SMC Networks SMC8724M, SMC8748M User Manual

Download

TigerStack 10G

Gigabit Ethernet Switch

◆ 24/48 auto-MDI/MDI-X 10/100/1000BASE-T ports

◆ 4 ports shared with 4 SFP transceiver slots

◆ Non-blocking switching architecture

◆ Support for a redundant power unit

◆ Spanning Tree Protocol, RSTP, and MSTP

◆ Up to 32 LACP or static 8-port trunks

◆ Layer 2/3/4 CoS support through eight priority queues

◆ Layer 3/4 traffic priority with IP Precedence and IP DSCP

◆ Full support for VLANs with GVRP

◆ IGMP multicast filtering and snooping

◆ Support for jumbo frames up to 9 KB

◆ Manageable via console, Web, and SNMP/RMON

Management Guide

SMC8724M SMC8748M

TigerStack 10G Management Guide

From SMC’s Tiger line of feature-rich workgroup LAN solutions

38 Tesla Irvine, CA 92618 Phone: (949) 679-8000

October 2004

Pub. # 150200049000A
