Snapper PP71250KW User Manual
Specifications and Main Features
- Model Numbers: PL71250KW PP71250KW, PL7140KWV PP7140KWV, PMA7360, PMA7480
- Engine Type: Kawasaki
- Power Capacity: 12.5 H.P.
- Cutting Height Adjustment: Ranges from 1” to 4.5” allowing for cutting height adjustment.
- Traction Type: Hydro-static traction drive
- Wheel Configuration: Caster wheels, adjustable
- Safety Features: Operator presence control and emergency stop mechanism
- Blade Engagement: Engagement is by use of a blade clutch lever it’s done manually.
- Transmission Types: Peerless 700 series transmission
- Tire Pressure Specifications: REAR TYRES (MAX 28PSI) FRONTS TYRES (MAX 50PSI)
- Maintenance Requirements: Routine service every 100 hours and lubrication are required with periodic adjustment to restore lubrication.
- Weight: As not specified
- Warranty: Stipulations for Original Purchaser A Limited Warranty Commences for 1 Year
Frequently Asked Questions
Q: Please explain how to start the Snapper PRO736 & PRO748 mower?
A: Rotate the petrol tank shut off valve to the on position, pull both traction levers to the handlebar close which locks them on park brake position , shift the transmission shift lever on neutral, then push the pistol grip outwards disengaging the clutch , then lastly pulling the recoil starter handles would start the engine.
Q: The mower doesn’t come on, how do I fix this?
A: Ensure that the ignition is turned key on as well as confirming that the fuel tank has fuel, and that the fuel shut off, as well as the throttle control of the engine, is set to fast.
Q: How frequent do you recommend I carry out maintenance on my mower equipment?
A: Implementing maintenance once every 100 hours of use is a good practice, this should also include checking and adjusting of blade brakes, lubrication of moving parts, and an inspection of the engine and the transmission.
Q: Is there any possibility to change the height from which the lawn mower will cut the grass?
A: Moving the mower deck position on the power unit, changing the blade position on the cutter spindle shaft, and adjusting the caster wheel spacers will all allow for height adjustment while cutting.
Q: How am I supposed to react to a situation where the mower is vibrating more than usual?
A: Verify if there is any damage or looseness because these could be a problem, in addition to checking all they bolts and ensuring that the blade is properly balanced and fitted.
