Snapper SGT27540D User Manual

Parts Manual fo

r

r

GT600 Diesel 4WD

3 Point Hitch Tracto

GT600 SERIES

MODEL

SGT27540D (2690626)
SGT27540D (2690627)
SGT27540D (2690628)
SGT27540D (2690629)
SGT27540D (2690634)
SGT27540D (2690667)

Briggs & Startton Yard Power Products Group
Copyright © 2007
Milwaukee, WI USA. All Rights Reserved

Briggs & Startton Corporation

Revision 1,

McDonough, GA, 30253 U.S.A.

8/31/2007

Manual No. 7006465

TP 400-5260-1-TC-N

s

PAGE GROUP

4
6

8
12
16
22
26
30
34
36
40
44
46
48

Wheel & Tires Group
Steering & Front Axle Group
Body Group
Frame & Transmission Group
Controls Group
Hydraulic Group
Engine Group - 27HP Briggs & Stratton Diesel Diagram 1
Engine Group - 27HP Briggs & Stratton Diesel Diagram 2
54" Mower Deck - Drive Group
54" Mower Deck - Height Adjustment & Roller Group
54" Mower Deck - Housing, Arbors & Blades Group
3-Point Hitch Group
Decals Group
Electrical Group - 27HP Briggs & Stratton Diesel

Table Of Content

GT600 SERIES

Manual No. 7006465GT600 Diesel 4WD

3

TP 400-5260-1-TC-N

Manual No. 7006465 GT600 Diesel 4WD
TP 400-5260-1-TC-N

4

GT600 SERIES

Wheel & Tires Group

p

y

Part No Descri

1 1724845 2 WHEEL & TIRE ASSEMBLY, Turf Tires, Rear (Includes Reference Nos. 2, 3, &

1 1726030 2 WHEEL & TIRE ASSEMBLY, HD Field Trac, Rear (Includes Reference No. 4)
2 1725724 2 TIRE, Turf Tire, 26 x 12-12
3 1725723 2 WHEEL, Turf Tire, Rear 8.5 x 12
4 2172353 2 VALVE STEM & CAP
5 1729280 20 HUB BOLT

15 1724849 2 WHEEL & TIRE ASSEMBLY, Turf Tires, Front, 4 Wheel Drive (Includes Reference Nos. 4, 16,

15 1726032 2 WHEEL & TIRE ASSEMBLY, HD Field Trac, Front, 4 Wheel

Drive
16 1725720 2 TIRE, Turf Tire, Front, 18 x 8.5-8
17 1725719 2 WHEEL, Turf Tire, Front, 4 Wheel Drive

tionItem Qt

Note

4)

& 17)
(Includes Reference No. 4)

Footnotes:

Note: * Use for Model 2690626 only.
Note: * Use for Model 2690627 and 2690667.

Manual No. 7006465GT600 Diesel 4WD

GT600 SERIES

5

TP 400-5260-1-TC-N

Steering & Front Axle Group

Manual No. 7006465 GT600 Diesel 4WD
TP 400-5260-1-TC-N

6

GT600 SERIES

Steering & Front Axle Group

p

y

Part No Descri

1 1724273 1 AXLE ASSSEMBLY
2 1960201 2 WASHER
3 1725013 2 FITTING, Elbow Hose
4 1725012 1 HOSE ASSEMBLY, Hydraulic
5 1724890 1 HOSE ASSEMBLY, Hydrualic
6 1725617 1 CLAMP, Worm Hose
7 1725581 1 COVER, Drive Shaft

8 1724562 1 SHAFT ASSEMBLY
13 1919439 2 NUT, Hex, Lock, 3/8-16 NC
14 1921971 2 CAPSCREW, Hex Head, 3/8-16 x 1-3/4 G5
15 1701011 2 TIE, Self Locking
16 1960223 3 CARRIAGE BOLT, 5/16-16 x 1 G5
17 1933988 3 NUT, Push, 1/4
18 1724685A 1 PLATE, Steering
19 1723898 2 SPACER, Flat
20 1960636 3 NUT, Hex, Keps 5/16-18 Black
21 1733790 1 TILT STEERING UNIT, 2 Holes, Legacy
22 1724368 1 BELLOWS, Tilt Steering Unit With Slot
23 1724576 1 STEERING WHEEL
24 1715920 1 CAP, Steering Wheel
26 1725294 1 ADAPTER TILT, 9 Tooth With Powerdered Metal
28 1960691 1 NUT, Hex, Toplock Flange 3/4-10
40 1924366 1 WASHER, 0.625 (0.66ID x 1.12 x .11THK) Black
48 1664847 1 SCREW, Hex Washer Head, Taptite, 5/16-18 x 3/4
49 1704314 1 FITTING, Lube, 1/4 Drive
50 1724841 1 SHAFT & ANCHOR ASSEMBLY, Pivot
51 1960576 1 NUT, Hex
52 1732090 1 SPACER, 0.793 x 1-3/4 x 1/4
53 1732089 1 CUP, Grass Shield
54 2176111 1 O-RING

tionItem Qt

Note

Footnotes:

Manual No. 7006465GT600 Diesel 4WD

GT600 SERIES

7

TP 400-5260-1-TC-N

Body Group

Manual No. 7006465 GT600 Diesel 4WD
TP 400-5260-1-TC-N

8

GT600 SERIES

Body Group

p

y

Part No Descri

1 1663752 2 SPACER

2 1960667 9 SCREW, Hex, Flange Whiz Lock, Dog Point, 5/16-18 x 1

3 1960687 2 NUT, Hex, Flange ESNA Lock, Black 3/8-16

4 1723707A 1 PAN, Seat

5 1725300 1 SEAT, Black

6 1716977A 1 SUPPORT, Seat Lower

7 1931333 4 CARRIAGE BOLT, Black, 5/16-18 x 3/4

8 1960686 6 NUT, Nut, Flange Lock, ESNA, 5/16-18

9 1709256 6 LOCKWASHER, Black
10 1717051 2 SPRING, Seat
11 1931335 2 CARRIAGE BOLT, Black, 5/16-18 x 1
12 1931350 2 CARRIAGE BOLT, Black, 3/8-16 x 1
13 1717009 1 SLIDE, Seat
14 1960295 8 CAPSCREW, Hex, Head, 1/4-20 x 5/8
15 1725822D 1 PANEL, Side R.H., Legacy XL
16 1725821D 1 PANEL, Side L.H., Legacy XL
17 1717008 1 SLIDE, Seat, L.H.
18 1716336 1 HANDLE, Grab, RH, Black
19 1687053 1 POD, Legacy XL, 2WD
20 1726823 1 POD, Legacy XL, 4WD
21 1664847 6 CAPSCREW, Hex, Washer Head, Taptite, Black, 5/16-18 x 3/4
22 1724581D 1 DECK, Seat, Legacy XL
23 1725290 1 POD, Legacy XL, L.H.
24 1716335 1 HANDLE, Grab, L.H., Black
25 1715915 2 TAIL LIGHT ASSEMBLY
26 1718048 4 CLIP, “L”
27 1933988 4 NUT, Push, Black, 5/16
28 1925205 4 CAPSCREW, Hex Head, Black, 5/16-18 x 5/8
29 1960044 4 WASHER, Black, 5/16
30 1960578 10 CAPSCREW, Hex Washer Head, #12-24 x 5/8
31 1933896 1 NUT, Nylock, # 10-24
32 1718611 1 PLUG, Dashboard, Diesel
33 1724584 1 DASH, Upper, Black, Diesel
34 1960252 4 CARRIAGE BOLT, Black, 1/4-20 x 5/8
35 1725032A 1 DASH, Lower, Black, Diesel
36 1960685 4 NUT, Hex, KEPS, Black, 1/4-20
37 1724869 1 ROD, Dash Support

tionItem Qt

Note

Footnotes:

Manual No. 7006465GT600 Diesel 4WD

GT600 SERIES

9

TP 400-5260-1-TC-N

Body Group

Manual No. 7006465 GT600 Diesel 4WD
TP 400-5260-1-TC-N

10

GT600 SERIES

Body Group

p

y

Part No Descri

38 1960393 1 SCREW, Phillips, Pan Head, Black, #10-24 x 1
39 1960684 9 NUT, Hex, Keps, Black, 5/16-18
41 1725658C 1 HOOD & SCREEN ASSEMBLY
42 1725654 1 EDGING, Rubber, Black, 23” Long
43 1725653 1 EDGING, Rubber, Black, 2-5/8” Long
44 1725775 1 COVER ASSEMBLY, Dash, Black (Diesel Only)
45 1717523 1 CLIP, “U”
46 1724580 1 PAD, Footrest, R.H.
47 1724268D 1 TUNNEL, Legacy XL
48 1724579 1 PAD, Footrest, L.H.
49 1704351 19 FASTENER, Panel
50 1925003 7 CAPSCREW, Hex, Washer Head, Taptite, Black, 1/4-20 x 1/2
51 1717076 2 ELBOW & TUBE ASSEMBLY
53 1654930 2 BUSHING
54 2860665 5 SCREW, Pan Head, Torx, SEMS, #10-32 x 1/2
55 1725301 1 SENDER, Fuel
56 1685303 1 GASKET
57 1718633 1 CAP, Fuel, Diesel
58 1726783 1 TANK, Fuel, Diesel
59 1716927A 2 SUPPORT, Fuel Tank
60 1723168 2 HOOK
61 2171600 2 STRAP, Hood, Black Rubber
62 1715923 1 HEADLIGHT ASSEMBLY
63 1930641 12 NUT, Hex, Flange Whiz Lock, Black, 1/4-20
64 1960611 4 CAPSCREW, Hex, Whiz Lock, Black, 1/4-20 x 1
65 1725631D 1 GRILL, Legacy XL (Red)
66 1718479 1 ROD, Hood Hinge
67 1726044 2 SCREW, Binding
68 1726454 2 CLIP, Hood
69 1726482 2 EDGING, Side Panel
70 1960518 2 NUT, Push (Diesel Only)
71 1725060 2 SCREW, Quarter Turn (Diesel Only)
72 2860707 2 SCREW, Hex, Serrated Flange
73 1704723 1 GRIP, Black Vinyl
74 1717002 1 ROD, Seat Slide
75 1920466 2 RIVET
76 1726917 1 TUBE ASSEMBLY, Fuel With Screen

tionItem Qt

Note

Footnotes:

Manual No. 7006465GT600 Diesel 4WD

GT600 SERIES

11

TP 400-5260-1-TC-N

Frame & Transmission Group

Manual No. 7006465 GT600 Diesel 4WD
TP 400-5260-1-TC-N

12

GT600 SERIES

Frame & Transmission Group

p

y

Part No Descri

1 1664847 22 CAPSCREW, Hex, Washer Head, Taptite, 5/16-18 x 3/4, Black

2 1725752A 1 BRACKET, Upstop

3 1725171A 1 BUMPER & BRACKETS ASSEMBLY

4 1960706 2 CARRIAGE BOLT-RD, 1/2-13 x 2, Black

5 1920328 2 CAPSCREW, Hex Head, 1/2-13 x 1-1/2, Black

6 1960708 4 NUT, Hex, Lock ESNA, 1/2-13

9 1724838A 1 SUPPORT, Control Valve
10 1931333 6 CARRIAGE BOLT, 5/16-18 x 3/4, Black
11 1960684 6 NUT, Hex, KEPS 5/16-18, Black
12 1724108A 1 TOWER ASSEMBLY
13 1725095A 1 SUPPORT, Seat Support, R.H.
14 1724765A 1 SHAFT ASSEMBLY
15 1725096A 1 SUPPORT, Seat Support, L.H.
16 1720147A 2 STRAP
17 1725094A 1 SUPPORT, Seat Deck
18 1921333 1 CAPSCREW, Hex Head, 5/16-18 x 1, Black
19 1919326 1 WASHER, 5/16, Black
20 2153010 1 SPRING, Compresion, Conocal
21 1724248 1 BRACKET, Free Wheel
22 1725308 1 SUPPORT, Free Wheel Latch
23 1725081A 1 SUPPORT, Dump Valve
24 1724244A 1 BRACKET, Torque Strap
25 1931350 9 CARRIAGE BOLT, 3/8-16 x 1 Black
26 1724817A 1 SHIELD & BRACKET ASSEMBLY
27 1960677 2 CAPSCREW, Hex Head, M12-1.75 x 25MM (540 PTO Models Only)
28 1960687 4 NUT, Hex, Flange ESNA, 3/8-16, Black
29 1960423 4 NUT, Hex Flange Center Lock, M12-1.25, Black
30 1916966 4 LOCKWASHER, 1/2, Black
31 1725635 1 ROD
32 1960680 5 NUT, Hex, KEPS 3/8-16, Black
33 1724936A 1 BRACE, Cross
34 1724144A 1 FRAME ASSEMBLY
35 1913744 2 NUT, Hex, Jam, 1/2-13, Black
36 1726019A 2 LOCK, Hood
37 1924361 4 WASHER, 1/2
38 1960482 4 CAPSCREW, Hex Head, M12-1.25 x 100MM, Black
39 1724561 1 TRANSMISSION ASSEMBLY, 4WD, K92C, W/540

tionItem Qt

Note

Footnotes:

Manual No. 7006465GT600 Diesel 4WD

GT600 SERIES

13

TP 400-5260-1-TC-N

Frame & Transmission Group

Manual No. 7006465 GT600 Diesel 4WD
TP 400-5260-1-TC-N

14

GT600 SERIES

Frame & Transmission Group

p

y

Part No Descri

40 1960686 1 NUT, Hex, Flange ESNA, 5/16-18, Black
41 1726474 1 COVER, PTO Shaft
42 1960268 1 BOLT, 3/8-16 x 1 1/4
43 1960373 1 SCREW, Hex, Washer 5/16-18 x 1.000

tionItem Qt

Note

Footnotes:

Manual No. 7006465GT600 Diesel 4WD

GT600 SERIES

15

TP 400-5260-1-TC-N

Controls Group

Manual No. 7006465 GT600 Diesel 4WD
TP 400-5260-1-TC-N

16

GT600 SERIES

Controls Group

p

y

Part No Descri

1 1721577 1 PAD, Brake Pedal

2 1724676 1 ROD, Brake Pedal

3 2860396 1 PIN, Spring

4 2176440 6 BUSHING

5 1931317 3 CARRIAGE BOLT, 1/4-20 x 3/4 G5

6 1722460 11 PIN, Quick

7 1725276 1 ROD, 4 Bends, 13.63 LG

8 1717006 1 BRACKET, Parking Brake Pivot

9 1960685 2 NUT, Hex, KEPS, 1/4-20 Conical Washer
10 1717004 1 ROD, 10-24 x 31/50, 3.91 LG
11 1960591 3 NUT, Hex, KEPS, #10-24
12 1725277 1 KNOB, Interior Thread, Parking
13 1725550 1 CLIP, Rod End Linkage, L.H., For .188 Rod
14 1960234 1 SPACER, .320 LG
15 1960687 2 NUT, Hex, Flange, 3/8-16, ESNA
16 1922611 3 WASHER, 3/4
17 1677746 1 SPRING, Complete
18 1713791 2 SPACER, 7/16 LG Powdered Metal
19 1924356 1 WASHER, 3/8
20 1960114 2 WASHER, 3/4
21 1724850 1 ROD, 4WD Shift, 10.74 LG
22 1664847 6 SCREW, Hex Washer Head, Taptite, 5/16-18 x 3/4
23 1933737 2 SCREW, Hex Washer Head, Slot #10-24 x 5/8
24 1717050 1 SWITCH, Push Button, Nuetral/Start
25 1724866A 1 BRACKET, 2 Speed Pivot
26 1674631 4 BEARING HALF, Outer Nylon
27 1713843 1 KNOB, Sphere Softer
28 1724902 1 ROD, Shift 2 Speed, 19-1/4 LG
29 1930600 4 SCREW, Hex Washer Head, Taptite, 5/16-18 x 1-1/2
30 1919326 6 WASHER
31 1716994A 1 BRACKET, Mounting, 4.63 LG
32 1960684 7 NUT, Hex, KEPS 5/16-18, Conical Washer
33 1725357 1 KNOB, With Cruise Control Rod Molded In
34 1931335 2 CARRIAGE BOLT, 5/16-18 x 1 G5
35 1724669A 1 LEVER ASSEMBLY, Cruise
36 1669105 1 SPACER, 1-1/2 LG HARDEN
37 1924940 1 WASHER, 3/8

tionItem Qt

Note

Footnotes:

Manual No. 7006465GT600 Diesel 4WD

GT600 SERIES

17

TP 400-5260-1-TC-N

Controls Group

Manual No. 7006465 GT600 Diesel 4WD
TP 400-5260-1-TC-N

18

GT600 SERIES

Controls Group

p

y

Part No Descri

38 1922130 1 CAPSCREW, Hex Head, 3/8-16 x 2-1/4 G5
40 1960615 1 CARRIAGE BOLT, 3/8-16 x 2-1/2
41 1922755 5 WASHER, 3/4
42 1724686A 1 ARM, Cruise Return
43 1724913 1 LINK & PIN ASSEMBLY, Cruise
44 1923903 1 CAPSCREW, Hex Head, 3/8-16 x 3.00
45 1676148 2 BUSHING, 2/5 LG Powdered Metal
46 1960666 1 SCREW, 1/4-20 x 7/8
47 1726043 1 HANDLE, 540 PTO 3/8 x 7/8 Slot
48 1724225A 1 HANDLE ASSEMBLY, Control
49 1724216 1 ARM & HUB ASSEMBLY, Control
50 1725010 1 PIN, Spring
51 1724229 1 ROD, Control, 9.23 LG
52 1960680 1 NUT, Hex, KEPS 3/8-16 Conical Washer
53 1960692 1 NUT, Hex, Toplock Flange 7/16-20
54 1725278 1 SPRING, Complete
55 1725011 2 PIN, Clevis
56 1918447 3 PIN, Cotter 3/32 X 3/4
57 1724783A 1 LINK & BRACE ASSEMBLY, Brake
58 1724200 1 ROD
59 1724858 1 ROD, Diff Lock, 20.7 LG
60 1611710 2 RING, Klipring Extension, 3/4 Shaft
61 1724859 1 PEDAL ASSEMBLY, Diff Lock
62 1716289 1 KNOB, Hole
63 1724672 1 SHAFT ASSEMBLY, Brake
64 1925125 1 WASHER, 7/16
65 1726765A 1 ARM ASSEMBLY, Control
66 1931337 1 CARRIAGE BOLT, 5/16-18 x 1-1/2 G5
67 1931320 1 CARRIAGE BOLT, 1/4-20 x 1-1/4 G5
68 1726766 1 CONTROL ASSEMBLY, Foot Pedals
69 1702552 1 SPACER
70 1725275 1 ARM, Brake Lock
71 1960686 1 NUT, Hex Flange, 5/16-18, ESNA
72 1931334 4 CARRIAGE BOLT, 5/16-18 x 7/8 G5
73 1721675 1 PAD, Foot Pedal, Forward
74 1724266A 1 PEDAL, Foot, Forward
75 1721674 1 PAD, Foot Pedal, Reverse
76 1722071A 1 PEDAL, Reverse

tionItem Qt

Note

Footnotes:

Manual No. 7006465GT600 Diesel 4WD

GT600 SERIES

19

TP 400-5260-1-TC-N

Controls Group

Manual No. 7006465 GT600 Diesel 4WD
TP 400-5260-1-TC-N

20

GT600 SERIES

Controls Group

p

y

Part No Descri

77 1921332 1 CAPSCREW, Hex Head, 5/16-18 x 3/4 G5
78 1924856 2 SCREW, Hex Washer Head, Taptite, 5/16-18 x 1/2
79 1707944 1 CAM, Roller
80 1724679A 1 ARM ASSEMBLY, Brake
81 1724846A 1 LINK, Brake
82 1724844 1 ACTUATOR, Switch 20GA
83 1721995 1 SPRING, Extension
84 1727215A 1 ACTUATOR, Switch 20GA
85 1920397 2 NUT, Hex Nylon, 1/4 -20
86 1920252 2 BOLT, Carriage, 1/4-20 x 5/8
87 1726443 1 DISC, Friction

tionItem Qt

Note

Footnotes:

Manual No. 7006465GT600 Diesel 4WD

GT600 SERIES

21

TP 400-5260-1-TC-N

Hydraulic Group

Manual No. 7006465 GT600 Diesel 4WD
TP 400-5260-1-TC-N

22

GT600 SERIES

Hydraulic Group

p

y

Part No Descri

1 1726319 1 WASHER

2 2173360 4 PLUG, Plastic

3 2173358 4 BODY ASSEMBLY, Coupler 1/4-18 Int, 1.94 LG

4 1726321 1 WASHER

5 1725351 7 FITTING, Tube Elbow

6 1725687 1 TUBE, Hydraulic

7 1725686 1 TUBE, Hydraulic

8 1725688 1 TUBE, Hydraulic

9 1725080 1 VALVE ASSEMBLY, Control 2 Spool
10 1725690 1 TUBE, Hydraulic
11 1960700 2 CARRIAGE BOLT, 1/4-20 x 2 G5
12 1724434 1 ROD & PIN ASSEMBLY, Control
13 1724878 1 ROD & PIN ASSEMBLY, Control
14 1725012 1 HOSE ASSEMBLY, Hydraulics, R.H.
15 1724890 1 HOSE ASSEMBLY, Hydraulics, L.H.
16 1960685 4 NUT, Hex 1/4-20 Conical Washer
17 1724881 1 PAD, Hydraulic
18 2860697 3 NUT, Hex, Spiralock Flange 1/4-28
19 1725117 3 JOINT, Ball, 1/4-28 Int
20 1923341 2 CAPSCREW, Hex Head, 1/4-20 x 3/4 G5
21 1725100A 1 LEVER ASSEMBLY, Joystick
22 1960666 1 SCREW, TORX PLUS Socket Head, 1/4-20 x 7/8
23 1722303 1 HANDLE, Cruise 3/8 x 7/8 Slot
24 1920397 1 NUT, Hex, Lock, ESNA LIGHT, 1/4-20 NC-3B
25 1725120 1 BOOT, Hydraulic Control
26 2860696 3 SCREW, Hex SEMS Square Washer, 1/4-28 x 3/4
27 2860444 4 CAPSCREW, Hex Head
28 1916964 4 LOCKWASHER, Spring
29 1725288 1 POWER STEERING UNIT
30 1725485 1 O-RING
31 1724886 1 TUBE, Hydraulic
32 1725604 1 HOSE ASSEMBLY, Hydraulic Rubber, 29 LG, 1 Swivel
33 1960033 1 CLIP, Hair Pin
34 1725655 1 FITTING, Tube Elbow 9/16-18 13/16-16, 90 Degrees
35 1729590 1 TUBE, Assembly Hydraulic
36 1729591 1 FITTING, Tube Elbow, 9/16-18 11/16-16, 45 Degrees
37 1725111 1 HOSE ASSEMBLY, Hydraulic Rubber, 180 Degrees

tionItem Qt

Note

Footnotes:

Manual No. 7006465GT600 Diesel 4WD

GT600 SERIES

23

TP 400-5260-1-TC-N

Hydraulic Group

Manual No. 7006465 GT600 Diesel 4WD
TP 400-5260-1-TC-N

24

GT600 SERIES

Hydraulic Group

p

y

Part No Descri

38 1729275 1 PIN, Round Head Drilled, 1/2 x 2-1/2
39 1918452 1 PIN, Cotter, 1/4 x 1
40 1726442 1 CYLINDER ASSEMBLY, Hydraulic
41 1725223 1 PIN, Clevis
42 1725691 1 HOSE, Hydraulic
43 2819171 2 TUBE, Fitting Mail 1/8 NPT+7/16-20 .250TU
44 1725110 1 HOSE ASSEMBLY, Hydraulic Rubber, 13.7 LG, 30 Degrees
45 1960221 2 CLIP, Hair Pin
46 1960571 2 SCREW, Hex, Washer Head Taptite, 1/4-20 x 1-3/4
47 1724857 1 VALVE ASSEMBLY, Selector
48 1725684 1 TUBE, Hydraulic
49 1725685 1 TUBE, Hydraulic
50 1726320 1 WASHER
51 1726318 1 WASHER
52 1725323A 1 SUPPORT, Quick Disc L.H.
53 1930594 4 SCREW, Hex Lock Flange 1/4-20 x 3/4
54 1725325A 1 SUPPORT, Quick Disc R.H.

tionItem Qt

Note

Footnotes:

Manual No. 7006465GT600 Diesel 4WD

GT600 SERIES

25

TP 400-5260-1-TC-N

Engine Group - 27HP Briggs & Stratton Diesel Diagram 1

Manual No. 7006465 GT600 Diesel 4WD
TP 400-5260-1-TC-N

26

GT600 SERIES

Engine Group - 27HP Briggs & Stratton Diesel Diagram 1

p

y

Part No Descri

1 1934654 13 SCREW, Hex Whiz Lock Flange, 3/8-16 x 1

2 1718628 1 MUFFLER

3 ----- 4 * NUT

4 ----- 1 * BRACKET

5 1926018 6 NUT, Speed, 1/4-20, U Type

6 1664847 17 SCREW, Hex, Washer, Head, Taptite, 5/16-18 x 3/4

7 1725627A 1 SHIELD, Hood 18GA

8 1725590A 1 BAFFLE, Hood 18GA

9 1725731 2 SEAL, Foam 1-1/2 x 1-1/2, 2.8LG
10 1960578 2 SCREW, Hex, Washer Head, Taptite, 12-24 x 5/8
11 1725328 1 CONTROL, Throttle
12 1933896 1 NUT, Hex Lock, 10-24
13 1725337 1 KNOB, Slot
14 1960393 1 SCREW, Pan Head, PHILLIPS, 10-24 x 1
15 1724571 1 SHAFT ASSEMBLY, Drive (Includes Ref. Nos. 16, 17, 18 &

16 ----- 1 YOKE, Drive Shaft (Order Complete Shaft

17 ----- 2 CROSS & BEARING KIT, Includes Grease Fitting (Order Complete Shaft

18 ----- 1 YOKE & TUBE ASSEMBLY (Order Complete Shaft

19 ----- 1 YOKE & FLANGE, Drive Shaft (Order Complete Shaft

20 1960347 10 CAPSCREW, Hex Head,
21 1917356 6 LOCKWASHER, Spring, 5/16
22 ----- 1 * ENGINE, 26.5HP Diesel B&S Mod. 582447-0224-E2
23 1921972 4 CAPSCREW, Hex Head, 3/8-16 x 2-1/2, G5
24 1924940 8 WASHER, 3/8
25 1726580A 1 MOUNT ASSEMBLY, Engine, L.H.
26 1917356 12 LOCKWASHER, Spring, 5/16
27 2825094 3 TIE, Self Locking, 7.31LG
28 1724813A 1 MOUNT, Engine, L.H.
29 1718655 4 MOUNT, Engine, Rear
30 1718640A 4 WASHER, 1/2
31 1960680 17 NUT, Hex KEPS, 3/8-16 Conical Washer
32 1724812A 1 MOUNT, Engine, R.H.
33 1725598A 1 HOLD DOWN ASSEMBLY, Battery
34 1922755 7 WASHER, 3/8
35 1928727 2 SCREW, Hex, Whiz Lock, Flange, 3/8-16 x 1-1/4
36 1734572 1 COVER ASSEMBLY, Air Cleaner
37 1734571 1 FILTER, Air Cleaner

tionItem Qt

Note

19)

Assembly, Ref. 15)

Assembly, Ref. 15)

Assembly, Ref. 15)

Assembly, Ref. 15)

Footnotes:

Note: * See your local Briggs & Stratton distributor for parts & service.

Manual No. 7006465GT600 Diesel 4WD

GT600 SERIES

27

TP 400-5260-1-TC-N

Engine Group - 27HP Briggs & Stratton Diesel Diagram 1

Manual No. 7006465 GT600 Diesel 4WD
TP 400-5260-1-TC-N

28

GT600 SERIES

Engine Group - 27HP Briggs & Stratton Diesel Diagram 1

p

y

Part No Descri

38 1719546 1 AIR CLEANER ASSEMBLY
39 1725588A 1 BRACKET, Air Cleaner
40 1725630 1 HOSE, Air Inlet, 28LG
41 1726042 1 HOSE, Inlet
42 1725661 1 FAN
43 1725746 5 CLAMP, Hose, Worm
44 1726581A 1 MOUNT ASSEMBLY, Engine R.H.
45 1718639A 1 BRACKET, Muffler
46 1960687 4 NUT, Hex, Flange, 3/8-16, ESNA
47 1930591 4 SCREW, Hex, Whiz Lock, Flange 5/16-18 x 1-1/4
48 1960686 1 NUT, Hex, Flange, 5-16-18, ESNA
49 1950018 6 CAPSCREW, Hex Head
50 1670578 1 KNOB
51 1921677 1 CAPSCREW, Hex Head 5/16-18 x 1-1/2
52 1919326 1 WASHER, 11/32 x 3/4 x 1/16
53 1666697 2 SPACER
54 1917372 1 NUT, Hex, 5/16-18

tionItem Qt

Note

Footnotes:

Note: * See your local Briggs & Stratton distributor for parts & service.

Manual No. 7006465GT600 Diesel 4WD

GT600 SERIES

29

TP 400-5260-1-TC-N

Engine Group - 27HP Briggs & Stratton Diesel Diagram 2

Manual No. 7006465 GT600 Diesel 4WD
TP 400-5260-1-TC-N

30

GT600 SERIES

Engine Group - 27HP Briggs & Stratton Diesel Diagram 2

p

y

Part No Descri

1 1725746 4 CLAMP, Hose, Worm

2 1718629 1 HOSE, Radiator

3 1930591 4 SCREW, Hex, Whiz Lock, Flange, 5/16-16 x 1-1/4

4 1725033A 1 SHIELD, R.H., 16GA

5 1664847 17 SCREW, Hex, Washer Head, Taptite, 5/16-18 x 3/4

6 1725559 1 COOLER ASSEMBLY, Oil

7 1925003 2 SCREW, Hex, Washer Head, Taptite, 1/4-20 x 1/2

8 1921319 2 WASHER, 1/4

9 2860266 4 CLAMP, Hose
10 1725098 1 ROD, Radiator, R.H.
11 1725363A 2 SLIDE, Offset, 14GA
12 1725362A 2 SLIDE, Screen Flat, 14GA
13 1725099 1 ROD, Radiator, L.H.
14 1722460 2 PIN, Quick
15 1675043 4 RIVET, Pop
16 1724906 1 RADIATOR
17 ----- 4 SPACER (Included with Ref. No. 16)
18 1922755 7 WASHER, 3/4
19 1726813A 1 SUPPORT, Radiator Shroud, 10GA
20 1718630 1 HOSE, Radiator
21 1725711 2 CLIP, 1/4 Turn Push
22 1725430A 1 COVER, Bracket, Top, 12GA
23 1725034A 1 SHIELD, L.H., 16GA
24 1717596 1 DECAL, Clean Radiator
25 1725116 1 SHROUD, Radiator
26 1960687 4 NUT, Hex, Flange, 3/8-16 ESNA
27 1950018 2 CAPSCREW, Hex Head
28 1917356 6 LOCKWASHER, Spring, 5/16
29 1725589A 1 BRACKET, Fuel Filter
30 ----- 1 * FUEL FILTER ASSEMBLY (Includes Fuel Filter)
30 ----- 1 * FILTER, Fuel
32 1725749 1 HOSE, Fuel
33 1679214 6 CLAMP, Hose
34 1718663 1 SENDER, Temperature
35 1718645 1 HOSE, Fuel
36 1725749 1 HOSE, Fuel (Cut to 71.5)
37 1725623A 1 SCREEN, Corrugated, 20GA

tionItem Qt

Note

Footnotes:

Note: * See your local Briggs & Stratton distributor for parts and service.

Manual No. 7006465GT600 Diesel 4WD

GT600 SERIES

31

TP 400-5260-1-TC-N

Engine Group - 27HP Briggs & Stratton Diesel Diagram 2

Manual No. 7006465 GT600 Diesel 4WD
TP 400-5260-1-TC-N

32

GT600 SERIES

Engine Group - 27HP Briggs & Stratton Diesel Diagram 2

p

y

Part No Descri

38 1725026A 1 BAFFLE, R.H., 16GA
39 1935255 3 NUT, Speed, 5/16-18, Lug Type
40 1725422A 1 BAFFLE, L.H., 16GA
41 1725429A 1 COVER, Bracket, Bottom
42 1960680 17 NUT, Hex, KEPS, 3/8-16 Conical Washer
43 1928727 2 SCREW, Hex, Whiz Lock, Flange, 3/8-16 x 1-1/4
44 1725598A 1 HOLD DOWN ASSEMBLY, Battery
45 ----- 1 * RADIATOR, Overflow
46 ----- 1 * HOSE, Radiator Overflow
47 1679061 1 CLAMP, Hose, Worm

tionItem Qt

Note

Footnotes:

Note: * See your local Briggs & Stratton distributor for parts and service.

Manual No. 7006465GT600 Diesel 4WD

GT600 SERIES

33

TP 400-5260-1-TC-N

54" Mower Deck - Drive Group

Manual No. 7006465 GT600 Diesel 4WD
TP 400-5260-1-TC-N

34

GT600 SERIES

54" Mower Deck - Drive Group

p

y

Part No Descri

1 1725190 1 BRACKET, Spring Mounting

2 1718016 1 SPRING, Extension

3 1923701 1 CAPSCREW, Hex Head, 3/8-16 x 2, Black

4 1924940 1 WASHER, 3/8

5 1674669 1 SPACER

6 1676148 2 BUSHING

7 1922611 1 WASHER, 3/8

8 2812808 1 FITTING, Grease

9 1931352 1 CARRIAGE BOLT, 3/8-16 x 1-1/2
10 1725189A 1 IDLER ARM ASSEMBLY (Includes Ref. No. 6)
11 1667811 1 SPACER
12 1725372 1 PULLEY, Idler
13 1960687 4 NUT, Hex, Flange Lock, ESNA, 3/8-16, Black
14 1960695 6 CAPSCREW, Hex Washer Head, 3/8-16 x 1-1/8, Black
15 1724513A 1 SUPPORT, Height of Cut
16 1724514A 1 BRACE, Height of Cut
17 1725217 1 DRIVE SHAFT ASSEMBLY
18 1960702 2 BOLT, Carriage, 3/8-16 x 1
19 1725298 1 GEARBOX ASSEMBLY
20 1921159 1 CAPSCREW, Hex Head, 1/4-20 x 2-1/4, Black
21 1928721 3 SCREW, Set, Square Head, Cup Point, 5/16-18 x 1/2, G8
22 1923358 2 NUT, Hex Center Lock, 1/4-20, Black
23 1732086 1 V-BELT, 54" Mower 103.50
24 2822138 1 KEY, Hi Pro, 1/4 x 7/8
25 1731974 1 PULLEY & HUB ASSEMBLY
26 1960568 2 CAPSCREW, Hex Head, 1/4-20 x 7/8, Black
27 1720182A 2 PULLEY ASSEMBLY, Side
28 1679161A 1 PULLEY ASSEMBLY, Center
29 1724537A 1 SUPPORT, Gearbox

tionItem Qt

Note

Footnotes:

Manual No. 7006465GT600 Diesel 4WD

GT600 SERIES

35

TP 400-5260-1-TC-N

54" Mower Deck - Height Adjustment & Roller Group

Manual No. 7006465 GT600 Diesel 4WD
TP 400-5260-1-TC-N

36

GT600 SERIES

54" Mower Deck - Height Adjustment & Roller Group

p

y

Part No Descri

1 2107031 2 CHAIN ASSEMBLY, 5 Links

2 1716986 1 HARNESS ASSEMBLY

3 1715885 1 MOTOR, Electric

4 1675198 1 BOLT, Tensioner

5 2860664 3 CAPSCREW, Hex Washer Head, Dog Point, 1/4-20 x 7/8

6 1715886 1 ADAPTER, Motor

7 1960685 1 NUT, Hex, Washer, KEPS, 1/4-20

8 1960581 1 PIN, Spring

9 1715887 1 HUB
10 1716998 1 WASHER, Special, Nylon
11 1733670A 2 BRACKET, Lift
12 1715891 1 BEARING, Thrust
13 1724524 1 ROD & SPACER ASSEMBLY
14 1960689 1 NUT, Hex, Top Lock, 1/2-13
15 1715881A 1 LEVER
16 1716424 1 COVER, Rod
17 1704314 1 FITTING, Lube
18 1715892 1 TRUNNION
19 1679166 1 SPACER
20 1733735 2 SPACER, Lift
21 7035835 2 POST, Anti-Scalp
22 1930651 1 NUT, Lock, 3/8-16
23 1700184 1 GAGE WHEEL
24 1920415 2 CAPSCREW, 3/8-18 x 1.25
25 2860681 6 NUT, Hex Top Lock, 3/8-16
26 1733732A 2 SUPPORT ASSEMBLY, Gage Wheel, L.H.
27 7091049 2 NUT, WING, 3/8-16
28 7029265 2 BOLT, Gage Wheel
29 1664847 8 CAPSCREW, Hex Washer Head, 5/16-18 x 3/4
30 1720147A 4 STRAP
31 1960687 2 NUT, Hex Flange Lock, ESNA, 3/8-16
32 1733674 2 CHAIN, 8 Link
33 1931350 2 CARRIAGE BOLT, 3/8-16 x 1
34 1960489 1 CARRIAGE BOLT, 1/2-13 x 2-1/2
35 1920397 2 NUT, Hex, Esna Lock, 1/4-20
36 1704116A 1 BRACKET, Height of Cut
37 1924856 2 CAPSCREW, Hex Washer Head, Taptite, 5/16-18 x 1/2

tionItem Qt

Note

Footnotes:

Manual No. 7006465GT600 Diesel 4WD

GT600 SERIES

37

TP 400-5260-1-TC-N

54" Mower Deck - Height Adjustment & Roller Group

Manual No. 7006465 GT600 Diesel 4WD
TP 400-5260-1-TC-N

38

GT600 SERIES

54" Mower Deck - Height Adjustment & Roller Group

p

y

Part No Descri

38 1720643A 1 INDICATOR, Height of Cut
40 1921960 2 CAPSCREW, Hex, 1/4-20 x 1.00
41 1922755 2 WASHER, Flat 3/8
42 1611705 2 SPACER
43 1960353 4 WASHER, Plain, 1/4
44 1922014 4 NUT, Hex, Jam, 5/8-18
45 1924366 2 WASHER, 5/8
46 1960074 1 CLIP, Hair Pin
47 1725201A 1 TRUNION
48 1722819 1 PIN, Yoke, Drilled, 1/2 x 2
49 1722507 1 STUD, 5/8-18 x 8-9/16
50 1725296A 1 ARM & TUBE ASSEMBLY
51 1725092 1 RING, Retaining, External, 1
52 1919394 1 WASHER, 1
53 1717075 2 PIN
54 2176012 3 PIN, Spring
55 1715872 1 ROD
56 1724528A 1 HITCH
57 1921971 2 CAPSCREW, Hex Head, 3/8-16 x 1-3/4
58 1924356 2 WASHER, 3/8
59 1726089 2 SPACER
60 1724523A 1 HITCH ASSEMBLY
61 1919438 2 NUT, Esna Lock, 5/16-18
62 1733774A 1 BRACKET, Lift, R.H.
63 1733733A 1 ROCKER, Shaft Assembly
64 1727612A 1 GAGE, Wheel Assembly, R.H.
65 1733775A 1 BRACKET, Lift, L.H.
66 2825094 1 WIRE TIE

tionItem Qt

Note

Footnotes:

Manual No. 7006465GT600 Diesel 4WD

GT600 SERIES

39

TP 400-5260-1-TC-N

54" Mower Deck - Housing, Arbors & Blades Group

Manual No. 7006465 GT600 Diesel 4WD
TP 400-5260-1-TC-N

40

GT600 SERIES

54" Mower Deck - Housing, Arbors & Blades Group

p

y

Part No Descri

1 1705449 1 DEFLECTOR, Plastic

2 1960353 2 WASHER, Plain, 1/4

3 1723323 2 CAP, Spring End

4 1920397 2 NUT, Hex, Lock ESNA, 1/4-20, Black

5 1706709 1 ROD, Deflector, Front

6 1720184D 1 COVER, Arbor, RH (Red)

7 1720623 4 CLIP, Spring

8 1929000 4 SCREW Hex Head, Taptite,1/4-20 x 3/8

9 1720186D 1 COVER, Arbor LH (Red)
10 1919326 1 WASHER, Plain, 5/16
11 1918199 2 WASHER, Lock, 7/16
12 1933263 2 WASHER, 7/16
13 7101082 1 SPRING, Torsion
14 1657969 3 SHIELD, Bearing Upper, Arbor
15 1655729A 3 HOUSING, Arbor, Top
16 1676278 3 ARBOR SHAFT & BEARING ASSEMBLY (Includes Ref. Nos. 17

& 18)
17 2108202 6 BEARING, Ball, 3/4 x 1-3/4 x 5/8
18 1676277 3 ARBOR SHAFT
19 2823471 6 CAPSCREW, Hex Head, 7/16-14 x 1-1/4, G8
22 1687177 1 HOUSING ASSEMBLY, 54" Legacy XL (Red)
23 1707335 3 GASKET, Foam
24 1703273A 3 ASSEMBLY, Housing, Bottom (Includes Ref. No. 25)
25 1704314 3 FITTING, Lube
26 1700230 3 WASHER, Shim
27 1725921 2 BLADE, Mower, 20-1/2
28 1679711 3 WASHER, Spline
29 1656916 3 WASHER, Spring
30 1657528 3 RING, Self Locking
31 1655777 3 ADAPTER, Blade
32 1700229 3 SHIELD, Grass
33 1664847 16 CAPSCREW, Hex Head, Taptite, 5/16-18x 3/4, Black
34 1960684 3 NUT, Hex, KEPS, 5/16-18, Black
35 1720962A 1 BAFFLE, Front, Anti-Blowout
36 1931333 2 CARRIAGE BOLT, 5/16-18 x 3/4
37 1725922 1 BLADE, Mower, 16
38 1720497 2 SPINDLE, Assembly
39 1716353 2 WHEEL, Gauge

tionItem Qt

Note

Footnotes:

Manual No. 7006465GT600 Diesel 4WD

GT600 SERIES

41

TP 400-5260-1-TC-N

54" Mower Deck - Housing, Arbors & Blades Group

Manual No. 7006465 GT600 Diesel 4WD
TP 400-5260-1-TC-N

42

GT600 SERIES

54" Mower Deck - Housing, Arbors & Blades Group

p

y

Part No Descri

40 1960020 2 WASHER, Plain 1/2
41 1703805 4 KLIP, Ring
42 1716346 2 SPRING
43 1960033 1 PIN, Hairpin
44 1960698 2 CARRIAGE BOLT, 1/4-20 x 1, Black
45 1960518 2 NUT, Push
46 1724976A 1 BAFFLE, Discharge
47 1704873 1 CLAMP, Wire
48 1925205 1 CAPSCREW, Hex Head, 5/16-18 x 5/8, Black

tionItem Qt

Note

Footnotes:

Manual No. 7006465GT600 Diesel 4WD

GT600 SERIES

43

TP 400-5260-1-TC-N

3-Point Hitch Group

Manual No. 7006465 GT600 Diesel 4WD
TP 400-5260-1-TC-N

44

GT600 SERIES

3-Point Hitch Group

p

y

Part No Descri

1 1716422 1 BALL JOINT & STUD ASSEMBLY, R.H., Upper
2 1716425 1 TURNBUCKLE, 5/8-18 x 2-1/2
3 1922014 1 NUT, Hex, Jam, 5/8-18
4 1724829 1 CLEVIS ASSEMBLY
5 1725049 7 PIN, Clevis, 5/8 x 2-1/2
6 1960033 9 CLIP, Hair Pin
7 1921969 2 CAPSCREW, Hex Head, 3/8-16 x 1-1/2
8 1700312A 2 CHAIN, 16 Link

9 2156306 2 PIN, Round Head, 3/4 x 1-1/2
10 1724769 2 LINK & BALL JOINT ASSEMBLY
11 2176012 3 PIN, Spring
12 1724763 1 ROD ASSEMBLY, Lift
13 1919439 2 LOCKNUT, Hex, Nylock, 3/8-16
14 1960355 8 LOCKNUT, Hex, 1/2-13
15 1724826A 2 SUPPORT, Inner, Pin
16 1920328 8 CAPSCREW, Hex Head, 1/2-13 x 1-1/2
17 1724809 1 CLEVIS ASSEMBLY, Fixed
18 2860743 1 NUT, Hex Top Lock, 1/2-13, Yellow
19 1700419 1 STUD & BALL JOINT ASSEMBLY, R.H.
20 1960297 1 NUT, Jam, 3/4-10
21 1700479 1 TUBE & PIN ASSEMBLY, Upper
22 1725244 1 PIN, Clevis, Rear
23 1725235 1 BALL JOINT & STUD ASSEMBLY
24 1724758A 1 HITCH ASSEMBLY
25 1725281 1 ROD, Hitch
26 1726412A 2 CLAMP, Upper Link .162 Diameter, Stainless, Black
27 1960667 2 Screw, Hex Lock Flange, 5/16-18 x 1
28 1960684 2 NUT, Hex, Conical Washer, 5/16-18

tionItem Qt

Note

Footnotes:

Manual No. 7006465GT600 Diesel 4WD

GT600 SERIES

45

TP 400-5260-1-TC-N

Decals Group

Manual No. 7006465 GT600 Diesel 4WD
TP 400-5260-1-TC-N

46

GT600 SERIES

Decals Group

p

y

Part No Descri

1 1722806 1 DECAL, Ignition Switch Symbols, White/Black

2 1718025 1 DECAL, Automatic Control Traction

3 1722814 1 DECAL, Tunnel Cover, Danger Slopes/Blades

3 1734027 1 DECAL, Tunnel Cover, Danger Slopes/Blades (Export)

3 1726923 1 DECAL, Tunnel Cover

5 1727013 1 DECAL, Drive Belts, Mower Blades (Export)

5 1725573 1 DECAL, Drive Belts, Mower Blades

6 1720454 1 DECAL, Touch Up Paint, Orange, Black, Red

7 1723296 2 DECAL, Protective Sticker

8 ----- 1 * LABEL, Decibel, Power Mass

9 ----- 1 * DECAL, I.D. Plate
10 ----- 1 * DECAL, Patent
12 1725776 1 DECAL, Transmission Release Valve
14 1704276 1 DECAL, Danger Do Not Put Hands/Feet in Mower
16 ----- 1 * DECAL, OPEI Certified
17 1722791 1 DECAL, 54", Silver on Black with Stripe
18 1704277 1 DECAL, Danger Do Not Operate without Deflector
19 1717583 1 DECAL, Height of Cut (Export)
19 1721197 1 DECAL, Height of Cut
20 1733763 1 DECAL, Snapper, 4WD Diesel, R.H.
21 1733764 1 DECAL, Snapper, 4WD Diesel, L.H.
22 1725571 1 DECAL, Throttle Speed Silver/Black
23 1727089 1 DECAL, Danger 4WD Tip Over On Slopes
24 1726045 1 DECAL, Rotating Fan Blades
25 1725603 1 DECAL, Hydraulic Lift
26 1725544 1 DECAL, PTO Selector Position
27 1725575 1 DECAL, Danger, Rotating Parts
28 1731955 1 DECAL, Snapper, Silver/Black
29 1733762 2 DECAL, GT600 27HP Snapper
30 1731419 1 DECAL, Snapper Steering Wheel Icon

tionItem Qt

Note

Footnotes:

Note: * Not a service part.

Manual No. 7006465GT600 Diesel 4WD

GT600 SERIES

47

TP 400-5260-1-TC-N

Electrical Group - 27HP Briggs & Stratton Diesel

Manual No. 7006465 GT600 Diesel 4WD
TP 400-5260-1-TC-N

48

GT600 SERIES

Electrical Group - 27HP Briggs & Stratton Diesel

p

y

Part No Descri

1 1715923 1 HEADLIGHT

2 1717649 2 BULB, Headlight, Halogen

3 1726997 1 HARNESS, Headlight

4 2172434 1 CLIP, Wire

5 1708007 1 CLAMP, Wire 3/8 Diameter

6 1701011 12 TIE, Self Locking 7 in. Long

7 1686734 1 SWITCH ASSEMBLY, Ignition 5/8-32, 6 Pin INDAK

8 1960547 1 LOCKWASHER, Internal Tooth, 5/8, Thin

9 1717549 1 NUT, Hex Flange 5/8-32 Ignition Switch
10 1717550 1 COVER, Ignition Switch, Black
11 1717163 1 KEYS, Set of 2
12 1716329 1 SWITCH, Electric Lift, 6 Terminal
13 1724967 1 PANEL, Instrument (Includes Ref. Nos. 14, 15 & 16)
14 1717634 10 BULB, Instrument Panel
15 1729948 10 SEAL, Lamp Socket Plug
16 1722061 10 HOLDER, Bulb, Instrument Panel (Includes Ref. No. 15)
17 1960578 4 SCREW, Hex Washer Head, Thread Cutting, #12-24 x 5/8
18 1725534 1 BREAKER, Circuit 12VOLT 10AMP
19 1665238 1 BREAKER, Circuit 12VOLT 20AMP with Tab
20 1726556 1 MODULE, RMO
21 1726557 1 KEY, RMO Module, Plastic
22 1722887 1 SWITCH, PTO Push/Pull, Yellow
23 1726829 2 RELAY, 12VOLT 5 Blade
24 1933896 1 NUT, Hex Lock 10-24 with Nylock Insert, NC3B
25 1960589 1 SCREW, Round Head Phillips #10-24 x 3/4
26 1726829 1 RELAY, Glow Plug
27 1726776 1 HARNESS, Main Diesel
28 1719680 2 COVER, Wire, Black, Vinyl
29 1928919 2 NUT, Hex & Washer Assembly, KEPS
30 1719311 1 BREAKER, Circuit 30AMP 12VOLT
31 1701011 3 TIE, Self Locking 15 in. Long
32 2122023 1 COVER, Terminal Red
33 1725263 1 CABLE, Battery, # 4 x 10 in Long, Black
34 2820426 1 LOCKWASHER, External Tooth 5/16
35 1918266 1 WASHER, 3/8
36 2850017 1 CAPSCREW, Hex Head M08-1.25 x 16MM
37 1713534 1 INSULATOR, Battery Terminal, Red

tionItem Qt

Note

Footnotes:

Manual No. 7006465GT600 Diesel 4WD

GT600 SERIES

49

TP 400-5260-1-TC-N

Electrical Group - 27HP Briggs & Stratton Diesel

Manual No. 7006465 GT600 Diesel 4WD
TP 400-5260-1-TC-N

50

GT600 SERIES

Electrical Group - 27HP Briggs & Stratton Diesel

p

y

Part No Descri

38 1725262 1 CABLE, Battery, # 4 x 15 in Long, Red
39 1917356 1 LOCKWASHER, Spring 5/16
40 2860433 1 NUT, Hex Flange M08-1.25
41 1724588 1 BOOT, Cable Terminal
42 1686714 1 BATTERY, 12 Volt 6 Cell, 500 CCA
43 1727679 1 HARNESS, Rear
44 1933737 4 SCREW, Hew Washer Head Slot, #10-24 x 5/8
45 1717050 1 SWITCH, Push Button, Cuise Control
46 1701521 1 SWITCH, Push Button, Foot Pedal
47 1960591 4 NUT, Hex KEPS #10-24
48 1716987 1 HARNESS ASSEMBLY, Power Outlet
49 1732004 1 SWITCH, Push Button (No) Regent
50 1726810A 1 BRACKET, Switch Mounting, Reverse Pedal
51 1929000 3 CAPSCREW, Hex Head Taptite, 1/4-20 x 3/8
52 1724963 1 HARNESS, Trasnmission, PTO Lights (540 PTO Only)
53 1654634 2 SWITCH, Interlock Ball Check 5/16 (540 PTO Only)
54 1716951 1 SWITCH, Headlights, 2 Terminal
55 1715915 2 TAIL LIGHT ASSEMBLY
56 1717650 2 BULB, Tail Light
57 1725212 1 SWITCH, Rocker, Solenoid Select
58 1725302 1 POWER OUTLET, 12VOLT with Dust Cap
59 1704351 3 FASTENER, Panel
60 1733112 1 CABLE, 6 X 15 LG (2) Ring Terminals, Black
61 2827187 1 SCREW, Hex Washer HD, TAPTT 3/8-16 x 1
62 2820427 1 LOCKWASER, External Tooth, 3/8, Yellow

tionItem Qt

Note

Footnotes:

Manual No. 7006465GT600 Diesel 4WD

GT600 SERIES

51

TP 400-5260-1-TC-N

Parts Manual fo

r

GT600 Diesel 4WD

3 Point Hitch Tractor

GT600 SERIES

IT IS THE POLICY OF BRIGGS & STRATTON CORP TO IMPROVE ITS

PRODUCTS WHENEVER IT IS POSSIBLE AND PRACTICAL TO DO SO.

WE RESERVE THE RIGHT TO MAKE CHANGES OR ADD

IMPROVEMENTS AT ANY TIME WITHOUT INCURRING ANY

OBLIGATION TO MAKE SUCH CHANGES ON PRODUCTS

Briggs & Startton Yard Power Products Group
Copyright © 2007
Milwaukee, WI USA. All Rights Reserved

Briggs & Startton Corporation

Revision 1,

McDonough, GA, 30253 U.S.A.

8/31/2007

Manual No. 7006465

TP 400-5260-1-TC-N
