Smittybilt MN1450-4S User Manual

Installation Instructions

Sure Steps (Part # MN1450-4S)

2004-2005 Nissan Titan

Crew Cab 4 Door

QTY PART # DESCRIPTION

1 NN1450-S4L Sure-Step, left side
1 NN1450-S4R Sure-Step, right side
1 HW-NN1450-S4 hardware kit

NOTE: Please read this information before installing. Check components received with components listed
above.
NO DRILLING REQUIRED for installation of these Sure-Step side bars. To obtain correct installation, we
recommend you to follow these step by step installation instructions carefully. Please take care when
installing this product to protect the finish and your investment. For Technical Assistance please call (951)
736-8686

Step One: Locate the hardware kit and check contents with the hardware list below.
QTY PART # DESCRIPTION

6 901106 8mm x 25mm hex head bolt, zinc plated GR5
12 901179 8mm flat washer, zinc plated
6 901180 8mm lock nut, zinc plated
12 901105 10mm-1.25 x 30mm hex head bolt, zinc plated GR8.8
12 901140 10mm flat washer, zinc plated
12 901141 10mm split lock washer, zinc plated
3 000000-LT support bracket, left side-black
3 000000-RT support bracket, right side-black

Step Two: Locate the driver side bar, three left side brackets, six 10mm hex bolts, six 10mm flat washers,

and six 10mm lock nuts. Using the hardware listed in this step, secure the brackets to the side bar
as shown in the photo below. Do not fully tighten hardware at this time.

Step Three: Locate three 8mm hex head bolts, six 8mm flat washers, and three 8mm split lock nuts. Using the

hardware listed in this step secure the brackets to the side of the frame as shown in photo below.
Fully tighten hardware at this time.

For Technical Support/Warranty Information please call 310-762-9944

Smittybilt, 400 West Artesia Blvd, Compton, CA 90220

Installation Instructions

Sure Steps (Part # MN1450-4S)

2004-2005 Nissan Titan

Crew Cab 4 Door

10mm

Step Four: Repeat steps two and three on opposite side of vehicle. Be sure to use all hardware supplied and

tighten all bolts.

IMPORTANT: Sure-Step side bars have a 300 lb. weight capacity. To protect your investment, wax this product
after installing. Regular waxing is recommended to add a protective layer over the finish.

Product cleaning and maintenance instructions

Stainless Steel Finish – Aluminum polish may be used to polish small scratches and scuffs on the finish. Mild soap,
window or glass cleaner may be used to clean the finish. Dual state powder coat finish – Mild soap, window or glass
cleaner may be used to clean the finish. In order to protect the finish, you may wax your product on a regular basis with
pure carnauba automotive wax. Do not use any types of soap, polish or was that contains abrasive that could damage
the finish. Textured coated finishes should be cleaned with a mild soap on a damp sponge. Do not apply polish or
was that requires to be removed by means of buffing. This type of wax is commonly used at car wash facilities.
Chrome Finish – Mild soap, window or glass cleaner may be used to clean the finish. In order to protect the finish you
should wax your product on a regular basis with pure carnauba automotive wax. Do not use any types of soap, polish or
was that contains abrasive that could damage the finish.

Smittybilt’s products are covered under the following limited warranties only. Note that the duration of the limited warranty differs
according to the material and finish of the product purchased. Subject to the duration and conditions of the limited warranty stated
below, Smittybilt warrants to the original retail purchaser that its products are free from defects in material and workmanship. All
other warranties and representations express or implied are hereby disclaimed, including fitness for merchantability and buyer’s
intended use or purpose. All parts are sold “AS IS” except for the limited warranties granted herein. Buyer assumes all risks as to
the selection, suitability and performance of all goods and products selected. This limited warranty does not cover damage or
impairment in any part due to misuse, improper installation, accident or contact with on-road or off-road hazards, product
modification, improper or inadequate cleaning and/or maintenance. Smittybilt is not responsible for items damaged during
shipping. This warranty is not transferable from the original buyer. For the original Buyer to be eligible for the limited warranty
coverage, the Buyer must provide proof of purchase. Smittybilt strongly recommends returning th e warranty registration card.

For Technical Support/Warranty Information please call 310-762-9944

Smittybilt, 400 West Artesia Blvd, Compton, CA 90220
