Snapper 204400 User Manual

REPLACES FORM MS--6444--08/01/2008

Not for

Reproduction

FILE IN SECT. 2 OF SERVICE MANUAL

Illustrated Parts List

Model Series

204400

TYPE NUMBERS

0036 through 0536.

TABLE OF CONTENTS

Air Cleaner 5.........................

Alternator 9..........................

Blower Housing/Shrouds 6............

Camshaft 2...........................

Carburetor 4..........................

Controls 7............................

Crankcase Cover 2....................

Crankshaft 2..........................

Cylinder 2............................

Cylinder Head 3.......................

Electric Starter 8......................

Exhaust System 5.....................

Flywheel 6............................

Fuel Supply 8.........................

Gasket Set -- Engine 3.................

Gasket Set -- Valve 3..................

Governor Spring 7....................

Ignition 9.............................

Kit -- Carburetor Overhaul 4............

Lubrication 2.........................

Operator’s Manual 2..................

Piston/Rings/Connecting Rod 2........

Rewind Starter 6......................

Valves 3..............................

Warning Label 2......................

FORM MS--6444--10/07/2008

204400

All rights reserved. No part of this material may be reproduced or transmitted,
in any form or by any means, electronic or mechanical, including photocopying,
recording or by any information storage and retrieval system, without permission
in writing from Briggs & Stratton Corporation.

COPYRIGHT by BRIGGS & STRATTON CORPORATION

PRINTED IN U.S.A.

204400

Not for

Reproduction

1058 OPERATOR’S MANUAL 1319 WARNING LABEL

847

287

523

842

306

307

REQUIRED when replacing parts
with warning labels affixed.

529

1

2

3

18

19

20

17

525

524

415

1194

22

522

1221

21

170

16

146

741

219

220

29

30

32

742

746

24

46

28

552

718

27

27

25

998

15

718A

15B

26

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

6444--2 Assemblies include all parts shown in frames. 10/07/2008

2

204400

Not for

Reproduction

5

51

33

34

868

45

42

42

35

7

36

883

1026

1029

51A

192

1022

1100

798

13

1023

1022

337

1171

914

383

635

12

358 ENGINE GASKET SET

3

7

163

20

868

883

51

51A

883A

1022

1095 VALVE GASKET SET

51A

7

51

868

883

1022

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

6444--3 Assemblies include all parts shown in frames. 10/07/2008

3

204400

Not for

Reproduction

GHOSTED PARTS ARE NOT SERVICEABLE

AND ARE SHOWN FOR REFERENCE ONLY.

125

97

633A

93

51

51A

632

109

633

98

692

130
95

142

106
105

975

137

276
950

WALBRO CARBURETOR

977 CARBURETOR GASKET SET

93

51A

51

121 CARBURETOR OVERHAUL KIT

93

98

104

105

106

51

127

137

137

163

51A

163

133

104

276

633

633A

276

633

633A

955

108B

127

186

231

955

143

141A

633B

141

633B

951

633B

109G

633B

109E

633B

108B

108A

231A

125A

118

951

97A

633B

98A

51A

51

632

109D

633B

633B

130A

95A

975A

133A

137A

1127A

NIKKI CARBURETOR

121A CARBURETOR OVERHAUL KIT

98A

104A

105A

51A

51

122

51

51A

141C

108A

633B

127A

117

135

369

105A

104A

127A

137A

163

633B

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

6444--4 Assemblies include all parts shown in frames. 10/07/2008

4

204400

Not for

Reproduction

832

300

163

161

836

53

161A

883A

185

11C

445

968A

967

425

968

425A

883

81

613A

300C

832C

883C

NOTE: This muffler is intended for replacement

purposes only and is not to be used
for retrofitting to engines with different
exhaust systems.

613

836C

676

677

436C

437

1177

740

863C

740A

355

819

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

6444--5 Assemblies include all parts shown in frames. 10/07/2008

5

204400

Not for

Reproduction

608A

597

1298

725A

728

1046

622

1036 EMISSIONS LABEL

298

725B

305

304

37

23

78

695

304A

592

65

727A

732

60

59

608

597

60

58

59

58

456

456

689

689

459

459

1210

1211

592

1210

1211

592

65

65

55A

55

1005

1070

363

455

332

455A

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

6444--6 Assemblies include all parts shown in frames. 10/07/2008

6

281

Not for

Reproduction

204400

663

632

222

504

621

1138

773

271A

668

188

188

410

271

269

227

562

615

616

616

270

268

265

267

1404

1230

278

505

209

211

222B

222A

604

564A

604A

564

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

6444--7 Assemblies include all parts shown in frames. 10/07/2008

7

204400

Not for

Reproduction

972A

957

601

958

601

240

601

356

799

774

240A

187C187 187B187A

1052A

187E

601

601

493

813

364A

190

309

503

1090

803

310

802

697

579

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

6444--8 Assemblies include all parts shown in frames. 10/07/2008

8

510

513

783

1051

544

801

204400

Not for

Reproduction

NOTE: All stators use a No. mounting screw.
NOTE: The proper flywheel part number and/or the alternator magnet size will

determine the alternator type or output. See repair instruction manual
for additional information.

813

1119

503

579

920

990A

577A

474A

578

892A

DC ONLY

526A

501A

500A

10 -- 16 AMP

474D

578

526

501

356

356A

347B

361A

578A

627A

990

575

664

627

500

361

892

641A

636

641

1046

347

347A

333

851

286

286A

286C

334

356B

356C

356D

356F

356J

356L

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

6444--9 Assemblies include all parts shown in frames. 10/07/2008

9

204400

Not for

Reproduction

REF. PART REF. PART REF. PART

NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION

1 794849 Cylinder Assembly

-- -- -- -- -- -- N o t e -- -- -- -- -- --

793617 Cylinder

Assembly
Used on Type No(s).

0179.

2 698340 Kit--Bushing/Seal

(Magneto Side)

3 K391086S Seal--Oil

(Magneto Side)

5 793009 Head--Cylinder
7 K∆694872 Gasket--Cylinder Head

-- -- -- -- -- -- N o t e -- -- -- -- -- --

K∆697690 Gasket--
Cylinder Head
Used on Type No(s).

0179.

11C 696796 Tube--Breather

12 K694953 Gasket--Crankcase
13 690360 Screw

(Cylinder Head)

15 691686 Plug--Oil Drain

(Square Head)

15B 695757 Plug--Oil Drain

Used on Type No(s).
0276, 0417, 0529.

16 794717 Crankshaft

Used on Type No(s).
0036, 0100, 0105,
0110, 0155, 0160,

0536.

-- -- -- -- -- -- N o t e -- -- -- -- -- -­794716 Crankshaft

Used on Type No(s).
0114, 0115, 0117,
0125, 0157, 0159.
694678 Crankshaft
Used on Type No(s).
0109, 0118, 0119,
0129, 0130, 0134,
0136, 0141, 0142,
0143, 0145, 0146,
0147, 0149, 0150,
0151, 0153, 0154,
0156, 0162, 0163,
0164, 0168, 0171,
0177, 0178, 0179,

0278.
696512 Crankshaft
Used on Type No(s).

0113.
794720 Crankshaft
Used on Type No(s).
0213, 0214.
695306 Crankshaft
Used on Type No(s).
0276, 0417, 0529.

17 695434 Bearing--Ball
18 791965 Cover--Crankcase

-- -- -- -- -- -- N o t e -- -- -- -- -- -­791412 Cover--

Crankcase
(Ball Bearing Cover)
Used on Type No(s).
0036, 0110, 0175,
0213, 0214, 0536.

19 698340 Kit--Bushing/Seal

(PTO Side)

20 K391086S Seal--Oil

(PTO Side)

21 281658S Cap--Oil Fill
22 695174 Screw

(CrankcaseCover-­Sump)

23

794814 Flywheel

-- -- -- -- -- -- N o t e -- -- -- -- -- -­695485 Flywheel

Used on Type No(s).
0110, 0115, 0129,
0141, 0143, 0154,
0157, 0164, 0168,
0177, 0179, 0214,

0278.

24 222698S Key--Flywheel
25 792117 Piston Assembly

(Standard)

-- -- -- -- -- -- N o t e -- -- -- -- -- -­792144 Piston

Assembly
(.020” Oversize)
793794 Piston
Assembly
Used on Type No(s).

0179.
793797 Piston
Assembly
(.020” Oversize)
Used on Type No(s).

0179.

26 792026 Ring Set

(Standard)
(Used After Code Date

05080900).

-- -- -- -- -- -- N o t e -- -- -- -- -- -­694004 Ring Set

(Used Before Code
Date 05081000).
792073 Ring Set
(.020” Oversize)
(Used After Code Date

05080900).
694008 Ring Set
(.020” Oversize)
(Used Before Code
Date 05081000).
793319 Ring Set
Used on Type No(s).

0179.
793324 Ring Set
(.020” Oversize)
Used on Type No(s).

0179.

K Included in Engine Gasket Set--Ref. No. 358.
D Included in Carburetor Overhaul Kit--Ref. No. 121 or 121A.

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

6444--10 Assemblies include all parts shown in frames. 10/07/2008

10

z Included in Carburetor Gasket Set--Ref. No. 977.

∆ Included in Valve Gasket Set--Ref. No. 1095.

204400

Not for

Reproduction

REF. PART REF. PART REF. PART

NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION

27 690975 Lock--Piston Pin
28 696581 Pin--Piston
29 694691 Rod--Connecting
30 694692 Dipper--Connecting

Rod

32 690976 Screw

(Connecting Rod)

33 499596 Valve--Exhaust
34 792200 Valve--Intake
35 694865 Spring--Valve

(Intake)

36 694865 Spring--Valve

(Exhaust)

37 790730 Guard--Flywheel
42 499586 Keeper--Valve
45 690977 Tappet--Valve
46 790958 Camshaft

Dz∆694874 Gasket--Intake

51K

51AK

Dz∆694875 Gasket--Intake

53 694869 Stud

(Carburetor)

55 695288 Housing--Rewind

Starter

55A 691421 Housing--Rewind

Starter

58 693389 Rope--Starter

(Cut To Required
Length)

59 805957 Insert--Grip
60 490652 Grip--Starter Rope
65 690837 Screw

(Rewind Starter)

-- -- -- -- -- -- N o t e -- -- -- -- -- -­690759 Screw

(Rewind Starter)
Used on Type No(s).
0110, 0115, 0129,
0141, 0143, 0154,
0157, 0164, 0168,
0177, 0179, 0214,

0278.

78 690372 Screw

(Cover Flywheel
Guard)

81 695400 Lock--Muffler Screw

Dz690602 Bushing--Throttle Shaft

93

(Walbro)

95 691636 Screw

(Throttle Valve)

95A 690718 Screw

(Throttle Valve)

97 695325 Shaft--Throttle

97A 696387 Shaft--Throttle

D495800 Kit--Idle Speed

98

D695408 Kit--Idle Speed

98A

104 D690525 Pin--Float Hinge

104A D694918 Pin--Float Hinge

D691782 Valve--Float Needle

105

105A D696136 Valve--Float Needle

106 D690577 Seat--Inlet
108A 696143 Valve--Choke
108B 696209 Valve--Choke

(Used Before Code
Date 04020500).
Used on Type No(s).
0109, 0118, 0129,
0130, 0134, 0136,
0141, 0142, 0143,
0145, 0147, 0149,
0153, 0154, 0156.

109 695331 Shaft--Choke
109D 790149 Shaft--Choke

109E 696735 Shaft--Choke

109G 790077 Shaft--Choke

D696134 Jet--Main

117

(Standard)

118 696135 Jet--Main

(High Altitude)

121 695441 Kit--Carburetor

Overhaul
(Walbro)

121A 696146 Kit--Carburetor

Overhaul
(Nikki)

122 694876 Spacer--Carburetor

125 Carburetor

(For Service of
Complete Carburetor,
See Ref 125A)

125A 699966 Carburetor

D694524 Plug--Welch

127
127A

130A 696139 Valve--Throttle

D690727 Plug--Welch

130 690468 Valve--Throttle

133 494381 Float--Carburetor

133A 694914 Float--Carburetor

135 696142 Tube--Fuel Transfer
137

Dz281165S Gasket--Float Bowl

137A

141A 698457 Kit--Choke Shaft
141C 699979 Kit--Choke Shaft

161A 699960 Base--Air Cleaner

D695426 Gasket--Float Bowl

141 696145 Kit--Choke Shaft

142 695528 Nozzle--Carburetor

(Standard)

143 695529 Nozzle--Carburetor

(High Altitude)

146 690979 Key--Timing
161 695384 Base--Air Cleaner

(Metal)

(Metal)
Used on Type No(s).
0163, 0164, 0168,
0171, 0177, 0178,
0179, 0278.

-- -- -- -- -- -- N o t e -- -- -- -- -- -­699960 Base--Air

Cleaner
(Metal)
(Used After Code Date

04020400).
Used on Type No(s).
0109, 0118, 0129,
0130, 0134, 0136,
0141, 0142, 0143,
0145, 0147, 0149,
0153, 0154, 0156.
694870 Base--Air
Cleaner
(Metal)
(Used Before Code
Date 04020500).
Used on Type No(s).
0109, 0118, 0129,
0130, 0134, 0136,
0141, 0142, 0143,
0145, 0147, 0149,
0153, 0154, 0156.

163K

Dz692277 Gasket--Air Cleaner

170 695296 Stud

(Crankcase
Cover/Sump)

K Included in Engine Gasket Set--Ref. No. 358.
D Included in Carburetor Overhaul Kit--Ref. No. 121 or 121A.

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

6444--11 Assemblies include all parts shown in frames. 10/07/2008

11

z Included in Carburetor Gasket Set--Ref. No. 977.

∆ Included in Valve Gasket Set--Ref. No. 1095.

204400

Not for

Reproduction

REF. PART REF. PART REF. PART

NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION

185 690958 Nut

(Air Cleaner Base)

186 692317 Connector--Hose
187 791766 Line--Fuel

(15 Inches Long)(Cut
To Required Length)

187A 791869 Line--Fuel

(Used After Code Date

05063000).

-- -- -- -- -- -- N o t e -- -- -- -- -- -­695429 Line--Fuel

(Used Before Code
Date 05070100).

187B 791834 Line--Fuel

(Used After Code Date

05063000).

-- -- -- -- -- -- N o t e -- -- -- -- -- -­695482 Line--Fuel

(Used Before Code
Date 05070100).

187C 791871 Line--Fuel

(Used After Code Date

05063000).

-- -- -- -- -- -- N o t e -- -- -- -- -- -­695483 Line--Fuel

(Used Before Code
Date 05070100).

187E 791745 Line--Fuel

(23 Inches Long)(Cut
To Required Length)

188 690877 Screw

(Control Bracket)

190 692127 Screw

(Fuel Tank)

192 690083 Adjuster--Rocker Arm
209 694867 Spring--Governor

-- -- -- -- -- -- N o t e -- -- -- -- -- -­696638 Spring--

Governor
Used on Type No(s).
0114, 0115, 0125,

0157.

211 695307 Spring--Governed Idle
219 693578 Gear--Governor
220 691724 Washer

(Governor Gear)

222 695380 Bracket--Control

222A 694866 Bracket--Control

Used on Type No(s).
0109, 0118, 0119,
0125, 0129, 0130,
0134, 0136, 0141,
0142, 0143, 0145,
0146, 0147, 0149,
0150, 0151, 0153,
0154, 0156, 0162,
0163, 0164.

222B 791753 Bracket--Control

227 694864 Lever--Governor

Control

231 691636 Screw

(Choke Valve)

231A 690718 Screw

(Choke Valve)

240 298090S Filter--Fuel

Used on Type No(s).
0109, 0119, 0125,
0130, 0134, 0136,
0141, 0142, 0147.

-- -- -- -- -- -- N o t e -- -- -- -- -- -­394358S Filter--Fuel

Used on Type No(s).
0118, 0129, 0143,

0149.

240A 694485 Filter--Fuel

265 691024 Clamp--Casing
267 692577 Screw

(Casing Clamp)

268 691025 Casing--Control Wire

(Cut To Required
Length)

269

691026 Wire--Control

(Cut To Required
Length)

270 691027 Nut

(Control Wire Casing)

271 691028 Lever--Control

271A 695381 Lever--Control

276

Dz692255 Washer--Sealing

278 792008 Washer

(Governor Control
Lever)

281 697268 Panel--Control

(Used After Code Date

01102800).

-- -- -- -- -- -- N o t e -- -- -- -- -- -­695294 Panel--Control

(Used Before Code
Date 01102900).

286 695186 Module--Oil Sensor

(Used Before Code
Date 03010600).
Used on Type No(s).
0109, 0118, 0119,
0130, 0134, 0136,
0142, 0145, 0146,
0147, 0149, 0150,

0151.

286A 696058 Module--Oil Sensor

(Used Before Code
Date 03010600).
Used on Type No(s).

0143.

286C 699951 Module--Oil Sensor

(Used After Code Date

03010500).
Used on Type No(s).
0109, 0118, 0119,
0129, 0130, 0134,
0136, 0141, 0142,
0143, 0145, 0146,
0147, 0149, 0150,
0151, 0153, 0154,
0156, 0162, 0164,
0178, 0278.

287 691693 Screw

(Dipstick Tube)

298 698838 Locknut--Muffler/Elbow
300 697252 Muffler

300C 793701 Muffler

(This muffler is
intended for
replacement purposes
only and is not to be
used for retrofitting to
engines with different
exhaust systems)

K Included in Engine Gasket Set--Ref. No. 358.
D Included in Carburetor Overhaul Kit--Ref. No. 121 or 121A.

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

6444--12 Assemblies include all parts shown in frames. 10/07/2008

12

z Included in Carburetor Gasket Set--Ref. No. 977.

∆ Included in Valve Gasket Set--Ref. No. 1095.

204400

Not for

Reproduction

REF. PART REF. PART REF. PART

NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION

304 791478 Housing--Blower

-- -- -- -- -- -- N o t e -- -- -- -- -- -­791478 Housing--

Blower
(Used Before Code
Date 03012200).
Used on Type No(s).

0156.
791478 Housing-­Blower
(Used Before Code
Date 01081400).
Used on Type No(s).

0109.

304A 791481 Housing--Blower

(Used After Code Date

03012100).
Used on Type No(s).

0156.

-- -- -- -- -- -- N o t e -- -- -- -- -- -­791481 Housing--

Blower
(Used After Code Date

01081300).
Used on Type No(s).

0109.

305 691108 Screw

(Blower Housing)

-- -- -- -- -- -- N o t e -- -- -- -- -- -­691125 Screw

(Blower Housing)
Used on Type No(s).
0142, 0147, 0154,
0156, 0163, 0164,
0168, 0171.

306 697240 Shield--Cylinder

(Used After Code Date

01102800).

-- -- -- -- -- -- N o t e -- -- -- -- -- -­696698 Shield--

Cylinder
(Used Before Code
Date 01102900).

307 691108 Screw

(Cylinder Shield)
(M4)

-- -- -- -- -- -- N o t e -- -- -- -- -- -­691660 Screw

(Cylinder Shield)
(1/4--20)

309 695479 Motor--Starter

-- -- -- -- -- -- N o t e -- -- -- -- -- -­794498 Motor--Starter

Used on Type No(s).
0164, 0168, 0179,
0177E1.

310 690323 Screw

(Starter Motor)

332 694685 Nut

(Flywheel)

333 492341 Armature--Magneto
334 691061 Screw

(Magneto Armature)

337 491055S Plug--Spark

-- -- -- -- -- -- N o t e -- -- -- -- -- -­691043 Plug--Spark

Used on Type No(s).
0105, 0118, 0536.

347 698338 Switch--Rocker

Used on Type No(s).
0125, 0155, 0163,
0168, 0171, 0177,

0179.

347A 697854 Switch--Rocker

Used on Type No(s).
0109, 0118, 0119,
0129, 0130, 0134,
0136, 0141, 0142,
0145, 0146, 0147,
0149, 0150, 0151,
0153, 0154, 0156,
0162, 0164, 0178,

0278.

347B 790949 Switch--Rocker

355 691075 Washer

(Muffler Bracket)

356 692603 Wire--Stop
356A 692390 Wire--Stop
356B 695815

Wire--Stop
Used

on Type No(s).
0036, 0114, 0117,
0160, 0213, 0214.

356C 695295 Wire--Stop
356D 695366 Wire--Stop

Used on Type No(s).

0143.

-- -- -- -- -- -- N o t e -- -- -- -- -- -­695366 Wire--Stop

(Used After Code Date
03010500 and Before
Code Date 03072400).
Used on Type No(s).
0109, 0118, 0119,
0129, 0130, 0134,
0136, 0141, 0142,
0145, 0146, 0147,
0149, 0150, 0151,
0153, 0154, 0156.

356F 697336 Wire--Stop

Used on Type No(s).
0115, 0143, 0157.

356J 699994 Wire--Stop

Used on Type No(s).
0143, 0162, 0164,
0178, 0278.

-- -- -- -- -- -- N o t e -- -- -- -- -- -­699994 Wire--Stop

(Used After Code Date

03072300).
Used on Type No(s).
0109, 0118, 0119,
0129, 0130, 0134,
0136, 0141, 0142,
0145, 0146, 0147,
0149, 0150, 0151,
0153, 0154, 0156.

356L 792609 Wire--Stop

358 695438 Gasket Set--Engine
361 691681 Screw

(Starting Switch)
Used on Type No(s).

0109.

361A 690297 Screw

(Starting Switch)

K Included in Engine Gasket Set--Ref. No. 358.
D Included in Carburetor Overhaul Kit--Ref. No. 121 or 121A.

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

6444--13 Assemblies include all parts shown in frames. 10/07/2008

13

z Included in Carburetor Gasket Set--Ref. No. 977.

∆ Included in Valve Gasket Set--Ref. No. 1095.

204400

Not for

Reproduction

REF. PART REF. PART REF. PART

NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION

363 19203 Puller--Flywheel

364A 699947 Terminal--Oil Plug

Used on Type No(s).
0109, 0118, 0119,
0129, 0130, 0134,
0136, 0141, 0142,
0143, 0145, 0146,
0147, 0149, 0150,
0151, 0153, 0154,
0156, 0162, 0164,
0178, 0278.

369 695422 Spring--Float Bowl
383 19374S Wrench--Spark Plug
410 695382 Link--Control
415 691363 Plug
425 694515 Screw

(Air Cleaner Cover)

425A 790043 Screw

(Air Cleaner Cover)

436C 792374 Manifold--Exhaust

437 696705 Screw

(Exhaust Manifold)

445 491588S Filter--Air Cleaner

Cartridge

455 694683 Cup--Flywheel

-- -- -- -- -- -- N o t e -- -- -- -- -- -­694683 Cup--Flywheel

(Used Before Code
Date 03012100).
Used on Type No(s).

0156.

455A 697357 Cup--Flywheel

Used on Type No(s).
0109, 0178.

-- -- -- -- -- -- N o t e -- -- -- -- -- -­697357 Cup--Flywheel

(Used After Code Date

03012100).
Used on Type No(s).

0156.

456 692299 Plate--Pawl Friction
459 281505S Pawl--Ratchet

474A 695730 Alternator

(3 Amps DC)
Used on Type No(s).
0115, 0141, 0143,
0154, 0157, 0214,

0278.

474D 695466 Alternator

(10 Amp Regulator)
Used on Type No(s).

0110.

493 694861 Bracket--Mounting

-- -- -- -- -- -- N o t e -- -- -- -- -- -­691177 Bracket--

Mounting
Used on Type No(s).
0110, 0157.

500 691086 Washer

(Key Switch)

500A 792613 Washer

(Key Switch)

501 691185 Regulator

Used on Type No(s).

0110.

501A 691188 Regulator

Used on Type No(s).

0157.

503 691532 Strap--Starter
504 695383 Washer Set--Friction
505 691251 Nut

(Governor Control
Lever)

510 693699 Drive--Starter
513 692024 Clutch--Drive
522 697689 Plug--Dipstick/Fill

Used on Type No(s).
0130, 0134, 0149,
0150, 0151, 0164,

0168.

523

695344 Dipstick
524 691876 Seal--Dipstick Tube
525 695343 Tube--Dipstick
526 690297 Screw

(Regulator)
Used on Type No(s).

0110.

526A 690326 Screw

(Regulator)
Used on Type No(s).

0157.

529 791822 Grommet
544 692034 Armature--Starter
552 694674 Bushing--Governor

Crank

562 793216 Bolt

(Governor Control
Lever)

564 692577 Screw

(Control Cover)

564A 692198 Screw

(Control Cover)

575 692303 Switch--Starting

577A 690795 Cable--Starter

578 692306 Wire Assembly

578A 790948 Wire Assembly

579 691029 Nut

(Starter Cable)

592 690800 Nut

(Rewind Starter)

597 691696 Screw

(Pawl Friction Plate)

601 791850 Clamp--Hose

K Included in Engine Gasket Set--Ref. No. 358.
D Included in Carburetor Overhaul Kit--Ref. No. 121 or 121A.

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

6444--14 Assemblies include all parts shown in frames. 10/07/2008

14

z Included in Carburetor Gasket Set--Ref. No. 977.

∆ Included in Valve Gasket Set--Ref. No. 1095.

204400

Not for

Reproduction

REF. PART REF. PART REF. PART

NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION

604 697326 Cover--Control

Used on Type No(s).

0145.

-- -- -- -- -- -- N o t e -- -- -- -- -- -­697326 Cover--Control

(Used Before Code
Date 05071800).
Used on Type No(s).
0109, 0147, 0149,
0150, 0151, 0163,

0164.
697326 Cover--Control
(Used After Code Date
01061000 and Before
Code Date 05071800).
Used on Type No(s).
0118, 0119, 0125,
0129, 0130, 0134,
0142, 0143.
696078 Cover--Control
(Used Before Code
Date 01061100).
Used on Type No(s).
0118, 0119, 0125,
0129, 0130, 0134,
0142, 0143.

604A 791752 Cover--Control

Used on Type No(s).
0168, 0171, 0177,
0178, 0278.

-- -- -- -- -- -- N o t e -- -- -- -- -- -­791752 Cover--Control

(Used After Code Date

05071700).
Used on Type No(s).
0109, 0119, 0125,
0129, 0134, 0142,
0143, 0147, 0150,
0151, 0154, 0156,
0163, 0164

608 695287 Starter--Rewind

-- -- -- -- -- -- N o t e -- -- -- -- -- -­697356 Starter--

Rewind
Used on Type No(s).
0109, 0178.
697356 Starter-­Rewind
(Used After Code Date

03012100).
Used on Type No(s).

0156.
695287 Starter-­Rewind
(Used Before Code
Date 03012200).
Used on Type No(s).

0156.

608A 497680 Starter--Rewind

613 695312 Screw

(Muffler)

613A 695399 Screw

(Muffler)

615 694676 Retainer--Governor

Shaft

616 694675 Crank--Governor
621 692310 Switch--Stop
622 698839 Washer

(Heat Shield)

627 696064 Bracket--Stopswitch

627A 792608 Bracket--Stopswitch

632 694868 Link--Throttle

(Walbro)

-- -- -- -- -- -- N o t e -- -- -- -- -- -­695917 Link--Throttle

(Nikki)

633

Dz690597 Seal--Choke/Throttle

Shaft

633A

Dz691326 Seal--Choke/Throttle

Shaft

633B

641A 690282 Washer

D690998 Seal--Choke/Throttle

Shaft

635 691909 Boot--Spark Plug
636 696198 Nut

(Starting Switch)

641 691075 Washer

(Starting Switch)

(Starting Switch)

663 692577 Screw

(Control Panel)

664 691087 Nut

(Key Switch)

668 694257 Spacer

(Control Bracket)

676 393761 Deflector--Muffler
677 690367 Screw

(Muffler Deflector)

689 691855 Spring--Friction
692 691301 Spring--Detent
695 698807 Screw

(Ring Gear)

697 690372 Screw

(Drive Cap)

718 690959 Pin--Locating

(Head)

718A 695178 Pin--Locating

(Head)

725A 698836 Shield--Heat

Used on Type No(s).
0142, 0147, 0154,
0156, 0163, 0164,
0168, 0171.

725B 698837 Shield--Heat

Used on Type No(s).
0142, 0147, 0154,
0156, 0163, 0164,

0168.

727A 697465 Cover--Starter Drive

728 696763 Screw

(Heat Shield)

732 691097 Screw

(Starter Drive Cover)

740 710090 Nut

(Muffler Bracket)

740A 793859 Nut

(Muffler Bracket)

741 691288 Gear--Timing
742 692564 Retainer--E Ring
746 694679 Gear--Idler
773 694258 Retainer
774 695447 Screw

(Stop Wire)

783 693713 Gear--Pinion
798 697890 Screw

(Rocker Arm)

799 695446 Screw
801 694482 Cap--Drive
802 691286 Cap--End
803 Housing--Starter

(Not Serviced
Separately, Order
Starter Motor 695479)

813 690635 Clamp
819 690352 Screw

(Muffler Bracket)

K Included in Engine Gasket Set--Ref. No. 358.
D Included in Carburetor Overhaul Kit--Ref. No. 121 or 121A.

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

6444--15 Assemblies include all parts shown in frames. 10/07/2008

15

z Included in Carburetor Gasket Set--Ref. No. 977.

∆ Included in Valve Gasket Set--Ref. No. 1095.

204400

Not for

Reproduction

REF. PART REF. PART REF. PART

NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION

832 795035 Guard--Muffler

832C 792380 Guard--Muffler

836 695312 Screw

(Muffler Guard)
(Used After Code Date

01061000).

-- -- -- -- -- -- N o t e -- -- -- -- -- -­690367 Screw

(Muffler Guard)
(Used Before Code
Date 01061100).

836C 710023 Screw

(Muffler Guard)

842 691031 Seal--O Ring

(Dipstick Tube)

847 695342 Dipstick/Tube

Assembly

851 692424 Terminal--Spark Plug

863C 793700 Bracket--Muffler

868 K∆690968 Seal--Valve

883 K∆695398 Gasket--Exhaust
883A K697255 Gasket--Exhaust
883C 710250 Gasket--Exhaust

892 392833 Switch--Key
892A 791944 Switch--Key

914 693732 Screw

(Rocker Cover)

920 691656 Solenoid--Starter

950 695407 Screw--Float Bowl

-- -- -- -- -- -- N o t e -- -- -- -- -- -­691657 Screw--Float

Bowl
Used on Type No(s).
0036, 0100, 0110,

0114.

951 699961 Shaft--Choke

955 695659 Plug--Carburetor

957 792647 Cap--Fuel Tank

(Plastic)

958 698180 Valve--Fuel Shut Off

(Plastic)

967 491435S Filter--Pre Cleaner

968 790959 Cover--Air Cleaner
968A 692321 Cover--Air Cleaner
972A 694260 Tank--Fuel

(Plastic)

975 495933 Bowl--Float
975A 696138 Bowl--Float

977 695439 Gasket Set--Carburetor

(Walbro)

990 691959 Key Set
990A 695756 Key Set

998 696683 Pipe--Oil

1005 694684 Fan--Flywheel
1022 K∆690971 Gasket--Rocker Cover
1023 697691 Cover--Rocker Arm
1026 695177 Rod
1029 690972 Arm--Rocker
1036 Label--Emissions

1046 691337 Plug--Blower Housing

1051 691265 Ring--Retaining

1052A 791159 Sensor--Oil

1058 277040 Manual--Operator’s

1070 691183 Screw

--Push

(Available From A
Briggs & Stratton
Authorized Dealer)

Used on Type No(s).

0143.

-- -- -- -- -- -- N o t e -- -- -- -- -- -­MS3780 Manual--

Operator’s
Used on Type No(s).
0105, 0136, 0141,
0153, 0156E1, 0162,

0536.
MS3797 Manual-­Operator’s
Used on Type No(s).
0154, 0156E2, 0178,
0213, 0214, 0276,
0278, 0417, 0529.

(Flywheel Fan)

1090 691293 Retainer--Brush
1095 695440 Gasket Set--Valve
1100 791959 Pivot--Rocker Arm

1119 691058 Screw

(Alternator)

-- -- -- -- -- -- N o t e -- -- -- -- -- -­691183 Screw

(Alternator)
Used on Type No(s).
0110, 0115, 0129,
0141, 0143, 0154,
0157, 0214, 0278.

1127A 695407 Screw

(Float Bowl)

1138 694255 Nut

(Control Bracket)

1171 696754 Stud

(Rocker Cover)
Used on Type No(s).
0134, 0142, 0147,
0150, 0151, 0154,
0156, 0163, 0164,
0168, 0171, 0177,
0178, 0179, 0278.

1177 710090 Nut

(Muffler)

1194 691876 Seal--O Ring

(Plug)

1210 498144 Pulley/Spring

Assembly
(Pulley)

1211 498144 Pulley/Spring

Assembly
(Spring)

1230 791754 Stud

(Control Bracket)

1298 696757 Nut

(Heat Shield)

1319 794467 Label--Warning
1404 696757 Nut

(Control Cover)

K Included in Engine Gasket Set--Ref. No. 358.
D Included in Carburetor Overhaul Kit--Ref. No. 121 or 121A.

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

6444--16 Assemblies include all parts shown in frames. 10/07/2008

16

z Included in Carburetor Gasket Set--Ref. No. 977.

∆ Included in Valve Gasket Set--Ref. No. 1095.

Not for

Reproduction

Not for

Reproduction

Not for

Reproduction

Not for

Reproduction
