9
0 Before Starting
i
Note: the SMH Technologies website (www.smh-tech.com)
may contain an updated version of this user’s manual.
Please check before continuing reading this documentation.
0.1 Important Notice to Users
While every effort has been made to ensure the accuracy of all information in
this document, SMH Technologies assumes no liability to any party for any
loss or damage caused by errors or omissions or by statements of any kind
in this document, its updates, supplements, or special editions, whether such
errors are omissions or statements resulting from negligence, accidents, or
any other cause.
0.2 Safety
To protect FR3070A against electrostatic discharge (ESD), always connect
yourself to ground (e.g. via wrist straps) when handling the board.
Always store FR3070A inside an antistatic bag when not in use.
0
Before Starting
10
0.3 Getting Technical Support
SMH Technologies is continuously working to improve the firmware and to
release programming algorithms for new devices. SMH Technologies offers
a fast and knowledgeable technical support to all of its customers and is
always available to solve specific problems or meet specific needs.
To get in touch with SMH Technologies, please refer to the contact
information below.
Phone: +39 0434 421111
Fax: +39 0434 639021
Technical Support: support@smh-tech.com
0.4 Additional Documentation
This user’s manual provides information about how to setup FR3070A and
its hardware characteristics.
For information about FlashRunner commands and their syntax, including
specific commands for specific family of microcontrollers, please refer to the
FlashRunner Programmer’s Manual, included (in PDF format) in the
FlashRunner CD-ROM, or download the latest version on SMH
Technologies website (www.smh-tech.com) in the download area.
FR 3070 A User’s Manual
11
1 Overview
1.1 What is FR3070A?
FR3070A is an optional daughter board that can be mounted on Agilent
Medalist In-circuit Board Test System Utility Card.
With the Agilent Medalist In-Circuit Board Test System Utility Card, the
integration of implementation of the general MCUs, Flash and EEPROM
programming or any other functional testing can be easily achieved
multiples of plug-in cards support
Dedicated 12 signal pins to DUT - (no MUX)
It provides plug-in slots for common programming protocols for MCUs, Flash
and EEPROM used in Automotive and other electronic industries.
The plug-in card should come with the necessary software and drivers that
can be integrated into the Agilent Medalist Window XP environment to
improve the user experience in developing and debugging production tests.
Figure 1.1: FR 3070 A
1
Overview
12
1.2 Features
1.2.1 General features
Fastest programming algorithms (as fast as target device’s memory
technology limit), approved by silicon manufacturers;
Supports most ISP protocols (BDM, JTAG, SPI, I2C, MON, ICC, SCI,
etc.);
Data integrity guaranteed (every data transfer to/from the host system
or Secure Digital card is CRC tagged).
1.2.2 Hardware
12V power supply input;
ISP lines:
Six digital I/O lines;
Two digital I/O or analog output lines;
Two programmable output voltages;
One programmable clock output
Secure Digital memory cards (up to 2 GB);
512 bytes on-board dynamic memory;
No magnetic isolated Ethernet channels.
Clear and card reset input lines
1.2.3 Software
Controllable by any Windows based system through specific DLL
unlimited software-selectable scripts projects
Interface Library DLL to control the instrument from within user written
applications
Erase, blank check, program, read, verify, oscillator trimming, etc.
FR 3070 A User’s Manual
13
1.3 Package Checklist
The FR3070A package includes the following items:
FR3070A unit including pre-installed uSD cards with the programming
algorithm(s) specified at the time of purchase
FlashRunner “System Software” CD-ROM, containing the FlashRunner
Programmer’s Manual in PDF format;
User’s manual
Registration card
1.4 Hardware Overview
FR3070A is composed of one board assembly witch can be connected
through a 2 X 28 pins connectors to the Agilent Medalist In-circuit Board
Utility card
1.4.1 Power Supply
FR3070A is powered through a 12V DC power supply.
1.4.2 LAN Connection
i
Note: No magnetic is used. Isolation is done using a 0.01uF
capacitor (this is a intended to be use as a transformerless
Ethernet). Possible connection is to use similar biasing on
the plug-in side to achieve proper communication
1.4.3 ISP lines
12 specific fully configurable lines are available.
1
Overview
14
1.5 Programming Algorithms and Licenses
FR3070A includes programming algorithms for several devices. In order to
program a specific device, however, a specific license file for that device
must be purchased.
i
Note: FR3070A comes already preinstalled with the
license(s) you specified at the moment of purchase. You can
purchase additional licenses at any future moment.
Programming algorithms and license files are stored in the SD card (see the
FlashRunner Programmer’s Manual for more information).
1.5.1 Installing New Licenses
When you buy an additional license for a specific device, you will get:
An algorithm file (.alg);
A license file (.lic);
A device-specific script example (.frs).
The .alg file contains the actual programming algorithm for the requested
device (and several other devices of the same family).
The .lic file contains an unlocking code that will let you use the programming
algorithm. A license file enables the use of a specific programming algorithm
on a specific FR3070A instrument (licenses are serial number specific).
The script file contains an example of script to use as a starting point for your
specific programming needs (for more information on scripts, see the
FlashRunner Programmer’s Manual).
To install the new license, do the following (for each programming module):
1. Copy the .alg file into the \ALGOS directory of the SD card (if an
.alg file with the same name already exists, overwrite it);
2. Copy the .lic file into the \LICENSES directory of the SD card.
FR 3070 A User’s Manual
15
To copy files on the SD card, use either a standard card reader connected to
a PC or transfer the files using the FlashRunner FSSENDFILE command
(for more information on FR3070A commands, see the FlashRunner
Programmer’s Manual).
1.6 Upgrading the Firmware
The FR3070A firmware can be easily upgraded, for more information, please
refer to the FlashRunner Programmer’s Manual.
2
System Setup
16
2 System Setup
2.1 Overview
This chapter will explain how to set up FR3070A for the first time.
i
Note: to install the FR3070A hardware please refer to the
Agilent Medalist In-circuit Board Utility card technical
specifications
2.2 Software Setup
The FR3070A system software CD contains the following components:
DLL files
Script examples
Documentation in PDF format
2.2.1 DLL installation
See Agilent Medalist In-circuit Board Utility card technical specifications
FR 3070 A User’s Manual
17
2.3 Programming example
Here below a typical example of FR3070A software interfacing:
xdload "FR3070A1"
xdconnect "FR3070A1"
xdcall "FR3070A1","send_command",Var,Rtn$; "run SCRIPT.FRS"
xdcall "FR3070A1","get_answer",Var,Rtn$; "20000"
if Rtn$ = ">" then
print "Programming Passed"
else
print "Programming Failed, The error code is "; Rtn$
end if
xddisconnect "FR3070A1"
xdunload "FR3070A1"
2.4 LAN Configuration
FlashRunner Programmer’s Manual describes the proper procedure for
modifying LAN parameters.
FR3070A is shipped with following factory parameters:
IP address: 10.3.112.20
Subnet id: 255.0.0.0
Gateway: 10.3.112.2
2
System Setup
18
If Ethernet module is reset, factory parameters will not be loaded. New
parameters are the following ones:
IP address: 192.168.1.100
Subnet id: 255.255.255.0
Gateway: 192.168.1.1
3
Connectors
20
3 Connectors
3.1 Overview
FR3070A must be connected to the Agilent Medalist In-circuit Board utility
card by using 2 high-density connectors.
3.2 ISP connector
All the ISP line are connected trough the J601 connector (see figure below).
This connector has several input/output lines (both digital and analog) that
are automatically configured depending on the specific target device to be
programmed (see the Programmer’s Manual to learn how to connect these
lines to your specific target device).
!
Note: ISP and I/O signals are not optoisolated and are
referenced to GND (the power supply ground).
FR 3070 A User’s Manual
21
3.3 ISP and Communication connectors
Figure 3.1: “J601” and “J602” connectors (top wiew)
Table 3.1: “J601” Connector Signals
Pin #
Signal Name
Description
A1
N.C.
Not Connected
A2
DIO0/AO0
Digital input/output 0 or analog output 0
A3
N.C.
Not Connected
A4
DIO1/AO1
Digital input/output 1 or analog output 1
A5
N.C.
Not Connected
A6
DIO2
Digital input/output 2
A7
N.C.
Not Connected
A8
DIO3
Digital input/output 3
A9
GND
Ground
A10
DIO4
Digital input/output 4
A11
N.C.
Not Connected
A12
DIO5
Digital input/output 5
A13
N.C.
Not Connected
A14
DIO6
Digital input/output 6
A15
N.C.
Not Connected
A16
GND
Ground
A17
N.C.
Not Connected
A18
CLKOUT
Clock output
A19
N.C.
Not Connected
A20
GND
Ground
A21
N.C.
Not Connected
A22
VPROG0
Programmable voltage 0
A23
GND
Ground
A24
VPROG1
Programmable voltage 1
A25
GND
Ground
A26
AIN0
Analog Input Line 0
A27
12Vdc
DC power supply
A28
N.C.
Not Connected
3
Connectors
22
Pin #
Signal Name
Description
A29
12Vdc
DC power supply
A30
N.C.
Not Connected
Table 3.2: “J602” Connector Signals
Pin #
Signal Name
Description
A1
N.C.
Not Connected
A2
Reserved
Reserved
A3
N.C.
Not Connected
A4
GND
Ground
A5
N.C.
Not Connected
A6
Reserved
Reserved
A7
N.C.
Not Connected
A8
Reserved
Reserved
A9
AGND
Analog Gound
A10
ETH_TXP
ethernet TX+
A11
N.C.
Not Connected
A12
N.C.
Not Connected
A13
ETH_TXN
ethernet TX-
A14
N.C.
Not Connected
A15
AGND
Analog Gound
A16
AGND
Analog Gound
A17
N.C.
Not Connected
A18
N.C.
Not Connected
A19
ETH_RXP
ethernet RX+
A20
N.C.
Not Connected
A21
ETH_RXN
ethernet RX-
A22
N.C.
Not Connected
A23
AGND
Analog Gound
A24
N.C.
Not Connected
A25
GND
Ground
A26
N.C.
Not Connected
A27
N.C.
Not Connected
A28
UNIV_CLEAR#
Universal Clear
A29
N.C.
Not Connected
A30
CARD_RESET#
Plug-in Card Reset
N.C.
Not Connected
FR 3070 A User’s Manual
23
4 Technical Specifications
4.1 Absolute Maximum Ratings
Table 4.1: Absolute Maximum Ratings
Parameter
Value
“J601” power
Maximum supply voltage on line POWER (reference GND)
-20V to 15V
“J601” ISP lines
Maximum input voltage on lines DIO/AO[1..0], DIO[6..2], CLKOUT
-1V to +7V
Maximum current on lines DIO/AO[1..0], DIO[6..2], CLKOUT
±50mA
Maximum current on line VPROG0
500mA
Maximum current on line VPROG1
250mA
“J602” communication lines
Maximum input voltage on lines UNIV_CLEAR#, CARD_RESET#
-1V to +7V
4.2 DC Characteristics and Functional Operating
Range
Table 4.2: DC Characteristics and Functional Operating Range
“J601” Connector
VIL (input low voltage) on lines DIO
Configured as digital lines
- - 0.3V
PROG0
VIH (input high voltage) on lines DIO
Configured as digital lines
0.7V
PROG0
-
V
PROG0
VOL (output low voltage) on lines DIO, CLKOUT
Configured as digital lines,
V
PROG0
= 3V, IOL = 12mA
- - 0.36V
VOH (output high voltage) on lines DIO, CLKOUT
Configured as digital lines,
V
PROG0
= 3V, IOH = 12mA
2.56V - -
VOL (output low voltage) on lines DIO, CLKOUT
Configured as digital lines,
V
PROG0
= 5.5V, IOL = 24mA
- - 0.36V
VOH (output high voltage) on lines DIO, CLKOUT
Configured as digital lines,
V
PROG0
= 5.5V, IOH = 24mA
4.86V - -
IOH current (source) on lines DIO
Configured as input with
active pull-ups
-
3.4mA
-
4
Technical Specifications
24
DIO/AO[1..0] voltage
Configured as analog output
0V - 14.5V
DIO/AO[1..0] IO current (sink and source)
Configured as analog output
- - ±40mA
IOH current (source) on lines DIO/AO[1..0]
Configured as analog lines
with active pull-ups
-
5.5mA
-
VPROG0 output voltage
1.6V - 5.5V
VPROG0 current (source)
- -
500mA
VPROG1 output voltage
3.5V - 13V
VPROG1 current (source)
- -
250mA
Supply voltage
- 12V
-
Power consumption
- -
1.5A
“J602” Connector
VIL (input low voltage) on lines UNIV_CLEAR#,
CARD_RESET#
- -
0.99
VIH (input high voltage) on lines UNIV_CLEAR#,
CARD_RESET#
2.30 - 3.6
FR 3070 A User’s Manual
25
4.3 AC Characteristics
Table 4.3: AC Characteristics
Parameter
Condition
Value
Min
Typ
Max
t
RISE
on lines DIO[6..2],
DIO[1..0], CLKOUT when
configured as digital output
push-pull
V
PROG0
= 1.8V
Load: 470Ω//100pF
(see figure 4.1a)
-
40ns
-
V
PROG0
= 3.3V
-
30ns
-
V
PROG0
= 5V
-
25ns
-
t
FALL
on lines DIO[6..2],
DIO[1..0], CLKOUT when
configured as digital output
push-pull
V
PROG0
= 1.8V
Load: 470Ω//100pF
(see figure 4.1a)
-
35ns
-
V
PROG0
= 3.3V
-
25ns
-
V
PROG0
= 5V
-
25ns
-
t
RISE
on lines DIO/AO[1..0]
configured as analog output
V
PROG1
= 3V
Load: 4.7KΩ//100pF
(see figure 4.1a)
-
7µs - V
PROG1
= 12V
-
11µs
-
V
PROG1
= 14.5V
-
12µs
-
t
FALL
on lines DIO/AO[1..0]
configured as analog output
V
PROG1
= 3V
Load: 100pF (see figure 4.1b)
-
8µs - V
PROG1
= 12V
-
20µs
-
V
PROG1
= 14.5V
-
30µs
-
t
RISE
on line VPROG0
V
PROG0
= 0-1.8V
Load: 15Ω//10mF (see figure 4.1a)
-
10ms
-
V
PROG0
= 0-3.3V
Load: 22Ω//10mF (see figure 4.1a)
-
15ms
-
V
PROG0
= 0-5.5V
Load: 22Ω//10mF (see figure 4.1a)
-
20ms
-
t
FALL
on line VPROG0
V
PROG0
= 1.8-0V
Load: 10mF (see figure 41b)
-
300ms
-
V
PROG0
= 3.3-0V
-
350ms
-
V
PROG0
= 5.5-0V
-
350ms
-
t
RISE
on line VPROG1
V
PROG1
= 0-3V
Load: 10Ω//1mF (see figure 4.1a)
-
1.3ms
-
V
PROG1
= 0-5V
Load: 47Ω//1mF (see figure 4.1a)
-
1.8ms
-
V
PROG1
= 0-14.5V
Load: 94Ω//1mF (see figure 4.1a)
-
13ms
-
t
FALL
on line VPROG1
V
PROG1
= 3-0V
Load: 1mF (see figure 4.1b)
-
18ms
-
V
PROG1
= 5-0V
-
30ms
-
V
PROG1
= 14.5-0V
-
45ms
-
CLKOUT frequency
0MHz
-
50MHz
4
Technical Specifications
26
4.4 Physical and Environmental Specifications
Table 4.6: Physical and Environmental Specifications
Parameter
Value
Dimensions
150x74x11
Operating temperature
0-50°C
Operating humidity
90% max (without condensation)
Storage temperature
0-70°C
Storage humidity
90% max (without condensation)
VAT (P.I./C.F.) n. IT01697470936
Via Giovanni Agnelli, 1
33083 Villotta di Chions (PN) Italy
Phone +39 0434 421111
Fax +39 0434 639021
info@smh-tech.com
www.smh-tech.com
Registered office/sede legale:
V.lo del Forno 9
Zip/Cap 33170 Pordenone (PN) Italy
Share Capital/Capitale Sociale € 10.000
Systein Italia Srl
Loading...
