PRECAUTIONS
General safety instructions
Risk of personal injury
• According to current
regulations, children between 3
and 8 years of age can take or
load food from the appliance,
but it is highly discouraged to
allow children under 8 years of
age to perform these
operations and in general to
use the appliance.
• Keep children under the age of
eight at a safe distance unless
they are constantly supervised
and make sure that they do not
play with the appliance.
• Never try to put out a fire or
flames with water: turn off the
appliance and smother the
flames with a fire blanket.
• Do not touch the heating
elements on the outside of the
appliance.
• Cleaning and maintenance that
should be performed by the
user must not be carried out by
unsupervised children.
• Do not modify this appliance.
• Do not insert pointed metal
objects (cutlery or utensils) into
the slots in the appliance.
PRECAUTIONS - 3914779594/C
• Do not touch (especially with
wet hands) frozen products or
put them in your mouth directly.
• Do not store inflammable,
explosive or volatile
substances.
• Do not keep explosive
substances, such as spray
bottles with flammable
propellants in the appliance.
• Bottles containing strong
alcoholic drinks must be tightly
closed and stored vertically.
• Organic compounds, acids
and essential oils can corrode
the seals and plastic surfaces if
left in contact with them for
extended periods.
• Turn off the appliance and
unplug it from the mains before
cleaning or maintenance.
• Do not pull the cable to unplug
the appliance.
Risk of damaging the appliance
• Never rest sharp metal objects
such as knives, forks, spoons
and lids on the appliance
during use.
• Do not use abrasive or
corrosive detergents (e.g.
scouring powders, stain
removers and metallic
sponges) on glass parts.
• Do not sit on the appliance.
• Do not sit or lean on the door
or any open drawers.
• Do not prize on the door or
handle to move the appliance.
• Do not use steam jets to clean
the appliance.
• Do not use electrical
appliances (e.g. hair dryers) or
sprays for defrosting, the plastic
parts could be damaged.
• Do not use the appliance to
cool rooms for any reason.
• Always unplug the appliance in
the event of a fault or when
performing cleaning or
maintenance.
• Do not keep liquids in tins or
glass containers in the freezer.
• Do not use sharp metal objects
to remove excess ice build-up
in the freezer compartment.
• Do not use adaptors for plugs.
• CAUTION: do not place
portable multiple sockets or
portable power supply units at
the back of the appliance.
• Do not place heavy objects on
the top of the appliance.
• Do not use sharp objects when
removing ice and frost in order
not to damage the appliance's
walls.
Installation and maintenance
• The appliance must be
connected to ground in
compliance with electrical
system safety standards.
• Position the appliance with the
aid of a second person.
• Never use the open door to
lever the appliance into place
when fitting.
4 - PRECAUTIONS 914779594/C
e
• Avoid exerting too much
pressure on the door when
open.
• The appliance must not be
installed near heat sources. If
this is not possible, suitable
insulation must be used.
• The appliance must not be
exposed to direct sunlight.
• Do not use the appliance
outdoors.
• Installation and servicing should
be carried out by qualified
personnel in accordance with
current standards.
• Have the electrical connection
performed by authorised
technical personnel.
• For avoiding dangers, if the
power supply cable is
damaged, contact technical
support immediately and they
will replace it, so as to prevent
any risk.
• Always use any necessary/
required personal protective
equipment (PPE) before
performing any work on the
appliance (installation,
maintenance, positioning or
movement).
• Before performing any
operation on the appliance,
switch off the power supply.
• If installed near another
refrigerator or freezer, keep it
at a minimum distance of 2 cm.
• Do not try to repair the
appliance yourself or without
the assistance of a qualified
technician.
• Do not install/use the
appliance outdoors.
• CAUTION: while positioning
the appliance, make sure that
the power supply cable is not
caught or damaged.
• To prevent instability of the
appliance, install and secure it
correctly as indicated in the
instructions provided in this
manual.
• This appliance can be used up
to a maximum altitude of 2,000
metres above sea level.
For this appliance
• The appliance may only be
used by children aged 8 years
and over, and by people of
reduced physical, sensory or
mental capacity, or lacking in
experience and knowledge in
the use of the appliance,
provided that they instructed on
safe use of the appliance and
the risks connected to it by
adults who are responsible for
their safety.
• Children must be supervised to
ensure that they do not play
with the appliance.
• Do not rest any weight or sit on
the open door of the
appliance.
• Take care that no objects are
stuck in the doors.
• The appliance contains a small
quantity of isobutane (R600a),
PRECAUTIONS - 5914779594/C
make sure not to damage the
cooling circuit during transport,
installation and cleaning.
• Keep the ventilation openings
surrounding the appliance or in
the nearby area free from any
obstructions.
• Do not use mechanical,
electrical or chemical products
other than those recommended
by the manufacturer to speed
up the defrosting process.
• Do not damage the cooling
circuit (if it can be accessed).
• Do not use electrical
appliances inside food storage
compartments unless these are
of the type recommended by
the manufacturer.
• In the event of damage to the
cooling circuit, avoid the use of
naked flames and ventilate the
area properly.
• Do not use the appliance or
parts of it in ways other than
those specified in this manual.
• Caution: risk of fire, flammable
materials.
•Opening the door for long
periods can cause the
temperature in the appliance
compartments to rise
considerably.
• Clean surfaces that may come
into contact with food and
accessible drainage systems
regularly.
• Store raw meat and fish in
suitable containers in the
refrigerator, so that it does not
come into contact with other
food or drip on it.
• If the appliance is left empty for
long periods of time, switch it
off, thaw it, clean it, dry it and
leave the door open to prevent
the development of mould
inside.
Appliance purpose
• This appliance is not intended
to be used as a built-in
appliance.
• The appliance is not designed
for professional and
commercial use.
• This appliance is for
refrigeration and conservation
of fresh and frozen foods in the
home. Every other use is
considered inappropriate.
• The appliance is designed for
use in a domestic or similar
environment, for instance:
- staff kitchen areas in shops,
offices and other working
environments;
- farm houses and by guests in
hotels, motels and other
residential type environments;
- bed and breakfast
establishments;
- catering and similar non-retail
applications.
6 - PRECAUTIONS 914779594/C
e
• The appliance is not designed
to operate with external timers
or with remote-control systems.
This user manual
• This user manual is an integral part of the
appliance and must therefore be kept in its
entirety and within the user's reach for the
whole working life of the appliance.
• Read this user manual carefully before using
the appliance.
Manufacturer’s liability
The manufacturer declines all liability for
damage to persons or property caused by:
• use of the appliance other than that
specified;
• failure to comply with the instructions in the
user manual;
• tampering with any part of the appliance;
• use of non-original spare parts.
Technical Support.
• In the event of failure of the appliance,
contact the technical support and have the
repair carried out by qualified personnel
only.
• make sure you have the model and serial
number available on the identification plate.
• Use original spare parts only.
• Do not try to repair the appliance yourself or
without the assistance of a qualified
technician: this affects safety and may void
the warranty.
• Genuine spare parts for some specific
components remain available for a minimum
of 7 or 10 years, depending on the type of
component, from the date the model is
released on the market.
Identification plate
The identification plate bears the technical data,
serial number and brand name of the
appliance. Do not remove the identification
plate for any reason.
Energy label
To be informed about the performance of your
device via the EU EPREL database
visit the following web address and enter the
model name (available on the identification
plate):
https://eprel.ec.europa.eu
On the energy label there is a QR code for a
quick access to the web address. Use a device
equipped with an appropriate reading
program.
The energy label must be kept together with all
documents supplied with the appliance.
Disposal
This appliance conforms to the WEEE
European directive (2012/19/EU) and
must be disposed of separately from
other waste at the end of its service life.
The appliance does not contain substances in
quantities sufficient to be considered hazardous
to health and the environment, in accordance
with current European directives.
Power voltage
Danger of electrocution
• Disconnect the mains power supply.
• Unplug the appliance.
To dispose of the appliance:
• Cut the power cable and remove it.
• Deliver the appliance to the appropriate
recycling centre for electrical and electronic
equipment waste, or return it to the retailer
when purchasing an equivalent product, on
a one for one basis.
Our appliances are packaged in non-polluting
and recyclable materials.
• Deliver the packing materials to the
appropriate recycling centre.
Plastic packaging
Danger of suffocation
• Do not leave the packaging or any part of it
unattended.
• Do not let children play with the plastic
bags.
Information for control bodies
• For EcoDesign checks, the installation and
preparation of the appliance must comply
with EN 62552 standard.
• Ventilation requirements, dimensions and
minimum space from the rear wall are
indicated in the "Installation" chapter of this
manual.
• Contact the manufacturer for more
information.
PRECAUTIONS - 7914779594/C
To save energy
• Correct use of the appliance, correct
packaging of foodstuffs, a constant
temperature and food hygiene have effects
on the quality of storage.
• Reduce the number of times that the doors
are opened and the length of time they
remain open to prevent the compartments
from heating up excessively.
• Clean the condenser (if it can be accessed)
at the rear of the appliance periodically to
prevent the appliance from losing efficiency.
• Defrost frozen food in the refrigerator
compartment in order to make use of the
cold stored in the frozen foods.
• Placing the shelves at different heights does
not affect the stated energy consumption.
Light sources
• This appliance contains light sources which
cannot be replaced by the user and must
only be replaced by the technical assistance
service.
• This appliance contains light sources of
efficiency class "G".
How to read the user manual
This user manual uses the following reading
conventions:
Warning/Caution
Information/Advice
8 - PRECAUTIONS 914779594/C
e
DESCRIPTION
1
3
2
4
10
9
7
8
5
6
General Description
1 Control panel
For setting the temperature inside the refrigerator
and freezer compartments.
2 Fan
Distributes the temperature and reduces
condensation on the shelves and other surfaces.
3 Interior lighting
The interior of the appliance is lit when the door
is opened.
4 Refrigerator compartment
For storing fresh foods.
5 Chill drawer
Useful to preserve the freshness and flavour of
delicate foods such as meat and fish for longer.
6 Fruit and vegetable drawer
7 Quick freeze drawer
For quickly freezing fresh food.
8 Freezer compartment
For storing frozen foods, freezing fresh foods
and producing ice cubes.
9 Fridge door
10 Freezer door
DESCRIPTION - 9914779594/C
Control panel
11 2 3
456
7
88
9
10
11 121314
1 Turning ON/OFF the appliance
2 Refrigerator compartment super-cold
function ON/OFF button; Vacation function
(long press)
3 Refrigerator compartment temperature
setting button
4 Freezer compartment temperature setting
button
5 Freezer compartment super-cold function
ON/OFF button; “ECO” function (long
press)
6 Alarm deactivation button.
7 Appliance off indicator.
8 Refrigerator compartment super-cold
function indicator.
9 Refrigerator compartment temperature
display.
10 Vacation function indicator.
11 Alarm warning indicator.
12 Freezer compartment temperature display.
13 “Eco” function ON/OFF indicator.
14 Freezer compartment super-cold function
indicator.
Accessories
Not all accessories are available on
some models.
Shelves
For optimising fridge space and placing
foodstuffs inside the refrigerator compartment.
Fruit and vegetable drawer
For storing fruit and vegetables, maintaining a
constant humidity level.
Refrigerator drawer
The accessories intended to come into
contact with food are made of materials
that comply with the provisions of
current legislation.
Original supplied and optional
accessories can be requested to
Authorised Assistance Centres. Use only
original accessories supplied by the
manufacturer.
10 - DESCRIPTION 914779594/C
Can be used for maintaining freshness and
e
flavour of delicate food such as meat, fish and
lightly frozen foods for a longer time period,
since temperature is kept constantly between
−3°C and +3°C.
Do not place food to be frozen or trays
to make ice in the refrigerator
compartment.
Freezer drawers
For storing frozen or deep-frozen food.
USE
Door balconies and shelves
For storing foodstuffs in small containers. The
shelf in the lower part of the door is useful for
storing bottles.
Preliminary operations
See General safety instructions.
• Remove any protective film from the outside
or inside of the appliance, including
accessories.
• Remove any labels (apart from the technical
data plate) from the accessories and
shelves.
• Remove and wash all the appliance
accessories (see chapter "CLEANING
AND MAINTENANCE").
First use
After installing or repositioning the
appliance, wait at least two hours
before activating it.
1. Keep the ON/OFF button on the control
panel pressed for 3 seconds to switch
on the appliance.
After a power failure, the appliance will
automatically switch on with the
previously selected settings.
The appliance is set by default to +5°C
for the fridge and -18°C for the freezer.
Temperature setting
The refrigerator temperature can be set
between +1°C and +8°C.
The freezer temperature can be set
between -18°C and -24°C.
1. To set the refrigerator temperature, press the
button; press the button for the
freezer.
2. The set temperature will be shown on the
relevant display.
Refrigerator super-cold function
The refrigerator super-cold function is
used for quick cooling of large
quantities of food.
1. Press the button to activate/deactivate
the super-cold function, the relevant
indicator turns on.
2. After 1 hour the super-cold function is
switched off automatically. The refrigerator
compartment returns to its previous setting.
USE - 11914779594/C
Vacation function
Useful during periods of prolonged
absence; the Vacation function allows
you to turn off the refrigerator
compartment while keeping the freezer
active.
1. To activate/deactivate the Vacation
function, keep the button pressed for 3
seconds.
2. The indicator will turn on in the display,
and the temperature will not be shown
.
Remove the stored products from the
refrigerator compartment.
Useful during periods of prolonged
absence; the Vacation function allows
you to turn off the refrigerator
compartment while keeping the freezer
active.
ECO mode
1. To activate/deactivate the ECO mode,
keep the button pressed for 3 seconds.
2. The indicator will turn on in the display.
The appliance will reduce power
3.
consumption after 6 hours since the
activation of the ECO mode.
The ECO mode is deactivated after a
power failure or when the appliance is
switched off.
the appliance, an alarm will sound and the
indicator will turn on in the display. Check food
inside the refrigerator compartment and press
the button to deactivate the alarm.
Using the accessories
Shelves
These can be positioned at different heights on
the guides according to requirements. Each
shelf has a safety fitting to prevent it from being
accidentally removed.
To extract them fully, lift up the rear part (1) and
remove them (2).
Perishable foods should be placed on
the rear part of the shelves where the
temperature is lower.
Door balconies and shelves
Suitable for storing eggs, butter, dairy products,
conserves and other small food packages/
containers. The lower part of the door has a
shelf for bottles. Avoid placing excessively
heavy bottles on the shelf and do not let them
drop onto the bottom when inserting them.
Activation of the super-cold function
(refrigerator/freezer) deactivates the
ECO mode.
Alarm for door open
When the refrigerator compartment door
remains open for a long time, the appliance
sounds to warn the user that door should be
closed; press the button to deactivate the
alarm.
High temperature alarm
If the temperature in the compartment is high
due to prolonged power failure or to a fault of
12 - USE 914779594/C
Fruit and vegetable drawer
Located at the bottom of the refrigerator
compartment, which is fitted with a glass shelf to
cover fresh foods that require constant humidity
e
for optimum storage.
Storing vegetables with high content of
water can generate condensation on
the glass shelf. This is a natural
phenomenon which does not affect the
appliance’s operation in any way.
Freezer drawers
For storing frozen foods and foods to be frozen.
To remove them, pull them towards you and lift
the front part of each drawer.
Using the refrigerator compartment
Arranging food
Arrange food on the various shelves, making
sure that they are wrapped and covered
hermetically. This precaution ensures that:
• the flavour, moisture and freshness of the
foods is preserved;
• any contamination of foods with odours or
tastes from other foods can be avoided;
• the humidity level inside the refrigerator is
prevented from becoming too high as a
result of the normal transpiration of food
(especially fresh fruit and vegetables). In
some operating conditions (rise in ambient
temperature and humidity, more frequent
opening of the door) this might cause
condensation to form on the shelves.
Always allow hot foods and drinks to
cool to room temperature before putting
them in the appliance.
Storage life table
Foodstuff Time
Eggs, smoked meats, marinated foods, cheese
Root vegetables max 8 days
Butter max 7 days
Pastries, fruit, ready meals,
fresh meat
Fish, minced meat, seafood max 1 day
max 10 days
max 2 days
Ice packs
The use of ice packs guarantees reduced
freezing times and improved freezer autonomy
in case of power failure. The ice packs are
removable and can be used safely in the picnic
fridge or in the cooler bag.
Ventilation
Before introducing food into the
appliance, seal it thoroughly.
The forced recirculation air in the appliance is
free of humidity and quickly dries the food
inside.
The inner ventilation system cools food more
rapidly and keeps refrigeration homogeneous
inside the appliance.
Using the freezer compartment
To keep and freeze foods properly:
• pack fruit and vegetables in portions of no
more than 1 kg; meat and fish in portions of
up to 2 kg.
• small packages freeze quickly which means
that the foods' nutritional properties are
preserved better, including after defrosting/
preparation.
• package foods in hermetically sealed
packages, expelling air as much as
possible.
• Do not use paper bags or shopping bags,
use the suitable freezer bags/containers.
Always allow hot foods and drinks to
cool to room temperature before putting
them in the appliance.
USE - 13914779594/C
Frozen foods storage life table
Foodstuff Time
Fruit, beef max 10-12 months
vegetables, veal, poultry max 8-10 months
Game max 6-8 months
Pork max 4-6 months
Mince max 4 months
Bread, desserts, cooked foods,
oily fish
Offal max 2 months
Sausages, lean fish max 1 month
max 3 months
Defrosted foods
Food must be consumed as soon as possible
once defrosted. Freezing foods preserves them,
but it does not destroy any micro-organisms,
which are activated after thawing, damaging
the foods.
Partial defrosting lowers the nutritional value of
the foodstuffs, particularly of fruit, vegetables
and ready meals.
Noises during operation
The refrigerator and freezer compartments are
cooled by means of a compression system. In
order to maintain the preset temperature inside
the refrigerator and freezer compartments, the
compressor comes into operation in response to
the level of cooling required, and may operate
continuously if necessary. When the compressor
starts up a humming sound will be heard,
tending to drop in volume after a few minutes.
Another normal operating noise of the
appliance is a gurgling due to the coolant
flowing through the pipes in the circuit. This noise
is normal and does not indicate an appliance
malfunction. If it becomes too loud, this may
mean that there are other causes. Checks must
then be made to ensure that:
• The refrigerator is properly levelled on the
floor and does not vibrate when the
compressor is in operation: if this is not the
case, adjust the appliance's feet until it is
level;
• The drawers, shelves and trays on the door
are correctly positioned in their holders: if
they are not, put them in correctly;
• Bottles and containers on the various shelves
are stable and not touching each other:
otherwise, the vibration resulting from
compressor operation could generate
noise;
• Do not place the fridge in such a way that it
is in contact with furniture or other household
appliances.
Heated front surface
There is a front surface heating system inside the
cabinet to limit the formation of condensation
around the door seal.
Turning the appliance off
Whenever the appliance is to remain unused for
long periods, it should be switched off.
1. Keep the ON/OFF button on the
control panel pressed for 3 seconds. The
symbols are displayed on the
refrigerator and freezer temperature
displays.
2. Unplug the appliance from the wall socket.
3. Empty the compartments.
4. Once the freezer has fully defrosted, dry
any residual accumulated moisture with a
tea towel.
Leave the door ajar to ensure that
moisture and stagnant air do not cause
unpleasant odours.
Storage advice
General advice
• Always check the expiry date on the food
packaging.
• The foodstuffs must be stored in closed or
pre-packaged containers and must not be
able to emit or absorb moisture and odours.
• Remove perishable products from the
appliance if you are going away for a long
period.
Refrigerator compartment door
• Keep eggs, butter, cheese etc. in the upper
and central parts.
• Keep drinks, bottles, cans etc. in the lower
part.
Refrigerator compartment
• Keep conserves, wine, biscuits etc. in the
upper part.
• Keep dairy products, ready meals, pastries,
fruit juices, beer etc. in the central part.
• Keep meats, cold cuts etc. in the lower part.
• Keep fresh and tropical fruit, vegetables,
carrots, potatoes, onions, etc. in the fruit and
14 - USE 914779594/C
e
vegetable drawer.
Freezer compartment
• The type of food, quantity and date of
freezing should be marked on the
container/packaging.
• Use small containers, if possible already
cold.
• The quantity of fresh foods which can be
frozen at the same time is listed on the
nameplate inside the refrigerator
compartment.
• Use suitable freezer bags, tinfoil, cling-film
for use with food, and freezer containers.
• Do not use paper bags, cellophane for nonfood use, shopping bags or pre-used
freezer bags.
• Avoid frozen food coming into contact with
fresh food to be frozen.
• Keep bagged frozen vegetables, ice, ice
cream etc.
CLEANING AND MAINTENANCE
Cleaning the appliance
See General safety instructions.
A special antibacterial protection on the
appliance's interior walls prevents bacterial
growth and keeps them clean. They must
nevertheless be cleaned regularly in order to
keep them in good condition.
Cleaning the outside of the appliance
• The appliance may be cleaned with water
or alcohol-based liquid detergents (e.g.
window cleaning products).
• Avoid aggressive detergents and rough
sponges in order not to damage the
surfaces.
• Use a soft brush to remove dust and fume
deposits from the condenser on the rear of
the appliance.
• Clean the tank above the compressor.
Cleaning the inside of the appliance
• Clean the inside of the appliance with
diluted liquid detergent and warm water,
adding a little bit of vinegar.
• The door balconies and shelves can be
removed: tap them upwards with your fist,
first on one side and then on the other in the
insertion zone.
• Remove any ice thicker than 3-5 mm. Do not
use sharp objects or spray products.
Defrosting
Occasional presence of frost inside the
freezer compartment is normal.
Do not use electrical appliances (e.g.
hair dryers) or sprays for defrosting, the
plastic parts could be damaged.
Defrosting the refrigerator compartment
The refrigerator/freezer compartment does not
require defrosting, as any ice which forms on the
refrigeration plate will melt when the
compressor is switched off. The defrosting
process is automatic.
Defrost water is channelled directly into the
dedicated pan on the back of the appliance,
which lets it evaporate by means of the heat
generated by the compressor.
Interior lighting
Interior lighting, if damaged, must be repaired
by Technical Service only.
What to do if...
The appliance does not work:
• Make sure that the appliance is plugged in
and that the main switch is turned on.
The compressor starts to function too often or
functions continuously:
• The room temperature is too high.
• The door is being opened too often or for
too long.
• The door is not closing/sealing properly.
• The freezer is loaded with too many fresh
foods.
• Check that sufficient air can circulate around
the sensor on the right-hand side of the
refrigerator compartment.
CLEANING AND MAINTENANCE - 15914779594/C
• Check that the back of the refrigerator is
properly ventilated and that the condenser is
not too dirty.
Excessive ice or condensation has built up inside
the refrigerator compartment:
• The door is being opened too often or for
too long.
• Hot foods have been placed inside the
refrigerator compartment.
• The foodstuffs or containers are in contact
with the rear wall.
• The door seal is damaged or dirty. Clean or
replace it.
The refrigerator compartment is not sufficiently
cold:
• The thermostat is set at too high a
temperature.
• The door is being opened too often or for
too long.
• The door is not closing/sealing properly.
• The room temperature is too high.
The temperature inside the refrigerator
compartment is too cold and the foodstuffs are
freezing:
• The thermostat is set at too low a
temperature.
• Foodstuffs not contained in suitable
containers or bags.
• Fruit and vegetables might be too wet.
• Foodstuffs placed against the rear wall of
the refrigerator compartment.
Temperature inside freezer compartment not
low enough to freeze foods properly:
• The thermostat is set at too high a
temperature.
• The door is being opened too often or for
too long.
• The door is not closing/sealing properly.
• The door seal is damaged or dirty. Clean or
replace it.
• The food to be frozen contains large
quantities of sugar.
Excessive ice has built up inside the freezer
compartment:
•The thermostat is set at too low a
temperature.
• The room temperature is too high.
• The door is being opened too often or for
too long.
• The door is not closing/sealing properly.
• The door seal is damaged or dirty. Clean or
replace it.
• Hot foods have been placed inside the
freezer compartment.
Doors are hard to open just after closing:
• If you attempt to open the door again just
after closing it (especially the freezer door),
considerable strength is required. This is due
to the vacuum created by the cooling of the
warm air which has entered the freezer.
The doors are misaligned:
• Check that the appliance is level.
• Level the appliance using its feet.
INSTALLATION
Electrical connection
See General safety instructions.
General information
• Check the mains characteristics against the
data indicated on the plate. The
identification plate bearing the technical
data, serial number and brand name is
visibly positioned inside the appliance. Do
not remove this plate for any reason.
• Make sure that the plug and socket are of
the same type.
• Avoid using adapters, gang sockets or
shunts as these could cause overheating
and a risk of burns.
16 - INSTALLATION 914779594/C
• The plug must always be accessible when
the appliance is installed.
• Leave the appliance standing vertically for
at least two hours before turning it on for the
first time.
• If it is necessary to replace the power cable,
this must be performed by an authorised
technician from Technical Support Service.
Positioning
See General safety instructions.
Choice of location
Always install the appliance in a dry place with
satisfactory ventilation. Depending on its climate
e
class (stated on the nameplate inside the
refrigerator compartment), the appliance can
be used in different temperature conditions.
• Install the appliance at least 3 cm away
from electrical or gas cookers and at least
30 cm away from combustion heaters or
radiators.
• The appliance must not be installed near
heat sources. If this is not possible, suitable
insulation must be used.
• If installed underneath wall units, at least 5
cm clearance must be left.
• Ensure that the appliance is located with
sufficient space for the door to open and for
the internal drawers and shelves to be
removed, if necessary.
Class Room temperature
SN (Subnormal) + 10°C to + 32°C
N (Normal) + 16°C to + 32°C
ST (Subtropical) + 18°C to + 38°C
T (Tropical) + 18°C to + 43°C
Spacers
To ensure proper cooling of the condenser, the
appliance must not be placed too close to the
wall. To prevent this, the appliance comes
complete with two plastic spacers, which must
be fitted in the rear part of the appliance.
Positioning
Position the appliance on a firm, level surface.
The appliance has two small wheels on the
back to allow it to be moved and positioned
more easily.
In any case, we recommend moving the
appliance very carefully in order to avoid
damaging the floor (especially in the case of
wooden floors).
If the floor is not perfectly level, use the two
adjustable feet on the front part of the
appliance.
Level the appliance horizontally adjusting its
feet.
Lean the appliance slightly towards the
rear part to facilitate proper door
closure.
INSTALLATION - 17914779594/C
In order for the freezer to be installed
601
160,5
100
100
1968 (1963-1980)
30 (25-40)
1085
840,5
601
600
768
20
788
728
correctly, the door must be able to
close properly. Ensure that the door
seals close hermetically, especially at
the corners.
Pressure on the seal
Risk of damage to the appliance
• Do not press, do not tear or detach the seal
from the door.
A few days after installation, check that the initial
level adjustment is still correct. Make sure that
the appliance is still stable and the door seals
still close hermetically when it is in operation and
loaded with food. If necessary, re-adjust the
level and the seals.
Appliance overall dimensions (mm)
18 - INSTALLATION 914779594/C
e
110°
592
601
325
926
1158
592
90°
600
601
163
764
1197
INSTALLATION - 19914779594/C
Loading...
