Snapper Series 0, Series 4 User Manual
Specifications and Main Features
- Series denotement: Series 0 – produced in 1991, Series 1 and 2 – produced in 1993 and Series 4 (produced pre-1995)
- Mower Units (examples):
- Mower Units of Series 0: PMA7360, PMA7480
- Mower Units of Series 1 and 2: PMA7361, PMA7362, PMA7481, PMA7482
- Mower Units of Series 4: PMA7364, PMA7484, PMA7524, PMHA7364, PMHA7484
- Available models with axial choppers with a width of cut of 32’’ to 61’’
- Specified Operational Torque Values for capscrews (for instance, 1/4"-20 capscrew at 5-8 Ft-Lb and 1/2"-13 capscrew at 39-75 Ft-Lb)
- Recommend Cutting Performance: All Mower Units are cut less than 1/4" to 3/8" near the front after leveling and adjustments
- General Workshop Safety Tips: Not running engine within confined spaces, not using gasoline as solvent, and so forth
Frequently Asked Questions
Q: What range of cutting widths is offered for the SNAPPER PRO Mower Units?
A: The cutting width for each unit varies from 32’ to 61’as per the model.
Q: What are the procedures for cut posture adjustment?
A: The angle adjustment for cutter can be done by adding spacers from below the cutter housing to above the cutter pulley, this allows an increase of cutting hight by 1/4".
Q: What can be done in case it is observed that the mower unit is not cutting accordingly?
A: Cam attachment shafts should be checked for an imbalanced number of blade microns, low pressure in caster tires, misplaced mower deck positioning, slipping belts, or stiff blade spindles alongside dull blades.
Q: What is the frequency of lubrication required for the caster swivel shafts?
A: The caster swivel shafts gon’ need lubrication in a frequency of once every week.
Q: What can be done in case the blade brake is incapable of bringing the mower blades to a halt in a timely manner?
A: During routine maintenance, the blade brake should be inspected for worn-out or broken components and replaced when necessary as needed. Adjustments are in order, if the blades have not been arrested within 7 seconds with the use of the brake.
