Wireless
SMCWUSBT-G
EZ Connect™g 802.11g 108Mbps Wireless USB 2.0 Adapter
www.smc.com
EZ Connect 2.4GHz 802.11g 108Mbps Wireless USB 2.0
Adapter (SMCWUSBT-G) is another cutting edge introduction in 2.4GHz wireless communication for your laptop or
desktop. Designed for both business and home users, this
new adapter provides the speed, coverage, and security
expected by today's wireless users. Based on the IEEE
802.11g standard, the new EZ Connect g Wireless USB 2.0
Adapter is 15 times faster than the widely used 802.11b wireless networking devices and is 100% compatible with existing
802.11b wireless networks. The SMCWUSBT-G is extremely
fast and can handle streaming video, multimedia and all other
bandwidth-intensive applications. Wireless clients can now
easily obtain instant, seamless high-speed network connection. The SMCWUSBT-G 802.11g Wireless USB Adapter complies with USB 2.0 and is backward compatible with USB 1.1.
With a USB performance of 480 Mbps (40 times the speed of
USB 1.1), this new product can take full advantage of the
802.11g bandwidth. Its compact, sleek design makes it convenient and easy to carry. Using the new SMCWUSBT-G, you
can simplify PC connections in the home, office or on the
road.
The EZ Connect 2.4GHz 802.11g 108Mbps Wireless USB 2.0
Adapter includes an EZ Installation Wizard that enables
quick and easy setup. Simply put the EZ Installation Wizard
CD into your CD drive, click on Install Driver/Utility Link, the
wizard will perform the installation automatically. Then plug
in your SMCWUSBT-G into the USB slot of your laptop, and
you are now ready to enjoy the freedom of wireless networking.
To ensure secure transmissions across your wireless network, this USB adapter supports 64/128-bit Wired
Equivalent Privacy (WEP), Wi-Fi Protected Access (WPA),
and the new WPA2. WPA and WPA2 are interoperable security improvements that greatly increase the level of data
encryption and authentication for existing and future wireless LAN systems. In addition, the EZ Connect™ g 802.11g
Wireless USB 2.0 Adapter offers an auto-fallback feature
that provides scalable connectivity under noisy environments and enables a larger wireless operating range.
This wireless USB adapter combines the ease-of-use and
convenience of USB-enabled PCs with the benefits of high
speed 108Mbps wireless operation in a full-featured solution
for the networked environment. It connects instantly with an
existing Ethernet installation to support mobile users, temporary work sites, sharing of peripherals, and wireless multimedia. Wireless solutions provide the ultimate in mobility,
simple and flexible installation options, a reduced cost of
ownership (no cabling costs or maintenance), and excellent
scalability in supporting additional PCs on the LAN.
FEATURES
EZ Installation Wizard; Plug-and-Play™
Wireless connectivity via high speed USB 2.0 port
Compact and sleek design
IEEE 802.11b and 802.11g compliant, up to 108 Mbps wireless
LAN
Robust security features include 64-bit/128-bit WEP
encryption, WPA, and the new WPA2
Profile management and Site Survey
Simple and easy installation on Windows 98SE/ME/2000/XP.
Plug-and-play, no configuration needed
USB 2.0 interface with 480 Mbps high data rate performance up to 40 times faster than USB v1.0 and 1.1
Compact, easy-to-carry form factor
Provides high speed wireless communication at up to 108 Mbps;
802.11g compliance allows seamless interoperation among
multiple vendors
Advanced security through 64-bit/128-bit WEP encryption,
Wi-Fi Protected Access (WPA), and the new WPA2 to protect
your information and to ensure secure data transmissions
Ability to scan for all available Access Points on the wireless
network and create multiple profiles, making it easy to use in the
home, office or on the road
BENEFITS
OVERVIEW
TECHNICAL SPECIFICATIONS SMCWUSBT-G
STANDARDS
• 802.11b
• 802.11g
• USB 1.0, 1.1, 2.0
DATA R AT E S
• 1 / 2 / 5.5 / 11 Mbps
• 6 / 9 / 12 / 18 / 24 / 36 / 48 / 54 / 108 Mbps
FREQUENCY BAND
• CSMA/CA
OPERATIONAL MODE
• 802.11g Radio : 2.4 GHz
• 802.11b Radio : 2.4 GHz
• USA - FCC: 2412~2462MHz (Channel 1~Channel 11)
• Canada - IC: 2412~2462MHz (Channel 1~Channel 11)
• Europe - ETSI: 2412~2472MHz (Channel 1~Channel 13)
MODULATION TYPE
• OFDM, CCK
OPERATIONAL CHANNELS
• IEEE 802.11b compliant:
• 11 channels (US, Canada)
• 13 channels (ETSI)
• 14 channels (Japan)
• IEEE 802.11g compliant:
• 11 channels (US, Canada)
• 13 channels (Europe, Japan)
SECURITY
• 64/128-bit WEP
•WPA
•WPA2
ANTENNA
• Internal
TRANSMITTED POWER
Modulation Rate Output Power 2.4-2.5GHz (dBm)
802.11b - 1Mbps 16
802.11b - 2Mbps 16
802.11b - 5.5Mbps 16
802.11b - 11Mbps 16
Modulation Rate Output Power 2.4-2.5GHz (dBm)
802.11g - 6Mbps 14
802.11g - 9Mbps 14
802.11g - 12Mbps 14
802.11g - 18Mbps 14
802.11g- 24Mbps 13
802.11g - 36Mbps 13
802.11g- 48Mbps 12
802.11g - 54Mbps 12
RATES/SENSITIVITY/ALLOWABLE PATH LOSS
Modulation Rate Receiver Sensitivity (dBm) 2.412 ~ 2.484 GHz
802.11b - 1Mbps -92
802.11b - 2Mbps -89
802.11b - 5.5Mbps -85
802.11b- 11Mbps -82
Modulation Rate Receiver Sensitivity (dBm)
802.11g - 6Mbps -82
802.11g - 9Mbps -81
802.11g - 12Mbps -79
802.11g - 18Mbps -77
802.11g- 24Mbps -74
802.11g - 36Mbps -70
802.11g- 48Mbps -66
802.11g - 54Mbps -65
REGULATORY COMPLIANCE
•FCC
•ETSI/CE
•Industry Canada
•C-Tick
CURRENT CONSUMPTION
•TX: 485mA Max
•RX: 330mA Max
HOST INTERFACE
•USB 2.0
TEMPERATURE
•Operating: 0 ~ 45°C / 32° ~ 113°F ambient
•Storage: -20 ~ 70°C / -4° ~ 158°F ambient
HUMIDITY
•5 ~ 90% non-condensing
DIMENSION
•3.25 x 1.125 in / 82.5 x 28.5mm
WEIGHT
•0.06 lbs / 27g
North America
38 Tesla
Irvine, CA 92618
1-800-SMC-4YOU
24/7 Technical Support
Europe/ Africa
Fructuos Gelabert 6-8
08970 Sant Joan Despí
Barcelona, Spain
Check www.smc.com for your local
country contact information
