Smeg FC182PMNE, FC182PXNE User Manual

No-Frost Combi Refrigerator
Fridge - Freezer
User manual
No-Frost Kühl-/Gefrierkombination
Betriebsanleitung
Combine Froid Ventile
CongelateurRéfrigérateur -
Guide d’utilisation
Frigo - Congelatore
Istruzioni per l'uso
FC182PMNE FC182PXNE
Index
BEFORE USING THE APPLIANCE .................................3
General warnings...................................................................... 3
Old and out-of-order fridges...................................................... 5
Safety warnings ........................................................................ 5
Installing and operating your fridge........................................... 6
Before Using your Fridge .......................................................... 7
Information about New Generation Cooling Technology .......... 8
THE PARTS OF THE APPLIANCE AND THE
COMPARTMENTS ...........................................................9
THE VARIOUS FUNCTION AND POSSIBILITIES .........11
Display and control panel .........................................................11
Operating your fridge ............................................................... 13
Super freeze mode .............................................................. 13
Super cool mode .................................................................. 13
Economy mode .................................................................... 13
Holliday mode ...................................................................... 14
Drink cool mode ................................................................... 15
Screen saver mode .............................................................. 15
Function of Child lock .......................................................... 16
Light cancelling mode .......................................................... 16
Cooler temperature settings .................................................... 17
Freezer temperature settings................................................... 17
Warnings about Temperature Adjustments .............................. 18
EN
1
ACCESSORIES ..............................................................19
Freezer box.............................................................................. 19
Chiller Shelf ............................................................................. 19
Humidity Controler ................................................................... 20
Natural Ion Tech / Ionisier (in some models) ........................... 20
Adjustable Door Shelf .............................................................. 21
Adjustable Glass Shelf............................................................. 21
CLEANING AND MAINTENANCE .................................. 22
Defrosting ................................................................................ 23
EN 2
ARRANGING FOOD IN THE APPLIANCE ..................... 24
Refrigerator compartment ........................................................ 24
Freezer compartment .............................................................. 25
TRANSPORTATION AND CHANGING OF INSTALLATION
POSITION ........................................................................30
Repositioning the door ............................................................. 30
BEFORE CALLING YOUR AFTER SALES SERVICE ... 31
TIPS FOR SAVING ENERGY ..........................................35
BEFORE USING THE APPLIANCE
General warnings
WARNING: Keep vantilation openings, in the appliance
enclosure or in the built-in structure, clear of obstruction. WARNING: Do not use mechanical devices or other
means to accelerate the defrosting process, other than those recommended by the manufacturer.
WARNING: Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of the type recommended by the manufacturer.
WARNING: Do not damage the refrigerant circuit. WARNING: In order to avoid any hazards resulting
from the instability of the appliance, it must be xed in
accordance with the following instructions:
If your appliance uses R600a as a refrigerant (this information will be provided on the label of the cooler) you should take care during transportation and installation to prevent the cooler elements from being damaged. R600a is an environmentally friendly and natural gas, but it is explosive. In the event of a leak due to damage of the cooler elements, move your
fridge away from open ames or heat sources and
ventilate the room where the appliance is located for a few minutes.
EN
3
While carrying and positioning the fridge, do not damage the cooler gas circuit.
Do not store explosive substances such as aerosol cans with a ammable propellant in this appliance.
This appliance is intended to be used in household
and domestic applications such as:
- staff kitchen areas in shops, ofces and other working environments.
EN 4
BEFORE USING THE APPLIANCE
- farm houses and by clients in hotels, motels and other residential type environments.
- bed and breakfast type environments;
- catering and similar non-retail applications.
If the socket does not match the refrigerator plug, it must be replaced by the manufacturer, a service
agent or similarly qualied persons in order to avoid
a hazard.
A specially grounded plug has been connected to the power cable of your refrigerator. This plug should be used with a specially grounded socket of 16 amperes. If there is no such socket in your house, please have one installed by an authorised electrician.
This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.
If the supply cord is damaged, it must be replaced by the manufacturer, an authorised service agent or
similar qualied persons, in order to avoid a hazard.
This appliance is not intended for use at altitudes
exceeding 2000 m.
BEFORE USING THE APPLIANCE
Old and out-of-order fridges
If your old fridge has a lock, break or remove the lock before discarding it, because children may get trapped inside it and may cause an accident.
Old fridges and freezers may contain isolation material and refrigerant with CFC or HFC. Therefore, take care not to harm environment when you are discarding your old fridges.
Please ask your municipal authority about the disposal of the WEEE reuse, recycle and recovery purposes.
Notes:
Please read the instruction manual carefully before installing and using your appliance. We are not
responsible for the damage occurred due to misuse.
Follow all instructions on your appliance and instruction manual, and keep this manual in a safe place to resolve the problems that may occur in the future.
This appliance is produced to be used in homes and it can only be used in domestic environments and for the
specied purposes. It is not suitable for commercial or
common use. Such use will cause the guarantee of the appliance to be cancelled and our company will not be responsible for losses incurred.
This appliance is produced to be used in houses and it is only suitable for cooling / storing food. It is not suitable for commercial or common use and/or for storing substances except for food. Our company is not responsible for losses to be incurred in the contrary case.
EN
5
Safety warnings
Do not connect your Fridge Freezer to the mains electricity supply using an extension lead.
Do not plug in damaged, torn or old plugs.
Do not pull, bend or damage the cord.
EN 6
BEFORE USING THE APPLIANCE
This appliance is designed for use by adults, do not allow children to play with the appliance or let them hang off the door.
Never touch the power cord/plug with wet hands as this could cause a short circuit or electric shock.
Do not place glass bottles or beverage cans in the ice­making compartment as they can burst as the contents freeze.
• Do not place explosive or ammable material in your
fridge. Place drinks with high alcohol content vertically in the fridge compartment and make sure that their tops are tightly closed.
When removing ice from the ice-making compartment, do not touch it. Ice may cause frost burns and/or cuts.
Do not touch frozen goods with wet hands. Do not eat ice­cream or ice cubes immediately after you have taken them out of the ice-making compartment.
Do not re-freeze frozen goods after they have melted. This may cause health issues such as food poisoning.
Do not cover the body or top of fridge with lace. This affects the performance of your fridge.
Secure any accessories in the fridge during transportation to prevent damage to the accessories.
Installing and operating your fridge
Before using your fridge, you should pay attention to the following points:
The operating voltage for your fridge is 220-240 V at 50Hz.
We do not accept responsibility for any damages that
occur due to ungrounded usage.
Place your fridge where it will not be exposed to direct sunlight.
Your appliance should be at least 50 cm away from stoves, gas ovens and heater cores, and at least 5 cm away from electrical ovens.
Your fridge should never be used outdoors or exposed to rain.
When your fridge is placed next to a deep freezer, there
BEFORE USING THE APPLIANCE
should be at least 2 cm between them to prevent humidity forming on the outer surface.
Do not place anything on your fridge, and install your fridge in a suitable place so that at least 15 cm of free space is available above it.
Use the adjustable front legs to make sure your appliance is level and stable. You can adjust the legs by turning them in either direction. This should be done before placing food in the fridge.
Before using your fridge, wipe all parts with a solution of warm water and a teaspoon of sodium bicarbonate, then rinse with clean water and dry. Place all parts in the fridge after cleaning.
Install the plastic distance guide (the part with black vanes at the rear) by turning it 90° (as shown in the gure) to
prevent the condenser from touching the wall.
The refrigerator should be placed against a wall with a free space not exceeding 75 mm.
Before Using your Fridge
• When using your fridge for the rst time, or after
transportation, keep it in an upright position for at least 3
hours before plugging into the mains. This allows efcient
operation and prevents damage to the compressor.
Your fridge may have a smell when it is operated for the rst time. This is normal and the smell will fade away when
your fridge starts to cool.
EN
7
EN 8
BEFORE USING THE APPLIANCE
Information about New Generation Cooling Technology
Fridges with new generation cooling technology have a different working system than static fridges. In normal fridges, humid air that enters into fridge and the water vapor that comes out from the foods, accumulates frost formation in freezer compartment. In order to melt this frost, in other words defrost, the fridge has to be stopped. During the stopping period, to keep the foods cold, user has to extract the food to outside of fridge and user has to clear the ice during this period.
In the fridges with new generation cooling technology, situation in the freezer compartment is completely different. With the aid of fan, cold and dry air is blown out through many points into the freezer compartment. As a result of the homogenously blown cold air, even in the spaces between shelves, foods are frozen equally and correctly. On the other hand there will be no frost formation.
In the refrigerator compartment, there will be nearly same
conguration with freezer compartment. Air, that is emitted
with the fan, located at the top of refrigerator compartment, is cooled while passing through the gap behind the air duct. At the same time, air is blown out through the holes on the air duct so that cooling process is successfully completed in the refrigerator compartment. Holes on the air duct are designed such that the air distribution becomes homogenous in this compartment.
As there is no air passage between freezer and refrigerator compartment, there will be no odor mixing.
As a result of these, your fridge with new generation cooling technology, gives you, ease of use beside the huge volume and esthetic appearance.
THE PARTS OF THE APPLIANCE AND THE COMPARTMENTS
EN
9
A
1
2 3
4 5
6
7
8
15
14
13
12
B
11
9
10
This presentation is only for information about the parts of the
appliance. Parts may vary according to the appliance model.
EN 10
THE PARTS OF THE APPLIANCE AND THE COMPARTMENTS
A) Fridge compartment B) Freezer compartment
1) Wine rack *
2) Fridge shelves
3) Ionisier *
4) Chiller *
5) Crisper cover
6) Crisper
7) Freezer top baskets
8) Freezer bottom basket
9) Leveling feet
10) Ice tray
11) Freezer glass shelves
12) Bottle shelf
13) Adjustable door shelf * / Door shelf
14) Door shelf
15) Egg holder
* In some models
This presentation is only for information about the parts of the
appliance. Parts may vary according to the appliance model.
THE VARIOUS FUNCTION AND POSSIBILITIES
Display and control panel
EN
11
1
2
3
4
5
8
6 7
9
10
11
EN 12
THE VARIOUS FUNCTION AND POSSIBILITIES
Use of control panel
1. It is cooler set value screen.
2. It is super cooling indicator.
3. It is freezer set value screen.
4. It is super freeze indicator.
5. It is alarm symbol.
6. It is economy mode symbol.
7. It is holiday mode symbol.
8. It is child-lock symbol.
9. It enables the setting value of cooler to be modied and super cool
mode to be activated if desired. Cooler maybe set to 8, 6, 5, 4, 2 °C super cool.
10. It enables the setting value of freezer to be modied and super freeze
mode to be activated if desired. Freezer may be set to -16, -18, -20, -22,
-24°C super freeze.
11. It enables the modes (economy, holiday…) to be activated if desired.
THE VARIOUS FUNCTION AND POSSIBILITIES
Operating your fridge
Super freeze mode
How would it be used?
Press freezer set button until Super freeze symbol will be seen on the screen. Buzzer will sound beep beep. Mode will be set.
During this mode:
Temperature of cooler and super cool mode may be adjusted. In this case super freeze mode continues.
Economy and Holiday mode can not be selected.
Super freeze mode can be cancelled by the same
operation of selecting.
Super cool mode
How would it be used?
Press cooler set button until Super cool symbol will be seen on the screen. Buzzer will sound beep beep. Mode will be set.
EN
13
During this mode:
Temperature of freezer and super freeze mode may be adjusted. In this case super cool mode continues.
Economy and Holiday mode can not be selected.
Super cool mode can be cancelled by the same operation
of selecting.
Economy mode
How would it be used?
Push "mode button" until eco symbol appears.
If no button is pressed for 1 second. Mode will be set. Eco
symbol will blink 3 times. When mode is set, buzzer will sound beep beep.
Freezer and refrigerator temperature segments will show "E".
• Economy symbol and E will light till mode nishes.
EN 14
THE VARIOUS FUNCTION AND POSSIBILITIES
During this mode:
Freezer may be adjusted. When economy mode will be cancelled, the selected setting values will proceed.
Cooler may be adjusted. When economy mode will be cancelled, the selected setting values will proceed.
Super cool and super freeze modes can be selected. Economy mode is automatically cancelled and the selected mode is activated.
Holiday mode can be selected after cancelling the economy mode. Then the selected mode is activated.
To cancel, you will just need to press on mode button.
Holliday mode
How would it be used?
Push "mode button" until holiday symbol appears
If no button is pressed for 1 second. Mode will be set.
Holiday symbol will blink 3 times. When mode is set, buzzer will sound beep beep.
Cooler temperature segment will show "--".
• Holiday symbol and "--" will light till mode nishes.
During this mode:
Freezer may be adjusted. When holiday mode will be cancelled , the selected setting values will proceed.
Cooler may be adjusted. When holiday mode will be cancelled, the selected setting values will proceed.
Super cool and super freeze modes can be selected. Holiday mode is automatically cancelled and the selected mode is activated.
Economy mode can be selected after cancelling the holiday mode. Then the selected mode is activated.
To cancel, you will just need to press on mode button.
THE VARIOUS FUNCTION AND POSSIBILITIES
Drink cool mode
When would it be used?
This mode is used to cool the drinks within adjustable time.
How would it be used?
Press freezer button for 3 seconds.
Special animation will start on freezer set value screen
and 05 will blink on cooler set value screen.
Press cooler button to adjust the time (05 - 10 - 15 - 20 ­25 - 30 minutes).
When you select the time the numbers will blink 3 times on screen and sound beep beep.
If no button is pressed within 2 seconds the time will be set.
The countdown starts from the adjusted time minute by minute.
Remaining time will blink on the screen.
To cancel this mode press freezer set button for 3 seconds.
EN
15
Screen saver mode
How to use?
This mode will be activated when you press on mode button for 5 seconds.
If no button is pressed within 5 seconds when he mode is active, lights of the control panel will go off.
If you press any button when lights of control panel are off, the current settings will appear on the screen, and then you can maket he adjustment as you want. If you neither cancel screen saver mode nor press on any button in 5 seconds, the control panel will go off again.
To cancel screen saver mode press on mode button for 5 seconds again.
When screen saver mode is active you can also activate child lock.
EN 16
THE VARIOUS FUNCTION AND POSSIBILITIES
If no button is pressed within 5 seconds after child lock is activated, the lights of the control panel will turn off. You can see latest status of settings or modes after you pres any button. While control panel ‘s light is on, you can cancel child lock as described in the instruction of this mode.
Function of Child lock
When would it be used?
To prevent children from playing with the buttons and changing the settings you have made, child lock is available in the appliance.
Activating Child Lock
Press on Freezer and Cooler buttons simultaneously for 5 seconds.
Deactivating Child Lock
Press on Freezer and Cooler buttons simultaneously for 5 seconds.
Note: Child lock will also be deactivated if electricity is interrupted or the fridge is unplugged.
Light cancelling mode
When would it be used?
If you want to cancel lights of cooler, you can select this mode.
While pushing the freezer and mode buttons, open and close cooler door 3 times. The mode will be selected in this way. From now on, the lights will not come on when the function is not cancelled by the same way.
If you want to cancel this mode, repeat the same process or the mode will automatically cancel itself after 24 hours.
THE VARIOUS FUNCTION AND POSSIBILITIES
Cooler temperature settings
Initial temperature value for Cooler Setting Indicator is +4 °C.
Press cooler button once.
• When you rst push this button, the last value appears on
the setting indicator of the cooler.
Whenever you press on this button, lower temperature will be set. (+8°C, +6°C, +5°C, +4°C, +2°C, supercool)
When you push the cooler set button until supercool symbol appears, and if you do not push any button in 1
seconds Super Cool will ash.
If you continue to press, it will restart from +8°C.
The temperature value selected before Holiday Mode,
Super Freeze Mode, Super Cool Mode or Economy Mode is activated will remain the same when the mode is over or cancelled. The appliance continues to operate with this temperature value.
Freezer temperature settings
Initial temperature value for Freezer Setting Indicator is
-18°C.
Press freezer set button once.
• When you rst push this button, the last set value will blink
on screen.
Whenever you press on this button, lower temperature will be set (-16°C, -18°C, -20°C, -22°C, -24°C superfreeze).
When you push the freezer set button until superfreeze symbol appears, and if you do not push any button in 1
seconds Super Freeze will ash.
If you continue to press, it will restart from -16°C.
The temperature value selected before Holiday Mode,
Super Freeze Mode, Super Cool Mode or Economy Mode is activated will remain the same when the mode is over or cancelled. The appliance continues to operate with this temperature value.
EN
17
EN 18
THE VARIOUS FUNCTION AND POSSIBILITIES
Warnings about Temperature Adjustments
Your temperature adjustments will not be deleted when an energy breakdown occurs.
Temperature adjustments should be made according to the frequency of door openings and the quantity of food kept inside the fridge.
Do not pass to another adjustment before completing an adjustment.
Your fridge should be operated up to 24 hours according to the
ambient temperature without interruption after being plugged in to be completely cooled. Do not open doors of your fridge frequently and do not place much food inside it in this period.
A 5 minute delaying function is applied to prevent damage to the compressor of your fridge, when you take the plug off and then plug it on again to operate it or when an energy breakdown occurs. Your fridge will start to operate normally after 5 minutes.
Your fridge is designed to operate in the ambient temperature intervals stated in the standards, according to the climate class stated in the information label. We do not recommend operating your fridge out of stated temperatures value limits in terms of cooling effectiveness.
This appliance is designed for use at an ambient temperature within the 10°C - 43°C range.
Climate Class Ambient Temperature oC
T Between 16 and 43 (°C)
ST Between 16 and 38 (°C)
N Between 16 and 32 (°C)
SN Between 10 and 32 (°C)
ACCESSORIES
Freezer box
The freezer box allows foods are maintained more regularly.
Removing The freezer box;
Pull the box out as far as possible
Pull the front of box up and out.
! Make the inverse of the same operation for the resetting the sliding
compartment.
Note: Always Keep the handle of box while removing the box.
Freezer boxes
EN
19
Chiller Shelf
Do not put foods you want to freeze or ice trays in order to make ice.
Removing the Chiller shelf
Pull the chiller shelf out toward you by sliding on rails.
Pull the chiller shelf up from rail to remove.
(In some models)
Keeping food in the Chiller compartment instead of the freezer or refrigerator compartment allows
food retain freshness and avour longer, while
preserving its fresh appearance. When chiller tray becomes dirty, remove it and wash it with water.
(Water freezes at 0°C, but foods containing salt or sugar freeze at temperature lower than that)
Normally people use the chiller compartment for
raw sh, lightly pickled, rice, etc...
EN 20
ACCESSORIES
Humidity Controler
When the humidity controler in the closed position, it allows fresh fruit and vegetables to be stored longer.
In case of the crisper is totally full, the fresh dial is located in front of crisper, should be opened. By means of this the air in the crisper and humidity rate will be controlled and endurance life will be increased.
If you see any condensation on glass shelf, humidity control should be taken into the open positions.
Natural Ion Tech / Ionisier (in some models)
Natural Ion Tech spreads negative ions which neutralize particles of unpleasant smell and dust in the air.
By removing these particles from the air in the refrigerator, Natural Ion Tech improves air quality and eliminates odours.
This feature is optional. It may not exist on your product.
The location of your ioniser device may vary from product to product.
(In some models)
Ionisier
ACCESSORIES
Adjustable Door Shelf
Six different height adjustments can be made to provide storage areas that you need by adjustable door shelf.
To change the position of adjustable door shelf ; Hold the bottom of the shelf and pull the buttons on the side of
the door shelf direction of arrow (Fig.1).
Position door shelf the height you need by moving up and down. After you get the position that you want the door shelf, release the buttons on the side of the door shelf (Fig.2) Before releasing the door shelf, move up down and make sure the
door shelf is xed.
Note: Before moving door shelf is loaded, you must hold the shelf by supporting the bottom. Otherwise, door shelf could fall off the rails due to the weight. So damage may occur on the door shelf or rails.
(In some models)
EN
21
Figure -1
Figure -2
Adjustable Glass Shelf
Adjustable glass shelf mechanism provides higher storage spaces with a simple movement. To cover the glass shelf, push it.
You can load your food as you want in the resulting extra space. To bring the shelf in its original position, pull it toward you.
Visual and text descriptions on the accessories section may
vary according to the model of your appliance.
(In some models)
Figure -1
Figure -2
EN 22
CLEANING AND MAINTENANCE
• Disconnect the unit from the power supply before cleaning.
Do not clean the appliance by pouring water.
Make sure that no water enters the lamp housing and
other electrical components.
The refrigerator should be cleaned periodically using a solution of bicarbonate of soda and lukewarm water.
Clean the accessories separately with soap and water Do not clean them in the dishwasher.
Do not use abrasive products, detergents or soaps. After washing, rinse with clean water and dry carefully. When
you have nished cleaning, reconnect the plugto the mains
supply with dry hands.
Clean the condenser with a broom at least twice a year. This will help you to save on energy costs and increase productivity.
THE POWER SUPPLY MUST BE DISCONNECTED.
CLEANING AND MAINTENANCE
Defrosting
Your refrigerator performs automatic defrosting. The water formed as a result of defrosting passes through the water
collection spout, ows into the vaporisation container behind
your refrigerator and evaporates there.
Make sure you have disconnected the plug of your refrigerator before cleaning the vaporisation container.
Remove the vaporisation container from its position by removing the screws as indicated. Clean it with soapy
water at specic time intervals. This will prevent odours
from forming.
Replacing LED Lighting
If your refrigerator has LED lighting contact the help desk as this should be changed by authorized personnel only.
EN
23
Evaporating tray
EN 24
ARRANGING FOOD IN THE APPLIANCE
Refrigerator compartment
For normal operating conditions, adjusting the temperature value of the cooler partition of the fridge to 4°C will be enough.
To reduce humidity and consequent increase of frost never place liquids in unsealed containers in the refrigerator. Frost tends to concentrate in the coldest parts of the evaporator and in time will require more frequent defrosting.
Never place warm food in the refrigerator. Warm food should be allowed to cool at room temperature and should be arranged to ensure adequate air circulation in the refrigerator compartment.
Nothing should touch on the back wall as it will cause frost and the packages can stick on the back wall. Do not open the refrigerator door too frequently.
• Arrange the meat and cleaned sh(wrapped in packages or sheets
of plastic) which you will use in 1-2 days,in the bottom section of the refrigerator compartment(that is above the crisper) as this is the coldest section and will ensure the best storing conditions.
You can put the fruits and vegetables into crisper without packing.
Some recommendations have been specied below for the placement
and storage of your food in the cooling compartment.
Food
Vegetables and fruits
Meatandsh 2 - 3 Days
Fresh cheese 3 - 4 Days In special door shelf Butter and
margarine
Bottled products milk and yoghurt
Eggs 1 month In the egg shelf Cooked food All shelves
NOTE: Potatoes, onions and garlic should not be stored in the refrigerator.
Maximum Storing
time
1 week Vegetable bin
1 week In special door shelf
Until the expiry date
recommended by
the producer
Where to place in the
fridge department
Wrapped in plastic foil or
bags or in a meat container
(on the glass shelf)
In special door shelf
ARRANGING FOOD IN THE APPLIANCE
Freezer compartment
Please use the deep freeze compartment of your refrigerator for storing the frozen food for a long time and for producing ice.
To get maximum capacity for freezer compartment, please just use glass shelves for upper and middle section. For bottom section, please use lower basket.
Please do not place the food you shall newly freeze nearby the already frozen food.
• You should freeze the food to be frozen (meat, minced meat, sh,
etc.) by dividing them into portions in such a way that they can be consumed once.
Please do not refreeze the frozen food once they are thawed. It may pose a danger for your health since it might cause problems such as food poisoning.
Do not place the hot meals in your deep freeze before they become cold. You would cause the other food frozen beforehand in the deep
freeze to become putreed.
When you buy frozen food, makes sure that they were frozen under
appropriate conditions and the package is not torn.
While storing the frozen food, the storage conditions on the package should certainly be observed. If there is not any explanation, the food must be consumed within the shortest time possible.
• If there had been humidication in the frozen food package and it
has a foul smell, the food might have been stored under unsuitable conditions previously and gone rotten. Do not purchase this type of foods!
The storage durations of frozen food change depending on the ambient temperature, the frequent opening and closing of the doors, thermostat settings, food type and the time elapsed from the purchase time of the food to the time it is placed into the freezer. Always abide by the instructions on the package and never exceed the indicated storage duration.
During long lasting power failures, please do not open the door of the deep freeze compartment. Your refrigerator shall preserve your frozen food for about 18 hours in ambient temperatures of 25°C and for about 13 hours in ambient temperatures of 32°C. This value will decrease under higher ambient temperatures. During longer power failures, do not refreeze your food and consume them as soon as possible.
EN
25
EN 26
ARRANGING FOOD IN THE APPLIANCE
Not that; if you want to open again immediately after closing the
freezer door, it will not be opened easily. It’s quite normal! After reaching equilibrium condition, the door will be opened easily.
Important note:
• Frozen foods, when thawed, should be cooked just like fresh foods. If they are not cooked after being thawed they must NEVER be re­frozen.
The taste of some spices found in cooked dishes (anise, basilica, watercress, vinegar, assorted spices, ginger, garlic, onion, mustard, thyme, marjoram, black pepper, etc.) changes and they assume a strong taste when they are stored for a long period. Therefore, the frozen food should be added little amount of spices or the desired spice should be added after the food has been thawed.
The storage period of food is dependent on the oil used. The suitable oils are margarine, calf fat, olive oil and butter and the unsuitable oils are peanut oil and pig fat.
The food in liquid form should be frozen in plastic cups and the other food should be frozen in plastic folios or bags.
Some recommendations have been specied on pages 27, 28 and 29 for
the placement and storage of your food in the deep freeze compartment.
ARRANGING FOOD IN THE APPLIANCE
Maximum
Meatandsh Preparation
Steak Wrapping in a foil 6 - 8 Lamb meat Wrapping in a foil 6 - 8 Veal roast Wrapping in a foil 6 - 8 Veal cubes In small pieces 6 - 8 Lamb cubes In pieces 4 - 8
Minced meat
Giblets (pieces) In pieces 1 - 3 Bologna sausage/
salami Chicken and turkey Wrapping in a foil 4 - 6 Goose and Duck Wrapping in a foil 4 - 6
Deer, Rabbit, Wild Boar
Fresshwatershes
(Salmon, Carp, Crane, Siluroidea)
Leansh;bass,turbot, ounder
Fattyshes(Tunny, Mackarel,bluesh,
anchovy)
Shellsh Cleaned and in bags 4 - 6
Caviar
Snail
In packages without using spices
Should be packaged even if it has membrane
In 2.5 kg portions and as
llets
After cleaning the bowels
and scales of the sh, wash
and dry it; and if necessary, cut the tail and head.
In its package, aluminium or plastic container
In salty water, aluminum or plastic container
Storing time
(month)
1 - 3
6 - 8
2 - 4
2 - 3
EN
27
2
4
3
Note: Frozen meat should be cooked as fresh meat after being thawed. If the meat is not cooked after being thawed, it should never be frozen again.
EN 28
String beans and beans
Beans Hull and wash and boil in water 12 Cabbage Cleaned and boil in water 6 - 8
Carrot
Pepper
Spinach Washed and boil in water 6 - 9
Cauliower
Eggplant Cut to pieces of 2cm after washing 10 - 12
Corn
Apple and pear Peel and slice 8 - 10
Apricot and Peach
Strawberry and Blackberry
Cooked fruits
Plum, cherry, sourberry
ARRANGING FOOD IN THE APPLIANCE
Vegetables and
Fruits
Wash and cut to small pieces and
Clean and cut to slices and boil in
Cut the stem, cut into two pieces
and remove the core and boil in
Take the leaves apart, cut the heart
into pieces, and leave it in water
with a little lemon juice for a while
Clean and pack with its stem or as
Cut into two pieces and remove the
Adding 10 % of sugar in the
Preparation
boil in water
water
water
sweet corn
stone
Wash and hull 8 - 12
container
Wash and hull the stems 8 - 12
Maximum
Storing
time
(months)
10 - 13
12
8 - 10
10 - 12
12
4 - 6
12
ARRANGING FOOD IN THE APPLIANCE
EN
29
Dairy
Products
Packet (Homogenize) Milk
Cheese­excluding white cheese
Butter, margarine
Bread 4 - 6 2 - 3 4-5 (220-225 °C) Biscuits 3 - 6 1 - 1,5 5-8 (190-200 °C) Pastry 1 - 3 2 - 3 5-10 (200-225 °C) Pie 1 - 1,5 3 - 4 5-8 (190-200 °C) Phyllo
dough Pizza 2 - 3 2 - 4 15-20 (200 °C)
Preparation
In its own packet
In slices 6 - 8
In its package 6
Maximum
Storing time
(months)
2 - 3 1 - 1,5 5-8 (190-200 °C)
Maximum
Storing time
(months)
2 - 3
Thawing
time in room
temperature
(hours)
Storing Conditions
Pure Milk – In its own packet
Original package may be used for short storing period. It should be wrapped in foil for longer periods.
Thawing time in
oven (minutes)
EN 30
TRANSPORTATION AND CHANGING OF INSTALLATION POSITION
Transportation and Changing of Installation Position
The original packages and foamed polystyrene (PS) can be retained if required.
During transportation, the appliance should be secured with a wide string or a strong rope. The instructions written on the corrugated box must be followed while transporting.
Before transporting or changing the installation position, all the moving objects (ie,shelves,crisper…) should be
taken out or xed with bands in order to prevent them from
getting damaged.
Repositioning the door
It is not possible to change the opening direction of your refrigerator door, if the door handle on your refrigerator is installed from the front surface of the door.
It is possible to change the opening direction of the door on models without any handles.
If the door opening direction of your refrigerator may be changed, you should contact the nearest Authorised Service Agent to have the opening direction changed.
BEFORE CALLING YOUR AFTER SALES SERVICE
Check Warnings;
Your fridge warns you if the temperatures for cooler and freezer are in improper levels or when a problem occurs in the appliance. Warning codes are displayed in the Freezer and Cooler Indicators.
ERROR TYPE MEANING WHY WHAT TO DO
SR
SR – Set
value blink
on freezer
set value
screen
SR – Set value
Blink on cooler
set value
screen
SR – Set value
blink on freezer
and cooler set
value screen
"Failure
Warning"
Freezer comp.
Not Cold enough
"Refrigerator
comp.
Not Cold enough"
"not cold enough
Warning"
There is/are some
part(s) Out of order
or there is a failure in
cooling process
This caution will be
seen especially after
long term of power
failure
Ideal temperature for
Ref. Compartment is
+4 oC. If you see this
warning your foods
have risk of spoiling.
It is combination of
"not cool enough"
error for both of the
compartments.
Call Service for assistance as soon as possible.
1. Do not freeze the foods that are thaw and use in short time period.
2. Set the freezer temperature to colder values or set the super freeze , until the compartment gets to normal temperature.
3. Do not put fresh food until this failure is off.
1. Set the refrigerator temperature to colder values or set the super cooling mode until the compartment gets to normal temperature.
2. Do not open the door much until this failure is off.
You will see this failure
when rst starting the
appliance. It will be off after the compartments gets normal temperature
EN
31
SR – Set value
blink on cooler
set value
screen
Refrigerator
comp. too Cold
The foods starts to
freeze because of
the too much cold
temperature
1. Check if the “Super cooling mode” is on
2. Decrease the refrigerator temperature values
EN 32
BEFORE CALLING YOUR AFTER SALES SERVICE
“--”
"Low voltage
Warning"
When the power
supply gets lower
than 170 V the
appliance gets to
steady position.
This is not a failure. This prevents any damages on the compressor. This warning will off after the voltage gets required level
If your fridge is not operating;
Is there a power failure?
Is the plug connected to the socket correctly?
Is the fuse of the socket to which the plug is connected or the main
fuse blown?
Is there any failure at the socket? To check this, plug your refrigerator to a socket this is surely operating.
If your fridge is not cooling enough;
Is the temperature adjustment right?
Is the door of your fridge opened frequently and left open for a long
while?
Is the door of fridge closed properly?
Did you put a dish or food on your fridge so that it contacts the rear
wall of your fridge so as to prevent the air circulation?
• Is your fridge lled excessively?
Is there adequate distance between your fridge and the rear and side
walls?
• Is the ambient temperature within the range of values specied in the
operating manual?
If the food in your refrigerator compartment is over cooled
Is the temperature adjustment right?
Are there many food recently put inside the freezer compartment?
If so, your fridge may over cool the food inside the refrigerator compartment as it will operate longer to cool these food.
If your fridge is operating too loudly;
To maintain the set cooling level, compressor may be activated from time to time. Noises from your fridge at this time are normal and due to its function. When the required cooling level is reached, noises will be decreased automatically. If the noises persist;
BEFORE CALLING YOUR AFTER SALES SERVICE
Is your appliance stable? Are the legs adjusted?
Is there anything behind your fridge?
Are the shelves or dishes on the shelves vibrating? Re-place the
shelves and/or dishes if this is the case.
Are the items placed on your fridge vibrating?
Normal Noises; Cracking (Ice cracking) Noise:
During automatic defrosting.
When the appliance is cooled or warmed (due to expansion of
appliance material).
Short cracking: Heard when the thermostat switches the compressor on/off.
Compressor noise (Normal motor noise): This noise means that the compressor operates normally Compressor may cause more noise for a short time when it is activated.
Bubbling noise and splash: This noise is caused by the ow of the
refrigerant in the tubes of the system.
Waterownoise: Normal ow noise of water owing to the evaporation
container during defrosting. This noise can be heard during defrosting. Air Blowing Noise (Normal fan noise): This noise can be heard in No-
Frost fridge during normal operation of the system due to the circulation of air.
EN
33
If humidity builds up inside the fridge;
Are all food packed properly? Are the containers dried before placing them in the fridge?
Are the fridge doors opened frequently? Humidity of the room gets in the fridge when the doors are opened. Humidity build up will be faster when you open the doors more frequently, especially if the humidity of the room is high.
If the doors are not opened and closed properly;
Do the food packages prevent closing of the door?
Are the door compartments, shelves and drawers placed properly?
Are door gaskets broken or torn?
Is your fridge on a level surface?
EN 34
BEFORE CALLING YOUR AFTER SALES SERVICE
If the edges of fridge cabinet that the door joint contact are warm;
Especially in summer (hot weather), the surfaces that the joint contact may get warmer during the operation of the compressor, this is normal.
IMPORTANT NOTES:
Compressor protection function will be activated after sudden power breakdowns or after unplugging the appliance, because the gas in the cooling system is not stabilized yet. Your fridge will start after 5 minutes, there is nothing to worry about.
If you will not use your fridge for a long time (e.g. in summer holidays) unplug it. Clean your fridge according to Part 4 and leave the door open to prevent humidity and smell.
If the problem persists after you have followed all the instructions above, please consult to the nearest authorized service.
The appliance you bought is designed for home type use and can be used only at home and for the stated purposes. It is not suitable for commercial or common use. If the consumer use the appliance in a way that does not comply with these features, we emphasize that the producer and the dealer shall not be responsible for any repair and failure within the guarantee period.
TIPS FOR SAVING ENERGY
1. Install the appliance in a cool, well ventilated room , but not in direct sunlight and not near a heat source (radiator, cooker.. etc). Otherwise use an insulating plate.
2. Allow warm food and drinks to cool down outside the appliance.
3. When thawing frozen food, place it in the refrigerator compartment. The low temperature of the frozen food will help to cool the refrigerator compartment when it is thawing. This will help to save energy. If the frozen food is put out, it results in a waste of energy.
4. Cover drinks or other liquids when placing them in the appliance Otherwise humidity increases in the appliance. Therefore, the working time gets longer. Also covering drinks and other liquids helps to preserve smell and taste.
5. Try to avoid keeping the doors open for long periods or opening the doors too frequently as warm air will enter the cabinet and cause the compressor to switch on unnecessarily often.
6. Keep the covers of the different temperature compartments (crisper, chiller ...etc ) closed
7. Door gasket must be clean and pliable. Replace gaskets if worn.
EN
35
EN 36
Loading...
