Dear Customer,
Thank you for choosing this special edition Smeg – Dolce&Gabbana, Sicily is my love
small domestic appliance.
Smeg and Dolce&Gabbana have combined their artistic talents to create a unique
collection, made in Italy by Smeg with unmistakeable Dolce&Gabbana design touches.
We hope you enjoy using your new appliance!
Kindest regards,
SMEG S.p.A.
Contents
1 Instructions 32
1.1 Introduction 32
1.2 This user manual 32
1.3 Intended use 32
1.4 General safety instructions 33
1.5 Manufacturer liability 35
1.6 Identification plate 35
1.7 Disposal 35
2 Description 36
2.1 Product description 36
2.2 Description of parts 37
2.3 Standard accessories 38
3 Use 40
3.1 Before first use 40
3.2 Using the stand mixer 40
3.3 Using the pouring shield 45
3.4 Functions 46
3.5 Speed setting suggestions 47
4 Cleaning and care 51
4.1 Instructions 51
4.2 Ordinary daily cleaning 51
4.3 What to do if... 52
EN
We advise you to read this manual carefully, it contains all the instructions for maintaining the appliance’s aesthetic
and functional qualities.
For further information on the product: www.smeg.com
31
Instructions
1 Instructions
1.1 Introduction
Key information for the user:
Instructions
General information on this user
manual, on safety and final
disposal.
Description
Description of the appliance and its
accessories.
Use
Information on the use of the
appliance and its accessories,
advice on preparing recipes with
the appliance.
Cleaning and care
Information for correct cleaning and
care of the appliance.
Safety instructions
Information
1.2 This user manual
This user manual is an integral part of the
appliance and must therefore be kept in its
entirety and within the user’s reach for the
whole working life of the appliance.
1.3 Intended use
• The appliance is designed exclusively for
home use.
• Do not use the appliance for anything
other than the intended use.
• Use the appliance indoors.
• The stand mixer can be used to mix,
whip, whisk and knead solid and liquid
ingredients to speed up various
preparations and recipes. With the
addition of optional accessories, it is
able to roll out and cut pasta into
different shapes.
• The appliance is not designed to operate
with external timers or with remotecontrol systems.
• This appliance may not be used by
people (including children) of reduced
physical, sensory and mental capacity,
or lacking in experience in the use of
electrical appliances, unless they are
supervised or instructed by adults who
are responsible for their safety.
32
Advice
Instructions
1.4 General safety instructions
Follow all safety instructions in order to be
able to use the appliance safely.
• Read this user manual carefully before
using the appliance.
• Switch off the appliance immediately
after use.
• Do not leave the appliance unattended
while it is operating.
• Disconnect the appliance from the
power socket as soon as you have
finished using it and before cleaning it.
• Do not immerse the appliance, the
power cord or the plug in water or any
other liquid.
• Do not use the appliance when the
power cord or the plug is damaged or
when the appliance has been dropped
or is damaged in any manner.
• The cable is short to prevent accidents.
Do not use an extension cord.
• Ensure the cord does not come into
contact with sharp edges.
• Do not pull on the cord to unplug it from
the power socket.
• Do not place the appliance above or
near lit hob burners or electric rings,
inside an oven or near other heat
sources.
• Do not try to repair the appliance
yourself or without the assistance of a
qualified technician.
• In the event of a fault, repairs should only
be carried out by a qualified engineer.
• Do not modify the appliance.
• Never try to put out a fire or flames with
water: turn off the appliance and remove
the plug from the socket and smother the
flames with a fire blanket or other
appropriate cover.
• Keep the appliance out of children’s
reach.
IT
EN
33
Instructions
For this appliance
• Unplug the appliance from the power
socket before changing the accessories
or approaching moving parts.
• Do not insert, remove or replace
standard accessories with the safety lock
disengaged (motor head lowered).
• Do not touch moving parts while the
appliance is operating. Keep hands,
hair, clothing, spatulas and any other
objects away from the mixer’s standard
and optional accessories to avoid
personal injury or damage to the
machine.
• Do not remove accessories while the
mixer is operating.
• Check that the bowl is correctly
positioned and locked into its base
before you start using the appliance with
its accessories.
• Do not release or remove the bowl while
the appliance is operating.
• Do not exceed the bowl’s maximum
capacity.
• Let the appliance cool down before
cleaning.
• Only use original standard and optional
accessories provided by the
manufacturer. The use of non-original
components, standard and optional
accessories could lead to personal injury
or damage to the appliance.
• Do not place objects on top of the
appliance.
• Do not use harsh detergents or sharp
objects to wash or remove residue from
the bowl, standard and optional
accessories.
• Keep a close eye on children and
ensure they do not play with the
appliance.
34
Instructions
1.5 Manufacturer liability
The manufacturer shall not be held
responsible for personal injuries or property
damage caused by:
• Any use of the appliance other than the
one it was designed for
• Not having read the user manual
• Tampering with any part of the
appliance
• Use of non-original spare parts
• Not following the safety instructions.
1.6 Identification plate
The identification plate bears the technical
data, serial number and brand name of the
appliance. Do not remove the identification
plate for any reason.
1.7 Disposal
This appliance must be disposed of
separately from other waste
(Directive 2012/19/EU). The
appliance does not contain substances in
quantities sufficient to be considered
hazardous to health and the environment, in
accordance with current European
directives.
• Old appliances do not belong in
household waste! To comply with
current legislation, old appliances,
having reached the end of their useful
lives, should be taken to a disposal
facility where they can be sorted. In this
way, any valuable material contained in
the old appliances can be recycled,
helping to protect the environment. The
relevant local authorities or their waste
disposal operators can provide further
information.
Our appliances are packaged in nonpolluting and recyclable materials.
• Deliver the packing materials to the
appropriate recycling centre.
Plastic packaging
Danger of suffocation
• Do not leave the packaging or any part
of it unattended.
• Do not let children play with the plastic
bags.
IT
EN
Electrical power
Danger of electrocution
• Disconnect the mains power supply.
• Unplug the appliance.
35
2 Description
11
12
2
8
10
1
3
3
4
9
13
14
4
5
6
7
2.1 Product description
Description
Model SMF02 - SMF03 - SMF13 - Stand Mixer
1 Motor head
2 Body
3 Power and speed selector
4 Head raising/lowering release button
5 Lower attachment for standard
accessories
6 Front attachment hub for optional
accessories
7 Front hub cover
8 Bowl base
9 Bowl**
10 Pouring shield*
11 Dough hook
12 Flat beater
13 Wire whisk
14 Flex edge beater*
*Standard only on certain models. Also available as an optional accessory.
**The bowl design and material may vary according to the model of stand mixer.
36
Description
2.2 Description of parts
Motor head (1)
Upper part of the appliance, responsible
for rotating the standard and optional
accessories.
Power and speed selector (3)
Lever for speed selection.
The ‘0’ position of the lever corresponds to
the OFF position (appliance off).
To start the appliance, position the lever on
one of the 10 available speeds (positions
1-10), depending on the type of mixing
required.
See ”3.5 Speed setting suggestions” for
more details and suggestions.
Head raising/lowering release button (4)
Button which releases the motor head to
position it in one of its two possible
configurations (raised or lowered position).
Lower attachment for standard
accessories (5)
Attachment for inserting standard
accessories. Holds the accessory solidly in
position during planetary movement.
Front attachment hub for optional
accessories (6)
Attachment for connecting optional
accessories.
It is protected by a removable cover.
Bowl base (8)
Base with slots in which to insert the bowl
and which then lock it in position.
Bowl** (9)
Bowl capacity 4.8 litres.
Ideal for holding both large and small
quantities of ingredients.
The handle simplifies insertion and removal.
IT
EN
**The bowl design and material may be different depending on model of mixer.
37
Description
2.3 Standard accessories
Aluminium dough hook
For slowly combining, mixing and kneading
leavened dough type mixtures including
bread, pasta, pizza, etc.
Aluminium flat beater
Stainless-steel wire whisk
For beating, mixing, whisking, whipping
ingredients such as butter, eggs, cream, etc.
Also ideal for preparing creams, custards,
sauces, etc.
Flex edge beater*
For combining, mixing, and starting all
mixing procedures.
For preparing cake batters and pastries,
biscuits, icing, etc. and for other, thicker
batters and mixes
*Standard only on certain models. Also available as an optional accessory.
38
Stainless steel beater with flexible silicone
edges.
Useful for mixing doughs and soft batters.
The removable edges guarantee even
consistency throughout the process.
Description
Pouring shield*
For protecting against splattering and to
facilitate the addition of ingredients when in
use.
Only suitable for use with the stainless steel
bowl*.
The standard and optional
accessories intended to come into
contact with food are made of
materials that comply with the
provisions of current legislation.
IT
EN
*Standard only on certain models. Also available as an optional accessory.
39
Use
1
2
3 Use
Danger of electrocution
• Plug into an earthed three-pin socket.
• Do not tamper with or remove the earth
pin.
• Do not use an adapter.
• Do not use an extension cord.
• Failure to follow these instructions could
result in death, fire, or electrical shock.
3.1 Before first use
1. Remove any protective films or other
packaging from the outside or inside of
the appliance, including standard
accessories.
2. Remove any labels (apart from the
technical data plate) from the appliance,
its components and standard
accessories.
3. Remove and wash the bowl and
accessories (see ”4 Cleaning and
care”).
4. Clean the body and head of the
appliance with a damp cloth.
5. Dry the components thoroughly and
place them in their working positions.
3.2 Using the stand mixer
1. Place the mixer on a flat, stable and dry
surface.
2. Press the release button (1).
3. Hold down the button and raise the
head (2), accompanying its movement
with your hand.
It is possible for the motor head to
move slightly when mixing or
kneading dense mixtures or large
quantities. This should be
considered normal and will not
compromise the operation or long
lifetime or the appliance.
40
Use
3
5
4
A
B
4. Insert the bowl (3) in its base (4).
Grasp the bowl by its handle (5) and
turn the bowl (3) clockwise until it locks
into place.
5. Select the accessory required based on
the type of mixing to be performed.
6. Insert the accessory (6) in the lower
attachment (7) and push it upwards.
Keep pressing the accessory upwards
and turn it anticlockwise until the pin (8)
locks fully into place.
7
6
8
IT
EN
Moving parts
Danger of personal injury
• Do not operate the mixer with the
accessory without having locked the
bowl in position.
6
Ensure that the accessory is
correctly locked into place in the
attachment.
41
Use
1
2
9
10
7. Add the ingredients to the bowl.
8. To close, bring the motor head down by
pressing the release button (1) and then
tilt the motor head (2) slightly backwards
until it releases.
9. Keep the button pressed down and
lower the head (2), accompanying its
movement with your hand.
11. Check that the speed selector (10) is
positioned on ‘0’ (OFF).
12. Insert the plug into the power socket.
13. Select the required speed (from 1 to
10) using the selector (10) to start the
appliance and begin mixing the
ingredients. See ”3.5 Speed setting
suggestions”.
10. Position the pouring shield (9) on the
bowl if required, with the opening
facing outwards.
42
Warnin g!
• For greater safety, each time that power
is cut to the motor, for example by
raising the motor head or unplugging
the appliance at the socket, it is first
necessary to return the speed selector
to zero in order to restart the mixer.
In order to stop the appliance and
raise the head to change the
accessory or remove the bowl,
move the speed selector to ‘0’
(OFF).
Use
9
Moving parts
Danger of personal injury and
damage to the appliance
• Do not touch the accessories while the
appliance is moving.
• Do not operate the mixer with the
accessory inserted and the bowl empty.
When you have finished using the mixer:
1. Position the speed selector (10) on ‘0’
(OFF) and remove the plug from the
socket.
2. Remove the pouring shield, if it is on the
bowl (9).
3. Press the release button (1) to raise the
head (2).
2
121
IT
EN
43
Use
6
7
6
8
3
4
B
A
4. Push the accessory (6) upwards slightly
and turn it clockwise to unlock it from the
pin (8).
Extract the accessory (6) from the lower
attachment (7).
5. Remove the bowl (3) from its base (4) by
turning it anticlockwise to release it.
44
Use
1
3.3 Using the pouring shield
1. Fit the pouring shield (1) to the upper lip
of the stainless steel bowl* after inserting
the bowl in its base and the accessory in
the lower attachment and lowering the
head into the operating position.
2. Fit the pouring shield with the opening (1)
facing outwards in order to add
ingredients to the bowl without stopping
the stand mixer.
1
Moving parts
Risk of damage to the cover
IT
EN
• Remove the pouring shield to raise or
lower the head with the accessory fixed
to the lower attachment.
*Standard only on certain models. Also available as an optional accessory.
45
Use
3.4 Functions
Safety lock system
The appliance has a safety system which
automatically shuts off the appliance when
the motor head is raised.
You should nevertheless always
place the speed selector in the 0
(OFF) position before pressing the
button to move the motor head.
Smooth Start Function
The Smooth Start function starts the
appliance up with a reduced initial speed,
regardless of the speed set with the
selector.
The speed progressively increases until the
set speed is reached.
This avoids damage to the appliance and
the accessories, and ensures ingredients
are not thrown from the bowl.
Planetary movement
The planetary movement is generated by
rotation (1) of the accessory around its axis
in the opposite direction to the rotary
movement (2) of the mixer.
This movement maximises coverage of the
entire bowl with consistent results for all
mixtures.
2
1
46
Hot appliance
• Following prolonged use, the upper part
of the motor head may heat up. This is
not, however, normally indicative of a
malfunction.
3.5 Speed setting suggestions
Use
IT
The speed selector shows the most
appropriate accessory to use with
the selected speed.
The speeds indicated in the table
are approximate and can vary
depending on the recipe and the
interaction of the different
ingredients used.
Speed setting Function Accessory
LOW
1 - 3
LOW
1 - 3
COMBINE
Combining ingredients.
KNEAD
Kneading - preparing leavened
doughs (bread, pizza, egg pasta
etc.), see ” Bread/pizza dough and
egg pasta dough”.
EN
MEDIUM
4 - 7
HIGH
8 - 10
MIXING
Mixing and beating dense batters.
Beating eggs and butter, cake mixes
such as fruit cake.
WHIPPING AND WHISKING
Whisking light or dense batters.
whipping cream, egg whites or
sauces.
47
Use
Table of recommended accessory, recommended speeds and maximum capacities
Accessory Preparation Speed Time Min/max capacity
Egg whites 8 -10 2-3 min
Cream 8-10 2-3 min 100 ml/1000 ml
Prepared cake batters 1 - 7 3-4 min 2 kg total batter
or
Pastry 1 - 7 3-4 min 2.6 kg total batter
Bread/pizza dough 1 - 3 4 min
Egg pasta dough 1 - 3 5-7 min
(1)
Average egg size: 53-63 g
(1)
2 - 12
1.8 kg total dough (max
1.2 kg flour)
500 g total dough with 3
eggs
48
The table should be taken as a
guideline only.
The speed and capacity depend
on the accessory used, the quantity
of mixture in the bowl and the
ingredients used.
Use
General advice
• Never exceed the maximum speed and
capacity indicated in the table in order to
prevent damage to the appliance.
• Turn on the appliance at a low speed
until all the ingredients are mixed, then
increase the speed on the basis of the
required operation.
• When adding ingredients, always pour
them onto the edge of the bowl and not
directly onto the moving accessory.
• Reduce the speed when you add dry or
liquid ingredients to stop them splattering.
Increase the speed again when they
have been mixed.
• Use the pouring shield* on the bowl for
liquid mixtures or when adding dry
ingredients to avoid getting objects in the
vicinity of the stand mixer dirty or being
hit by splattered liquids or powder.
• Keep the bowl and accessories clean,
and attach them to the appliance only
when they are perfectly dry.
• Clean the head and body of the mixer
carefully using a damp cloth if they are
dirty.
Tips for whisking egg whites
• For the best results, use egg whites at
room temperature.
• Before whisking the egg whites, ensure
that the accessory and bowl are not
damp or greasy and that they have no
trace of yolk on them.
• To prevent splattering, gradually
increase the speed up to the
recommended speed, then whisk until
you achieve the required stiffness.
• The stand mixer allows very rapid
whisking of egg whites. Pay close
attention to the process to avoid overwhisking the egg whites, which would
result in separation.
Tips for whipping cream
• For the best results, use cold whipping or
double cream straight out of the fridge.
• To prevent splattering, gradually
increase the speed up to the
recommended speed, then whip until
you achieve the required consistency.
• When whisking a quantity equivalent to
one litre of liquid cream, start at a speed
of 7-8 for the first minute, or at least until
it starts thickening. Then increase the
speed to 10 for the remaining time.
IT
EN
*Standard only on certain models. Also available as an optional accessory.
49
Use
Recommendations for recipes using eggs
• For the best results, use eggs at room
temperature.
• When working with stiff pasta doughs,
do not exceed the quantity of 3 medium
eggs, adding small quantities of water if
necessary.
Recommendations for kneading
• Make sure that the proportion of liquids
in doughs is sufficient (at least 50-60% of
the quantity of flour, by weight). Doughs
which are too dry and therefore stiff can
overload the motor.
• If the appliance is struggling, switch it off,
divide the dough into two pieces and
knead them separately.
Bread/pizza dough and egg pasta dough
• Start the appliance at speed 1 until the
ingredients are incorporated, then
increase to speed 3.
• In order to allow the ingredients to best
amalgamate, we recommend adding
the liquid ingredients to the bowl at the
start.
• Egg pasta, bread, pizza: only knead
using the dough hook. Use the flat
beater only to start the kneading
procedure.
DO NOT use the flex edge beater*.
Prepared cake batters
• For up to 1 kg of batter: start up the
appliance at a low speed until the
ingredients start to come together, then
gradually increase the speed up to 7 for
the remaining time.
• For up to 2 kg of batter: start up the
appliance at speed 1 until the
ingredients start to come together, then
gradually increase the speed up to 3-4
for the remaining time.
Pastry
• Cold ingredients should always be used
when making pastry, particularly short
pastes, unless the recipe states
otherwise.
• When preparing cakes, initially beat
butter at room temperature with sugar,
then add the eggs and finally the flour.
It is possible for the motor head to
move slightly when mixing or
kneading dense mixtures or large
quantities. This should be
considered normal and will not
compromise the operation or long
lifetime or the appliance.
*Standard only on certain models. Also available as an optional accessory.
50
Cleaning and care
4 Cleaning and care
4.1 Instructions
Improper use
Danger of electrocution
• Switch off and unplug the appliance
before cleaning the mixer and its
standard and optional accessories.
Improper use
Risk of damage to surfaces
• Do not use steam jets to clean the
appliance.
• Do not use cleaning products containing
chlorine, ammonia or bleach on steel
parts or parts with metallic finishes (e.g.
anodised, nickel- or chrome-plated).
• Do not use abrasive or corrosive
detergents (e.g. scouring powders, stain
removers and pan scourers).
• Do not use rough or abrasive materials
or sharp metal scrapers.
4.2 Ordinary daily cleaning
To keep the surfaces of the appliance in
good condition, clean them with a damp
cloth after use.
Wipe over thoroughly and dry with a soft
cloth or microfibre cloth.
Splattered liquids or batters should
be removed immediately using a
soft, damp, cotton cloth.
The pouring shield* and the wire whisk can
be washed by hand using a neutral
detergent and a soft sponge.
The dough hook, the flat beater and the
stainless steel bowl* can be washed in a
dishwasher.
The glass bowl* can be washed by hand
with warm water and a neutral detergent or
in a dishwasher using a low temperature
program.
The flex edge beater* can be washed in a
dishwasher.
To facilitate cleaning, the silicone edges
can be removed and washed in the
dishwasher.
IT
EN
*Standard only on certain models. Also available as an optional accessory.
51
4.3 What to do if...
Problem Possible cause Solution
The motor will not start
Cleaning and care
The motor has overheated.
The plug is not properly inserted in
the power socket.
The cable is defective.
Disconnect the mixer from
the power and leave the
motor to cool.
Insert the plug into the
power socket. Do not use
adaptors or extensions.
Check that the house main
breaker is on.
Have the cable replaced at
an Authorised Service
Centre.
52
Lack of power.
The head has been raised during
operation.
Check that the house main
breaker is on.
The safety lock system has
operated. Move the speed
selector to 0 (OFF), press
and hold down the button
on the rear to release the
head and lower it.
Cleaning and care
Problem Possible cause Solution
The mixer vibrates
The mixer is not resting on a stable
surface.
The anti-slip rubber feet are worn.
The speed has been set too high
or the load is excessive.
The bowl has not been correctly
locked into its base.
The lower attachment has come
loose over time.
IT
EN
Place the mixer on a flat,
stable surface.
Have them replaced at an
Authorised Service Centre.
Set a lower speed and
ensure the bowl has not
been overfilled.
Check that the bowl is
correctly locked into its
base.
Have the mixer checked
and adjusted at an
Authorised Service Centre.
The accessories hit the
sides of the bowl
The accessory or the bowl is not
correctly locked into position.
Move the speed selector
to 0, press the button on the
rear of the appliance to
raise the head and check
that the accessory is
correctly locked into
position in the lower
attachment and the bowl is
correctly locked into
position on the base.
53
Cleaning and care
Problem Possible cause Solution
The accessory is
struggling to turn inside
the bowl
If the problem has not been
resolved or in the event of another
type of fault, contact your local
technical support centre.
The dough mixture is too thick and
is stopping the accessory from
turning.
The bowl is too full.
IT
EN
Add water or other liquid to
loosen the dough mixture.
Remove half the bowl’s
contents and work it
separately.
54
Loading...
