Install the Base
1
to a Surface
PadDock™ Pivot
Dual Arm Locking Tablet Stand
(VP3670)
Install
2
the Arm
Congratulations on your purchase of your new PadDock™ Pivot Dual Arm Locking
Tablet Stand. PadDock™ Pivot installation takes just minutes.
Simply follow our four easy steps.
a
A. Normal
Installation
Table thickness
up to 60mm
3 4
Secure the Tablet
a
Note: Paddock™ Pivot can only be adjusted when unlocked.
YOUR PIVOT CLAW KEYS ARE NOT REPLACEABLE.
Be sure to store them in a safe place to ensure access to your tablet.
B. Secure Base
Installation
(Optional)
b
a
Place upper piece
into base.
Place the security
key into the base
mount with the
teeth facing down.
c
b
b
Make sure to tighten
by turning clockwise.
Place the
teeth into the
corresponding
hole on the
security ring.
c
Route the Cable
Route your tablet charge/sync cable using
the cable managment clamps provided.
Turn clockwise
to tighten.
Use key to unlock the security lock. Unlock the claw. Extend each claw.
d
Place tablet. Lock the claws, then push the claw towards
e
Note:
Extra cushion
is available in
the package for
thinner devices.
Paste the cushion
in the indicated
position.
the tablet to x its position. Lock the security
lock by pressing the knob.
Package Contents
Body Base Tention
Tool
Positions
(VP3670)
Cable
Management
Key Cushion Security
Tool
Base
Tool
Tension Adjustment
Note: All products are adjusted to the
most suitable tension before leaving the
factory. Do not alter unless necessary.
Screws & hinges will loosen during use.
Use the tools provided to tighten them as
necessary.
Tighten by
turning clockwise.
