Smeg SM1634 User Manual
IT
Istruzioni per l'uso e l'installazione
GB
FR
ES
User's book
Notice d'utilisation
Istrucciones para el uso
ITALIANO 3-12
IT
ENGLISH 13-22
GB
FRANÇAIS 23-32
FR
ESPAÑOL 33-42
ES
ENGLISH
13
Dear customer,
Thank you for choosing our product.
Please read these instructions carefully before connecting and using the machine. An awareness
of how the machine operates will help guarantee its correct and safe use. The instructions also
contain some useful information on the machine’s functions that will help you get the most out of its
use.
If you decide to sell or give the washing machine to someone else, remember to give the instruction book to the new owner.
INDEX
NOTES AND ADVICE FOR THE USER 14-15
DESCRIPTION OF THE MACHINE 15
INSTALLING THE MACHINE 16-18
• Unpacking and unblocking the machine 16
• Positioning and levelling the machine 17
• Connecting to the water supply system 17
• Connecting to the power supply 18
USING THE WASHING MACHINE 18-20
• Using the machine 18
• Use of detergents 19
• How to eliminate stains 20
• International clothing care symbols 20
MAINTENANCE 21-22
• Cleaning the machine 21
• Cleaning the filter 21
• Troubleshooting 22
MODEL:
PRODUCTION CODE:
DATE OF PURCHASE:
SM1634
.....................................................................................................................................................................................................................
.................................................................................................................................................................................
...........................................................................................................................................................................................
GB
14
NOTES AND USEFUL ADVICE FOR THE USER
The washing machine has been designed for
❃
domestic use only, and as such any other
use is regarded as improper and therefore
potentially dangerous.
Any modifications or attempts to alter the
❃
equipment in any way may be dangerous for
the user and cause damage to the washing
machine.
Due to the weight of the machine, special
❃
safety standards must be observed during
handling.
The machine must not be used by unsuper-
❃
vised children.
Any modifications to the water or electrical
❃
system must be carried out by authorised
specialists.
When positioning the appliance, make sure
❃
that the power supply cable is not bent or
squashed and that it is accessible.
Before operating the machine, remove all
❃
packing materials and the locking device
used for protection during transport (protec-
tion screws). Failure to do this may result in
serious damage to the machine and to your
home.
If the machine is installed on a carpeted floor,
❃
make sure that air is free to circulate between
the machine and the floor.
The washing machine must never be over-
❃
loaded.
When the machine is in operation, avoid any
❃
contact with the water coming out of the drain
hose, as this may be hot. Do not touch the
door glass as this may also heat up during
the wash
Only wash clothes that are machine wash-
❃
able. In case of doubt, check the manufacturer’s instructions found on the label attached to the clothes (see “Clothing cares
symbols “ ) .
Before loading clothes into the washing ma-
❃
chine, check that all the pockets are empty.
Hard or pointed objects such as coins, pins,
nails, screws or even stones can cause serious damage.
Do not plug-in or unplug
the machine with wet
hands.
The door can only be
opened approximately
three minutes after the end
of each wash, as a safety
device has been fitted to
protect from accidental
opening.
N.B. for electronic models
the door will open when the
“end” indicator lights up
GB
The power supply socket
to which the machine is
connected must be
earthed and must comply
with the safety requirements
Unplug the washing machine from the power
supply before servicing
and cleaning.
Extension leads or multiple
adapters must not be used
to connect the washing
machine to the mains supply.
To disconnect the machine from the power supply, pull the plug and not
the cable.
Do not expose the appliance to atmospheric
agents.
After the end of each
washing cycle it is advisable to unplug the machine and shut-off the
water supply.
SM1634
NOTES AND USEFUL ADVICE FOR THE USER
15
Clothes that have been dirtied with sub-
❃
stances containing petroleum cannot be
washed in the machine. If stains have been
removed using vaporising products, before
loading the clothes in the washing machine,
wait until the substances have completely
evaporated from the material.
Do not use detergents formulated for hand
❃
washing, in that the excessive lather produced could damage the internal components.
After washing rugs, blankets or any other long
❃
fibre fabrics, remember to check the filter and,
if necessary, clean it.
It is advisable to leave the door open at the
❃
end of the wash cycle.
Under no circumstances should any repairs
❃
to the machine be attempted by unqualified
persons as this could result in serious damage and will invalidate the guarantee.
Repairs to the washing machine must only
❃
be carried out by persons authorised to do
so by the service centres. Only original spare
parts may be used for repairs.
THE MANUFACTURER WILL NOT BE HELD
RESPONSIBLE FOR ANY ACCIDENTS
THAT MAY RESULT FROM NON-COMPLIANCE WITH THE REQUIREMENTS OF
SAFETY STANDARDS OR THIS INSTRUCTION MANUAL
DESCRIPTION OF THE MACHINE
The washing machine is a household appliance that can wash any type of fabric whenever you want.
▼ The structure of the machine is fabricated in steel sheet, which has been worked using a special
process and then enamelled in order to maintain its external appearance and protect it against
corrosion.
▼ The motor and all the other moving parts are built to ensure noiseless machine operation.
▼ The large stainless steel drum is well placed to guarantee a good wash quality and prolong the life
of the washing.
▼ The easy to use control panel makes the selection of any wash or dry programme quick and
simple (see control panel and table of programmes).
▼ The ample glass door makes loading and unloading easier.
▼ The perfect machine balance is the result of many years of research aimed at finding the correct
balance between the various moving parts.
A - Glass door
B - Filter
C - Adjustable feet
D - Top cover
E -Drum
F - Control panel
SM1634
1
GB
16
The machine must be installed by professionally qualified technicians, according to
the manufacturer’s indications. Incorrect installation may result in damage to persons and property.
The machine can be installed anywhere, provided the temperature in the place of
installation is not below 3°C and the cables and hoses at the rear of the machine are
not crushed in any way.
For transport purposes the swinging unit in the machine is blocked using 4
spacers with screws. Before starting the machine these spacers and lock screws
must be removed, and stored for use in the event of a possible change of
location.
Block off the holes with the plugs provided, which can be found in the bag
containing the documents.
N.B. If the spacers fall into the inside of the machine, open the rear panel,
recover them and then replace the panel.
INSTALLING THE MACHINE
(ACCORDING TO MODEL)
V
2
For transport purposes the swinging unit in the machine is blocked using 4
spacers with screws. Before starting the machine these screws must be removed using a screwdriver.
Insert a screwdriver in the holes and proceed as shown in the figure to recover
the 4 plastic spacers.
N.B. If the spacers fall into the inside of the machine, open the rear panel,
recover them and then replace the panel.
GB
3
2A
3A
SM1634
