Snapper MGT2000H User Manual

Specifications and Main Features

  • Model: MGT2000H
  • Type: Garden Tractor
  • Engine: Twin-cylinder
  • Drive System: Hydrostatic
  • Fuel Capacity: 31.23 Stan. which takes unleaded gasoline with a minimum octane number of 87
  • Motor Oil:
  • 10W30 (year-round over 0⁰C)
  • 5W30 (under 0⁰C)
  • Differential Lubricant: 80/90 gear lube (2 pints)
  • Final Drive Lubricant: 80/90 gear lube (1.5 pints for each)
  • Hydraulic Oil: Dexton II hydraulic oil (2.25 gallons)
  • Tire Pressure: Fuel load to drive type and conditions (are recommended in the sheets)
  • Maximum Slope Operation: 15 degrees
  • Maximum Speed:
  • Forward: 0-7.4 miles per hour
  • Reverse: 0-3 miles per hour
  • Weight: N/A
  • Brake Type: Rear wheel brakes are individually controlled
  • Standard Fittings: including
  • Hitch block front
  • Weldment middle lift
  • Towing bar rear
  • Optional Fittings:
  • Hitch three point
  • Auxiliary hydraulic lift
  • PTO Rear
  • Controls:
  • Seat - adjust
  • Steering Wheel
  • Switched Off and On
  • Knob Choke
  • Hand Throttle
  • Pedal Neutral
  • Control Lever Motion
  • Two brake pedals
  • Pull knob Parking Brake
  • Hydraulic Lever Lift Control
  • Switch Blade
  • Gauge Characteristics:
  • Hourmeter
  • PTO Light
  • Oil Pressure Light
  • Battery Light
  • Security Features:
  • Interlocks for Operator Safety
  • Turn Off Blades Before Dismounting

Frequently Asked Questions

Q: What Type Of Fuel is Used with the Mgt2000h?

A: An unleaded petrol of not less than octane 87 should do the trick.

Q: How Often Should the Engine Oil be Replaced?

A: Engine oil and the filter should be replaced after five hours of the first use and afterwards every hundred hours.

Q: What Slope Maximum does the Tractor Operate At?

A: The tractor is not recommended for use in slopes more than fifteen degrees.

Q: In Cold Conditions How Should I Start The Engine?

A: Lighter oil taking into consideration of the temperature should be used, during standard operations after the Engine has been allowed to warm up should the choke be pushed in.

Q: The Tractor Serial Number, Where to Locate Them?

A: The serial number can be found situated on the left side of the frame.

Q: What Is The Best Way To Assess The Battery?

A: Once a week or after every 25 hours of use battery connections and electrolyte levels should be evaluated.

Q: What maintenance is necessary after every use?

A: Check the air cleaner, engine oil, fuel, and inspect for debris or damage.

Q: Can additional implements be fitted on the tractor?

A: The tractor can be fitted with a range of implements such as a 3point hitch and rear PTO.

Q: How do I go about cleaning of the air filter? Invite 683.travel?

A: Take off and wash and drip dry the foam precleaner. The paper air filter should be substituted if it is dirty or damaged.

Q: Is it permissible to use the tractor when under the influence of drugs of any sort?

A: No, a person who has taken alcohol or drugs should not operate the tractor.
