Installation Instructions
Tonneau Cover (#7010XX-7210XX)
1987-95 Jeep Wranglers
Before You Begin
Included Components:
1-Tonneau Cover
Thank you for purchasing the Smittybilt Tonneau Cover for 87-95 Jeep Wrangler. Before you
get started, please read the important information listed below:
1. For this Tonneau Cover to fit correctly you must have Soft Top equipment, factory
installed hardware on your vehicle.
2. All Smittybilt Soft tops are pre-fit at the factory. Please note that in order to provide long
term fit, Smittybilt designs each top to fit very tight on the initial installation. Please
make sure it is at least 70 degrees F. when you first install this top or it will be very
difficult to install. If you use a hair dryer to warm the fabric, the install will be easier.
3. The Tonneau Cover may seem wrinkled when first installed, this is caused by the fabric
becoming wrinkled during shipping. The fabric and the wrinkles will relax after a few
days installed on the vehicle.
Warning: this top is designed to protect you from the elements only and is not designed
!
to keep you inside the vehicle in the event of an accident. Always fasten your seat belt.
IF YOU HAVE ANY PROBLEMS WITH THE INSTALLATION OR PERFORMANCE OF THIS
TONNEAU COVER , DO NOT RETURN THE PRODUCT TO THE RETAILER. PLEASE CALL
909-272- 3176 FOR INSTALLATION HELP. FACTORY TRAINED PERSONNEL WILL BE
ABLE TO WALK YOU THROUGH THE INSTALLATION/PROBLEM.
Installation Instructions
1. Before installing the Tonneau, remove the original plastic pin (supplied by Jeep®) from the hole of
the factory soft-top bow assembly slider track. This will allow the bow assembly to move forward
for proper installation and fitting of the Tonneau cover (Figures 1 and 2).
Figure 1
Figure 2
For Technical Support/Warranty Information please call 310-762-9944
Smittybilt, 400 West Artesia Blvd, Compton CA 90220
Installation Instructions
Tonneau Cover (#7010XX-7210XX)
1987-95 Jeep Wranglers
2. Lay the Tonneau over vehicle and wrap around the roll bar at the rear of the vehicle (Figure 3).
Figure 3
3. Lift flap on rear of Tonneau and slide factory tailgate channel on Tonneau retainer. Insert channel
back onto vehicle (Figures 4 and 5).
Figure 4
Figure 5
For Technical Support/Warranty Information please call 310-762-9944
Smittybilt, 400 West Artesia Blvd, Compton CA 90220
Installation Instructions
Tonneau Cover (#7010XX-7210XX)
1987-95 Jeep Wranglers
4. Starting at the rear of the vehicle, insert the plastic retainer strip (sewn into Tonneau) into the soft-top
channel. Work towards the front pulling the Tonneau forward. Complete for the driver, passenger,
and rear sides (Figure 6).
5. Wrap the Flaps at the front of the Tonneau around the roll bar and fasten into buckle (Figure 7).
Figure 6
Figure 7
For Technical Support/Warranty Information please call 310-762-9944
Smittybilt, 400 West Artesia Blvd, Compton CA 90220
Installation Instructions
Tonneau Cover (#7010XX-7210XX)
1987-95 Jeep Wranglers
LIMITED WARRANTY
Smittybilt (The Company) warrants to the original purchaser of this product that should the product or any part thereof,
under normal use and conditions, be proven defective in material or workmanship within the warranty period of 1 year from
the date of purchase, such defect(s) will be repaired or replaced (At the Company’s option) without charge for parts or labor.
To obtain repair or replacement within the terms of the warranty, the product is to be delivered with proof of warranty
coverage ( e.g. dated bill of sale, receipt), specification of defect, freight pre-paid with Returns Good Authorization Number
from Smittybilt to place of purchase. Items returned to Smittybilt Automotive without an Returns Authorization Number will
be refused and returned to sender at the senders expense.
This warranty does not apply to any product or part thereof which, in the opinion of the Company, has suffered or been
damaged through altercation, improper installation, mishandling, misuse, neglect accident or acts of nature. THE EXTENT
OF THE COMPANY’S LIABILITY UNDER THIS WARRANTY IS LIMITED TO THE REPAIR OR
REPLACEMENT PROVIDED ABOVE AND, IN NO EVENT, SHALL THE COMPANY’S LIABILITY EXCEED
THE PURCHASE PRICE PAID BY THE PURCHASER FOR THIS PRODUCT.
This warranty is in lieu of all expressed warranties and liabilities. ANY IMPLIED WARRANTIES, INCLUDING ANY
IMPLIED WARRANTY OF MERCHANTABILITY SHALL BE LIMITED TO THE DURATION OF THIS WRITTEN
WARRANTY. ANY ACTION FOR BREACH OF ANY WARRANTY HEREUNDER INCLUDING ANY IMPLIED
WARRANTY OF MERCHANTABILITY MUST BE BROUGHTH WITHIN A PERIOD OF 90 DAYS FROM DATE OF
ORIGINAL PURCHASE.IN NO CASE SHALL THE COMPANY BE LIABLE FOR ANY CONSEQUENTIAL OR
INCIDENTAL DAMAGES FOR BREACH OF THIS OR ANY OTHER WARRANTY, EXPRESSED OR
IMPLIED,WHATSOEVER. No person or representative is authorized to assume for the company any liability other than
expressed herein in connection with the sale of this product. Some states do not allow limitations on how long an implied
warranty lasts or the exclusion or limitation of incidental or consequential damage, therefore above limitations may not apply
to you. This warranty gives the purchaser specific legal rights. The purchaser may have additional rights, which vary from
state to state.
Some states do not allow limitations on how long an implied warranty lasts or the exclusion or limitation of incidental or
consequential damage, therefore above limitations may not apply to you. This warranty gives the purchaser specific legal
rights. The purchaser may have additional rights, which vary from state to state.
For Technical Support/Warranty Information please call 310-762-9944
Smittybilt, 400 West Artesia Blvd, Compton CA 90220
