Precautions for Use
1. PRECAUTIONS FOR USE
THIS MANUAL IS AN INTEGRAL PART OF THE APPLIANCE. TAKE GOOD CARE
OF IT AND KEEP IT TO HAND THROUGHOUT THE OVEN'S LIFE CYCLE.
WE URGE YOU TO READ THIS MANUAL AND ALL THE INFORMATION IT
CONTAINS CAREFULLY BEFORE USING THE APPLIANCE. INSTALLATION
MUST BE CARRIED OUT BY QUALIFIED STAFF IN COMPLIANCE WITH THE
RELEVANT REGULATIONS. THIS APPLIANCE IS INTENDED FOR HOUSEHOLD
USE AND COMPLIES WITH THE EEC DIRECTIVES CURRENTLY IN FORCE.
THE APPLIANCE IS BUILT TO PROVIDE THE FOLLOWING FUNCTION:
COOKING AND HEATING FOODS; ALL OTHER USES ARE TO BE
CONSIDERED IMPROPER.
THE MANUFACTURER DECLINES ALL LIABILITY FOR USES OTHER THAN
THOSE STATED ABOVE.
NEVER USE THIS APPLIANCE FOR HEATING ROOMS.
NEVER USE PACKAGING RESIDUES UNATTENDED IN THE HOME.
SEPARATE THE VARIOUS PACKAGING MATERIALS BY TYPE AND CONSIGN
THEM TO THE NEAREST SEPARATE DISPOSAL CENTRE.
THIS APPLIANCE IS MARKED ACCORDING TO THE EUROPEAN DIRECTIVE
2002/96/EC ON WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT (WEEE).
THIS GUIDELINE IS THE FRAME OF A EUROPEAN-WIDE VALIDITY OF
RETURN AND RECYCLING ON WASTE ELECTRICAL AND ELECTRONIC
EQUIPMENT.
NEVER OBSTRUCT THE OPENINGS AND SLITS PROVIDED FOR
VENTILATION AND HEAT DISPERSAL.
THE NAMEPLATE WITH THE TECHNICAL DATA, SERIAL NUMBER AND MARK
ARE IN A VISIBLE POSITION ON THE OVEN DOOR FRAME.
THE NAMEPLATE MUST NEVER BE REMOVED.
NEVER USE METAL SCOURING PADS OR SHARP SCRAPERS;
THEY WILL DAMAGE SURFACES.
USE ORDINARY NON-ABRASIVE PRODUCTS WITH THE AID OF
WOODEN OR PLASTIC UTENSILS IF NECESSARY. RINSE
THOROUGHLY AND DRY WITH A SOFT CLOTH OR CHAMOIS
LEATHER.
DO NOT ALLOW SPILLS OF FOODS WITH HIGH SUGAR CONTENT
(E.G. JAM) TO DRY INSIDE THE OVEN. IF THEY DRY FOR TOO
LONG, THEY MIGHT DAMAGE THE ENAMEL COATING OF THE
INSIDE OF THE OVEN.
31
Page 3
Disposal instructions
2. DISPOSAL INSTRUCTIONS - OUR ENVIRONMENT POLICY
Our products are only packaged using non-pollutant, environment-friendly,
recyclable materials. We urge you to cooperate by disposing of the
packaging properly. Contact your local dealer or the competent local
organisations for the addresses of collection, recycling and disposal
facilities.
Never leave all or part of the packaging lying around. Packaging parts, and
especially plastic bags, may represent a suffocation hazard for children.
Your old appliance must also be disposed of properly.
Important: deliver the appliance to your local organisation authorised to
collect scrapped appliances. Proper disposal allows the intelligent
recovery of valuable materials.
Before scrapping your appliance it is important to remove doors and leave
shelves in position as for use, to ensure that children cannot accidentally
become trapped inside the oven during play. Also, cut the power supply
lead and remove it and the plug.
32
Page 4
Safety Precautions
3. SAFETY PRECAUTIONS
SEE INSTALLATION INSTRUCTIONS FOR SAFETY REGULATIONS FOR
ELECTRIC OR GAS APPLIANCES AND FOR VENTILATION FUNCTIONS.
IN YOUR INTEREST AND TO ENSURE YOUR SAFETY, BY LAW ALL ELECTRIC
APPLIANCES MUST ONLY BE INSTALLED AND SERVICED BY QUALIFIED
STAFF, IN ACCORDANCE WITH THE RELEVANT REGULATIONS.
OUR APPROVED INSTALLATION ENGINEERS GUARANTEE YOU A JOB WELL
DONE. GAS OR ELECTRIC APPLIANCES MUST ALWAYS BE DISCONNECTED
BY SUITABLY SKILLED PEOPLE.
THE PLUG TO BE CONNECTED TO THE POWER SUPPLY LEAD AND THE
RELATIVE SOCKET MUST BE OF THE SAME TYPE AND COMPLY WITH THE
RELEVANT REGULATIONS.
THE POWER SUPPLY SOCKET MUST BE ACCESSIBLE EVEN AFTER THE
APPLIANCE HAS BEEN BUILT-IN.
NEVER DISCONNECT THE PLUG BY PULLING ON THE POWER SUPPLY
LEAD.
THE APPLIANCE MUST BE CONNECTED TO EARTH IN COMPLIANCE WITH
ELECTRICAL SYSTEM SAFETY REGULATIONS.
IMMEDIATELY AFTER INSTALLATION, CARRY OUT A QUICK TEST ON THE
APPLIANCE FOLLOWING THE INSTRUCTIONS PROVIDED LATER IN THIS
MANUAL. IF THE APPLIANCE FAILS TO OPERATE, DISCONNECT IT FROM
THE ELECTRICAL MAINS AND CONTACT YOUR NEAREST SERVICE CENTRE.
NEVER ATTEMPT TO REPAIR THE APPLIANCE.
NEVER PLACE FLAMMABLE OBJECTS IN THE OVEN: IF IT SHOULD
ACCIDENTALLY BE SWITCHED ON, THIS MIGHT CAUSE A FIRE.
THE APPLIANCE BECOMES VERY HOT DURING USE. TAKE CARE NOT TO
TOUCH THE HEATING ELEMENTS INSIDE THE OVEN.
THE USE OF THIS APPLIANCE IS NOT PERMITTED TO PEOPLE (INCLUDING
CHILDREN) OF REDUCED PHYSICAL AND MENTAL ABILITY, OR LACKING IN
EXPERIENCE IN THE USE OF ELECTRICAL APPLIANCES, UNLESS THEY ARE
SUPERVISED OR INSTRUCTED BY ADULTS OR PEOPLE RESPONSIBLE FOR
THEIR SAFETY.
BEFORE THE APPLIANCE IS PUT INTO OPERATION, ALL THE LABELS AND
PROTECTIVE FILMS APPLIED INSIDE OR OUTSIDE MUST BE REMOVED.
AFTER EACH USE, ALWAYS CHECK THAT THE CONTROL KNOBS ARE
TURNED TO 0 (OFF).
The manufacturer declines all responsibility for injury or damage caused by
failure to comply with the above regulations or deriving from tampering with
even just one part of the appliance and the use of non-original spare parts.
33
Page 5
Instructions for the User
4. GET TO KNOW YOUR OVEN
CONTROL PANEL
OVEN LIGHT
HOT AIR FAN (ON SOME
MODELS ONLY)
SHELF AND TRAY RUNNERS
5. BEFORE INSTALLATION
Never leave packaging residues unattended in the home. Separate waste
packaging materials by type and consign them to the nearest separate
disposal centre.
The inside of the appliance should be cleaned to remove all manufacturing
residues. For further information, see "10. CLEANING AND
MAINTENANCE".
When the oven and grill are used for the first time, they should be heated
to the maximum temperature for long enough to burn off any oily residues
left by the manufacturing process, which might contaminate foods with
unpleasant smells.
34
Page 6
Instructions for the User
6. DESCRIPTION OF FRONT PANEL CONTROLS
All the cooker's control and monitoring devices are placed together on the
front panel. The table below provides the key to the symbols used.
35
Page 7
Instructions for the User
FUNCTION SELECTOR KNOB (STATIC OVEN)
The cooking temperature is selected by turning
the knob clockwise to the value required, between
50° and 240/250°C (depending on the model).
For different heating effects, users can switch on only the bottom heating
element ( ) or only the grill element ( ). At the end of the knob
rotation scale, the symbol switches on the rotisserie motor and the grill
top heating element.
THERMOSTAT KNOB (MULTIFUNCTION OVEN)
The cooking temperature is
selected by turning the knob
clockwise to the value required,
between 50° and 240/250°C
(depending on the model).
THERMOSTAT LIGHT
Illuminates to indicate that the oven is heating
up. Goes out when the set temperature is
reached; flashes at regular intervals to indicate
that the temperature inside the oven is being
kept constantly at the set level.
36
Page 8
Instructions for the User
FUNCTION CONTROL KNOB (MULTIFUNCTION OVEN)
Rotate the knob in either direction to select desired function from the
following:
NO FUNCTION SET THAWING
INSIDE LIGHT (NO HEATING
ELEMENTS ON)
TOP+BOTTOM HEATING
ELEMENTS
GRILL ELEMENT IN OPERATION
ALTERNATING WITH BOTTOM
HEATING ELEMENT + FAN
GRILL ELEMENT SMALL GRILL ELEMENT + FAN
BOTTOM HEATING ELEMENT BOTTOM HEATING ELEMENT +
SMALL GRILL ELEMENT TOP+BOTTOM HEATING
TOP+BOTTOM HEATING
ELEMENTS+FAN
GRILL ELEMENT + FAN
FAN HEATING ELEMENT
FAN
ELEMENTS + FAN HEATING
ELEMENT
MINUTE MINDER KNOB
Setting is on a gradual scale and
intermediate positions between the numbers
can be used. The end of cooking buzzer does
not turn off the oven.
37
Page 9
Instructions for the User
TIMER KNOB
Allows selection of manual
cooking or the minute minder
function with the oven
automatically switched off at the
end of the cooking time. If no
cooking duration is selected,
the timer knob must be turned
to the symbol.
To set the cooking duration, turn the knob clockwise to the "90/120" setting
and then set the cooking duration required. Numbers 5 to 90/120
correspond to minutes. Setting is on a gradual scale and intermediate
positions between the numbers shown can be used. At the end of the
programmed cooking time, a buzzer will sound; it will stop automatically
after 4-5 seconds.
IMPORTANT (ON MODELS WITH INTEGRATED CONTROLS)
To access the control knobs they must first be
extracted; simply press them and they will spring
out into the operating position on their own (Fig.
A). They must remain in this position as long as the
oven is in operation as otherwise they may
overheat. To return them to the rest position, press
them right down until the catch engages. To open
the oven door the handle must first be extracted;
simply press it and it will spring out into the right
position (Fig. B). It must remain in this position as
long as the oven is in operation as otherwise it may
overheat.
A)
B)
38
Page 10
Instructions for the User
7. USING THE OVEN
7.1 Precautions and General Advice
When the oven and grill are used for the first time, they should be heated
to the maximum temperature for long enough to burn off any oily residues
left by the manufacturing process, which might contaminate foods with
unpleasant smells.
During cooking, do not cover the bottom of the oven with aluminium or tin
foil, and do not place pans or oven dishes on it; this may damage the
enamel coating. If you wish to use greaseproof paper, position it so that it
does not interfere with the hot air circulation inside the oven.
Oven accessories which may come into contact with foods are made from
materials compliant with EEC directive 89/109 of 21/12/88 and national
relevant regulations.
To avoid unpleasant contact with any steam inside
the oven, open the door in two stages; hold it open
just a little (about 5 cm) for 4-5 seconds, then open
it completely. If you have to check or carry out other
procedures on food during cooking, leave the door
open for as short a time as possible to prevent a
drop in the oven temperature which will impair the
cooking results. When the door is opened the
oven's internal fan cuts out automatically; it starts
up again when the door is closed (Depending on
models).
39
Page 11
Instructions for the User
7.2 Cooling fan system (on some models only)
The appliance is equipped with a
cooling system which comes into
operation when the oven is switched
on. The operation of the fans
generates a normal air flow which
comes out above the door
depending on the model, and may
continue for a short time even after
the oven is switched off.
7.3 Inside light (Depending on models)
Depending on the model, the oven light switches on:
• when the oven door is opened, or;
• when function knob is turned to any function, or;
• when the function knob is turned to the symbol.
40
Page 12
Instructions for the User
8. ACCESSORIES AVAILABLE
The oven is fitted with 4 runners for placing
trays and shelves at different heights.
Shelf: useful to support pans containing the
food for cooking.
Tray grid : for placing on top of a tray for
cooking foods which may drip.
Oven tray: useful for collecting fat from foods
placed on the grid above.
Pastry tray: useful for cooking cakes, pizza
and confectionery.
Roof liner: remove it to simplify cleaning
inside the oven.
Rotisserie shelf (models with static oven
only): for fitting onto the oven runners before
the rotisserie rod is used.
Rotisserie rod (models with static oven
only): useful for cooking chicken, sausages
and all foods which require uniform cooking
over their entire surface.
Chromium-plated gripper: useful for
removing hot shelves and trays.
Not all accessories are provided on some models.
Optional accessories
Original accessories can be ordered through our Authorised Service
Centres.
41
Page 13
Instructions for the User
9. COOKING ADVICE
The oven should always be preheated in fan mode to 30/40°C above the
cooking temperature. This considerably shortens cooking times and
reduces electricity consumption, as well as giving better results.
The oven door must be closed during cooking operations.
9.1 Conventional cooking
FUNCTION SELECTOR
THERMOSTAT
This conventional cooking method, with heat from above and below, is
suitable for cooking food on just one shelf. The oven must be preheated to
the chosen temperature. Do not place the food in the oven until the
thermostat light goes out. Place frozen meat in the oven directly, without
thawing. The only precaution required is to set temperatures about 20°C
lower and cooking times about 1/4 longer than for fresh meat.
50 ÷ 250 °C
9.2 Hot air cooking
FUNCTION SELECTOR
THERMOSTAT
This system is suitable for cooking on several shelves, even with foods of
different kinds (fish, meat, etc.) without cross-contamination of flavours or
smells. The air circulation inside the oven ensures uniform heat
distribution.
Multiple cooking is possible provided that all foods require the same
temperature.
50 ÷ 250 °C
42
Page 14
Instructions for the User
9.3 Delicate cooking
FUNCTION SELECTOR
THERMOSTAT
50 ÷ 250 °C
This type of cooking, for which it is extremely important to preheat the
oven in fan mode, is particularly suitable for finishing cooking of foods
underneath, or for processes which require heat mainly from below. The
tray should be placed on the bottom runner.
9.4 Grilling
FUNCTION SELECTOR
THERMOSTAT
Used for quick browning of foods. For short processes and small amounts,
place the shelf on the fourth runner from the bottom. For longer cooking
times and grilling, place the shelf on lower runners, depending on the size
of the food.
Keep the door closed during grilling. Grilling with the door open may
permanently damage the oven and reduce operating safety.
9.5 Hot air grilling
FUNCTION SELECTOR
THERMOSTAT
200 °C
Allows uniform heat distribution with better penetration to the core of
foods. Foods are lightly browned on the outside but still soft on the inside.
During cooking the oven door must be closed, and the maximum heating
time must not exceed 60 minutes.
43
Page 15
Instructions for the User
Keep the door closed during grilling. Grilling with the door open may
permanently damage the oven and reduce operating safety.
9.6 Thawing
FUNCTION SELECTOR
THERMOSTAT
The air movement provided by the hot air fan alone thaws foods more
quickly. The air circulating inside the oven is at room temperature.
Thawing at room temperature has the advantage that the food's flavour
and appearance are retained intact.
0
44
Page 16
Instructions for the User
9.7 Rotisserie cooking (models with static oven only)
THERMOSTAT
Prepare the rotisserie rod with the food, tightening the screws A of the
prongs. Fit the shelf B onto the third runners from the bottom. Remove the
handle D and position the rotisserie rod so that the pulley E is still in the
guides on the shelf B. Push the shelf B fully in until the tip of the rotisserie
rod enters the hole C on the rear of the oven. Place a drip tray F on the
bottom runner and pour a little water into it to prevent smoke from forming.
It is normal for the thermostat light to switch on and off at regular intervals
during cooking; it indicates that the temperature inside the oven is being
kept constant.
45
Page 17
Instructions for the User
9.8 Recommended cooking tables
Cooking times, for meat in particular, vary depending on the food's
thickness and quality and personal preference. All times are calculated
with the oven preheated.
CONVENTIONAL COOKING
RUNNER POSITION FROM
THE BOTTOM
PA STA
LASAGNE
PASTA BAKES
MEAT
ROAST VEAL
ROAST BEEF
ROAST PORK
CHICKEN
DUCK
GOOSE-TURKEY
RABBIT
LEG OF LAMB
FISH 1 - 2 170 - 200 Depending on size
PIZZA 1 - 2 210 - 240 40 - 45
CONFECTIONERY
PASTRY
SPONGE CAKE
CROISSANTS
FRUIT CAKE
ANGEL CAKE
APPLE CAKE
RICE CAKE
2 - 3
2 - 3
2
2
2
2
2
2
2
2
1 - 2
1 - 2
1 - 2
1 - 2
1 - 2
1 - 2
1 - 2
TEMPERATURE
°C.
210 - 230
210 - 230
170 - 200
210 - 240
170 - 200
170 - 200
170 - 200
140 - 170
170 - 200
170 - 200
170 - 200
165
170 - 200
170 - 200
170
190
180
TIME IN MINUTES
30
40
30 - 40 PER Kg.
30 - 40 PER Kg.
30 - 40 PER Kg.
45 - 60
45 - 60
45 - 60
50 - 60
40 - 50
15 - 20
35 - 45
40 - 45
20 - 30
60
60
60
PORK CHOP
PORK FILLET
FILLET STEAK
SLICED LIVER
VEAL ESCALOPES
HALF CHICKEN
SAUSAGE
MEATBALLS
FISH FILLET
TOASTED SANDWICHES
46
GRILLING
RUNNER POSITION
FROM THE BOTTOM
4
3
3
4
4
3
4
4
4
4
TIME IN MINUTES
1ST SIDE 2ND SIDE
7 - 9
9 - 11
9 - 11
2 - 3
7 - 9
9 - 14
7 - 9
7 - 9
5 - 6
2 - 4
5 - 7
5 - 9
9 - 11
2 - 3
5 - 7
9 - 11
5 - 6
5 - 6
3 - 4
2 - 3
Page 18
Instructions for the User
HOT AIR COOKING
RUNNER POSITION FROM
THE BOTTOM
PASTA
LASAGNE
PASTA BAKES
CREOLE RICE
MEAT
ROAST VEAL
ROAST PORK
ROAST BEEF
FILLET STEAK
ROAST LAMB
RARE ROAST BEEF
ROAST CHICKEN
ROAST DUCK
ROAST TURKEY
ROAST RABBIT
ROAST HARE
ROAST PIGEON
FISH 2 - 3 150 - 170 Depending on size
PIZZA
BREAD
TOASTED SANDWICHES
CONFECTIONERY
SPONGE CAKE
FRUIT CAKE
CROISSANTS
PASTRY
RICE CAKE
APPLE CAKE
ANGEL CAKE
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2 - 3
2 - 3
1 - 2
2 - 3
2 - 3
2 - 3
2 - 3
2 - 3
2 - 3
2 - 3
TEMPERATURE
°C.
190 - 210
190 - 210
190 - 210
150 - 170
150 - 160
160 - 170
160 - 180
130 - 150
170 - 180
170
160 - 170
150 - 160
150 - 160
160 - 170
140 - 170
210 - 240
190 - 210
220 - 240
150 - 160
150 - 160
150 - 160
150 - 160
150 - 160
150 - 160
150 - 160
TIME IN MINUTES
20 - 25
25 - 30
20 - 25
65 - 90
70 - 100
65 - 90
35 - 45
100 - 130
40 - 45
70 - 90
100 - 160
160 - 240
80 - 100
30 - 50
15 - 25
30 - 50
40
7
35 - 45
40 - 50
40 - 60
25
65
65
65
47
Page 19
Instructions for the User
10. CLEANING AND MAINTENANCE
Before carrying out any operations, disconnect the appliance from the
electricity supply.
Never use a jet of steam for cleaning the inside of the oven.
10.1 Cleaning stainless steel
To keep stainless steel in good condition, it must be cleaned regularly,
after each use of the oven, after allowing it to cool.
10.2 Routine daily cleaning
When cleaning and caring for stainless steel surfaces, always use only
specific products which do not contain abrasives or chlorine-based acids.
Instructions for use: pour the product onto a damp cloth and wipe over
the surface, then rinse thoroughly and dry with a soft cloth or chamois
leather.
10.3 Food stains or spills
Never use metal scouring pads or sharp scrapers; they will
damage surfaces.
Use ordinary non-abrasive products with the aid of wooden or
plastic utensils if necessary. Rinse thoroughly and dry with a soft
cloth or chamois leather.
Do not allow spills of foods with high sugar content (e.g. jam) to
dry inside the oven. If they dry for too long, they might damage
the enamel coating of the inside of the oven.
48
Page 20
Instructions for the User
10.4 Cleaning the oven
To keep the oven in good condition, it must be cleaned regularly, after
allowing it to cool down.
Remove all removable parts.
• Clean the oven shelves with hot water and non-abrasive detergents,
rinse and dry.
• For easier cleaning, the door can be removed (see point “10.6
Removing the door”)
10.5 Cleaning the oven with self-cleaning liners (on some
models only)
The oven is fitted with enamelled liners that are continuously self-cleaning.
These liners simplify cleaning of the oven and ensure it continues to
perform well over time.
10.5.1 Using the self-cleaning liners
To keep the inside of the oven clean and free from food residues and
unpleasant smells, it should periodically be operated empty at a
temperature of at least 200° C for a time varying between 30 and 60
minutes. This allows the self-cleaning liners to oxidise any deposits
present, which can then be wiped away with a damp sponge once the
oven has cooled.
10.5.2 Maintenance of self-cleaning liners
The liners should not be cleaned using abrasive creams and ordinary
cleaners. Simply wipe with a damp sponge to avoid damaging the special
enamel coating.
49
Page 21
Instructions for the User
10.5.3 Removing the self-cleaning liners
Remove all accessories from the inside of the oven and proceed as
follows:
1 Remove the side runners (fig.1);
2 Extract the side liners “F” and “G” (fig. 2); 3 Extract the back liner “A” after undoing the threaded ring-nut “C”
(fig. 2);
4 Replace the liners in their original positions.
1) 2)
10.6 Removing the door
10.6.1 Removing doors with mobile hinges
With the door completely open, lift the levers A of the two hinges until they
touch the hinges B and take hold of the two sides of the door with both
hands close to the hinges themselves. Raise the door to an angle of about
45° and remove it. If the hinges have not locked, repeat the operation,
raising the levers A and keeping the door slightly raised. To reassemble, fit
the hinges B into their grooves, then lower the door into place, ensuring
that it remains fitted into the grooves C, then lower the levers A.
50
Page 22
Instructions for the User
10.6.2 Removing doors with pins
Open the door completely and insert the pins (supplied) into the holes
from the inside. Close the door to an angle of about 45° and lift it off. To
reassemble, fit the hinges into their grooves, then lower the door into place
and extract the pins.
10.7 Removing the door glazing
The glass in the door should always be kept thoroughly clean. For easier
cleaning, the door glazing can be fully removed by proceeding as
described below. After blocking the door in position as described in point
"10.6 Removing the door", remove the inner glass using leverage as
shown in figure 1, and release the 4 pins which fix the glass to the door. If
your oven also has the middle glass (figure 2) this can simply be lifted out.
After cleaning, first fit the middle glass (if featured on your oven) and then
replace the inner glass, using the oven door supports as a fulcrum as
shown in figure 3 (see detail A in figure 3. Once the glass has been fitted
on the door, apply a little pressure against the 4 fixing pins.
If the door should close during these operations, simply relock one of the
hinges as described in point "10.6 Removing the door". The panes of
glass can now be washed separately.
51
Page 23
1)
Instructions for the User
2)
52
3)
Use absorbent kitchen roll; remove stubborn dirt with a damp sponge and
ordinary detergent.
Warning: before removing the panes of glass, make sure that the door has
been locked in open position as described in points "10.6 Removing the
door". This operation might have to be repeated during the removal
process if the door is accidentally freed.
To replace the panes of glass in the oven door, follow the instructions
provided in reverse order.
WARNING. Never use the oven without the glass fitted: the outside
surface of the door overheads
Page 24
Instructions for the User
11. EXTRAORDINARY MAINTENANCE
Occasionally, the oven will require minor servicing procedures or the
replacement of parts subject to wear and tear, such as gaskets, light
bulbs, etc. The specific operations for each procedure of this kind are
provided below.
Before carrying out any operation involving access to live parts,
disconnect the appliance from the electricity supply.
11.1 Changing the light bulb
Remove the protective cover A by unscrewing it anti-clockwise and
replace the bulb B with another of the same type (25 W). Replace the
protective cover A.
Use only light bulbs approved for ovens (T 300°C).
8-function model with glass front panel. The standard light bulbs are of
halogen type do not touch them with your fingers, wrap them in an
insulating material. Use only light bulbs available from our Authorised
Service Centres.
11.2 Removing the gasket
To allow thorough cleaning of the oven, the door
gasket can be removed.
Before removing the gasket, remove the oven
door as described above. Once the door has
been removed, lift the tangs at the corners as
shown in the figure.
53
Page 25
Instructions for the Installer
12. INSTALLING THE APPLIANCE
12.1 Electrical connection
The nameplate with the technical data, serial number and mark is in a
visible position on the oven door frame.
The nameplate must never be removed.
The appliance must be connected to earth in compliance with electrical
system safety regulations.
If a permanent connection is used, the appliance's power supply line must
be fitted with an omnipolar breaking device with contact gap of at least
3mm, located in an easily accessible position close to the appliance itself.
If a socket and plug connection is used, check that they are of the same
type. Do not use reducers, adapters or junctions since they may cause
overheating or burns.
Operation at 220-240 V~: use a
H05RR-F three-wire cable (cable
of 3 x 1.5 mm
2
).
54
The earth wire (yellow-green)
must be at least 20 mm longer
than the other wires at the end
for connection to the appliance.
Page 26
Instructions for the Installer
12.2 Positioning the oven
The appliance is designed for building-in to cabinets made from any heatresistant material. Comply with the dimensions shown in figures 1, 2, and
3. When installing under worktops, comply with the dimensions shown in
figure 1-3. When installing under worktops incorporating combined hobs, a
gap of at least 110 mm must be left from any side wall, as shown in figure
1. When installing in tall units, comply with the dimensions shown in figure
1-2, bearing in mind that the top/rear of the unit must have an opening 80-
90 mm deep. Screw the 4 screws A into the inside of the frame (fig. 1). For
installation under tops, make sure that the rear/bottom of the unit has an
opening similar to that shown in figure 1 (ref. B). See the instructions
supplied with the hob for the relative positioning and fixing procedures.
55
Page 27
Instructions for the Installer
Never use the door for leverage when inserting
the oven in the cabinet. Never apply excessive
pressure to the open door.
56
Loading...
