SMC Networks SMC8950EM, SMC8926EM User Manual

INSTALLATION GUIDE
ta
SMC8926EM
SMC8950EM
TigerStack II 10/100/1000 24/48-Port Stackable Layer 3 Gigabit Switch
TigerStack II 10/100/1000 Installation Guide
From SMC's Tiger line of feature-rich workgroup LAN solutions
20 Mason Irvine, CA 92618 Phone: (949) 679-8000
Pub. # 150200000054A
August 2009
E082009-MW-R01
Information furnished by SMC Networks, Inc. (SMC) is believed to be accurate and reliable. However, no responsibility is assumed by SMC for its use, nor for any infringements of patents or other rights of third parties which may result from its use. No license is granted by implication or otherwise under any patent or patent rights of SMC. SMC reserves the right to change specifications at any time without notice.
Copyright © 2009 by
SMC Networks, Inc.
20 Mason
Irvine, CA 92618
All rights reserved. Printed in China
Trademarks: SMC is a registered trademark; and EZ Switch, TigerStack and TigerSwitch are
trademarks of SMC Networks, Inc. Other product and company names are trademarks or registered trademarks of their respective holders.
Warranty and Product Registration
To register SMC products and to review the detailed warranty statement, please refer to the Support Section of the SMC Website at http://www.smc.com.
Compliances and Safety Warnings
FCC - Class A
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.
You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment.
You may use unshielded twisted-pair (UTP) for RJ-45 connections - Category 3 or better for 10 Mbps connections, Category 5 or better for 100 Mbps connections, Category 5, 5e, or 6 for 1000 Mbps connections. For fiber optic connections, you may use 50/125 or 62.5/ 125 micron multimode fiber or 9/125 micron single-mode fiber.
Industry Canada - Class A
This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus as set out in the interference-causing equipment standard entitled “Digital Apparatus,” ICES-003 of the Department of Communications.
Cet appareil numérique respecte les limites de bruits radioélectriques applicables aux appareils numériques de Classe A prescrites dans la norme sur le matériel brouilleur: “Appareils Numériques,” NMB-003 édictée par le ministère des Communications.
i
CE Mark Declaration of Conformance for EMI and Safety (EEC)
This information technology equipment complies with the requirements of the Council Directive 89/336/EEC on the Approximation of the laws of the Member States relating to Electromagnetic Compatibility and 73/23/EEC for electrical equipment used within certain voltage limits and the Amendment Directive 93/68/EEC. For the evaluation of the compliance with these Directives, the following standards were applied:
RFI Emission: • Limit class A according to EN 55022:1998
• Limit class A for harmonic current emission according to EN 61000-3-2/1995
• Limitation of voltage fluctuation and flicker in low-voltage supply system according to EN 61000-3-3/1995
Immunity: • Product family standard according to EN 55024:1998
• Electrostatic Discharge according to EN 61000-4-2:1995 (Contact Discharge: ±4 kV, Air Discharge: ±8 kV)
• Radio-frequency electromagnetic field according to EN 61000-4-3:1996 (80 - 1000 MHz with 1 kHz AM 80% Modulation: 3 V/m)
• Electrical fast tra nsient/burst according to EN 61000-4-4:1995 (AC/DC power supply: ±1 kV, Data/Signal lines: ±0.5 kV)
• Surge immunity test according to EN 61000-4- 5:1995 (AC/DC Line to Line: ±1 kV, AC/DC Line to Earth: ±2 kV)
• Immunity to conducted disturbances, Induce d by radio-frequency fields: EN 61000-4-6:1996 (0.15 - 80 MHz with 1 kHz AM 80% Modulation: 3 V/m)
• Power frequency magnetic field immunity te st according to EN 61000-4-8:1993 (1 A/m at frequency 50 Hz)
• Voltage dips, short interruptions and voltage variations immunity test according to EN 61000-4-11:1994 (>95% Reduction @10 ms, 30% Reduction @500 ms, >95% Reduction @5000 ms)
LVD: • EN 60950-1:2001
Caution: Do not plug a phone jack connector in the RJ-45 port. This may damage this
device.
Attention: Les raccordeurs ne sont pas utilisés pour le système téléphonique!
ii
Safety Compliance
CLASS I
LASER DEVICE
DISPOSITIF LASER
DE CLASSE I
LASERGER DER KLASSE I
ÄT
Warning: Fiber Optic Port Safety
When using a fiber optic port, never look at the transmit laser while it is powered on. Also, never look directly at the fiber TX port and fiber cable ends when they are powered on.
Avertissment: Ports pour fibres optiques - sécurité sur le plan optique
Ne regardez jamais le laser tant qu'il est sous tension. Ne regardez jamais directement le port TX (Transmission) à fibres optiques et les embouts de câbles à fibres optiques tant qu'ils sont sous tension.
Warnhinweis: Faseroptikanschlüsse - Optische Sicherheit
Niemals ein Übertragungslase r betrachten, während dieses eingeschaltet ist. Niemals direkt auf den Faser-TX-Anschluß und auf die Faserkabelenden schauen, während diese eingeschaltet sind.
PSE Alarm
本製品に同梱いたしております電源コードセットは、本製品専用です。本電源コード セットは、本製品以外の製品並びに他の用途でご使用いただくことは出来ません。 製品本体に同梱された電源コードセットを利用し、他製品の電源コードセットを使用し ないで下さい。
Power Cord Safety
Please read the following safety information carefully before installing the switch:
WARNING: Installation and removal of the unit must be carried out by qualified personnel only.
• The unit must be connected to an earthed (grounded) outlet to comply with international safety standards.
• Do not connect the unit to an A.C. outlet (power supply) without an earth (ground) connection.
• The appliance coupler (the connector to the unit and not the wall plug) must have a configuration for mating with an EN 60320/IEC 320 appliance inlet.
• The socket outlet must be near to the unit and easily accessible. You can only remove power from the unit by disconnecting the power cord from the outlet.
• This unit operates under SELV (Safety Extra Low Voltage) conditions according to IEC 60950. The conditions are only maintained if the equipment to which it is connected also operates under SELV conditions.
France and Peru only
This unit cannot be powered from IT† supplies. If your supplies are of IT type, this unit must be powered by 230 V (2P+T) via an isolation transformer ratio 1:1, with the secondary connection point labelled Neutral, connected directly to earth (ground).
Impédance à la terre
iii
Important! Before making connections, make sure you have the correct cord set. Check it (read the label on the cable) against the following:
Power Cord Set
U.S.A. and Canada The cord set must be UL-approved and CSA certified.
The minimum specifications for the flexible cord are:
- No. 18 AWG - not longer than 2 meters, or 16 AWG.
- Type SV or SJ
- 3-conductor The cord set must have a rated current capacity of at least 10 A The attachment plug must be an earth-grounding type with NEMA
5-15P (15 A, 125 V) or NEMA 6-15P (15 A, 250 V) configuration.
Denmark The supply plug must comply with Sect ion 107-2-D1, Standard
Switzerland The supply plug must comply with SEV/ASE 10 11. U.K. The supply plug must comply with BS1363 (3-pin 13 A) and be fitted
Europe The supply plug must comply with CEE7/7 (“SCHUKO”).
DK2-1a or DK2-5a.
with a 5 A fuse which complies with BS1362. The mains cord must be <HAR> or <BA SEC> marked and be of type
HO3VVF3GO.75 (minimum).
The mains cord must be <HAR> or <BA SEC> marked and be of type HO3VVF3GO.75 (minimum).
IEC-320 receptacle.
Veuillez lire à fond l'information de la sécurité suivante avant d'installer le Switch:
AVERTISSEMENT: L’installation et la dépose de ce groupe doivent être confiés à un personnel qualifié.
• Ne branchez pas votre appareil sur une prise secteur (alimentation électrique) lorsqu'il n'y a pas de connexion de mise à la terre (mise à la masse).
• Vous devez raccorder ce groupe à une sortie mise à la terre (mise à la masse) afin de respecter les normes internationales de sécurité.
• Le coupleur d’appareil (le connecteur du groupe et non pas la prise murale) doit
respecter une configuration qui permet un branchement sur une entrée d’appareil EN 60320/IEC 320.
• La prise secteur doit se trouver à proximité de l’appareil et son accès doit être facile.
Vous ne pouvez mettre l’appareil hors circuit qu’en débranchant son cordon électrique au niveau de cette prise.
• L’appareil fonctionne à une tension extrêmement basse de sécurité qui est conforme à
la norme IEC 60950. Ces conditions ne sont maintenues que si l’équipement auquel il est raccordé fonctionne dans les mêmes conditions.
iv
France et Pérou uniquement:
Ce groupe ne peut pas être alimenté par un dispositif à impédance à la terre. Si vos alimentations sont du type impédance à la terre, ce groupe doit être alimenté par une tension de 230 V (2 P+T) par le biais d’un transformateur d’isolement à rapport 1:1, avec un point secondaire de connexion portant l’appellation Neutre et avec raccordement direct à la terre (masse).
Cordon électrique - Il doit être agréé dans le pays d’utilisation
Etats-Unis et Canada:
Danemark: La prise mâle d’alimentation doit respecter la section 107-2 D1 de la
Suisse: La prise mâ le d’ al imenta tion doit resp ecte r la n orme SEV/A SE 1011 . Europe La prise secteur doit être conforme aux normes CEE 7/7 (“SCHUKO”)
Le cordon doit avoir reçu l’homologation des UL et un certificat de la CSA.
Les spe'cifications minimales pour u n cable flexible sont AWG No. 18, ouAWG No. 16 pour un cable de longueur infe'rieure a` 2 me'tres.
- type SV ou SJ
- 3 conducteurs Le cordon doit être en mesure d’acheminer un courant nominal d’au
moins 10 A. La prise femelle de branchement do it être du type à mise à la terre
(mise à la masse) et respecter la conf iguration NEMA 5-15P (15 A, 125 V) ou NEMA 6-15P (15 A, 250 V).
norme DK2 1a ou DK2 5a.
LE cordon secteur doit porter la mention <HAR> ou <BASEC> et doit être de type HO3VVF3GO.75 (minimum).
Bitte unbedingt vor dem Einbauen des Switches die folgenden Si­cherheitsanweisungen durchlesen:
WARNUNG: Die Installation und der Ausbau des Geräts darf nur durch Fachpersonal erfolgen.
• Das Gerät sollte nicht an eine ungeerdete Wechselstromsteckdose angeschlossen werden.
• Das Gerät muß an eine geerdete Steckdose angeschlossen werden, welche die internationalen Sicherheitsnormen erfüllt.
• Der Gerätestecker (der Anschluß an das Gerät, nicht der Wandsteckdosenstecker) muß einen gemäß EN 60320/IEC 320 konfigurierten Geräteeingang haben.
• Die Netzsteckdose muß in der Nähe des Geräts und leicht zugänglich sein. Die Stromversorgung des Geräts kann nur durch Herausziehen des Gerätenetzkabels aus der Netzsteckdose unterbrochen werden.
• Der Betrieb dieses Geräts erfolgt unter den SELV-Bedingungen (Sicherheitskleinstspannung) gemäß IEC 60950. Diese Bedingungen sind nur gegeben, wenn auch die an das Gerät angeschlossenen Geräte unter SELV-Bedingungen betrieben werden.
v
Stromkabel
Schweiz Dieser Stromstecker muß die SEV/ASE 1011Bestimmungen ein-
Europe Das Netzkabel muß vom Typ HO3VVF3GO.75 (Mindestanforderung)
. Dies muss von dem Land, in dem es benutzt wird geprüft werden:
halten.
sein und die Aufschrift <HAR> oder <BASEC> trag en. Der Netzstecker muß die Norm CEE 7/7 erfüllen (”SCHUKO”).
Warnings and Cautionary Messages
Warning: This product does not contain any serviceable user parts. Warning: Installation and removal of the unit must be carried out by qualified
personnel only.
Warning: When connecting this device to a power outlet, connect the field ground lead
Warning: This switch uses lasers to transmit signals over fiber optic cable. The lasers
Caution: Wear an anti-static wrist strap or take other suitable measures to prevent
Caution: Do not plug a phone jack connector in the RJ-45 port. This may damage this
Caution: Use only twisted-pair cables with RJ-45 connectors that conform to FCC
on the tri-pole power plug to a valid earth ground line to prevent electrical hazards.
are compliant with the requirements of a Class 1 Laser Product and are inherently eye safe in normal operation. However, you should never look directly at a transmit port when it is powered on.
electrostatic discharge when handling this equipment.
device. Les raccordeurs ne sont pas utilisé pour le système téléphonique!
standards.
Environmental Statement
The manufacturer of this product endeavours to sustain an environmentally-friendly policy throughout the entire production process. This is achieved though the following means:
• Adherence to national legislation and regulations on environmental production standards.
• Conservation of operational resources.
• Waste reduction and safe disposal of all harmful un-recyclable by-products.
• Recycling of all reusable waste content.
• Design of products to maximize recyclables at the end of the product’s life span.
• Continual monitoring of safety standards.
End of Product Life Span
This product is manufactured in such a way as to allow for the recovery and disposal of all included electrical components once the product has reached the end of its life.
Manufacturing Materials
There are no hazardous nor ozone-depleting materials in this product.
vi
Documentation
All printed documentation for this product uses biodegradable paper that originates from sustained and managed forests. The inks used in the printing process are non-toxic.
vii
About This Guide
Purpose
This guide details the hardware features of this device, including the physical and performance-related characteristics, and how to install it.
Audience
The guide is intended for use by network administrators who are responsible for installing and setting up network equipment; consequently, it assumes a basic working knowledge of LANs (Local Area Networks).
Conventions
The following conventions are used throughout this guide to show information: Note: Emphasizes important information or calls your attention to related features or
instructions.
Caution: Alerts you to a potential hazard that could cause loss of data, or damage the
system or equipment.
Warning: Alerts you to a potential hazard that could cause personal injury.
Related Publication
The following publication gives specific information on how to operate and use the management functions of the switch:
The Management Guide
Also, as part of the switch’s software, there is an online web-based help that describes all management related features.s
Revision History
This section summarizes the changes in each revision of this guide.
August 2009 Revision
This is the first revision of this guide.
viii
Contents
Chapter 1: Introduction 1-1
Overview 1-1
Switch Architecture 1-2 Network Management Options 1-2
Description of Hardware 1-3
10/100/1000BASE-T Ports 1-3 SFP Slots 1-3 10 Gigabit Ethernet Module Slots 1-3 Stacking Ports 1-3 Port and System Status LEDs 1-3 Optional Redundant Power Supply 1-5 Power Supply Sockets 1-5 Optional Media Extender Modules 1-6 Extender Module LEDs 1-6
Features and Benefits 1-7
Connectivity 1-7 Expandability 1-7 Performance 1-7 Management 1-7
Chapter 2: Network Planning 2-1
Introduction to Switching 2-1 Application Examples 2-2
Collapsed Backbone 2-2 Network Aggregation Plan 2-3 Remote Connections with Fiber Cable 2-4 Making VLAN Connections 2-5 Using Layer 3 Routing 2-6
Application Notes 2-7
Chapter 3: Installing the Switch 3-1
Selecting a Site 3-1 Ethernet Cabling 3-1 Equipment Checklist 3-2
Package Contents 3-2 Optional Rack-Mounting Equipment 3-2
Mounting 3-3
Rack Mounting 3-3
ix
Contents
Desktop or Shelf Mounting 3-4 Installing an Optional Module into the Switch 3-5 Installing an Optional SFP Transceiver 3-6 Connecting Switches in a Stack 3-7
Stacking Topologies 3-8 Connecting to a Power Source 3-8 Connecting to the Console Port 3-9
Wiring Map for Serial Cable 3-9
Chapter 4: Making Network Connections 4-1
Connecting Network Devices 4-1 Twisted-Pair Devices 4-1
Cabling Guidelines 4-1
Connecting to PCs, Servers, Hubs and Switches 4-2
Network Wiring Connections 4-2 Fiber Optic SFP Devices 4-3 10 Gbps Fiber Optic Connections 4-4 Connectivity Rules 4-6
1000BASE-T Cable Requirements 4-6
10 Gbps Ethernet Collision Domain 4-6
1000 Mbps Gigabit Ethernet Collision Domain 4-7
100 Mbps Fast Ethernet Collision Domain 4-7
10 Mbps Ethernet Collision Domain 4-7 Cable Labeling and Connection Records 4-8
Appendix A: Troubleshooting A-1
Diagnosing Switch Indicators A-1
Diagnosing Power Problems with the LEDs A-1 Power and Cooling Problems A-2 Installation A-2 In-Band Access A-2 Stack Troubleshooting A-3
Appendix B: Cables B-1
Twisted-Pair Cable and Pin Assignments B-1
10BASE-T/100BASE-TX Pin Assignments B-1
Straight-Through Wiring B-2
Crossover Wiring B-2
1000BASE-T Pin Assignments B-3
Cable Testing for Existing Category 5 Cable B-4
Adjusting Existing Category 5 Cabling to Run 1000BASE-T B-4 Fiber Standards B-4
x
Contents
Appendix C: Specifications C-1
Physical Characteristics C-1
Switch Features C-3
Management Features C-3
Standards C-3
Compliances C-4
Extender Modules C-4
10GBASE Extender Module (XFP) C-4
Glossary
Index
xi
Tables
Table 1-1 Port Status LEDs 1-4 Table 1-2 System Status LEDs 1-4 Table 1-3 Supported XFP Transceivers 1-6 Table 1-4 Module LEDs 1-6 Table 3-1 Serial Cable Wiring 3-9 Table 4-1 Maximum 10GBASE-SR 10 Gigabit Ethernet Cable Length 4-6 Table 4-2 Maximum 10GBASE-LR 10 Gigabit Ethernet Cable Length 4-6 Table 4-3 Maximum 10GBASE-ER 10 Gigabit Ethernet Cable Length 4-6 Table 4-4 Maximum 1000BASE-T Gigabit Ethernet Cable Length 4-7 Table 4-5 Maximum 1000BASE-SX Gigabit Ethernet Cable Length 4-7 Table 4-6 Maximum 1000BASE-LX Gigabit Ethernet Cable Length 4-7 Table 4-7 Maximum 1000BASE-LH Gigabit Ethernet Cable Length 4-7 Table 4-8 Maximum Fast Ethernet Cable Length 4-7 Table 4-9 Maximum Ethernet Cable Length 4-7 Table A-1 Troubleshooting Chart A-1 Table A-2 Power/RPS LEDs A-1 Table B-1 10/100BASE-TX MDI and MDI-X Port Pinouts B-2 Table B-2 1000BASE-T MDI and MDI-X Port Pinouts B-3 Table B-3 Fiber Standards B-4
xii
Figures
Figure 1-1 Front Panels 1-1 Figure 1-2 Rear Panel 1-2 Figure 1-3 Port LEDs 1-4 Figure 1-4 System LEDs 1-4 Figure 1-5 Power Supply Sockets 1-5 Figure 1-6 Single-Port 10GBASE Module (XFP) 1-6 Figure 2-1 Collapsed Backbone 2-2 Figure 2-2 Network Aggregation Plan 2-3 Figure 2-3 Remote Connections with Fiber Cable 2-4 Figure 2-4 Making VLAN Connections 2-5 Figure 2-5 IP Routing for Unicast Traffic 2-6 Figure 3-1 RJ-45 Connections 3-2 Figure 3-2 Attaching the Brackets 3-3 Figure 3-3 Installing the Switch in a Rack 3-4 Figure 3-4 Attaching the Adhesive Feet 3-4 Figure 3-5 Installing an Optional Module 3-5 Figure 3-6 Inserting an SFP Transceiver into a Slot 3-6 Figure 3-7 Making Stacking Connections 3-7 Figure 3-8 Power Socket 3-8 Figure 3-9 Serial Port (RJ-45) Pin-Out 3-9 Figure 4-1 Making Twisted-Pair Connections 4-2 Figure 4-2 Network Wiring Connections 4-3 Figure 4-3 Making Connections to SFP Transceivers 4-4 Figure 4-4 Connecting to an XFP Transceiver 4-5 Figure B-1 RJ-45 Connector Pin Numbers B-1 Figure B-2 Straight-through Wiring B-2 Figure B-3 Crossover Wiring B-3
xiii
Figures
xiv

Chapter 1: Introduction

Overview

The SMC8926EM and SMC8950EM are intelligent multilayer switches (Layer 2, 3) with 24/48 10/100/1000BASE-T ports, four of which are combination ports
*
that are shared with four SFP transceiver slots (see Figure 1-1, Port s 21-24/45-48). The rear panel provides two slots for single-port 10 Gigabit Ethernet hot-swappable expansion modules, and two stacking ports. Units can be stacked up to eight high through the built-in stacking ports that provide a 50 Gbps stack backplane.
The switches include an SNMP-based management agent embedded on the main board, which supports both in-band and out-of-band access for managing the stack.
These switches can easily tame your network with full support for Spanning Tree Protocol, Multicast Switching, Virtual LANs, and IP routing. It brings order to poorly performing networks by segregating them into separate broadcast domains with IEEE 802.1Q compliant VLANs, empowers multimedia applications with multicast switching and CoS services, and eliminates conventional router bottlenecks.
These switches can be used to augment or completely replace slow legacy routers, off-loading local IP traffic to release valuable resources for non-IP routing or WAN access. With wire-speed performance for Layer 2 and Layer 3, these switches can significantly improve the throughput between IP segments or VLANs.
SMC8950EM
SMC8926EM
5
1
4
7
3
6
2
8910
Port Status LEDs
10/100/1000 Mbps RJ-45 Ports
15
11
14
17
13
18 19 20
16
12
21 222324
21 22 23 24
21 22 23 24
System Status LEDs
Stack
Stack
Master
Power
Master
Stack
Master
Stack ID
RPU
Link
Select
Diag
Module
Stack ID
Stack ID
Console
Serial Console Port
SFP Slots
ES4626H
Figure 1-1 Front Panels
* If an SFP transceiver is plugged in, the corresponding RJ-45 port is disabled for ports 21-24
on SMC8926EM or ports 45-48 on SMC8950EM.
1-1
Introduction
Stacking Ports
Power Socket
Redundant PowerSocket
ModuleSlots
1
Figure 1-2 Rear Panel

Switch Architecture

These Gigabit Ethernet switches employ a wire-speed, non-blocking swit ching fabric. This permits simultaneous wire-speed transport of multiple packets at low latency on all ports. The switches also feature full-duplex capability on all ports, which effectively doubles the bandwidth of each connection.
For communications between different VLANs, these switches use IP routing. For communications within the same VLAN, they use store-and-forward switching to ensure maximum data integrity. With store-and-forward switching, the entire packet must be received into a buffer and checked for validity befo re bein g forwarded . Th is prevents errors from being propagated throughout the network.
These switches include built-in stacking ports that enable up to eight units to be connected together through a 48 Gbps stack backplane. The switch stack can be managed from a master unit using a single IP address.
These switches also include two slots on the rear panel for slide-in single-port 10GBASE modules with XFP transceivers.

Network Management Options

These switches contain a comprehensive array of L EDs for “at-a-gl ance” moni toring of network and port status. They also include a management agen t that allows you to configure or monitor the switch using its embedded management software, or via SNMP applications. To manage each switch, you can make a direct connection to the console port (out-of-band), or you can manage the switches through a network connection (in-band) using Telnet, the on-boa rd web agent, or SNMP-based net work management software.
For a detailed description of both switches’ advanced features, refer to the Gigabit Ethernet Switch Management Guide.
1-2
Chapter 1: Introduction
Serial Console Port
10/100/1000 Mbps RJ-45 Ports

SFP Slots

Port Status LEDs
System Status LEDs
Stack ID
SMC8950EM
SMC8926EM
1
2
3
4
5
6
7
8910
11
12
13
14
15
16
17
18 19 20
21 222324
21 22 23 24
Stack Master
Power
Module
Diag
Stack Link
Stack ID
RPU
ES4626H
Master Select
Console
Stack ID
Stack Master
21 22 23 24
Overview
The SMC8926EM and SMC8950EM are intelligent multilayer switches (Layer 2, 3) with 24/48 10/100/1000BASE-T ports, four of which are combination ports
*
that are shared with four SFP transceiver slots (see Figure 1-1, Port s 21-24/45-48). The rear panel provides two slots for single-port 10 Gigabit Ethernet hot-swappable expansion modules, and two stacking ports. Units can be stacked up to eight high through the built-in stacking ports that provide a 48 Gbps stack backplane.
The switches include an SNMP-based management agent embedded on the main board, which supports both in-band and out-of-band access for managing the stack.
These switches can easily tame your network with full support for Spanning Tree Protocol, Multicast Switching, Virtual LANs, and IP routing. It brings order to poorly performing networks by segregating them into separate broadcast domains with IEEE 802.1Q compliant VLANs, empowers multimedia applications with multicast switching and CoS services, and eliminates conventional router bottlenecks.
These switches can be used to augment or completely replace slow legacy routers, off-loading local IP traffic to release valuable resources for non-IP routing or WAN access. With wire-speed performance for Layer 2 and Layer 3, these switches can significantly improve the throughput between IP segments or VLANs.
Figure 1-1 Front Panels
* If an SFP transceiver is plugged in, the corresponding RJ-45 port is disabled for ports 21-24
on SMC8926EM or ports 45-48 on SMC8950EM.
1-1
Introduction
Port Status LEDs
1
2
3
4
5
6
7
8910
11
12
13
14
15
24
Stack
Master
Power
Module
Diag
Stack
Link
Stack ID
RPU
Master Select
Console
Stack ID
Stack
Master
24
System Status LEDs
1
LED Condition Status
Link/ Activity/
Speed
On/Flashing Amber Port has a valid link at 10 or 100 Mbps. Flashing indicates activity . On/Flashing Green Port has a valid link at 1000 Mbps. Flashing indicates activity. Off The link is down.
Figure 1-3 Port LEDs
Table 1-1 Port Status LEDs
Figure 1-4 System LEDs
Table 1-2 System Status LEDs
LED Condition Status
Power Green Internal power is operating normally.
Amber Internal power supply failure. Off Power off or failure.
Diag Flashing Green System self-diagnostic test in progress.
RPS Green Redundant power supply is receiving power.
Green System self-diagnostic test successfully completed. Amber System self-diagnostic test has detected a fault.
Amber Fault in redundant power supply , including thermal or fan failure.
1-4
Off Redundant power supply is off or not plugged in.
Description of Hardware
Power Socket
Redundant Power Socket
Table 1-2 System Status LEDs (Continued)
LED Condition Status
Stack Master Green Switch is the Master unit of the stack. State may include t opo logy
Flashing Green Switch is the Master unit of the stack, system is initializing. Amber Switch is operating as a Slave unit in the stack. Flashing Amber System in Master arbitration/election state. Off System in standalone mode.
Stack Link Green Uplink and downlink operating normally.
Flashing Green Uplink has failed. Flashing Amber Downlink has failed. Off No stacking link present.
Module Green An expansion module is installed and operating normally.
Amber An expansion module is installed but has failed. Off There is no module installed.
Stack ID 1-8 Indicates the switch stack ID.
Off In standalone mode.
discovery, IP assignmen t, or normal operations.
The Master unit is numbered 1. (Note that If the master unit fails and a backup unit takes over, the stack IDs do not change.)
Slave units are numbered 2-8.
1

Optional Redundant Power Supply

The switch supports an optional Redundant Power Supply (RPS), that can supply power to the switch in the event the internal power supply fails.

Power Supply Sockets

There are two power sockets on the rear panel of each switch. The standard power socket is for the AC power cord. The socket labeled “RPS” is for the optional Redundant Power Supply (RPS).
Figure 1-5 Power Supply Sockets
1-5
Loading...
+ 53 hidden pages
