Snapper 422023BVE User Manual

Parts Manual fo

r

E

E

REAR ENGINE RIDER

42" MOWER

SERIES 23

MODEL

421823BV
422023BV

COPYRIGHT ©2005
SNAPPER PRODUCTS, INC.
ALL RIGHTS RESERVED.

Revision 4,

McDonough, GA, 30253 U.S.A.

8/1/2005

Manual No. 7006154

TP 400-5020-4-RE-N

s

PAGE GROUP

4
6

8
10
12
16
18
20
22
24
26
28
30
32
34
38
40
44
46
48
50
52
54
56

WHEELS - FRONT
WHEELS - REAR
FRONT END, STEERING
FRONT END, STEERING (Water Bottle)
MAIN CASE PT.1
MAIN CASE PT.2
DIFFERENTIAL, R. H. FENDER
CHAIN CASE, L. H. FENDER
SMOOTH CLUTCH ASSEMBLY
MAIN CASE (Yoke View)
FUEL TANK AND OPERATORS SEAT
EXHAUST MUFFLER, ENGINE
DRIVE DISC ASSEMBLY
THROTTLE CONTROL
RAILS, LIFT ARMS, CAM LIFT PT.1
RAILS, LIFT ARMS, CAM LIFT PT.2
42" MOWER DECK ASSEMBLY PT.1
42" MOWER DECK ASSEMBLY PT.2
DECK COVER, BELTS, BLADE BRAKE
SPINDLE ASSEMBLY
DECALS
ELECTRICAL SYSTEMS (For 18 & 20HP Briggs)
WIRING SCHEMATIC for 18 & 20HP Briggs
SNAPPER REAR ENGINE RIDER ACCESSORIES

Table Of Content

SERIES 23

Manual No. 7006154REAR ENGINE RIDER

3

TP 400-5020-4-RE-N

WHEELS - FRONT

Manual No. 7006154 REAR ENGINE RIDER
TP 400-5020-4-RE-N

4

SERIES 23

WHEELS - FRONT

p

y

Part No Descri

1 7058943 2 ASSEMBLY, Front Tire & Rim (11.0”) (Complete) (Includes Items 2 thru 6)
2 7073563 1 TIRE, 11 x 4.00-4 (Kenda) per front tire ass'y.
3 7017146 1 RIM (For 11.0 x 4.0 x 4 Tire) per front tire ass'y.
4 7011807 2 BALL BEARING, Flange (3/4” I.D.) per front tire ass'y.
5 7012234 1 VALVE STEM, Snap In per front tire ass'y.
6 7014669 1 LUBE Fitting per front tire ass'y.
7 7010935 3 WASHER, .77 x 1.13 x .06 Flat per front tire ass'y.
8 7011022 1 HUB CAP per front tire ass'y.

9 7011032 1 FELT SEAL per front tire ass'y.
10 7031038 1 CAP, Dust per front tire ass'y.
11 7091516 1 COTTER PIN, 5/32 x 1” per front tire ass'y.
12 7010821 1 TUBE, Inner (For 4.10/3.50 x 4 Tire) per front tire ass'y.

tionItem Qt

Note

Footnotes:

Manual No. 7006154REAR ENGINE RIDER

SERIES 23

5

TP 400-5020-4-RE-N

WHEELS - REAR

Manual No. 7006154 REAR ENGINE RIDER
TP 400-5020-4-RE-N

6

SERIES 23

WHEELS - REAR

p

y

Part No Descri

1 7058951 2 ASSEMBLY, Rear Tire & Rim (Includes 2, 3, & 4)

2 7073584 1 TIRE, 16 x 6.50-8 (Kenda) (per rear tire ass'y)

3 7012163 1 RIM, Extra Wide (For 16/7.50 x 8 Tire) Was 17147 (per rear tire ass'y)

4 7012234 1 VALVE STEM, Snap In (per rear tire ass'y)

5 7012332 1 CLAMP, Right Hand (for 2” Hose) (per rear tire ass'y)

6 7091502 3 BOLT, 1/2-20 x 3/4” Lug, GR5 (per rear tire ass'y)

7 7031732 1 BOOT, Right Hand (per rear tire ass'y)

8 7011817 1 SEAL, Oil (per rear tire ass'y)

9 7040433 1 HUB, Rear Wheel R. H. (Weldment) (per right rear tire ass'y)
10 7023895 1 CAP, Hub (per rear tire ass'y)
11 7023522 1 CAP, Hub, L. H. (Long Axle) (per left rear tire ass'y)
12 7040434 1 HUB, Rear Wheel L. H. (Weldment) (per left rear tire ass'y)
13 7092062 1 NUT, 5/16-24 Hex Lock, GR C Was 11201 (per rear tire ass'y)
14 7011035 1 AXLE BOLT, 5/16-24 x 1-5/8” Tapered (Left Hand) (per left rear tire ass'y)
15 7011013 1 WHEEL BOLT, 5/16-24 x 2” Tapered (Right Hand) (per right rear tire ass'y)

tionItem Qt

Note

Footnotes:

Manual No. 7006154REAR ENGINE RIDER

SERIES 23

7

TP 400-5020-4-RE-N

FRONT END, STEERING

Manual No. 7006154 REAR ENGINE RIDER
TP 400-5020-4-RE-N

8

SERIES 23

FRONT END, STEERING

p

y

Part No Descri

1 7058030 1 ASSEMBLY, Steering Wheel (for 5/8” shaft) Includes item 2

2 7023781 1 LOGO, Steering Wheel

3 7013862 1 PIN, 1/4 x 1-1/2" Roll

4 7038243 1 LATCH, Parking Brake

5 7074131 1 CABLE, Clutch/Brake (55” long) used on 33” & 42” Models

6 7090122 2 WASHER, 3/8” Flat SAE

7 7011815 1 PAD, Clutch/Brake Pedal

8 7010694 1 BUSHING, Nylon

9 7047888 1 WELDMENT, Clutch/Brake Pedal
10 7010986 4 BEARING, Nylon
11 7046232 1 WELDMENT, Steering Shaft
12 7013321 4 BUSHING, Tie Rod
13 7012541 1 TIE ROD, Left Hand (9.91” long)
14 7041687 1 KING PIN Weldment, Left Hand
15 7012540 1 TIE ROD, Right Hand (9.91” long)
16 7041688 1 KING PIN Weldment, Right Hand
17 7053266 1 WELDMENT, Front Axle, Wide
18 7014048 2 FOOT PAD, Long
19 7015444 1 SPRING, Parking Brake Latch
20 7090183 2 WASHER, .66 x 1.31 x .09 Flat
21 7046158 2 BUSHING, Nylon
22 7011714 1 HAIR PIN 2-1/4”
23 7023667 1 FOAM COVER, Steering Shaft
24 7090296 1 PIN, 3/16 x 1” Cotter
25 7090122 2 WASHER, 3/8” Flat Was 91514
26 7091515 1 PIN, 3/16 x 1-1/2” Cotter Was 90753
27 7091516 2 PIN, 5/32 x 1” Cotter Was 90364
28 7010776 1 RING, 1/2” External Retaining (Heavy Duty)
29 7010746 2 RING, 3/4” External Retaining
30 7091598 2 PIN, 1/8 x 3/4” Cotter Was 90365
31 7010935 6 WASHER, .77 x 1.13 x .06 Flat
32 7023671 1 COVER, Steering Shaft
36 7072648 1 CABLE, Brake (29” long)
37 7034174 2 CONNECTOR, Cable
38 7091495 1 SCREW, 1/4-20 x 3/4” Hex Head Cap, GR5
39 7090372 1 NUT, 1/4-20 Hex Center Lock, GR5 or B

tionItem Qt

Note

Footnotes:

Manual No. 7006154REAR ENGINE RIDER

SERIES 23

9

TP 400-5020-4-RE-N

FRONT END, STEERING (Water Bottle)

Manual No. 7006154 REAR ENGINE RIDER
TP 400-5020-4-RE-N

10

SERIES 23

FRONT END, STEERING (Water Bottle)

p

y

Part No Descri

33 7074560 1 HOLDER, Bottle (Wire)
34 7090913 2 SCREW, #10-24 x 1/2” Hex Washer Self-Tap (Torx)
35 7074561 1 BOTTLE, Water

tionItem Qt

Note

Footnotes:

Manual No. 7006154REAR ENGINE RIDER

SERIES 23

11

TP 400-5020-4-RE-N

MAIN CASE PT.1

Manual No. 7006154 REAR ENGINE RIDER
TP 400-5020-4-RE-N

12

SERIES 23

MAIN CASE PT.1

p

y

Part No Descri

1 7053698 1 WELDMENT, Main Case (Commercial)

2 7033587 1 BUMPER (1-Piece) (42” Deck)

3 7037285 1 FENDER, Left Hand (Standard) see Chain Case, L.H. Fender

4 7090595 2 BOLT, 5/16-18 x 3/4” Hex Flange Lock, GR5

7 7047189 1 BRACKET, Drive Support

8 7091601 2 NUT, 5/16-18 Hex Flange Lock, GR5 Was 90585

9 7090793 4 SCREW, 5/16-18 x 3/4” Hex Washer Self-Tap
10 7023676 1 SHIFT LINK, Long
11 7041384 1 WELDMENT, Shift Arm
12 7033799 1 CROSS BRACE
13 7011018 1 SHFT LINK, Short (5/16-24 thread)
22 7074650 1 BUSHING, Pivot
23 7090391 1 WASHER, 5/16” Internal Tooth Lock
29 7090361 8 SCREW, 5/16-18 x 5/8” Hex Washer Self-Tap
30 7012652 1 CLIP, Wire
31 7034299 2 WING, Rear Deck
32 7028200 2 SWIVEL, Adjustable
33 7091272 7 FASTENER, 1/4” Ratchet
34 7091506 4 SCREW, 5/16-18 x 1-1/2” Hex Washer Self-Tap
35 7090238 4 SCREW, 5/16-24 x 1” Hex Head Cap, GR5
36 7011791 4 RETAINER, 5/16” Bolt
37 7090324 4 SCREW, 3/8-16 x 1” Hex Washer Self-Tap
38 7091315 5 WASHER, .32 x .58 x .08 Split Lock
39 7091297 5 NUT, 5/16-24 Hex, GR5
40 7027972 1 ASSEMBLY, Oil Valve
41 7028769 1 BELT GUIDE, 4216
42 7010969 1 NUT, 5/16-24 Flange Lock (Large)
43 7074946 1 PLATE, Engine (Kohler Engine)
44 7091503 2 HAIR PIN, 3/32 x 1-1/2”
45 7090188 2 WASHER, 5/16” Flat Was 91296
48 7091318 2 SCREW, 5/16-18 x 3/4” Hex Head Cap, GR5 Was 90206
49 7091513 1 SCREW, 5/16-24 x 1-3/4” Hex Head Cap, GR5
50 7073735 1 BRACKET, Switch
51 7090981 2 SCREW, #10-32 x 1/4” Hex Washer Self-Tap
52 7031100 1 TUBE CLAMP
53 7090358 1 SCREW, 5/16-24 x 2-1/2” Hex Head Cap, GR5
54 7071754 2 PLATE, Bumper Spacer

tionItem Qt

Note

Page for related parts

Footnotes:

Manual No. 7006154REAR ENGINE RIDER

SERIES 23

13

TP 400-5020-4-RE-N

MAIN CASE PT.1

Manual No. 7006154 REAR ENGINE RIDER
TP 400-5020-4-RE-N

14

SERIES 23

MAIN CASE PT.1

p

y

Part No Descri

55 7074210 1 BRACKET, Belt Adjuster
56 7091198 2 SCREW, 3/8-16 x 5/8” Hex Washer Self-Tap

tionItem Qt

Note

Footnotes:

Manual No. 7006154REAR ENGINE RIDER

SERIES 23

15

TP 400-5020-4-RE-N

MAIN CASE PT.2

Manual No. 7006154 REAR ENGINE RIDER
TP 400-5020-4-RE-N

16

SERIES 23

MAIN CASE PT.2

p

y

Part No Descri

5 7028990 1 COVER, Battery

6 7073268 1 COVER, Solenoid (Kohler)
14 7091511 2 NUT, 5/16-18 Hex, GR 5 or B Was 90196
15 7040598 1 ARM, Shift Handle (weldment)
16 7010754 1 SPRING, Shift Detent
17 7058763 1 ASSEMBLY, Speed Adjustment Latch Includes Spring, Part Number

18 7059212 1 HANDLE, Shift (weldment)
19 7015761 1 SHOULDER BOLT, 5/16-18
20 7023656 1 GRIP, Shift Handle
21 7073289 1 LEVER, Over-Ride
24 7091597 1 COTTER PIN, 3/32 x 3/4” Was 90037
25 7023914 1 PIN, 1/4 x 1-3/4” Tapered Clevis
26 7019245 1 BUSHING, 3/4 x 1.62 Flange (Nylon)
27 7031036 2 WASHER, Thrust
28 7019246 2 BUSHING, 3/4 x I.O. Flange (Nylon)
29 7090361 2 SCREW, 5/16-18 x 5/8” Hex Washer Self-Tap
38 7091315 2 WASHER, .32 x .58 x .08 Split Lock
39 7091297 2 NUT, 5/16-24 Hex, GR5
46 7091595 1 WASHER, .47 x .92 x .065 Flat
47 7091298 1 NUT, 5/16-18 Hex Nyloc

tionItem Qt

Note

26292

Footnotes:

Manual No. 7006154REAR ENGINE RIDER

SERIES 23

17

TP 400-5020-4-RE-N

DIFFERENTIAL, R. H. FENDER

Manual No. 7006154 REAR ENGINE RIDER
TP 400-5020-4-RE-N

18

SERIES 23

DIFFERENTIAL, R. H. FENDER

p

y

Part No Descri

1 7054372 1 ASSEMBLY, R.H. Fender Bearing & DX Bearing

2 7091819 13 SCREW, 1/4-20 x 5/8” Hex Washer Head Self-Tap Was 90362

3 7031079 1 WASHER, Thrust

4 7010969 1 NUT, 5/16-24 Flange Lock (Large)

5 7038067 1 PLATE, Differential

6 7022115 8 SPACER, Pinion

7 7021127 8 GEAR, Differential Pinion (12T 12P)

8 7011072 1 WASHER, Thrust

9 7051584 1 ASSEMBLY, Drive Hex Tube
10 7010988 1 WASHER, Hex Insert (nylon)
11 7010964 1 GEAR, 11 Tooth, 10 Pitch
12 7010941 1 CHAIN, 46 Pitch (#35 Endless)
13 7021129 1 SPROCKET, 34T, 3/8P
14 7010965 1 RING, 1-3/16” External Retaining
15 7021128 1 SPACER, Differential Case
16 7012332 2 BOOT CLAMP (for 2” Hose)
17 7075115 1 BOOT, Oil Seal (Short Axle)
18 7011024 1 PLUG, 1/2” Cup Insert
19 7037279 1 CASE, Transmission
20 7028762 1 GASKET, Transmission Case
21 7037280 1 FENDER, R. H. (1.62” Dia. Hole)
22 7027644 1 GEAR, 63 Tooth 10 Pitch
23 7075479 1 AXLE, Long Was 47763
24 7074431 1 SPACER, Differential Case
25 7057398 1 ASSEMBLY, Short Axle, 23T (Includes Gear) Use only with Long Axle P/N

26 7012333 8 BOLT, 5/16-24 x 1-5/8” Hex Special Lock (Vibresist)
27 7011156 2 O-RING, 5/16"
28 7011782 2 WASHER, 5/16” Belleville
29 7090395 1 WASHER, 5/16” External Tooth Lock
30 7090188 1 WASHER, .34 x .69 x .08 Flat
31 7011042 1 SCREW, 5/16-24 x 2-5/8” Hex Head Cap
32 7090361 11 SCREW, 5/16-18 x 5/8” Hex Washer Self-Tap
33 7061017 GREASE, Transmission (24 oz. Required)

- 7057260 1 ASSEMBLY, Differential (Incl. items 5, 6, 7, 23, 24, 25 & 26)

- 7060662 1 KIT, Differential (Incl. 18822, Ball Bearing & 37957 Fender)

- 7060411 1 KIT, Differential (Incl. 12296 p.m. bearing for

tionItem Qt

Note

47763

item 1 &N 37280 fender)

Footnotes:

Manual No. 7006154REAR ENGINE RIDER

SERIES 23

19

TP 400-5020-4-RE-N

CHAIN CASE, L. H. FENDER

Manual No. 7006154 REAR ENGINE RIDER
TP 400-5020-4-RE-N

20

SERIES 23

CHAIN CASE, L. H. FENDER

p

y

Part No Descri

1 7052683 1 ASSEMBLY, Primary Chain Case Includes Items 2 thru 13 & 15,

2 7041136 1 WELDMENT, Primary Chain Case, Right Hand

3 7028761 1 GASKET, Primary Chain Case

4 7011121 2 WASHER, 5/8” Belleville

5 7010756 2 BEARING, .625 x 1.37 x .435

6 7018963 1 WELDMENT, Sprocket & Shaft

7 7010614 1 KEY,#5 Woodruff

8 7039778 1 CHAIN CASE HALF, Primary

9 7010942 2 BEARING, Needle
10 7011086 2 THRUST WASHER, Nylon
11 7040355 1 WELDMENT, Hub & Sprocket
12 7010941 1 CHAIN, 46 Pitch (#35 Endless)
13 7090913 10 SCREW, #10-24 x 1/2" Hex Washer Self-Tap (Torx) Was 90307
14 7011024 1 PLUG, 1/2” Cup Insert
15 7022785 1 ROLLER, 1-3/8 Long
16 7010776 1 RING, 1/2” External Retaining (Heavy Duty)
17 7059183 1 ASSEMBLY, Left Hand Fender (Incl. items 18 & 19)
18 7037285 1 FENDER, Left Hand (1.628” I. D. Hole)
19 7052827 1 ASSEMBLY, Axle Bearing (Incl. items 20 thru 23)
20 7052827 1 BEARING, Left Hand Fender, 3/4” Was 74184
21 7013324 1 FITTING, Lube, 45 Degree, 3/16” w/Hex
22 7074500 1 SEAL, Dust/Grease Axle
23 7074182 2 BEARING, 3/4” I.D. DX
24 7012271 1 WASHER, Shim or quantity as required
25 7011070 1 TIE ROD (5/16-24 thread- both ends)
26 7012332 2 BOOT CLAMP (for 2” Hose)
27 7075115 1 BOOT, Rear Axle, Thick Flange
28 7011071 1 THRUST WASHER (Nylon)
29 7011072 1 WASHER, Thrust
30 7091505 1 NUT, 5/8-18 Hex Nyloc
31 7010969 1 NUT, 5/16-24 Flange Lock (Large)
32 7019260 2 O-RING, 1/2 x 5/8”
33 7027981 1 WASHER, Shim .625 x .875

- 7061017 GREASE, Transmission (2 oz. Maximum)

- 7051451 1 ASSEMBLY, Left Hand Fender (Incl. Fender 37958 & Bearing

14624)

tionItem Qt

Note

16, 30 & 31

Footnotes:

Manual No. 7006154REAR ENGINE RIDER

SERIES 23

21

TP 400-5020-4-RE-N

SMOOTH CLUTCH ASSEMBLY

Manual No. 7006154 REAR ENGINE RIDER
TP 400-5020-4-RE-N

22

SERIES 23

SMOOTH CLUTCH ASSEMBLY

p

y

Part No Descri

1 7053114 1 ASSEMBLY, Smooth Clutch (Incl. items 2 thru 6) Non-Asbestos

2 7059443 1 ASSEMBLY, Driven Disc Hub Was 54243

3 7053103 1 DISC, Driven (rubber tire bonded to rim)

4 7014523 1 THRUST WASHER

5 7032331 1 PLATE, Drive Disc

6 7091601 4 NUT, 5/16-18 Hex Flange Lock, GR5 Was 90585

7 7052497 1 ASSEMBLY, Brake Lever (Includes brake pad & rivet)

8 7012313 1 RING, 3/8” External Retaining

9 7090303 1 NUT, 1/4-28 Hex Top Lock
10 7091294 1 WASHER, .28 x .63 x .06 Flat, GR5
11 7072593 1 SPACER, Brake Arm Pivot
12 7091504 1 SCREW, 1/4-28 x 1” Hex Head Cap, (Washer Face) GR5
13 7072406 1 SPRING, Torsional Brake Return
14 7013885 1 SPRING, Clutch & Brake
15 7046162 1 LIFT, Yoke
16 7011048 2 BEARING, Yoke
17 7092062 2 NUT, 5/16-24 Hex Center Lock Was 11201
18 7090238 2 SCREW, 5/16-24 x 1” Hex Head Cap, GR5
19 7091198 1 SCREW, 3/8-16 x 5/8” Hex Washer Self-Tap
20 7033291 1 COLLAR, Yoke
21 7011763 2 FENDER WASHER, 5/16”
22 7073733 1 ARM, Yoke
23 7091122 2 SCREW, 1/4-20 x 1/2” Hex Washer Self-Tap Was 90539
24 7015464 1 STUD, Clutch Link (3/8-24 thread)
25 7090390 1 WASHER, 3/8” Internal Tooth Lock
26 7091630 1 NUT, 3/8-24 Hex, GR5 or B
27 7047190 1 BRACKET, Slide
28 7091597 1 PIN, 3/32 x 3/4” Cotter Was 90037
29 7014663 2 SLIDE HALF
30 7014664 1 BOLT, 5/16-18 Shoulder
31 7090187 1 WASHER, 5/16” Split Lock
32 7091511 1 NUT, 5/16-18 Hex, GR 5 or B Was 90196
33 7090122 2 WASHER, 3/8” Flat SAE
34 7059068 1 ASSEMBLY, Leaf Spring

tionItem Qt

Note

Footnotes:

Manual No. 7006154REAR ENGINE RIDER

SERIES 23

23

TP 400-5020-4-RE-N

MAIN CASE (Yoke View)

Manual No. 7006154 REAR ENGINE RIDER
TP 400-5020-4-RE-N

24

SERIES 23

MAIN CASE (Yoke View)

p

y

Part No Descri

- - 1 View shows assembly of PT.1 parts

tionItem Qt

Note

Footnotes:

Manual No. 7006154REAR ENGINE RIDER

SERIES 23

25

TP 400-5020-4-RE-N

FUEL TANK AND OPERATORS SEAT

Manual No. 7006154 REAR ENGINE RIDER
TP 400-5020-4-RE-N

26

SERIES 23

FUEL TANK AND OPERATORS SEAT

p

y

Part No Descri

1 7075071 1 SEAT, V2400 w/slotted Switch Hole

2 7051905 1 ASSEMBLY, Fuel Tank (Includes item 3)

3 7012515 1 CAP, Fuel Tank
3A 7019377 1 CAP, Fuel Tank w/Gauge

4 7016325 1 VALVE, Fuel Shut-Off (Accessory)

5 7029900 4 CLAMP, Fuel Line replaces 12222

6 7076272 1 HOSE, Fuel (1/4” I.D. x 8-1/2” long)

7 7014359 1 FILTER, Fuel (In-Line)

8 7036549 1 BRACKET, Tank, Tall (for Briggs 16HP)

9 7091542 2 SCREW, 5/16-18 x 1/2” Pan Head Self-Tap (Torx #T-40)
10 7033377 1 BRACKET, Fuel Tank (Rear)
11 7091038 2 BOLT, 5/16-18 x 1/2” Hex Flange Nyloc

12A 7023735 2 KNOB, Seat Adjusting, 5/16-18 thread
12B 7023191 2 KNOB, Seat Adjusting (5/16-18 thread)

13 7011791 4 RETAINER, 5/16” Bolt
14 7090858 2 SCREW, 5/16-18 x 1/2” Hex Washer Self-Tap
15 7073240 1 HOSE, Fuel (5” long) Was 32038

16A 7029211 1 SWITCH, Seat (NC) (for 3" round hole)
16B 7023354 1 SWITCH, Seat (NC) (for slotted hole)

17 7075018 2 BRACKET, Seat
18 7091714 4 BOLT, 5/16-18 x 1” Square Neck Carriage, GR5
19 7090672 2 NUT, 5/16-18 Hex Flange Top Lock
20 7013849 2 SPACER, .33 x .63 x .156

tionItem Qt

Note

Footnotes:

Manual No. 7006154REAR ENGINE RIDER

SERIES 23

27

TP 400-5020-4-RE-N

EXHAUST MUFFLER, ENGINE

Manual No. 7006154 REAR ENGINE RIDER
TP 400-5020-4-RE-N

28

SERIES 23

EXHAUST MUFFLER, ENGINE

p

y

Part No Descri

-- -- 1 ENGINE, 18 HP Briggs (Model 40F777, Type 0122, Trim E1) electric start

-- -- 1 ENGINE, 20 HP (B&S 40G777-0114-E1) electric start
1 7071755 1 MUFFLER (B&S 18HP Intek V-Twin)
2 7091738 2 or 4 SET SCREW, 5/16-18 x 3/4” Socket Head, GR 8
3 7063283 1 GASKET, 20HP B&S Intek

tionItem Qt

Note

Footnotes:

Purchase engine parts from engine manufacture dealer.

Manual No. 7006154REAR ENGINE RIDER

SERIES 23

29

TP 400-5020-4-RE-N

DRIVE DISC ASSEMBLY

Manual No. 7006154 REAR ENGINE RIDER
TP 400-5020-4-RE-N

30

SERIES 23

DRIVE DISC ASSEMBLY

p

y

Part No Descri

1 7072658 1 WELDMENT, 5.75” O.D. Drive Disc
2 7090132 2 SET SCREW, HRSS, 3/8-16 x 3/8”
3 7010210 1 KEY,1/4” Square x 2” Long

tionItem Qt

Note

Footnotes:

Manual No. 7006154REAR ENGINE RIDER

SERIES 23

31

TP 400-5020-4-RE-N

THROTTLE CONTROL

Manual No. 7006154 REAR ENGINE RIDER
TP 400-5020-4-RE-N

32

SERIES 23

THROTTLE CONTROL

p

y

Part No Descri

1 7074321 1 CONTROL, Throttle (33.6” long) (Briggs 18 & 20 HP Engine)
2 7090913 2 SCREW, #10-24 x 1/2” Hex Washer Self-Tap (Torx)
3 7033470 1 PLATE, Throttle Control
4 7075006 1 CONTROL, Choke (44” long) Was 24185 36" long
5 7091122 2 SCREW, 1/4-20 x 1/2” Hex Washer Self-Tap Was 90539
6 7091630 1 NUT, 3/8-24 Hex, GR B Was 90155
7 7090390 1 WASHER, 3/8” Internal Tooth Lock

tionItem Qt

Note

Footnotes:

NOTE: SNAPPER part number & revision is stamped on throttle and choke cables.

Manual No. 7006154REAR ENGINE RIDER

SERIES 23

33

TP 400-5020-4-RE-N

RAILS, LIFT ARMS, CAM LIFT PT.1

Manual No. 7006154 REAR ENGINE RIDER
TP 400-5020-4-RE-N

34

SERIES 23

RAILS, LIFT ARMS, CAM LIFT PT.1

p

y

Part No Descri

1 7041248 1 ASSEMBLY, Rear Lift Arm
3 7073269 1 RAIL, Left Half
4 7036430 4 RAIL, Deck Lift, Right Hand Was 43848
5 7041578 1 STUCTURE, Front Lift Arm
6 7040502 1 WELDMENT, Top Brace
7 7018574 1 IDLER, 4-1/8” Flat
8 7034759 1 BRACE, R.H. Spindle

9 7038096 2 BRACE, L.H. Spindle
10 7034763 1 BRACE/IDLER Mounting Bracket
11 7091497 1 SCREW, 3/8-16 x 1-1/2” Hex Head Cap, GR5
12 7034213 1 PIVOT, Leveling
13 7027944 1 ROD, Leveling
14 7090499 3 NUT, 3/8-24 Hex Top Lock
16 7034857 1 BELT GUIDE, 42”
17 7042613 1 GUIDE, Belt, 42” RER (Weldment)
19 7013861 1 KEY, 3/16 x 7/8” Woodruff
21 7091290 1 NUT, #10-24 Hex Nyloc
22 7090815 6 SCREW, 3/8-16 x 3/4” Hex Washer Self-Tap
23 7091585 3 NUT, 3/8-16 Hex Center Lock Was 90546
24 7090134 2 SCREW, 3/8-16 x 3/4” Hex Head Cap, GR5
25 7091299 1 NUT, 3/8-16 Hex Nyloc
26 7028200 2 SWIVEL, Adjustable
27 7090390 1 WASHER, 3/8” Internal Tooth Lock
28 7091619 NUT, 3/8-16 Hex Flange Lock Was 90613
30 7012067 2 RING, Front Lift Arm (Red)
31 7090858 4 SCREW, 5/16-18 x 1/2” Hex Washer Self-Tap
32 7022717 1 ROD, Deck Support (Front Lift Arm to Front End)
33 7017847 2 RING, .438 External Retaining
34 7012068 2 RING, Rear Lift Arm (Blue)
36 7015447 1 ECCENTRIC, Leveling
37 7015495 1 BOLT, 3/8-24 x 3/4” Shoulder, GR5
38 7032997 1 ARM, Front Lift (Left Side)
39 7027198 1 BOLT, 3/8-16 x 1” Hex Flange Lock, GR5
40 7090606 4 BOLT, 5/16-18 x 5/8” Hex Flange Lock
48 7091503 2 HAIR PIN, 3/32 x 1-1/2”
49 7028728 2 ADJUSTER, Chain (5/16-18 thread)
50 7090122 1 WASHER, 3/8” Flat SAE

tionItem Qt

Note

Footnotes:

Manual No. 7006154REAR ENGINE RIDER

SERIES 23

35

TP 400-5020-4-RE-N

RAILS, LIFT ARMS, CAM LIFT PT.1

Manual No. 7006154 REAR ENGINE RIDER
TP 400-5020-4-RE-N

36

SERIES 23

RAILS, LIFT ARMS, CAM LIFT PT.1

p

y

Part No Descri

51 7010935 2 WASHER, .77 x 1.13 x .06 Flat
52 7014526 2 SPACER
53 7014532 2 PULLEY, 5” O. D.
54 7074467 2 NUT, 3/4-16 Hex Jam, GR 8
55 7073066 1 DECAL, Blade Engagement, 42”
56 7090361 1 SCREW, 5/16-18 x 5/8” Hex Washer Self-Tap
57 7032368 1 BELT GUIDE
58 7058969 1 ASSEMBLY, Clutch Plate
59 7073216 1 CABLE, No-Mow-In-Reverse
60 7092051 1 BOLT, #10-24 x 1” Flat Head Square Neck

tionItem Qt

Note

Footnotes:

Manual No. 7006154REAR ENGINE RIDER

SERIES 23

37

TP 400-5020-4-RE-N

RAILS, LIFT ARMS, CAM LIFT PT.2

Manual No. 7006154 REAR ENGINE RIDER
TP 400-5020-4-RE-N

38

SERIES 23

RAILS, LIFT ARMS, CAM LIFT PT.2

p

y

Part No Descri

2 7053300 1 LEVER, Height Adjustment Lift (Weldment)
15 7090390 1 WASHER, 3/8” Internal Tooth Lock
18 7034069 1 QUADRANT, Lift Lever
20 7010746 1 RING, 3/4” Retaining Was 27920
22 7090815 6 SCREW, 3/8-16 x 3/4” Hex Washer Self-Tap
29 7090844 1 ROLL PIN, 3/16 x 3/4”
35 7023658 1 GRIP, Height Adjustment Lever
41 7024914 1 SPRING Extension
42 7012122 1 SPRING, Latch
43 7091515 2 PIN, 3/16 x 1-1/2” Cotter Was 90753
44 7041581 1 LATCH Weldment
45 7026286 1 GRIP, Lift Latch
46 7011021 1 PIN, 1/4 x 1-1/4” Clevis
47 7090360 1 COTTER PIN, 1/16 x 3/4”

tionItem Qt

Note

Footnotes:

Manual No. 7006154REAR ENGINE RIDER

SERIES 23

39

TP 400-5020-4-RE-N

42" MOWER DECK ASSEMBLY PT.1

Manual No. 7006154 REAR ENGINE RIDER
TP 400-5020-4-RE-N

40

SERIES 23

42" MOWER DECK ASSEMBLY PT.1

p

y

Part No Descri

1 7063040 1 WELDMENT, 42” Deck Was 42645

2 7051401 1 ASSEMBLY, Side Chute (Includes decal 26831)

3 7059628 2 ASSEMBLY, Spindle

4 7026691 2 BLADE, 21” Standard Lift

5 7014168 1 SPRNG, Blade Handle

6 7012055 1 ROD, Idler Control

7 7038021 1 MOUNT, Handle/Switch

8 7046874 1 GRIP, Handle

9 7053034 2 ASSEMBLY, Spindle Ring
10 7029264 4 WHEEL, Gage
11 7035835 4 POST, Anti-Scalp
12 7029265 4 BOLT, Gage Wheel, 3/8-16 x 3-3/8” Hex Head Shoulder
13 7014852 1 DECAL, Caution
14 7013010 1 DECAL, Danger Was 26831
15 7091619 6 NUT, 3/8-16 Hex Flange Lock Was 90613
16 7091508 4 BOLT, 5/16-18 x 3/4” Short Neck Carriage, GR5
17 7029303 2 STAND-OFF, 3-1/2” long, 5/16-18 top, 3/8-16 bottom threads
18 7091619 6 NUT, 3/8-16 Hex Flange Lock Was 90613
19 7059254 1 WELDMENT, Blade Engagement Handle
20 7090299 1 SCREW, #10-32 x 1” Hex Washer Head Self-Tap
21 7018524 1 SWITCH, Deck Interlock (NO)
22 7091294 1 WASHER, 1/4” Flat Was 90055
23 7091597 1 PIN, 3/32 x 3/4” Cotter Was 90037
24 7012063 4 WASHER, 13/32” I.D. Cone
25 7090824 1 SCREW, 3/8-24 x 1-1/4” Hex Head Cap, GR5
26 7012670 2 TOLERANCE RING, 2.0
27 7014526 2 SPACER
28 7011791 2 RETAINER, 5/16” Bolt
29 7091537 2 WING-NUT, 5/16-18 Lock
30 7090188 2 WASHER, 5/16” Flat Was 91296
31 7091585 4 NUT, 3/8-16 Hex Center Lock
32 7091049 4 WING-NUT, 3/8-16 Nyloc
33 7091328 4 SCREW, 3/8-16 x 1-1/4” Hex Head Cap, GR5
34 7046567 1 HANDLE, Blade Engagement
35 7091974 1 PIN, 3/16 x 1” Clevis
36 7046648 1 SPRING, Torsion
37 7091597 1 PIN, 3/32 x 1/2” Cotter Was 90555

tionItem Qt

Note

Footnotes:

Manual No. 7006154REAR ENGINE RIDER

SERIES 23

41

TP 400-5020-4-RE-N

42" MOWER DECK ASSEMBLY PT.1

Manual No. 7006154 REAR ENGINE RIDER
TP 400-5020-4-RE-N

42

SERIES 23

42" MOWER DECK ASSEMBLY PT.1

p

y

Part No Descri

38 7091819 2 SCREW, 1/4-20 x 5/8” Hex Washer Head Self-Tap Was 90362

tionItem Qt

Note

Footnotes:

Manual No. 7006154REAR ENGINE RIDER

SERIES 23

43

TP 400-5020-4-RE-N

42" MOWER DECK ASSEMBLY PT.2

Manual No. 7006154 REAR ENGINE RIDER
TP 400-5020-4-RE-N

44

SERIES 23

42" MOWER DECK ASSEMBLY PT.2

p

y

Part No Descri

39 - 1 ASSEMBLY, Rail (see Rails, Lift Arms, Cam Lift page for parts

breakdown)
40 7073267 1 FOOT PEDAL, Blade Stop Control
41 7034758 1 ARM, Idler
42 7028200 1 SWIVEL, Adjustment (with 5/16-18 internal thread)
43 7073217 1 CABLE CLIP
44 7015448 1 SPRING, Pedal
45 7090606 5 BOLT, 5/16-18 x 5/8” Hex Flange Lock
46 7010740 4 RING, 2” External Retaining
47 7029244 1 EYE-BOLT, 5/16-18 x 3”
48 7091503 1 HAIR PIN, 3/32 x 1-1/2”
49 7091601 5 NUT, 5/16-18 Hex Flange Lock, GR5 Was 90585
50 7090289 1 NUT, 3/8-24 Hex Center Lock
51 7014795 2 WASHER, Nylon
52 7015446 1 SHOULDER BOLT, 3/8-24 x 9/16”
53 7090250 3 WASHER, 1/2” Flat SAE
54 7024341 1 SPRING, Return
55 7074649 1 SPRING, Latch
56 7090122 1 WASHER, 3/8” Flat Was 91514
57 7034754 1 BRAKE PAD, Spring
58 7091584 1 NUT 1/4-20 Hex Flange Lock Was 90583
59 7090584 2 BOLT, 1/4-20 x 1/2” Hex Flange Lock
60 7028786 1 BUSHING, .375 Nylon Snap
61 7076978 1 NUT, 1/4-20 Hex Nyloc
62 7028754 1 LINK, Spindle Brake, 1/4-20 thread
63 7090673 1 PIN, 1/16 x 1/2” Cotter
64 7091530 1 BOLT, 1/4-20 x 3/4” Square Neck Carriage, GR5 Was 91776
65 7091576 1 NUT, 1/4-20 Hex, GR5 or B

tionItem Qt

Note

Footnotes:

Manual No. 7006154REAR ENGINE RIDER

SERIES 23

45

TP 400-5020-4-RE-N

DECK COVER, BELTS, BLADE BRAKE

Manual No. 7006154 REAR ENGINE RIDER
TP 400-5020-4-RE-N

46

SERIES 23

DECK COVER, BELTS, BLADE BRAKE

p

y

Part No Descri

1 7043834 1 COVER, Belt, 42” RER
2 7029624 1 PULLEY, Seam Welded Idler
3 7091537 2 WING-NUT, 5/16-18 Was 90492
4 7090188 2 WASHER, 5/16” Flat Was 91296
5 7090741 5 SCREW, 1/4-20 x 5/8” Hex Head w/Free Spinning Washer Was 91016
6 7027921 1 COVER, Lift Quadrant
7 7028995 1 DECAL, Brake/Blade Operation
8 7074467 1 NUT, 3/4-16 Hex Jam, GR 8

9 7028784 1 BELT, 5L Section (110.28” effective length)
10 7090122 2 WASHER, 3/8” Flat SAE
11 7091294 1 WASHER, 1/4” Flat Was 90055
12 7091597 2 PIN, 3/32 x 3/4” Cotter Was 90037
13 7014304 1 PIN, 1/4 x 1-5/8” Clevis
14 7014314 1 SPACER, .39 x 1.0 x .31 Nylon
15 7034852 1 BAND, Brake (Formed)
16 7035378 1 DRUM, Brake Spindle
17 7014526 1 SPACER
18 7010935 2 WASHER, .77 x 1.13 x .06 Flat
19 7010740 2 RING, 2” External Retaining
20 7014795 2 WASHER, Nylon
21 7014527 2 SPACER
22 7047862 1 WELDMENT, Brake Arm
23 7090289 1 NUT, 3/8-24 Hex Center Lock
24 7034297 1 LINK
25 7090160 1 SCREW, 3/8-24 x 1” Hex Head Cap, GR5
26 7091299 2 NUT, 3/8-16 Hex Nyloc
27 7090122 2 WASHER, 3/8” Flat Was 91514
28 7018574 1 IDLER, 4-1/8” Flat
29 7091497 2 SCREW, 3/8-16 x 1-1/2” Hex Head Cap, GR5

tionItem Qt

Note

Footnotes:

Manual No. 7006154REAR ENGINE RIDER

SERIES 23

47

TP 400-5020-4-RE-N

SPINDLE ASSEMBLY

Manual No. 7006154 REAR ENGINE RIDER
TP 400-5020-4-RE-N

48

SERIES 23

SPINDLE ASSEMBLY

p

y

Part No Descri

1 7059628 1 ASSEMBLY, Spindle Housing (Includes items 2 thru 8)

2 7012491 2 RING, 1.85” Internal Retaining

3 7013313 2 BEARING, Spindle

4 7051469 1 HOUSING, Spindle (weldment) Was 47849

5 7010817 1 LUBE FITTING, 3/16” Press-In

6 7032294 1 HOLDER, Blade

7 7014407 1 WASHER, Spindle

8 7027640 1 SPINDLE SHAFT (9.5” Length)

9 7012670 1 TOLERANCE RING, 2.0

tionItem Qt

Note

Footnotes:

Manual No. 7006154REAR ENGINE RIDER

SERIES 23

49

TP 400-5020-4-RE-N

DECALS

Manual No. 7006154 REAR ENGINE RIDER
TP 400-5020-4-RE-N

50

SERIES 23

DECALS

p

y

Part No Descri

1 7071916 1 DECAL, SNAPPER

2 7046440 1 DECAL, Warning, Safety Instructions

3 7046720 1 DECAL, Chute/Deflector

4 7015691 1 DECAL, Battery Caution

5 7013010 1 DECAL, Danger (Heavy Adhesive) Was 26831

6 7028995 1 DECAL, Brake/Blade Operation

7 7074481 1 DECAL, No-Mow-In-Reverse

8 7012358 1 DECAL, Battery

9 7029113 1 DECAL, Caution, Fuel (English)
10 7073066 1 DECAL, Blade Engagement, 42”
11 7075165 1 DECAL, B&S AIR Index/Emission Label
12 7024910 1 DECAL - 42 Inch
13 7034206 1 DECAL, Fuel Routing
14 7024506 1 DECAL, Fuel Shut-Off
15 7073335 1 DECAL OPEI Ride-On
16 7029470 1 DECAL, Patent Numbers
17 7075607 1 DECAL, Service Parts, RER Domestic

tionItem Qt

Note

Footnotes:

Manual No. 7006154REAR ENGINE RIDER

SERIES 23

51

TP 400-5020-4-RE-N

ELECTRICAL SYSTEMS (For 18 & 20HP Briggs)

Manual No. 7006154 REAR ENGINE RIDER
TP 400-5020-4-RE-N

52

SERIES 23

ELECTRICAL SYSTEMS (For 18 & 20HP Briggs)

p

y

Part No Descri

1 7060753 1 KIT, 12 Volt Dry Charge Battery

2 7075671 1 SOLENOID, Super-Trombetta replaces 18817

3 7015430 1 HARNESS, Starter Wiring (Briggs)

4 7074406 1 HARNESS, Ignition Wiring (14.5 B&S)

5 7016168 1 HOLDER, Fuse (Includes Fuse)

- 7016169 1 FUSE, 10 Amp
6 7063064 1 INTERLOCK MODULE, Briggs Was 28606
7 7028386 1 HARNESS (Deck Interlock Wiring)
8 7018524 1 SWITCH, Deck Interlock (NO)
9 7012444 1 COVER, Battery Cable

10 7019326 1 WIRE, Positive (Red, 17” long)
11 7026343 1 SWITCH, Ignition-Afterfire Solenoid
12 7091546 1 WASHER, 5/8” Internal Tooth Lock Was 90880
13 7015438 1 NUT, 5/8-32 Hex
14 7011138 1 IGNITION KEY, Pair
15 7091122 3 SCREW, 1/4-20 x 1/2” Hex Washer Self-Tap Was 90539
16 7012485 2 RETAINER, 1/4” Bolt
17 7028675 1 HARNESS WIRE, Operator Presence Control (OPC)
18 7090053 2 WASHER,1/4” Internal Tooth Lock
19 7090072 2 SCREW, 1/4-20 x 5/8” Hex Head Cap. GR5 Was 27172
20 7028027 1 WIRE, Negative, Black (15” long)
21 7091576 2 NUT, 1/4-20 Hex, GR5 or B (attaches to starter terminal)
22 7012080 2 CABLE TIE, 7”
23 7090372 2 NUT, 1/4-20 Hex Center Lock, GR5 or B
24 7022886 1 SWITCH, Operator Presence Control (OPC) Traction (NO/NC)
25 7023354 1 SWITCH, Seat (Normally Closed)

tionItem Qt

Note

Footnotes:

Manual No. 7006154REAR ENGINE RIDER

SERIES 23

53

TP 400-5020-4-RE-N

WIRING SCHEMATIC for 18 & 20HP Briggs

Manual No. 7006154 REAR ENGINE RIDER
TP 400-5020-4-RE-N

54

SERIES 23

WIRING SCHEMATIC for 18 & 20HP Briggs

p

y

Part No Descri

- - 1 Wiring schematic includes harness #'s 15430, 74406, 28386, &

28675

tionItem Qt

Note

Footnotes:

Manual No. 7006154REAR ENGINE RIDER

SERIES 23

55

TP 400-5020-4-RE-N

SNAPPER REAR ENGINE RIDER ACCESSORIES

Manual No. 7006154 REAR ENGINE RIDER
TP 400-5020-4-RE-N

56

SERIES 23

SNAPPER REAR ENGINE RIDER ACCESSORIES

p

y

Part No Descri

- 7061987 1 KIT, Ninja Mulching used on all 42” Deck Rear

- 7060944 1 KIT, Single Bag Collector (5 Bu.) used on all 42” Deck Rear

- 7060948 1 KIT, Thatcherizer, 28” used on all 42” Deck Rear

- 7060959 1 KIT, Dozer Blade (36” Blade) used on all 42” Deck Rear

- 7061822 1 KIT, Tire Chains used on all 42” Deck Rear

- 7060697 1 KIT, Dump Cart (6 Cu. Ft.) used on all 42” Deck Rear

- 7063023 1 KIT, 42" Dual Idler Deck used on all 42” Deck Rear

tionItem Qt

Note

Engine Riders

Engine Riders

Engine Riders

Engine Riders

Engine Riders

Engine Riders

Engine Riders

Footnotes:

Manual No. 7006154REAR ENGINE RIDER

SERIES 23

57

TP 400-5020-4-RE-N

Parts Manual fo

r

REAR ENGINE RIDER
42" MOWER
SERIES 23

RESERVE THE RIGHT TO MAKE CHANGES OR ADD IMPROVEMENTS

COPYRIGHT ©2005
SNAPPER PRODUCTS, INC.
ALL RIGHTS RESERVED.

IT IS THE POLICY OF SNAPPER TO IMPROVE ITS PRODUCTS

WHENEVER IT IS POSSIBLE AND PRACTICAL TO DO SO. WE

AT ANY TIME WITHOUT INCURRING ANY OBLIGATION TO MAKE

SUCH CHANGES ON PRODUCTS MANUFACTURED PREVIOUSLY.

McDonough, GA, 30253 U.S.A.

Revision 4,

8/1/2005

Manual No. 700615 4

TP 400-5020-4-RE-N
