Installation Instructions
Chevy Silverado 1500,2500,3500
Part #17290
Alcohol Towelette
Note the areas where the Fender Flares
If Fender Flares are being painted; do not install edge extrusion until painting is complete.
STEP 1:
wrench/socket. (wrench/socket and Allen key not supplied).
STEP 2:
Flares. Peel back 2” of the adhesive backing and position
contact with the vehicle body.
Bolt-On Fender Flares
(07-13)
WWW.SMITTYBILT.COM
Hardware Included QTY Hardware Included QTY Bolt Kit Included QTY
Extrusion 27ft
CLIP .6mm 12 Nuts 42
Washers 42
Ensure that both left and right hand Fender Flares suit the profile of the vehicle.
come in contact with the vehicle. NOTE: Before fitting Fender Flares remove any moldings, strips or existing flares from
the wheel arch. If there is a body side molding, mark where the molding is to be cut, alternatively the Fender Flare can
be cut to go around the molding. Be sure to allow enough room for the extrusion.
*PRIOR TO ANY PAINTING & INSTALLATION, PRODUCT SHOULD BE THOROUGHLY
INSPECTED FOR ALL COMPONENTS LISTED ABOVE. PRODUCT SHOULD ALSO BE TEST
FITTED PRIOR TO ANY PAINTING & INSTALLATION. PLEASE CONTACT SMITTYBILT IF YOU
HAVE ANY FITMENT QUESTIONS AND OR MISSING COMPONENTS.
PAINTING INSTRUCTIONS –
Prior to painting, clean all surfaces to be painted using clean water and a mild detergent, do not use lacquer thinner or
any solvent based products. Wipe completely dry. Best results will be achieved by wiping the areas to be painted with a
tack rag just prior to painting. Most automotive paints can be applied directly to the Fender Flares, however some may
require a primer (check paint manufacturer specifications). Good adhesion will be achieved without sanding. Select a
paint (and primer if necessary) that is suitable for rigid plastics PMMA (Acrylic). If using a paint system that requires
baking, do not expose the product to temperatures above 70°C (158°F). Do not fit the extrusion or any of the hardware
to the Fender Flares until the paint is completely dry.
Please read instructions entirely before installing this product.
4 Black Hex Bolts 42
Attach the 9 bolts, washers and nuts to each
Fender Flare using a 5/32” Allen key and a 3/8”
Ensure inside of Fender Flares where the rubber seal is
attached is clean, using the alcohol wipes provided. Wipe
away any residue with a dry clean cloth.
on the Fender Flare. Attach the seal to the Fender Flare,
peeling back a few inches at a time. Ensure pressure is
used to secure rubber seal to Fender Flare edge. Attach
rubber seal along all areas the Fender Flare will make
For Technical Support/Warranty Information please call 310-762-9944
Smittybilt, 400 West Artesia Blvd, Compton, CA 90220
Attach the included rubber seal to the Fender
Installation Instructions
Chevy Silverado 1500,2500,3500
Part #17290
STEP 5:
STEP 6
:
when satisfied tighten the screws fully to ensure rubber
STEP 4:
Bolt-On Fender Flares
STEP 3:
Trim any excess rubber seal and discard.
WWW.SMITTYBILT.COM
(07-13)
Flares will make contact. Ensure fenders are dry prior to
install.
Clean the body areas where the Fender
Place the Fender Flare on the vehicle into the
position of best fit. Note where the slots in Fender Flare
at positions A, B, C, and D align with the existing screws
in the vehicle. Remove Fender Flare. Use the original
manufacturer’s hardware that is in the wheel arch of the
vehicle to fit the Fender flares. Remove the x4 9/32”
(7mm) socket head screws from the fasteners on the
vehicle.
For Technical Support/Warranty Information please call 310-762-9944
Smittybilt, 400 West Artesia Blvd, Compton, CA 90220
Place the front Fender Flares onto the vehicle
and line up the holes on the part with screw holes on the
vehicle. Re-Install the socket head screws into the
fender to secure the Fender Flares. Fit the Fender Flares
loosely until the Fender Flares are aligned as desired,
seal is flush neatly against the body.
Installation Instructions
Chevy Silverado 1500,2500,3500
Part #17290
STEP 10:
STEP 8:
Flares. Peel back 2” of the adhesive backing and position
contact with the vehicle body.
STEP 7:
Attach the 11 bolts, washers and nuts to each
wrench/socket. (wrench/socket and Allen key not
Bolt-On Fender Flares
WWW.SMITTYBILT.COM
REAR FENDER FLARE INSTALLATION
Fender Flare using a 5/32” Allen key and a 3/8”
supplied). Ensure inside of Fender Flares where the
rubber seal is attached is clean, using the alcohol wipes
provided. Wipe away any residue with a dry clean cloth.
(07-13)
Attach the included rubber seal to the Fender
on the Fender Flare. Attach the seal to the Fender Flare,
peeling back a few inches at a time. Ensure pressure is
used to secure rubber seal to Fender Flare edge. Attach
rubber seal along all areas the Fender Flare will make
STEP 9:
Trim any excess rubber seal and discard.
For Technical Support/Warranty Information please call 310-762-9944
Smittybilt, 400 West Artesia Blvd, Compton, CA 90220
Clean the body areas where the Fender
Flares will make contact. Ensure fenders are dry prior to
install.
Installation Instructions
Chevy Silverado 1500,2500,3500
Part #17290
STEP 12:
Double check the front and rear Fender Flares
STEP 11:
are to the body, take the
neatly against the body.
Bolt-On Fender Flares
WWW.SMITTYBILT.COM
To secure the Fender Fl
black metal clips and slide them over the Fender Flare and
the inner wheel arch lip. Position the clip so that the barb in
the clip locates in the slot of the Fender Flare. Ensure all
fixing points are secure and that the rubber seal is flush
(07-13)
to make sure all bolts are tight and clips are securely
fastened. Your installation is now complete. Do not use
abrasive cleaners.
For Technical Support/Warranty Information please call 310-762-9944
Smittybilt, 400 West Artesia Blvd, Compton, CA 90220
