Parts Manual fo
r
PREMIUM RIDER 33" (84cm)
LT75 SERIES
MODEL
7800352, LT75RD-CE
7800353, LT75RD-CE, FR
7800356, LT75RD-CE
7800357, LT75RD-CE, FR
Briggs & Stratton Yard Power Products Group
535 Macon Road
McDonough, GA, 30253 U.S.A.
800-935-2967
Revision IR,
Manual No. 885194
TP 400-5415-IR-RE-N9/12/2008
s
PAGE GROUP
4
6
10
12
16
18
20
22
24
28
30
Wheel & Tire Group
Steering Group
Seat, Body, Dash & Fuel Tank Group
Drive Group
Engine & Electric Clutch Group - Briggs & Stratton
Electrical Group
Decals Group - Brand & Model
Decals Group - Common & Safety
33" Mower Deck - Housing & Arbors Group
33" Mower Deck - Arbors Group
Bagger Group
Table Of Content
PREMIUM RIDER 33" (84cm)
LT75 SERIES
Manual No. 885194
3
TP 400-5415-IR-RE-N
Wheel & Tire Group
Manual No. 885194
TP 400-5415-IR-RE-N
PREMIUM RIDER 33" (84cm)
4
LT75 SERIES
Wheel & Tire Group
p
y
Part No Descri
1 885029 2 REAR TIRE ASSY - 16/650
2 885028 2 FRONT TIRE ASSY - 13/500
3 721318 4 H U B CA P
4 720010 2 RING- -E-.750D-.050T
5 722620 4 WASHER - FLAT
7 722617 4 WASHER - FLAT
8 720390 2 PIN-COTTER.13D-.880L
tionItem Qt
Note
Footnotes:
Manual No. 885194 PREMIUM RIDER 33" (84cm)
LT75 SERIES
5
TP 400-5415-IR-RE-N
Steering Group
Manual No. 885194
TP 400-5415-IR-RE-N
PREMIUM RIDER 33" (84cm)
6
LT75 SERIES
Steering Group
p
y
Part No Descri
1 729275 1 COVER, INTEGRA
2 727627 1 ST WHEEL INTEGRA - HARD
3 885022 1 FOOTREST CAP
4 885106 1 SHAFT, STEERING - LONG
5 720563 1 BELLOWS
6 720173 2 WASHER.54.81 16G FLT
7 885007 1 FOOTREST SLEEVE - SNAPPER
8 885002 1 FOOTREST - PLASTIC
9 721950A 1 SUPPORT, STEERING
10 721966 1 BEARING, UPPER STEERING
11 726537A 2 LINK, DRAG
12 885036A 1 BRACKET, SUPPORT
13 729342A 1 BRACKET, AXLE FRONT
14 885081A 1 AXLE AND SPINDLE ASSY
15 721949A 1 RACK, STEERING
16 721971 1 GEAR, PINION
17 721973 2 ROLLER
18 721970 1 BEARING, LOWER STEERING
19 727201A 1 PLATE, GEAR MTG.
20 720107 2 BOLT, SHOULDER
21 720145 2 NUT.31-18 HEX FLG CTRLKZ
22 722584 1 WASHER-1-1.3 16G FLT
23 722622 2 WASHER, .328X1.062X.062 Z
24 720211 2 BOLT-HEX.31-24X2.75 PLAIN
25 720142 2 NUT.38-16 HEX FLG CTRLKZ
26 722395 2 NUT.31-24 FLANGELOCK Z-BL
27 722580 2 WASHER.39-1. 14G FLT
28 722858 13 SCREW-.312-18X.75
29 720117 1 RING- -E-1.00D-.050T
30 727875 2 BUMPER-FRONT AXLE EPDM
31 720042 1 SCREW-THD.FORM.HEX.
32 722593 1 WASHER.34-1. 2 11G FL
33 722863 1 SCREW
34 720192 2 BOLT-HEX.38-16x1.50 Z
35 885110 1 T HROTTLE CONT RO L
36 722841 2 SCREW Z/BL CHROMATE
37 885118 1 TINNERMAN CLIP
tionItem Qt
Note
Footnotes:
Manual No. 885194 PREMIUM RIDER 33" (84cm)
LT75 SERIES
7
TP 400-5415-IR-RE-N
Steering Group
Manual No. 885194
TP 400-5415-IR-RE-N
PREMIUM RIDER 33" (84cm)
8
LT75 SERIES
Steering Group
p
y
Part No Descri
38 885102 1 FLOORMAT, RH
39 885103 1 FLOORMAT, LH
40 885223A 1 STEERING SUPPORT PLATE
41 721246 1 RETAINER - SPRING
42 729075 2 SCREW-TAPPING 10-16
tionItem Qt
Note
Footnotes:
Manual No. 885194 PREMIUM RIDER 33" (84cm)
LT75 SERIES
9
TP 400-5415-IR-RE-N
Seat, Body, Dash & Fuel Tank Group
Manual No. 885194
TP 400-5415-IR-RE-N
10
PREMIUM RIDER 33" (84cm)
LT75 SERIES
Seat, Body, Dash & Fuel Tank Group
p
y
Part No Descri
1 885003D 1 FOOTREST
2 885001A 1 SEAT SUPPORT
3 885009A 1 SEAT SUPPORT COVER
4 885091A 1 DECK LIFT INDEX ASSY
5 885002 1 FOOTREST - PLASTIC
6 885004 1 BODY - PLASTIC - SNAPPER
7 885021 1 BATTERY COVER - SNAPPER
8 885010A 1 SEAT BRACKET
9 885060A 1 SEAT SUPT. BRKT. RH
10 885061A 1 SEAT SUPT. BRKT. LH
11 722411 2 SPRING - SEAT
12 720049 4 BOLT-CRG.31-18X1.12
13 720139 4 NUT
14 720095 6 BOLT, SHOULDER SELF TAP
15 720102 2 BOLT-SHD .32-18X .375D
16 720145 4 NUT
17 720159 2 WASHER
18 720358 4 SCREW
19 9075071 1 SEAT - PREMIUM
20 885108 4 SHOULDER BOLT
21 885100A 1 LEVER - SEAT ADJ.
22 722858 8 SCREW-.312-18X.75
23 722866 6 SCREW .25-20x0 .59 HEX
24 720049 2 CARRIAGE BOLT
25 721403 2 HOSE CLAMP - YELLOW
26 729007 1 FUEL LINE
27 727333 1 FUEL CAP
28 885006 1 TANK, FUEL 1.6 GAL.
29 885101A 1 BRACKET, FUEL TANK
30 720048 2 BOLT, CARRIAGE 1/4"
31 720132 2 NUT
32 720173 2 WASHER .54.81 16G FLT
33 721609 1 FOAM BAFFLE
34 720140 4 NUT
35 885215 1 GRIP - SEAT ADJ. LEVER
tionItem Qt
Note
Footnotes:
Manual No. 885194 PREMIUM RIDER 33" (84cm)
LT75 SERIES
11
TP 400-5415-IR-RE-N
