Instructions for Use
Washing machine
Page 2
187348
Thank you for your condence in purchasing our washing machine, and
congratulations on the excellent choice.
Your new washing machine meets the requirements of modern treatment of
laundry. It is rational in the consumption of energy, water and washing agents.
Our appliances are friendly to the environment. Some of the materials may be
recycled, others deposited or decomposed. To avoid pollution of environment,
once your appliance is no longer useful, take it to your local authorized waste
appliance dealer.
The appliance is intended exclusively for use in households. If the appliance is
used for professional purposes, for prot, or for purposes beyond regular use
in a household, or if appliance is used by a person who is not a consumer, the
warranty period equals the shortest warranty period possible as stipulated by
the relevant legislation.
Description of washing machine .....................3
Cautions .............................................................4
Installation and connection .............................. 6
Operation.......................................................... 10
Tips for washing and energy saving .............19
Cleaning and maintenance ............................. 21
Failures .............................................................24
Tables ...............................................................27
2
Page 3
187348
1. Front panel
2. Detergent dispenser
3. Door
4. Filter lid
5. Adjustable legs
6. Water outlet hose
7. Water inlet hose
8. Mains power cable
Dimensions (w x d x h):
600 mm x 600 mm x 850 mm
Depth with door open: 106 cm
Weight (net): 90 kg
Nominal voltage: 230 V, 50 Hz
Power: 2000 W
Max. load: 6 kg
Power socket: (230 V, 50 Hz, 10 A)
Water pressure: min. 0,05 MPa, max. 0,8 MPa
Fuse: 10 A
3
Description of washing machine
Technical information
Page 4
187348
•
Be sure to remove transport brackets prior rst use of the appliance. Attempted
operation of the blocked machine may result in irreparable damage which is not
covered by the manufacturer’s warranty!
•
When connecting your washing machine to water supply, be sure to use brand
new water inlet hose and appropriate sealing gaskets (attached).
•
Do not locate the machine in a room with temperature below 0°C. Parts of the
machine may be damaged if frozen.
•
Install the washing machine in a perfectly horizontal position, on solid at
concrete oor.
•
Follow the instructions for correct installation and water and mains
connections.
•
Never immerse the end of the drain hose into the draining water.
•
Prior starting the washing cycle lock the door by pressing them at the designed
spot.
•
Door may not be open during the washing cycle.
•
Use only detergents and softeners for machine wash. Manufacturer may not
assume responsibility for any damage and eventual discoloring of gaskets
and plastic components as a consequence of incorrect use of bleach and/or
coloring agents.
•
For removal of lime residues use such agents with added anti-corrosion
agents. Follow the manufacturer’s instructions. Finish the lime removal by
multiple rinsing to remove completely eventual acid residues.
•
Never use detergents containing solvents, since there is a danger of creating
toxic gasses which may damage the machine and result in ignition or
explosion.
•
Upon completion of washing operation close the water faucet.
•
Before any transport block the machine by inserting at least one transport
blocking rod. Prior this operation disconnect the appliance from the mains
power!
•
Rating plate with basic information is located above the opening of the
machine.
•
The warranty shall not apply to consumables (bulbs), minor discoloration or
deviations of color, increased noise level as a consequence of appliance age,
which does not affect appliance functionality, and aesthetical deciencies
which do not affect appliance functionality or safety.
4
Cautions
Page 5
187348
Before connecting the appliance read
these instructions carefully. Repairing
the failure arising from inappropriate
connections or use of the appliance is not
covered by the guarantee.
The symbol on the product or on its
packaging indicates that this product
may not be treated as household
waste. Instead it shall be handed over
to the applicable collection point for the
recycling of electrical and electronic
equipment. By ensuring this product
is disposed of correctly, you will help
prevent potential negative consequences
for the environment and human health,
which could otherwise be caused
by inappropriate waste handling of
thisproduct. For more detailed information
about recycling of this product, please
contact your local city ofce, your
household waste disposal service or the
shop where you purchased the product.
5
Page 6
187348
In removing the wrapping be careful not to
damage the appliance with a sharp object.
Before connecting the appliance, let it
warm up to room temperature (wait for two
hours).
•
Our appliances are packed in environmentally
friendly materials which may be recycled,
deposited or decomposed without any threat to
the environment.
•
To this end all wrappings are marked accordingly.
•
Move the pipes.
•
Loosen screws A at the rear of the machine
(Fig. 1).
•
Remove the brackets B (Fig. 1) and slide them
into the groove on the blocking rod (Fig. 2) - the
right one should be turned around.
•
Use the brackets to rotate blocking rods for 90°
and pull them out.
•
Close the openings with attached plastic pegs.
Save transport brackets for eventual later use.
Be sure to remove the transport brackets
prior rst use, otherwise the appliance
may be permanently damaged. In such
cases the warranty conditions are void.
Fig. 1
Fig. 2
Fig. 2
6
Installation and connection
Package removal
Removal of transport
brackets
Page 7
187348
•
Put the appliance in horizontal position by turning
the adjustable legs.
The legs are adjustable up to +/- 1 cm.
After the adjustment tighten the nuts rmly (A)
- towards the bottom of the machine!
Vibrations, moving of the appliance and
loud operation due to incorrect setting of the
adjustable feet shall not be covered by this
warranty.
The appliance should be placed on a surface
with concrete base; the surface should be
dry and clean in order to prevent slipping.
The adjustable feet should also be cleaned
before installation.
•
If you have a tumble dryer of the same
dimensions, you can place it on top of the
washing machine.
To ensure correct operation of the appliance,
water pressure inlet must be between 0,05 and
0,8 MPa.
Minimum water pressure can be established
by measuring the quantity of poured out water.
3 litres of water must be poured out from
completely opened tap in 15 seconds.
•
Insert the gasket with screen into the water inlet
hose thread Screw the hose thread to the water
faucet
•
In case of hot and cold water connection, connect
one hose to cold and other to hot water faucet as
marked at the rear of the appliance (letters C and H)
(C - cold; H - hot)
7
Water inlet connection
Leveling the appliance
Page 8
187348
Partial Aqua-stop (water stop system)
In case of damage on the interior pipe, leaking is
prevented by automatic closing system which stops
water inlet to the machine. In such cases display A
turns red.
Inlet pipe must be replaced.
Complete Aqua-stop
In case of damage on the interior pipe, leaking is
prevented by automatic closing system which stops
water inlet to the machine.
Security system also detects whether there is any
water leakage within the interior of the machine.
In such cases washing is suspended, machine
switches on the pump and signals error.
Do not immerse the Aqua-stop system inlet
pipe into the water, because it contains the
electric valve!
•
Fix the outlet hose to run into the sink or the
bathtub, or connect it directly to the wall drain
outlet (diameter min. 4 cm).
•
Wall drain must be installed properly and must
enable occasional cleaning.
•
Fasten the outlet hose support with a piece of
rope led through the hose elbow, to prevent the
hose from slipping to the oor.
The end of outlet hose should be placed between
minimum 60 cm and maximum 100 cm above the
oor level.
•
Plug the mains power cable to the wall mains
socket.
•
Required voltage and other information are written
on the rating plate above the door opening of the
machine.
8
Connect the appliance
to the mains supply
Water outlet connection
Page 9
187348
The wall socket must be accessible at all
times and must be equipped with an earth
lead (in accordance with the local safety
regulations).
The permanent connection must be tted
by an authorized personnel only.
Damaged mains power cable may be
replaced only by the producer or his
authorized personnel.
Never plug the appliance into the electric
shaver socket or hair dryer socket.
If the socket, the machine is connected to, is protected by the
overload protection switch (FID), the nominal differential current
of the switch must be 30 mA (switch mark Idn or I∆n). In case
of a smaller nominal current in the switch, the machine may be
switched off during its normal operation.
9
Page 10
187348
A - program selector
B - Spin - reduced spinning key-
switch
C - Quick wash
D - Higher water level - HWL
E - Rinse hold button
F - START/PAUSE button
Signal LED’s:
- washing program stages
• wash
• rinse
• spin
- Lock / End
10
Operation
Page 11
187348
•
Open the door of the machine.
•
Load the laundry into the drum.
•
Close the door.
•
Open the water inlet faucet.
•
Select the program.
•
Add washing and treatment agents (detergent and
softener).
•
Start the operation by pushing the START/PAUSE
button (F).
- Open the door of the machine.
Door is opened by pulling the handle (lever) on the
right hand side of the door towards you.
- Sort the laundry by the type of fabrics.
Do the buttons and zippers, tie the strings
and pull out the pockets.
Very delicate laundry should be put in a
special protective sack.
It is suggested to load the drum with items
of different sizes.
Washing procedureWashing procedure
11
Page 12
187348
Pay attention to the labels on the clothes,
indicating the recommending washing
mode (see table of textile treatment
symbols on the last page of these
instructions).
Program is selected by turning the program selector
(A) from the “0” position to the desired washing
program. The signal LED indicating particular
washing stage for the chosen program starts
ashing. The program selector (A) may be turned
in both directions, and the appropriate program
selected according to the type of laundry washed
and the required washing temperature (see
Program Chart for help). You may select basic or
partial programs.
Select additional functions by pressing their relevant
buttons (F).
- Selection of basic programs
Basic programs represent integral programs
containing all washing stages, including softening
and spinning (see Program Chart). They are
selected by turning the program selector (A) to the
appropriate position.
Cotton (whites/colored)
Normally stained cotton and ax bed linen and
underwear, table cloth, bathroom towels, top
garments, etc.
For heavily stained cotton use the heavy program,
or program with the pre-wash.
If you wish the laundry not to be excessively
Washing machine
operation
Washing machine
operation
12
Page 13
187348
creased at the end of washing, use easy ironing
program.
Synthetic
Normally stained shirts, blouses and other polyester
and polyamide garments, or a mixture of these
fabrics with cotton.
For heavily soil permanent press use program with
pre-wash.
Delicate
This is a program for delicate fabrics (dresses,
skirts, blouses) and curtains.
Wool
Especially gentle program for washing wool and
garments made from mixture of other fabrics with
wool, appropriately marked for machine washing.
Hand wash
Very gentle program concluded with short gentle
spin (max. 400 RPM).
It is suitable for washing fabrics from ax, silk, wool
or viscose, marked accordingly for hand wash.
Mixed
Special program for washing normally stained
colored laundry made from various resistant fabrics
at 30°C.
- Selection of additional function
Additional functions alter the basic washing cycle
procedure.Particular function is switched on by
pressing the relevant button. The selection is
conrmed with sound signal and switching on the
signal LED above the selected function. If certain
function is not available for the selected program,
signal LED will not illuminate.
The function is switched off by pressing the same
button again - signal LED goes off.
13
Page 14
187348
Select the particular function after the
selection of the basic program, but prior
pressing the START/PAUSE button (F).
Reduced spin RPM
•
Reduction of spin RPM depends on program
selection and maximum RPM for particular type of
machine.
Basic programs Spin speed - RPM
max. reduced
Cotton 1200/1400 1200 → 600
1400 → 700
Synthetics, Mixed 1000 600
Delicate 700 0
Wool 600 0
Hand wash 400 0
Quick wash (selection by separate button)
•
Program saves energy.
•
Convenient for washing less stained laundry, or
smaller quantities of laundry.
•
Washing and rinsing time is reduced.
•
Reduced water consumption.
Higher water level (HWL)
For washing heavily stained laundry.
Using the HWL button (C) you may increase
quantity of water for rinsing. For certain programs
this function is available also for washing.
Rinse hold
RINSE HOLD function is selected if you want the
laundry not to be excessively creased in case you
are unable to remove it from the drum immediately
after the end of washing cycle. This is specially
handy for washing of synthetics and delicate
laundry. However, it is not recommended for wool
or hand wash.
14
Page 15
187348
- Selection of partial programs
These are independent programs and may be used
when you do not need the entire washing program.
In case you would like to use more additional
programs in a sequence, you must turn off the
appliance prior any new program selection (turn the
program selector to “0” for at least one second).
Rinse
Independent program for rinsing delicate laundry,
without intermediate spinning and with short nal
spin. You may use it for rinsing manually washed
delicate laundry.
You may engage the reduced spin RPM button.
Softener
This program is intended for softening, bleaching
or impregnating of washed laundry. It is completed
with spinning at 1000 RPM.
You may engage the reduced spin RPM button.
Rinse hold
Use it when the washing program was interrupted
or if pump stop function was engaged, and you
only wish to drain the water out of the drum, without
spinning.
Spin
Intensive spinning for non-delicate laundry at high
spin RMP.
You may engage the reduced spin RPM button.
15
Page 16
187348
- Adding washing and softening agents
(see Tips for washing and energy saving)
•
pre-wash compartment
•
main wash compartment
•
softener compartment
If you do not apply the program which includes the
pre-wash feature, you may add washing detergent
directly into the drum, using the measuring vessel.
When adding softener, be careful to ll the
dispenser only up to the marked level.
Be sure to close the detergent dispenser
when opening/closing the appliance door.
•
Push the START/PAUSE button (F). Sound signal
conrms the start, the LED indicating particular
washing stage stops ashing. The machine starts
operating after a few seconds. If the door is not
properly closed after starting the operation, the
washing stage indicator LED starts ashing again
after a few seconds. When you close the door, the
machine initiates the selected program.
•
As each washing stage is completed the relevant
washing stage indicator LED goes off and the
subsequent one goes on.
•
In case you would like to alter the washing
program after the initiated washing operation,
turn the program selector for one second to the
position “0”, followed by the selection of a new
program.
Start the operationStart the operation
16
Page 17
187348
Upon switching OFF, all additional pre-
selected functions are deleted; therefore
they must be switched-ON again.
- End of operation
Flashing LED’s for washing stages indicate that the
program was completed.
•
Sound signal indicates that you may now open
the door of the machine.
•
Extract the laundry from the drum and remove
any alien objects from the door gasket.
•
Leave the door ajar to allow the interior to dry.
•
Close the water inlet faucet.
•
Switch the machine off by turning the program
selector to position “0”.
•
By the user
Own interruption
You may stop the program by turning the program
selector to the position “0”. If there is water in the
drum select one of additional programs (drain, spin)
to empty the water and terminate the program.
PAUSE
By pressing the START/PAUSE button (F) program
may be suspended at any time. After certain time
you may open the door if there is no water in the
drum, otherwise this is not possible. Program is
continued by pressing the START/PAUSE button
(F).
•
Failures
Program is suspended in case a failure occurs.
Signal LED’s are ashing and sound signal is
heard (see cf. Failures).
•
Power failure
If a power failure occurs the washing program is
InterruptionsInterruptions
17
Page 18
187348
interrupted, and when the power is restored the
program is automatically resumed.
If a power failure occurs when the drum is
still full of water, be careful not to open the
door before you pump the water out.
•
Lock
- It is switched on by simultaneously pressing the
Quich wash button (C) and HWL button (D) for
at least 3 seconds. Selection is conrmed by the
sound signal and illuminated signal LED Lock/
End. The function is switched off following the
same procedure.
- As long as the Lock function is engaged
you may not alter the program or additional
functions. You may merely switch off the
machine by turning the program selector (A) to
the position “0”. Lock remains active even after
the appliance is switched off, and you have to
disengage it if you want to select a new washing
program.
•
Setting the sound signal
The appliance has the possibility of setting
stronger sound signal. Press the Spin button
(B) and switch the machine on. The selection of
the function is conrmed by the sound signal.
The function is disengaged following the same
procedure.
Special functionsSpecial functions
18
Page 19
187348
•
Before washing sort out the laundry according to
the type, degree of dirtiness and color resistance.
•
Prior selecting the washing program consult the
sewn tab with information on a particular piece
of laundry (see Maintenance Chart on the last
page).
•
Wash separately the new colored textile products
or the rst time.
•
Wash heavily soiled laundry in small quantities
and add more detergent.
•
Treat stubborn stains with special stain remover, it
will save energy.
•
With lightly stained laundry select washing
program without pre-wash, use short program and
select lower washing temperature. This way you
may save up to 50% of energy.
•
Avoid washing too little quantities of laundry
because of energy saving and for better
performances of the appliance.
•
The largest allowed quantity of dry laundry is
indicated in the Program chart.
•
Before washing empty the pockets, close zip
fasteners, and remove any metal fasteners or
badges that might clog the drain or damage the
laundry or drum interior.
•
Loosen the stacked laundry prior inserting it into
the drum.
•
Use only detergents for machine wash.
•
Add powder or liquid detergents according to the
manufacturer’s instructions.
•
If water hardness level exceeds 14°dH degrees,
the use of water softener is required.
19
Tips for washing and energy saving
Page 20
187348
•
If you do not apply the program which includes
the pre-wash feature, you may add washing
detergent directly into the drum.
•
If you use thick liquid softener it is recommended
to dilute it with water, to prevent clogging of
dispenser compartment ducts.
•
Washing machine is equipped with the dispenser
partition gate, so you may pour liquid detergent
also into the central compartment. If you use
powder detergent the gate is lifted up, and in case
of liquid detergent it is slid down.
•
Liquid detergents are intended for main wash
only, without pre-wash.
•
Insert particularly delicate linen (stockings,
delicate female underwear, etc.) into the special
bag.
•
High spin RPM leave less moisture in laundry
which dries out much quicker in the tumble dryer,
thereby saving energy.
Do not put clods of detergent into the
soap dispenser as the tube in the washing
machine may clog.
20
Hardness
scale
Degree of hardness
°dH(°N) m mol/l °fH(°F) p.p.m.
1 - Soft 0-7 0-1,3 0-12 0-120
2 - Medium 7-14 1,3-2,5 12-25 120-250
3 - Hard 14-21 2,5-3,8 25-37 250-370
4 - Extra hard >21 >3,8 >37 >370
In case of hard water add detergent according to the Chart for
degree 1 and add appropriate quantity of water softener (see
manufacturer’s instructions).
Page 21
187348
Disconnect the washing machine from the
mains before cleaning!
•
The casing should be cleaned with soft cloth and
mild detergent.
•
The interior of the drum and the door gasket is
cleaned by washing at 60°C without laundry and
adding half quantity of detergent.
•
If necessary, clean the detergent dispenser. Pull it
out from its casing completely by pressing the ap
(see Fig.).
•
If necessary, clean the cover of the bung under
the running water.
21
Cleaning and maintenance
Page 22
187348
•
Wash it under running water using a brush, and
dry it. Remove any leftover dried detergent from
the bottom of the casing.
•
Clean the entire rinsing area of the washing
machine with a brush, especially the nozzles on
the upper side of the rinsing chamber.
•
Clean frequently the water inlet hose screen
under running water.
•
After each wash wipe the door rubber gasket. This
will prolong its useful life.
•
Open the lter lid using at screwdriver or similar
tool.
•
Filter needs occasional cleaning, especially
following heavily shaggy or old laundry. Before
cleaning, drain any water from the machine via
drain pipe.
22
Page 23
187348
•
Turn it anti-clockwise, pull it out and clean under
running water.
•
Insert the lter back as shown on the picture
(arrow and pointer), and tighten by turning it in
clockwise direction. To ensure good sealing the
gasket surface (A) must be dirt free.
23
Page 24
187348
The washing machine automatically monitors the execution of particular
functions during the operation, and reports any detected failures. In such
cases signal LED’s start ashing in certain sequence, accompanied by the
audible signal, sounding in the same sequence as the indicator LED’s ash.
The ashing sequence changes in accordance with the nature of the detected
failure.
In some cases you may attempt removing certain failures yourself, so count the
number of ashes, repeating after certain pauses.
The machine signals failures immediately after detecting them and stops the
program, except for heater failure, where the machine completes the washing
program without heating water.
Failures
In certain cases you may remove the failure yourself:
2 - two ashes: door is not correctly closed
3 - three ashes: inappropriate water intake
7 - seven ashes: inappropriate water outlet.
In all other instances mark the number of ashes indicating the failure, switch
off the machine and call nearest authorized service center (LED’s continue
ashing until you switch the machine off).
Interferences from the ambient (for example electrical wiring) could induce
signalization of different faults. In such cases:
- switch the appliance off, and wait for a few seconds;
- switch the appliance back on and repeat the washing program.
If the fault repeats, call authorized service shop.
Warranty shall not apply in case of failures due to interferences from the
environment (lightning stroke, power supply circuit faults, natural disasters).
24
Failures
Page 25
187348
25
Failure Possible cause Remedy
The machine does not
work (indicator LED’s
are not illuminated).
Machine is not powered. Check if:
• power in the socket,
• the fuse is OK,
• plug is in the socket.
Washing program
does not start
(washing stage LED is
ashing).
Door is not properly closed. Push it towards the machine.
Water does not enter
the machine (after
approx. 8 min the
machine reports
failure -3 ashes).
Disturbed water inlet. Check if:
• the water faucet is open,
• inlet pipe net lter is clean.
Push the START button.
Water is leaking from
the machine.
Filter is not tightly screwed in.
Inlet pipe is not tightly screwed
to the machine or to the water
faucet.
Outlet pipe fell to the oor.
Tighten the lter properly.
Tighten the inlet pipe.
Afx the outlet pipe to the drain.
The machine moves
during operation.
The machine is not properly
leveled.
Transport brackets are not
removed.
Level the machine with the adjustable
legs.
Remove transport brackets.
The machine vibrates
during the spin.
Unevenly distributed laundry,
especially with very small
quantities (for ex. only the
bathrobe).
This is normal, the machine will
reduce the RPM if vibrations are too
strong.
Wash larger quantity of laundry.
Excessive foaming
during washing.
Excessive measure of detergent. Use washing powder according to
the instructions by the producer and
according to the water hardness and
soiled laundry.
Use only detergents for machine
washing.
Water is poorly
pumped out or not at
all (machine reports
failure - seven ashes
of LED).
Water outlet is clogged. Check if:
• the lter is clean,
• outlet pipe is not jammed,
• outlet pipe is positioned higher than
1 m.
Push START again.
Laundry is not
properly spun.
No failure is reported.
The machine switched on the
UKS* function. Because of bad
laundry balance, the machine
has automatically reduced spin
RPM.
The machine operates normally.
Wash large and small pieces of
laundry together.
Page 26
187348
* UKS: universal stability control - this function prevents excessive vibrations during spinning.
In case you were not successful in repairing the
malfunctions in spite of the above suggestion chart,
call the nearest authorized service shop.
Repairing the failure arising from inappropriate
connections or use of the appliance is not covered
by the guarantee, and the repair expenses are paid
by the customer.
26
Failure Possible cause Remedy
Greasy wads appear
on the laundry.
Too little detergent (laundry was
very greasy).
Wash the laundry again.
Add more detergent for such soiled
laundry, or use liquid detergent.
Laundry is stained
after washing.
You used liquid detergent or
detergent for colored laundry
which does not contain whitener.
Use the detergent containing
whitener.
White powdery
residues on the
laundry.
It is not the consequence of bad
rinsing, but because of neophosphate detergents containing
non soluble components
(zeolites) for water softening.
Such substances may be
deposited upon the laundry.
Immediately rinse the laundry once
again.
• Use liquid detergents which do not
contain zeolites.
• Try removing the residues with the
brush.
Detergent residues in
the dispenser.
Low water ow pressure.
Some detergents may stick to
the dispenser rather hard if it is
wet.
• Clean the inlet pipe lter net.
• In case of low water pressure
increase water level.
• Wipe the dispenser prior loading
detergent.
Softener is not
completely rinsed,
or water is left in the
dispenser dish.
Sucking cover is not correctly
positioned or is clogged.
Clean the dispenser and rmly x the
cover to its place.
Washing time is
longer than usual.
• The machine switched on
the UKS* system because of
uneven laundry load.
• Power failure occurred.
• Washing program time may be
prolonged for 10 minutes and the
machine still functions perfectly.
• Time is prolonged for the power
failure period.
Page 27
187348
* Testing program by EN 60456 with the selection of max. spin
RPM.
27
Basic programs
Max. load (kg)
Temp. (°C)
Spin speed
(max RPM)
Duration (min.)
Water cons.
(L/basic cycle)
Energy cons. (kWh/
basic cycle)
Cotton 6 95
1400
139 51 2,10
Cotton 6 60 119 45 1,12
Cotton + prewash 6 60 150 53 1,34
Cotton - heavy soil * 6 60 140 45
1,14
Cotton 6 40 121 45 0,66
Cotton - easy ironing 3 60
1000
115 45 1,10
Synthetic 3 60 106 43 0,93
Synthetic 3 40 95 40 0,52
Delicate 2,5 40
700
59 55 0,45
Delicate 2,5 30 53 55 0,36
Wool 2 40
600
51 42 0,32
Wool 2 30 46 42 0,22
Hand wash 1,5 30 400 47 50 0,25
Mixed 3 1000 72 40 0,32
Partial programs
Rinse
3 700 25 40 0,02
Softener
6 1000 15 16 0,02
Drain
6 - 2 -
Spin
6 1400 12 - 0,03
Tables
Program chart
Page 28
187348
possibility
28
Program
Rinse hold
Quick wach
Higher water
level (HWL)
Spin
Basic programs
Cotton
Cotton with prewash
Cotton heavy
Cotton - easy ironing
Synthetics with prewash
Synthetic
Delicate
Wool
Hand wash
Mixed
Partial programs
Rinse
Softening
Pumping water
Spinning
Program chart/
Additional functions
Page 29
187348
29
Normal wash
Delicate wash
Max.
washing
temp. 95°C
Max.
washing
temp.
60°C
Max.
washing
temp.
40°C
Max.
washing
temp.
30°C
Manual
washing
Washing
not
allowed
Whitening
Whitening in cold water
Whitening not allowed
Ironing Hot iron max.
200°C
Hot iron max.
150°C
Hot iron max.
110°C
Ironing not
allowed
Dry cleaning Dry cleaning in all
solvents
Perchlorin-
etyhlene
R11, R113,
Kerosene
Dry cleaning in
kerosene, in pure
alcohol and in
R 113
Dry cleaning not
allowed
Drying Place on
at surface
Hang wet Hang
High
temperature
Low
temperature
Tumble drying
not allowed
Maintenance chart
Loading...
