Snapper 1696001, 1696003, 1696002 User Manual

Not for
Reproduction
Parts Manual fo
r
2
3
27" & 29" TWO STAG
INTERMEDIATE SNOWTHROWERS
2011
DescriptionModel No.
1696001 M1227E 169600 169600
M1227EX M1529E
Briggs & Stratton Yard Power Products Group
535 Macon Road McDonough, GA, 30253 U.S.A. 800-935-2967
Manual No. Revision:
7105285
- 6/14/2011
Not for
Reproduction
Not for
Reproduction
s
PAGE GROUP
4
8 10 12 14 16 20 22 24
Handles & Controls Group Auger Housing Group Auger Drive Group Gear Case Assembly Discharge Chute Group Engine & Frame Group Traction Drive Group - Standard Decals Group Wheels & Tires Group
Table Of Content
27" & 29" TWO STAGE 2011
Manual No.
3
TP 400-5494---IS-N
7105285
Not for
Reproduction
Handles & Controls Group
Manual No.
7105285 27" & 29" TWO STAGE
4
2011
Not for
Reproduction
Part No DescriptionItem Qty
0010 1923701 2 CAPSCREW, Hex Head, 3/8-16 x 2 G5 0030 1736192 1 LEVER, Deflector Control (Remote Chute) 0040 1924356 1 WASHER, 3/8 (Remote Chute) 0050 724361 2 SPRING 0060 1918266 2 WASHER, 3/8 0070 1919439 2 NUT, Hex Lock, Esna Light, 3/8-16 0080 1737690 1 LEVER, Clutch, Left 0100 1736836 1 SPEED LEVER 0120 1921962 4 CAPSCREW, Hex Head, 1/4-20 x 1-3/4 G5 0130 1737684 1 BRACKET, Controls 0140 1734354 1 ROD, 25.3/8 Long 0150 1931277 3 NUT, Hex Flange, Whiz Lock, 5/16-18 0170 2820263 2 NUT, Hex, 5/16-24 0180 1739487 2 BRACKET, Mounting, Dash 0190 724360 1 BALLJOINT 0200 1917356 1 LOCKWASHER, Spring, 5/16 0230 1750775 1 HARNESS, Wire, Headlights (Remote Chute) 0230 1750773 1 HARNESS, Wire, Electric Deflector (Electric Chute) 0230-10 ----- 1 * FUSE, Mini, 10 Amp 0235 1752164 1 HARNESS, Heated Hand Grip (M1227EX & M1529E) 0300 1920397 4 NUT, Hex Lock, Esna Light, 1/4-20 0320 1732470 1 KNOB, Internal Thread, 3/8-16 (Remote Chute) 0330 1738327 1 DASH ASSEMBLY, Twin Light (Remote Chute) 0330 1738330 1 DASH ASSEMBLY, Twin Light (Electric Chute) 0340 1960001 2 SCREW, Hex Washer Head, Plastite, 10-14 x 5/8 0360 1922837 2 CAPSCREW, Hex Head, 1/4-20 x 1-1/2 G5 0370 723873 3 BOLT, Carriage, 5/16-18 x 3/4 0390 1739500A 1 SUPPORT, Dash Panel 0400 1737544 1 CABLE, Auger Drive 0410 1736323 1 LEVER, Clutch, Right 0420 1923358 2 NUT, Hex Centerlock, 1/4-20 0430 1726317 2 GRIP (M1227E) 0430 1738124 2 GRIP, Heated (M1227EX & M1529E) 0440 1736542 2 SPACER, Stepped 0450 1678392 2 SPACER, 1/4ID x 3/8OD x 5/16 0470 1734587A 1 HANDLE, Upper, Right 0480 1734586A 1 HANDLE, Upper, Left 0490 1750299 2 BOLT, Carriage, Curved Head, 5/16-18 x 2-1/4 0500 1737274A 1 HANDLE, Lower 0510 7035744 4 KNOB, Wing, 5/16-18 0515 7090391 4 WASHER, Internal Tooth, 5/16 0520 1736176 1 HEADLIGHT ASSEMBLY 0520-10 ----- 1 LENS, Twin Light 0520-20 ----- 2 DEFLECTOR, Twin Light
Handles & Controls Group
Footnotes:
Note* See your local hardware store for replacement bulbs & fuses.
2011
Manual No.
5
710528527" & 29" TWO STAGE
Not for
Reproduction
Handles & Controls Group
Manual No.
7105285 27" & 29" TWO STAGE
6
2011
Not for
Reproduction
Handles & Controls Group
Part No DescriptionItem Qty
0520-30 1736180 2 SOCKET/GASKET ASSEMBLY 0520-50 ----- 2 * BULB, 12V - 20W Halogen 0530 1664847 2 SCREW, Hex Washer Head, Taptite, 5/16-18 x 3/4 0540 723259 1 BRACKET, Cable Adjusting 0550 723154 1 BOOT, Spring End Cover 0560 727331 1 CABLE, FR-DR P7 EXT-HDL 0590 1733505A 1 BRACKET, Pivot, Free Hand 0600 1733095 1 SPACER, 1/4ID x 3/8OD x 1/8 0610 1736363 1 ROD & SPRING ASSEMBLY (Remote Chute) 0610 1733509 1 ROD & SPRING ASSEMBLY (Electric Chute) 0630 2108360 1 SPRING, Compression, 2-1/2 Inch 0640 1960353 1 WASHER, 1/4 0650 1736360 1 ROD, 5-1/2 Long 0670 7012080 3 TIE, Cable 0680 1733192 1 KNOB, Slot Speed 0700 1921319 2 WASHER, 1/4 0740 7091105 4 SCREW, Hex Washer Head, Hi-Lo, #10-16 x 1/2 0750 1960589 1 SCREW, Round Head Phillips, #10-24 x 3/4 0760 7091290 1 NUT, Hex Lock, 10-24 0790 7091189 2 BOLT, Carriage, Curved Head, 5/16-18 x 2 0880 7091081 2 SCREW, Hex Washer Head, Self Tap, 1/4-15 x 3/4 0900 1960684 2 NUT, Hex KEPS, 5/16-18 0910 723873 2 BOLT, Carriage, 5/16-18 x 3/4 0920 1709188 1 PLUG (Remote Chute) 0930 725331 2 WASHER, Flat 0970 1752242 1 SWITCH, Heated Hand Grip (M1227EX & M1529E) 0980 1739861 1 BRACKET, Heated Hand Grip (M1227EX & M1529E) 0990 1960556 1 SCREW, Pan Head Torx, Taptite, 1/4-20 x 3/4 (M1227EX & M1529E)
Footnotes:
Note* See your local hardware store for replacement bulbs & fuses.
2011
Manual No.
7
710528527" & 29" TWO STAGE
Not for
Reproduction
Auger Housing Group
Manual No.
7105285 27" & 29" TWO STAGE
8
2011
Not for
Reproduction
Part No DescriptionItem Qty
0010 1687616 1 HOUSING, 27" 0010 1687617 1 HOUSING, 29" 0020 1736620 2 CLIP, Retainer 0030 1960569 2 SCREW, Truss Head Torx, #10-24 x 3/8 0040 7091290 2 NUT, Nylock, 10 x 24 0060 1736094 1 BRUSH, Cleanout 0070 724427 2 BEARING, Auger Shaft 0080 722839 4 SCREW, Hex Washer Head, 5/16-18 x 3/4 0090 7091547 4 BOLT, Carriage, 3/8-16 x 3/4 GR5 0100 7091619 4 NUT, Hex Flange, 3/8-16 0110 725273 7 NUT, Hex Flange, Serrated Lock, 5/16-18 0150 1727854A 2 SKID, Shoe Reversible 0160 1740745A 1 BLADE, Scraper, 27" 0160 1740746A 1 BLADE, Scraper, 29" 0170 724712 1 RETAINER, Ball Bearing 0180 1705897 1 BEARING, Ball 0190 720018 3 BOLT, Hex, 5/16-18 x 5/8 0200 725521 2 PLUG 0210 7090799 4 BOLT, Carriage, 5/16-18 x 5/8 GR5 0220 1733102A 2 DRIFT CUTTER 0230 723873 2 BOLT, Carriage, 5/16-18 x 3/4 0240 725347 2 NUT, Wing, 5/16-18
Auger Housing Group
Footnotes:
2011
Manual No.
9
710528527" & 29" TWO STAGE
