Snapper 98900 User Manual

REPLACES FORM MS−0235−06/30/2008

Illustrated Parts List

Model Series

098900

TYPE NUMBERS

0101 through 2254.

TABLE OF CONTENTS

Air Cleaner 5. . . . . . . . . . . . . . . . . . . . . . . . .

Blower Housing/Shrouds 7. . . . . . . . . . . .

Brake 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Camshaft 3. . . . . . . . . . . . . . . . . . . . . . . . . . .

Carburetor 4. . . . . . . . . . . . . . . . . . . . . . . . . .

Controls 5. . . . . . . . . . . . . . . . . . . . . . . . . . . .

Crankcase Cover/Sump 3. . . . . . . . . . . . . .

Crankshaft 3. . . . . . . . . . . . . . . . . . . . . . . . .

Cylinder 2. . . . . . . . . . . . . . . . . . . . . . . . . . . .

Cylinder Head 2. . . . . . . . . . . . . . . . . . . . . .

Exhaust System 6. . . . . . . . . . . . . . . . . . . .

Flywheel 7. . . . . . . . . . . . . . . . . . . . . . . . . . .

Fuel Supply 4. . . . . . . . . . . . . . . . . . . . . . . . .

Gasket Set − Engine 2. . . . . . . . . . . . . . . . .

Gasket Set − Valve 2. . . . . . . . . . . . . . . . . .

Governor Spring 5. . . . . . . . . . . . . . . . . . . .

Ignition 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Lubrication 2. . . . . . . . . . . . . . . . . . . . . . . . .

Operator’s Manual 2. . . . . . . . . . . . . . . . . .

Piston/Rings/Connecting Rod 3. . . . . . . .

Rewind Starter 7. . . . . . . . . . . . . . . . . . . . . .

Warning Label 2. . . . . . . . . . . . . . . . . . . . . .

FORM MS−0235−08/08/2008

FILE IN SECT. 2 OF SERVICE MANUAL

098900

PRINTED IN U.S.A.

All rights reserved. No part of this material may be reproduced or transmitted,
in any form or by any means, electronic or mechanical, including photocopying,
recording or by any information storage and retrieval system, without permission
in writing from Briggs & Stratton Corporation.

COPYRIGHT by BRIGGS & STRATTON CORPORATION

098900

358 ENGINE GASKET SET

1330 REPAIR MANUAL1058 OPERATOR’S MANUAL 1319 WARNING LABEL

REQUIRED when replacing parts
with warning labels affixed.

3

7

9

1095 VALVE GASKET SET

7 9

5

12

20

51A

51

883

7

883

163

444

524

426

200

1

2

3

668

523A

524

718

50

870 871869

529

11

847

523

287

51

842

525

287

524

54

8

9

10

635

13

50A

54

337

51A

383

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

0235−2 Assemblies include all parts shown in frames. 08/08/2008

2

25

098900

26

16

741

16A

741A

34

33

718A

40

40

35

36

377

357

24

45

45

16B

741

718A

27

28

27

29

32

46A

46

374

43

4

12

20

15

22

22A

4A

20

12

444

178

20A

1143

101

83

743

721

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

0235−3 Assemblies include all parts shown in frames. 08/08/2008

3

098900

365

90

976

913

106

1218

393

394

163

612

390

529

97

130

633

617

724

181

180

957

190A

957A

957B

190

670

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

0235−4 Assemblies include all parts shown in frames. 08/08/2008

4

098900

265

267

265A

271

265B

269

268

201

188

270

209

334

426

333

851

211

222A

621222

356

356A

24

578

536

643

535A

534

535

163

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

0235−5 Assemblies include all parts shown in frames. 08/08/2008

5

098900

300

883

303

298

300A

81

613

832

R

832A

836

836

832B

836A

676

676A

677

677

994

346

676B

677

676C

677

772

772

772B

236

745

745A

925

923

236A

729

923A

621

933

815

922

772A

1208

621

922A

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

0235−6 Assemblies include all parts shown in frames. 08/08/2008

6

930

930A

098900

332

74

455

930B

1036 EMISSIONS LABEL

678

57

56

921

969

75

257

66

71

67

70

68

73

608

1210

55

1211

23

459

456

689

73B

363

65

592

58

60

597

58A

304A

304

78

37

305

37A

60A

59

78

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

0235−7 Assemblies include all parts shown in frames. 08/08/2008

7

098900

REF. PART REF. PART REF. PART

NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION

1 699653 Cylinder Assembly
2 399269 Kit−Bushing/Seal

(Magneto Side)

3 K299819S Seal−Oil

(Magneto Side)

4 698691 Sump−Engine

(Used After Code Date

02111200).

−−−−−− Note −−−−−−
395384 Sump−Engine

(Used Before Code
Date 02111300).

4A Sump−Engine

(NO LONGER
AVAILABLE)

5 790169 Head−Cylinder
7 KΔ698717 Gasket−Cylinder Head
8 791781 Breather Assembly
9 KΔ695890 Gasket−Breather

10 691666 Screw

(Breather Assembly)

11 691245 Tube−Breather

12 K692218 Gasket−Crankcase

(Standard)
(.015” Thick)

−−−−−− Note −−−−−−

K270895 Gasket−
Crankcase
(.005” Thick)
K270896 Gasket−
Crankcase
(.009” Thick)

13 691640 Screw

(Cylinder Head)

15 691680 Plug−Oil Drain
16 796212 Crankshaft

(Used After Code Date

08071300).
Used on Type No(s).
1602, 1615, 1650,
1651, 2000, 2001,
2002, 2011, 2012,
2030, 2031, 2033,
2063, 2069, 2070,
2139, 2210, 2239,
2249, 2252.

−−−−−− Note −−−−−−
796211 Crankshaft

(Used After Code Date

08071300).
Used on Type No(s).
1616, 2013, 2032,
2065, 2078, 2086,
2087, 2100, 2101,
2166, 2178, 2180,
2250, 2251, 2253,

2254.
796213 Crankshaft
(Used After Code Date

08071300).
Used on Type No(s).

1618.

16A 692990 Crankshaft

Used on Type No(s).
0899, 1110, 2026,
2027, 2028, 2029,
2066, 2077, 2085,
2093, 2097, 2099,
2109, 2125, 2163,
2179, 2192, 2194,
2198, 2203, 2207,
2209, 2215, 2229,
2231, 2242, 2243,
2244, 2246.

−−−−−− Note −−−−−−
692990 Crankshaft

(Used Before Code
Date 08071400).
Used on Type No(s).
1602, 1615, 1650,
1651, 2000, 2001,
2002, 2011, 2012,
2030, 2031, 2033,
2063, 2069, 2070,
2139, 2210, 2239,
2249, 2252.

793062 Crankshaft
Used on Type No(s).
0115, 0120, 0123,
0128, 0129, 0131,
0132, 0144, 0145,
0151, 0197, 0198,
0306, 0308, 0312,
0313, 0320, 0321,
0323, 0326, 0337,
0338, 0344, 0347,
0350, 0353, 0354,
0358, 0366, 0371,
0373, 0374, 0378,
0380, 0381, 0383,
0386, 0388, 0389,
0395, 0401, 0837,
1144, 1316, 1516,
1644, 2023, 2044,
2045, 2047, 2064,
2098, 2137, 2144,
2147, 2181, 2186,
2213, 2216, 2227,
2232, 2235, 2236,
2238, 2240.
793062 Crankshaft
(Used Before Code
Date 08071400).
Used on Type No(s).
1616, 2013, 2032,
2065, 2078, 2086,
2087, 2100, 2101,
2166, 2178, 2180,
2250, 2251, 2253,

2254.
692991 Crankshaft
Used on Type No(s).
1603, 1607, 1612,
2010, 2024, 2025,
2050, 2202, 2211,
2212, 2214, 2217,
2222, 2224, 2225,
2228, 2234, 2237,
2247, 2248.
692991 Crankshaft
(Used Before Code
Date 08071400).
Used on Type No(s).

1618.
791342 Crankshaft
Used on Type No(s).

2103.

K Engine Gasket Set−Reference 358 Δ Valve Gasket Set−Reference 1095

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

0235−8 Assemblies include all parts shown in frames. 08/08/2008

8

098900

REF. PART REF. PART REF. PART

NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION

16B 492748 Crankshaft

−−−−−− Note −−−−−−
496069 Crankshaft

Used on Type No(s).
0130, 2030.
690805 Crankshaft
Used on Type No(s).
0125, 0139, 0140,
0143, 0148, 0167,
0322, 0328, 0364,
0402, 0866, 0891,
1303, 1304, 1305,
1318, 1518, 2043.
493618 Crankshaft
Used on Type No(s).
0119, 0137, 0141,
0341, 0359, 0382.

20 K391483S Seal−Oil

(PTO Side)

20A K691952 Seal−Oil

(PTO Side)
(Auxiliary PTO)

22 692551 Screw

(Crankcase
Cover/Sump)
(1 3/16” Long)

22A 691108 Screw

(Crankcase
Cover/Sump)
(3/4” Long)

23 795549 Flywheel

−−−−−− Note −−−−−−
795695 Flywheel

(Used After Code Date

08012900).
Used on Type No(s).
1602, 1603, 2069,
2250, 2251.
690843 Flywheel
(Used Before Code
Date 08013000).
Used on Type No(s).
1602, 1603, 2069,
2250, 2251.
690843 Flywheel
Used on Type No(s).
0115, 0132, 0137,
0138, 0139, 0141,
0143, 0145, 0328,
0345, 0346, 0347,
0358, 0364, 0369,
0382, 0386, 0395,
0890, 1302, 1303,
1304, 1305, 1446,
2043, 2044, 2045,
2047, 2050, 2146,
2147, 2186, 2222,
2224, 2228.

24 222698S Key−Flywheel
25 790908 Piston Assembly

(Standard)
(Used After Code Date

04111400).

−−−−−− Note −−−−−−
699657 Piston

Assembly
(Standard)
(Used After Code Date
030803000 and Before
Code Date 04111500).
790908 Piston
Assembly
(Standard)
(Used After Code Date
92092800 and Before
Code Date 03080400).
793214 Piston
Assembly
(Standard)
(Used Before Code
Date 92092900).

792532 Piston
Assembly
(.020” Oversize)
(Used After Code Date

92092800).
298906 Piston
Assembly
(.020” Oversize)
(Used Before Code
Date 92092900).

26 790909 Ring Set

(Standard)
(Used After Code Date

04111400).

−−−−−− Note −−−−−−
699658 Ring Set

(Standard)
(Used After Code Date
030803000 and Before
Code Date 04111500).
498680 Ring Set
(Standard)
(Used After Code Date
92092800 and Before
Code Date 03080400).
298982 Ring Set
(Standard)
(Used Before Code
Date 92092900).

795134 Ring Set
(.020” Oversize)
(Used After Code Date

04111400).
498682 Ring Set
(.020” Oversize)
(Used After Code Date
96020500 and Before
Code Date 04111500).
298984 Ring Set
(.020” Oversize)
(Used Before Code
Date 96020600).

27 691588 Lock−Piston Pin
28 699659 Pin−Piston

(Standard)
(Used After Code Date

03080300).

−−−−−− Note −−−−−−
298909 Pin−Piston

(Standard)
(Used Before Code
Date 03080400).

K Engine Gasket Set−Reference 358 Δ Valve Gasket Set−Reference 1095

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

0235−9 Assemblies include all parts shown in frames. 08/08/2008

9

098900

REF. PART REF. PART REF. PART

NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION

29 699655 Rod−Connecting

(Standard)

32 691664 Screw

(Connecting Rod)

33 296676 Valve−Exhaust
34 296677 Valve−Intake
35 690520 Spring−Valve

(Intake)

36 690520 Spring−Valve

(Exhaust)

37 690482 Guard−Flywheel

(Carburetor Side)

37A 691209 Guard−Flywheel

(Muffler Side)

40 692194 Retainer−Valve
43 698690 Slinger−Governor/Oil

(Used After Code Date

02110400).

−−−−−− Note −−−−−−
691983 Slinger−

Governor/Oil
(Used Before Code
Date 02110500).

45 691762 Tappet−Valve
46 691998 Camshaft

46A 690645 Camshaft

(Clockwise)
Used on Type No(s).
0123, 0165, 0371,
0373, 0374, 0378,
0865, 1351, 1551,
1651, 2065, 2178.

−−−−−− Note −−−−−−
690644 Camshaft

(Counterclockwise)
Used on Type No(s).
0114, 0117, 0121,
0126, 0127, 0133,
0147, 0149, 0166,
0317, 0319, 0390,
0394, 0396, 0399,
0407, 0849, 1350,
1650, 2026, 2027,
2049, 2066, 2194,
2196, 2207, 2211.

50 699644 Manifold−Intake

(Used After Code Date

03080300).

50A 693446 Manifold−Intake

(Used Before Code
Date 03080400).

51 K699649 Gasket−Intake

(Used After Code Date

03080300).

51A 270345S Gasket−Intake

(Used Before Code
Date 03080400).

54 691111 Screw

(Intake Manifold)

55 692144 Housing−Rewind

Starter

56 281336S Pulley−Starter
57 490179 Spring−Rewind Starter
58 697316 Rope−Starter

(88 5/8” Long)

58A 691921 Rope−Starter

(70” Long)

59 396892 Insert−Grip
60 691915 Grip−Starter Rope

60A 393152 Grip−Starter Rope

65 690837 Screw

(Rewind Starter)

66 399671 Clutch−Starter

(Used Before Code
Date 97060600).

67 394897 Housing−Clutch

(Used Before Code
Date 97060600).

68 691604 Ball−Clutch

(Used Before Code
Date 97060600).

70 691945 Ratchet−Clutch
71 691359 Cover−Ratchet

(Used Before Code
Date 97060600).

73 699850 Screen−Rotating

(Used After Code Date

97060500).

73B 691725 Screen−Rotating

(Used Before Code
Date 97060600).

74 690345 Screw

(Rotating Screen)

75 691736 Washer

(Flywheel)

78 692198 Screw

(Flywheel Guard)

81 691179 Lock−Muffler Screw
83 691240 Shaft−Auxiliary Drive

−−−−−− Note −−−−−−
690506 Shaft−Auxiliary

Drive
Used on Type No(s).
0396, 1350, 1650,

2196.
690514 Shaft−Auxiliary
Drive
Used on Type No(s).
0147, 0317, 0319,
0390, 0399, 0407,

2207.
691249 Shaft−Auxiliary
Drive
Used on Type No(s).
0117, 0133, 0149,
0371, 0373, 0374,
0378, 0849, 2049,
2178, 2211.

90 498809 Carburetor

(Used After Code Date

96051900).

−−−−−− Note −−−−−−
494775 Carburetor

(Used Before Code
Date 96052000).

97 691931 Shaft−Throttle
101 691623 Pin−Shaft
106 691901 Seat−Inlet
130 691190 Valve−Throttle
163 K271139S Gasket−Air Cleaner
178 690398 Cover−Drive Gear
180 494406 Tank−Fuel
181 493982S Cap−Fuel Tank
188 692198 Screw

(Control Bracket)

190 691640 Screw

(Fuel Tank)
(1 3/4” Long)

190A 691108 Screw

(Fuel Tank)
(9/16” Long)

200 691912 Blade−Governor
201 690347 Link−Air Vane

K Engine Gasket Set−Reference 358 Δ Valve Gasket Set−Reference 1095

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

0235−10 Assemblies include all parts shown in frames. 08/08/2008

10

098900

REF. PART REF. PART REF. PART

NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION

209 691297 Spring−Governor

(Used After Code Date

96051900).

−−−−−− Note −−−−−−
262760 Spring−

Governor
(Used Before Code
Date 96052000).
690251 Spring−
Governor
(Used After Code Date

96051900).
Used on Type No(s).
0120, 0121, 0123,
0125, 0126, 0127,
0128, 0131, 0140,
0141, 0144, 0147,
0148, 0150, 0151,
0166, 0167, 0197,
0312, 0313, 0314,
0317, 0319, 0320,
0325, 0347, 0353,
0366, 0367, 0370,
0379, 0380, 0382,
0383, 0386, 0388,
0390, 0392, 0393,
0396, 0397, 0398,
0399, 0401, 0891,
1144, 1315, 1316,
1318, 1350, 1351,
1515, 1516, 1518,
1551, 1612, 1615,
1616, 1618, 1644,
1650, 1651, 2002,
2012, 2023, 2024,
2025, 2026, 2027,
2044, 2066, 2078,
2086, 2087, 2093,
2097, 2100, 2101,
2125, 2139, 2147,
2166, 2179, 2180,
2181, 2186, 2192,
2193, 2194, 2196,
2197, 2198, 2209,
2212, 2214, 2227,
2229, 2231, 2232,
2234, 2235, 2243,

2253.

692211 Spring−
Governor
(Used Before Code
Date 96052000).
Used on Type No(s).
0120, 0121, 0123,
0125, 0126, 0127,
0128, 0131, 0140,
0147, 0148, 0150,
0151, 0166, 0167,
0197, 0312, 0313,
0314, 0317, 0319,
0320, 0325, 0353,
0358, 0362, 0366,
0367, 0370, 0371,
0373, 0379, 0380,
0383, 0388, 0390,
0392, 0393, 0394,
0396, 0397, 0398,
0399, 0401, 1144,
1305, 1315, 1316,
1318, 1350, 1351,

2222.
690252 Spring−
Governor
(Used After Code Date

96051900).
Used on Type No(s).
0115, 0129, 0132,
0137, 0138, 0139,
0143, 0145, 0307,
0322, 0328, 0345,
0346, 0352, 0363,
0364, 0368, 0369,
0372, 0377, 0381,
0395, 0402, 0890,
1302, 1303, 1304,
1446, 1472, 1477,
2043, 2050, 2146,
2168, 2224.
262942 Spring−
Governor
(Used Before Code
Date 96052000).
Used on Type No(s).
0115, 0132, 0137,
0139, 0143, 0307,
0322, 0328, 0352,
0363, 0364, 0368,
0372, 0377, 0381,
0395, 0402, 1304.

262943 Spring−
Governor
(Used Before Code
Date 96052000).
Used on Type No(s).
0129, 0138, 0345,
0346, 0369, 1302,

1303.
690254 Spring−
Governor
(Used After Code Date

96051900).
Used on Type No(s).
0358, 0362, 0371,
0394, 1305, 2013,
2045, 2047, 2147,
2178, 2250, 2251.
692531 Spring−
Governor
(Used Before Code
Date 96052000).
Used on Type No(s).
0141, 0309, 0376,
0385, 0403.
691861 Spring−
Governor
(Used After Code Date

96051900).
Used on Type No(s).
0373, 0374, 0378,

2238.
690253 Spring−
Governor
(Used Before Code
Date 96052000).
Used on Type No(s).
0373, 0374, 0378.
690250 Spring−
Governor
Used on Type No(s).
1602, 1603, 2032,
2063, 2069, 2077,
2163E1, 2202, 2210,
2215, 2225, 2246.
692698 Spring−
Governor
Used on Type No(s).
2222, 2228.
691862 Spring−
Governor
Used on Type No(s).
0145, 2163B1.

K Engine Gasket Set−Reference 358 Δ Valve Gasket Set−Reference 1095

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

0235−11 Assemblies include all parts shown in frames. 08/08/2008

11

098900

REF. PART REF. PART REF. PART

NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION

211 691859 Spring−Governed Idle

222 691446 Bracket−Control

Used on Type No(s).
0101, 0110, 0114,
0117, 0119, 0121,
0123, 0125, 0126,
0127, 0128, 0129,
0130, 0131, 0133,
0134, 0140, 0142,
0147, 0148, 0149,
0150, 0151, 0165,
0166, 0167, 0168,
0197, 0198, 0199,
0300, 0310, 0312,
0313, 0314, 0317,
0319, 0320, 0321,
0323, 0325, 0330,
0334, 0337, 0341,
0350, 0355, 0360,
0361, 0362, 0365,
0370, 0371, 0376,
0379, 0380, 0383,
0388, 0390, 0391,
0392, 0393, 0394,
0396, 0397, 0398,
0399, 0404, 0407,
0810, 0837, 0849,
0865, 0866, 0891,
0899, 1110, 1607,
2000, 2001, 2002,
2010, 2023, 2024,
2025, 2026, 2027,
2029, 2030, 2031,
2032, 2042, 2049,
2065, 2066, 2068,
2093, 2097, 2098,
2099, 2100, 2103,
2110, 2125, 2137,
2139, 2179, 2180,
2181, 2191, 2192,
2193, 2194, 2196,
2197, 2198, 2204,
2207, 2209, 2211,
2212, 2213, 2217,
2229, 2234, 2235,
2236, 2237, 2238,
2240, 2244, 2247,
2248, 2253, 2254.

222A 691445 Bracket−Control

236 691867 Link−Lockout

(Used After Code Date

97071300).

236A 691826 Link−Lockout

(Used Before Code
Date 97071400).

257 691660 Screw

(Starter Clutch)

265 692179 Clamp−Casing
265A 690798 Clamp−Casing
265B 691024 Clamp−Casing

267 691044 Screw

(Casing Clamp)

268 691025 Casing−Control Wire

(Cut To Required
Length)

269 691026 Wire−Control

(Cut To Required
Length)

270 691027 Nut

(Control Wire Casing)

271 691028 Lever−Control

287 691002 Screw

(Dipstick Tube)

298 691720 Locknut−Muffler/Elbow

300 692307 Muffler

(Super Lo Tone)

300A 394569S Muffler

(Round Lo Tone)

303 690291 Elbow−Exhaust

304 691484 Housing−Blower

(Compliance Engines)

−−−−−− Note −−−−−−
692536 Housing−

Blower
(Non Compliance
Engines)
Used on Type No(s).
1602, 1603, 2011,
2012, 2028, 2033,
2044, 2045, 2047,
2050, 2063, 2064,
2065, 2069, 2070,
2077, 2078, 2085,
2086, 2087, 2101,
2109, 2144, 2147,
2163, 2178, 2186,
2202, 2203, 2210,
2214, 2215, 2216,
2222, 2224, 2225,
2227, 2228, 2232,
2239, 2242, 2243,
2246, 2249, 2250,
2251, 2252.

304A 694051 Housing−Blower

(Non Compliance
Engines)
Used on Type No(s).

2013.

305 692198 Screw

(Blower Housing)

332 690662 Nut

(Flywheel)

333 793281 Armature−Magneto
334 691061 Screw

(Magneto Armature)

337 802592S Plug−Spark

−−−−−− Note −−−−−−
697451 Plug−Spark

Used on Type No(s).
1615, 1650, 1651,
2002, 2011, 2012,
2013, 2023, 2024,
2031, 2032, 2033,
2063, 2064, 2065,
2069, 2070, 2085,
2086, 2087, 2093,
2097, 2101, 2103,
2137, 2139, 2163,
2166, 2178, 2180,
2181, 2186, 2192,
2194, 2210, 2216,
2225, 2232, 2246,
2248, 2249, 2251,

2253.

346 690661 Screw

(Spark Arrestor)

356 692390 Wire−Stop

356A 398808 Wire−Stop

357 692191 Key−Drive Pulley
358 794209 Gasket Set−Engine
363 19069 Puller−Flywheel
365 790029 Screw

(Carburetor)

374 691074 Washer

(Camshaft)

K Engine Gasket Set−Reference 358 Δ Valve Gasket Set−Reference 1095

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

0235−12 Assemblies include all parts shown in frames. 08/08/2008

12

098900

REF. PART REF. PART REF. PART

NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION

377 692193 Key−Woodruff
383 89838S Wrench−Spark Plug
390 691839 Spring−Choke

Diaphragm

393 691837 Screen−Carburetor
394 795083 Diaphragm−Carburetor

(Used After Code Date

07080800).

−−−−−− Note −−−−−−
495770 Diaphragm−

Carburetor
(Used Before Code
Date 07080900).

426 691107 Screw

(Governor Blade)

444 K691868 Gasket−Drive Gear

Cover

455 691236 Cup−Flywheel
456 692299 Plate−Pawl Friction
459 281505S Pawl−Ratchet
523 692040 Dipstick

523A 691913 Dipstick

524 K691876 Seal−Dipstick Tube
525 691320 Tube−Dipstick
529 692189 Grommet
534 691417 Screw

(Air Cleaner)

535 698369 Filter−Air Cleaner

Foam
(Used After Code Date

02101000).

535A 272235S Filter−Air Cleaner

Foam
(Used Before Code
Date 02101100).

536 698472 Cleaner−Air
578 398153 Wire Assembly
592 690800 Nut

(Rewind Starter)

597 691696 Screw

(Pawl Friction Plate)

608 690101 Starter−Rewind

(70” Rope)

−−−−−− Note −−−−−−
499706

(88 5/8” Rope)
499925 Starter−
Rewind
(88 5/8” Rope)
Used on Type No(s).

0890.

Starter−Rope

612 496046S Tube−Pick Up

613 691413 Screw

(Muffler)

617 270344S Seal−O Ring

(Intake Manifold)

621 692310 Switch−Stop

633 691321 Seal−Choke/Throttle

Shaft
(Throttle)

635 66538S Boot−Spark Plug

643 691911 Retainer−Air Filter

668 692889 Spacer

(Cylinder)

670 691633 Spacer−Fuel Tank

(Non Compliance
Engines)
(13/16” Long)
(Used After Code Date

97071300).

−−−−−− Note −−−−−−
691631 Spacer−Fuel

Tank
(Compliance Engines)
(11/16” Long)
(Used Before Code
Date 97071400).

676 396548 Deflector−Muffler

Used on Type No(s).
0132, 0319, 0328,
0369, 2069.

676A 393760 Deflector−Muffler

Used on Type No(s).
0317, 0341, 0346,
0402, 0890, 1446,
2027, 2146, 2202,
2225, 2231.

676B 393756 Deflector−Muffler

Used on Type No(s).
0147, 0322, 0341,
0345, 0359, 0381,
0382, 1315, 1316,
1318, 1350, 1351,
1515, 1516, 1518,
1612, 1615, 1616,
1618, 1650, 1651,
2027, 2045, 2214.

676C 397931 Deflector−Muffler

Used on Type No(s).
0374, 0378, 2178,

2211.

677 690661 Screw

(Muffler Deflector)

678 691924 Spacer−Rewind
689 691855 Spring−Friction
718 690959 Pin−Locating

(Cylinder)

718A 499047 Pin−Locating

(Crankshaft)
(Used Before Code
Date 08071400).

721 690397 Stop−Shaft
724 697478 Retainer−Seal
729 690586 Clip−Wire
741 796210 Gear−Timing

(Used After Code Date

08071300).

741A 691805 Gear−Timing

(Used Before Code
Date 08071400).

743 690516 Gear−Drive

−−−−−− Note −−−−−−
691772 Gear−Drive

(Counterclockwise)
Used on Type No(s).
0114, 0117, 0121,
0126, 0127, 0133,
0147, 0149, 0166,
0317, 0319, 0390,
0394, 0396, 0399,
0407, 0849, 1350,
1650, 2026, 2027,
2049, 2066, 2194,
2196, 2207, 2211.

745 691146 Screw

(Brake)
(7/8” Long)

745A 690859 Screw

(Brake)
(1/2” Long)

772 691183 Screw

(Linkage Cover)
(3/4” Long)
(Top)

772A 690345 Screw

(Linkage Cover)
(7/16” Long)
(Front)

K Engine Gasket Set−Reference 358 Δ Valve Gasket Set−Reference 1095

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

0235−13 Assemblies include all parts shown in frames. 08/08/2008

13

098900

REF. PART REF. PART REF. PART

NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION

772B 691111 Screw

(Linkage Cover)
(1 1/8” Long)
(Front)

815 690324 Screw

(Band Brake Pivot)

832 699299 Guard−Muffler
832A 699670 Guard−Muffler
832B 790743 Guard−Muffler

836 690664 Screw

(Muffler Guard)
(13/32” Long)

836A 790745 Screw

(Muffler Guard)
(1/2” Long)

842 K691870 Seal−O Ring

(Dipstick Tube)

847 691440 Dipstick/Tube

Assembly

851 493880S Terminal−Spark Plug

869 699641 Seat−Valve

(Intake)
(Used After Code Date

03080300).

−−−−−− Note −−−−−−
691701 Seat−Valve

(Intake)
(Used Before Code
Date 03080400).

870 699642 Seat−Valve

(Exhaust)
(Used After Code Date

03080300).

−−−−−− Note −−−−−−
691702 Seat−Valve

(Exhaust)
(Used Before Code
Date 03080400).

871 699643 Bushing−Valve Guide

(Exhaust Valve)
(Used After Code Date

03080300).

−−−−−− Note −−−−−−
231348 Bushing−Valve

Guide
(Exhaust Valve)
(Used Before Code
Date 03080400).
63709 Bushing−Valve
Guide
(Intake Valve)

883 KΔ691880 Gasket−Exhaust
913 494409 Seat−
921 694044 Cover−Blower Housing

922 692135 Spring−Brake

922A 691809 Spring−Brake

923 691487 Brake

923A 394867 Brake

925 691349 Cover−Linkage

930 691330 Guard−Rewind
930A 690601 Guard−Rewind
930B 691348 Guard−Rewind

933 690428 Pivot−Band Brake

957 497929S Cap−Fuel Tank

957A 692050 Cap−Fuel Tank

Check Valve

Used on Type No(s).

2013.

(Used After Code Date

97071300).

(Used Before Code
Date 97071400).

(Used After Code Date

97071300).

(Black)

(Red)
Used on Type No(s).
0149, 0165, 0849,
1110, 2049, 2065.

957B 791129 Cap−Fuel Tank

(Black)
Used on Type No(s).
2011, 2050, 2224,

2228.

969 694046 Screw

(Blower Housing
Cover)
(2 1/3” Long)
Used on Type No(s).

2013.

976 694394 Primer−Carburetor
994 398067 Arrestor−Spark

1036 Label−Emissions

(Available From A
Briggs & Stratton
Authorized Dealer)

1058 277038 Operator’s Manual
1095 498526 Gasket Set−Valve
1143 691141 Screw

(Drive Gear Cover)

1208 691146 Screw

(Brake Bracket)

1210 499901 Pulley/Spring

Assembly
(Pulley)

1211 499901 Pulley/Spring

Assembly
(Spring)

1218 695866 Seal−

1319 794467 Label−Warning
1330 270962 Repair Manual

O Ring

(Carburetor)

K Engine Gasket Set−Reference 358 Δ Valve Gasket Set−Reference 1095

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

0235−14 Assemblies include all parts shown in frames. 08/08/2008

14
