Snapper 210, 240 User Manual

Specifications and Main Features

  • Type: T110P-D
  • Bore and Stroke: 30 X 30 mm
  • Engine Size: 21.2 cc
  • Net Power: 0.85 PS at 7000 revolutions per minute
  • Maximum Power: 1.1 PS at 8000 revolutions per minute.
  • Peak Torque: 0.108 kg-m at 6500 revolutions per minute
  • Engine Turning: Counter-clockwise
  • Fuel Combination Ratio: 20-25:1 gasoline and oil
  • Fuel Container Volume: 0.5 L
  • Weight Without Fuel: 2.2 kg
  • Size Specifications: 152 x 202 x 238 mm
  • Type: T140P-D
  • Bore and Stroke: 32 x 30 mm
  • Engine Size: 24.1 cc.
  • Net Power: 1.0 PS at 6,100 revolutions per minute
  • Maximum Power: 1.4 PS at 8,000 revolutions per minute
  • Peak Torque: 0.15 kg-m at 6000 revolutions per minute.
  • Engine Rotation: Counterclockwise
  • Fuel Combination Ratio: 20-25:1 in gasoline and oil.
  • Fuel Container Volume: 0.6 L
  • Weight Without Fuel: 2.3 kg
  • Size Specifications: 152 x 209 x 242 mm
  • Type: T180P-D
  • Bore and Stroke: 36 x 32 mm
  • Engine Size: 32.5 cc.
  • Rated Output: 1.3 PS at 6000 RPM
  • Maximum Power: 1.8 PS at 7000 rpm.
  • Peak Torque: 0.20 kg-m at 5500 revolutions per minute.
  • Engine Rotation: Counterclockwise
  • Fuel Combination Ratio: 20-25:1 in gasoline and oil.
  • Volume of fuel tanks: 0.9 L
  • Overall Weight: 2.7 kg
  • Measure: 159 x 224 x 264 mm

Frequently Asked Questions

What is the recommended fuel mixture to use on the snapper Trimmer Engines?

The recommended ratio of the mix is 20-25:1 gasoline-oil mix.

What sort of lubrication oil should be used?

Lubrication should be done with 2-cycle motor oil.

What is the best way to check if the fuel tank is clean?

First check if the fuel filter has been clogged and also ensure that the tank does have old mixed oil.

What should I do, jan82147 in case the engine refuses to start?

Assure yourself whether the fuel tank has enough fuel, also check the fuel-oil mixture ratio and ensure that the air cleaner is clean.

How often should the air cleaner be checked?

An air cleaner should be cleaned after every 25 hours of operation or if the performance has deteriorated.

What spark plug should be used on Snapper Trimmer Engines?

The Trimmer recommends the NGK BM-6A spark plug.

How do I adjust the throttle for maximum performance?

With the use of the adjusting nut, you can vary the play of the throttle wire within the standard value of 0.5 to 1.0 mm.

Q: What maintenance should I perform on a regular basis?

A: Maintenance that ought to be scheduled and done on a regular basis include: spark plug gap inspection and adjustment if necessary, cleaning of the air cleaner, and checking of the fuel system.
