Gebruik‐
saanwijzing
User Manual
Notice d'utili‐
sation
Benutzerin‐
formation
Koelkast
Refrigerator
Réfrigérateur
Kühlschrank
RI360RX
CONTENTS
Safety information 17
Safety instructions 18
Operation 20
Daily use 22
Hints and tips 23
Care and cleaning 24
Troubleshooting 25
Installation 27
Technical data 30
Subject to change without notice.
SAFETY INFORMATION
Before the installation and use of the appliance, carefully read
the supplied instructions. The manufacturer is not responsible
for any injuries or damages that are the result of incorrect
installation or usage. Always keep the instructions in a safe
and accessible location for future reference.
Children and vulnerable people safety
• This appliance can be used by children aged 8 years and
above and by persons with reduced capabilities provided
that they have been given instruction and/or supervision
regarding the safe use of the appliance and understand the
potential hazards involved.
• Do not let children play with the appliance.
• Children shall not carry out cleaning and user maintenance
of the appliance without supervision.
Keep all packaging away from children and dispose of it
•
appropriately.
17
General Safety
This appliance is intended to be used in household and
•
similar applications such as:
Farm houses; staff kitchen areas in shops, offices and
–
other working environments
By clients in hotels, motels, bed and breakfast and other
–
residential type environments
Keep ventilation openings, in the appliance enclosure or in
•
the built-in structure, clear of obstruction.
18
• Do not use mechanical devices or other means to accelerate
the defrosting process, other than those recommended by
the manufacturer.
• Do not damage the refrigerant circuit.
• Do not use electrical appliances inside the food storage
compartments of the appliance, unless they are of the type
recommended by the manufacturer.
• Do not use water spray and steam to clean the appliance.
• Clean the appliance with a moist soft cloth. Only use neutral
detergents. Do not use abrasive products, abrasive cleaning
pads, solvents or metal objects.
• Do not store explosive substances such as aerosol cans
with a flammable propellant in this appliance.
• If the supply cord is damaged, it must be replaced by the
manufacturer, its Authorised Service Centre or similarly
qualified persons in order to avoid a hazard.
SAFETY INSTRUCTIONS
Installation
WARNING! Only a qualified
person must install this
appliance.
• Remove all the packaging and the transit
bolts.
• Do not install or use a damaged
appliance.
• Follow the installation instruction
supplied with the appliance.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
• Make sure the air can circulate around
the appliance.
• Wait at least 4 hours before connecting
the appliance to the power supply. This
is to allow the oil to flow back in the
compressor.
• Do not install the appliance close to
radiators or cookers, oven or hobs.
• The rear of the appliance must stand
against the wall.
• Do not install the appliance where there
is direct sunlight.
• Do not install this appliance in areas that
are too humid or too colds, such as the
construction appendices, garages or
wine cellars.
• When you move the appliance, lift it by
the front edge to avoid scratching the
floor.
Electrical connection
WARNING! Risk of fire and
electrical shock.
• The appliance must be earthed.
• Make sure that the electrical information
on the rating plate agrees with the
power supply. If not, contact an
electrician.
• Always use a correctly installed
shockproof socket.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to the
electrical components (e.g. mains plug,
mains cable, compressor). Contact the
Authorised Service Centre or an
19
electrician to change the electrical
components.
• The mains cable must stay below the
level of the mains plug.
• Connect the mains plug to the mains
socket only at the end of the installation.
Make sure that there is access to the
mains plug after the installation.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
Use
WARNING! Risk of injury,
burns, electrical shock or fire.
• Do not change the specification of this
appliance.
• Do not put electrical appliances (e.g. ice
cream makers) in the appliance unless
they are stated applicable by the
manufacturer.
• Be careful not to cause damage to the
refrigerant circuit. It contains isobutane
(R600a), a natural gas with a high level of
environmental compatibility. This gas is
flammable.
• If damage occurs to the refrigerant
circuit, make sure that there are no
flames and sources of ignition in the
room. Ventilate the room.
• Do not let hot items to touch the plastic
parts of the appliance.
• Do not store flammable gas and liquid in
the appliance.
• Do not put flammable products or items
that are wet with flammable products in,
near or on the appliance.
• Do not touch the compressor or the
condenser. They are hot.
Care and cleaning
WARNING! Risk of injury or
damage to the appliance.
• Before maintenance, deactivate the
appliance and disconnect the mains
plug from the mains socket.
• This appliance contains hydrocarbons in
the cooling unit. Only a qualified person
must do the maintenance and the
recharging of the unit.
• Regularly examine the drain of the
appliance and if necessary, clean it. If
the drain is blocked, defrosted water
collects in the bottom of the appliance.
Disposal
WARNING! Risk of injury or
suffocation.
• Disconnect the appliance from the mains
supply.
• Cut off the mains cable and discard it.
• Remove the door to prevent children
and pets to be closed inside of the
appliance.
• The refrigerant circuit and the insulation
materials of this appliance are ozonefriendly.
• The insulation foam contains flammable
gas. Contact your municipal authority for
information on how to discard the
appliance correctly.
• Do not cause damage to the part of the
cooling unit that is near the heat
exchanger.
56 4 3 2
1
A
GH F E
CB D
20
OPERATION
Control Panel
Display
1
Temperature warmer button
2
Temperature colder button
3
OK
4
It is possible to change predefined sound of
buttons by pressing together Mode and
Display
Switching on
1. Connect the mains plug to the power
socket.
2. Press the appliance ON/OFF if the
display is off. The temperature
indicators show the set default
temperature.
To select a different set temperature refer to
"Temperature regulation".
If "dEMo" appears on the display, refer to
"Troubleshooting" .
Mode
5
ON/OFF
6
temperature colder button for a few
seconds. Change is reversible.
A. Timer indicator
B. Shopping function
C. Holiday function
D. Temperature indicator
E. Alarm indicator
F. ChildLock function
G. DrinksChill function
H. Fan function
Switching off
1. Press the appliance ON/OFF for 5
seconds.
The display switches off.
2. Disconnect the mains plug from the
power socket.
Temperature regulation
Set the temperature of the appliance by
pressing the temperature regulators.
Default set temperature:
• +5°C for the fridge
The temperature indicators show the set
temperature.
21
The set temperature will be
reached within 24 hours.
After a power failure the set
temperature remains stored.
Shopping function
If you need to insert a large amount of
warm food, for example after doing the
grocery shopping, we suggest activating
the Shopping function to chill the products
more rapidly and to avoid warming the
other food which is already in the
refrigerator.
1.
Press the Mode until the corresponding
icon appears.
The Shopping indicator flashes.
2.
Press the OK to confirm.
The Shopping indicator is shown.
The Shopping function shuts off
automatically after approximately 6 hours.
To switch off the function before its
automatic end, repeat the procedure.
The function switches off by
selecting a different fridge set
temperature.
Holiday function
This function allows you to keep the
appliance closed and empty during a long
holiday period without the formation of bad
odours.
1. Press the Mode until the corresponding
icon appears.
The Holiday indicator flashes. The
temperature indicator shows the set
temperature.
2. Press the OK to confirm.
The Holiday indicator is shown.
The function switches off by
selecting a different set
temperature.
Door open alarm
An acoustic alarm will sound if the door is
left open for a few minutes. The door open
alarm conditions are indicated by:
• a flashing Alarm indicator;
• an acoustic buzzer.
When normal conditions are restored (door
closed), the alarm will stop. The buzzer can
also be switched off by pressing any
button.
ChildLock function
Activate the ChildLock function to lock the
buttons from unintentional operation.
1. Press Mode until the corresponding
icon appears.
The ChildLock indicator flashes.
2.
Press OK to confirm.
The ChildLock indicator is shown.
To deactivate the ChildLock function,
repeat the procedure until the ChildLock
indicator goes off.
DrinksChill function
The DrinksChill function is to be used to set
an acoustic alarm at the preferred time,
useful for example when a recipe requires
to cool down food products for a certain
period of time.
1. Press Mode until the corresponding
icon appears.
The DrinksChill indicator flashes.
The Timer shows the set value (30 minutes)
for a few seconds.
2. Press the Timer regulator to change the
Timer set value from 1 to 90 minutes.
3. Press OK to confirm.
TheDrinksChill indicator is shown.
The Timer start to flash (min).
At the end of the countdown the DrinksChill
indicator flashes and an audible alarm
sounds. Press OK to switch off the sound
and terminate the function.
To switch off the function repeat the
procedure until the DrinksChill goes off.
It is possible to change the time
at any time during the
countdown and at the end by
pressing the Temperature colder
button and the Temperature
warmer button.
22
Fan function
1. Press Mode until the corresponding
icon appears.
The Fan indicator flashes.
2. Press the OK to confirm.
The Fan indicator appears.
To switch off the function, repeat the
procedure until the Fan indicator goes off.
DAILY USE
WARNING! Refer to Safety
chapters.
Cleaning the interior
Before using the appliance for the first time,
the interior and all internal accessories
should be washed with lukewarm water
and some neutral soap to remove the
typical smell of a brand-new product, then
dried thoroughly.
CAUTION! Do not use
detergents, abrasive powders,
chlorine or oil-based cleaners as
they will damage the finish.
Positioning the door shelves
To permit storage of food packages of
various sizes, the door shelves can be
placed at different heights.
1.
Gradually pull the shelf in the direction
of the arrows until it comes free.
2.
Reposition as required.
The activation of the Fan
function increases energy
consumption.
If the function is activated
automatically the Fan indicator is
not shown (refer to "Daily use").
Movable shelves
The walls of the refrigerator are equipped
with a series of runners so that the shelves
can be positioned as desired.
Do not move the glass shelf
above the vegetable drawer to
ensure correct air circulation.
Low Temperature compartment
In models equipped with this feature in the
fridge part, it is intended for a best
conservation of fresh foods like fish, meat,
seafood, etc.
It is located in the lower part, directly above
of the vegetable conservation drawer.
Temperature indicator
For proper storage of food the refrigerator is
equipped with the temperature indicator.
The symbol on the side wall of the
appliance indicates the coldest area in the
refrigerator.
If OK is displayed (A), put fresh food into
area indicated by symbol, if not (B), adjust
OK
OK
A
B
23
the temperature controller to a colder
setting and wait 12 hours before checking
the temperature indicator again.
After putting fresh food into the
appliance or after opening the
door repeatedly or for a long
period, it is normal for the
indicator not to show OK; wait
at least 12 hours before
readjusting the temperature
controller.
Fan
The refrigerator compartment is equipped
with a device that allows for rapid cooling of
foods and more uniform temperature in the
compartment.
This device activates by itself when needed,
for example for a quick temperature
recovering after door opening or when the
ambient temperature is high.
It is possible to switch on the
device manually when needed
(refer to "Fan function").
The Fan device stops when the
door is open and restarts
immediately after the door
closing.
HINTS AND TIPS
Normal operating sounds
The following sounds are normal during
operation:
• A faint gurgling and bubbling sound from
coils sound when refrigerant is pumped.
• A whirring and pulsating sound from the
compressor when refrigerant is pumped.
• A sudden cracking noise from inside
appliance caused by thermic dilatation (a
natural and not dangerous physical
phenomenon).
• A faint click noise from the temperature
regulator when the compressor switches
on or off.
Hints for energy saving
• Do not open the door frequently or leave
it open longer than absolutely necessary.
Hints for fresh food refrigeration
To obtain the best performance:
• do not store warm food or evaporating
liquids in the refrigerator
• do cover or wrap the food, particularly if
it has a strong flavour
• position food so that air can circulate
freely around it
Hints for refrigeration
Useful hints:
• Meat (all types): wrap in a suitable
packaging and place it on the glass shelf
above the vegetable drawer. Store meat
for at most 1-2 days.
• Cooked foods, cold dishes: cover and
place on any shelf.
24
• Fruit and vegetables: clean thoroughly
and place in a special drawer. Bananas,
potatoes, onions and garlic must not be
kept in the refrigerator if not packed.
• Butter and cheese: place in a special
airtight container or wrap in an
CARE AND CLEANING
WARNING! Refer to Safety
chapters.
General warnings
CAUTION! Unplug the
appliance before carrying out
any maintenance operation.
This appliance contains
hydrocarbons in its cooling unit;
maintenance and recharging
must therefore only be carried
out by authorized technicians.
The accessories and parts of
the appliance are not suitable for
washing in a dishwasher.
Periodic cleaning
CAUTION! Do not pull, move or
damage any pipes and/or
cables inside the cabinet.
aluminium foil or a polythene bag to
exclude as much air as possible.
• Bottles: close with a cap and place on
the door bottle shelf, or (if available) on
the bottle rack.
This operation will improve the
performance of the appliance and save
electricity consumption.
Defrosting of the refrigerator
Frost is automatically eliminated from the
evaporator of the refrigerator compartment
every time the motor compressor stops,
during normal use. The defrost water drains
out through a trough into a special
container at the back of the appliance, over
the motor compressor, where it evaporates.
It is important to periodically clean the
defrost water drain hole in the middle of the
refrigerator compartment channel to
prevent the water overflowing and dripping
onto the food inside.
CAUTION! Take care of not to
damage the cooling system.
CAUTION! When moving the
cabinet, lift it by the front edge
to avoid scratching the floor.
The equipment has to be cleaned regularly:
1. Clean the inside and accessories with
lukewarm water and some neutral soap.
2. Regularly check the door seals and
wipe clean to ensure they are clean and
free from debris.
3. Rinse and dry thoroughly.
4. If accessible, clean the condenser and
the compressor at the back of the
appliance with a brush.
Periods of non-operation
When the appliance is not in use for long
periods, take the following precautions:
1. Disconnect the appliance from
electricity supply.
2. Remove all food.
3. Clean the appliance and all accessories.
4. Leave the door/doors open to prevent
unpleasant smells.
WARNING! If you want to keep
the appliance switched on, ask
somebody to check it once in a
while to prevent the food inside
from spoiling in case of a power
failure.
We recommend activating
Holiday mode.
TROUBLESHOOTING
WARNING! Refer to Safety
chapters.
What to do if...
Problem Possible cause Solution
The appliance does not operate.
The mains plug is not con-
There is no voltage in the
The appliance is noisy. The appliance is not sup-
Audible or visual alarm is on. The cabinet has been re-
A rectangular symbol is
shown instead of numbers
on the Temperature Display.
The lamp does not work. The lamp is in stand-by. Close and open the door.
The appliance is switched
off.
nected to the mains socket
correctly.
mains socket.
ported properly.
cently switched on or the
temperature is still too high.
The temperature in the appliance is too high.
The door is left open. Close the door.
The temperature in the appliance is too high.
Temperature sensor problem.
Switch on the appliance.
Connect the mains plug to the
mains socket correctly.
Connect a different electrical
appliance to the mains socket.
Contact a qualified electrician.
Check if the appliance stands
stable.
Refer to "Door open alarm"or
"High temperature alarm".
Refer to "Door open alarm"or
"High temperature alarm".
Contact a qualified electrician
or contact the nearest Authorised Service Centre.
Contact the nearest Authorised
Service Centre (the cooling system will continue to keep food
products cold, but temperature
adjustment will not be possible).
25
26
Problem Possible cause Solution
The lamp does not work. The lamp is defective. Contact the nearest Authorised
Service Centre.
The compressor operates
continually.
Many food products were
The room temperature is
Food products placed in
The compressor does not
start immediately after pressing the Shopping, or after
changing the temperature.
Water flows inside the refrigerator.
Water flows on the floor. The melting water outlet is
Temperature cannot be set. The FastFreeze or Shop-
dEMo appears on the display.
The temperature in the appliance is too low/too high.
Temperature is set incorrectly.
put in at the same time.
too high.
the appliance were too
warm.
The door is not closed correctly.
The Shopping is switched
on.
This is normal, no error has
occurred.
The water outlet is clogged.
Food products prevent that
water flows into the water
collector.
not connected to the evaporative tray above the compressor.
ping function is switched
on.
The appliance is in demonstration mode.
The temperature regulator
is not set correctly.
Refer to "Operation".
Wait some hours and then
check the temperature again.
Refer to climate class chart on
the rating plate.
Allow food products to cool to
room temperature before storing.
Refer to "Closing the door".
Refer to "Shopping function".
The compressor starts after a
period of time.
Clean the water outlet.
Make sure that food products
do not touch the rear plate.
Attach the melting water outlet
to the evaporative tray.
Switch off FastFreeze or Shopping manually, or wait until the
function resets automatically to
set the temperature. Refer to
"FastFreeze or Shopping function".
Keep the OK pressed for approximately 10 seconds until a
long sound is heard and display
shuts off for a short time.
Set a higher/lower temperature.
Problem Possible cause Solution
The door is not closed correctly.
The food products' temperature is too high.
Many food products are
stored at the same time.
The door has been opened
often.
There is no cold air circulation in the appliance.
Refer to "Closing the door".
Let the food products temperature decrease to room temperature before storage.
Store less food products at the
same time.
Open the door only if necessary.
Make sure that there is cold air
circulation in the appliance.
27
If the advice does not lead to
the desired result, contact the
nearest Authorised Service
Centre.
Replacing the lamp
The appliance is equipped with a longlife
LED interior light.
Only service is allowed to replace the
lighting device. Contact your Authorised
Service Centre.
INSTALLATION
Location
Refer to the assembly
instructions for the installation.
To ensure best performance, install the
appliance well away from sources of heat
such as radiators, boilers, direct sunlight
etc. Make sure that air can circulate freely
around the back of the cabinet.
Positioning
Install the appliance in a dry, well ventilated
indoors where the ambient temperature
corresponds to the climate class indicated
on the rating plate of the appliance.
Closing the door
1. Clean the door gaskets.
2. If necessary, adjust the door. Refer to
assembly instructions.
3. If necessary, replace the defective door
gaskets. Contact the Authorised
Service Centre.
Climate
class
SN +10°C to + 32°C
N +16°C to + 32°C
ST +16°C to + 38°C
T +16°C to + 43°C
Ambient temperature
5 cm
min.
200 cm
2
min.
200 cm
2
x
x
28
Some functional problems might
occur for some types of models
when operating outside of that
range. The correct operation
can only be guaranteed within
the specified temperature range.
If you have any doubts
regarding where to install the
appliance, please turn to the
vendor, to our customer service
or to the nearest Authorised
Service Centre.
Electrical connection
• Before plugging in, ensure that the
voltage and frequency shown on the
rating plate correspond to your domestic
power supply.
• The appliance must be earthed. The
power supply cable plug is provided with
a contact for this purpose. If the
domestic power supply socket is not
earthed, connect the appliance to a
separate earth in compliance with
current regulations, consulting a qualified
electrician.
• The manufacturer declines all
responsibility if the above safety
precautions are not observed.
• This appliance complies with the E.E.C.
Directives.
CAUTION! Refer to the
assembly instructions for the
installation.
Installing the appliance
CAUTION! Make sure that the
mains cable can move freely.
1. Apply the adhesive sealing strip to the
appliance as shown in figure.
2. Remove the red cover as shown in
figure .
Ventilation requirements
The airflow behind the appliance must be
sufficient.
3. Install the appliance in the niche.
4.
Attach the appliance to the niche with 4
screws.
29
• The sealing strip is attached tightly to the
cabinet.
• The door opens and closes correctly.
Assembly instructions for the
compensator lower part of the
door
1. With the door open, loosen the two
screws situated in the lower part
without unscrewing them completely.
2.
Position the steel compensator as
indicated in the figure and insert the
upper part under the head of the
screws.
5. Fix the covers on the screws.
Do a final check to make sure that:
• All screws are tightened.
3. Align the compensator with the steel
door panel and tighten the screws.
4. Insert the steel carter inside the
compensator as indicated in the figure.
30
TECHNICAL DATA
Technical data
Dimensions of the recess
Height mm 1780
Width mm 560
Depth mm 550
Voltage Volts 230-240
Frequency Hz 50
The technical information is situated in the
rating plate, on the external or internal side
of the appliance and in the energy label.
ENVIRONMENT CONCERNS
Please recycle all materials marked with the
symbol . Dispose of all packaging
materials appropriately and help to protect
the environment, and future generations.
Do not dispose of electrical equipment
marked with the
symbol along with the
general house hold waste. Dispose all
electrical goods via applicable local
authority collections, or at local authority or,
commercial recycling centres.
EN
Product fi che - Regulation (EU) No 1060/2010 of 28 September 2010
923 582 006 / RI360RX
Supplier’s name or trademark SMEG
Supplier’s model identifi er RI360RX
Category of the household refrigerating appliance model Refrigerator
Energy effi ciency class of the model A++
Energy consumption in kWh per year, based in standard test results for 24 hours. Actual energy consumption will depend on how the appliance is used and where it is located
Storage volume of each compartment and applicable star rating Refrigerator - 319
The design temperature of ‘other compartments’. For wine storage compartments, the coldest storage
temperature, either pre-set in the compartment or capable of being maintained continuously according
to the manufacturer’s instructions, shall be given
The mention ‘frost-free’ for the relevant compartment (s) Refrigerator
Power cut safe “X” h’ defi ned as’ temperature rise time’ x
Freezing capacity’ in kg/24 h x
Climate class SN-N-ST
Airborne acoustical noise emissions 34
113
x
The model is intended to be a build-in appliance yes
This appliance is intended to be used exclusively for the storage of wine no
222372819-A-092016
Loading...
