Snapper 1699022 User Manual

Not for

Reproduction

20" 48V Cordless Self-propelled Mower

2691565 & 80076017 / 20SPWM48

1688022 / 20SPWM48K

Owner’s Manual

TOLL-FREE HELPLINE: 1-800-317-7833

www.snapper.com

Read all safety rules and instructions carefully before operating this tool.

Not for

Reproduction

CONTENTS

Product Specications ..............................................................................2

Safety Informat io n ....................................................................................3

Symbols ...................................................................................................8

Features and Controls ............................................................................10

Assembly ...............................................................................................11

Operation ...............................................................................................18

Maintenance ..........................................................................................25

Environmentally Safe Battery D ispo sal ...................................................29

Troubleshooting ......................................................................................30

Warranty ................................................................................................31

Exploded View .......................................................................................34

Part s L is t ................................................................................................35

PRODUCT SPECIFICATIONS

48 V 20" CORDLESS SELF -PROP ELLED MOWER

Battery type ................................................................48 V Lithium- ion

No-load speed Self propelled speed Deck size Height adjustments Torque (for the blade bolt) Functions Weight (without battery)

Disclaimer: *Maximum initial battery voltage (measured without a workload) is 48 volts. Nominal voltage is 43.

.....................................................................2800 RPM

....................................2.3-4.44 fps (0.7-1.35 m/s)

.........................................................................20” (50.8 cm)

.....................................1 3/8 - 3 3/4” (3.5 - 9.5 cm)

..................................24-27 lb- f t (33-37 Nm)

.............................. 3-in-1: Mulch, side discharge or rear bag

................................................60 lbs (27.2 kg)

Not for

Reproduction

SAFETY INFORMATION

READ ALL INSTRUCTIONS

WARNING

This mower is capable of amputating hands and feet and throwing objects. Failure to observe the following safety instructions could result in serious injury or death.

WARNING

When using electric lawn mowers, basic safety precautions should always be

followed to reduce the risk of re, electric shock, and personal injury, including

the following:

1. GENERAL OPERATION

• Avoid Dangerous Environment – Don’t use lawn mowers in damp or wet locations.

• Don’t Use In Rain.

• Keep Children Away – All visitors should be kept a safe distance from work area.

• Dress properly. Do not wear loose clothing or jewelry that can get caught in moving parts. The wearing of protective gloves and safety footwear is recommended.

• Use Safety Glasses – Always use face or dust mask if operation is dusty.

• Use Right Appliance – Do not use lawn mower for any job except that for which it is intended.

• Don’t Force Lawn Mower – It will do the job better and safer at the rate for which it was designed.

• Don’t Overreach – Keep proper footing and balance at all times.

• Stay Alert – Do not operate the mower when you are tired. Pay attention to what you are doing. Use common sense.

• Store Idle Lawn Mower Indoors – When not in use, lawn mower should be stored in an indoor dry and locked-up place – out of reach of children.

• Maintain Lawn Mower With Care – Keep cutting edges sharp and clean for best and safest performance.

• Follow instructions for lubricating and changing accessories.

• Keep handles dry, clean, and free from oil and grease.

Not for

Reproduction

SAFETY INFORMATION

• Keep safety devices (guards, shields, switches etc.) in place and working.

• Keep blades sharp.

• Keep hands and feet away from cutting area.

• Objects struck by the lawn mower blade can cause severe injuries to persons. The lawn should always be carefully examined and cleared of all objects prior to each mowing.

• If lawn mower strikes a foreign object, follow these steps:

i) Stop lawn mower. Release the switch. ii) Remove battery. iii) Inspect for damage. iv) Repair any damage before restarting and operating the lawn mower.

• Use identical replacement blades only.

• Do not charge lawn mower in rain, or in wet locations.

• Remove or disconnect battery before servicing, cleaning, or removing material from the lawn mower.

• Use only approved replacement batteries, other batteries may cause injury or damage to the mower. For use only with Briggs & Stratton batteries BSB2AH48 or BSB5AH48 and Briggs & Stratton charger BS2AC48.

• Do not dispose of the battery in a re. The cell may explode. Check with local codes for possible special disposal instructions.

• Do not open or mutilate the battery. Released electrolyte is corrosive and may cause damage to the eyes or skin. It may be toxic if swallowed.

• Exercise care in handling batteries in order not to short the battery with conducting materials such as rings, bracelets, and keys. The battery or conductor may overheat and cause burns.

• Read, understand, and follow all instructions on the machine and in the manual(s) before starting.

• Only allow responsible adults who are familiar with the instructions to operate this machine.

• Clear the area of objects such as rocks, wire, toys, etc., which could be thrown by the blade. Stay behind the handle when the engine (motor) is running.

• Be sure the area is clear of bystanders before operating. Stop machine if anyone enters the area.

Not for

Reproduction

SAFETY INFORMATION

• Do not operate machine barefooted or while wearing sandals. Always wear substantial footwear.

• Do not pull machine backward unless absolutely necessary. Always look down and behind before and while moving backward.

• Never direct discharged material toward anyone. Avoid discharging material against a wall or obstruction. Material may ricochet back toward the operator. Stop the blade when crossing gravel surfaces.

• Do not operate machine without the entire grass catcher, discharge guard, rear guard, or other safety protective devices in place and working.

• Never leave a running machine unattended.

• Stop the motor and wait until the blade comes to a complete stop before removing the grass catcher or unclogging the chute.

• Operate machine only in daylight or good articial light.

• Do not operate machine while under the inuence of alcohol or drugs.

• Never operate mower in wet grass. Always be sure of your footing; walk, never run.

• Disengage the drive system, if so equipped, before starting the motor.

• If the machine should start to vibrate abnormally, stop the motor and check for the cause immediately. Vibration is generally a warning of trouble.

• Always wear eye protection when operating machine.

• See manufacturer’s instructions for proper operation and installation of accessories. Only use accessories approved by the manufacturer.

2. SLOPE OPERATION

• Slopes are a major factor related to slip and fall accidents, which can result in severe injury. Operation on all slopes requires extra caution. If you feel uneasy on a slope, do not mow it.

• Mow across the face of slopes; never up and down. Exercise extreme caution when changing direction on slopes.

• Watch for holes, ruts, bumps, rocks, or other hidden objects. Uneven terrain could cause a slip and fall accident. Tall grass can hide obstacles.

• Do not mow on wet grass or excessively steep slopes. Poor footing could cause a slip and fall accident.

Not for

Reproduction

SAFETY INFORMATION

3. CHILDREN

Tragic acc idents can occur if the operator is not aler t to the presence of children. Children are often at tr acted to t he machin e and the m owing ac tivity. Never assume that children will remain where you last saw them.

• Keep children out of the mowing area and under the watchful care of a responsible adult.

• Stay alert, and turn the mower off if a child or any other person enters the mowing area.

• Never allow children to operate the machine

• Use extreme care when approaching blind corners, doorways, shrubs, trees, or other objects that may obscure your view of a child who may run into the path of the mower.

4. SERVICE

• Keep all nuts, bolts, and screws tight in order to be sure that the equipment is in safe working condition.

• Never remove or tamper with safety devices. Check their proper operation regularly. Never do anything to interfere with the intended function of a safety device or to reduce the protection provided by a safety device.

• Keep machine free of grass, leaves, or other debris build up. Allow machine to cool before storing.

• After striking a foreign object, stop the motor. Thoroughly inspect the mower for any damage. Repair any damage before operating the mower.

• Never make any adjustments or repairs with the motor running.

• Always remove battery pack from mowers before adjusting, cleaning, or repairing.

• Check grass catcher components and the discharge guard frequently and replace with manufacturer’s recommended parts, when necessary.

• Mower blades are sharp, and can cut. Wrap the blades or wear gloves, and use extra caution when servicing.

• Maintain or replace safety and instruction labels, as necessary.

Not for

Reproduction

SAFETY INFORMATION

WARNING(PROPOSITION65)

This product contains a chemical known to the state of California to cause cancer, birth defects or other reproductive harm.

Some dust created by power sanding, sawing, grinding, drilling and other construction activities contains chemicals known to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are:

• Lead from lead-based paints,

• Crystalline silica from bricks and cement and other masonry products, and

• Arsenic and chromium from chemically-treated lumber.

Your risk of exposure to these chemicals varies depending on how often you do this type of work. To reduce your exposure to these chemicals, work in a wellventilated area, and work with approved safety equipment, such as dust masks

that are specially designed to lter out microscopic particles.

SAVE THESE INSTRUCTIONS

Not for

Reproduction

SYMBOLS

Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the product better and safer.

SYMBOL NAME DESIGNATION/EXPLANATION

V Volts Voltage A Amperes Current

Hz Hertz Frequency (cycles per second)

W Watt Power

min Minutes Time

/min Per Minute

Alternating Current

Direct Current

No Load Speed

Class II Construction

Wet Conditions Alert

Read The Operator’s Manual

Safety Alert Precautions that involve your safety.

Eye Protection

Type of current

Type or a characteristic of current

Rational speed, at no load

Double-insulated construction Revolutions, strokes, surface speed, orbits

etc., per minute Do not expose to rain or use in damp

locations. To reduce the risk of injury, user must read

and understand operator’s manual before using this product.

Always wear eye protection with side shields marked to comply with ANSI Z87.1 when operating this equipment.

Not for

Reproduction

SYMBOLS

Keep Hands and Feet Away

No Reach

The following signal words and meanings are intended to explain the levels of risk associated with this product.

No Slope

Keep Bystanders Away

Ricochet

Keep hands and feet away from blade and cutting area.

Do not reach hands or feet under mower deck.

Do not operate on inclines greater than 15º. Mow across the face of slopes, never up and down.

Keep all bystanders at least 100 ft. away.

Pay attention that bystanders are not injured through foreign objects thrown from the mower.

SYMBOLS SIGNAL MEANING

Indicates an imminently hazardous situation,

DANGER

which, if not avoided, will result in death or serious injury.

Indicates a potentially hazardous situation,

WARNING

CAUTION

which, if not avoided, could result in death or serious injury.

Indicates a potentially hazardous situation, which, if not avoided, may result in minor or moderate injury.

(Without Safety Alert Symbol) Indicates a situation that may result in property damage.

SAVE THESE INSTRUCTIONS

Not for

Reproduction

FEATURES AND CONTROLS

Read this operator's manual and safety rules before operating your mower. Compare the illustration in Figure 1 to your mower in order to familiarize yourself with the location of various controls and adjustments. Save this manual for future reference.

Self propel

Mulching plug

Side discharge chute

Height adjustment lever

Battery door

Bail lever

Safety lock-out button

Rear cover

lever

Self-Propel Speed Controls

Upper handle

Lower handle

Side discharge cover

Front wheel

Grass catcher bag

Rear wheel

Fig. 1

Not for

Reproduction

ASSEMBLY

UNPACKING

• Carefully remove the product and any accessories from the box. Make sure that all items listed in the packing list are included.

• Inspect the product carefully to make sure no breakage or damage occurred during shipping.

• Do not discard the packing material until you have carefully inspected and satisfactorily operated the product.

• If any parts are damaged or missing, please call 1-800-317-7833 for assistance.

WARNING

If any parts are damaged or missing do not operate this product until the parts are replaced. Using a product with damaged or missing parts could result in serious personal injury.

WARNING

Do not attempt to modify this product or create accessories not recommended

for use with this product. Any such alteration or modication is misuse and

could result in a hazardous condition leading to possible serious personal injury.

WARNING

Do not insert battery until assembly is complete and you are ready to mow. Failure to comply could result in accidental starting and possible serious personal injury.

WARNING

To prevent accidental starting that could cause serious personal injury, always remove the battery pack from the product when assembling parts.

WARNING

Never operate the mower without the proper safety devices in place and working. Never operate the mower with damaged safety devices. Operation of this product with damaged or missing parts could result in serious personal injury.

Not for

Reproduction

ASSEMBLY

UNFOLDING AND ADJUSTING LOWER HANDLE

(See Figure 2)

WARNING

Folding or unfolding the handle improperly can damage the cables, causing an unsafe operating condition.

• Do not damage the cables when folding or unfolding the handle.

• If a cable is damaged, contact an Authorized Service Dealer.

• Pull and rotate the handle knobs (1) 90° o n both sides to loosen the lower handles (2) on both sides.

• Move the lower handles to the operating position. You may raise or lower the handle to a position c omfortable for you. There are 3 p ositions (3) for you to choose. Release the handle knobs to lo ck the lower handle into position.

Note: Ensure both sides are set at the same position for proper assembly.

(2)

(1)

(3)

Fig. 2

Not for

Reproduction

ASSEMBLY

INSTALLING THE UPPER HANDLE (See Figure 3)

• Align the mounting holes o n the upper handle (1) and the lower handle (2). Inser t the bolts (3) and use the knobs (4) to tighten them. Repeat the operation on the other side.

(1)

(4)

(3)

(2)

(4)

(3)

Fig. 3

Not for

Reproduction

ASSEMBLY

INSTALLING THE GRASS CATCHER BAG (See Figure 4)

• Lift the rear cover (1).

• Lift the grass catcher by its handle (2) and place under the rear cover so that the hooks (3) on the grass catcher (4) are seated on the door rod (5).

• Release the rear cover. When installed correctly, the hooks on the grass catcher will extend through the openings on the rear cover.

NOTE: When using the grass catcher, do not install either the side discharge

deector or the mulching plug.

(1)

(5)

(2)

(4)

(3)

Fig. 4

Not for

Reproduction

ASSEMBLY

INSTALLING/REMOVING THE MULCHING P LUG (See Figure 5)

• To remove the mulching plug, lift the rear cover (1).

• Grasp the handle (2) of the mulching plug. Lift and pull the mulching plug out using the handle.

• The mulching plug (3) is inserted at an angle, so it requires some force to remove it.

• The mulching plug must be removed in order to install the grass catcher bag.

• The mulching plug must be re-installed when the grass catcher bag is removed.

(1)

(2)

(3)

Fig. 5

Not for

Reproduction

ASSEMBLY

INSTALLING SIDE DISCHARGE CHUTE (See Figure 6)

• Lift the side discharge cover (1).

• Align the grooves (2) on the discharge chute (3) with the pins (4) on the

underside of the discharge cover (1).

• Lower the discharge chute until the hooks on the mower deck are secured

in the openings in the discharge chute.

• Release the side discharge cover.

(4)

(2)

(3)

(1)

Fig. 6

Not for

Reproduction

ASSEMBLY

TO INSTALL BATTERY PACK (See Figure 7)

• Lift and hold up the battery door (1).

• Align the battery (2) with the mower’s battery port.

• Make sure the battery release button (3) snaps in place and that battery is fully seated and secure in the mower before beginning operation.

• Insert the safety key (4). If the machine is not going to be used immediately, do not insert the safety key.

• Close the door.

(1)

(3)

(2)

(4)

TO REMOVE BATTERY PACK (See Figure 7)

• Release the bail lever to stop the mower.

• Open the battery door. Remove the safety key.

• Press the battery release button (3) on the mower. This will cause the battery to raise out of the tool slightly.

• Remove battery from the mower.

Fig. 7

Not for

Reproduction

OPERATION

STARTING/STOPPING T HE MOWER (See Figure 8)

To start the motor:

• Open the battery door. Insert the battery. Insert the safety key.

• Press and hold the safety lock-out button (1).

• Pull the bail lever (2) upward to the handle to start the mower and release the button.

To stop the motor:

• Release the bail lever.

SELF-PROPELLED MOWING (See Figure 8)

To engage the self-propelled feature:

• Open the battery door. Insert the battery. Insert the safety key.

• Pull the self propel lever (3) upward to meet the handle.

To disengage the self-propelled feature:

• Release the self propel lever.

To adjust the speed of self-propelled feature:

• Pull the variable speed control lever (4) towards the Rabbit Symbol to increase speed.

• Push the variable speed control lever (4) towards the Turtle Symbol to decrease speed.

(2)

(1)

(4)

(3)

Fig. 8

Not for

Reproduction

OPERATION

Soft-Start

This LI-ION mower is equipped with a “soft-start” feature. When initially starting up, the mower will take approx. 3 seconds to get up to full speed. If the mower does not initially start: Remove the battery and check under the mower deck to ensure there is nothing obstructing the blade and that the blade can spin freely by hand. Even a small amount of grass on start up will prevent the “softstart” from turning the mower on.

CAUTION

Do not attempt to override the operation of the safety lock-out button or bail lever.

WARNING

The operation of any mower can result in foreign objects being thrown into the eyes, which can cause severe eye damage. Always wear safety glasses while operating the mower and while performing any adjustments or repairs.

INSPECT THE CUTTING AREA. Remove all stones, sticks, wire, bones, and other debris that might be thrown by the rotating blades.

Not for

Reproduction

OPERATION

CUTTING HEIGHT ADJUSTMENT (See Figure 9)

When shipped, the wheels on the mower are set to a low-cutting position.

Before using the mower for the rst time, raise the cutting position to the

height best suited for your lawn. The average lawn should be between 1 1/2" to 2" (3.8 to 5 cm) during cool months and between 2" and 3 1/2" (5 cm to 8.3 cm) during hot months

To adjust the blade height:

• To raise the blade height, grasp the height adjustment lever (1) and move it toward the back of the mower.

• To lower the blade height, grasp the height adjustment lever (1) and move it toward the front of the mower.

Height Adjustments 1 3/8 - 3 3/4" 1st setting 1 3/8" 2nd setting 1 7/8" 3th setting 2 1/8" 4th setting 2 5/8" 5th setting 3"

6th setting 3 3/8" 7th setting 3 3/4"

(1)

Fig. 9

Not for

Reproduction

OPERATION

SLOPE GAUGE (See Figure 10)

WARNING

Slopes are a major factor related to accidents involving slips and falls, which can result in severe injury. Operating the mower on a slope requires extra caution. If you feel uneasy on a slope, do not mow it. For your safety, use the slope gauge that is included as part of this manual to measure slopes before operating this unit on a sloped or hilly area.

• Mow across the face of a slo pe, and never up and down. Exercise extreme caution when changing direction on a slope.

• Watch for holes, ruts, rocks, hidden obje ct s, or bum ps that may cause a s lip or a trip. Tall grass can hide obstacles.

• Always be sure of your footing. If you feel like you are losing your balance, release the blade/motor contro l handle immediately. The blade wil l stop rotating within 3 seconds.

• Do not mow near drop- offs, ditches, or embankme nts, because you could lose your footing or balance.

• Do not mow a slope that has an angle of greater th an 15°, as determined using the slope gauge.

• Do not mow wet or damp grass. Unstable footing can cause slipping.

WARNING

Do not mow a slope that has an angle of greater than 15° (a rise of approximately 2 1/2 feet [.75 m] every 10 feet [3 m]). Mow across the face of a slope, and never up and down.

Not for

Reproduction

OPERATION

Fig. 10

Not for

Reproduction

OPERATION

MOWING TIPS

NOTE: A sharp blade will greatly enhance the performance of the mower, especially when cutting high grass. Be sure to check the blade and to sharpen it at least once per year, as described in the Maintenance section.

• Verify that the lawn is free of stones, sticks, wires, and other objects that could damage the blades or the motor. These objects could be accidentally thrown by the mower in any direction, and could cause serious personal injury to the operator and to others. In order to prevent electric shock, do not operate the mower in damp or wet conditions.

• Do not mow in circles. Travel back and forth across the lawn.

• When cutting thick grass, reduce walking speed in order to allow for a more effective cut and a proper discharge of the clippings.

• For a healthy lawn, always cut off one-third or less of the total length of the grass. The average lawn should be approximately 1 1/2 to 2” (3.8 to 5 cm) long during cool months, and between 2" to 3 1/4" (5 cm to 8.3 cm) long during hot months. If there is growth, the lawn should be cut in the fall.

MULCHING TIP S

NOTE: INSPECT THE AREA WHERE THE MOWER IS TO BE USED, AND REMOVE ALL STONES, STICKS, WIRE, BONES, AND OTHER DEBRIS THAT MIGHT BE THROWN BY THE ROTATING BLADE.

• Release the bail lever to turn the mower OFF when crossing any graveled area (stones can be thrown by the blade).

• Set mower to the highest cutting height when mowing on uneven ground or in tall weeds.

• For effective mulching, do not cut wet grass, because it tends to stick to the underside of the deck, preventing proper mulching of grass clippings. New or thick grass may require a narrower cut. The ground speed should be adjusted to the condition of the lawn. If mowing has been delayed and the grass has been allowed to grow longer than 4" (10 cm), mow the lawn twice in order to reduce the grass height to a maximum of 3 1/4” (8.3 cm).

• Walk at a steady pace. Overlap the cutting rows. Do not let the grass get too tall. If the grass gets too long, start at the highest cutting position and work down to the desired cutting height.

WARNING

If you strike a foreign object, stop the motor and remove the battery. Thoroughly inspect the mower for any damage. Repair any damage before operating the mower. Excessive vibration of the mower during operation is an indication of damage. Thoroughly inspect the mower and repair any damage before operating the mower.

Not for

Reproduction

OPERATION

EMPTYING THE GRASS CATCHER BAG (See Figure 1 1)

• Stop mower, allow blades to completely stop, and remove the battery.

• Lift the rear discharge cover.

• Lift the grass catcher bag by its handle to remove from mower.

• Empty grass clippings.

• Lift the rear discharge cover and reinstall the grass catcher bag as described earlier in this manual.

Fig. 11

Not for

Reproduction

MAINTENANCE

REPLACING THE CUTTING BLADE (See Figure 12)

WARNING

Always protect your hands by wearing heavy gloves and/or wrapping the cutting edges with rags or other materials when performing any maintenance on the blades. ALWAYS remove the battery when servicing or transporting the mower.

• REMOVE BATTERY.

• While wearing leather padded gloves, wedge a block of wood between the blade and the mower deck in order to prevent the blade from turning when the bolt (1) is being removed.

• Using an adjustable wrench or 27 mm socket, loosen the bolt (1), spacer (3) and remove the blade (2). Turn the bolt “COUNTERCLOCKWISE” to loosen it and “CLOCKWISE” to tighten it.

• Remove the bolt (1), spacer (3) and the blade (2).

• To re-install the blade, position the blade with the cutting edges toward the ground. Assemble the bolt as shown.Torque the blade bolt down clockwise using a torque wrench (not provided) to ensure the bolt is properly tightened. The recommended torque for the blade bolt is 24-27 lb-ft (33-37 Nm).

NOTE: Be sure to replace the parts in the exact order in which they were removed. When installing the cutting blade, verify that it is installed with the curved ends pointing toward the mower deck, and not toward the ground.

Fig. 12

(2)

(3)

(1)

Not for

Reproduction

MAINTENANCE

CLEANING THE MOWER

WARNING

In order to reduce the risk of electric shock, do not expose the mower to water. The underside of the mower deck should be cleaned after each use, because grass clippings, leaves, dirt, and other debris will accumulate, which will cause rust and corrosion.

Remove any build-up of grass and leaves on or around the motor cover (do not use water).Occasionally wipe the mower clean with a dry cloth. If debris builds up on the underside of the mower during use, stop the motor, disconnect it from the battery, and then tilt the mower on its side, and scrape it clean using an appropriate tool.

STORING THE MOWER

The following steps should be taken in order to prepare the lawn mower for storage.

• Clean the mower as described in the previous section.

• Inspect the blade, and replace it or sharpen it, if required, refer to the Maintenance section.

• Store the mower in a dry, clean location. Do not store it next to corrosive materials, such as fertilizer or rock salt.

• Store the mower indoors, in a cool, dry place, out of the reach of children. Do not cover the lawn mower with a solid plastic sheet. Plastic coverings trap moisture around the mower, which causes rust and corrosion.

• Remove the battery and store it in a cool dry location.

• Remove the battery and store in a secure location out of the reach of children.

WARNING

This battery must be charged every 3 months while in storage to maintain maximum capacity.

Not for

Reproduction

MAINTENANCE

• When servicing the mower, use only identical replacement parts that are available from the manufacturer. In order to obtain replacement parts, call the toll-free helpline, at 1-800-317-7833. The use of parts that do not meet

the original equipment specications may lead to improper performance,

and may compromise safety.

• Before cleaning, repairing, or inspecting, verify that the blade and all moving parts have come to a complete stop. Remove the battery when making any adjustments or when any of the four wheels must be lifted off the ground.

• Follow the instructions for lubricating and changing accessories.

• Keep the handles dry, clean, and free of oil and grease.

• In order to reduce the risk of re, keep the motor free of grass, leaves, and debris build-up.

• Check the blade and motor mounting bolts for proper tightness frequently. Visually inspect blade for damage (e.g., bent, cracked, or worn).

• For best and safest performance, maintain the mower with care. Keep the mower blade sharp and clean. Mower blades are sharp, and can cut. Wrap the blades or wear gloves, and use extra caution when servicing.

• Keep all nuts, bolts, and screws tight in order to be sure that the equipment is in safe working condition.

• Never tamper with safety devices. Check them regularly for proper operation.

• After striking a foreign object, stop the motor. Thoroughly inspect the mower for any damage. Repair any damage before operating the mower.

• The grass catcher components, discharge cover, and trail shield are subject to wear and damage, which could expose moving parts or allow objects to be thrown. As a safety precaution, check these components frequently, and immediately replace any parts that show signs of wear, or that are cracked or broken. Use original equipment manufacturer's (OEM) parts only, as listed in this manual.

• When it is not in use, store the mower indoors in a dry area, and out of the reach of children.

WARNING

Always remove battery when servicing or transporting the mower.

Not for

Reproduction

MAINTENANCE

VERTICAL STORAGE FUNCTION (See Figure 13)

• Remove the battery from the mower. Remove the grass catcher bag.

• Rotate the handle knobs to the unlocked position.

• Lower the handle assembly and rotate the handle knobs to the locked position.

• Lift the mower by the front end to the vertical position.

WARNING

Always remove the battery from the mower before placing the unit in the vertical storage position.

STORAGE SWITCH:

When the handle is rotated into the fully locked storage position, the mower is equipped with a storage switch (1) that will disable the mower from running in the storage position. The storage switch (1) does not replace the need to remove the safety key and battery to prevent accidental start-up or unauthorized use.

(1)

Fig. 13

Not for

Reproduction

ENVIRONMENTALLY SAFE BATTERY DISPOSAL

The following toxic and corrosive materials are in the batteries used in this tool battery pack: Lithium-Ion, a toxic material.

WARNING

Toxic materials must be disposed of in a specied manner in order to prevent

contamination of the environment. Before disposing of damaged or worn out Lithium-Ion battery packs, contact your local waste disposal agency for

information and specic instructions. Take the battery to a local recycling and/

or disposal centre that is certified for disposal. If the battery pack cracks or breaks, whether it leaks or not, do not recharge it and do not use it. Dispose of it and replace it with a new battery pack. DO NOT ATTEMPT T O REPAIR IT!

Follow these instructions in order to avoid injury and the risk of re, explosion,

or electric shock, and to avoid damage to the environment:

• Cover the battery's terminals with heavy-duty adhesive tape.

• Do not attempt to remove or destroy any of the components of the batter y pack.

• Do not attempt to open the battery pack.

• If a leak develops, the electroly tes that are re lease d are c or r osive and toxic. Do not get the solution in the eyes or on the skin, and do not swallow it.

• Do not place batteries in regular household trash.

• DO NOT incinerate batteries.

• DO NOT place batteries where they will become part of any waste landll or municipal solid waste stream.

• Dispose of batteries at a certied recycling or disposal center.

Not for

Reproduction

TROUBLESHOOTING

PROBLEM POSSIBLE CAUSE SOLUTION

The battery is not charged.

The switch is defective.

Charge the battery. Replace the switch (Contact an

authorized service center).

The mower does not start.

The mower cuts the grass unevenly.

The mower does not mulch properly.

The mower is hard to push.

The mower is excessively noisy and vibrates.

Grass jammed between the deck and blade.

The battery is not fully inserted in the mower.

Battery may require service or replacement.

The lawn is rough or uneven.

The cutting height is not set properly.

Wet grass clippings are sticking to the underside of the deck.

The mulching plug is missing.

The grass is too tall, or the cutting height is too low.

The rear of the grass catcher bag is dragging in thick grass.

The motor shaft is bent.

The blade is unbalanced.

Remove battery; check under deck for jams.

Check the connection between the battery and the mower. Make sure the battery clicks into place.

Contact an authorized service center or replace battery.

Check the mowing area. Move the wheels to a higher

setting.

Wait until the grass dries before mowing.

Install the mulching plug.

Raise the cutting height.

Empty the grass clippings from the grass catcher bag.

Stop the motor, and inspect for damage.

Repair before restarting. If vibration persists, contact an authorized service center.

+ 78 hidden pages
