Parts Manual fo
r
2
2
T
2
T
T
T
19" WALK-BEHIND MOWERS
SERIES 0, 1, 3, & 5
MODEL
19300
1930019301-
19301D
19301D-2
19301
19303
19303-
19303-2
19303B
19303D
19303D-2
19303D-2
19303DB
19305-2
19305B
19305DB
G19355
COPYRIGHT ©2005
SNAPPER PRODUCTS, INC.
ALL RIGHTS RESERVED.
Revision 3,
McDonough, GA, 30253 U.S.A.
9/20/2005
Manual No. 7006031
TP 400-5101-3-WB-N
s
PAGE GROUP
4
6
8
10
12
14
16
18
20
22
Upper & Middle Handles & Controls - Series 0, 1 & 3
Upper & Middle Handles & Controls - Series 5
Lower Handles (19300, 19301 Series)
Lower Handles - Series 3 & 5
Cutting Deck, Blade, Interlock
Wheels, Guard, Axles
Accessory - Side Chute, Adapter, Grass Catcher - Series 0 & 1
Accessory - Grass Bag
Accessory - Mulcherizer
Decals
Table Of Content
SERIES 0, 1, 3, & 5
Manual No. 700603119" WALK-BEHIND MOWERS
3
TP 400-5101-3-WB-N
Upper & Middle Handles & Controls - Series 0, 1 & 3
Manual No. 7006031 19" WALK-BEHIND MOWERS
TP 400-5101-3-WB-N
4
SERIES 0, 1, 3, & 5
Upper & Middle Handles & Controls - Series 0, 1 & 3
p
y
Part No Descri
1 7036153 HANDLE, Upper (19303 Series). ('86 & '87
7036029 HANDLE, Upper (19300, 19301 Series). ('85 &
2 7014343 2 BUSHING
3 14310 DECAL, Blade Controls
4 7019714 CONTROL, Blade
5 7033904 CLIP (Left Hand-Tecumseh, Right Hand-Briggs) Was 32244
6 7014305 CABLE, Control (Briggs)
7014306 CABLE, Control (Tecumseh)
7 7090898 SCREW, #10-32 x 1/4" Hex Sems (Tecumseh)
7090816 SCREW, #10-32 x 3/8" Hex Head Cap (Briggs)
8 7036037 HANDLE, Middle (See "Lower Handles (19300,
9 7090095 2 NUT, 1/4-28 Hex
10 7090053 2 WASHER, 1/4" Internal Tooth Lock
11 7090529 2 SCREW, 1/4-28 x 1-1/4" Hex Head Cap, Grade 5
12 7023813 3 CLIP Was 14374
tionItem Qt
Note
Models)
'Earlier Models)
19301)" ill. & parts list for 19300
& 19301 Series)
Footnotes:
These 19303 Series Handles Are Required For Kwik-N-Ezy Grass Catchers
For 19300 & 19301 Series Handles Use Grass Catcher Found On "Accessory - Side Chute, Adapter, Grass Catcher"
illustration and parts list
Manual No. 700603119" WALK-BEHIND MOWERS
SERIES 0, 1, 3, & 5
5
TP 400-5101-3-WB-N
Upper & Middle Handles & Controls - Series 5
Manual No. 7006031 19" WALK-BEHIND MOWERS
TP 400-5101-3-WB-N
6
SERIES 0, 1, 3, & 5
Upper & Middle Handles & Controls - Series 5
p
y
Part No Descri
1 7036204 HANDLE, Upper Was 36198 (19303 Series)('88 &
2 7036202 HANDLE, Middle (19303 Series)('88 & Later
3 7019714 CONTROL, Blade
4 7033904 CLIP (Left Hand-Tecumseh, Right Hand-Briggs) Was 32560
5 7014305 CABLE, Control (Briggs & Stratton)
7014306 CABLE, Control (Tecumseh)
6 7014343 2 BUSHING
7 7023813 3 CLIP Was 14374
8 7015693 2 NUT, 1/4-20 Wing
9 7090965 2 SCREW, 1/4-20x1-3/8" Curved Head
10 14310 DECAL, Blade Control
11 7090898 SCREW, #10-32x1/4" Hex Sems (Tec.)
7090816 SCREW, #10-32x3/8" Hex Head Cap (B&S)
tionItem Qt
Note
Later Models)
Models)
Footnotes:
Manual No. 700603119" WALK-BEHIND MOWERS
SERIES 0, 1, 3, & 5
7
TP 400-5101-3-WB-N
Lower Handles (19300, 19301 Series)
Manual No. 7006031 19" WALK-BEHIND MOWERS
TP 400-5101-3-WB-N
8
SERIES 0, 1, 3, & 5
Lower Handles (19300, 19301 Series)
p
y
Part No Descri
1 7039746 HANDLE, Lower ('85 & Earlier). (19300, 19301
2 7015693 2 NUT, 1/4-20 Wing Was 14207
3 7090015 2 BOLT, 1/4-20 x 1-3/4" Square Neck Carriage
4 7091303 2 BOLT, 5/16-18 x 1" Short Neck Carriage, Grade 5 Was 90383
5 7090189 2 WASHER, 5/16" Internal/External Tooth Lock
6 7090188 2 WASHER, 5/16" Flat
7 7090187 2 WASHER, 5/16 Split Lock
8 7091511 2 NUT, 5/16-18 Hex Was 90196
9 7090534 2 SCREW, 5/16-18 x 1/2" Hex head Cap, Grade 2 Was 90203
10 7090388 2 T-NUT, 5/16-18
11 7023813 3 CLIP Was 14374
tionItem Qt
Note
Series)
Footnotes:
Manual No. 700603119" WALK-BEHIND MOWERS
SERIES 0, 1, 3, & 5
9
TP 400-5101-3-WB-N
Lower Handles - Series 3 & 5
Manual No. 7006031 19" WALK-BEHIND MOWERS
TP 400-5101-3-WB-N
10
SERIES 0, 1, 3, & 5
Lower Handles - Series 3 & 5
p
y
Part No Descri
1 7038209 2 HANDLE, Lower (19303). ('86 Model Year)
2 7038246 HANDLE, Lower R.H. (19303). ('87 Model Year)
3 7038247 HANDLE, Lower L.H. (19303). ('87 Model Year)
4 7035342 HANDLE, Lower R.H. (19305). ('88 Model Year & later)
5 7046502 HANDLE, Lower L.H. Was 38401 (19305). ('88 Model
6 7090015 2 BOLT, 1/4-20 x 1-3/4" Short Neck Carriage
7 7015693 2 NUT, 1/4-20 Wing Was 14207
8 7090799 4 BOLT, 5/16-18 x 5/8" Short Neck Carriage, Grade 5
9 7090188 2 WASHER, 5/16" Flat
10 7090189 2 WASHER, 5/16" Internal/External Tooth Lock
11 7091601 4 NUT, 5/16-18 Hex Flange Lock Was 90585
12 7090222 2 NUT, 5/16-24 Hex Center Lock
13 7090233 2 SCREW, 5/16-24 x 3/4" Hex Head Cap, Grade 5
14 7090534 2 SCREW, 5/16-15 x 1/2" Hex Head Cap, Grade 2 Was 90203
15 7090388 T-NUT, 5/16-18
16 7015693 2 NUT, 1/4-20 Wing
17 7090965 2 SCREW, 1/4-20 x 1-3/8" Curved Head
tionItem Qt
Note
Year & later)
Footnotes:
Manual No. 700603119" WALK-BEHIND MOWERS
SERIES 0, 1, 3, & 5
11
TP 400-5101-3-WB-N
Cutting Deck, Blade, Interlock
Manual No. 7006031 19" WALK-BEHIND MOWERS
TP 400-5101-3-WB-N
12
SERIES 0, 1, 3, & 5
Cutting Deck, Blade, Interlock
p
y
Part No Descri
1 40525 *DECK, Structure (Short engine mount) Not Available, use 57662
2 7019711 BLADE, Cutter
3 7090167 SCREW, 3/8-24 x 2" Hex Head Cap, Grade 5
4 7012063 WASHER, Cone
5 7010783 KEY, Hi-Pro
6 7012927 HUB, Blade Drive
7 7032137 SPRING, Interlock
8 7012048 INSULATOR, Interlock
9 7090385 WASHER, #8 Tab
10 7090379 SCREW, #8-18 x 3/4" Self-Tapping
11 7090071 2 SCREW, 1/4-20 x 1/2" Hex Head Cap, Grade 5
12 7091584 2 NUT, 1/4-20 Hex Flange Lock Was 90583
13 7090204 4 SCREW, 5/16-18 x 5/8" Hex Head Cap (Tecumseh). Engine Mounting
14 7091601 4 NUT, 5/16-18 Hex Flange Lock Was 90585 (Tecumseh). Engine
15 7011791 3 RETAINER, 5/16 Bolt (Tecumseh). Engine Mounting
16 7090324 3 SCREW, 3/8-16 x 1" Hex Washer Self-Tap (Briggs). Engine Mounting
tionItem Qt
Note
Hardware
Mounting Hardware
Hardware
Hardware
Footnotes:
Also you must install longer crankshaft.
It was 1 13/16" long, change to 2 7/16" long verson.
Manual No. 700603119" WALK-BEHIND MOWERS
SERIES 0, 1, 3, & 5
13
TP 400-5101-3-WB-N
Wheels, Guard, Axles
Manual No. 7006031 19" WALK-BEHIND MOWERS
TP 400-5101-3-WB-N
14
SERIES 0, 1, 3, & 5
Wheels, Guard, Axles
p
y
Part No Descri
1 7026160 2 WHEEL, Front 7 x 1.50 Was 18484
2 7013024 4 HUB-CAP, Wheel
3 7013320 4 BUSHING, Height Adjustment
4 7013307 1 SPRING, Front Axle
5 7090122 2 WASHER, 3/8" Flat
6 7034357 2 AXLE, 3/8 x 19-3/8" Was 37946
7 7029399 2 WHEEL, Rear 8 x 1.75 Was 18485
8 7032118 2 CLIP, Rear Guard
9 7013027 2 SPRING, Rear Axle
10 7018444 1 FOOT-GUARD, Rear
tionItem Qt
Note
Footnotes:
Manual No. 700603119" WALK-BEHIND MOWERS
SERIES 0, 1, 3, & 5
15
TP 400-5101-3-WB-N
Accessory - Side Chute, Adapter, Grass Catcher - Series 0 & 1
Manual No. 7006031 19" WALK-BEHIND MOWERS
TP 400-5101-3-WB-N
16
SERIES 0, 1, 3, & 5
Accessory - Side Chute, Adapter, Grass Catcher - Series 0 & 1
p
y
Part No Descri
7060422 KIT, Grass Catcher (Includes items 1 thru 6)
1 7018413 BAG, Grass
2 7050711 ASSEMBLY, Rope & Slider
3 7053681 ADAPTER, Bag Was 19920
4 7047876 CONNECTOR, Bag
5 7018412 WIRE, Rear Bag
6 7090375 WING-NUT, 5/16-18 (Not used anymore, use # 10)
7 7035771 CHUTE, Side 20" Was 28504
8 7090799 BOLT, 5/16-18 x 5/8" Short Neck Carriage, Grade 5
9 7090188 WASHER, 5/16 Flat
10 7090851 NUT, 5/16-18 Nyloc
11 7011791 RETAINER, 5/16 Bolt
tionItem Qt
Note
Footnotes:
Manual No. 700603119" WALK-BEHIND MOWERS
SERIES 0, 1, 3, & 5
17
TP 400-5101-3-WB-N
Accessory - Grass Bag
Manual No. 7006031 19" WALK-BEHIND MOWERS
TP 400-5101-3-WB-N
18
SERIES 0, 1, 3, & 5
Accessory - Grass Bag
p
y
Part No Descri
7060738 KIT, KWIN-N-EZY Catcher (Incl. Items 1 thru 5)
7060933 KIT, KWIN-N-EZY Catcher Was 60723 (Includes 1 thru 4)
1 7051636 ASSEMBLY, Grass Bag (Incl. Items 2 and 4)
2 7016005 BAG, KWIK-N-EZY
3 7051889 ASSEMBLY, Bag Wire Was 51577
4 7047876 CONNECTOR, Grass Bag
5 7053681 ADAPTER, Bag Was 19920
6 7023152 DEFLECTOR, Muffler (Briggs)
7 7023023 3 SCREW, #8-18 x 3/8" Hex Head Cap
tionItem Qt
Note
Footnotes:
Manual No. 700603119" WALK-BEHIND MOWERS
SERIES 0, 1, 3, & 5
19
TP 400-5101-3-WB-N
Accessory - Mulcherizer
Manual No. 7006031 19" WALK-BEHIND MOWERS
TP 400-5101-3-WB-N
20
SERIES 0, 1, 3, & 5
Accessory - Mulcherizer
p
y
Part No Descri
60457 KIT, Mulcherizer (Incl. Items 1 thru 8)
1 7019690 3 LINER
2 7013870 HUB, 7/8" I.D.
3 7019673 BLADE, Mulcherizer
4 7090483 SCREW, 3/8-24 x 1-3/4" Hex Head Cap, Grade 5
5 7012063 2 WASHER, Cone
6 7090100 3 SCREW, 1/4-28 x 5/8" Hex Head Cap, Grade 5
7 7091294 6 WASHER, 1/4" Flat Was 90055
8 7090303 3 NUT, 1/4-28 Hex Top Lock
tionItem Qt
Note
Footnotes:
Manual No. 700603119" WALK-BEHIND MOWERS
SERIES 0, 1, 3, & 5
21
TP 400-5101-3-WB-N
Decals
Manual No. 7006031 19" WALK-BEHIND MOWERS
TP 400-5101-3-WB-N
22
SERIES 0, 1, 3, & 5
Decals
p
y
Part No Descri
1 7013010 DECAL, Danger (Keep Hands & Feet Away)
2 7011160 DECAL, Cranking (Used on 19300 Series Only)
3 7012929 FOOT-PAD (Used on 19300 Series Only).
4 7013298 DECAL, Stop Warning (19300 Series w/Briggs Engine
5 13297 DECAL, Stop Warning (19300 Series w/Tecumseh
6 7013312 DECAL, Caution (Side Chute-Grass Catcher)
7 7023870 DECAL, Start-Stop Was 14345 (All 19301 & 19303
8 7024211 DECAL, Blade Control (All 19301 & 19303 Series)
9 7014898 DECAL, Warning - Discharge Opening (19303 Series)
tionItem Qt
Note
(Not Shown)
Only)
Engine Only)
Series)
Footnotes:
Manual No. 700603119" WALK-BEHIND MOWERS
SERIES 0, 1, 3, & 5
23
TP 400-5101-3-WB-N
Parts Manual fo
r
19" WALK-BEHIND MOWERS
SERIES 0, 1, 3, & 5
RESERVE THE RIGHT TO MAKE CHANGES OR ADD IMPROVEMENTS
COPYRIGHT ©2005
SNAPPER PRODUCTS, INC.
ALL RIGHTS RESERVED.
IT IS THE POLICY OF SNAPPER TO IMPROVE ITS PRODUCTS
WHENEVER IT IS POSSIBLE AND PRACTICAL TO DO SO. WE
AT ANY TIME WITHOUT INCURRING ANY OBLIGATION TO MAKE
SUCH CHANGES ON PRODUCTS MANUFACTURED PREVIOUSLY.
McDonough, GA, 30253 U.S.A.
Revision 3,
9/20/2005
Manual No. 700603 1
TP 400-5101-3-WB-N
