SMC Networks SMC EZ Card 1000 SMC9452TX, 9452TX - annexe 1 User Manual

EZ Card 1000

1000 Mbps Gigabit Ethernet
PCI Network Card

High performance for instant access to network resources
Delivers 2 Gbps of bandwidth over installed
Category 5 UTP
Support for 32-bit PCI bus up to 66 MHz
Full- and half-duplex operation at 1000, 100, and
10 Mbps
IP, TCP and UDP checksum off-loading capability to reduce
CPU overhead

User Guide

SMC9452TX

6 Hughes
Irvine, CA 92618
Phone: [phone]

EZ Card 1000
User Guide

From SMC’s EZ line of low-cost workgroup LAN solutions

June 2001

Pub. # 150000003500A

Information furnished by SMC Networks, Inc. (SMC) is believed to
be accurate and reliable. However, no responsibility is assumed by
SMC for its use, nor for any infringements of patents or other rights
of third parties which may result from its use. No license is granted
by implication or otherwise under any patent or patent rights of
SMC. SMC reserves the right to change specifications at any time
without notice.

Copyright © 2001 by

SMC Networks, Inc.

6 Hughes

Irvine, CA 92618

All rights reserved. Printed in Taiwan

Trademarks:

SMC is a registered trademark; and EZ Card, EtherPower and SuperDisk are trademarks of SMC
Networks, Inc. Other product and company names are trademarks or registered trademarks of
their respective holders.

i

Limited Warranty

Limited Warranty Statement: SMC Networks, Inc. (“SMC”) warrants its products to
be free from defects in workmanship and materials, under normal use and service,
for the applicable warranty term. All SMC products carry a standard 90-day limited
warranty from the date of purchase from SMC or its Authorized Reseller. SMC may,
at its own discretion, repair or replace any product not operating as warranted with
a similar or functionally equivalent product, during the applicable warranty term.
SMC will endeavor to repair or replace any product returned under warranty within
30 days of receipt of the product.

The standard limited warranty can be upgraded to a Limited Lifetime* warranty by
registering new products within 30 days of purchase from SMC or its Authorized
Reseller. Registration can be accomplished via the enclosed product registration
card or online via the SMC web site. Failure to register will not affect the standard
limited warranty. The Limited Lifetime warranty covers a product during the Life of
that Product, which is defined as the period of time during which the product is an
‘Active’ SMC product. A product is considered to be ‘Active’ while it is listed on the
current SMC price list. As new technologies emerge, older technologies become
obsolete and SMC will, at its discretion, replace an older product in its product line
with one that incorporates these newer technologies. At that point, the obsolete
product is discontinued and is no longer an ‘Active’ SMC product. A list of
discontinued products with their respective dates of discontinuance can be found at
http://www.smc.com/smc/pages_html/support.html.

All products that are replaced become the property of SMC. Replacement products
may be either new or reconditioned. Any replaced or repaired product carries
either a 30-day limited warranty or the remainder of the initial warranty, whichever
is longer. SMC is not responsible for any custom software or firmware,
configuration information, or memory data of Customer contained in, stored on, or
integrated with any products returned to SMC pursuant to any warranty. Products
returned to SMC should have any customer-installed accessory or add-on
components, such as expansion modules, removed prior to returning the product
for replacement. SMC is not responsible for these items if they are returned with the
product.

Customers must contact SMC for a Return Material Authorization number prior to
returning any product to SMC. Proof of purchase may be required. Any product
returned to SMC without a valid Return Material Authorization (RMA) number
clearly marked on the outside of the package will be returned to customer at
customer’s expense. For warranty claims within North America, please call our
toll-free customer support number at [phone]. Customers are responsible for
all shipping charges from their facility to SMC. SMC is responsible for return
shipping charges from SMC to customer.

L

IMITED WARRANTY

ii

WARRANTIES EXCLUSIVE: IF AN SMC PRODUCT DOES NOT OPERATE AS
WARRANTED ABOVE, CUSTOMER'S SOLE REMEDY SHALL BE REPAIR OR
REPLACEMENT OF THE PRODUCT IN QUESTION, AT SMC'S OPTION. THE
FOREGOING WARRANTIES AND REMEDIES ARE EXCLUSIVE AND ARE IN LIEU
OF ALL OTHER WARRANTIES OR CONDITIONS, EXPRESS OR IMPLIED, EITHER
IN FACT OR BY OPERATION OF LAW, STATUTORY OR OTHERWISE, INCLUDING
WARRANTIES OR CONDITIONS OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE. SMC NEITHER ASSUMES NOR AUTHORIZES ANY OTHER
PERSON TO ASSUME FOR IT ANY OTHER LIABILITY IN CONNECTION WITH
THE SALE, INSTALLATION, MAINTENANCE OR USE OF ITS PRODUCTS. SMC
SHALL NOT BE LIABLE UNDER THIS WARRANTY IF ITS TESTING AND
EXAMINATION DISCLOSE THE ALLEGED DEFECT IN THE PRODUCT DOES NOT
EXIST OR WAS CAUSED BY CUSTOMER’S OR ANY THIRD PERSON’S MISUSE,
NEGLECT, IMPROPER INSTALLATION OR TESTING, UNAUTHORIZED ATTEMPTS
TO REPAIR, OR ANY OTHER CAUSE BEYOND THE RANGE OF THE INTENDED
USE, OR BY ACCIDENT, FIRE, LIGHTNING, OR OTHER HAZARD.

LIMITATION OF LIABILITY: IN NO EVENT, WHETHER BASED IN CONTRACT OR
TORT (INCLUDING NEGLIGENCE), SHALL SMC BE LIABLE FOR INCIDENTAL,
CONSEQUENTIAL, INDIRECT, SPECIAL, OR PUNITIVE DAMAGES OF ANY KIND,
OR FOR LOSS OF REVENUE, LOSS OF BUSINESS, OR OTHER FINANCIAL LOSS
ARISING OUT OF OR IN CONNECTION WITH THE SALE, INSTALLATION,
MAINTENANCE, USE, PERFORMANCE, FAILURE, OR INTERRUPTION OF ITS
PRODUCTS, EVEN IF SMC OR ITS AUTHORIZED RESELLER HAS BEEN ADVISED
OF THE POSSIBILITY OF SUCH DAMAGES.

SOME STATES DO NOT ALLOW THE EXCLUSION OF IMPLIED WARRANTIES OR
THE LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR
CONSUMER PRODUCTS, SO THE ABOVE LIMITATIONS AND EXCLUSIONS MAY
NOT APPLY TO YOU. THIS WARRAN’Y GIVES YOU SPECIFIC LEGAL RIGHTS,
WHICH MAY VARY FROM STATE TO STATE. NOTHING IN THIS WARRANTY
SHALL BE TAKEN TO AFFECT YOUR STATUTORY RIGHTS.

* SMC will provide warranty service for one year following discontinuance from the
active SMC price list. Under the limited lifetime warranty, internal and external
power supplies, fans, and cables are covered by a standard one-year warranty from
date of purchase.

SMC Networks, Inc.

SMC Networks, Inc.

6 Hughes

Irvine, CA 92618

iii

C

OMPLIANCES

FCC - Class B

This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide rea­sonable protection against harmful interference in a residential installation. This equip­ment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with instructions, may cause harmful interference to radio communi­cations. However, there is no guarantee that the interference will not occur in a particu­lar installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:

• Reorient the receiving antenna

• Increase the separation between the equipment and receiver

• Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected

• Consult the dealer or an experienced radio/TV technician for help

C

OMPLIANCES

iv

EC Conformance Declaration - Class B

SMC contact for these products in Europe is:

SMC Networks Europe,
Edificio Conata II,
Calle Fructuós Gelabert 6-8,

2o, 4a,

08970 - Sant Joan Despí, Barcelona, Spain.

This information technology equipment complies with the requirements of the Council
Directive 89/336/EEC on the Approximation of the laws of the Member States relating to
Electromagnetic Compatibility and 73/23/EEC for electrical equipment used within cer­tain voltage limits and the Amendment Directive 93/68/EEC. For the evaluation of the
compliance with these Directives, the following standards were applied:

Warning:

Do not plug a phone jack connector in the RJ-45 port. This may damage this

device. Les raccordeurs ne sont pas utilisé pour le systéme téléphonique!

RFI Emission:

• Limit class B according to EN 55022:1998

• Limit class B for harmonic current emission according to

EN 61000-3-2/1995

• Limitation of voltage fluctuation and flicker in low-voltage
supply system according to EN 61000-3-3/1995

Immunity:

• Product family standard according to EN 55024:1998

• Electrostatic Discharge according to EN 61000-4-2:1995

(Contact Discharge: ±4 kV, Air Discharge: ±8 kV)

• Radio-frequency electromagnetic field according to
EN 61000-4-3:1996 (80 - 1000 MHz with 1 kHz AM 80%
Modulation: 3 V/m)

• Electrical fast transient/burst according to EN 61000-4-4:1995
(AC/DC power supply: ±1 kV, Data/Signal lines: ±0.5 kV)

• Surge immunity test according to EN 61000-4-5:1995
(AC/DC Line to Line: ±1 kV, AC/DC Line to Earth: ±2 kV)

• Immunity to conducted disturbances, Induced by
radio-frequency fields: EN 61000-4-6:1996 (0.15 - 80 MHz with
1 kHz AM 80% Modulation: 3 V/m)

• Power frequency magnetic field immunity test according to
EN 61000-4-8:1993 (1 A/m at frequency 50 Hz)

• Voltage dips, short interruptions and voltage variations immunity
test according to EN 61000-4-11:1994 (>95% Reduction @10 ms,
30% Reduction @500 ms, >95% Reduction @5000 ms)

LVD:

• EN 60950 (A1/1992; A2/1993; A3/1993; A4/1995; A11/1997)

C

OMPLIANCES

v

Industry Canada - Class B

This digital apparatus does not exceed the Class B limits for radio noise emissions from
digital apparatus as set out in the interference-causing equipment standard entitled
“Digital Apparatus,” ICES-003 of the Department of Communications.

Cet appareil numérique respecte les limites de bruits radioélectriques applicables aux
appareils numériques de Classe B prescrites dans la norme sur le matériel brouilleur:
“Appareils Numériques,” NMB-003 édictée par le ministère des Communications.

Japan VCCI Class B

Australia AS/NZS 3548 (1995) - Class B

SMC contact for products in Australia is:

SMC Communications Pty. Ltd.
Suite 18, 12 Tryon Road,
Lindfield NSW2070,
Phone: [phone]
Fax: [phone]

C

OMPLIANCES

vi

vii

T

ABLE OF

C

ONTENTS

1 Installing The Network Card . . . . . . . . . . . . . . . 1-1

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1

Hardware Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

LED Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4

System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5

Inserting the Network Card . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5

PCI Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7

Connecting Category 5 Cable . . . . . . . . . . . . . . . . . . . . . . . . . 1-8

Cable Testing for Existing Category 5 Cable . . . . . . . . . . 1-8

Adjusting Existing Category 5 Cabling to Run 1000BASE-T .

1-8

Connecting UTP Cable . . . . . . . . . . . . . . . . . . . . . . . . . 1-9

2 Installing and Configuring Network Drivers . . 2-1

Windows NT 4.0 Installation . . . . . . . . . . . . . . . . . . . . . . . . . 2-1

First-Time Installation . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1

Secondary Installation . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3

Further Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4

Windows 2000 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5

Novell NetWare Installation . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6

NetWare Server 5.0 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6

NetWare Server 4.11 . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8

Linux 2.2.X or Later Installation . . . . . . . . . . . . . . . . . . . . . . 2-10

Manual Loading and Configuration . . . . . . . . . . . . . . . 2-10

Automatic Installation . . . . . . . . . . . . . . . . . . . . . . . . . 2-12

Windows 98 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-14

Other Installations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-16

Latest Drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-16

3 Configuring theNetwork Card . . . . . . . . . . . . . . 3-1

Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

IEEE Compliant Link . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

Media Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2

viii

Offload Checksum . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2

Packet Size (Maximum) . . . . . . . . . . . . . . . . . . . . . . . . 3-2

Pause Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3

Receive Buffer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3

VLAN ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3

Using VLANs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4

Traffic Priority . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4

A Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . .A-1

PCI Compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1

Solutions for Common Problems . . . . . . . . . . . . . . . . . . . . . . A-3

Network Card Installation Problems . . . . . . . . . . . . . . . A-3

Network Connection Problems . . . . . . . . . . . . . . . . . . . A-4

B Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-1

Cable Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-1

Twisted-Pair Cable and Pin Assignments . . . . . . . . . . . . . . . . B-2

1000BASE-T Pin Assignments . . . . . . . . . . . . . . . . . . . . B-3

C Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . .C-1

Software Drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-3

Index

1-1

C

HAPTER

1

I

NSTALLING

T

HE

N

ETWORK

C

ARD

Introduction

SMC’s EZ Card 1000, SMC9452TX, is a Gigabit Ethernet network
interface card for 32-bit PCI local bus-compliant computers. It
operates under the 1000BASE-T specification over Category 5 UTP
Cable, as well as being compatible with 100BASE-TX and 10BASE-T
connections. This network card provides up to ten times the
bandwidth of Fast Ethernet, and can deliver a full 2 Gbps of
throughput to the host PC. A true plug-and-play device, the card is
auto-configurable upon power up. Leading-edge ASIC technology
and performance-enhancing techniques maximize throughput and
minimize CPU utilization. The result is a network card that delivers
the performance and reliability demanded by today’s high-end
servers and workstations.

I

NSTALLING THE NETWORK CARD

1-2

Hardware Description

The EZ Card 1000 is a Gigabit Ethernet network card designed for
32-bit PCI-bus computers. The card has a single RJ-45 connector to
attach to Category 5 UTP cable and supports
10 Mbps, 100 Mbps and 1000 Mbps Ethernet operations. It also
supports full- and half-duplex and features auto-negotiation.

Figure 1-1. The EZ Card 1000 SMC9452TX

1

0

100

100

0

LINK

A

C

T

Boot ROMSocket for Optional

LED Indicators

for 10/100 Mbps

RJ-45 Connector

I

NSTALLING THE NETWORK CARD

1-3

LED Indicators

The EZ Card 1000 network card includes status LED indicators as
described in the following figure and table.

Figure 1-2. Status LEDs

LED Status Description

Link On Green Indicates a valid 1000BASE-T

connection.

ACT Flashing

Green

Indicates that the adapter is
transmitting or receiving data.

1000 On Green Indicates that the adapter is

operating at 1000 Mbps.

100 On Green Indicates that the adapter is

operating at 100 Mbps.

10 On Green Indicates that the adapter is

operating at 10 Mbps.

I

NSTALLING THE NETWORK CARD

1-4

Package Contents

After unpacking the EZ Card 1000, check the contents of the box to
be sure you have received the following components:

◆ EZ Card 1000 network card SMC9452TX

◆ SuperDisk™ network drivers diskette

◆ This User Guide

◆ SMC Warranty Registration Card

Immediately inform your dealer in the event of any incorrect,
missing or damaged parts. If possible, please retain the carton and
original packing materials in case there is a need to return the
product.

Please fill out and return the Warranty Registration Card to SMC or
you may register the product on SMC’s Web site. The EZ Card 1000
is covered by a limited lifetime warranty.

I

NSTALLING THE NETWORK CARD

1-5

System Requirements

Before you install the EZ Card 1000, check your system for the
following requirements:

◆ A PC and BIOS that support the PCI Local Bus Specification
v2.0 or later

◆ An available bus-mastering 32-bit PCI slot

◆ Category 5 or 5e UTP cable with RJ-45 connectors

◆ An IEEE 802.3ab-compliant Gigabit Ethernet device installed in

your network

Note: If you are installing in an older PC model (Pentium or

earlier), upgrade the BIOS to the latest version.

Inserting the Network Card

WARNINGS:

• This network adapter requires a PC and BIOS that support the
PCI Local Bus Specification v2.0 or later. If you are installing in
an older PC model, upgrade the BIOS to the latest version

• Network cards are sensitive to static electricity. To protect the
card, avoid touching its electrical components and always
touch the metal chassis of your computer before handling the
card.

• Back up your SuperDisk driver diskette and use the copy as the
working diskette to protect the original from accidental
damage.

1. Switch off the computer, unplug the power cord, and remove

the computer’s cover.

2. Select an available bus-mastering PCI slot and remove the cover

bracket.

I

NSTALLING THE NETWORK CARD

1-6

• When using a 32-bit PCI slot, the end of the card’s edge
connector will be exposed. Be careful that it does not touch
any conducting parts on the PC motherboard.

3. Install the network card into the slot so that it is firmly seated.
Then screw the card’s bracket securely into the PC’s chassis.

Figure 1-3. Inserting the Network Card

32-Bit PCI Slot

I

NSTALLING THE NETWORK CARD

1-7

4. Replace the chassis cover on your PC and power it on.

5. The EZ Card 1000 should be automatically configured by the
host computer’s BIOS. However, if you have an older computer,
you may have to manually configure the computer’s BIOS
settings (see Appendix, A “Troubleshooting”).

6. The SMC SuperDisk that accompanies the EZ Card 1000
contains all the network operating system drivers supported by
this card. Please read the “RELEASE.TXT” file on the diskette for
a list of all drivers. Refer to Chapter 2 in this guide for
instructions on installing drivers. Also, a text file is included
with each driver to detail the proper installation procedure. Any
new or updated drivers can be downloaded from SMC’s Web
site (see the back cover of this guide).

PCI Configuration

In most cases, your network card is automatically configured when
you power-up your computer. In certain computers, however, you
must modify PCI settings by running your computer’s BIOS Setup
program. For more information, refer to “PCI Compatibility” on
page A-2.

I

NSTALLING THE NETWORK CARD

1-8

Connecting Category 5 Cable

To connect to a 1000BASE-T Gigabit Ethernet device, use the RJ-45
connector on the network card and Category 5, 5e or better UTP
cable. This connection can be made directly to the device, or
indirectly via a wall outlet that has the proper wiring for an RJ-45
connector. Connections can be made for a distance of 100m
(328 ft). It is recommended that for all critical connections, or any
new cable installations, Category 5e (enhanced Category 5) cable
should be used. The Category 5e specification includes test
parameters that are only recommendations for Category 5.
Therefore, the first step in preparing existing Category 5 cabling for
running 1000Base-T is a simple test of the cable installation to be
sure that it complies with the IEEE 802.3ab standards.

Cable Testing for Existing Category 5 Cable

Installed Category 5 cabling must pass tests for Attenuation,
Near-End Crosstalk (NEXT), and Far-End Crosstalk (FEXT). This
cable testing information is specified in the ANSI/TIA/EIA-TSB-67
standard. Additionally, cables must also pass test parameters for
Return Loss and Equal-Level Far-End Crosstalk (ELFEXT).
These tests are specified in the ANSI/TIA/EIA-TSB-95 Bulletin, “The
Additional Transmission Performance Guidelines for 100 Ohm
4-Pair Category 5 Cabling.” When testing your cable installation, be
sure to include all patch cables between switches and end devices.

Adjusting Existing Category 5 Cabling to Run
1000BASE-T

If your existing Category 5 installation does not meet one of the test
parameters for 1000Base-T, there are basically three measures that
can be applied to try to correct the problem:

1. Replace any Category 5 patch cables with high-performance
Category 5e cables.

2. Reduce the number of connectors used in the link.

3. Reconnect some of the connectors in the link.

I

NSTALLING THE NETWORK CARD

1-9

Connecting UTP Cable

1. Attach the male RJ-45 connector on one end of a UTP cable to
the network card’s RJ-45 port.

Figure 1-4. Connecting UTP Cable

2. Attach the male connector on the other end of the UTP cable
directly to an Ethernet, Fast Ethernet or Gigabit Ethernet device.

OR

Attach the male connector on the other end of the UTP cable to
a wall outlet with an RJ-45 connector properly wired for
1000BASE-T Gigabit Ethernet. Wiring from the wall outlet
connection is usually routed to a hub or switch through a
punch-down block located in a wiring closet.

3. For 1000 Mbps operation, make certain that the device you are
connecting to is compliant with IEEE 802.3ab 1000BASE-T.

Category 5 Cable

RJ-45 Port

1

0

100

1000

LIN

K

A

C

T

I

NSTALLING THE NETWORK CARD

1-10

2-1

C

HAPTER

2

I

NSTALLING AND

C

ONFIGURING

N

ETWORK

D

RIVERS

Windows NT 4.0 Installation

Caution: Prior to installing the driver, make sure you have

upgraded to NT Service Pack 4 or later.

First-Time Installation

If you have already installed a network card, configured Windows
NT Networking, or configured a network driver, refer to the
procedure entitled “Secondary Installation” on page 3. If Windows
NT is already installed on your computer, proceed to Step 2.
Otherwise, complete a first-time Windows NT installation without
the SMC network card installed. Be sure to also install NT Service
Packet 4 or later.

1. Shut down your PC, install the SMC network card, and attach
the network cable. Restart Windows NT.

2. Double-click on the “My Computer,” “Control Panel,” and
“Network” icons. The “Network Configuration” window
appears, prompting you to install Windows NT Networking.
Select “Yes.” Windows NT starts the “Network Setup Wizard.”
Click on “Next.”

3. When prompted to “Search for a Network Adapter,” click on
“Select from List.”

I

NSTALLING AND CONFIGURING NETWORK DRIVERS

2-2

4. When prompted to “Select a Network Adapter,” click on “Have
Disk.” Insert the SuperDisk when prompted and click on “OK.”

5. You are presented with the “Select OEM Option” window.
Highlight “EZ Card 1000” and click on “OK.”

6. When prompted to “Search for an Adapter,” click on “Next.”

7. Select network protocols when prompted and click “Next.”

Note: To complete a TCP/IP installation, you will need to know

your IP Address and Subnet Mask. For further information,
contact your network administrator or Internet service
provider.

8. Click on “Next” and then “Next” again when prompted to
“Install Network Components.” When prompted for Windows
NT installation files, type the path to your Windows NT files on
your CD-ROM (e.g., D:\WINNT) or hard drive, and click on
“OK.”

9. You are presented with the “Network Card Setup” window
where you can specify the network card data rate.
“AUTONEGOTIATE” is the recommended setting for the EZ
Card 1000 network card. Select “Continue” after verifying
network card settings.

10. Click on “Next” and then “Next” again when prompted to “Start
the Network.”

11. Enter the “Work gr oup” or “Domain” names (optional) when
prompted and click on “Next.”

Note: For further information, contact your network administrator

or Internet service provider.

12. Select “Finish” when prompted and click on “Yes” when
prompted to reboot. Remove the SuperDisk from the drive.

I

NSTALLING AND CONFIGURING NETWORK DRIVERS

2-3

Secondary Installation

Follow this procedure if you have already installed another network
card or loaded another driver.

1. Be sure to install Windows NT Service Packet 4 or later if it is
not already installed.

2. Install the SMC network card (if not already installed), attach the
network cable, and boot Windows NT.

3. Double-click on the “My Computer,” “Control Panel,” and
“Network” icons. From the “Network” window, select the
Adapter tab.

4. Do not select any of the network cards listed. Select “Add.”

5. You are presented with the “Select Network Adapter” window.
Click on “Have Disk.”

6. You are presented with the “Insert Disk” window. Specify the

7. path to the root directory of the SuperDisk (e.g., A:\WINNT)
and click on “OK.”

8. You are presented with the “Select OEM Option” window.
Highlight “EZ Card 1000” and click on “OK.”

9. You are presented with the “Network Card Setup” window
where you can specify the network card data rate.
“AUTONEGOTIATE” is the recommended setting for the EZ
Card 1000 network card. Select “OK” after verifying network
card settings.

10. You are presented with the “Network” window where the SMC
network card is now listed as an installed adapter. At this point
you can select “Close” to exit the Network applet and follow the
prompts to restart Windows NT.

11. Select “Yes” when prompted to reboot for the changes to take
effect.

I

NSTALLING AND CONFIGURING NETWORK DRIVERS

2-4

Further Configuration

You can modify card settings, install additional protocols and other
network components via the Windows NT “Network” applet.

1. Double-click on the “My Computer,” “Control Panel,” and

“Network” icons. The “Network” dialog box appears. Select the
“Protocols” tab. If the correct network protocols are not listed

in the list box, click on the “Add” button and follow the
on-screen directions to select network protocols.

2. Click on the appropriate tab, “Identification,” “Services” or
“Bindings,” to add or modify other network components, as
needed.

3. To modify other network card properties, click on the
“Adapters” tab and select the EZ Card 1000 in the list box. Then
click on the “Properties” button to run the card’s configuration
utility. Refer to Chapter 3 for a description of the card’s
configuration utility and its options.

I

NSTALLING AND CONFIGURING NETWORK DRIVERS

2-5

Windows 2000 Installation

The EZ Card 1000 driver for Windows 2000 conforms to the
Network Driver Interface Specification (NDIS) 5.0 and can be found
in the “\Win2000” directory on the SMC SuperDisk driver diskette.

1. If Windows 2000 is already installed on your computer, proceed
to Step 2. Otherwise, install Windows 2000 without the SMC
network card installed.

2. Shut down your PC, install the SMC network card, and attach a
network cable.

3. Reboot Windows 2000. Make sure you have your Windows
2000 installation CD available, or that you are aware of the path
to the installation files on your hard drive.

4. After you have logged in, a “Welcome to the Found New
Hardware Wizard” window will appear if Windows 2000 cannot
locate the driver. If this window does not appear, Windows
2000 was able to locate the driver and installation is complete.
If the window appears, click on “Next.” Select “Search for a
suitable driver” and click on “Next.” Select “Specify location”
and then type in “A:\WIN2000”, or browse to the WIN2000
folder on the SuperDisk, and click on “OK.”

5. Follow the remaining Windows 2000 instructions to complete
the installation.

I

NSTALLING AND CONFIGURING NETWORK DRIVERS

2-6

Novell NetWare Installation

NetWare Server 5.0

Installing the LAN driver is part of the NetWare installation process.
Use the following instructions with those in the NetWare installation
manual to install the driver. You will need the SMC SuperDisk
during this procedure. Shut down your computer and install the EZ
Card 1000 network card in a PCI slot. Connect the card to the
network using UTP cable.

1. Turn your computer on and boot it to the NetWare 5.0 console
prompt.

2. At the NetWare console prompt enter the command “load
nwconfig” to start the install utility. The Installation Options
dialog box is displayed.

3. Select the Driver Options menu item and press enter. The Driver
Options dialog box is displayed.

4. Select the Configure Network Drivers menu item and press
enter. The Additional Driver Actions dialog box is displayed.

5. Insert the SMC SuperDisk driver diskette into the “A” drive.

6. Select the “Load an additional driver” menu item option and
press Enter. The “Select a driver” dialog box is displayed. Press
the “Ins” key to install an unlisted driver. A dialog box is
displayed indicating the A drive will be scanned for drivers.
Press Enter to continue.

7. Press Enter to select the SMC9452.LAN from the “Select a driver
to install” dialog box. A message asking if you want to copy the
driver is displayed. Select “Yes” to continue. The device driver
is copied.

I

NSTALLING AND CONFIGURING NETWORK DRIVERS

2-7

8. A screen with three dialog boxes is displayed. To change the
driver configuration, tab to the “SMC9452_1 Parameters” dialog
box and modify the driver parameters. Depending on the
network the card is attached to, the Link, Speed and Duplex
Mode parameters may need to be changed from their default
values. If you are not sure what values are required for your
network, contact your network administrator.

9. Tab to the “SMC9452_1 Protocols” and select the desired
protocols.

10. Tab to the “Board SMC9452_1 Actions” dialog box. Select the
“Save Parameters and Load Driver” option and press Enter to
continue.

11. Perform protocol specific configuration as required.

12. Select “No” when asked if you want to load additional drivers.

13. On the “Additional Driver Actions” dialog box, select “Return to
previous menu” and press Enter to continue.

14. On the “Driver Options” dialog box, select “Return to previous
menu” and press Enter to continue.

15. On the “Installation Options” dialog box, select “Exit” to return
to the NetWare console prompt.

I

NSTALLING AND CONFIGURING NETWORK DRIVERS

2-8

NetWare Server 4.11

Installing the LAN driver is part of the NetWare installation process.
Use the following instructions with those in the NetWare installation
manual to install the driver. You will need the SMC SuperDisk
during this procedure.

1. Shut down your computer and install the EZ Card 1000 network
card in a PCI slot. Connect the card to the network using UTP
cable.

2. Turn your computer on and boot it to the NetWare 4.11 console
prompt.

3. At the NetWare console prompt Enter the command “load
install” to start the install utility. The Installation Options dialog
box is displayed.

4. Select the “Driver Options” menu item and press enter. The
“Driver Options” dialog box is displayed.

5. Select the “Configure Network Drivers” menu item and press
Enter. The “Additional Driver Actions” dialog box is displayed.

6. Insert the SMC SuperDisk driver diskette into the “A” drive.

7. Select the “Load an additional driver” menu item option and
press Enter. The “Select a driver” dialog box is displayed. Press
the “Ins” key to install an unlisted driver. A dialog box is
displayed indicating that the A drive will be scanned for drivers.
Press Enter to continue.

8. Press Enter to select the SMC9452.LAN from the “Select a driver
to install” dialog box. A message asking if you want to copy the
driver is displayed. Select “Yes” to continue. The device driver
is copied.

I

NSTALLING AND CONFIGURING NETWORK DRIVERS

2-9

9. A screen with three dialog boxes is displayed. To change the
driver configuration, tab to the “SMC9452_1 Parameters” dialog
box and modify the driver parameters. Depending on the
network that the card is attached to, the Link, Speed and Duplex
Mode parameters may need to be changed from their default
values. If you are not sure what values are required for your
network, contact your network administrator.

10. Tab to the “SMC9452_1 Protocols” and select the desired
protocols.

11. Tab to the “Board SMC9452_1 Actions” dialog box. Select the
“Save Parameters and Load Driver” option and press Enter.

12. Perform protocol specific configuration as required.

13. Select “No” when asked if you want to load additional drivers.

14. On the “Additional Driver Actions” dialog box, select “Return to
previous menu” and press Enter to continue.

15. On the “Driver Options” dialog box, select “Return to previous
menu” and press Enter to continue.

16. On the “Installation Options” dialog box, select “Exit” to return
to the NetWare console prompt.

I

NSTALLING AND CONFIGURING NETWORK DRIVERS

2-10

Linux 2.2.X or Later Installation

This section describes the procedure for manual and automatic
loading and configuration of the EZ Card 1000 Unix stream driver
for Linux 2.2.X or later. The Linux driver can be found in the
“\linux” directory on the SMC SuperDisk driver diskette.

Manual Loading and Configuration

Note: In the following sections that describe the driver

configuration it is suggested that these instructions be
carried out in a single-user environment.

1. Log into the Unix system as supervisor (root) and enter
Maintenance mode. Make sure that the current directory is “/”
using the Unix command “pwd.”

2. Use the following steps to uncompress the package file:

# cd /tmp

(and insert the floppy in the proper drive, i.e., a:)
# mcopy a:/linux/2_2_X/nic/SMC9452t.o./temp
# cd temp

Now the installation directory is ready for use.

3. Load the EZ Card 1000 device driver module by simply running
the command:

# insmod SMC9452t.o

You can also specify command line parameters for the driver,
such as:

#insmod MaxTxDesc=150 MaxRxDesc=150 RxBufSize=2048

The following command line parameters are supported:

I

NSTALLING AND CONFIGURING NETWORK DRIVERS

2-11

RxBufSize: This is the size of the receive buffer memory space
allocated per receive descriptor (the label given to each packet
received). The default value is 2048. It should be set at 2048 to
ensure good performance when not using jumbo frames. When
using jumbo frames it should be set at 4096.

MaxRxDesc: This is the maximum number of receive descriptors
that will be allocated. This value should be at least 100. The default
value is 200.

MaxTxDesc: This is the maximum number of transmit descriptors
that will be allocated. This value should be at least 100. The default
value is 200.

<mtu-size>: This is the maximum transmission packet size and can
be increased up to 4000 bytes for effective operation. To enable the
use of jumbo frames, the mtu size can be increased by using the
ifconfig utility, as follows

#ifconfig <interface-name> mtu <mtu-size>

for example:

ifconfig eth0 mtu 3000

Assuming the card has been assigned the device name “eth0,” the
following command brings the card into an operational state:

# ifconfig eth0 up

Next the driver must be bound to an active protocol, almost always
TCP/IP, using the following command:

#ifup eth0

Note that this is meaningful only if the system can find a
configuration script that contains the necessary network info. A
sample is given below.

DEVICE=eth0
USERCTL=no
ONBOOT=yes

I

NSTALLING AND CONFIGURING NETWORK DRIVERS

2-12

BOOTPROTO=none
BROADCAST=207.200.5.255
NETWORK=207.200.5.0
NETMASK=255.255.255.0
IPADDR=207.200.5.2

Automatic Installation

This section describes how to install the Linux driver so that it is
automatically loaded and configured at boot time. The following
description is based on the Red Hat 7.0 distribution, but it can easily
be ported to other distributions as well.

Note: Before automatically loading the driver at boot time, ensure

that the system will function correctly after the driver has
been loaded manually.

1. Log into the Unix system as supervisor (root) and enter
Maintenance mode. Make sure that the current directory is “/”
using Unix command “pwd.”

2. Use the following steps to uncompress the package file:

#cd tmp and insert the floppy in drive a:
#mcopy a:/linux/2_2_X/nic/SMC9452t.o ./temp
#cd temp

Now the installation directory is ready for use.

3. Copy the lacp.o and the SMC9452t.o file to the network
modules directory, typically /lib/modules/2.4.X/kernel/drivers/
net

#cp ./lacp.o /lib/modules/2.2.X/kernel/drivers/net
#cp ./SMC9452t.o /lib/modules/2.2.X/kernel/drivers/
net

4. Locate the boot module configuration file, most commonly
“conf.modules” in the “/etc.” directory. Add the following line:

alias ethx SMC9452

I

NSTALLING AND CONFIGURING NETWORK DRIVERS

2-13

where “ethx” will be “eth0” if you do not have any other
adapters, “eth1” if you already have one, and so on. The
parameters are the ones discussed in the previous paragraph.

5. Find out where the network configuration scripts are, normally
in the “/etc/sysconfig/network-scripts” directory, and create a
configuration script (sample discussed above) named
“ifcfg-ethx” that contains network information.

# cd /etc/sysconfig/network-scripts
# vi ifcfg-ethx (make a configuration script file)

6. Reboot the Unix system to initialize the driver function.

# reboot

I

NSTALLING AND CONFIGURING NETWORK DRIVERS

2-14

Windows 98 Installation

The EZ Card 1000 driver for Windows 98 conforms to the Network
Driver Interface Specification (NDIS) 5.0 and can be found in the
“\Win98” directory on the SMC SuperDisk driver diskette.

1. If Windows 98 is already installed on your computer, proceed
to Step 2. Otherwise, complete a first-time Windows 98
installation without the SMC network card installed.

2. Shut down your PC, install the SMC network card, and attach
network cable. Make sure you have your Windows 98
installation CD available, or that you are aware of the path to
the installation files on your hard drive.

3. Power on your PC and boot into Windows 98.

4. When Windows 98 prompts with “PCI Ethernet Controller” in
the “New Hardware Found” dialog box, click the “Next” button.

5. Select “Search for the best driver for your device
(Recommended)” in the “Add New Hardware Wizard” dialog
box, then click the “Next” button.

6. Insert the EZ Card 1000 Driver Diskette in your floppy drive.

7. Select “Specify a location” and type path “A:\Win98” in the “Add
New Hardware Wizard” dialog box, then click the “Next”
button.

8. Click the “Next” button in the “Add New Hardware Wizard”
dialog box.

9. Windows 98 will prompt with “SMC EZ Card 1000 Adapter” in
the “Add New Hardware Wizard” dialog box.

10. Click the “Next” button in the “Add New Hardware Wizard”
dialog box, then Windows 98 will copy the driver
(SMC9452.sys) from “A:\Win98” to the

I

NSTALLING AND CONFIGURING NETWORK DRIVERS

2-15

“C:\WINDOWS\SYSTEM” directory and the “SMC9452.INF” file
from “A:\Win98” to the “C:\WINDOWS\INF” directory.

11. When Windows prompts with “SMC EZ Card 1000 Adapter” in
the “Add New Hardware Wizard” dialog box, click the “Finish”
button.

12. Remove the SMC SuperDisk driver diskette from your floppy
drive.

13. Restart your computer to initialize the network function.

Note: “C:\WINDOWS” is the directory where your Windows 98

system is located.

I

NSTALLING AND CONFIGURING NETWORK DRIVERS

2-16

Other Installations

Refer to the installation documents on SMC’s SuperDisk for
instructions on installing drivers for use with other operating
systems.

Please note that new releases of SMC drivers and operating systems
may result in procedures slightly different than those described in
this chapter.

Latest Drivers

The SuperDisk contains the latest drivers available at shipping time.
If more recent versions of these drivers are available, you can
download them from SMC’s Web site. Refer to the back cover of this
user guide.

3-1

C

HAPTER

3

C

ONFIGURING THE

N

ETWORK

C

ARD

Configuration

This section describes the configuration procedure in a Windows
environment. When you install the Windows driver, the
configuration utility is also installed. You can run this utility by
clicking on the “Properties” button for the card in the “Network”
control panel applet. Using this utility you configure the following
parameters:

Address

This field lets you set a local network MAC address to override the
permanent MAC address that is stored in EEPROM on the card. This
feature is useful if the card is being used in a test environment.
However, for normal use it is recommended to retain the factory-set
“Permanent” MAC address.

IEEE Compliant Link

This option should be set to disabled if the link partner does not
comply to the IEEE 802.3 specifications for 1000BASE-T network
cards. This is often characterized by an intermittent connection and
can occur with older Gigabit Ethernet hardware.

C

ONFIGURING THE NETWORK CARD

3-2

Media Type

In this field auto-negotiation can be enabled, or the card’s link
speed and duplex mode can be selected. If auto-negotiation is
enabled, the card will match settings with its link partner. If the link
partner has a fixed configuration, the link speed will be sensed and
the mode will default to half duplex. If the link partner is configured
to full duplex, the card will not connect correctly, resulting in high
error rates and inefficient communication. Therefore,
auto-negotiation should be disabled when connecting to a device
with a fixed configuration. The default for this field is “Auto-
Negotiate”.

Offload Checksum

The checksum of received packets is recomputed to check for
corruption of data. A checksum is inserted into transmitted packets.
Enabling Offload Checksum off-loads this function from the CPU to
the card. The default is Tx Checksum.

Packet Size (Maximum)

The card can be configured to use Jumbo Frames. This increases the
maximum Ethernet frame size to greater than 1514 bytes. Using
Jumbo Frames greatly reduces packet processing overhead and can
boost throughput by up to 300% for bulk data transfers.

Note: To use Jumbo Frames, both communicating computers

must have network cards that support this feature. Also, at
full duplex, all switches in the network between the two
end computers must be able to accept the extended frame
size. With half-duplex connections, all devices in the
collision domain need to support Jumbo Frames.

C

ONFIGURING THE NETWORK CARD

3-3

Pause Control

Pause frames are used to control network congestion. In this field
the card may be configured to transmit and to receive pause frames
(IEEE 802.3x dull duplex flow control). The default is “Enabled”.

Receive Buffer

This field lets you set the number of buffers allocated in the
memory for use by the card while receiving packets. Decreasing the
number of buffers reduces the memory requirement of the card.

VLAN ID

Select “VLAN ID” to configure the VLAN ID for the card. VLAN IDs
can range from 1 to 4094.

C

ONFIGURING THE NETWORK CARD

3-4

Using VLANs

The TigerCard 1000 network card supports the IEEE 802.1Q VLAN
standard and can be configured to participate in a network with
other devices that use VLANs.

An IEEE 802.1Q VLAN is a group of ports that can be located
anywhere in the network, but communicate as though they belong
to the same physical segment. VLANs help to simplify network
management by allowing you to move devices to a new VLAN
without having to change any connections. VLANs can be easily
organized to reflect departmental groups (such as Marketing or
R&D) or usage groups (such as e-mail or video conferencing).

VLANs provide greater network efficiency by reducing broadcast
traffic, but also allow you to make network changes without having
to update IP addresses or IP subnets. VLANs inherently provide a
high level of network security, since traffic must pass through a
router or a Layer 3 switch to reach a different VLAN. Usually VLANs
are configured within IEEE 802.1Q VLAN-enabled switches in the
network where ports are assigned to specific VLAN IDs.

Note: The VLAN ID configured within the card must match one of
those in the IEEE 802.1Q-compliant switches throughout the
network.

Traffic Priority

The TigerCard 1000 network card supports the IEEE 802.1p Quality
of Service standard with eight levels of priority. Defining priority
levels in the network card allows it to work with other network
devices to deliver higher priority packets first. Note that the IEEE

802.1p standard must be supported by the other devices in the
network. Refer to the documentation of your network devices for
configuration options on handling frames with priority tags.

A-1

A

PPENDIX

A

T

ROUBLESHOOTING

PCI Compatibility

Early PCI BIOS versions do not properly support the PCI
specification and may “hang” when a network card driver tries to
load. If this occurs, make sure your BIOS correctly supports the PCI
Local Bus Specification (v2.0 or later) and upgrade your computer
BIOS to the latest version.

Some PCI computers are not self-configuring and require you to
perform some or all of the following functions by motherboard
jumper changes and/or BIOS Setup program configuration:

◆ Verify that the PCI slot is an enabled bus-master slot and not a

slave PCI slot. The EZ Card 1000 must be installed in a PCI
bus-master slot. In some computers the PCI slot must be
configured to enable bus mastering. Refer to your PC’s manual
and check the PCI BIOS Setup program to be sure the PCI slot
is an enabled busmaster slot.

◆ In some computers, you may be required to disable Plug-and-

Play in the BIOS Setup program if resources are not properly
assigned between the network card and other installed cards.

◆ Some computers may require you to reserve interrupts and

memory addresses for installed ISA cards to prevent PCI cards
from using the same settings. Refer to your PC’s manual and
check the PCI BIOS Setup program configuration options for
ISA cards.

T

ROUBLESHOOTING

A-2

◆ Make sure the PCI slot is configured to support INTA.

◆ Ensure that INTA for the slot is assigned to a free interrupt

(IRQ) number.

◆ Check the BIOS Setup program’s PCI parameters for the slot
where the EZ Card 1000 network card is installed. Ensure that
the slot is configured for level-triggered interrupts instead of
edge-triggered interrupts. An example of typical PCI
parameters follows:

PCI Slot #: (slot number where the network card

is installed)

Master: Enabled

Slave: Enabled

Latency Timer: 40 (range is 20 to 255)

Interrupt Type: Level-Triggered

Interrupt Number: (choose any number the BIOS Setup

supplies that does not conflict with
another installed card)

Note that the wording of these parameters varies with different
computers, and not all parameters may be configurable.

Always consult your computer manual for information on changing
motherboard jumper settings and BIOS Setup program parameters
for use with PCI network cards. If you set a motherboard jumper
and modify the computer’s BIOS Setup, make sure the jumper and
BIOS settings match.

T

ROUBLESHOOTING

A-3

Solutions for Common Problems

Problems are often caused by cabling errors, conflicts with other
devices installed in the same computer, or software that has been
configured incorrectly. If you encounter a problem with the EZ
Card 1000 network card, use the following checklists to identify and
correct the problem.

Network Card Installation Problems

If your computer cannot find the EZ Card 1000, or the network
driver does not install correctly, check the following items before
contacting SMC Technical Support.

◆ Make sure the card is securely seated in the PCI slot. Check for
any hardware problems, such as physical damage to the card’s
edge connector.

◆ Try the card in another PCI bus-master slot. If this fails, test with
another EZ Card 1000 card that is known to operate correctly.

◆ Check for resource conflict in the PCI configuration. See section
“PCI Compatibility” in this chapter.

◆ Make sure your computer is using the latest BIOS available.

◆ If there are other network cards in the computer, they may be

causing conflict. Remove all other cards from the computer and
test the EZ Card 1000 separately.

◆ Check for a defective computer or PCI bus by trying the
network card in another computer that is known to operate
correctly.

T

ROUBLESHOOTING

A-4

Network Connection Problems

If your computer cannot find the EZ Card 1000 card, or the network
driver does not install correctly, check the following items before
contacting SMC Technical Support.

◆ Make sure your card is installed properly. See “Network Card
Installation Problems” for installation troubleshooting.

◆ If you cannot access a Windows or NetWare service on the
network, check that you have enabled and configured the
service correctly. If you cannot connect to a particular server,
ensure that you have access rights and a valid ID and password.

◆ If you cannot access the Internet, be sure you have configured
your system for TCP/IP.

B-1

A

PPENDIX

B

C

ABLES

Cable Specifications

Cable Types and Specifications

Cable Type Max. Length Connector

10BASE-T Cat. 3, 4, 5 100-ohm UTP 100 m (328 ft) RJ-45

100BASE-TX Cat. 5 100-ohm UTP 100 m (328 ft) RJ-45

1000BASE-T Cat. 5, 5e 100-ohm UTP 100 m (328 ft) RJ-45

C

ABLES

B-2

Twisted-Pair Cable and Pin Assignments

Caution: DO NOT plug a phone jack connector into any RJ-45

port. Use only twisted-pair cables with RJ-45 connectors
that conform with FCC standards.

The RJ-45 port on the EZ Card 1000 supports 1000, 100, and 10
Mbps Ethernet operation, with auto-negotiation of speed and flow
control.

Caution: Each wire pair must be attached to the RJ-45 connectors

in a specific orientation.

Figure B-1 illustrates how the pins on the RJ-45 connector are
numbered. Be sure to hold the connectors in the same orientation
when attaching the wires to the pins.

Figure B-1. RJ-45 Connector Pin Numbers

C

ABLES

B-3

1000BASE-T Pin Assignments

1000BASE-T ports support automatic MDI/MDI-X operation, so
you can use straight-through cables for all network connections. In
straight-through cable, pins 1-8, at one end of the cable, are
connected straight through to pins 1-8 at the other end of the
cable.

Use 100-ohm Category 5 or 5e unshielded twisted-pair (UTP) or
shielded twisted-pair (STP) cable for 1000BASE-T connections.
Also be sure

that the length of any twisted-pair connection does not

exceed 100 meters (328 feet)

.

The table below shows the 1000BASE-T MDI and MDI-X port
pinouts. These ports require that all four pairs of wires be
connected. Note that for 1000BASE-T operation, all four pairs of

wires are used for both transmit and receive.

Pin MDI Signal Name MDI-X Signal Name

1 Transmit Data plus (TD1+) Transmit Data plus (TD2 +)

2 Receive Data minus (RD1-) Receive Data minus (RD2-)

3 Transmit Data plus (TD2+) Transmit Data plus (TD1+)

4 Transmit Data plus (TD3+) Transmit Data plus (TD4+)

5 Receive Data minus (RD3-) Receive Data minus (RD4-)

6 Receive Data minus (RD2-) Receive Data minus (RD1-)

7 Transmit Data plus (TD4+) Transmit Data plus (TD3+)

8 Receive Data minus (RD4-) Receive Data minus (RD3-)

C

ABLES

B-4

C-1

A

PPENDIX

C

S

PECIFICATIONS

Bus Interface

32-bit bus master, PCI
33 MHz and 66 MHz

Interrupt

INTA

Network Interface

1000BASE-T:

UTP cable; Category 5, 5e or better

100BASE-TX:

UTP cable; Category 5

10BASE-T:

UTP cable; Category 3, 4, or 5

Data Rate

1000 Mbps, 100 Mbps, 10 Mbps half and full duplex

Cabling

4 pairs of Category 5, 5e or better UTP cable:
maximum 100 m (328 ft)

Configuration

Address, IEEE Compliant Link, Media Type, Offload Checksum,
Packet Size, Pause Control, Receive Buffer

LED Indicators

1000, 100, and 10 Mbps link
Activity
Link

S

PECIFICATIONS

C-2

Operating Voltage

+5 VDC @ 2.7 A maximum

Size (without bracket)

7.9 x 16.5 cm (3.11 x 6.50 in.)

Weight

80g (2.8 oz)

Temperature

Operating 0 to 55 °C (32 to 131 °F)
Storage -20 to 65 °C (-4 to 150 °F)

Humidity

5% to 95% (non-condensing)

Standards

IEEE 802.3ab 1000BASE-T
IEEE 802.3u 100BASE-TX
IEEE 802.3x Full-Duplex flow control
IEEE 802.1Q VLAN Tagging
IEEE 802.1p Port Priority
PCI v2.2

Compliances

CE Mark
Emissions

FCC Class B
VCCI Class B
Industry Canada Class B
EN55022 (CISPR 22) Class B

Warranty

Limited lifetime

S

PECIFICATIONS

C-3

Software Drivers

ODI Drivers NetWare Server 4.1x or later

NDIS Drivers Windows NT 4.0

Windows 95
Windows 98
Windows ME
Windows 2000

Unix Drivers Linux 2.2.X or later

S

PECIFICATIONS

C-4

Glossary-1

G

LOSSARY

10BASE-T

IEEE 802.3 specification for 10 Mbps Ethernet over two pairs of
Category 3, 4, or 5 UTP cable.

100BASE-TX

IEEE 802.3u specification for 100 Mbps Fast Ethernet over two pairs
of Category 5 UTP cable.

1000BASE-T

IEEE 802.3ab specification for Gigabit Ethernet over four pairs of
Category 5 UTP cable.

Bandwidth

The difference between the highest and lowest frequencies
available for network signals. Also synonymous with wire speed,
the actual speed of the data transmission along the cable.

Collision

A condition in which packets transmitted over the cable interfere
with each other. The interference makes both signals unintelligible.

Collision Domain

Single CSMA/CD LAN segment.

CSMA/CD

CSMA/CD (Carrier Sense Multiple Access/Collision Detect) is the
communication method employed by Ethernet and Fast Ethernet.

G

LOSSARY

Glossary-2

End Station

A workstation, server, switch, bridge or router.

Ethernet

A network communication system developed and standardized by
DEC, Intel, and Xerox, using baseband transmission, CSMA/CD
access, logical bus topology and coaxial cable. The successor IEEE

802.3 standard provides for integration into the OSI model and

extends the physical layer and media with repeaters and
implementations that operate on fiber, thin coax and twisted-pair
cable.

Fast Ethernet

A 100 Mbps network communication system based on Ethernet and
the CSMA/CD access method.

Full Duplex

Transmission method that allows two network devices to transmit
and receive concurrently, effectively doubling the bandwidth of
that link.

Gigabit Ethernet

A 1000 Mbps network communication system based on Ethernet
and the CSMA/CD access method.

IEEE

Institute of Electrical and Electronic Engineers.

G

LOSSARY

Glossary-3

IEEE 802.3

Defines carrier sense multiple access with collision detection
(CSMA/CD) access method and physical layer specifications.

IEEE 802.3u

Defines CSMA/CD access method and physical layer specifications
for 100BASE-TX Fast Ethernet.

IEEE 802.3ab

Defines CSMA/CD access method and physical layer specifications
for 1000BASE-T Gigabit Ethernet over Category 5 UTP cable.

Local Area Network (LAN)

A group of interconnected computer and support devices.

LAN Segment

Separate LAN or collision domain.

LED

Light emitting diode used for monitoring a device or network
condition.

Media Access Control (MAC)

A portion of the networking protocol that governs access to the
transmission medium, facilitating the exchange of data between
network nodes.

MII

Media Independent Interface, the standard interface for Fast
Ethernet—similar to the AUI interface for traditional Ethernet.

G

LOSSARY

Glossary-4

Network Diameter

Wire distance between two end stations in the same collision
domain.

Switched Ports

Ports that are on separate collision domains or LAN segments.

Transmission Control Protocol/Internet Protocol (TCP/IP)

Protocol suite that includes TCP as the primary transport protocol,
and IP as the network layer protocol.

UTP

Unshielded twisted-pair cable.

Index-1

A

auto-negotiation 2-2

B

BIOS requirements 1-5, A-1
bus-mastering 1-5

, A-1

C

cable

adjusting Category 5 cable 1-8
guidelines 1-7

specifications B-1
card installation 1-5
Category 5 cable 1-8
CE Mark iv
checklist of contents 1-4
compliances iii
configuration

Linux 2-10

Windows 2000 2-14

Windows 98 2-14

Windows NT 2-4
connection

guidelines 1-7
connections

Category 5 cable 1-8

UTP cable 1-9
contents of package 1-4

D

driver files 1-7
driver installation 2-1

new or updated 1-7

other 2-16

Windows 98 2-14

E

EC conformance iv
