Thank you for choosing this product.
This user manual contains important information on safety and instructions intended to
assist you in the operation and maintenance of your appliance.
Please take the time to read this user manual before using your appliance and keep this
book for future reference.
Icon Type Meaning
WARNING Serious injury or death risk
RISK OF ELECTRIC SHOCK Dangerous voltage risk
FIRE Warning; Risk of re / ammable materials
CAUTION Injury or property damage risk
IMPORTANT Operating the system correctly
EN - 2
CONTENTS
1 SAFETY INSTRUCTIONS .................................................................................4
1.1 General Safety Warnings ...............................................................................................4
1.2 Installation warnings .......................................................................................................8
1.3 During Usage..................................................................................................................9
2 DESCRIPTION OF THE APPLIANCE ............................................................. 10
2.1 Dimensions ...................................................................................................................11
3 USING THE APPLIANCE ................................................................................12
3.1 Information about New Generation Cooling Technology ..............................................12
3.2 Display and Control Panel ............................................................................................12
3.3 Operating Your Fridge Freezer .....................................................................................13
3.3.1 Super Freeze Mode ...................................................................................................13
3.3.2 Super Cool Mode ......................................................................................................13
3.3.3 Economy Mode..........................................................................................................13
3.3.4 Holiday Mode.............................................................................................................14
3.3.5 Drink Cool Mode ........................................................................................................14
3.3.6 Screen Saver Mode ...................................................................................................14
3.3.7 The Child Lock Function ............................................................................................15
3.4 Temperature Settings ...................................................................................................15
3.4.1 Freezer Temperature Settings ...................................................................................15
3.4.2 Cooler Temperature Settings .....................................................................................16
3.4.3 Door Open Alarm Function ........................................................................................16
3.5 Temperature Adjustment Warnings...............................................................................16
3.6 Accessories ..................................................................................................................17
3.6.1 The Icematic ..............................................................................................................17
3.6.2 The Chiller Shelf ........................................................................................................17
3.6.3 The Fresh Dial ...........................................................................................................18
3.6.4 Adjustable Door Shelf ................................................................................................18
4 FOOD STORAGE ............................................................................................19
4.1 Refrigerator Compartment ............................................................................................19
4.2 Freezer Compartment ..................................................................................................20
5 CLEANING AND MAINTENANCE ..................................................................23
6 SHIPMENT AND REPOSITIONING .................................................................24
6.1 Transportation and Changing Positioning ....................................................................24
6.2 Repositioning the Door .................................................................................................24
7 BEFORE CALLING AFTER-SALES SERVICE ............................................... 25
8 TIPS FOR SAVING ENERGY .......................................................................... 27
9 TECHNICAL DATA ..........................................................................................28
10 INFORMATION FOR TEST INSTITUTES ...................................................... 28
11 CUSTOMER CARE AND SERVICE ...............................................................29
EN - 3
1 SAFETY INSTRUCTIONS
1.1 General Safety Warnings
Read this user manual carefully.
WARNING: Keep ventilation openings, in the
appliance enclosure or in the built-in structure, clear of
obstruction.
WARNING: Do not use mechanical devices or
other means to accelerate the defrosting process,
other than those recommended by the manufacturer.
WARNING: Do not use electrical appliances inside
the food storage compartments of the appliance,
unless they are of the type recommended by the
manufacturer.
WARNING: Do not damage the refrigerant circuit.
WARNING: When positioning the appliance,
ensure the supply cord is not trapped or damaged.
WARNING: Do not locate multiple portable socket-
outlets or portable power supplies at the rear of the
appliance.
WARNING: In order to avoid any hazards resulting
from the instability of the appliance, it must be xed in
accordance with the instructions.
If your appliance uses R600a as a refrigerant (this
information will be provided on the label of the cooler)
you should take care during transportation and
installation to prevent the cooler elements from being
damaged. R600a is an environmentally friendly and
EN - 4
natural gas, but it is explosive. In the event of a leak
due to damage of the cooler elements, move your
fridge away from open ames or heat sources and
ventilate the room where the appliance is located for a
few minutes.
• While carrying and positioning the fridge, do not
damage the cooler gas circuit.
• Do not store explosive substances such as aerosol
cans with a ammable propellant in this appliance.
• This appliance is intended to be used in household
and domestic applications such as:
– staff kitchen areas in shops, ofces and other
working environments.
– farm houses and by clients in hotels, motels and
other residential type environments.
– bed and breakfast type environments;
– catering and similar non-retail applications.
• If the socket does not match the refrigerator plug,
it must be replaced by the manufacturer, a service
agent or similarly qualied persons in order to avoid
a hazard.
• A specially grounded plug has been connected
to the power cable of your refrigerator. This plug
should be used with a specially grounded socket
of 16 amperes. If there is no such socket in your
house, please have one installed by an authorised
electrician.
EN - 5
• This appliance can be used by children aged from
8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
supervision or instruction concerning use of the
appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made
by children without supervision.
• Children aged from 3 to 8 years are allowed to load
and unload refrigerating appliances. Children are not
expected to perform cleaning or user maintenance
of the appliance, very young children (0-3 years old)
are not expected to use appliances, young children
(3-8 years old) are not expected to use appliances
safely unless continuous supervision is given, older
children (8-14 years old) and vulnerable people can
use appliances safely after they have been given
appropriate supervision or instruction concerning
use of the appliance. Very vulnerable people are
not expected to use appliances safely unless
continuous supervision is given.
• If the supply cord is damaged, it must be replaced
by the manufacturer, an authorised service agent or
similar qualied persons, in order to avoid a hazard.
• This appliance is not intended for use at altitudes
exceeding 2000 m.
EN - 6
To avoid contamination of food, please respect the
following instructions:
• Opening the door for long periods can cause
a signicant increase of the temperature in the
compartments of the appliance.
• Clean regularly surfaces that can come in contact
with food and accessible drainage systems
• Store raw meat and sh in suitable containers in the
refrigerator, so that it is not in contact with or drip
onto other food.
• Two-star frozen-food compartments are suitable for
storing pre-frozen food, storing or making ice cream
and making ice cubes.
• One-, two- and three-star compartments are not
suitable for the freezing of fresh food.
• If the refrigerating appliance is left empty for long
periods, switch off, defrost, clean, dry, and leave the
door open to prevent mould developing within the
appliance.
EN - 7
1.2 Installation warnings
Before using your fridge freezer for the rst
time, please pay attention to the following
points:
• The operating voltage for your fridge
freezer is 220-240 V at 50Hz.
• The plug must be accessible after
installation.
• Your fridge freezer may have an odour
when it is operated for the rst time. This
is normal and the odour will fade when
your fridge freezer starts to cool.
• Before connecting your fridge freezer,
ensure that the information on the data
plate (voltage and connected load)
matches that of the mains electricity
supply. If in doubt, consult a qualied
electrician.
• Insert the plug into a socket with an
efcient ground connection. If the socket
has no ground contact or the plug does
not match, we recommend you consult a
qualied electrician for assistance.
• The appliance must be connected
with a properly installed fused socket.
The power supply (AC) and voltage at
the operating point must match with
the details on the name plate of the
appliance (the name plate is located on
the inside left of the appliance).
• We do not accept responsibility for any
damages that occur due to ungrounded
usage.
• Place your fridge freezer where it will not
be exposed to direct sunlight.
• Your fridge freezer must never be used
outdoors or exposed to rain.
• Your appliance must be at least 50 cm
away from stoves, gas ovens and heater
cores, and at least 5 cm away from
electrical ovens.
• If your fridge freezer is placed next to a
deep freezer, there must be at least 2
cm between them to prevent humidity
forming on the outer surface.
• Do not cover the body or top of fridge
freezer with lace. This will affect the
performance of your fridge freezer.
• Clearance of at least 150 mm is required
at the top of your appliance. Do not place
anything on top of your appliance.
• Do not place heavy items on the
appliance.
• Clean the appliance thoroughly before
use (see Cleaning and Maintenance).
• Before using your fridge freezer, wipe all
parts with a solution of warm water and
a teaspoon of sodium bicarbonate. Then,
rinse with clean water and dry. Return all
parts to the fridge freezer after cleaning.
• Use the adjustable front legs to make
sure your appliance is level and stable.
You can adjust the legs by turning them
in either direction. This must be done
before placing food in the appliance.
• When the product is running, high
temperature can be noticed on the side
panels. This situation is normal.
• In order for the product to work efciently,
there must be some gap around it for
air circulation. If you are going to place
the product in a recessed area on the
wall, make sure that the gap should be
100 mm between top surface and ceiling,
50 mm between walls and side panels.
EN - 8
100mm
50mm
50mm
• The distance between the appliance and
back wall must be a maximum of 75 mm.
1.3 During Usage
• Do not connect your fridge freezer to
the mains electricity supply using an
extension lead.
• Do not use damaged, torn or old plugs.
• Do not pull, bend or damage the cord.
• Do not use plug adapter.
• This appliance is designed for use by
adults. Do not allow children to play with
the appliance or hang off the door.
• Never touch the power cord/plug with wet
hands. This may cause a short circuit or
electric shock.
• Do not place glass bottles or cans in the
ice-making compartment as they will
burst when the contents freeze.
• Do not place explosive or ammable
material in your fridge. Place drinks with
high alcohol content vertically in the
fridge compartment and make sure their
tops are tightly closed.
• When removing ice from the ice-making
compartment, do not touch it. Ice may
cause frost burns and/or cuts.
• Do not touch frozen goods with wet
hands. Do not eat ice-cream or ice cubes
immediately after they are removed from
the ice-making compartment.
• Do not re-freeze thawed frozen food. This
may cause health issues such as food
poisoning.
Old and Out-of-order Fridges
• If your old fridge or freezer has a
lock, break or remove the lock before
discarding it, because children may
get trapped inside it and may cause an
accident.
• Old fridges and freezers contain
isolation material and refrigerant with
CFC. Therefore, take care not to harm
environment when you are discarding
your old fridges.
CE Declaration of conformity
We declare that our products meet the
applicable European Directives, Decisions
and Regulations and the requirements
listed in the standards referenced.
Disposal of your old appliance
The symbol on the product or on
its packaging indicates that this
product may not be treated as
household waste. Instead it shall
be handed over to the applicable
collection point for the recycling of electrical
and electronic equipment. By ensuring
this product is disposed of correctly,
you will help prevent potential negative
consequences for the environment and
human health, which could otherwise be
caused by inappropriate waste handling
of this product. For more detailed
information about recycling of this product,
please contact your local city ofce, your
household waste disposal service or the
shop where you purchased the product.
EN - 9
Packaging and the Environment
Packaging materials protect
your machine from damage that
may occur during transportation.
The packaging materials are
environmentally friendly as they are
recyclable. The use of recycled material
reduces raw material consumption and
therefore decreases waste production.
Notes:
• Please read the instruction manual
carefully before installing and using your
appliance. We are not responsible for the
damage occurred due to misuse.
• Follow all instructions on your appliance
and instruction manual, and keep this
manual in a safe place to resolve the
problems that may occur in the future.
• This appliance is produced to be used
in homes and it can only be used in
domestic environments and for the
specied purposes. It is not suitable for
commercial or common use. Such use
will cause the guarantee of the appliance
to be cancelled and our company will not
be responsible for any losses incurred.
• This appliance is produced to be used
in houses and it is only suitable for
cooling / storing foods. It is not suitable
for commercial or common use and/or
for storing substances except for food.
Our company is not responsible for any
losses incurred by inappropriate usage of
the appliance.
General notes:
Fresh Food Compartment (Fridge): Most
efcient use of energy is ensured in the
conguration with the drawers in the bottom
part of the appliance, and shelves evenly
distributed, position of door bins does not
affect energy consumption.
Freezer Compartment (Freezer): Most
Efcient use of energy is ensured in the
conguration with the drawers and bins are
on stock position.
2 DESCRIPTION OF THE
APPLIANCE
This appliance is not intended to be used
as a built-in appliance.
1
2
3
4
5
6
7
8
9
This presentation is only for
information about the parts of the
appliance. Parts may vary according to the
appliance model.
A) Freezer compartment
B) Refrigerator compartment
1) Freezer shelf
2) Icemaker *
3) Turbo fan *
4) Wine rack *
5) Refrigerator shelves
6) Chiller *
7) Crisper cover
8) Crispers
9) Levelling feet
10) Door bottom shelf *
11) Bottle shelf
12) Adjustable door shelf * / door shelf
13) Door shelf
14) Freezer door shelves *
15) Ice box tray *
16) Egg holder
* In some models
A
B
14
15
13
16
12
11
10
EN - 10
2.1 Dimensions
H1
H2
Overall dimensions
1
H1 mm 1830
W1 mm 700
D1 mm 772,3
Space required in use
2
H2 mm 1980
W2 mm 800
D2 mm 812,3
D2
W2
D1
W1
D3
W3
Overall space required in use
3
W3 mm 1137,3
D3 mm 1390,3
EN - 11
3 USING THE APPLIANCE
3.2 Display and Control Panel
3.1 Information about New Generation
Cooling Technology
Fridges with new-generation cooling
technology have a
different operating
system to static
fridges. Other (static)
fridges may
experience a build up
of ice in the freezer
compartment due to
door openings and
humidity in the food.
In such fridges,
regular defrosting is
required; the fridge
must be switched off,
the frozen food moved
to a suitable container
and the ice which has
formed in the freezer
compartment
removed.
In fridges with new-generation cooling
technology, a fan blows dry cold air
evenly throughout the fridge and freezer
compartments. The cold air cools your food
evenly and uniformly, preventing humidity
and ice build-up.
In the refrigerator compartment, air
blown by the fan, located at the top of
the refrigerator compartment, is cooled
while passing through the gap behind
the air duct. At the same time, the air is
blown out through the holes in the air duct,
evenly spreading cool air throughout the
refrigerator compartment.
There is no air passage between the
freezer and refrigerator compartments,
therefore preventing the mixing of odours.
As a result, your fridge, with newgeneration cooling technology, provides
you with ease of use as well as a huge
volume and aesthetic appearance.
1
2
3
4
5
7
6
8
9
10
11
Using the Control Panel
1. It is super freeze indicator.
2. It is freezer set value screen.
3. It is super cooling indicator.
4. It is cooler set value screen.
5. It is alarm symbol.
6. It is child-lock symbol.
7. It is holiday mode symbol.
8. It is economy mode symbol.
9. It enables the setting value of freezer
to be modied and super freeze mode
to be activated if desired. Freezer may
be set to -16, -18, -20, -22, -24 °C super
freeze.
10. It enables the setting value of cooler to
be modied and super cool mode to be
activated if desired. Cooler maybe set
to 8, 6, 5, 4, 2 °C super cool.
11. It enables the modes (economy,
holiday…) to be activated if desired.
EN - 12
3.3 Operating Your Fridge Freezer
Lighting (If available)
When the product is plugged in for the
rst time, the interior lights may turn on 1
minute late due to opening tests.
3.3.1 Super Freeze Mode
Purpose
• To freeze a large quantity of food that
cannot t on the fast freeze shelf.
• To freeze prepared foods.
• To freeze fresh food quickly to retain
freshness.
How Would It Be Used?
Press freezer set button
until Super freeze symbol
will be seen on the
screen. Buzzer will sound
beep beep. Mode will be
set.
During This Mode:
• Temperature of cooler
and super cool mode
may be adjusted. In
this case super freeze
mode continues.
• Economy and Holiday
mode can not be selected.
• Super freeze mode can be cancelled by
the same operation of selecting.
Notes:
• The maximum amount of fresh food (in
kilograms) that can be frozen within 24
hours is shown on the appliance label.
• For optimal appliance performance in
maximum freezer capacity, activate SF
mode 3 hours before you put fresh food
into the freezer.
• At the end of this period, the fridge will
sound an audible alarm notifying that it is
ready.
Super freeze mode will automatically
cancel after 24 hours, depending on
the environmental temperature or when the
freezer sensor reaches a sufciently low
temperature.
3.3.2 Super Cool Mode
Purpose
• To cool and store a large quantity of food
in the fridge compartment.
• To quickly cool drinks.
How Would It Be Used?
Press cooler set button
until super cool symbol
will be seen on the
screen. Buzzer will sound
beep beep. Mode will be
set.
During This Mode:
• Temperature of freezer
and super freeze mode
may be adjusted. In
this case super cool
mode continues.
• Economy and holiday
mode can not be
selected.
• Super cool mode can be cancelled by the
same operation of selecting.
3.3.3 Economy Mode
Purpose
Energy savings. During periods of less
frequent use (door opening) or absence
from home, such as a holiday, Eco program
can provide optimum temperature whilst
saving power.
How Would It Be Used?
• Push "MODE" button
until eco symbol
appears.
• If no button is pressed
for 1 second. Mode will
be set. Eco symbol will
blink 3 times. When
mode is set, buzzer will
sound beep beep.
• Freezer and refrigerator
temperature segments
will show "E".
• Economy symbol and
E will light till mode
nishes.
EN - 13
During This Mode:
• Freezer may be adjusted. When
economy mode will be cancelled, the
selected setting values will proceed.
• Cooler may be adjusted. When economy
mode will be cancelled, the selected
setting values will proceed.
• Super cool and super freeze modes
can be selected. Economy mode is
automatically cancelled and the selected
mode is activated.
• Holiday mode can be selected after
cancelling the economy mode. Then the
selected mode is activated.
• To cancel, you will just need to press on
mode button.
3.3.4 Holiday Mode
How Would It Be Used?
• Push "MODE" button
until holiday symbol
appears
• If no button is pressed
for 1 second. Mode will
be set. Holiday symbol
will blink 3 times. When
mode is set, buzzer will
sound beep beep.
• Cooler temperature
segment will show "--".
• Holiday symbol and
"--" will light till mode
nishes.
During This Mode:
• Freezer may be adjusted. When holiday
mode will be cancelled, the selected
setting values will proceed.
• Cooler may be adjusted. When holiday
mode will be cancelled, the selected
setting values will proceed.
• Super cool and super freeze modes
can be selected. Holiday mode is
automatically cancelled and the selected
mode is activated.
• Economy mode can be selected after
cancelling the holiday mode. Then the
selected mode is activated.
• To cancel, you will just need to press on
mode button.
3.3.5 Drink Cool Mode
Purpose
This mode is used to cool drinks within an
adjustable time frame.
How Would It Be Used?
• Press freezer button for 3 seconds.
• Special animation will
start on freezer set
value screen and 05
will blink on cooler set
value screen.
• Press cooler button to
adjust the time (05 10 - 15 - 20 - 25 - 30
minutes).
• When you select the
time the numbers will
blink 3 times on screen
and sound beep beep.
• If no button is pressed
within 2 seconds the time will be set.
• The countdown starts from the adjusted
time minute by minute.
• Remaining time will blink on the screen.
• To cancel this mode press freezer set
button for 3 seconds.
3.3.6 Screen Saver Mode
Purpose
This mode saves energy by switching off all
control panel lighting when the panel is left
inactive.
How to Use?
• Screen saver mode
will be activated
automatically after 30
seconds.
• If you press any key
while the lighting of
the control panel is off,
the current machine
settings will reappear
on the display to let you
make any change you
wish.
• If you do not cancel the
screen saving mode or
press any key for 30
EN - 14
seconds, control panel will remain off.
To deactivate the screen saving mode,
• To cancel the screen saving mode, rst of
all, you need to press any key to activate
the keys and then press and hold the
Mode button for 3 seconds.
• To reactivate screen saving mode, press
and hold the mode button for 3 seconds.
Notes:
• When screen saver mode is active you
can also activate child lock.
• If no button is pressed within 5 seconds
after child lock is activated, the lights of
the control panel will turn off. You can see
latest status of settings or modes after
you pres any button. While control panel
‘s light is on, you can cancel child lock as
described in the instruction of this mode.
3.3.7 The Child Lock Function
Purpose
Child lock can be activated to prevent any
accidental or unintentional changes being
made to the appliance settings.
Activating Child Lock
Press on
freezer and
cooler buttons
simultaneously for
5 seconds.
Deactivating
Child Lock
Press on
freezer and
cooler buttons
simultaneously for
5 seconds.
Child lock
will also be
deactivated if electricity is interrupted or the
fridge is unplugged.
3.4 Temperature Settings
3.4.1 Freezer Temperature Settings
• The initial temperature value for the
freezer setting indicator is -18 °C.
• Press the set freezer
button once.
• When you rst push
this button, the last set
value will blink on the
screen.
• Whenever you press
this button, a lower
temperature will be set
(-16 °C, -18 °C, -20 °C,
-22 °C, -24 °C, super
freeze).
• When you push the
set freezer button until the super freeze
symbol appears, and if you do not push
any other button within 1 second, super
freeze will ash.
• If you continue to press it, it will restart
from -16 °C.
• The temperature value selected before
holiday mode, super freeze mode,
super cool mode or economy mode
is activated and will remain the same
when the mode is over or cancelled. The
appliance continues to operate with this
temperature value.
EN - 15
3.4.2 Cooler Temperature Settings
• Initial temperature value for the cooler
setting indicator is +4 °C.
• Press the cooler button
once.
• When you rst push
this button, the last
value will appear
on the cooler setting
indicator.
• Whenever you press
this button, a lower
temperature will be set.
(+8 °C, +6 °C, +5 °C,
+4 °C, +2 °C, super
cool)
• When you push the
cooler set button until the super cool
symbol appears, and if you do not push
any button within 1 second, super cool
will ash.
• If you continue to press the button, it will
restart from +8 °C.
• The temperature value selected before
holiday mode, super freeze mode,
super cool mode or economy mode
is activated and will remain the same
when the mode is over or cancelled. The
appliance continues to operate with this
temperature value.
Recommended Settings for the Freezer
and Cooler Compartment Temperature
Freezer
Compartment
-18 oC 4 oC
-20 oC, -22 oC
or -24 oC
Super Freeze 4 oC
Cooler
Compartment
4 oC
Remarks
For regular
use and best
performance.
Recommended
when
environmental
temperature
exceeds 30 °C.
Must be used
when you wish
to freeze food in
a short period of
time.
Freezer
Compartment
-18 oC, -20 oC,
-22 oC or
-24 oC
-18 oC, -20 oC,
-22 oC or
-24 oC
Cooler
Compartment
2 oC
Super Cool
These
temperature
settings must be
used when the
environmental
temperature is
high or if you think
the refrigerator
compartment is
not cool enough
becuse the door
is being opened
frequently.
Must be used
when the
refrigerator
compartment is
overloaded with
food or when
food needs to be
cooled quickly.
3.4.3 Door Open Alarm Function
If fridge door is opened more than 2
minutes, appliance sounds ‘beep beep’.
3.5 Temperature Adjustment Warnings
• It is not recommended that you operate
your fridge in environments colder than
10°C in terms of its efciency.
• Do not start another adjustment while you
are already making an adjustment.
• Temperature adjustments should be
made according to the frequency of door
openings, the quantity of food kept inside
the fridge and the ambient temperature in
the location of your fridge.
• In order to allow your fridge to reach
the operating temperature after being
connected to mains, do not open the
doors frequently or place large quantities
of food in the fridge. Please note that,
depending on the ambient temperature,
it may take 24 hours for your fridge to
reach the operating temperature.
• A 5 minute delay function is applied
to prevent damage to the compressor
of your fridge when connecting or
disconnecting to mains, or when an
energy breakdown occurs. Your fridge
will begin to operate normally after 5
minutes.
EN - 16
Remarks
• Your appliance is designed to operate in
the ambient temperature (T/SN = 10°C
- 43°C) intervals stated in the standards,
according to the climate class displayed
on the information label. We do not
recommend operating your appliance out
of the stated temperature limits in terms
of cooling effectiveness.
Climate class and meaning:
T (tropical): This refrigerating appliance
is intended to be used at ambient
temperatures ranging from 16 °C to 43 °C.
ST (subtropical): This refrigerating
appliance is intended to be used at ambient
temperatures ranging from 16 °C to 38 °C.
N (temperate): This refrigerating appliance
is intended to be used at ambient
temperatures ranging from 16 °C to 32 °C.
SN (extended temperate): This
refrigerating appliance is intended to be
used at ambient temperatures ranging from
10 °C to 32 °C.
3.6 Accessories
Visual and text descriptions in the
accessories section may vary according
to the model of your appliance.
3.6.1 The Icematic
• Pull the lever towards you and remove
the ice maker tray
• Fill with water to the marked level
• Hold the left end of the lever and set the
ice-tray on the icebox
• When ice cubes have formed, twist
the lever to drop the ice cubes into the
icebox.
Note:
Do not ll the icebox with water in
order to make ice. It can be broken.
The movement of the ice maker may
be difcult while the refrigerator is
running. In such a case should be cleaned
by removing the glass shelves.
Removing the icemaker
• Take out of the freezer glass shelves
• Remove the icemaker by dragging left or
right on the shelf.
You can remove the icemaker to use a
larger volume of the freezer compartment.
3.6.2 The Chiller Shelf
Chiller shelf
Keeping food in the Chiller compartment,
instead of the freezer or refrigerator
compartments, allows food to retain
freshness and avour for longer, while
preserving its fresh appearance. When the
Chiller tray becomes dirty, remove it and
wash with water.
(Water freezes at 0°C, but food containing
salt or sugar freezes at temperatures lower
than this).
The Chiller compartment is usually used
for storing foods such as raw sh, lightly
pickled food, rice, and so on.
Do not put food you want to freeze
or ice trays (to make ice) in the
Chiller compartment.
EN - 17
To remove the Chiller Shelf:
• Pull the chiller shelf towards you by
sliding it on the rails.
• Pull the chiller shelf up from the rail and
remove it from the fridge.
After the chiller shelf is removed, there
will be space for up to 20kg of food to
be placed in the fridge.
3.6.3 The Fresh Dial
Fresh dial
If the crisper is full, the fresh dial located
in front of the crisper should be opened.
This allows the air in the crisper and the
humidity rate to be controlled, to increase
the life of food within.
The dial, located behind the shelf, must be
opened if any condensation is seen on the
glass shelf.
3.6.4 Adjustable Door Shelf
Six different height adjustments can be
made to provide storage areas that you
need by adjustable door shelf.
To change the position of adjustable door
shelf ;
Hold the bottom of the shelf and pull the
buttons on the side of
the door shelf
direction of arrow.
(Fig.1)
Position door shelf
the height you need
by moving up and
down. After you get
Fig. 1
the position that you
want the door shelf,
release the buttons on
the side of the door
shelf (Fig.2) Before
releasing the door
shelf, move up down
and make sure the
Fig. 2
door shelf is xed.
Note: Before moving door shelf is
loaded, you must hold the shelf by
supporting the bottom. Otherwise, door
shelf could fall off the rails due to the
weight. So damage may occur on the door
shelf or rails.
EN - 18
4 FOOD STORAGE
4.1 Refrigerator Compartment
For normal operating conditions, set the
temperature of the cooler compartment to
+4 or +6 oC.
• To reduce humidity and avoid the
consequent formation of frost, always
store liquids in sealed containers in the
refrigerator. Frost tends to concentrate in
the coldest parts of the evaporating liquid
and, in time, your appliance will require
more frequent defrosting.
• Never place warm food in the
refrigerator. Warm food should be
allowed to cool at room temperature
and should be arranged to ensure
adequate air circulation in the refrigerator
compartment.
• Make sure no items are in direct contact
with the rear wall of the appliance as
frost will develop and packaging will stick
to it. Do not open the refrigerator door
frequently.
• We recommend that meat and clean sh
are loosely wrapped and stored on the
glass shelf just above the vegetable bin
where the air is cooler, as this provides
the best storage conditions.
• Store loose fruit and vegetable items in
the crisper containers.
• Store loose fruit and vegetables in the
crisper.
• Storing fruit and vegetables separately
helps prevent ethylene-sensitive
vegetables (green leaves, broccoli,
carrot, etc.) being affected by ethylenereleaser fruits (banana, peach, apricot,
g etc.).
• Do not put wet vegetables into the
refrigerator.
• Storage time for all food products
depends on the initial quality of the food
and an uninterrupted refrigeration cycle
before refrigerator storage.
• To avoid cross-contamination do not
store meat products with fruit and
vegetables. Water leaking from meat
may contaminate other products in the
refrigerator. You should package meat
products and clean any leakages on the
shelves.
• Do not put food in front of the air ow
passage.
• Consume packaged foods before the
recommended expiry date.
NOTE: Potatoes, onions and garlic
should not be stored in the refrigerator.
• For normal working conditions, it will
be sufcient to adjust the temperature
setting of your refrigerator to +4 °C.
• The temperature of the fridge
compartment should be in the range
of 0-8 °C, fresh foods below 0 °C are
iced and rotted, bacterial load increases
above 8 °C, and spoils.
• Do not put hot food in the refrigerator
immediately, wait for the temperature
to pass outside. Hot foods increase the
degree of your refrigerator and cause
food poisoning and unnecessary spoiling
of the food.
• Meat, sh, etc. should be store in the
chiller compartment of the food, and the
vegetable compartment is preferred for
vegetables. (if available)
• To prevent cross contamination, meat
products and fruit vegetables are not
stored together.
• Foods should be placed in the refrigerator
in closed containers or covered to
prevent moisture and odors.
IMPORTANT NOTES:
Potatoes, onions and garlic should not
be stored in the refrigerator.
Cooked dishes must remain covered
when they are kept in the fridge. Place
them in the fridge when they are cool,
otherwise the temperature/humidity inside
the fridge will increases, reducing the
fridge’s efciency. Covering food and drink
also preserves their avour and aroma.
EN - 19
Do not allow food to come into contact
with the temperature sensor, which is
located in the refrigerator compartment, in
order to keep the refrigerator compartment
at optimum temperature.
Temperature sensor area
The table below is a quick guide to show
you the most efcient way to store the
major food groups in your refrigerator
compartment.
Food
Vegetables
and fruits
Meat and
sh
Fresh
cheese
Butter and
margarine
Bottled
products
e.g. milk
and
yoghurt
Eggs 1 month
Cooked
food
Maximum
storage time
1 week Vegetable bin
2 - 3 days
3 - 4 days
1 week
Until the
expiry date
recommended
by the
producer
2 days All shelves
How and where to
store
Wrap in plastic foil,
bags, or in a meat
container and store
on the glass shelf
On the designated
door shelf
On the designated
door shelf
On the designated
door shelf
On the designated
egg shelf
4.2 Freezer Compartment
For normal operating conditions, set the
temperature of the freezer compartment to
-18 or -20 oC.
• The freezer is used for storing frozen
food, freezing fresh food, and making ice
cubes.
• For freezing fresh food; wrap and seal
fresh food properly, that is the packaging
should be air tight and shouldn’t leak.
Special freezer bags, aluminum foil
polythene bags and plastic containers
are ideal.
• Do not store fresh food next to frozen
food as it can thaw the frozen food.
• Before freezing fresh food, divide it into
portions that can be consumed in one
sitting.
• Consume thawed frozen food within a
short period of time after defrosting
• Never place warm food in the freezer
compartment as it will thaw the frozen
food.
• Always follow the manufacturer's
instructions on food packaging when
storing frozen food. If no information is
provided food, should not be stored for
more than 3 months from the date of
purchase.
• When purchasing frozen food, make sure
that it has been stored under appropriate
conditions and that the packaging is not
damaged.
• Frozen food should be transported in
appropriate containers and placed in the
freezer as soon as possible.
• Do not purchase frozen food if the
packaging shows signs of humidity
and abnormal swelling. It is probable
that it has been stored at an unsuitable
temperature and that the contents have
deteriorated.
• The storage life of frozen food depends
on the room temperature, the thermostat
setting, how often the door is opened,
the type of food, and the length of time
required to transport the product from
the shop to your home. Always follow the
instructions printed on the packaging and
never exceed the maximum storage life
indicated.
• The maximum amount of fresh food (in
kg) that can be frozen in 24 hours is
indicated on the appliance label.
EN - 20
• To freeze fresh food, ensure that as much
of the surface of the food as possible is in
contact with the cooling surface.
In some models: While loading the freezer
compartment, do not ll
above the guidelines
otherwise the door will not
close properly. If the
freezer compartment door
does not close properly,
excess ice will form in the
freezer compartment. To
prevent the problem recurring, clear the ice
and make sure the door is fully closed.
Also, not closing the freezer and/or fridge
compartment doors will increase your
energy consumption.
If the lower shelf of the freezer door is
removed and food obstructs the air suction
hole, the efciency of your fridge will
reduce.
Therefore, take care while loading the
freezer compartment and make sure not to
cover the air suction hole.
Important note:
• Never refreeze thawed frozen food.
• The taste of some spices found in cooked
dishes (anise, basilica, watercress,
vinegar, assorted spices, ginger, garlic,
onion, mustard, thyme, marjoram, black
pepper, etc.) changes and they assume
a strong taste when they are stored for a
long period of time. Therefore, add small
amounts of spices to food to be frozen, or
the desired spice should be added after
the food has thawed.
• The storage time of food is dependent
on the type of oil used. Suitable oils are
margarine, calf fat, olive oil and butter.
Unsuitable oils are peanut oil and pig fat.
• Food in liquid form should be frozen in
plastic cups and other food should be
frozen in plastic folios or bags.
Air suction hole
NOTE: If you attempt to open the freezer
door immediately after closing it, you
will nd that it will not open easily. This
is normal. Once equilibrium has been
reached, the door will open easily.
EN - 21
The table below is a quick guide to show you the most efcient way to store the major
food groups in your freezer compartment.
Meat and sh Preparation
Steak Wrap in foil 6 - 8
Lamb meat Wrap in foil 6 - 8
Veal roast Wrap in foil 6 - 8
Veal cubes In small pieces 6 - 8
Lamb cubes In pieces 4 - 8
Minced meat In packaging without using spices 1 - 3
Giblets (pieces) In pieces 1 - 3
Bologna sausage/salami Should be kept packaged even if it has a membrane
Chicken and turkey Wrap in foil 4 - 6
Goose and duck Wrap in foil 4 - 6
Deer, rabbit, wild boar In 2.5 kg portions or as llets 6 - 8
Freshwater sh
(Salmon, Carp, Crane,
Catsh)
Lean sh (Bass, Turbot,
Flounder)
Fatty shes (Tuna,
Mackerel, Bluesh,
Anchovy)
Shellsh Clean and in a bag 4 - 6
Caviar
Snails In salty water, or in an aluminium or plastic container 3
NOTE: Thawed frozen meat should be cooked as fresh meat. If the meat is not cooked after defrosting, it
must not be re-frozen.
After cleaning the bowels and scales of the sh,
wash and dry it. If necessary, remove the tail and
head.
In its packaging, or in an aluminium or plastic
container
Maximum storage time
(months)
2
4
2 - 4
2 - 3
Vegetables and Fruits Preparation
String beans and beans Wash, cut into small pieces and boil in water 10 - 13
Beans Hull, wash and boil in water 12
Cabbage Clean and boil in water 6 - 8
Carrot Clean, cut into slices and boil in water 12
Pepper
Spinach Wash and boil in water 6 - 9
Cauliower
Eggplant Cut into pieces of 2cm after washing 10 - 12
Corn Clean and pack with its stem or as sweet corn 12
Apple and pear Peel and slice 8 - 10
Apricot and Peach Cut into two pieces and remove the stone 4 - 6
Cut the stem, cut into two pieces, remove the core
and boil in water
Remove the leaves, cut the heart into pieces and
leave it in water with a little lemon juice for a while
Maximum storage time
(months)
8 - 10
10 - 12
EN - 22
Vegetables and Fruits Preparation
Strawberry and
Blackberry
Cooked fruits Add 10 % of sugar to the container 12
Plum, cherry, sourberry Wash and hull the stems 8 - 12
Wash and hull 8 - 12
Maximum storage time
(months)
Maximum storage time
(months)
Bread 4 - 6 2 - 3 4-5 (220-225 °C)
Biscuits 3 - 6 1 - 1,5 5-8 (190-200 °C)
Pastry 1 - 3 2 - 3 5-10 (200-225 °C)
Pie 1 - 1,5 3 - 4 5-8 (190-200 °C)
Phyllo dough 2 - 3 1 - 1,5 5-8 (190-200 °C)
Pizza 2 - 3 2 - 4 15-20 (200 °C)
Dairy products Preparation
Packet (Homogenized)
Milk
Cheese - excluding
white cheese
Butter, margarine In its packaging 6
In its own packet 2 - 3 Pure Milk – in its own packet
In slices 6 - 8
5 CLEANING AND
MAINTENANCE
Disconnect the unit from the power
supply before cleaning.
Do not wash your appliance by
pouring water on it.
Do not use abrasive products,
detergents or soaps for cleaning the
Thawing time at room
temperature (hours)
Maximum storage time
(months)
Thawing time in oven
(minutes)
Storage conditions
Original packaging may be
used for short-term storage.
Keep wrapped in foil for
longer periods.
• Clean the condenser with a brush at least
twice a year. This will help you to save on
energy costs and increase productivity.
The power supply must be
disconnected during cleaning.
Replacing LED Lighting
If your appliance has LED lighting
contact the help desk as this should
be changed by authorized personnel only.
appliance. After washing, rinse with clean
water and dry carefully. When you have
nished cleaning, reconnect the plug to the
mains supply with dry hands.
• Make sure that no water enters the lamp
housing and other electrical components.
• The appliance should be cleaned
regularly using a solution of bicarbonate
of soda and lukewarm water.
• Clean the accessories separately by
hand with soap and water. Do not wash
accessories in a dish washer.
EN - 23
6 SHIPMENT AND
REPOSITIONING
6.1 Transportation and Changing
Positioning
• The original packaging and foam may be
kept for re-transportation (optional).
• Fasten your appliance with thick
packaging, bands or strong cords and
follow the instructions for transportation
on the packaging.
• Remove all movable parts (shelves,
accessories, vegetable bins, and so on)
or x them into the appliance against
shocks using bands when re-positioning
or transporting.
Always carry your appliance in the
upright position.
6.2 Repositioning the Door
• It is not possible to change the opening
direction of your appliance door if door
handles are installed on the front surface
of the appliance door.
• It is possible to change the opening
direction of the door on models without
handles.
• If the door-opening direction of your
appliance can be changed, contact the
nearest Authorised Service Centre to
change the opening direction.
EN - 24
7 BEFORE CALLING AFTER-SALES SERVICE
Errors
Your fridge will warn you if the temperatures for the cooler and freezer are at improper levels
or if a problem occurs with the appliance. Warning codes are displayed in the freezer and
cooler indicators.
ERROR TYPE MEANING WHY WHAT TO DO
E01 Sensor warning
E02 Sensor warning
E03 Sensor warning
E06 Sensor warning
E07 Sensor warning
E08 Low Voltage Warning
E09
Freezer compartment
is not cold enough
Power supply to the device
has dropped to below
170 V.
Likely to occur after long
term power failure.
Call Service for assistance as
soon as possible.
Call Service for assistance as
soon as possible.
Call Service for assistance as
soon as possible.
Call Service for assistance as
soon as possible.
Call Service for assistance as
soon as possible.
- This is not a device failure, this
error helps to prevent damages
to the compressor.
- The voltage needs to be
increased back to required
levels
If this warning continues an
authorised technician needs to be
contacted.
1. Set the freezer temperature
to a colder value or set Super
Freeze. This should remove
the error code once the
required temperature has been
reached. Keep doors closed
to improve time taken to reach
the correct temperature.
2. Remove any products which
have thawed/defrosted during
this error. They can be used
within a short period of time.
3. Do not add any fresh produce
to the freezer compartment
until the correct temperature
has been reached and the
error is no longer.
If this warning continues an
authorised technician needs to be
contacted.
EN - 25
ERROR TYPE MEANING WHY WHAT TO DO
1. Set the fridge temperature to
a colder value or set Super
Cool. This should remove the
error code once the required
temperature has been reached.
Keep doors closed to improve
time taken to reach the correct
temperature.
2. Please empty the location
at the front area of air duct
channel holes and avoid
putting food close to the
sensor.
If this warning continues an
authorised technician needs to be
contacted.
1. Check is Super Cool mode is
activated
2. Reduce the fridge
compartment temperature
3. Check to see if vents are clear
and not clogged
If this warning continues an
authorised technician needs to be
contacted.
E10
E11
Fridge compartment is
not cold enough
Fridge compartment is
too cold
Likely to occur after:
- Long term power failure.
- Hot food has been left in
the fridge.
Various
If you are experiencing a problem with your
refrigerator, please check the following
before contacting the after-sales service.
Your refrigerator does not operate
Check if:
• Your fridge is plugged in and switched on
• The fuse has blown
• Is the temperature adjustment right?
• The socket is faulty. To check this, plug
another working appliance into the same
socket.
Your refrigerator is performing poorly
Check if:
• The appliance is overloaded
• The doors are closed properly
• There is any dust on the condenser
• There is an adequate distance between
the appliance and surrounding walls
Your refrigerator is operating noisily
The following noises can be heard during
normal operation of the appliance.
Cracking (ice cracking) noise occurs:
• During automatic defrosting.
• When the appliance is cooled
or warmed (due to expansion of
appliance material).
EN - 26
Clicking noise occurs: When the
thermostat switches the compressor on/
off.
Motor noise: Indicates the compressor
is operating normally. The compressor
may cause more noise for a short time
when it is rst activated.
Bubbling noise and splashing
occurs: Due to the ow of the
refrigerant in the tubes of the system.
Water owing noise occurs: Due
to water owing to the evaporation
container. This noise is normal during
defrosting.
Air blowing noise occurs: During
normal operation of the system due to
the circulation of air.
There is a build-up of humidity inside
the fridge
Check if:
• All food is packed properly. Containers
must be dry before being placed in the
fridge.
• The fridge doors are opened frequently.
Humidity of the room will enter the
fridge each time the doors are opened.
Humidity increases faster if the doors
are opened frequently, especially if the
humidity of the room is high.
• There is a build-up of water droplets
on the rear wall. This is normal after
automatic defrosting (in Static Models).
The doors are not opening or closing
properly
Check if:
• There is food or packaging preventing the
door from closing
• The door compartments, shelves and
drawers are placed properly
• The door gaskets are broken or torn
• Your fridge is level.
The edges of the fridge in contact with
the door joint are warm
Especially during summer (warm weather),
the surfaces in contact with the door joint
may become warmer during operation of
the compressor. This is normal.
Important Notes:
• In the case of a power failure, or if the
appliance is unplugged and plugged in
again, the gas in the cooling system of
your refrigerator will destabilise, causing
the compressor protective thermal
element to open. Your refrigerator will
start to operate normally after 5 minutes.
• If the appliance will not be used for a long
period of time (such as during holidays),
disconnect the plug. Defrost and clean
the refrigerator, leaving the door open
to prevent the formation of mildew and
odour.
• If the problem persists after you have
followed all the instructions above,
please consult the nearest Authorised
Service Centre.
• This appliance is designed for domestic
use and for the stated purposes only. It is
not suitable for commercial or common
use. If the consumer uses the appliance
in a way that does not comply with these
instructions, we emphasise that the
manufacturer and the dealer will not be
responsible for any repair or failure within
the guarantee period.
8 TIPS FOR SAVING ENERGY
1. Install the appliance in a cool, wellventilated room, but not in direct sunlight
and not near a heat source (such as a
radiator or oven) otherwise an insulating
plate should be used.
2. Allow warm food and drinks to cool
before placing them inside the appliance.
3. Place thawing food in the refrigerator
compartment. The low temperature
of the frozen food will help cool the
refrigerator compartment while the food
is thawing. This will save energy. Frozen
food left to thaw outside of the appliance
will result in a waste of energy.
4. Drinks or other liquids should be
covered when inside the appliance. If
left uncovered, the humidity inside the
appliance will increase, therefore the
appliance uses more energy. Keeping
drinks and other liquids covered helps
preserve their smell and taste.
5. Avoid keeping the doors open for long
periods and opening the doors too
frequently as warm air will enter the
appliance and cause the compressor to
switch on unnecessarily often.
6. Keep the covers of the different
temperature compartments (such as the
crisper and chiller) closed.
7. The door gasket must be clean and
pliable. In case of wear, replace the
gasket.
EN - 27
9 TECHNICAL DATA
The technical information is situated in
the rating plate on the internal side of the
appliance and on the energy label.
The QR code on the energy label supplied
with the appliance provides a web link to
the information related to the performance
of the appliance in the EU EPREL
database.
Keep the energy label for reference
together with the user manual and all other
documents provided with this appliance.
It is also possible to nd the same
information in EPREL using the link https://
eprel.ec.europa.eu and the model name
and product number that you nd on the
rating plate of the appliance.
See the link www.theenergylabel.eu for
detailed information about the energy label.
10 INFORMATION FOR TEST
INSTITUTES
Appliance for any EcoDesign verication
shall be compliant with EN 62552.
Ventilation requirements, recess
dimensions and minimum rear clearances
shall be as stated in this User Manual at
Chapter 2. Please contact the manufacturer
for any other further information, including
loading plans.
EN - 28
11 CUSTOMER CARE AND
SERVICE
Always use original spare parts.
When contacting our Authorised Service
Centre, ensure that you have the following
data available: Model, Serial Number and
Service Index.
The information can be found on the rating
plate. You can nd the rating label inside
the fridge zone on the left lower side.
The original spare parts for some specic
components are available for a minimum
of 7 or 10 years, based on the type of
component, from the placing on the market
of the last unit of the model.
Visit our website to:
Get User manuals: https://www.smeg.com/info/download-manuals
Get Service information: https://www.smeg.com/services/customer-service
EN - 29
Loading...
