Snapper ER195517B User Manual

Safety Instructions & Operator’s Manual for

EUROPEAN

19” STEEL DECK

WALK MOWERS

SERIES 17

MODEL

ER195517B

MODEL NUMBER EXPLANATION

E R 19 55 17 B

MODEL DESIGNATION BRIGGS & STRATTON CUTTING WIDTH SERIES DESIGNATION ENGINE HORSE POWER

E – European Model 17 - Series Designation R – Recycling Model 55 – 5.5 HP (Engine Horse Power)

19 – 19” Cutting Width B – Briggs & Stratton Engine

Thank you for buying a SNAPPER Product! Before operating your Walk Behind, read this manual carefully and pay particular attention to the “IMPORTANT SAFETY INSTRUCTIONS” on Pages 2 & 3. Remember that all power equipment can be dangerous if used improperly. Also keep in mind that SAFETY requires careful use in accordance with the operating instructions and common sense.

MANUAL No. 7-5722 (I.R. 5/6/03)

IMPORTANT SAFETY INSTRUCTIONS

WARNING: This powerful cutting machine is capable of amputating hands and feet and can throw objects that can cause injury and damage! Failure to comply with the follow ing SAFETY instructions could result in serious injury or death to the operator or other persons. The owner of the machine must understand these instructions and must allow only persons who understand these instructions to operate machine. Each person operating the machine must be of sound mind and body and must not be under the influence of any substance, which might impair vision, dexterity or judgment. If you have any questions pertaining to your machine which your dealer cannot answer to your satisfaction, call or write the Customer Service Department at SNAPPER, McDonough, Georgia 30253. Phone: (1-800-935-2967).

PROTECTION FOR CHILDREN

Tragic accidents can occur if the operator is not alert to the presence of children. Children are often attracted to the machine and the mowing activity. Never assume that children will remain where you last saw them.

1. KEEP children out of the mowing area and under the watchful care of a responsible adult.

2. DO NOT allow children in yard when machine is operated and turn machine OFF if anyone enters the area.

3. DO NOT allow pre-teenage children to operate machine.

4. ALLOW only responsible adults & teenagers with mature judgment under close adult supervision to operate machine.

5. DO NOT pull mower backwards unless absolutely necessary. LOOK and SEE behind and down for children, pets and hazards before and while backing.

6. USE EXTRA CARE when approaching blind corners, shrubs, trees, or other objects that may obscure vision.

SLOPE OPERATION

1. Slopes are a major factor related to slip and fall accidents, which can result in severe injury. All slopes require extra caution. If you feel uneasy on a slope, DO NOT mow it.

2. Mow across slopes, never up-and-down. Exercise extreme CAUTION when changing directions on slopes. DO NOT mow steep slopes or other areas where stability or traction is in doubt.

3. Use extra care with grass catchers or other attachments; these affect the handling and the stability of the machine.

PREPARATION

1. Read, understand, and follow instructions and warnings in this manual and on the mower, engine and attachments. Know the controls and the proper use of the mower before starting.

2. Only mature, responsible persons shall operate the machine and only after proper instruction.

PREPARATION

(Continued From Previous Column)

3. Data indicates that operators age 60 and above, are involved in a large percentage of mowerrelated injuries. These operators should evaluate their ability to operate the mower safely enough to protect themselves and others from serious injury.

4. Handle fuel with extra care. Fuels are flammable and vapors are explosive. Use only an approved fuel container. DO NOT remove fuel cap or add fuel with engine running. Add fuel outdoors only with engine stopped and cool. Clean spilled fuel and oil from machine. DO NOT smoke.

5. Check the area to be mowed and remove all objects such as toys, wire, rocks, limbs and other objects that could cause injury if thrown by blade or interfere with mowing. Also note the location of holes, stumps, and other possible hazards.

6. Keep people and pets out of the mowing area. Immediately, STOP Blade, Stop engine and Stop mower if anyone enters the area.

7. Check shields, deflectors, switches, blade controls and other safety devices frequently for proper operation and location.

8. Make sure all safety decals are clearly legible. Replace if damaged.

9. Protect yourself w hen mowing and wear safety glasses, long pants and substantial footwear. DO NOT mow barefooted or with sandals.

10. Know how to STOP blade and engine quickly in preparation for emergencies.

11. Use extra care when loading or unloading the machine into a trailer or truck.

12. Check grass catcher components frequently for signs of wear or deterioration and replace as needed to prevent injury from thrown objects going through weak or torn spots.

SAFE HANDLING OF GASOLINE

To avoid personal injury or property damage, use extreme care in handling gasoline. Gasoline is extremely flammable and the vapors are explosive

1. Extinguish all cigarettes, cigars, pipes and other sources of ignition.

2. Use only an approved fuel container.

IMPORTANT SAFETY INSTRUCTIONS

SAFE HANDLING OF GASOLINE

(Continued From Previous Page)

3. DO NOT remove fuel cap or add fuel with the engine running. Allow the engine to cool before refueling.

4. DO NOT refuel the machine indoors.

5. DO NOT store the machine or fuel container inside where there is an open flame, spark or pilot light such as on a water heater or other appliances.

6. DO NOT fill fuel containers inside a vehicle or on a truck or trailer bed with a plastic liner. Always place the containers on the ground away from the vehicle before filling.

7. Remove gas-powered equipment from the vehicle or trailer and refuel it on the ground. If this is not possible, then refuel equipment using a portable container, rather than a gasoline dispenser nozzle.

8. DO NOT start gas powered equipment in enclosed vehicles or trailers.

9. Keep the nozzle in contact with the rim of the fuel tank or container opening at all times until fueling is complete. DO NOT use a nozzle lock-open device

10. If fuel is spilled on clothing, change clothing immediately.

11. DO NOT overfill a fuel tank. Replace fuel cap and tighten securely.

OPERATION

1. DO NOT put hands or feet near or under rotating parts. Keep clear of discharge area while engine is running.

2. STOP engine when crossing gravel drives, walks, or roads, and under any conditions where thrown objects might be a hazard.

3. Mow only in daylight or good artificial light.

4. DO NOT operate mower while under the influence of alcohol or drugs.

5. After striking a foreign object or if mower vibrates abnormally, STOP the engine, disconnect and secure spark plug wire. Inspect the mow er for any damage and repair the damage.

6. DO NOT mow near drop offs, ditches or embankments. Operator could lose footing or balance.

7. STAY ALERT for holes and other hidden hazards. Tall grass can hide obstacles. Keep away from ditches, washouts, culverts, fences and protruding objects.

8. DO NOT mow on wet grass. Always be sure of your footing. Keep a firm hold on the handle and walk, never run. Slipping could cause injury.

9. DO NOT leave the machine w ith the engine running. STOP BLADE and STOP ENGINE before leaving the operators position for any reason.

10. Before cleaning, repairing or inspecting make certain engine, blade and all moving parts have STOPPED. Disconnect and secure spark plug wire away from plug to prevent accidental starting.

OPERATION

(Continued From Previous Column)

11. STOP engine and wait until the blade comes to complete STOP before removing grass bag and/or clearing grass.

12. DO NOT operate mower without the entire grass catcher or guards in place. DO NOT point discharge at people, passing cars, windows or doors.

13. Slow down before turning.

14. Watch out for traffic when near or crossing roadways.

15. DO NOT operate engine in enclosed areas. Engine exhaust gases contain carbon monoxide, a deadly poison.

MAINTENANCE AND STORAGE

1. DO NOT store mower or fuel container inside where fumes may reach an open flame, spark or pilot light such as in a water heater, furnace, clothes dryer or other gas appliance. Allow engine to cool before storing machine in an enclosure. Store fuel container out of reach of children in a well ventilated, unoccupied building.

2. Keep mower and engine free of grass, leaves or excess grease to reduce fire hazard and engine overheating.

3. When draining fuel tank, drain fuel into an approved container outdoors and away from open flame.

4. Keep all bolts, especially blade bolts, nuts and screws properly tight. Check that all cotter pins are in proper position.

5. Always provide adequate ventilation when running engine. Engine exhaust gases contain carbon monoxide, a deadly poison.

6. Service engine and make adjustments only when engine is stopped. Removed spark plug wire from spark plug and secure wire away from spark plug to prevent accidental starting.

7. DO NOT change engine governor speed settings or overspeed engine.

8. Check grass bag assembly frequently for wear or deterioration to avoid thrown objects and exposure to moving parts. Replace with new bag if loose seams or tears are evident. Replace slider or bag adapter if broken or cracked.

9. Mower blades are sharp and can cut. Wrap the blades or wear heavy leather gloves and use CAUTION when handling them.

10. DO NOT test for spark by grounding spark plug next to spark plug hole; spark plug could ignite gas exiting engine.

11. Have machine serviced by an authorized SNAPPER dealer at least once a year and have the dealer install any new safety devices.

12. Use only genuine SNAPPER replacement parts to assure that original standards are maintained.

TABLE OF CONTENTS

IMPORTANT SAFETY INSTRUCTIONS................................................2-3

TABLE OF CONTENTS.............................................................................4

SECTION 1 - FAMILIARIZATION..............................................................5

SECTION 2 - OPERATING INSTRUCTIONS......................................... 6-9

Pre-start Checklist......................................................................................................6

Starting & Stopping Engine & Blades................................................................... 6-7

Handle Height Adjustment.........................................................................................7

Cutting Height Adjustment ........................................................................................8

Recycling Operation...................................................................................................8

Recycling Cover Installation/Removal......................................................................8

Discharge Deflector Installation................................................................................9

SECTION 3 - MAINTENANCE INSTRUCTIONS................................10-11

Change Engine Oil....................................................................................................10

Check Mower Blade..................................................................................................10

Service - Annually.....................................................................................................11

Engine ...................................................................................................................11

Air Filter ................................................................................................................11

Engine Oil .............................................................................................................11

Storage Procedure....................................................................................................11

SECTION 4 - ADJUSTMENTS AND REPAIR.........................................12

Mower Blade Replacement ......................................................................................12

Mower Blade Sharpening.........................................................................................12

TROUBLESHOOTING.............................................................................13

SERVICE SCHEDULE.............................................................................14

Maintenance/Replacement Parts.............................................................................14

DECAL IDENTIFICATION ..................................................................15-16

WARRANTY ............................................................................................17

PRIMARY MANTENANCE .................................................................18-21

The figures and illustrations in this manual are provided for reference only and may differ from your specific model. Contact your Snapper dealer if you have questions.

IMPORTANT

Section 1 - FAMILIARIZATION

RECOIL ROPE GUIDE

ROPE START HANDLE

KNOB

BLADE CONTROL

PRIMER BULB

KNOB

OIL FILL CAP & DIPSTICK

FUEL FILLER CAP

AIR CLEANER

RECYCLING COVER

PRIMER SEE INSET

1.1 INTRODUCTION

This manual has been prepared for the operators of the SNAPPER WALK BEHIND MOWERS. Its purpose, aside from recommending operating and routine service requirements, is to promote safety through the use of accepted operating practices. Read, Understand and Follow the “IMPORTANT SAFETY INSTRUCTIONS” on Pages 2 & 3 of this manual and all safety messages on the mower and attachments before operating the mower.

FIGURE 1.1

1.2 NOMENCLATURE

MUFFLER

CUTTING DECK

CUTTING HEIGHT ADJUSTMENT BUSHINGS

The nomenclature information above, Figure 1.1, shows the essential parts of the SNAPPER WALK BEHIND MOWERS. It is recommended that all operators of the mower become thoroughly familiar with the controls, parts and operation of the mower before operating. Specific details involving the engine are found in the separate engine owner’s manual. Study these manuals before operating and keep both handy for future reference.

Section 2 - OPERATING INSTRUCTIONS

2.1 PRE-START CHECK LIST

Make the following checks and perform the service required before each start-up.

2.1.1. Check guards, deflectors, grass bag, adapter and covers to make sure all are in place and securely tightened.

2.1.2. Check blade control to insure it works freely. See Figure 2.1.

BLADE CONTROL

2.1.5. Add fuel to tank after pushing the mower

outside where fumes can safely dissipate. Make sure cap is tightened after refueling. Refer to Engine Owners Manual for fuel specifications.

2.1.6. Clean exterior surfaces of cutting deck and engine of any accumulation of spilled fuel, dirt, grass, oil, etc. Keep engine air intake screen and cooling fins clear at all times.

2.2 STARTING & OPERATION

2.2.1. ENGINE & BLADE

The engine speed is pre-set for optimum mowing performance and is not adjustable. An engine primer is provided to assist when starting a cold engine. The primer should not be required when restarting a hot engine.

1. Push primer bulb three times to start a cold engine. NOTE: Primer should not be required when restarting a hot engine. See Figure 2.3.

IMPORTANT: Stop the engine (and blade) by releasing

the blade control.

FIGURE 2.1

2.1.3. Check cutting height. Adjust to desired height.

2.1.4. Check engine oil and add oil as needed to

bring level up to the full mark. Refer to Engine Owner’s Manual for oil specifications. See Figure 2.2.

CHECK ENGINE OIL

FIGURE 2.2

PUSH PRIMER BULB THREE TIMES

FIGURE 2.3

2. Pull blade control against handle.

3. Pull rope start handle to crank engine.

4. After engine starts, allow a brief warm-up until

engine runs smooth.

Section 2 - OPERATING INSTRUCTIONS

2.3 STOPPING

Stop engine and blade by releasing the blade control. See Figure 2.4.

RELEASE BLADE CONTROL TO STOP ENGINE & BLADE

BLADE CONTROL

2.4 HANDLE HEIGHT ADJUSTMENT

The height of the mower handle can be adjusted as follows:

1. Loosen the two nuts on the inside of each of the lower handles as shown in Figure 2.5.

2. Move the handle up or down to the desired height.

3. Retighten all nuts securely after adjustment.

LOOSEN NUTS TO ADJUST HANDLE HEIGHT

FIGURE 2.4

WARNING

DO NOT attempt any maintenance, adjustments or service with engine and blade running. STOP engine and blade. Disconnect spark plug wire and secure away from spark plug. Engine and components are HOT. Avoid serious burns, allow sufficient time for all components to cool.

FIGURE 2.5
