Smeg CIR597XS, SMEGSTYLEPACK6, CIR597X5 Specifications Sheet

smeg 90cm topmount gas cooktop

ﬁnish satin stainless steel, cast-iron trivets (3) &

burner caps

actual size 885mmW x 500mmD

installation built-in one-piece hob

cutout 844mmW x 482mmD x 30mmH

capacity 44.3mj/hour max over ﬁve–six burners

• ultra-rapid inner, 3.5 mj.hr max

• ultra-rapid outer, 11.5mj/hr max

• combined 15.0mj/hr max

• large rapid burner, 12.0 mj/hr max

• 2x semi-rapid burners, 6.0mj/hr max

each

• 1x auxiliary burner, 4.8 mj/hr max

ignition automatic electronic

safety ame failure device (FFD) tted to each

burner

gas input set for natural gas — regulator supplied

adaptable for ULPG — no regulator required

accessories 3 cast-iron trivets, pot rest, wok stand

options cast-iron griddle plates —

• rectangular, 36cm x 21.5cm, code 9379

• luxury 46cm x 24cm (BB3679)

warranty two years parts and labour

SPACIOUS DESIGN

When space is not restrictive, this wide 90cm hob offers five burners ergonomically positioned for maximum benefit, with the possibility of several styles of cooking at the one time.

Also, cooked or yet to be cooked foods in their utensils are neatly contained within one safe area instead of occupying otherwise precious bench preparation or serving areas.

ULTRA-RAPID DUAL BURNER

Conveniently and ergonomically positioned on the left, this versatile burner, while being designed for perfect wok cooking, also suits the larger stock pots, saucepans and griddles.

AUXILIARY BURNERS

Perfectly situated, centre forward, this small burner enables a very low flame for the gentle simmer required for sauce reductions and low heat cooking and warming. A second auxiliary burner, capable of even lower heat simmering, is the separately controlled burner within the ultra-rapid dual control burner (wok).

ELECTRONIC IGNITION

The cooktop is connected with a power cord of 1.3 metre length to be plugged into a GPO located according to installation needs below the benchline. This supplies a continuous stored charge to spark the gas supply to the individual burner of your choice. Simply depress and turn the control of the desired cooking zone for flame ignition.

LOW MAINTENANCE

The seamless hob design allows for easy wipe-over cleaning and generous catchment of spills and accidental boilovers. The control knobs, also, are removable for cleaning access. Trivets, burner assemblies and wok stand can be washed in warm soapy water.

INSTALLATION

With only a 30mm displacement into the benchtop, the cooktop allows for easy installation underbench of either oven, cupboards or drawers.

CANALI DESIGN

The CIR597XS cooktop fits within a large and comprehensive range of Smeg appliances with complementing aesthetics. The architectural detail of Guido Canali makes possible the matching appliances, including the dishwasher.

FLAME FAILURE

A flame failure device, FFD, with rapid ignition is fitted to each burner. The FFD ensures that should a flame be extinguished accidentally — the gas supply to the specific burner(s) is stopped. For absolute safety, the burner(s) can only be reignited by physically resetting the control knob(s) to the OFF position and then following normal ignition procedure.

ID140510

Code CIR597X

smeg 90cm topmount gas cooktop

885

rapid 12.5mj/hr

semi rapid

6.0mj/hr each

auxiliary 4.8mj/hr

dual control utra rapid (wok) 15mj/hr inner 3.5mj/hr outer 11.5mj/hr

cutout 844mmW x 482mmD x 30mmH

500

gas connection

300

electrical connection

1.3m power cord

overall height above bench height below bench height

width

depth

packaged dimensions

net weight

gross weight

capacity

gas supply

ignition

supplied

100mm 65mm, includes control knobs

35mm

885mm

500mm

980mm x 650mm x 160mm = 0.11m

20.5kg

21.9kg

44.3mj/hour max over ﬁve–six burners

• ultra-rapid inner, 3.5 mj.hr max

• ultra-rapid outer, 11.5mj/hr max

• combined 15.0mj/hr max

• large rapid burner, 12.0 mj/hr max

• 2x semi-rapid burners, 6.0mj/hr max each

• 1x auxiliary burner, 4.8 mj/hr max

SFFD, super ame failure device, tted to each burner

• tted for natural gas regulator — supplied

• adaptable for ULPG — no regulator required

• ½” BSP gas inlet connection

• gas connection located below right-hand

rear corner

automatic electronic, 1.3 metre length power cord with 3-pin 10 plug for direct plugging to a 10 amp GPO

clips, seal, instructions for installation, operation, maintenance

NB drawings are not to scale — they are to assist only

PLAN

WARNING: technical speciﬁcations and product sizes can be varied by the manufacturer, without notice. Cutouts for appliances should only be by physical product measurements. The above information is indicative only.

ID150510

Code CIR597X
