© 2015 by Snow Joe®, LLC
All rights reserved. Original instructions.
A Division of Snow Joe®, LLC
Model iON13SS-HYB
OPERATOR’S MANUAL
SAVE THESE INSTRUCTIONS
CORDLESS + ELECTRIC HYBRID SNOW SHOVEL
13-INCH | 40 V MAX* | 15-AMP
Form No. SJ-iON13SS-HYB-880E-M
IMPORTANT!
Safety Instructions
All Operators Must Read These
Instructions Before Use
Read all instructions before using this hybrid snow shovel.
Basic safety precautions should always be followed to reduce
the risk of re, electric shock, and personal injury.
General Safety WARNINGS!
You and any other operator of this hybrid snow shovel must
read, understand, and follow these instructions in their entirety,
and should reread them at the start of each snow season.
Failure to follow these instructions may result in ELECTRIC
SHOCK, FIRE, and/or serious PERSONAL INJURY.
Notice the personal safety alert symbol m used in this
manual to draw your attention to a WARNING given along
with the particular operating instruction. This means that
the operation requires special ATTENTION, CAUTION, and
AWARENESS.
1. Keep work area clean and well lit – Cluttered, dark areas
invite accidents.
2. Use the right product – Do not use this machine for any
job except that for which it is intended.
3. Replacement parts – When servicing this unit, use only
identical replacement parts. If the charger becomes
damaged, discontinue use and repair or replace it
immediately.
Do not use on gravel surfaces unless the snow shovel
is adjusted for such surfaces in accordance with the
operator’s manual.
4. Keep children, bystanders, and pets away – All
spectators, including pets, should be kept a safe distance
away from the work area.
5. Dress properly – Do not wear loose articles of clothing or
jewelry. They can become caught in moving parts. Wear
rubber boots.
6. Avoid accidental starting – Make sure the safety
switch and the trigger switch are in the o position
before inserting the battery or connecting the power
cable to the unit. Do not carry or transport the hybrid
snow shovel with the safety switch and the trigger switch
engaged.
7. Moving parts – Keep hands and feet away from moving
parts. Keep guards in place and in proper working order.
8. mCAUTION! Exercise caution to avoid slipping or falling.
Wear protective footwear that will protect your feet and
improve your footing on slippery surfaces.
9. Use safety glasses – Also use safety footwear, snugtting clothing, protective gloves, and hearing and head
protection.
10. Stay alert – Watch what you are doing. Use common
sense. Do not operate the hybrid snow shovel when you
are tired or under the inuence of alcohol or drugs.
11. Do not force the tool – It will perform better with less
likelihood of personal or mechanical injury if it is used at
the rate for which it was designed.
12. Do not overreach – Keep proper footing and balance at
all times.
13. If the hybrid snow shovel strikes a foreign object, follow
these steps:
• Stop the hybrid snow shovel. Remove the battery or
disconnect the power cord.
• Inspect for damage.
• Repair any damage before restarting and operating
the hybrid snow shovel.
14. Disconnect the tool – Turn o the power switch, remove
the battery or disconnect the power cord when it is not in
use, before servicing it, when changing accessories, and
when performing any other maintenance task.
15. Store idle tool indoors – When not in use, the hybrid
snow shovel should be stored indoors in a dry, locked
place out of the reach of children.
16. Maintain the hybrid snow shovel with care – Follow the
applicable maintenance instructions for replacing parts
and changing accessories. Lubrication is not required.
mThis is the safety alert symbol. It is used to alert
you to potential personal injury hazards. Obey all
safety messages that follow this symbol to avoid
possible injury or death.
Improperly using or maintaining this hybrid snow
shovel could result in injury or death. To reduce
this potential, comply with the following safety
instructions.
This hybrid snow shovel can amputate hands and feet
if used incorrectly. It can also pick up foreign objects,
which can become dangerous projectiles when thrown
into the air. Failure to observe the following safety
instructions could result in serious personal injury.
1
Training
• Read, understand, and follow all instructions on the
machine and in the manual before operating this unit.
Thoroughly familiarize yourself with the controls and the
proper use of the equipment. Know how to stop the unit
and disengage the controls quickly.
• Children should never be allowed access to the equipment.
Adults should never operate the equipment without
carefully reading and understanding these instructions.
• Keep the area of operation clear of all persons, particularly
small children and pets.
• Exercise caution to avoid slipping or falling.
Preparation
• Thoroughly inspect the area where the equipment is to be
used and remove all doormats, sleds, boards, wires, and
other foreign objects.
• Do not operate the equipment without wearing adequate
winter garments. Avoid loose tting articles of clothing that
can become caught in moving parts. Wear footwear that will
improve footing on slippery surfaces.
• Do not attempt to clear snow from a gravel or crushed
rock surface. This product is intended for use only on
paved surfaces.
• Never attempt to make any adjustments while the motor
is running (except when specically recommended by the
manufacturer).
• Always wear safety glasses or eye shields during operation
or while performing an adjustment or repair to protect your
eyes from foreign objects that may be thrown from the
machine.
Operation
• Do not put hands or feet near or under rotating parts. Keep
clear of the discharge opening at all times.
• Exercise extreme caution when operating on or crossing
gravel drives, walks, or roads. Stay alert for hidden hazards
or trac.
• After striking a foreign object, stop the motor. Thoroughly
inspect the hybrid snow shovel for any damage, and repair
the damage before restarting and operating the hybrid
snow shovel.
• If the unit should start to vibrate abnormally, stop the motor
and check the unit immediately to ascertain the cause.
Vibration is generally a sign of trouble.
• Stop the motor, remove the battery or disconnect the power
cord whenever you leave the operating position, when
transporting the unit, before unclogging the rotor blade
housing, and when making any repairs, adjustments, or
inspections to the unit.
• When cleaning, repairing, or inspecting the hybrid snow
shovel, make sure that all moving parts have come to a
complete stop before beginning work.
• Exercise extreme caution when operating on slopes.
• Never operate the hybrid snow shovel without proper
guards and other safety devices in place and in proper
working order.
• Never direct the discharge toward people or areas where
property damage can occur. Keep children, pets, and other
bystanders away from the work area.
• Do not overload the machine capacity by attempting to
clear snow at too fast a rate.
• Look behind and use care when backing up with the
hybrid snow shovel.
• Never operate the hybrid snow shovel without good
visibility or light. Always be sure of your footing, and keep
a rm hold on the handles. Walk, never run, with the unit.
Clearing a Clogged Rotor Housing
Hand contact with the rotating rotor blades inside the rotor
housing is the most common cause of injury associated
with hybrid snow shovels. Never use your hands to clear a
clogged rotor housing.
To clear the rotor housing:
• Shut the motor o, remove the battery or disconnect the
power cord.
• Wait 10 seconds to be sure the rotor blades have come to a
complete stop.
• Always use a clean-out tool, not your hands, to free the
rotating blades.
Maintenance and Storage
• Check all fasteners at frequent intervals for proper tightness
to ensure that the equipment is in safe working condition.
• Always refer to the operator's manual for important details,
such as how to properly store your hybrid snow shovel for
an extended period of time.
• Maintain or replace safety and instruction labels as needed.
• Run the machine a few minutes after throwing snow to
prevent the rotor blades from freezing.
Double-Insulated Appliances
In a double-insulated appliance, two systems of insulation
are provided instead of grounding. No grounding means is
provided on a double-insulated appliance, nor should a means
for grounding be added to the appliance. Servicing a doubleinsulated appliance requires extreme care and knowledge
of the system, and should be performed only by qualied
service personnel at an authorized Snow Joe® + Sun Joe®
dealer. Replacement parts for a double-insulated appliance
must be identical to the parts they replace. A double-insulated
appliance is marked with the words “Double Insulation” or
“Double Insulated.” The symbol (square within a square)
may also be marked on the appliance.
DOUBLE-INSULATED: GROUNDING NOT
REQUIRED. WHEN SERVICING, USE ONLY
IDENTICAL REPLACEMENT PARTS.
2
This hybrid snow shovel is double-insulated, eliminating the
need for a separate grounding system. Use only identical
replacement parts. Read the instructions before servicing
double-insulated appliances. Use this hybrid snow shovel only
as described in this manual.
Safety WARNINGS!
When Using Electric Mode
• Electrical plugs must match the outlet. Never modify
the plug in any way. Do not use any adapter plugs with
grounded appliances. Unmodied plugs and matching
outlets will reduce the risk of electric shock.
• Avoid body contact with earthed or grounded surfaces
(i.e. upper and lower water pipes, radiators, ranges,
refrigerators, microwave ovens, and outer frames of heating
equipment). Take necessary precautions to avoid electric
shock. There is an increased risk of electric shock if your
body is earthed or grounded.
• Do not abuse the cord. Keep the cord away from heat, oil,
sharp edges, or moving parts. Never carry the hybrid snow
shovel by its cord or yank the cord to disconnect it from the
electrical outlet. Damaged or entangled cords increase the
risk of electric shock.
• Replace or properly repair damaged cords. If the cord
becomes damaged in any manner while plugged into the
wall receptacle, immediately unplug the extension cord plug
from the receptacle.
• Contact with water while operating the snow shovel
can result in electric shock and serious bodily injury. Do
not use the hybrid snow shovel in damp or wet locations or
expose to rain. Do not handle the plug or the appliance with
wet hands or while standing in water.
• mWARNING – Use outdoor extension cords marked
SW-A, SOW-A, STW-A, STOW-A, SJW-A, SJTW-A, or
SJTOWA. These cords are rated for outdoor use and
reduce the risk of electric shock.
• Ifyoundthemainpowercableortheextensioncable
damaged, immediately unplug the cable from the socket
and disconnect the power immediately. Repair the cable
or replace it if necessary.
• Do not move or transport the snow shovel when either
the plug or battery are connected and the switch is
turned on.
Battery + Charger
Safety Instructions
We pay a great deal of attention to the design of every battery
pack to ensure that we supply you with batteries that are safe,
durable and have a high energy density. The battery cells have
a wide range of safety devices. Each individual cell is initially
formatted and its electrical characteristic curves are recorded.
This data is then used exclusively to be able to assemble the
best possible battery packs.
Despite all the safety precautions, caution must always be
exercised when handling batteries. The following points must
be obeyed at all times to ensure safe use. Safe use can only
be guaranteed if undamaged cells are used. Incorrect handling
of the battery pack can cause cell damage.
IMPORTANT! Analyses conrm that incorrect use and poor
care of high-performance batteries are the main factors
responsible for personal and/or product damage.
mWARNING! Use only approved replacement batteries;
other batteries may damage the hybrid snow shovel and cause
it to malfunction, which can lead to serious personal injury.
mCAUTION! To reduce the risk of injury, charge the
EcoSharp® iBAT40 lithium-ion battery pack only in its
designated lithium-ion charger, the iCHRG40. Other types of
chargers present risk of re, personal injury and damage. Do
not wire a battery pack to a power supply plug or car cigarette
lighter. Such misuse will permanently disable or damage the
battery pack.
• Avoid dangerous environments – Do not charge the
battery pack in rain, snow or in damp or wet locations.
Do not use the battery pack or charger in the presence of
explosive atmospheres (gaseous fumes, dust or ammable
materials) because sparks may be generated when inserting
or removing the battery pack, which could lead to a re.
• Charge in a well-ventilated area – Do not block the
charger vents. Keep them clear to allow for proper
ventilation. Do not allow smoking or open ames near a
charging battery pack. Vented gases may explode.
NOTE: The safe temperature range for the battery is -4°F
(-20°C) to 113°F (45°C). Do not charge the battery outside
in freezing weather; charge it at room temperature.
• Maintain charger cord – When unplugging the charger, pull
the plug, not the cord, from the receptacle to reduce the
risk of damage to the electrical plug and cord. Never carry
the charger by its cord or yank it by the cord to disconnect
it from the receptacle. Keep the cord away from heat, oil
and sharp edges. Make sure the cord will not be stepped
on, tripped over or subjected to damage or stress when the
charger is in use. Do not use the charger with a damaged
cord or plug. Replace a damaged charger immediately.
• Do not use an extension cord unless it is absolutely
necessary – Using the wrong, damaged or improperly
wired extension cord poses a risk of re and electric shock.
If an extension cord must be used, plug the charger into a
properly wired 50-foot 14 gauge (or thicker) extension cord
with the female plug matching the male plug on the charger.
Make sure that the extension cord is in good electrical
condition.
• Charger iCHRG40 is rated for 120 volt AC only – The
charger must be plugged into an appropriate receptacle.
• Use only recommended attachments – Use of an
attachment not recommended or sold by the battery
charger or battery pack manufacturer may result in risk of
re, electric shock or personal injury.
3
• Unplug charger when not in use – Make sure to remove
battery packs from unplugged chargers.
mWARNING! To reduce the risk of electric shock,
always unplug the charger before performing any cleaning
or maintenance. Do not allow water to ow into the charger.
Use a Ground Fault Circuit Interrupter (GFCI) to reduce shock
hazards.
• Do not burn or incinerate battery packs – Battery packs
may explode, causing personal injury or damage. Toxic
fumes and materials are created when battery packs are
burned.
• Do not crush, drop, or damage battery packs – Do not
use the battery pack or charger if they have sustained a
sharp blow, been dropped, run over, or have been damaged
in any way (i.e. pierced with a nail, hit with a hammer,
stepped on, etc.).
• Do not disassemble – Incorrect reassembly may pose
a serious risk of electric shock, re, or exposure to toxic
battery chemicals. If the battery or charger are damaged,
contact an authorized Snow Joe® + Sun Joe® dealer or
call the Snow Joe® + Sun Joe® customer service center at
1-866-SNOWJOE (1-866-766-9563) for assistance.
• Battery chemicals cause serious burns – Never let a
damaged battery pack contact the skin, eyes, or mouth.
If a damaged battery pack leaks battery chemicals, use
rubber or neoprene gloves to safely dispose of it. If skin
is exposed to battery uids, wash the aected area with
soap and water and rinse with vinegar. If eyes are exposed
to battery chemicals, immediately ush with water for 20
minutes and seek medical attention. Remove and dispose
of contaminated clothing.
• Do not short circuit – A battery pack will short circuit if
a metal object makes a connection between the positive
and negative contacts on the battery pack. Do not place a
battery pack near anything that may cause a short circuit,
such as paper clips, coins, keys, screws, nails, and other
metallic objects. A short-circuited battery pack poses a risk
of re and severe personal injury.
• Store your battery pack and charger in a cool, dry
place – Do not store the battery pack or charger where
temperatures may exceed 104ºF (40ºC), such as in direct
sunlight or inside a vehicle or metal building during the
summer.
process. The battery pack must be replaced at the latest
when its capacity falls to just 80% of its capacity when
new. Weakened cells in an aged battery pack are no
longer capable of meeting the high power requirements
needed for the proper operation of your hybrid snow
shovel, and therefore pose a safety risk.
5. Do not throw battery packs into an open re as this poses
a risk of explosion.
6. Do not ignite the battery pack or expose it to re.
7. Do not exhaustively discharge batteries. Exhaustive
discharge will damage the battery cells. The most
common cause of exhaustive discharge is lengthy storage
or non-use of partially discharged batteries. Stop working
as soon as the performance of the battery falls noticeably
or the electronic protection system triggers. Place the
battery pack in storage only after it has been fully charged.
8. Protect batteries and the tool from overloads. Overloads
will quickly result in overheating and cell damage inside
the battery housing even if this overheating is not
apparent externally.
9. Avoid damage and shocks. Immediately replace batteries
that have been dropped from a height of more than one
meter or those that have been exposed to violent shocks,
even if the housing of the battery pack appears to be
undamaged. The battery cells inside the battery may have
suered serious damage. In such instances, please read
the waste disposal information for proper battery disposal.
10. If the battery pack suers overloading and overheating,
the integrated protective cuto will switch o the
equipment for safety reasons.
IMPORTANT! Do not press the ON/OFF switch any more
if the protective cut-o has been activated. This may
damage the battery pack.
11. Use only original battery packs. The use of other batteries
poses a re risk and may result in injuries or an explosion.
Information about the battery
1. The battery pack supplied with your hybrid snow shovel is
only partially charged. The battery pack has to be charged
completely before you use the tool for the rst time.
2. For optimum battery performance, avoid low discharge
cycles by charging the battery pack frequently.
3. Store the battery pack in a cool place, ideally at 59°F
(15°C) and charged to at least 40%.
4. Lithium-ion batteries are subject to a natural aging
4
Information about the charger and the
charging process
1. Please check the data marked on the rating plate of the
battery charger. Be sure to connect the battery charger
to a power supply with the voltage marked on the rating
plate. Never connect it to a dierent mains voltage.
2. Protect the battery charger and its cord from damage.
Keep the charger and its cord away from heat, oil, and
sharp edges. Have damaged cords repaired without delay
by a qualied technician at an authorized Snow Joe® +
Sun Joe® dealer or call the Snow Joe® + Sun Joe®
customer service center at 1-866-SNOWJOE
(1-866-766-9563).
3. Electrical plugs must match the outlet. Never modify
the plug in any way. Do not use any adapter plugs with
grounded appliances. Unmodied plugs and matching
outlets will reduce the risk of electric shock.
4. Keep the battery charger, battery pack(s), and the hybrid
tool out of the reach of children.
5. Do not use the supplied battery charger to charge other
cordless tools.
6. During periods of heavy use, the battery pack will become
warm. Allow the battery pack to cool to room temperature
before inserting it into the charger to recharge.
7. Do not overcharge batteries. Do not exceed the maximum
charging times. These charging times only apply to
discharged batteries. Frequent insertion of a charged or
partially charged battery pack will result in overcharging
and cell damage. Do not leave batteries in the charger for
days on end.
8. Never use or charge batteries if you suspect that it has
been more than 12 months since the last time they were
charged. There is a high probability that the battery pack
has already suered dangerous damage (exhaustive
discharge).
9. Charging batteries at a temperature below 50°F (10°C) will
cause chemical damage to the cells and may cause a re.
10. Do not use batteries that have been exposed to heat
during the charging process, as the battery cells may have
suered dangerous damage.
11. Do not use batteries that have suered curvature or
deformation during the charging process or those that
exhibit other atypical symptoms (gassing, hissing,
cracking, etc.)
12. Never fully discharge the battery pack (maximum
recommended depth of discharge is 80%). A complete
discharge of the battery pack will lead to premature aging
of the battery cells.
Protection from environmental infuences
1. Wear suitable work clothes. Wear safety goggles.
2. Protect your hybrid tool and the battery charger from
moisture and rain. Moisture and rain can cause dangerous
cell damage.
3. Do not use the hybrid tool or the battery charger near
vapors and ammable liquids.
4. Use the battery charger and the hybrid tool only in dry
conditions and at an ambient temperature of 50-104°F
(10-40°C).
5. Do not keep the battery charger in places where the
temperature is liable to reach over 104°F (40°C). In
particular, do not leave the battery charger in a car that is
parked in the sunshine.
6. Protect batteries from overheating. Overloads,
overcharging, and exposure to direct sunlight will result
in overheating and cell damage. Never charge or work
with batteries that have been overheated – replace them
immediately, if possible.
7. Store the charger and your hybrid tool only in dry locations
with an ambient temperature of 50-104°F (10-40°C).
Store your lithium-ion battery pack in a cool, dry place at
a temperature of 50-68°F (10-20°C). Protect the battery
pack, charger, and hybrid tool from humidity and direct
sunlight. Only place fully charged batteries in storage
(charged to at least 40%).
8. Prevent the lithium-ion battery pack from freezing. Battery
packs that were stored below 32°F (0°C) for more than 60
minutes must be discarded.
9. When handling batteries, be wary of electrostatic charge.
Electrostatic discharges can damage the electronic
protection system and the battery cells. Avoid electrostatic
charging and never touch the battery poles.
Electrical Safety
1. Ground fault circuit interrupter (GFCI) protection should
be provided on the circuit(s) or outlet(s) to be used for
the hybrid snow shovel. Receptacles are available having
built-in GFCI protection and may be used for this
measure of safety.
2. To prevent electric shock, use only with an extension cord
suitable for outdoor use, such as SW-A, SOW-A, STW-A,
STOW-A, SJW-A, SJOW-A, SJTW-A, or SJTOW-A.
Before use, check that the extension cord is in good
condition. When using an extension cord, make sure to
use one heavy enough to carry the current your product
will draw. For lengths less than 50 ft (15 m), a No.14 AWG
(or greater) extension cord should be used. An undersized
cord will cause a drop in line voltage resulting in loss of
power and overheating.
3. To reduce the risk of electric shock, this appliance has
a polarized plug (i.e. one blade is wider than the other).
Use this appliance only with a polarized UL-, CSA-, or
ETL-rated extension cord for outdoor, all-weather use.
The appliance plug will t into a polarized extension
cord only one way.
5
If the appliance plug does not t fully into the extension
cord, reverse the plug. If the plug still does not t, obtain
a correct polarized extension cord. A polarized extension
cord will require the use of a polarized wall outlet. The
extension cord plug will t into the polarized wall outlet
only one way. If the plug does not t fully into the wall
outlet, reverse the plug. If the plug still does not t, contact
a qualied electrician to install the proper wall outlet. Do
not modify the appliance plug, extension cord receptacle,
or extension cord plug in any way.
m WARNING! m
Electric shock may cause SEVERE INJURY or
DEATH. Heed these warnings:
• Do not allow any part of the hybrid snow shovel to
make contact with water while it is in operation. If the
appliance becomes wet while turned o, wipe dry
before starting.
• Use only a UL-, CSA-, or ETL-rated extension cord
for outdoor, all-weather use, such as the Snow Joe
+ Sun Joe
extension cord with lighted end (Model PJEXT50-B).
Visit snowjoe.com to purchase this extension cord
online or, to order by phone, call 1-866-SNOWJOE
(1-866-766-9563).
• Do not use an extension cord over 100 ft (30 m).
• Do not touch the appliance or its plug with wet hands
or while standing in water. Wearing rubber boots
oers some protection.
®
Power Joe SJTW-A 14-gauge 50-foot
®
5. Do not abuse the cord. Never pull the snow shovel by the
cord or yank the cord to disconnect it from the receptacle.
Keep the cord away from heat, oil, and sharp edges.
EXTENSION CORD CHART
Cord Length:
Min. Wire Gauge (A.W.G.):
4. To prevent the appliance cord from disconnecting from the
extension cord during operation, use the on-board cord
restraint hook and/or make a knot with the two cords as
shown in Table 1.
Table 1. Method of Securing Extension Cord
Cord set Appliance cord
(A) Tie cord as shown
(B) Connect plug and receptacle
50 ft (15 m)14100 ft (30 m)
12
6
Safety Symbols
The following table depicts and describes safety symbols that may appear on this product. Read, understand, and follow all
instructions on the machine before attempting to assemble and operate.
Symbols SymbolsDescriptions Descriptions
READ THE OPERATOR'S
MANUAL(S) – Read, understand,
and follow all instructions in the
user manual(s) before attempting
to assemble and operate.
WARNING! Do not expose the
unit to rain or wet conditions.
Keep dry.
SAFETY ALERT – Indicates a
precaution, a warning, or a danger.
Wear hearing protection.
Wear eye protection.
Wear breathing protection.
Wear protective gloves and
non-slip footwear when using
the machine and handling
debris.
Do not use hands to unclog chute.
DANGER! Cutting/dismemberment
hazard - Keep feet away from the
rotating auger.
CAUTION! Beware of stones and
other foreign objects that could
be thrown from the appliance.
Keep hands, feet, and clothing
away from the rotating auger to
avoid injury.
DANGER! Cutting/dismemberment
hazard - Keep hands away from the
rotating auger. Do not use hands to
unclog rotor housing. Stop motor
before removing debris.
Keep bystanders and children a
safe distance (at least 11 yd/10 m)
away from the work area.
Double Insulation.
The rotating part will continuously
run for several seconds after you
turn o the machine.
Indoor use only. Only use battery
charger indoors.
7
Know Your Hybrid Snow Shovel
Read the owner’s manual and safety rules carefully before operating your hybrid snow shovel. Compare the illustration
below to the actual unit in order to familiarize yourself with the location of the various controls and adjustments. Save this
manual for future reference.
1
1. Appliance cord
2. Extension cord restraint hook
3. Battery compartment
4. Upper handle
5. Safety lock switch
6. ON/OFF trigger switch
7 Adjustable handle
8. Handle knob
9. Upper tube
10. Joint-xing knob and bolt
11. Lower tube
12. Motor housing
13. High-impact/low-temperature-resistant paddle auger
14. Scraper blade
15. Push button for battery indicator
16. Battery indicator
17. Push lock button
18. EcoSharp® lithium-ion battery (iBAT40)
19. EcoSharp® battery charger (iCHRG40)
2
6
8
15
3
4
5
7
9
10
11
16
12
18
19
17
13
Technical Data
Rated Voltage 120 V ~ 60 Hz (5 A)
Battery Voltage* 40 V D.C.
Electric Power 15 A
Battery Capaciy 4.0 Ah
Charging Time 2.5 – 3 hours (for full charge)
Battery Run Time (Max) 52 mins
No Load Speed 1,500 ± 10% rpm
Rotor High-impact/low-temperature-
resistant paddle auger
*Initial no-load voltage, when fully charged, peaks at 40 volts; nominal voltage under typical load is 36 volts.
Motor Brushless
Clearing Width 13 in. (33 cm)
Depth of Snow Cut 6 in. (15 cm)
Throw Distance (Max) 25 ft. (7.6 m)
Plowing Capacity (Max) 300 lbs/min (136 kg/min)
Weight (snow shovel alone) 14.77 lbs (6.7 kg)
Weight
(snow shovel with battery installed)
8
14
17.4 lbs (7.9 kg)
Unpacking
2. Slide the upper tube inside the lower tube and align the
screw holes (Fig. 2).
Carton Contents
• Hybrid snow shovel
• 40 V EcoSharp® battery
• EcoSharp® battery charger
• Adjustable handle, bolt, and knob
• Joint-xing knob and bolt
• Manual with registration card
1. Carefully remove the hybrid snow shovel and check to see
that all of the above items are supplied.
2. Inspect the product carefully to make sure no breakage or
damage occurred during shipping. If you nd damaged or
missing parts, DO NOT return the unit to the store. Please
call the Snow Joe® + Sun Joe® customer service center at
1-866-SNOWJOE (1-866-766-9563).
NOTE: Do not discard the shipping carton and packaging
material until you are ready to use your new hybrid snow
shovel. The packaging is made of recyclable materials.
Properly dispose of these materials in accordance with
local regulations.
IMPORTANT! The equipment and packaging material are
not toys. Do not let children play with plastic bags, foils,
or small parts. These items can be swallowed and pose a
suocation risk!
Fig. 2
Upper tube
Lower tube
3. Insert the joint-xing bolt through the aligned holes in the
upper and lower tubes and secure the other end with the
joint-xing knob (Figs. 3 & 4).
NOTE: You may have to carefully move the wiring inside
the tube to one side if it blocks the path of the bolt. (Use
the shipping wire or the joint-xing bolt to maneuver the
electrical wiring; do not use a sharp tool.)
Fig. 3
Assembly
Connecting the Upper and Lower Tubes
1. Before connecting the upper and lower tubes, rst install
the adjustable handle by removing the knob and bolt from
the adjustable handle and sliding the adjustable handle
onto the upper tube at the middle section (Fig. 1). Reinstall
the handle knob and bolt onto the adjustable handle
(Fig. 6).
NOTE: Do not try to install the adjustable handle after the
tubes are assembled.
Fig. 1
Upper
tube
Middle
section
Lower tube
Adjustable
handle
Joint-xingbolt
Joint-xingknob
Fig. 4
Joint-xingbolt
Joint-xingknob
9
Positioning the Adjustable Handle
1. Loosen the handle knob.
2. Move and rotate the adjustable handle to a comfortable
working position (Fig. 5).
Light IndicatorsLights
Fig. 5
Adjustable
handle
3. Tighten the handle knob (Fig. 6).
Fig. 6
Charge level button
The battery is at 30% capacity
and requires charging
The battery is at 60% capacity
and requires charging soon
The battery is at full capacity
NOTE: If the charge level button does not appear to be
working, place the battery pack on the charger and charge as
needed.
NOTE: Immediately after using the battery pack, the charge
level button may display a lower charge than it will if checked
a few minutes later. The battery cells “recover” some of their
charge after resting.
Charger Operation
mWARNING! Charge only EcoSharp
battery packs in compatible EcoSharp® iCHRG40 lithium-ion
battery chargers. Other types of batteries may cause personal
injury and damage.
To reduce the risk of electric shock, do not allow water to ow
into the charger's AC/DC plug.
®
iBAT40 lithium-ion
Handle knob
Battery Pack Operation
The equipment can be powered by a lithium-ion battery. The
battery pack is completely sealed and maintenance free.
Battery Charge Level Indicator
The battery pack is equipped with a push button for checking
the charge level. Simply press the push button to read o the
battery charge level from the LEDs of the battery indicator:
• All 3 level monitoring LEDs are lit: Battery charge level
is high.
• 2 level monitoring LEDs are lit: Battery charge level is
decreasing. Stop work, or plug in the power cord as soon
as possible.
• 1 level monitoring LED is lit: Battery is at. Stop work,
or plug in the power cord IMMEDIATELY and charge the
battery. Otherwise the battery’s service life will be greatly
shortened.
When to Charge the EcoSharp® iBAT40
Lithium-Ion Battery
NOTE: The EcoSharp® iBAT40 lithium-ion battery packs do
not develop a "memory" when charged after only a partial
discharge. Therefore, it is not necessary to run down the
battery pack before placing it into the charger.
• Use the battery charge indicator lights to determine when to
charge your EcoSharp® iBAT40 lithium-ion battery pack.
• You can "top-o" your battery pack's charge before starting
a big job or after a long day of use.
10
Charging the Battery
1. Pull the push lock button on the battery to pull the battery
pack up and out of the equipment (Fig. 7).
Fig. 7
Push lock
button
2. Check that the mains voltage is the same as that marked
on the rating plate of the battery charger. Then, insert the
charger's plug into the electrical wall outlet. When you
plug in the charger, the top green light will illuminate and
stay green (Fig. 8).
4. When the bottom light turns green, the battery is fully
charged (Fig. 9).
Fig. 9
green
green
Charging
green
red
Fully charged
Fig. 8
green
Power on
3. Place the battery pack into the charger by sliding the
pack as shown to lock it into position. When you insert
the battery into the charger, the bottom red light will
illuminate to indicate that the battery is charging (Fig. 9).
NOTE: If the top light remains green while the bottom light
alternately ashes red and green, this indicates a temperature
abnormality (i.e. that the battery pack is either too hot or too
cold). If there is only a red blinking light, this indicates that
something is wrong with the battery. Contact Snow Joe® +
Sun Joe® customer service center at 1-866-SNOW-JOE
(1-866-766-9563) for assistance.
Green
Flashing red/green
Temperature abnormal
5. A fully discharged pack with an internal temperature
in the normal range will fully charge in 2.5 to 3 hours
(between 32ºF/0ºC and 113ºF/45ºC). Heavily cycled
battery packs may take longer to charge completely.
6. If the charging light indicator alternately blinks red and
green or the light indicator does not come on at all, check
that the battery pack is fully seated into the bay. Remove
the pack and reinsert. If the problem persists, contact the
Snow Joe® + Sun Joe® customer service center at
1-866-SNOWJOE (1-866-766-9563) for assistance.
Flashing red only
Something is wrong
11
7. When charging is complete, remove the battery from the
charger by pulling the push lock button and sliding the
battery backward to unlock it from the charger (Fig. 10).
Fig. 10
Push lock button
8. Timely recharging of the battery will help prolong the
battery's life. You must recharge the battery pack when
you notice a drop in the equipment's power.
IMPORTANT! Never allow the battery pack to become fully
discharged as this will cause irreversible damage to the
battery.
• IftheunithasthepowercordconnectedWITHOUTthe
battery inserted: the unit will start with in AC mode.
• IftheunithasthebatteryinsertedWITHOUTthe
power cord connected: the unit will start in DC mode.
m IMPORTANT! m
DO NOT start the machine with the battery in and the
power cord connected at the same time.
If you are using AC power mode:
1. Use only a UL-rated extension cord recommended for
outdoor use. Refer to the Extension Cord Chart on page 6.
2. Push a loop of the extension cord through the slot on the
cord lock from the opposite side of the restraint hook.
Position the loop over the hook and pull the cable back
through the slot (Fig. 11).
Fig. 11
Charging a Hot or Cold Battery Pack
A red and green ashing indicator light on the charger
indicates that the battery pack temperature is outside the
charging range. Once the pack is within the acceptable
range, normal charging will take place and the red light will
be continuous. Hot or cold battery packs may take longer to
charge.
Lithium-Ion Charging Status
Battery Pack
Temperature
Too hot Flashing Not charging
Normal range Continuous Normal charging
Too cold Flashing Not charging
Red Charger
Indicator Light
Charging
Status
Operation
mWARNING! Keep the area to be cleared free of stones,
toys, or other foreign objects that the rotor blades might pick
up and throw. Such items could be covered by snow and are
easy to overlook, so be sure to conduct a thorough inspection
of the area before beginning work.
Starting the Machine
NOTE: AC mode means the power is coming from the
electrical outlet. DC mode means the power is coming from
the lithium-ion battery.
Please note the AC mode takes priority over DC mode.
Extension
cord
Slot
3. Insert the female end of the extension cord into the
appliance's polarized male plug (Fig. 12).
Fig. 12
Appliance cord
Extension
cord
12
4. Note that the hybrid snow shovel has a polarized male
plug – one prong in the plug is slightly longer and wider
than the other (Fig. 13). The extension cord female end
should be likewise polarized so that the extension cord ts
snugly into the appliance plug.
If you are using DC power mode:
1. Open the battery compartment cover and slide the battery
down until it clicks to lock it into position, then close the
battery compartment cover (Fig. 15).
Fig. 13
Polarized plug
5. Push and hold the safety lock switch on the top of the
handle grip with your thumb and then squeeze the trigger
switch with your ngers. Once the machine powers on,
you can release the safety lock switch and proceed with
operation (Fig. 14).
Fig. 14
Fig. 15
Battery
compartment
cover
Battery
2. Push and hold the safety lock switch on the top of the
handle grip with your thumb and then squeeze the trigger
switch with your ngers. Once the machine powers on,
you can release the safety lock switch and proceed with
operation (Fig. 16).
Fig. 16
Safety lock
Trigger
switch
switch
m IMPORTANT! m
If you are switching to DC mode, be sure to
disconnect the power cord.
Safety lock
Trigger
switch
3. To stop the hybrid snow shovel, release the trigger switch.
switch
m IMPORTANT! m
If you are switching to AC mode, be sure to remove
the battery.
13
Operating Tips
• Start the hybrid snow shovel and tilt it forward until the
scraper blade at the base of the unit contacts the ground.
Push the shovel forward at a comfortable rate, yet slow
enough to clear the path completely. The clearing width of
the hybrid snow shovel and the depth of snowfall should
dictate your forward speed.
• Direct the snow discharge to the right or to the left by
holding the hybrid snow shovel at a slight angle.
• To remove snow most eciently, throw the snow
downwind and slightly overlap each swath.
• If you need to clear snow from a crushed rock or gravel
surface, push down on the handle to keep the scraper
blade clear of any loose material that the rotor blades
could throw.
• This hybrid snow shovel cuts a path 13 in. (33 cm) wide
and up to 6 in. (15 cm) deep in one pass.
• When clearing deeper drifts, hold the hybrid snow shovel
by the upper and lower handles and use a swinging or
sweeping motion. Remove up to 6 in. (15 cm) of snow with
each pass and repeat as many times as needed.
• Remove the battery after using the hybrid snow shovel.
Hang the shovel so it will not be misplaced or damaged.
Replacing the Auger
mWARNING! Make sure to turn o the switch, disconnect
the power cord, and remove the battery before performing any
maintenance task on your hybrid snow shovel.
1. Disassemble the left side cover by removing the ve
screws that hold it in place (Fig. 17).
Fig. 17
2. Remove the belt from the drive wheel (Fig. 18).
Maintenance
To order genuine replacement parts or accessories for the
Snow Joe® iON13SS-HYB hybrid snow shovel, please visit
snowjoe.com or contact the Snow Joe® + Sun Joe® customer
service center at 1-866-SNOWJOE (1-866-766-9563).
Proper Care for Battery + Charger
mWARNING! To reduce the risk of injury, always unplug
the charger and remove the battery pack from the charger
before performing any maintenance task. Never disassemble
the battery pack or charger. Contact your Snow Joe® +
Sun Joe® dealer or the Snow Joe® + Sun Joe® customer
service center for ALL repairs.
1. To reduce the risk of injury and damage, never immerse
your battery pack or charger in liquid or allow any liquid to
ow inside these components.
2. Clean out dust and debris from charger vents and
electrical contacts by blowing with compressed air.
3. Use only mild soap on a damp cloth to clean the battery
pack and charger, keeping away from all electrical
contacts. Certain cleaning agents and solvents are harmful
to plastics and other insulated parts. Some of these
include gasoline, turpentine, lacquer thinner, paint thinner,
chlorinated cleaning solvents, ammonia, and household
detergents containing ammonia. Never use ammable
or combustible solvents around battery packs, battery
chargers or tools.
4. The EcoSharp® iCHRG40 lithium-ion battery charger has
no serviceable parts.
Fig. 18
Belt
Drive wheel
3. Remove the screws and the bushings from the drive wheel
(Fig. 19).
Fig. 19
Screws and
bushings
Drive wheel
14
4. Disassemble the right side cover by removing the ve (5)
screws that hold it in place (Fig. 20).
Fig. 20
5. Secure the auger and remove the auger assembly nut
(Fig. 21).
Fig. 21
7. Remove the old auger from the housing (Fig. 23).
Fig. 23
Auger
8. Install the replacement auger by following the above steps
in reverse order (Fig. 24).
Fig. 24
Auger assembly nut
6. Remove the auger axle set (Fig. 22).
Fig. 22
Auger axle set
Replacing the Belt
mWARNING! Make sure to turn o the switch and
remove the battery before performing any maintenance task on
your hybrid snow shovel.
1. Disassemble the left side cover by removing the ve (5)
screws that hold it in place (Fig. 17).
2. Remove the old belt from the body by slowly turning the
auger while lifting the belt (Fig. 25).
Fig. 25
Belt
Auger
15
3. Replace the worn belt with a new belt (Fig. 26).
Fig. 26
Belt
3. Install the new scraper blade and fasten it securely to the
housing with the four screws (Fig. 29).
Fig. 29
Scraper blade
4. Place the left side cover back into position and refasten
the ve (5) screws.
Replacing the Scraper Blade
mWARNING! Make sure to turn o the switch and
remove the battery before performing any maintenance task on
your hybrid snow shovel.
1. Turn the hybrid snow shovel over. Using a drill or
screwdriver, remove the four screws that secure the
scraper blade to the base of the unit (Fig. 27).
Fig. 27
4 screws
Drill
2. Remove the old scraper blade (Fig. 28).
Fig. 28
Scraper blade
4 screws
Lubricating the Hybrid Snow Shovel
This hybrid snow shovel does not need lubrication. All
bearings are lubricated at the factory for the life of the product.
Storage
1. Examine the hybrid snow shovel thoroughly for worn,
loose, or damaged parts. Should you need to repair or
replace a part, contact an authorized Snow Joe® +
Sun Joe® dealer or call the Snow Joe® + Sun Joe®
customer service center at 1-866-SNOWJOE
(1-866-766-9563) for assistance.
2. Remove the battery from the hybrid snow shovel
before storing.
3. Store the hybrid snow shovel indoors in a locked, dry
place out of the reach of children to prevent unauthorized
use or damage.
Battery+ChargerO-SeasonStorage
1. Do not expose your battery pack or charger to water,
rain or allow them to get wet. This could permanently
damage the charger and the battery pack. Do not use oil
or solvents to clean or lubricate your battery pack as the
plastic casing can become brittle and crack, causing a
serious risk of injury.
2. Store the battery pack and charger at room temperature
away from moisture. Do not store in damp locations where
corrosion of terminals may occur. As with other battery
pack types, permanent capacity loss can result if the pack
is stored for long periods of time at high temperatures
(over 120ºF/49ºC).
3. EcoSharp® iBAT40 lithium-ion battery packs maintain
their charge during storage longer than other battery
pack types. As a general practice, it is best to unplug the
battery charger and remove the battery pack when they
are not in use. Recharge the battery pack every 6 months
to 50% capacity (2 lights on) during o-season storage to
maintain optimal battery performance.
16
Battery Caution + Disposal
Always dispose of your battery pack according to federal,
state, and local regulations. Contact a recycling agency in your
area for recycling locations.
mCAUTION! Even discharged battery packs contain
some energy. Before disposing, use electrical tape to cover
the terminals to prevent the battery pack from shorting, which
could cause a re or explosion.
mWARNING! To reduce the risk of injury or explosion,
never burn or incinerate a battery pack even if it is damaged,
dead, or completely discharged. When burned, toxic fumes
and materials are emitted into the surrounding atmosphere.
1. Batteries vary according to device. Consult your manual
for specic information.
2. Install only new batteries of the same type in your product
(where applicable).
3. Failure to insert batteries in the correct polarity, as
indicated in the battery compartment or manual, may
shorten the life of the batteries or cause batteries to leak.
4. Do not mix old and new batteries.
5. Do not mix Alkaline, Standard (Carbon-Zinc), or
Rechargeable (Nickel Cadmium, Nickel Metal Hydride, or
Lithium-Ion) batteries.
6. Do not dispose of batteries in re.
7. Batteries should be recycled or disposed of as per state
and local guidelines.
Service and Support
If your Snow Joe® iON13SS-HYB hybrid snow shovel requires
service or maintenance, please call the Snow Joe® +
Sun Joe® customer service center at 1-866-SNOWJOE
(1-866-766-9563).
Model and Serial Numbers
When contacting the company, reordering parts or arranging
service from an authorized dealer, you will need to provide the
model and serial numbers, which can be found on the decal
located on the housing of the unit. Copy these numbers into
the space provided below.
Record the following numbers from the housing or handle of your
new product:
i O N 1 3 S S - H Y B
Model #:
Serial #:
17
Accessories
mWARNING! ALWAYS use only authorized Snow Joe
replacement parts or accessories that are not intended for use with this hybrid snow shovel. Contact Snow Joe® + Sun Joe® if
you are unsure whether it is safe to use a particular replacement part or accessory with your hybrid snow shovel. The use of any
other attachment or accessory can be dangerous and could cause injury or mechanical damage.
®
+ Sun Joe® replacement parts and accessories. NEVER use
ModelAccessories Item
1
EcoSharp® 40 V 4.0 Ah
Lithium-Ion Battery
2
EcoSharp® PRO 40 V 5.0 Ah
Lithium-Ion Battery
iBAT40
iBAT40XR
3
EcoSharp® 40 V Lithium-Ion Battery Charger
iCHRG40
5
Snow Joe® + Sun Joe® Power Joe SJTW-A
14-gauge 50-foot extension cord with
lighted end
NOTE: Accessories are subject to change without any obligation on the part of Snow Joe® + Sun Joe® to provide notice of such
changes. Accessories can be ordered online at snowjoe.com or via phone by contacting the Snow Joe® + Sun Joe® customer
service center at 1-866-SNOWJOE (1-866-766-9563).
PJEXT50-B
18
SNOW JOE® + SUN JOE® CUSTOMER PROMISE
ABOVE ALL ELSE, Snow Joe® + Sun Joe® are dedicated to you, our customer. We strive to make your experience
as pleasant as possible. Unfortunately, there are times when a product does not work or breaks under normal
operating conditions. We think it’s important that you know what you can expect from us. That’s why we created
the Snow Joe® + Sun Joe® promise.
OUR PROMISE: Snow Joe® + Sun Joe® warrant new products for two years from the date of purchase. If your product
does not work, or there’s an issue with a specic part, we will x this by either sending you a free replacement part or
by sending you a new or comparable product at no charge. How cool is that! Before you know it, you’ll be back in
action cutting, sawing, mowing, washing and…?
GENERAL CONDITIONS:
Snow Joe® + Sun Joe® operating under Snow Joe®, LLC warrants
this new product to the original purchaser for two years against
defects in material or workmanship when used for normal
residential purposes. If a replacement part or product is needed,
it will be sent free of charge to the original purchaser except as
noted below.
The duration of this warranty applies only if the product is put
to personal use around the household. If the product is put to
any business, commercial or industrial use or is rented or leased,
then the duration of this warranty is 90 days from the date of
original purchase. It is the owner’s responsibility to correctly
perform all maintenance and minor adjustments explained in
the owner’s manual.
HOW TO OBTAIN YOUR REPLACEMENT PART OR PRODUCT:
To obtain a replacement part or product, please visit
snowjoe.com/help or email us at help@snowjoe.com for
instructions. Please be sure to register your unit beforehand to
speed up this process. Certain products may require a serial
number, typically found on the decal axed to the housing
or guard of your product. All products require a valid proof
of purchase.
EXCLUSIONS:
• Wearing parts like belts, augers, chains and tines are
not covered under this warranty. Wearing parts can be
purchased at snowjoe.com or by calling 1-866-SNOWJOE
(1-866-766-9563).
• Batteries are covered in full for 90-days from the date of
purchase.
Snow Joe® + Sun Joe® may from time to time change the design
of its products. Nothing contained in this warranty shall be
construed as obligating Snow Joe® + Sun Joe® to incorporate
such design changes into previously manufactured products, nor
shall such changes be construed as an admission that previous
designs were defective.
This warranty is intended to cover product defects only.
Snow Joe®, LLC is not liable for indirect, incidental or
consequential damages in connection with the use or misuse of
the Snow Joe® + Sun Joe® products covered by this warranty.
This warranty does not cover any cost or expense incurred
by the purchaser in providing substitute equipment or service
during reasonable periods of malfunction or non-use of this
product while waiting for a replacement part or unit under this
warranty. Some states do not allow exclusions of incidental or
consequential damages so the above exclusions may not apply
in all states. This warranty may give you specic legal rights in
your state.
HOW TO REACH US:
We’re here to help Monday through Friday from 9AM to 6PM EST.
You can reach us at 1-866-SNOWJOE (1-866-766-9563), online
at snowjoe.com, via email at help@snowjoe.com or tweet us
@snowjoe.
EXPORTS:
Customers who have purchased Snow Joe® + Sun Joe®
products exported from the United States and Canada should
contact their Snow Joe® + Sun Joe® distributor (dealer) to obtain
information applicable to your country, province or state. If for
any reason, you are not satised with the distributor’s service,
or if you have diculty obtaining warranty information, contact
your Snow Joe® + Sun Joe® seller. If in the event your eorts are
unsatisfactory, please reach out to us directly.
19
