Snapper 1600, 1600A User Manual
Specifications and Main Features
• Model: Kohler K341AQS Enging
• Engine Power: 16 hp with a maximum rpm of 3,600
• Engine Size: 35.89 cubic inches
• Bore And Stroke: 3.75 inches in diameter and 3.25 inches in length
• Crank case oil capacity: Holding approximately 4 pints
• Overall Weight: 120 lbs.
• Fuel Sytem: Fuel Pump and Internally vented float carburetor
• Engine Type: Air cooled internal combustion engine
• Idle RPM Speed: 2,100-2,300
• No Load Max Speed: 3,600rpm
• Transaxle: Peerless 2300 series transaxles
• Engine System Capacity: 4 US quarts
• Petrol Tank: 2.75 gallons
• Start Battery: 12v - 46Ah battery
• Wheelbase: 47 inches
• Length: 70.75 inches
• Width: 41.5 inches
• Height: 45.5 inches above the wheel
• Ground Clearance: 13.5 inches
• Front And Rear Wheel Tread: 30 and 30.5 inches respectively
• Drawbar Sole Height: 8.25 inches
• Tires Used: The front tire measures 16 x 6.50-8 2 Ply while the rear tire measures 23 x 10.50-12 2 Ply
• Front Power Take Off: Electric clutch fitted with V belt pulley and idler pulleys
• Rear Power Take Off Shaft: Fitted as standard to the 1600A variant, Optional to 1600 and max speed is 2000 rpm
• Approx. Weight With No Mowers Fitted: 760 lbs
Frequently Asked Questions
Q: What engine does the zonapper have , can it be replaced with others ?
A: The zonapper has a Kohler K341AQS engine, and the answer is no since the zonapper does not use interchangeable engines.
Q: What is the horsepower of the ZONAPPER?
A: It is 16 @ 3600 rpm for ZONAPPER.
Q: What is the fuel tank capacity of the ZONAPPER?
A: There is a fuel tank capacity of 2-3/4 gallons.
Q: What type of battery is used in ZONAPPER?
A: ZONAPPER operates on a 12 volt — 46 ampere hour battery.
Q: How do you check the oil level in the crankcase?
A: The dipstick is removed, then wiped clean, then put back in and removed again to check the oil.
Q: What is the recommended idle speed for the engine?
A: The engine soft idle speed is between 2100 to 2300 rpm.
Q: Is the ZONAPPER commercial grade?
A: There are, however, specific warranty conditions which are applicable. Yes, it is.
Q: How often should the air filter be cleaned, or when should it be replaced?
A: The air filter must be cleaned every 50 hours, and 100 to 200 hours of operation, it must be replaced.
