite accidents.

2. Keep children, bystanders and pets away – Always
keep children and spectators a safe distance away from
the mower during operation and as the machine cools.
Children must always be supervised to ensure that they
do not play with the equipment.

3. Dress properly – Always wear personal safety gear
(i.e. safety glasses, rubber gloves, protective non-slip
footwear and dust masks) and proper clothing when using

the mower. Loose clothing, long hair or jewelry may get

caught in the moving parts.

4. Use the right appliance – Do not use the lawn mower for
any purposes other than those for which it is intended.

5. Do not force the lawn mower – It will perform better with

less likelihood of personal or mechanical injury if it is used

at the rate for which it is designed.

6. mCAUTION: Sharp blades! – Remove the battery before
carrying out any repair work. The blades will continue to

rotate after the motor is switched o.

7. Stay alert – Always stay alert and watch what you are
doing. Use common sense. Do not operate the lawn

mower when you are tired or under the inuence of

alcohol or drugs. This lawn mower is not designed to be
used by people (including children) with limited physical,
sensory or mental capacities. It should also not be used
by those lacking the proper experience and/or knowledge

Form No. SJ-iON16LM-HYB-880E-M

OPERATOR’S MANUAL

unless they are supervised by a person who is responsible
for their safety or they have received instructions from
such a person on how to safely use the mower.

8. Store idle lawn mower indoors – When not in use, the
lawn mower should be stored indoors in a dry, locked
place out of the reach of children.

9. Maintain the lawn mower with care – Keep cutting
edges sharp and clean to maximize your mower's
performance and ensure operator safety. Keep handles
dry, clean and free from oil and grease.

mWARNING! Turn o the power switch, disconnect the

battery and/or the power cord before adjusting, inspecting,

servicing or cleaning the lawn mower, when changing
accessories or when any other dangerous conditions present
themselves. All maintenance tasks should be performed after
revolving parts inside the lawn mower stop completely. Such
preventive safety measures reduce the risk of starting the

power tool accidentally.

mWARNING! If you notice that the lawn mower is

not running properly or unusual vibrations occur from the
engine when it is in use, immediately stop the machine and
disconnect the battery and/or the power cord. Check the
cutters and clear them if necessary. If the machine continues
to vibrate, contact an authorized Snow Joe® + Sun Joe®

service center at 1-866-SNOWJOE (1-866-766-9563).

10. Moving parts present risks – Keep your face, hair,
clothing, hands and feet away from all moving parts. All
guards and safety attachments must be installed properly

before using the unit. Shut o and disconnect the battery

and/or the power cord before touching any parts other
than the handles and the switch.

11. Cutting/dismemberment hazard of hand – Do not touch
the blades until the battery and the power cord have been
disconnected from the mower and the blades have come
to a complete stop.

12. Avoid unintentional starting – Make sure the safety
switch and the switch bar lever are in the OFF position
before inserting the battery into the unit. Do not carry the
lawn mower with the safety switch and the switch bar
lever engaged.

13. Do not overreach – Maintain proper footing and balance

at all times. Place heels rmly on the ground and tightly

grasp the handle bar. Watch for uneven surfaces and do
not overreach. In case you fall or collide with the lawn
mower, inspect the unit for any damages or cracks.
When stepping backwards, be careful to avoid obstacles
beneath your feet or behind you to avoid falling.

© 2016 by Snow Joe®, LLC
All rights reserved. Original instructions.

SAVE THESE INSTRUCTIONS

1

mWARNING! If the lawn mower strikes any object,

follow these steps:

i) Stop the lawn mower. Remove the battery and/or

disconnect the power cord.

ii) Inspect for damage.

iii) Repair any damage before restarting and operating

the lawn mower.

IMPORTANT!

Safety Instructions for
Walk-Behind Mowers

General Operation

• Read, understand and follow all the safety regulations

and instructions on the machine and in the manual before
starting.

• Only responsible adults who are thoroughly familiar with

the operator controls and the operation of the machine
should be allowed to use the mower.

• Make sure that the mowing area is clear of children, pets
and other bystanders before starting the machine. Stop
the machine if anyone enters the area.

• Do not tip the machine when starting. The machine should
be on level ground and you should have a rm grasp on

the handle when powering ON.

• Disconnect the power supply (i.e. remove the battery and/

or disconnect the power cord):

i) Whenever you leave the machine unattended;

ii) Before releasing a blocked cutter;

iii) Before inspecting, cleaning or performing other

maintenance on the machine;

iv) If a foreign body has been struck;

v) Whenever the machine starts to vibrate oddly.

• Never mow in the direct vicinity of persons – especially
children – or animals.

• Do not operate the machine barefooted or while wearing

sandals. Always wear substantial footwear.

• Check the ground on which the equipment will be used
and remove all objects that could be picked up and
violently ung by the rotary mower blade.

• Before using the mower, visually inspect it to ensure that

the blade, mounting bolts and the entire cutting apparatus
are in proper working order (i.e. not worn or damaged).
To prevent any operating imbalance, replace worn or
damaged blades and mounting bolts as a set only (if
applicable).

Handling

• Only mow in broad daylight or under well-lit conditions.

• Avoid dangerous environments. Do not use the mower in

the rain or on damp/wet grass.

• Always maintain good footing on inclines.

• Only operate the mower at a walking pace.

• Always mow across hills (i.e. never straight up or straight

down).

• Be particularly careful when you change direction on a

slope.

• Do not mow on overly steep inclines.

• Take extra caution when turning the mower around and

when pulling it towards you.

• Switch the mower o, remove the battery and/or

disconnect the power cord, wait until the cutters have
reached a complete standstill when tipping the mower
over, transporting it over surfaces other than grass, and
when moving the mower to and from the area you wish to
mow.

• Never use the lawn mower if the guards (e.g. side­discharge chute deectors, grass-catching devices) are
damaged or not properly tted.

• Use the switch lever carefully as described in the

manufacturer’s instructions. Make sure that your feet are
far enough away from the mower blade when starting and
using the mower!

• The lawn mower should not be tilted when the motor

is switched on unless it has to be raised for starting
purposes. In this case, tilt it as little as absolutely
necessary and only raise the side opposite to that of the
user.

• Do not switch on the mower if you are positioned in front

of the discharge chute.

• Never move your hands or feet toward or under any

rotating parts. Keep clear of the discharge chute opening
at all times.

• Never lift or carry a lawn mower with the engine running.

• Switch o the motor, remove the battery and/or

disconnect the power cord and wait for the rotating blades
to stop completely: before you dislodge any blockages
or clogs in the discharge chute or mower deck; before
carrying out any checks, cleaning, maintenance or other
work on the lawn mower; and immediately after striking a

foreign object. Examine the mower for signs of damage

and carry out any necessary repairs before restarting and
continuing to work with the mower. If the lawn mower

starts to vibrate oddly, immediately switch it o and

inspect it.

• Switch o the mower, remove the battery and/or

disconnect the power cord whenever you leave the
mower.

2

Maintenance + Storage

• Make sure that all nuts, bolts and screws are tightened

securely and that the machine is in safe working condition.

• Allow the mower to cool before you put it into an enclosed

area.

• To avoid the risk of re, keep the motor housing and

ventilation slots clear of grass, leaves, oil and grease.

• Routinely check the grass basket for signs of wear and

impaired functionality.

• For your own safety, have worn or damaged parts

immediately replaced.

• Take care not to jam your ngers between moving blades

and stationary parts of the equipment while you are

adjusting the equipment.

• While you are carrying out maintenance work on the

blades, remember that the blades can still be moved even

if the power source has been switched o.

mWARNING! Some dust and debris created by the

use of the tool could contain chemicals known to the State
of California to cause cancer and birth defects or other
reproductive harm. Some examples of these chemicals are:

• Chemicals in fertilizers

• Compounds in insecticides, herbicides and pesticides

• Arsenic and chromium from chemically treated lumber

Your risk from exposure to these chemicals varies, and
depends on how often you do this type of work. To reduce
your exposure, work in a well-ventilated area and with
approved safety equipment, such as dust masks that are

specially designed to lter out microscopic particles.

Electrical Safety

The appliance plug will t into a polarized extension
cord only one way.

If the appliance plug does not t fully into the extension

cord, reverse the plug. If the plug still does not t, obtain

a correct polarized extension cord. A polarized extension
cord will require the use of a polarized wall outlet. The

extension cord plug will t into the polarized wall outlet
only one way. If the plug does not t fully into the wall
outlet, reverse the plug. If the plug still does not t,
contact a qualied electrician to install the proper wall

outlet. Do not modify the appliance plug, extension cord
receptacle, or extension cord plug in any way.

m WARNING m

Electric shock may cause SEVERE INJURY or
DEATH. Heed these warnings:

• Do not allow any part of the hybrid lawn mower to

make contact with water while it is in operation. If the

appliance becomes wet while turned o, wipe dry

before starting.

• Use only a UL-, CSA-, or ETL-rated extension cord

for outdoor, all-weather use.

• Do not use an extension cord over 100 ft (30 m).

• Do not touch the appliance or its plug with wet hands

or while standing in water. Wearing rubber boots

oers some protection.

EXTENSION CORD CHART

Extension Cord

Length

Wire Gauge (A.W.G.):

Up to 50 ft

(15 m)

16 14

+50 ft - 100 ft

(+15 m - 30 m)

1. Ground fault circuit interrupter (GFCI) protection should
be provided on the circuit(s) or outlet(s) to be used for
the hybrid lawn mower. Receptacles are available having
built-in GFCI protection and may be used for this
measure of safety.

2. To prevent electric shock, use only with an extension cord
suitable for outdoor use, such as SW-A, SOW-A, STW-A,
STOW-A, SJW-A, SJOW-A, SJTW-A, or SJTOW-A.

Before use, check that the extension cord is in good

condition. When using an extension cord, make sure to
use one heavy enough to carry the current to the product.

For lengths up to 50 ft (15 m), a No. 16 AWG (or greater)
extension cord must be used. For lengths more than
50 ft (15 m) and up to 100 ft (30 m), a No. 14 AWG

(or greater) extension cord must be used. An undersized
cord will cause a drop in line voltage resulting in loss of
power and overheating.

3. To reduce the risk of electric shock, this appliance has
a polarized plug (i.e. one blade is wider than the other).
Use this appliance only with a polarized UL-, CSA-, or
ETL-rated extension cord for outdoor, all-weather use.

4. To prevent the appliance cord from disconnecting from the
extension cord during operation, use the on-board cord
restraint hook and/or make a knot with the two cords as
shown in Table 1.

Table 1. Method of Securing Extension Cord

Cord set Appliance cord

(A) Tie cord as shown

(B) Connect plug and receptacle

3

5. Do not abuse the cord. Never pull the lawn mower by the
cord or yank the cord to disconnect it from the receptacle.
Keep the cord away from heat, oil, and sharp edges.

6. Avoid body contact with earthed or grounded surfaces,
such as pipes, radiators, ranges and refrigerators. There is
an increased risk of electric shock if your body is earthed
or grounded.

7. If the supply cord is damaged, it must be replaced by an
electrician or a power tool repairer.

8. If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
electric shock.

9. Have your tool repaired by an electrician or a qualied

service center. This power tool complies with relevant
safety requirements. To avoid danger, electrical appliances

must only be repaired by qualied personnel using original

spare parts; otherwise this may result in considerable

injury to the user.

Double-Insulated Appliances

In a double-insulated appliance, two systems of insulation
are provided instead of grounding. No grounding means is
provided on a double-insulated appliance, nor should a means
for grounding be added to the appliance. Servicing a double­insulated appliance requires extreme care and knowledge

of the system, and should be performed only by qualied

service personnel at an authorized Snow Joe® + Sun Joe®
dealer. Replacement parts for a double-insulated appliance
must be identical to the parts they replace. A double-insulated
appliance is marked with the words “Double Insulation” or
“Double Insulated.” The symbol (square within a square)
may also be marked on the appliance.

DOUBLE-INSULATED: GROUNDING NOT

REQUIRED. WHEN SERVICING, USE ONLY
IDENTICAL REPLACEMENT PARTS.

This hybrid lawn mower is double-insulated, eliminating the
need for a separate grounding system. Use only identical
replacement parts. Read the instructions before servicing
double-insulated appliances. Use this hybrid lawn mower only
as described in this manual.

Battery + Charger Safety
Instructions

We pay a great deal of attention to the design of every battery
pack to ensure that we supply you with batteries that are safe,
durable and have a high energy density. The battery cells have
a wide range of safety devices. Each individual cell is initially
formatted and its electrical characteristic curves are recorded.
This information is then used to manufacture the best possible
battery packs.

Despite all the safety precautions, caution must always be
exercised when handling batteries. The following points must
be obeyed at all times to ensure safe use. Safe use can only
be guaranteed if undamaged cells are used. Incorrect handling
of the battery pack can cause cell damage.

IMPORTANT! Analyses conrm that incorrect use and poor

care of high-performance batteries are the main factors
responsible for personal and/or product damage.

mWARNING! Use only approved replacement batteries;

other batteries may damage the lawn mower and cause it to

malfunction, which can lead to serious personal injury.

mCAUTION! To reduce the risk of injury, charge the

EcoSharp® iBAT40 lithium-ion pack only in its designated

lithium-ion charger, the iCHRG40. Other types of chargers
present risk of re, personal injury and damage. Do not wire

a battery pack to a power supply plug or car cigarette lighter.
Such misuse will permanently disable or damage the battery
pack.

• Avoid dangerous environments – Do not charge the
battery pack in rain, snow or in damp or wet locations.
Do not use the battery pack or charger in the presence of

explosive atmospheres (gaseous fumes, dust or ammable

materials) because sparks may be generated when inserting

or removing the battery pack, which could lead to a re.

• Charge in a well-ventilated area – Do not block the

charger vents. Keep them clear to allow for proper

ventilation. Do not allow smoking or open ames near a

charging battery pack. Vented gases may explode.

NOTE: The safe temperature range for the battery is -4°F

(-20°C) to 113°F (45°C). Do not charge the battery outside

in freezing weather; charge it at room temperature.

• Maintain charger cord – When unplugging the charger, pull
the plug, not the cord, from the receptacle to reduce the
risk of damage to the electrical plug and cord. Never carry
the charger by its cord or yank it by the cord to disconnect
it from the receptacle. Keep the cord away from heat, oil
and sharp edges. Make sure the cord will not be stepped

on, tripped over or subjected to damage or stress when the

charger is in use. Do not use the charger with a damaged
cord or plug. Replace a damaged charger immediately.

• Do not use an extension cord unless it is absolutely
necessary – Using the wrong, damaged or improperly

wired extension cord poses a risk of re and electric shock.

If an extension cord must be used, plug the charger into
a properly wired 16 gauge or larger extension cord with
blades that are the same number, size and shape as the
blades on the charger. Make sure that the extension cord is
in good electrical condition.

• Charger iCHRG40 is rated for 120 volt AC only – The
charger must be plugged into an appropriate receptacle.

• Use only recommended attachments – Use of an
attachment not recommended or sold by the battery
charger or battery pack manufacturer may result in risk of

re, electric shock or personal injury.

4

• Unplug charger when not in use – Make sure to remove

battery packs from unplugged chargers.

mWARNING! To reduce the risk of electric shock,

always unplug the charger before performing any cleaning or

maintenance. Do not allow water to ow into the AC/DC plug.
Use a Ground Fault Circuit Interrupter (GFCI) to reduce shock

hazards.

• Do not burn or incinerate battery packs – Battery packs
may explode, causing personal injury or damage. Toxic

fumes and materials are created when battery packs are
burned.

• Do not crush, drop or damage battery packs – Do not
use the battery pack or charger if they have sustained a
sharp blow, been dropped, run over or have been damaged
in any way (e.g. pierced with a nail, hit with a hammer,
stepped on, etc.).

• Do not disassemble – Incorrect reassembly may pose
a serious risk of electric shock, re or exposure to toxic

battery chemicals. If the battery or charger are damaged,
contact your Snow Joe® + Sun Joe® dealer or Snow Joe®

+ Sun Joe® customer service center at 1-866-SNOWJOE
(1-866-766-9563).

• Battery chemicals cause serious burns – Never let a
damaged battery pack contact the skin, eyes or mouth.
If a damaged battery pack leaks battery chemicals, use
rubber or neoprene gloves to safely dispose of it. If skin

is exposed to battery uids, wash the aected area with

soap and water and rinse with vinegar. If eyes are exposed

to battery chemicals, immediately ush with water for 20

minutes and seek medical attention. Remove and dispose
of contaminated clothing.

• Do not short circuit – A battery pack will short circuit if
a metal object makes a connection between the positive

and negative contacts on the battery pack. Do not place a
battery pack near anything that may cause a short circuit,
such as paper clips, coins, keys, screws, nails and other

metallic objects. A short-circuited battery pack poses a risk
of re and severe personal injury.

• Store your battery pack and charger in a cool, dry

place – Do not store the battery pack or charger where

temperatures may exceed 104ºF (40ºC), such as in direct

sunlight or inside a vehicle or metal building during the
summer.

when its capacity falls to just 80% of its capacity when

new. Weakened cells in an aged battery pack are no
longer capable of meeting the high power requirements
needed for the proper operation of your lawn mower, and
therefore pose a safety risk.

5. Do not throw battery packs into an open re. There is a

risk of explosion!

6. Do not ignite the battery pack or expose it to re.

7. Do not exhaustively discharge batteries. Exhaustive

discharge will damage the battery cells. The most
common cause of exhaustive discharge is lengthy storage
or non-use of partially discharged batteries. Stop working
as soon as the performance of the battery falls noticeably
or the electronic protection system triggers. Place the
battery pack in storage only after it has been fully charged.

8. Protect batteries and the tool from overloads. Overloads
will quickly result in overheating and cell damage inside
the battery housing even if this overheating is not
apparent externally.

9. Avoid damage and shocks. Immediately replace batteries
that have been dropped from a height of more than one
meter or those that have been exposed to violent shocks,
even if the housing of the battery pack appears to be
undamaged. The battery cells inside the battery may have

suered serious damage. In such instances, please read

the waste disposal information for proper battery disposal.

10. If the battery pack suers overloading and overheating,
the integrated protective cuto will switch o the

equipment for safety reasons.

IMPORTANT! Do not press the ON/OFF switch any more

if the protective cut-o has been activated. This may

damage the battery pack.

11. Use only original battery packs. The use of other batteries

poses a re risk and may result in injuries or an explosion.

Information about the battery

1. The battery pack supplied with your hybrid lawn mower is

not charged. The battery pack has to be charged before

you use the tool for the rst time.

2. For optimum battery performance avoid low discharge

cycles. Charge the battery pack frequently.

3. Store the battery pack in a cool place, ideally at 59°F
(15°C) and charged to at least 40%.

4. Lithium-ion batteries are subject to a natural aging

process. The battery pack must be replaced at the latest

5

Information about the charger and the
charging process

1. Please check the data marked on the rating plate of the

battery charger. Be sure to connect the battery charger
to a power supply with the voltage marked on the rating

plate. Never connect it to a dierent mains voltage.

2. Protect the battery charger and its cord from damage.
Keep the charger and its cord away from heat, oil and
sharp edges. Have damaged cords repaired without delay

by a qualied technician at an authorized Snow Joe® +

Sun Joe® service center at 1-866-SNOWJOE
(1-866-766-9563).

3. Electrical plugs must match the outlet. Never modify
the plug in any way. Do not use any adapter plugs with

grounded appliances. Unmodied plugs and matching

outlets will reduce the risk of electric shock.

4. Keep the battery charger, any batteries, and the hybrid
tool out of the reach of children.

5. Do not use the supplied battery charger to charge other
cordless tools.

6. During periods of heavy use, the battery pack will become
warm. Allow the battery pack to cool to room temperature
before inserting it into the charger to recharge.

7. Do not over-charge batteries. Do not exceed the
maximum charging times. These charging times only

apply to discharged batteries. Frequent insertion of a

charged or partially charged battery pack will result in
over-charging and cell damage. Do not leave batteries in
the charger for days on end.

8. Never use or charge batteries if you suspect that it has
been more than 12 months since the last time they were
charged. There is a high probability that the battery pack

has already suered dangerous damage (exhaustive

discharge).

9. Charging batteries at a temperature below 50°F (10°C) will
cause chemical damage to the cells and may cause a re.

10. Do not use batteries that have been exposed to heat
during the charging process, as the battery cells may have

suered dangerous damage.

11. Do not use batteries that have suered curvature or

deformation during the charging process or those that
exhibit other atypical symptoms (gassing, hissing,
cracking, etc.).

12. Never fully discharge the battery pack (maximum

recommended depth of discharge is 80%) A complete

discharge of the battery pack will lead to premature aging
of the battery cells.

Protectionfromenvironmentalinuences

1. Wear suitable work clothes. Wear safety goggles.

2. Protect your hybrid tool and the battery charger from

moisture and rain. Moisture and rain can cause dangerous
cell damage.

3. Do not use the hybrid tool or the battery charger near

vapors and ammable liquids.

4. Use the battery charger and hybrid tools only in dry

conditions and at an ambient temperature of 50-104°F
(10-40°C).

5. Do not keep the battery charger in places where the

temperature is liable to reach over 104°F (40°C). In

particular, do not leave the battery charger in a car that is
parked in the sunshine.

6. Protect batteries from overheating. Overloads, over­charging and exposure to direct sunlight will result in
overheating and cell damage. Never charge or work

with batteries that have been overheated – replace them

immediately, if possible.

7. Store the charger and your hybrid tool only in dry

locations with an ambient temperature of 50-104°F
(10-40°C). Store your lithium-ion battery pack in a cool,
dry place at a temperature of 50-68°F (10-20°C). Protect

the battery pack, charger and hybrid tool from humidity
and direct sunlight. Only place fully charged batteries in

storage (charged to at least 40%).

8. Prevent the lithium-ion battery pack from freezing. Battery

packs that were stored below 32°F (0°C) for more than 60

minutes must be discarded.

9. When handling batteries, be wary of electrostatic
charge. Electrostatic discharges can damage the
electronic protection system and the battery cells. Avoid
electrostatic charging and never touch the battery poles.

6

Safety Symbols

The following table depicts and describes safety symbols that may appear on this product. Read, understand and follow all
instructions on the machine before attempting to assemble and operate.

Symbols SymbolsDescriptions Descriptions

WARNING! To reduce the risk of

injury, user must read instruction

manual.

Safety alert. Caution.

Wear eye and hearing protection.
For protection against injury, wear
ear defenders and safety goggles.

Cutting/dismemberment hazard of
hand. Keep hands away from the
rotating blade.

WARNING! Do not expose the
unit to rain or wet conditions.
Keep dry.

Keep bystanders and children a safe
distance away.

Severing of toes or ngers by

rotary mower blade.

Slip on slope hazard – Use extra

caution when mowing on slopes to
prevent slip and fall accidents.

WARNING! Always turn the machine

OFF and remove the safety key

before conducting inspection,
cleaning and maintenance.

The rotating part will continuously
run for several seconds after you

turn o the machine.

Looking behind while backing.

CAUTION! Objects picked up

and thrown by the rotating blade

can cause severe injury.

Indoor use only. Only use battery
charger indoors.

Double Insulation.

7

Know Your Hybrid Lawn Mower

Read the owner’s manual and safety rules carefully before operating the lawn mower. Compare the illustration below
to the actual unit in order to familiarize yourself with the location of the various controls and adjustments. Save this
manual for future reference.

1. Switch bar lever

2. AC safety lock button

3. Extension cord restraint holder

4. Switch box

5. DC safety lock button

6. Upper handle

7. Appliance cord

8. Lower handle

9. Upper handle knobs and bolts (2)

10. Grass indicator window

11. AC slot

12. DC slot

13. Safety key

14. Slot cover

15. Battery cover

16. Battery compartment

17. Battery cover locking button

18. Front wheel (2)

19. Mower body

20. Rear wheel (2)

29

21. Cutting height

adjustment lever

22. Multi-position height

adjustment quick lock
wheel (2)

23. Grass collection bag

24. Ejector ap

25. Push button for battery indicator

26. Battery indicator

27. Push lock button

28. EcoSharp® battery charger

(iCHRG40)

29. EcoSharp® lithium-ion battery

(iBAT40)

11 12

13

25

26

27

2

14

15

16

17

10

1

4

6

9

19

18

3

5

7

8

24

23

22

21

20

Technical Data

Rated Voltage 120 V ~ 60 Hz (6.5 A)

Battery Voltage* 40 V D.C.

Battery Capacity 4.0 Ah

Charging Time 2.5 – 3 hours (for full charge)

Battery Run Time (Max) 25 min (max runtime under load)
78 min (max runtime no load)

No Load Speed AC: 3,800 rpm
DC: 2,900 rpm

Steel Blade 15 in. (38 cm)

Deck Size 16 in. (41 cm)

*Initial no-load voltage, when fully charged, peaks at 40 volts; nominal voltage under typical load is 36 volts.

28

Motor 780 W magnet motor

Cutting Height 1.18 in. to 3.15 in.

(30 mm to 80 mm)

Grass Bag Capacity 9.25 gal (35 l)

Wheel Size 6 in. (15.2 cm) front

8 in. (20.3 cm) rear

Weight (Mower Alone) 39.7 lbs (18 kg)

Weight 42 lbs (19.1 kg)
(Mower With Battery Installed)

Weight 43.2 lbs (19.6 kg)
(Mower + Battery + Charger)

8
