Parts Manual fo
r
7
2
2
19" WALK BEHIND MOWERS
SERIES
MODEL
19307T-2
19357B
D19357B
DLW307T-2
DLW357B
G19357B
GLW357B
GLW407T-
LW307T-
LW357B
RLW357B
RLW407T-2
COPYRIGHT ©2005
SNAPPER PRODUCTS, INC.
ALL RIGHTS RESERVED.
Revision 3,
McDonough, GA, 30253 U.S.A.
9/16/2005
Manual No. 7006038
TP 400-5097-3-WB-N
s
PAGE GROUP
4
6
8
10
12
14
16
18
20
22
Handles, Blade Control
Cutting Deck, Blade Interlock
Wheels, Guard, Axles
Accessory - Grass Bag
Accessory - Side Chute, Adapter
Accessory - Recycling Plug Kit
Decals (Part 1)
Decals (Part 2)
Accessory - Mulcherizer
Recycling Kit
Table Of Content
SERIES 7
Manual No. 700603819" WALK BEHIND MOWERS
3
TP 400-5097-3-WB-N
Handles, Blade Control
Manual No. 7006038 19" WALK BEHIND MOWERS
TP 400-5097-3-WB-N
4
SERIES 7
Handles, Blade Control
p
y
Part No Descri
1 7036353 HANDLE, Upper (Tecumseh)
7036354 HANDLE, Upper (Briggs)
2 7036350 HANDLE, Middle
3 7046502 HANDLE, Lower Left Hand Was 38467
4 7035342 HANDLE, Lower Right Hand Was 38466
5 7017072 CONTROL, Blade
6 7033904 CLIP, Blade Control Was 32829
7 7023820 CABLE, Blade Control (Briggs) ('90 Models)
7016121 CABLE, Blade Control (Tecumseh) ('90 Models)
7016707 CABLE, Blade Control (Briggs 3.5 HP) ('91 Models &
7023765 CABLE, Blade Control (Briggs 3.5 HP) (European
7016121 CABLE, Blade Control (Tecumseh 3 HP 2-CY.) ('91
7016709 CABLE, Blade Control (Tecumseh 4 HP 2-CY.) ('91
8 7014343 2 BUSHING
9 7023813 CLIP, Cable/Wiring
10 7019263 CONTROL, Throttle ('90 Models)
7017274 CONTROL, Throttle ('91 Models & Later) (Briggs)
7019254 CONTROL, Throttle ('91 Models & Later) (European
7016706 CONTROL, Throttle ('91 Models & later) (Tecumseh)
11 7023153 CLAMP, Casing
12 7023154 SCREW, #10-32 x 5/8" Self-Tapping (Briggs)
7090898 SCREW, 310-32 x 9/32" Self-Tap Sems (Tecumseh)
13 7023735 4 KNOB, 5/16-18
14 7091013 4 SCREW, 5/16-18 x 2" Curved Head
15 7023745 DECAL, Blade Control
7023893 DECAL, Blade Control (European Models)
16 7090816 SCREW, #10-32 x 3/8" Hex Head Cap, (Briggs)
17 7090799 4 BOLT, 5/16-18 x 5/8" Short Neck Carriage, Grade 5
7090799 4 BOLT, 5/16-18 x 5/8" Short Neck Carriage Was 91026 ('91 Models & Later)
18 7091601 4 NUT, 5/16-18 Hex Flange Lock, Grade 5 Was 90585
19 7090122 SCREW, 1/4-28 x 1-3/4" Hex Head Cap, Grade 5
20 7090053 WASHER, 1/4" Internal Tooth Lock Was 91023
21 7090095 NUT, 1/4-28 Hex, Grade 5 or B Was 91024
tionItem Qt
Note
Later)
Models)
Models & Later)
Models & Later)
Briggs)
Footnotes:
Manual No. 700603819" WALK BEHIND MOWERS
SERIES 7
5
TP 400-5097-3-WB-N
Cutting Deck, Blade Interlock
Manual No. 7006038 19" WALK BEHIND MOWERS
TP 400-5097-3-WB-N
6
SERIES 7
Cutting Deck, Blade Interlock
p
y
Part No Descri
1 7057662 WELDMENT, Deck (Tall Engine Mount) Was 47972
2 7017031 BLADE, Cutter (Replaces 19711)
7017167 BLADE, Cutter (Recycling Models)
3 7090167 SCREW, 3/8-24 x 2" Hex Head Cap, Grade 5
4 7012063 WASHER, Cone
5 7010783 KEY, Hi-Pro
6 7012927 HUB, Blade Drive ('90 Models & Earlier)
7015626 HUB, Blade Drive ('91 Models & Later)
7 7032137 SPRING, Interlock
8 7012048 INSULATOR, Interlock
9 7090385 WASHER, #8 Tab
10 7090379 SCREW, #8-18 x 3/4" Sheet Metal
11 7090071 2 SCREW, 1/4-20 x 1/2" Hex Head Cap, Grade 5
12 7091584 2 NUT, 1/4-20 Hex Flange Was 90583
13 7090204 4 SCREW, 5/16-18 x 5/8" Hex Head Cap, Grade 2 (only 1 shown)(Tecumseh)
14 7091601 4 NUT, 5/16-18 Hex Flange Lock Was 90585 (Tecumseh)
15 17191 4 RETAINER, 5/16" Bolt (Tecumseh) ENGINE
16 7090324 3 SCREW, 3/8-16 x 1" Hex Washer Self-Tap (Briggs) ENGINE MOUNTING
17 7011762 COVER, Spark Plug (Not shown)
18 7049753 STRUCTURE, Fender (European Models Only)
tionItem Qt
Note
ENGINE MOUNTING
HARDWARE
ENGINE MOUNTING
HARDWARE
MOUNTING HARDWARE
HARDWARE
Footnotes:
Manual No. 700603819" WALK BEHIND MOWERS
SERIES 7
7
TP 400-5097-3-WB-N
Wheels, Guard, Axles
Manual No. 7006038 19" WALK BEHIND MOWERS
TP 400-5097-3-WB-N
8
SERIES 7
Wheels, Guard, Axles
p
y
Part No Descri
1 7019193 2 WHEEL, Front 7 x 1.75 ('90 Models)
7019331 2 WHEEL, Front 7 x 1.75 ('91 Models & Later)
2 7013024 4 HUB-CAP, Wheel
3 7013320 BUSHING, Height Adjustment
4 7013307 SPRING, Rear Axle
5 7090122 6 WASHER, 3/8" Flat
6 7034357 2 AXLE, 3/8 x 19-3/8" Was 37946
7 7022260 2 WHEEL, Rear 8 x 2.00 Was 19194 ('90 Models)
7019332 2 WHEEL, Rear 8 x 2.00 ('91 Models & Later)
8 7032118 2 CLIP, Rear Guard
9 7013027 2 SPRING, Rear Axle
10 7018444 FOOT-GUARD, Rear
11 7019381 4 COVER, Wheel
tionItem Qt
Note
Footnotes:
Manual No. 700603819" WALK BEHIND MOWERS
SERIES 7
9
TP 400-5097-3-WB-N
Accessory - Grass Bag
Manual No. 7006038 19" WALK BEHIND MOWERS
TP 400-5097-3-WB-N
10
SERIES 7
Accessory - Grass Bag
p
y
Part No Descri
7061918 KIT, Grass Bag Catcher Was 60934 (Includes 1 thru 5)
7059322 KIT, Grass bag Catcher Was 60932 (Includes 1 thru 4)
1 7059322 ASSEMBLY, Grass Bag Was 51899 (Includes items 2
2 7017069 BAG, KWIK-N-EZY
3 7051906 ASSEMBLY, Bag Wire
4 7042489 CONNECTOR, Grass Bag Was 47969
5 7053681 ADAPTER, Bag Was 16088
6 7023152 DEFLECTOR, Muffler (Briggs)
7 7023023 3 SCREW, #8-18 x 3/8" Hex Head Cap
tionItem Qt
Note
thru 4)
Footnotes:
Manual No. 700603819" WALK BEHIND MOWERS
SERIES 7
11
TP 400-5097-3-WB-N
Accessory - Side Chute, Adapter
Manual No. 7006038 19" WALK BEHIND MOWERS
TP 400-5097-3-WB-N
12
SERIES 7
Accessory - Side Chute, Adapter
p
y
Part No Descri
1 7053681 ADAPTER, Bag Was 16088
7051952 ASSEMBLY, Bag Adapter (European Models)
2 7035771 CHUTE, Side Was 28504
3 7090799 3 BOLT, 5/16-18 x 5/8" Short Neck Carriage, Grade 5 ('90 Models)
7090799 3 BOLT, 5/16-18 x 5/8" Short Neck Carriage, Gr. 5 Was 91026 ('91 Models & Later)
4 7090951 3 NUT, 5/16-18 Hex Flange Center Lock
5 7011791 3 RETAINER, 5/16 Bolt
tionItem Qt
Note
Footnotes:
Manual No. 700603819" WALK BEHIND MOWERS
SERIES 7
13
TP 400-5097-3-WB-N
Accessory - Recycling Plug Kit
Manual No. 7006038 19" WALK BEHIND MOWERS
TP 400-5097-3-WB-N
14
SERIES 7
Accessory - Recycling Plug Kit
p
y
Part No Descri
7061033 KIT, Recycling Plug (Includes items 1 thru 4)
1 7017167 BLADE, 19" recycling
2 7016814 PLUG, Chute Adapter
3 7090167 SCREW, 3/8-24 x 2" Hex Head Cap, Grade 5
4 7012063 WASHER, Cone
tionItem Qt
Note
Footnotes:
This Kit is used on Models With Grass Bags
Manual No. 700603819" WALK BEHIND MOWERS
SERIES 7
15
TP 400-5097-3-WB-N
Decals (Part 1)
Manual No. 7006038 19" WALK BEHIND MOWERS
TP 400-5097-3-WB-N
16
SERIES 7
Decals (Part 1)
p
y
Part No Descri
1 7013010 DECAL, Danger (Keep Hands & Feet Away)
2 7044640 NAMEPLATE, SNAPPER Was 19279
3 7023870 DECAL, Warning
4 7013312 DECAL, Caution
tionItem Qt
Note
Footnotes:
Manual No. 700603819" WALK BEHIND MOWERS
SERIES 7
17
TP 400-5097-3-WB-N
Decals (Part 2)
Manual No. 7006038 19" WALK BEHIND MOWERS
TP 400-5097-3-WB-N
18
SERIES 7
Decals (Part 2)
p
y
Part No Descri
1 7017317 DECAL, Recycling Mower
2 17297 DECAL, Housing (Tecumseh)
3 17291 DECAL, Housing (Tecumseh)
4 17292 DECAL, Recoil (Tecumseh & Briggs)
5 17293 DECAL, Housing (Briggs)
6 17294 DECAL, Recoil (European)
7 17295 DECAL, Housing (European)
8 7023032 DECAL, Air Cleaner (European) (Not shown) MUST
9 7023037 LABEL, EUROPE
10 7017149 LOGO, SNAPPER
tionItem Qt
Note
BE ORDERED FROM BRIGGS
Footnotes:
Manual No. 700603819" WALK BEHIND MOWERS
SERIES 7
19
TP 400-5097-3-WB-N
Accessory - Mulcherizer
Manual No. 7006038 19" WALK BEHIND MOWERS
TP 400-5097-3-WB-N
20
SERIES 7
Accessory - Mulcherizer
p
y
Part No Descri
60457 KIT, Mulcherizer (Includes items 1 thru 8)
1 7019690 3 LINER
2 7013870 HUB, 7/8" I.D.
3 7019673 BLADE, Mulcherizer
4 7091506 SCREW, 3/8-24 x 1-3/4" Hex Head Cap, Grade 5 Was 90484
5 7012063 2 WASHER, Cone
6 7090100 3 SCREW, 1/4-28 x 5/8" Hex Head Cap, Grade 5
7 7091294 6 WASHER, 1/4" Flat Was 90055
8 7090303 3 NUT, 1/4-28 Hex Top Lock
tionItem Qt
Note
Footnotes:
Manual No. 700603819" WALK BEHIND MOWERS
SERIES 7
21
TP 400-5097-3-WB-N
Recycling Kit
Manual No. 7006038 19" WALK BEHIND MOWERS
TP 400-5097-3-WB-N
22
SERIES 7
Recycling Kit
p
y
Part No Descri
7061029 KIT, Recycling (Includes items 1 thru 4)
1 7017167 BLADE, 19" Recycling
2 7017169 COVER
3 7090167 SCREW, 3/8-24 X 2" Hex Head Cap, Grade 5
4 7012063 WASHER, Cone
tionItem Qt
Note
Footnotes:
This Kit is used on Side Discharge Models
Manual No. 700603819" WALK BEHIND MOWERS
SERIES 7
23
TP 400-5097-3-WB-N
Parts Manual fo
r
19" WALK BEHIND MOWERS
SERIES 7
RESERVE THE RIGHT TO MAKE CHANGES OR ADD IMPROVEMENTS
COPYRIGHT ©2005
SNAPPER PRODUCTS, INC.
ALL RIGHTS RESERVED.
IT IS THE POLICY OF SNAPPER TO IMPROVE ITS PRODUCTS
WHENEVER IT IS POSSIBLE AND PRACTICAL TO DO SO. WE
AT ANY TIME WITHOUT INCURRING ANY OBLIGATION TO MAKE
SUCH CHANGES ON PRODUCTS MANUFACTURED PREVIOUSLY.
McDonough, GA, 30253 U.S.A.
Revision 3,
9/16/2005
Manual No. 700603 8
TP 400-5097-3-WB-N
