Smittybilt C9989QC User Manual

Installation Instructions

Nerf-Step (Part # C9989QC)

99-06 Chevy/GMC Silverado/Sierra

Extended Cab, Short Bed

WWW.SMITTYBILT.COM

NOTE: Carefully read entire instructions thoroughly before attempting to install this part.

Drilling is required for installing of these bars. It is recommended to have some additional

help with the installation process.

Parts Included Qty Tools Needed

5/16” x 1” carriage Bolt 12 Drill and 3/8” drill bit
5/16” Nut 12 ½” wrench or ratchet with socket
3/8” Washer 12

`

Step 1:
Position the bar up to the truck approximately ¾” to 1” from the front wheel well opening.
(If you have over-sized tires you can mount the bar further back to insure you have tire-turning
clearance). Make sure not to hit the cab brace: this will cause the step plate not to be parallel
with the ground.

Step 2:
weld. (Fig A) Use the slotted holes in the angled flange as a guide to mark the holes to be
drilled into the pinch weld. (6 per side, the angle of the flange will appear to be at a different
angle than the pinch weld this is normal and the bar will “set” properly when installed. ) Once
holes are marked carefully set the bar to the side.

Open and identify the bars. The short end of the bar goes towards the front of the vehicle.

Hold the bar on the underside of the truck with the angled flange on the bracket below the pinch

For Technical Support/Warranty Information please call 310-762-9944

Smittybilt, 400 West Artesia Blvd. Compton, CA 90220

Picture is for sample use, may not be actual bars

Installation Instructions

Nerf-Step (Part # C9989QC)

99-06 Chevy/GMC Silverado/Sierra

Extended Cab, Short Bed

WWW.SMITTYBILT.COM

Fig A

NOTE: Picture is for sample use
only. Actual bracket may vary
from picture.

CAUTION: Always check
backside of pinch weld before
drilling.

The angled flange on the bracket goes
on the bottom of the pinch weld

Step 3: Proceed to drill the marked holes out to 3/8”. Be sure when drilling holes that you are drilling in
the center of the marked pinch weld area. (Usually about ½” – ¼” from the outside edge.) Doing
this will insure ease of installation of the nuts and washers.

Note: You will not normally be using the holes in the top of the mounting brackets. These
provide extra support if you plan on your bars impacting rocks or other hard surfaces.
These can be secured by using #8- 1inch self-tapping screws.(not provided) Make sure
no wires or other obstructions are in the way if used. Do not attach screws until bars is
securely fastened to the pinch weld area.
